AEG CIB6640ABM User manual
USER
MANUAL
CIB6640ABM
EN User Manual
Cooker
www.aeg.com
2
CONTENTS
1. SAFETY INFORMATION.............................................................................................2
2. SAFETY INSTRUCTIONS.............................................................................................5
3. PRODUCT DESCRIPTION...........................................................................................8
4. BEFORE FIRST USE..................................................................................................... 9
5. HOB - DAILY USE........................................................................................................ 9
6. HOB - HINTS AND TIPS............................................................................................14
7. HOB - CARE AND CLEANING................................................................................. 15
8. OVEN - DAILY USE ...................................................................................................16
9. OVEN - CLOCK FUNCTIONS...................................................................................18
10. OVEN - HINTS AND TIPS....................................................................................... 20
11. OVEN - CARE AND CLEANING............................................................................ 32
12. TROUBLESHOOTING.............................................................................................35
13. INSTALLATION........................................................................................................37
14. ENERGY EFFICIENCY.............................................................................................39
FOR PERFECT RESULTS
Thank you for choosing this AEG product. We have created it to give you
impeccable performance for many years, with innovative technologies that help
make life simpler features you might not find on ordinary appliances. Please
spend a few minutes reading to get the very best from it.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.aeg.com/webselfservice
Register your product for better service:
www.registeraeg.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.aeg.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the
following data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
SAFETY INFORMATION
1.
Before the installation and use of the appliance,
carefully read the supplied instructions. The
ENGLISH
manufacturer is not responsible for any injuries or
damages that are the result of incorrect installation or
usage. Always keep the instructions in a safe and
accessible location for future reference.
1.1 Children and vulnerable people safety
WARNING!
Risk of suffocation, injury or permanent
disability.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning the use of the appliance in a
safe way and understand the hazards involved.
• Children between 3 and 8 years of age and persons
with very extensive and complex disabilities shall be
kept away unless continuously supervised.
• Children of less than 3 years of age should be kept
away unless continuously supervised.
• Do not let children play with the appliance.
• Keep all packaging away from children and dispose of
it appropriately.
• Keep children and pets away from the appliance when
it operates or when it cools down. Accessible parts are
hot.
• If the appliance has a child safety device, it should be
activated.
• Children shall not carry out cleaning and user
maintenance of the appliance without supervision.
3
General Safety
1.2
• Only a qualified person must install this appliance and
replace the cable.
• This appliance must be connected to the mains with a
H05VV-F type cable to withstand the temperature of
the rear panel.
4
www.aeg.com
• This appliance is intended for use up to an altitude of
2000 m above sea level.
• This appliance is not intended to be used on a ships,
boats or vessels.
• Do not install the appliance behind a decorative door
in order to avoid overheating.
• Do not install the appliance on a platform.
• Do not operate the appliance by means of an external
timer or separate remote-control system.
• WARNING: Unattended cooking on a hob with fat or
oil can be dangerous and may result in fire.
• NEVER try to extinguish a fire with water, but switch
off the appliance and then cover flame e.g. with a lid
or a fire blanket.
• CAUTION: The cooking process has to be supervised.
A short term cooking process has to be supervised
continuously.
• WARNING: Danger of fire: Do not store items on the
cooking surfaces.
• Do not use a steam cleaner to clean the appliance.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the glass door or the glass of hinged
lids of the hob since they can scratch the surface,
which may result in shattering of the glass.
• Metallic objects such as knives, forks, spoons and lids
should not be placed on the hob surface since they
can get hot.
• If the glass ceramic surface / glass surface is cracked,
switch off the appliance and unplug it from the mains.
In case the appliance is connected to the mains
directly using junction box, remove the fuse to
disconnect the appliance from power supply. In either
case contact the Authorised Service Centre.
• After use, switch off the hob element by its control
and do not rely on the pan detector.
• WARNING: The appliance and its accessible parts
become hot during use. Care should be taken to
avoid touching heating elements.
ENGLISH
• Always use oven gloves to remove or put in
accessories or ovenware.
• Before maintenance cut the power supply.
• Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric
shock.
• If the mains power supply cable is damaged, it must
be replaced by the manufacturer, its Authorised
Service Centre or similarly qualified persons to avoid
an electrical hazard.
• Be careful when you touch the storage drawer. It can
get hot.
• To remove the shelf supports first pull the front of the
shelf support and then the rear end away from the
side walls. Install the shelf supports in the opposite
sequence.
• The means for disconnection must be incorporated in
the fixed wiring in accordance with the wiring rules.
• WARNING: Use only hob guards designed by the
manufacturer of the cooking appliance or indicated by
the manufacturer of the appliance in the instructions
for use as suitable or hob guards incorporated in the
appliance. The use of inappropriate guards can cause
accidents.
5
2.
SAFETY INSTRUCTIONS
2.1 Installation
WARNING!
Only a qualified person must
install this appliance.
• Remove all the packaging.
• Do not install or use a damaged
appliance.
• Follow the installation instructions
supplied with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use
safety gloves and enclosed footwear.
• Do not pull the appliance by the
handle.
• The kitchen cabinet and the recess
must have suitable dimensions.
• Keep the minimum distance from
other appliances and units.
• Install the appliance in a safe and
suitable place that meets installation
requirements.
• Parts of the appliance carry current.
Close the appliance with furniture to
prevent touching the dangerous
parts.
• The sides of the appliance must stay
next to appliances or units with the
same height.
• Do not install the appliance adjacent
to a door or under a window. This
prevents hot cookware to fall from the
www.aeg.com6
appliance when the door or the
window is opened.
• Make sure to install a stabilizing
means in order to prevent tipping of
the appliance. Refer to Installation
chapter.
2.2 Electrical Connection
WARNING!
Risk of fire and electric
shock.
• All electrical connections should be
made by a qualified electrician.
• The appliance must be earthed.
• Make sure that the parameters on the
rating plate are compatible with the
electrical ratings of the mains power
supply.
• Always use a correctly installed
shockproof socket.
• Do not use multi-plug adapters and
extension cables.
• Do not let mains cables touch or
come near the appliance door,
especially when the door is hot.
• The shock protection of live and
insulated parts must be fastened in
such a way that it cannot be removed
without tools.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• If the mains socket is loose, do not
connect the mains plug.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Use only correct isolation devices: line
protecting cut-outs, fuses (screw type
fuses removed from the holder), earth
leakage trips and contactors.
• The electrical installation must have
an isolation device which lets you
disconnect the appliance from the
mains at all poles. The isolation
device must have a contact opening
width of minimum 3 mm.
• Fully close the appliance door, before
you connect the mains plug to the
mains socket.
2.3 Use
WARNING!
Risk of injury and burns.
Risk of electrical shock.
• This appliance is for household use
only.
• Do not change the specification of
this appliance.
• Make sure that the ventilation
openings are not blocked.
• Do not let the appliance stay
unattended during operation.
• Deactivate the appliance after each
use.
• Be careful when you open the
appliance door while the appliance is
in operation. Hot air can release.
• Do not operate the appliance with
wet hands or when it has contact with
water.
• Do not use the appliance as a work
surface or as a storage surface.
• Users with a pacemaker must keep a
distance of minimum 30 cm from the
induction cooking zones when the
appliance is in operation.
WARNING!
Risk of fire and explosion
• Fats and oil when heated can release
flammable vapours. Keep flames or
heated objects away from fats and oils
when you cook with them.
• The vapours that very hot oil releases
can cause spontaneous combustion.
• Used oil, that can contain food
remnants, can cause fire at a lower
temperature than oil used for the first
time.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Do not let sparks or open flames to
come in contact with the appliance
when you open the door.
• Open the appliance door carefully.
The use of ingredients with alcohol
can cause a mixture of alcohol and air.
WARNING!
Risk of damage to the
appliance.
ENGLISH
7
• To prevent damage or discoloration
to the enamel:
– do not put ovenware or other
objects in the appliance directly
on the bottom.
– do not put water directly into the
hot appliance.
– do not keep moist dishes and
food in the appliance after you
finish the cooking.
– be careful when you remove or
install the accessories.
• Discoloration of the enamel or
stainless steel has no effect on the
performance of the appliance.
• Use a deep pan for moist cakes. Fruit
juices cause stains that can be
permanent.
• Do not keep hot cookware on the
control panel.
• Do not let cookware boil dry.
• Be careful not to let objects or
cookware fall on the appliance. The
surface can be damaged.
• Do not activate the cooking zones
with empty cookware or without
cookware.
• Do not put aluminium foil on the
appliance or directly on the bottom of
the appliance.
• Cookware made of cast iron,
aluminium or with a damaged bottom
can cause scratches. Always lift these
objects up when you have to move
them on the cooking surface.
• This appliance is for cooking
purposes only. It must not be used for
other purposes, for example room
heating.
2.4 Care and Cleaning
WARNING!
Risk of injury, fire, or damage
to the appliance.
• Before maintenance, deactivate the
appliance.
Disconnect the mains plug from the
mains socket.
• Make sure the appliance is cold.
There is the risk that the glass panels
can break.
• Replace immediately the door glass
panels when they are damaged.
Contact the Authorised Service
Centre.
• Be careful when you remove the door
from the appliance. The door is
heavy!
• Fat and food remaining in the
appliance can cause fire.
• Clean regularly the appliance to
prevent the deterioration of the
surface material.
• Make sure the cavity and the door are
wiped dry after each use. Steam
produced during the operation of the
appliance condensates on cavity walls
and can cause corrosion. To decrease
the condensation operate the
appliance for 10 minutes before
cooking.
• Clean the appliance with a moist soft
cloth. Only use neutral detergents. Do
not use any abrasive products,
abrasive cleaning pads, solvents or
metal objects.
• If you use an oven spray, obey the
safety instructions on the packaging.
• Do not clean the catalytic enamel (if
applicable) with any kind of
detergent.
2.5 Internal lighting
WARNING!
Risk of electric shock.
• The type of light bulb or halogen
lamp used for this appliance is for
household appliances only. Do not
use it for house lighting.
• Before replacing the lamp, disconnect
the appliance from the power supply.
• Only use lamps with the same
specifications.
2.6 Service
• To repair the appliance contact an
Authorised Service Centre.
• Use original spare parts only.
2.7 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
5
4
3
2
1
5
8
10
1 3
2 4
6
7
9
210 mm
180 mm
140 mm
180 mm
1 3
6 4
5
2
www.aeg.com8
• Cut off the mains electrical cable
close to the appliance and dispose of
it.
3. PRODUCT DESCRIPTION
3.1 General overview
3.2 Cooking surface layout
• Remove the door catch to prevent
children or pets from becoming
trapped in the appliance.
Knob for the heating functions
1
Display
2
Control knob (for the temperature)
3
Temperature indicator / symbol
4
Heating element
5
Lamp
6
Shelf support, removable
7
Fan
8
Cavity embossment
9
Shelf positions
10
Induction cooking zone 1400 W with
1
the PowerBoost 2500 W
Steam outlet - number and position
2
depend on the model
Induction cooking zone 1800 W with
3
the PowerBoost 2800 W
Induction cooking zone 1800 W with
4
the PowerBoost 2800 W
Control panel
5
Induction cooking zone 2300 W with
6
the PowerBoost 3600 W
3.3 Accessories
• Wire shelf
• Baking tray
• Grill- / Roasting pan
For cookware, cake tins, roasts.
For cakes and biscuits.
To bake and roast or as pan to collect
fat.
• Storage drawer
The storage drawer is below the oven
cavity.
4. BEFORE FIRST USE
ENGLISH 9
WARNING!
Refer to Safety chapters.
4.1 Initial Cleaning
Remove all accessories and removable
shelf supports from the oven.
Refer to "Care and cleaning" chapter.
Clean the oven and the accessories
before the first use.
Put the accessories and the removable
shelf supports back to their initial
position.
4.2 Using the sensor fields
To activate a function touch and hold the
selected symbol on the display for
minimum 1 second.
4.3 Setting the time
You must set the time before you
operate the oven.
The flashes when you connect the
appliance to the electrical supply, when
there was a power cut or when the timer
is not set.
Press the
time.
After approximately five seconds, the
flashing stops and the display shows the
time of day you set.
or to set the correct
4.4 Changing the time
You cannot change the time
of day if the Duration or
End function operates.
Press again and again until the
indicator for the Time of Day function
flashes.
To set a new time, refer to "Setting the
time".
4.5 Preheating
Preheat the empty oven before first use.
1. Set the function .Set the maximum
temperature.
2. Let the oven operate for 1 hour.
3. Set the function . Set the
maximum temperature.
4. Let the oven operate for 15 minutes.
5.
Set the function
maximum temperature.
6. Let the oven operate for 15 minutes.
7. Turn off the oven and let it cool
down.
Accessories can become hotter than
usual. The oven can emit an odour and
smoke. Make sure that the airflow in the
room is sufficient.
. Set the
HOB - DAILY USE
5.
WARNING!
Refer to Safety chapters.
642 3
8 7
51
10 9
www.aeg.com10
5.1 Hob control panel
Use the sensor fields to operate the appliance. The displays, indicators and sounds tell
which functions operate.
Sensor
field
1
2
3
- Heat setting display To show the heat setting.
4
- Timer indicators of cooking
5
- Timer display To show the time in minutes.
6
7
8
9
- Control bar To set a heat setting.
10
Function Comment
ON / OFF To activate and deactivate the hob.
Lock / Child Safety Device To lock / unlock the control panel.
STOP+GO To activate and deactivate the function.
zones
- To select the cooking zone.
- To increase or decrease the time.
/
PowerBoost To activate and deactivate the function.
5.2 Heat setting displays
Display Description
The cooking zone is deactivated.
To show for which zone you set the time.
-
The cooking zone operates.
STOP+GO operates.
Automatic Heat Up operates.
Display Description
PowerBoost operates.
ENGLISH
11
+ digit
/ /
There is a malfunction.
OptiHeat Control (3 step Residual heat indicator): continue cooking /
keep warm / residual heat.
Lock / Child Safety Device operates.
Incorrect or too small cookware or no cookware on the cooking zone.
Automatic Switch Off operates.
5.3 OptiHeat Control (3 step Residual heat indicator)
WARNING!
/ / There is a risk of
burns from residual heat.
The indicators show the level
of the residual heat for the
cooking zones you are
currently using. The
indicators may also come on
for the neighbouring
cooking zones even if you
are not using them.
The induction cooking zones produce
the heat necessary for the cooking
process directly in the bottom of the
cookware. The glass ceramic is heated by
the heat of the cookware.
5.4 Activating and deactivating
Touch for 1 second to activate or
deactivate the hob.
5.5 Automatic Switch Off
The function deactivates the hob
automatically if:
• all cooking zones are deactivated,
• you do not set the heat setting after
you activate the hob,
• you spill something or put something
on the control panel for more than 10
seconds (a pan, a cloth, etc.). An
acoustic signal sounds and the hob
deactivates. Remove the object or
clean the control panel.
• the hob gets too hot (e.g. when a
saucepan boils dry). Let the cooking
zone cool down before you use the
hob again.
• you use incorrect cookware. The
symbol comes on and the cooking
zone deactivates automatically after 2
minutes.
• you do not deactivate a cooking zone
or change the heat setting. After
some time comes on and the hob
deactivates.
The relation between the heat setting
and the time after which the hob
deactivates:
Heat setting The hob deacti-
vates after
1 - 3 6 hours
4 - 7 5 hours
8 - 9 4 hours
10 - 14 1.5 hour
5.6 The heat setting
To set or change the heat setting:
Touch the control bar at the correct heat
setting or move your finger along the
control bar until you reach the correct
heat setting.
12
www.aeg.com
5.7 Automatic Heat Up
Activate this function to get a desired
heat setting in a shorter time. When it is
on, the zone operates on the highest
setting in the beginning and then
continues to cook at the desired heating
setting.
To activate the function the
cooking zone must be cold.
To activate the function for a cooking
zone: touch
Immediately touch a desired heat
setting. After 3 seconds comes on.
To deactivate the function: change the
heat setting.
( comes on).
5.8 PowerBoost
This function makes more power
available to the induction cooking zones.
The function can be activated for the
induction cooking zone only for a limited
period of time. After this time the
induction cooking zone automatically
sets back to the highest heat setting.
To activate the function for a cooking
zone: touch . comes on.
To deactivate the function: change the
heat setting.
5.9 Timer
Count Down Timer
You can use this function to set how long
the cooking zone should operate for a
single cooking session.
First set the heat setting for the cooking
zone then set the function.
To set the cooking zone: touch
again and again until the indicator of a
necessary cooking zone comes on.
To activate the function: touch of
the timer to set the time (00 - 99
minutes). When the indicator of the
cooking zone starts to flash slowly the
time counts down.
To see the remaining time: set the
cooking zone with
the cooking zone starts to flash quickly.
The display shows the remaining time.
To change the time: set the cooking
zone with . Touch or .
To deactivate the function: set the
cooking zone with and touch . The
remaining time counts back to 00. The
indicator of the cooking zone goes out.
When the time comes to an
end, the sound operates and
00 flashes. The cooking zone
deactivates.
To stop the sound: touch .
CountUp Timer (The count up timer)
You can use this function to monitor how
long the cooking zone operates.
To set the cooking zone: touch
again and again until the indicator of a
necessary cooking zone comes on.
To activate the function: touch of
the timer.
indicator of the cooking zone starts to
flash slowly the time counts up. The
display switches between and
counted time (minutes).
To see how long the cooking zone
operates: set the cooking zone with .
The indicator of the cooking zone starts
to flash quickly. The display shows how
long the zone operates.
To deactivate the function: set the
cooking zone with
. The indicator of the cooking zone
goes out.
Minute Minder
You can use this function as a Minute
Minder when the hob is activated and
comes on. When the
. The indicator of
and touch or
ENGLISH
13
the cooking zones do not operate. The
heat setting display shows .
To activate the function: touch .
Touch or of the timer to set the
time. When the time comes to an end,
the sound operates and 00 flashes.
To stop the sound: touch .
The function has no effect
on the operation of the
cooking zones.
5.10 STOP+GO
This function sets all cooking zones that
operate to the lowest heat setting.
When the function operates, you cannot
change the heat setting.
The function does not stop the timer
functions.
To activate the function: touch .
comes on.
To deactivate the function: touch
The previous heat setting comes on.
.
5.11 Lock
You can lock the control panel while
cooking zones operate. It prevents an
accidental change of the heat setting.
Set the heat setting first.
To activate the function: touch .
comes on for 4 seconds. The Timer stays
on.
To deactivate the function: touch .
The previous heat setting comes on.
When you deactivate the
hob, you also deactivate this
function.
5.12 Child Safety Device
This function prevents an accidental
operation of the hob.
To activate the function: activate the
hob with . Do not set the heat setting.
Touch for 4 seconds. comes on.
Deactivate the hob with .
To deactivate the function: activate the
hob with
Touch for 4 seconds. comes on.
Deactivate the hob with .
To override the function for only one
cooking time: activate the hob with
comes on. Touch for 4 seconds.
Set the heat setting in 10 seconds. You
can operate the hob. When you
deactivate the hob with the function
operates again.
. Do not set the heat setting.
5.13 OffSound Control
(Deactivating and activating
the sounds)
Deactivate the hob. Touch
seconds. The display comes on and goes
out. Touch
comes on. Touch of the timer to
choose one of the following:
• - the sounds are off
- the sounds are on
•
To confirm your selection wait until the
hob deactivates automatically.
When the function is set to you can
hear the sounds only when:
• you touch
• Minute Minder comes down
• Count Down Timer comes down
• you put something on the control
panel.
for 3 seconds. or
for 3
5.14 Power management
function
• Cooking zones are grouped
according to the location and number
of the phases in the hob. See the
illustration.
• Each phase has a maximum electricity
load.
• The function divides the power
between cooking zones connected to
the same phase.
• The function activates when the total
electricity loading of the cooking
.
www.aeg.com
14
zones connected to a single phase is
exceeded.
• The function decreases the power to
the other cooking zones connected to
the same phase.
• The heat setting display of the
reduced zones changes between two
levels.
6. HOB - HINTS AND TIPS
WARNING!
Refer to Safety chapters.
6.1 Cookware
For induction cooking zones
a strong electro-magnetic
field creates the heat in the
cookware very quickly.
Use the induction cooking
zones with suitable
cookware.
Cookware material
• correct: cast iron, steel, enamelled
steel, stainless steel, multi-layer
bottom (with a correct marking from a
manufacturer).
• not correct: aluminium, copper,
brass, glass, ceramic, porcelain.
Cookware is suitable for an induction
hob if:
• water boils very quickly on a zone set
to the highest heat setting.
• a magnet pulls on to the bottom of
the cookware.
The bottom of the cookware
must be as thick and flat as
possible.
Ensure pan bases are clean
and dry before placing on
the hob surface.
Cookware dimensions
Induction cooking zones adapt to the
dimension of the bottom of the
cookware automatically.
The cooking zone efficiency is related to
the diameter of the cookware. The
cookware with a diameter smaller than
the minimum receives only a part of the
power generated by the cooking zone.
6.2 Minimum cookware diameter
Cooking zone Cookware diam-
eter (mm)
Left rear 125 - 140
Right rear 145 - 180
Right front 145 - 180
Left front 180 - 210
6.3 The noises during operation
If you can hear:
• crack noise: cookware is made of
different materials (a sandwich
construction).
• whistle sound: you use a cooking
zone with a high power level and the
cookware is made of different
materials (a sandwich construction).
• humming: you use a high power level.
• clicking: electric switching occurs.
• hissing, buzzing: the fan operates.
The noises are normal and do not
indicate any malfunction.
Loading...
