AEG EBCSL9S, EBCSL90S, EBCSL9 User Manual

2 x

Start-up

Use

AnwendungAnwendung

- Press button with your finger tip –> set within 5 seconds!

Control panel

Have you already set the time? See page 7

P =Automatic programme 1-12

P =Memory function

(d =Demo function)

Microwave functions

Oven functions

Microwave power

Thermometer symbol

Duration

Weight display

Page

Roasting / Baking

Evt. switch off first with stop button

During operation...

Select oven function

the temperature can be changed

MEMORY FUNCTION

Possible to store a setting that will be used again and again.

Page

Microwave

Evt. switch off first with stop button

1 2

Microwave

Recommendation: Place your food on the glass baking tray on the bottom glass

While time passes by...

PROGRAMMED RECIPES

see baking and roasting chart and automatic programme

MEMORY FUNCTION

See roasting / baking

Page

power can be changed

Change durationPress clock function

General

Roasting / Baking

Baking dishes

- Place lean meat, venison, meat loaf directly on the roasting tray

- Light-coloured moulds extend baking/roasting times

- Place baking dishes/dishware on the griddle

- With hot air use baking ceramic/heat-resistant moulds

Frozen pastry

- Place the griddle lined with baking paper to avoid distortion of baking sheet (Temperature differences)

- Use professional tray*

(roasting tin, Pyrex or stoneware)

(e.g. Pizza)

(*optional accessories p. 7)

Grill

Grill with curve upwards to prevent slipping of roast/baking dish

Grill

- Do not insert very fatty grilled food too close under the heating element

- Close oven door when grilling

- Always supervise grilling

- If several items of food have to be grilled in succession; clean the griddle each time

Sauces

- Allow the gravy to brown slightly, then pour on hot water With a roasting time of over 1h: Do not add

gravy ingredients into the roasting tin until 1/2h before the end

Page

Baking area

As a shelf runner safety device, all insertable components have a small curved indentation at the bottom on the right and left-hand edge. Always insert insertable components so that this indentation is at the back of the oven interior.

Watt

Start

Oven function

Automatic programme

Microwave functions

Memory function

Do not place aluminium foil / aluminium tray on the oven base! The bottom glass is a work space for heating food / liquid and imperative for microwave oven operation!

Surface grill

Microwave generator

Oven light

- is switched on as soon as a function is started or the door is open

- goes out after 10 minutes when the door is open and appliance is switched off

Griddle guides (3 slot levels)

Rear panel heating element

Bottom glass (removable)

Keeping warm

min gr

Setting temperature and time

Clock functions

General

- If the chosen function is not started within 30 seconds, the appliance switches off.

- If the door opens during operation, the function stops -> close door and press start button within 30 seconds.

During/at the end of the operation

No function when door opened

Interrupting operation

Continue operation -> Press start button

Switch off appliance

Temperature display

Appliance heats up Temperature reached

If time / end is up

(2 min.)

BEEPBEEP

After switching off the appliance the fan runs until the temperature is less than 80 °C.

End Time Short time

Stop/reset

Appliance switches off automatically

Switch off BEEP: Press any button

1 2

Select function

Press button repeatedly...

HOT AIR

TURBOGRILL

SURFACE GRILL

BAKING & DEFROSTING

for…

- Pastry (up to 2 levels)

- Select temp. 15° C lower than indicated on recipes

- High joints

- Rollbraten (sliced roast pork)

- Poultry

- Gratins/casseroles

- etc.

- For flat grilled food such as steaks, cutlets, sausages, fish

- Grilled toast

- Melting marzipan/ice cream

- Overcrusting of casseroles

- Baking/drying of herbs, fruit, vegetables (1 to 2 levels,

change plates from time to time)

- Defrosting

Select poss. temperature

Select poss. time / end

(see clock function, p. 5)

Press «M» button for 2 seconds until signal is audible (for new function button press again for 2 seconds)

Start the memory function:

1. Call up memory storage with «M» button

2. Press start

Plates / grid

3 2 1

1 or 2 plates 1 plate: 1 or 2

2 plates: 1 + 3

1 grid + 1 plate

1 or 2 plates Presetting:

Grid: 1 or 2

Plate: 1 level below

Grid: 2 or 3

Plate: 1 level below

1 plate: 2

2 plates: 1 + 2

TemperaturSlot level

Presetting: 170 °C

Setting range: 30-250 °C

Presetting: 180 °C

Setting range: 30-250 °C

Presetting: 250 °C

Setting range: 30-250 °C

30 °C

Setting range: 30-100 °C

Start

(*optional accessories p. 7)

- The joint is cooked once it no longer holds down

- Leave the roast uncovered for about 10 minutes before slicing

Distance to heating element can be

varied up or down

by grid curve

- insert the baking tray below as a collection pan

- Line griddle with

baking paper

- Place dry food in single layers/close together

- Open oven every now and then, cool down half-way

- Dry sheets are particularly suitable

- Check degree of dryness

regularly (moist or crumbly)

132

Select power output (Watt)

In 100th steps, Press button repeatedly...

Power

1000 Watt

900 Watt 800 Watt 700 Watt

600 Watt 500 Watt

The power outputs given are standard values

Suitable for…

- Heating fluids

- Parboiling at the start of cooking process

- Cooking vegetables

- Cooking of food

- Melting of gelatine or butter

- Defrosting and heating frozen foods

- Heating meals

- Cooking stews

- Cooking scrambled eggs

Microwave Quick Start

Set operating time

Max. 7 min. on maximum microwave power output

Combinated functions

Set cooking time

Start

(Time)

At 700 W to 1000 W, 0 to 7 min. 40 secs At 100 W to 600 W, 0 to 59 min.

The appliance switches on with maximum microwave power output.

Do not overcooke food by power and time that is set too high. Meals can dry out, burn or inflame in specific places.

Setting see microwave

The microwave can be switched to the various heating forms of oven functions. Food is cooked in the shortest time and browned at the same time, See baking and roasting charted suitable dishware /material page 4

400 Watt 300 Watt 200 Watt

100 Watt - Defrosting meat, fish, bread

1 2 354

Select oven function

Set temperature

Select MW power output

TIP

Familiarize yourself with a similar food and adapt the cooking times according to the following rule:

Double the quantity = almost double the time Half the quantity = half the time

- Cooking meals further

- Cooking delicate meals

- Heating baby food

- Preparing rice

- Heating delicate meals

- Melting cheese

- Defrosting cheese, cream, butter

- Defrosting fruit and cakes (cream cakes)

- Leaving dough

- Heating cold meals and drinks

Notes for microwave

- Only operate microwave with food inside - never empty!

- Only use dishware suitable for microwave p. 4

- Place food on bottom glass or glass baking tray

- Always place coffee spoon or glass stirrer (accessory) in the container when heating fluid, in order to avoid boiling retardation (overcooking or splashing)

- Prick food with «peel» or «shell» ((e.g. potatoes, tomatoes, sausages) several times using a fork to prevent from bursting

- Do not cook eggs in their shells, they can crack.

- Do not use aluminium foil. When using convenience foods always see that there is a space in the container (sparking)

see «Safety instructions»

MEMORY FUNCTION

see «baking and roasting»

StartSet

cooking time

Microwave

- Leave meals to stand for a few minutes after switching off appliance

- Remove aluminium packaging, metal boxes before preparation

- Metal objects or aluminium backing foil must be at least 2 cm from the cooking area walls and door

Convenience foods

- Always observe the manufacturer’s instructions imprinted on the packaging

(*optional accessories p. 7)

Cooking

- Covered up as much as possible, only if it is to form crust, cook meals uncovered

- Chilled or frozen meals need longer cooking time

- Stir meals containing sauce from time to time

- Cook vegetables with solid texture (e.g. carrots, peas, cauliflower) with water

- Cut vegetables into big pieces

- Use flat, wide cookware

Keeping warm

In order to pre-heat dishware or keep meals warm

Select keep warm function (Temperature, approx. 80 °C, is controlled automatically)

- e.g. shift around once (up/down)

Suitable dishware / material

Dishware/Material

Fireproof glass and porcelain, glass baking tray (no metal parts, e.g. Pyrex, Jenaer Glas)

Non fireproof glass and porcelain 1)

Glass and glass ceramics made with fire /rustproof material (e.g. arcoflam), grill

Ceramics 2), stoneware 2)

Heat-resistant plastic up to 200 °C

Cardboard, paper

Cling film

Roasting film with seal suitable for microwave use 3)

Roasting ovenware made in metal e.g. enamel, cast iron

Baking dishes, varnished in black or silicon-coated 3)

Baking tray

Crostinoplate (optional accessories p. 7)

Packaged convenience foods 3)

1) without silver, gold, platinum or metal plating / decorations

2) without crystal or metal parts, no glaze containing metal

3) please observe maximum temperatures given by the manufacturer

- When heating food in the microwave, stir/turn continuously, as heat is generated in the food itself and not all places are heated simultaneously.

- Leave food standing inside or outside the appliance, so that heat is distributed evenly.

Defrost

Meat, Poultry, fish:

- Place frozen, unwrapped food on small plate turned upside down with tin below and turn half way through the defrosting time

Butter, slice of cake, quark:

- Leave to defrost at room temperature, not completely in appliance

Fruit, vegetable:

- If it is raw processed, defrost at room temperature, and not completely in appliance

- If the fruit and vegetables are to be cooked, directly with higher microwave power, the output can be changed.

Switch on- arrange dishware evenly

Breakpoint/ switch off

Microwave

Defrost Heat Cooking

Oven

Grill

Watt

min gr

Clock functions

- After setting a time, symbol flashes for 5 sec., afterwards the time, short time or duration is illuminated, and the time starts.

- While the corresponding symbol flashes (5 sec.): Set/change times

- By repeated touch the current time can be prompted

DURATION / END can be used simultaneously, if:

- the oven shall be switched on and off automatically at the later time

- a programme is selected.

DURATION

END

When will the meal be ready?

(first select oven function)

Duration MICROWAVE

0 to 23 hrs 59 min.

set duration

set time

set duration

Short time

No impact on microwave / oven operation

Time

Time can only be faded out, if no other display is active!

Is the time faded out:

- Display is illuminated when switched on

- Display goes out when switched off

0 to 99 minutes

change (e.g. Summer-/ Wintertime)

set

fading in/out

Switching off Press off button at the same

Duration

time for about 2 seconds until display goes out/lights up

Child lock

Button locking mechanism

Switching off

No function can be selected!

Press the off switch at the same time for about 2 seconds, until the display goes out/lights up

Child lock on

Press the same button again for about 2 seconds in order to switch off child lock!

Buttons-signal

Switching on/off

Switching off

Press simultaneously for about 2 seconds until the signal is audible

Press the same button again for about 2 seconds in order to switch on the signal again!

Automatic switch off

Page

End Time Short time

Cleaning and care

While cleaning griddle guides, lamp glass and oven door, ensure no heating elements are switched on. The oven has to be cooled down so as to be able to touch the central panels safely. Only the oven light must be switched on.

NEVER use high pressure cleaning devices for the oven!

Clean the appliance thoroughly and frequently! Avoid repeated burning of residue.

Cleanemail oven

- Do not use fine steel wool, scratching and scrubbing cleaning agents!

- You can use commercially available oven spray. Observe the manufacturer’s instructions

-> Wash the inside of the oven with warm detergent lye or vinegar cleaner and a sponge/cloth TIP: Clean the chrome parts in the oven interior with a non-scratch / non-abrasive cleaning sponge (obtainable from large distributors). No steel wool or stainless steel scourers.

- Always keep the door seal, door seal surface and the inside clean. Lack of appliance cleanliness can lead to hazardous situations.

Control panel + oven door

- no aggressive/acidic or glass-ceramics cleaning agent

- no steel wool / pot cleaner

Cleaning movements

TIP: Clean with a soft, clean, moist micro-fibre cloth!!

- Only wash inside panel with hot detergent

- Soak severe residue

- Keep rubber seals clean and do not damage!

Do not graze glass interior with a knife, scotch brite etc

Remove griddle guides

Fit and unhinge griddle guides

Assembly: In reverse order.

Clean accessory

Clean with hot detergent lye (not suitable for dishwashers)

Wash with a soft brush in hot detergent lye.

Clean bottom glass after each use with a soft brush in hot detergent or in dishwater. For stubborn dirt soak in hot lye, possibly use glass scraper

No rotating movements when cleaning, as surfaces will be damaged!

Alulook outside surfaces:Outside surfaces chromium steel smoothed:

- If necessary a commercially available chromium steel cleaner can be used -> Observe manufacturer’s instructions in using these cleaning agents!

Page

Start-up

Set time

After electrical connection/ power breakdown the time symbol flashes

Set current time

After 5 seconds the flashing stops And time shows the time

Demo Mode

To test or carry out all operating modes. The oven does not heat.

1 2

Switch off appliance

Press simultaneously for about 2 seconds until the signal is audible!

Initial cleaning

Take out accessories and rinse (p. cleaning + service p. 6)

Initial heating

Clean with water + detergent –> see Cleaning + service p. 6)

12 3

Select «hot air» set 250° C

Preheating

Because set temperatures are reached very quickly, preheating is unnecessary for most programmes...

Close oven door and start

Operate closed 60 mins, switch off again

Recommendation preheating at:

- Meat dishes / short slices of meat (fillet, sirloin, cutlet, chops)

-> Meat pores close faster and roast meat remains juicy

- Cookies diverging slightly, bread roll, pastries, biscuit rolls

- Use in combination with microwave

Accessories (standard equipment)

Griddle guide*

*Not for microwave operation

Optional accessories

Baking/Roast/Grill

Glass baking tray for microwave operation

For further instructions see «Suitable dishware / material», p. 4

The oven only works with the time set!

Press the same button again for about 2 seconds to turn off Demo mode!

Switch on the Demo Mode

Remove objects from the oven! Not the type plate

Air the area well during initial heating phase.

Open window!

Glass bottom plate Glass stirrer

Page

Built-in Compact Oven

Hot air, microwave, grill

INSTRUCTIONS FOR USE

EBC SL9(S)

(55 cm)

EBC SL90(S)

(60 cm)

The documentation for the compact oven is 3-part: Instructions for use, baking / roasting chart and supplementary technical sheet. The safety instructions in the supplementary technical sheet are an integral part of this documentation.

Do not operate the appliance until you have read all documents and safety instructions. In order to guarantee that you have taken note of the content of these instructions, we request that you send the complete warranty card to Customer Service in Mägenwil. Please hand these instructions to anyone who may use this appliance.

If the function and temperature is set WITHOUT time restriction,the oven switches off automatically as follows:

at 30 - 120 °C at 120 - 200 °C at 200 - 250 °C

after 12,5 h after 8,5 h after 5,5 h

«OFF» appears in the display

Start-up after automatic switch off: Switch off oven completely, it can be restarted afterwards.

No microwave operation on bottom glass!

Subject to technical modifications

Crostino plate (non-scratch / firm, non-stick)

CP 28

Pastry/baked goods professional plate Drying/Baking (non-stick)

PB 426 S

05/2007
