AEG DL6250ML/S User Manual

DL 6250 -ml

Köksfläkt
Ventilator
Liesituuletin
Emhætte
Cooker Hood

Instruktionsbok
Bruksanvisning
Käyttöohje
Brugsvejledning
Operating and Installation Instructions

S Innehållsförteckning ............................................................2

N Innholdsfortegnelse...........................................................13

FIN Sisällysluettelo ..................................................................24

DK Indholdsfortegnelse ...........................................................35

UK Contents............................................................................47

Contents

Safety instructions ............................................................................ 47

Description of the cooker hood .......................................................... 48

Using the cooker hood ...................................................................... 4 9

Maintenance and cleaning................................................................. 50

If the cooker hood will not operate ..................................................... 53

T echnical data................................................................................... 55

Installation ........................................................................................ 55

Safety instructions

This appliance is to be used solely as a household appliance. It has
been manufactured according to the international safety and quality
standards. Note that the safety devices alone are not capable of
eliminating all accident risks.
It is therefore very important to carefully read all the operating
instructions, recommendations and warnings prior to installation and
use of the appliance. Note in particular the text paragraphs with the
danger triangle design, to avoid damages to persons or objects.
Keep this instruction booklet in a safe place: this booklet should
always accompany the appliance at such time as it is sold or given to
other persons for use.

Installation and service

• Any electrical installation of the cooker hood must be carried out by
a qualified electrician and the hood itself must be installed by
someone with experience. Installation made by an unqualified
person can lead to loss of function of the cooker hood and possible
damage to person and and/or property .

• The cooker hood must be at least 60 cm above electric hobs or
electric ranges, or at least 65 cm above gas burners or gas ranges.

• Ensure that the power cable is not damaged during installation.

• The cooker hood is only in stand by mode unless the plug or the

fuse is disconnected.

• The cooker hood cannot be connected to flues of other appliances
that run on energy sources other than electricity . Please, keep to the
provisions of official directives regarding fume discharge.

47

Use of cooker hood

• This appliance is for domestic use only in a normal household.

• Never leave any deep-frying, melting fat, paraffin or any other

inflammable liquid unattended on the hob. In the event of fire:
Immediately switch off the cooker hood and the cooker. Note!

Cover the fire. Never use water.

• Never do any flambé cooking underneath the cooker hood. It can
cause a fire. Remember that overheated fat may spontaneously
ignite. Never leave the frying pan unattended.

• It is essential that the grease filter is regularly cleaned to help avoid
fat dripping on to the hot zone and causing a fire. Read the section
on “Maintenance and Cleaning” in the instruction book.

Disposal

• Prevent accidents when disposing of your cooker hood. Disconnect
the power plug from the wall socket and cut the power cord at the
hood inlet.Contact your local authority for information on where to
dispose the cooker hood.

Description of the cooker hood

Functions

There are two possible systems:

• Extraction of air to the outside using
an optional venting kit and evacuation duct.

• Recirculation using an optional
carbon filter.

Accessories

The following are included with the cooker hood.

• 1 hood canopy complete with controls, lighting and fan motor.

• 1 Adaptor Ø 120 mm.

• 1 Adaptor Ø 120-100 mm.

• 1 plastic bag containing: documentation, screws to fix the hood.

The following can be ordered from your retailer:

• Charcoal filter, KFL 60/80 (should be replaced every year).

or

• Charcoal filter, KF8 (typ 150 – can be regenerated and should be
replaced every 3 years).

The carbon filter is to be used when the hood is connected to the
recirculation mode.

48

Extraction

Recirculation

Fig. 1

Using the cooker hood

The control panel

Best results are obtained by using a low speed for normal conditions
and high speed when odours are more concentrated.
Turn the hood on a few minutes before you start cooking then you will
get an underpressure in the kitchen. It should be left on after cooking
for about 15 minutes or until all odours have disappeared.The
switches are located on the right-hand side of the hood.

• the light switch switches the hood lamp on and off.

• the motor switch switches the cooking smoke and vapour extractor

motor on and off, enabling you to select the speed.

Light switch

= Light OFF
= Light ON

Motor switch

0 =Continuously
variable blower
control

Fig. 2

Correct ventilation

If the cooker hood is to work correctly there must be an underpressure
in the kitchen. It is important to keep the kitchen windows closed and
have a window in an adjacent room open.

Important to know

Not applicable for recirculation. Great care must be taken if the hood is
used at the same time as a burner or fireplace (e.g. gas, diesel, coal or
wood heaters, water heaters, etc.), as the hood will expel air which is
required by these other appliances. Attend to it by opening a window.
The negative pressure in the room must not exceed 0,04 mbar to
prevent fumes being drawn back into the room by the cooker hood.

49

Maintenance and cleaning

Disconnect the cooker hood from the power supply prior to
cleaning the appliance, either by removing the plug from the mains
or removing the fuse.

Clean the filter regularly . The grease deposits in the filter and
discharge tube are fire hazards where a hotplate (or another heat
source) is left on by error.

Cleaning the hood

Clean the outside of the hood using a damp cloth and a mild
detergent.
Never use corrosive, abrasive or flammable cleaning products.

Cleaning the grease filters

Clean the filter every month or every other month according to how
much the hood is used. The cleaner the filters, the more grease they
collect. To remove the filters:

• Press the handle Q that locks the grease filter N first towards the
opposite side and then extract downwards. Fig. 3.

The filter is made of aluminium wires on which the grease collects.
Clean the filter in hot water using a detergent, or in a dishwasher. Let
the filter dry before putting it back. Note that a dishwasher may
discolour the filter.

Q

N

Fig. 3

Carbon filter

• The activated carbon filter should only be used if you want to use
the hood in its filtering function.

• To do this you will need an original AEG activated carbon filter (see
special accessories).

• The carbon filters absorb smells and odours.

50
