Please read this instruction booklet before using the appliance
UCTION BOOKLETUCTION BOOKLET
UCTION BOOKLET
UCTION BOOKLETUCTION BOOKLET
35678-9002
Mod. EGG 689
GB
Important Safety Information
You MUST read these warnings carefully before installing or using the hob. If you need
assistance, contact our Customer Care Department on 08705 950950
During Operation
•This appliance has been designed for non professional
purpose in private houses only. It is meant to cook
edible foodstuff only and must not be used for any
other purposes.
•It is dangerous to alter the specification in any way.
•For hygiene and safety reasons, this appliance should
be kept clean at all times. A build-up of fats or other
foodstuff could result in a fire.
•Do not use this hob if it is in contact with water. Do
not operate the hob with wet hands.
•Never leave the hob unattended when cooking with
oil and fats.
•Unstable or misshapen pans should not be used on
the hob as unstable pans can cause an accident by
tipping or spillage.
•Never use plastic or aluminium foil dishes on the hob.
•Perishable food, plastic items and areosols may be
affected by heat and should not be stored above or
below the hob unit.
•Under no circumstances should you attempt to repair
the appliance yourself. Repairs carried out by
unexperienced persons may cause injury or serious
malfunctioning. Refer to your local Service Centre.
Always insist on genuine spare parts.
•Ensure that all control knobs are in the OFF position
when not in use.
•Should you connect any electrical tool to a plug near
this cooking appliance, ensure that electric cables
are not in contact with it and keep them far enough
from the heated parts of this appliance.
•If the appliance is out of order, disconnect it from the
electric supply.
Child Safety
! This appliance is not intended for use by children or
other persons whose physical, sensory or mental
capabilities or lack of experience and knowledge
prevents them from using the appliance safely without
supervision or instruction by a responsible person to
ensure that they can use the appliance safely.
•This appliance has been designed to be operated by
adults and children under supervision. Young children
must not be allowed to tamper with the controls or
play near or with the oven.
•Accessible parts of this appliance may become hot
when it is in use. Children should be kept away until
it has cooled.
•Children can also injure themselves by pulling pans
or pots off the hob.
About Installation, Cleaning
and Manteinance
! It is mandatory that all operations required for the
installation are carried out by a qualified or competent
person, in accordance with existing rules and
regulations in force in the country where the appliance
is used.
•Ensure a good ventilation around the appliance. A poor
air supply could cause lack of oxygen.
•Ensure that the gas and electrical supply complies
with the type stated on the identification label, placed
near the gas supply pipe.
•This appliance is not connected to a combustion
products evacuation device. It must be installed and
connected in accordance with current installation
regulations. Particular attention shall be given to the
relevant requirements regarding ventilation.
•The use of a gas cooking appliance results in the
production of heat and moisture in the room in which
it is installed. Ensure that the kitchen is well ventilated:
keep natural ventilation holes open or install a
mechanical ventilation device (mechanical extractor
hood).
•Prolonged intensive use of the appliance may call for
additional ventilation, for example opening of a window,
or more effective ventilation, for example increasing
the level of mechanical ventilation where present.
•Once you removed all packaging from the appliance,
ensure that it is not damaged and the electric cable
is in perfect conditions. Otherwise, contact your dealer
before proceeding with the installation.
•Disconnect the appliance from the electrical supply,
before carrying out any cleaning or manteinance work.
•This appliance cannot be cleaned with steam or with
a steam cleaning machine.
•The residual heat indicator comes on when the
cooking zone is switched on. Children should be kept
away until it switches off.
•Never use the ceramic hob as a working space. Do
not store things on the ceramic hob.
•Never use plastic or aluminium foil dishes on the
ceramic hob, as they could melt on the hob, thus
damaging it. Anyway,If anything of this nature
accidentally comes into contact with the ceramic
surface it must be scraped off immediately while stlll
hot and wiped away to avoid damage to the surface.
In the same way, remove sugar or food residues with
hich sugar content, which may have split from
saucepans by using a scraper for ceramic hobs.
•Unstable or misshapen pans should not be used on
the ceramic hob as unstable pans can cause an
accident by tipping or spillage.
2
•The ceramic hob is shockproof, but not unbreakable!
Hard or pointed objects falling from a height can
damage the hob. If scratches or cracks are noticed,
disconnect the appliance from the electrical supply
to avoid the risk of electric shock and call you nearest
Service Force Centre.
Never use scratching sponges, abrasive products or
chemically powerful detergents. Use only cleaning
agents specific for ceramic hobs.
•The manufacturer disclaims any responsability should
all the safety measures not be carried out.
Contents
For the User
Important Safety Information2
Description of the Hob3
Operation4
Maintenance and Cleaning5
Service
! •Under no circumstances should you attempt to
repair the appliance yourself. Repairs carried out by
unexperienced persons may cause injury or serious
malfunctioning. Refer to your local Service Centre.
Always insist on genuine spare parts.
Environmental Information
! After installation, please dispose of the packaging
with due regard to safety and the environment.
•When disposing of an old appliance, make it unusable,
by cutting off the cable.
•The symbol
indicates that this product may not be treated as
household waste. Instead it shall be handed over to
the applicable collection point for the recycling of
electrical and electronic equipment. By ensuring this
product is disposed of correctly, you will help prevent
potential negative consequences for the environment
and human health, which could otherwise be caused
by inappropriate waste handling of this product. For
more detailed information about recycling of this
product, please contact your local city office, your
household waste disposal service or the shop where
you purchased the product.
The following symbols will be found in the text to guide
you throughout the Instructions:
Safety Instructions
Step by step instructions for an operation
"
Hints and Tips
Enviromental information
3
Description of the Hob
1
1. Hob top
2. Rapid Burner
3. Semi-rapid Burner
4. Auxiliary Burner
5. Control knobs
3
3
5
4
2
Operation
Hob burners
"
To light a burner:
! push in the relevant control and turn it to maximum
position;
! then adjust the flame as required.
! If the burner does not ignite, turn the control knob to
zero, and try again.
In the absence of electricity, ignition can occur
without the electrical device; in this case approach
the burner with a flame, push the relevant knob
down and turn it anti-clockwise until it reaches
the"maximum" position.
When switching on the mains, after installation or
a power cut, it is quite normal for the spark
generator to be activated automatically.
If the control knobs become difficult to turn, please
contact your local Electrolux Service Centre.
If you use a saucepan which is smaller than the
recommended size, the flame will spread beyond
the bottom of the vessel, causing the handle to
overheat.
Take care when frying food in hot oil or fat, as
the overheated splashes could easily ignite.
As soon as a liquid starts boiling, turn down the
flame so that it will barely keep the liquid simmering.
Prolonged cooking with potstones, earthenware
pans or cast-iron plates is inadvisable. Also, do
not use aluminium foil to protect the top during
use.
Make sure pots do not protrude over the edges
of the cooktop and that they are centrally
positioned on the rings in order to obtain lower
gas consumption.
Do not place unstable or deformed pots on the
rings: they could tip over or spill their contents,
causing accidents.
Pots must not enter the control zone.
As soon as a liquid starts boiling, turn down the
flame so that it will barely keep the liquid
simmering.
Use only pans or pots with flat bottom.
To ensure maximum burner efficiency, you should only
use pots and pans with a flat bottom fitting the size of
the burner used (see table).
Burnerminimummaximum
diameterdiameter
Large (rapid)160 mm.240 mm.
Medium (semi-rapid)120 mm.220 mm.
Small (auxiliary)80 mm.160 mm.
4
Maintenance and Cleaning
Before any maintenance or cleaning can be carried
out, you must DISCONNECT the hob from the
electricity supply.
The hob is best cleaned whilst it is still warm, as
spillage can be removed more easily than if it is
left to cool.
The Hob Top
Regularly wipe over the hob top and the aluminium frame
using a soft cloth well wrung out in warm water to which
a little washing up liquid has been added. Avoid the use
of the following:
- household detergent and bleaches;
- impregnated pads unsuitable for non-stick saucepans;
- steel wool pads;
- bath/sink stain removers.
Should the hob top become heavily soiled, it is
recommended that a cleaning product such as Hob Brite
or Bar Keepers Friend is used.
Pan Supports
The pan supports are dishwasher proof. If washing them
by hand, take care when drying them as the enamelling
process occasionally leaves rough edges.
If necessary, remove stubborn stains using a paste
cleaner. Never use steel wool pads or acids.
The Burners
The burner caps and crowns can be removed for cleaning.
Wash the burner caps and crowns using hot soapy water,
and remove marks with a mild paste cleaner. A well
moistened soap impregnated steel wool pad can be used
with caution, if the marks are particularly difficult to
remove.
After cleaning, be sure to wipe dry with a soft cloth.
Something Not Working?
If the hob is not working correctly, please carry out the following checks before contacting your local Service Force
Centre.
IMPORTANT:
a charge will be made even if the appliance is under guarantee.
SYMPTOM
# There is no spark when lighting the gas
# The gas ring burns unevenly
If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation,
SOLUTION
$ Check that the unit is plugged in and the electrical
supply is switched on
$ Check that the RCCB has not tripped (if fitted)
$ Check the mains fuse has not blown
$ Check the burner cap and crown have been
replaced correctly, e.g. after cleaning.
$ Check the main jet is not blocked and the burner
crown is clear of food particles.
$ Check the burner cap and crown have been
replaced correctly, e.g. after cleaning.
If after all these checks, your hob still does not operate
correctly, contact your local Service Force Centre.
Please note that it will be necessary to provide proof of
purchase for any in-guarantee service calls.
In-guarantee customers should ensure that the
above checks have been made as the engineer will
make a charge if the fault is not a mechanical or
electrical breakdown.
5
Loading...
+ 11 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
