Advantech TPC130UHFRFID User Manual

User Manual

Fully-Rugged Tablet PC

Optional Accessories

PWS-870

Copyright

The documentation and the software included with this product are copyrighted 2012
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable.
However,
Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringements
of the rights of third parties, which may result from its use.

Acknowledgements

All other product names or trademarks are properties of their respective owners.

Declaration of Conformity

CE Conformity Statement

Radio products with the CE alert marking comply with the R&TTE Directive (1999/5/
EC) issued by the Commission of the European Community. Compliance with this
directive implies conformity to the following European Norms (in brackets are the
equivalent international standards)
 EN 60950-1 (IEC60950-1) - Product Safety
Products that contain the radio transmitter are labeled with CE alert marking and may
also carry the CE logo.

FCC Compliance Statement

This device complies with part 15 of the FCC Rules. Operation is subject to the
following
two conditions:

1. This device may not cause harmful interference;

2. This device must accept any interference received, including interference that may
cause undesired operation.

Caution! Exposure to Radio Frequency Radiation.

The radiated output of this device is far below the FCC radio frequency
exposure limits. Nevertheless, the device shall be used in such a manner
that the potential for human contact during normal operation is minimized.
When connecting an external antenna to the device, the antenna
shall be placed in such a manner to minimize the potential for human
contact during normal operation. In order to avoid the possibility of
exceeding the FCC radio frequency exposure limits, human proximity to
the antenna shall not be less than 20cm (8inches) during normal operation.

This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try
and correct the interference by one or more of the following measures:
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:

 Reorient or relocate the receiving antenna
 Increase the separation between the equipment and receiver

 Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected

 Consult the dealer or an experienced computer technician for help

Technical Support and Assistance

1. Visit the Advantech website at http://support.advantech.com where you can find
the latest information about the product.

2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:

– Product name and serial number
– Description of your peripheral attachments
– Description of your software (operating system, version, application software,

etc.)

– A complete description of the problem
– The exact wording of any error messages

Safety Instructions

Use the following safety guidelines to help protect yourself and PWS-870
 Do not attempt to service the PWS-870 yourself. Always follow installation

instructions closely.

 Be sure that nothing rests on the AC adapter's power cable and that the cable is

not located where it can be tripped over or stepped on.

 Do not cover the AC adaptor with papers or other items that will reduce cooling;

also, do not use the AC adapter while it is inside a carrying case.

 Use only the AC adapter, power cord, and batteries that are approved for use

with this PWS-870. Use of another type of battery or AC adapter may cause risk
of fire or explosion.

 If you use an extension cable with the AC adapter, ensure that the total ampere

rating of the products plugged in to the extension cable does not exceed the
ampere rating of the extension cable.

 When you move the PWS-870 between environments with very different

temperature and/ore humidity ranges, condensation may form on or within the
PWS-870. To avoid damaging the PWS-870, allow sufficient time for the
moisture to evaporate before using the PWS-870.

 When you disconnect a cable, pull on its connector or on its strain relief loop, not

on the cable itself. As you pull out the connector, keep it evenly aligned to avoid
bending any connector pins. Also, before you connect a cable make sure both
connectors are correctly oriented and aligned.

Chapter 1

Universal Cover, Handstrap and

Shoulder Belt

Universal Cover, Handstrap and Shoulder Belt are provided to carry your Tablet PC

No.

Component

1

Hook Point

securely and safely. You can use the Handstrap and Shoulder Strap we provide

separately or together to carry the PWS-870 either indoors and outdoors.

Exploring the Universal Cover, Handstrap and

Shoulder Belt

Front View

Rear View

No.

Component

2

HANDGRIP

3

Hook Point

Assemble PWS-870 with Universal Cover:

1. Connect PWS-870 to Universal Cover with care, via 2 setup points.

2. Push PWS-870 into universal cover and confirm the system is connected well

Remove PWS-870 from Universal Cover:

1. Pull latch up and push from rear.

Using the Handstrap:

The handstrap makes it easy to carry the device with one hand.

1. Insert the handstrap to the rear of Universal Cover using the Velcro on both

sides.

2. Ensure the handstrap to be securely attached
