ADAM-6000 Series

Ethernet Hub/Switch/Fiber Optical

The ADAM-6510/6520/6521 are industrial-grade Ethernet hubs and switches. They allow users to expand their industrial network fast and cost-effectively. The ADAM-6510 is a 10 Mbps hub, which has four twisted pair ports to connect up to four Ethernet devices. The ADAM-6520 is a 5-port 10/100 Mbps switch, which connects to 5 workstations and auto-detects both 10 Mbps and 100 Mbps connections. The ADAM-6521 consists of one ber optic and four RJ-45 ports. With ber optics, the transmission distance can be up to 2 km. In addition, noise interference is prevented. Moreover, the above products provide rugged industrial grade design to assure reliability and stability. Thus, the ADAM-6510/6520/6521 are especially suited for industrial environments with Ethernet networking needs: semi-conductor factories, inventory control environments, assembly lines and more.

Flexible Mounting

Due to its versatile and innovative design, the ADAM-6510/6520/6521 can be positioned/ mounted in three different ways: DIN rail, panel and piggyback mounting. Suitable for any industrial environment.

Advanced Surge Protection for Power Input

The ADAM-6510/6520/6521 support a wide voltage range of +10 ~ 30 VDC over the terminal block, which helps prevent system disconnection. Besides, it also provides 3000 VDC surge protection to protect itself from being damaged by over-voltage. This makes the system safer and more reliable.

Wide Operating Temperature Range

The operating temperature of the ADAM-6510/6520/6521 varies from -10 ~ 70° C. This advantage permits it to be functional in the harshest operating environments.

Easy to Troubleshoot

The six inclusive LED indicators make troubleshooting of the ADAM-6510/6520/6521 easier. Each port has a pair of LEDs that indicate link status and port activities. This function easily informs users of any collisions, link status, power failure and data receipt for immediate on-site diagnostics.

10-50

ADAM-6000 Smart Web Ethernet I/O Modules

Industrial Ethernet Networking

10/100Base-TX Ethernet to 100Base-FX Multi-Mode (ADAM-6541) and WDM Single Strand (ADAM-6542) Fiber Optics Converter

The ADAM-6541 and 6542 are industrial grade converters which are designed to convert Ethernet network (10/100Base-TX) to a ber optic network (100Base-FX). They transparently convert Ethernet signals into optic signals. The advantages of ber optics are wide bandwidth, EMI protection and less interference at long-distance transmissions. Therefore, the ADAM-6541 and 6542 are ideal solutions for “ber-to-building” applications at central ofces or local sites.

High-speed Transmission

The ADAM-6541 and 6542 support MDI/MDI-X of auto detection, so crossover wires are not required. They also include a switch controller that can sense the transmission speed (10/100 Mbps) automatically. Both the Ethernet port and the ber port have memory buffers that support a store-and-forward mechanism, assuring that data can be transmitted properly.

WDM Single Strand Fiber

The ADAM-6542 uses WDM technology that increases the information carrying capacity of ber via multiplex transmission and reception of signals at different wavelengths on a single strand cable. The WDM technology is implemented in couples. One site is installed with ADAM-6542/W15 where the transmission channel is 1550nm and the reception channel is 1310nm. The other site is installed with an ADAM6542/W13 where the transmission channel is 1310nm and the reception channel is 1550nm. Both transmission and reception channels of ADAM-6542/W15 and ADAM-6542/W13 are multiplexed to a single strand cable. So you can cut your cabling costs in half when you use ADAM-6542/W15 and ADAM-6542/W13 instead of a dual ber converter.

Industrial Grade Design

The ADAM-6541/6542 are extremely compact and they can be mounted via DIN rail, on a panel, or they can be piggy backed on top of each other.

The ADAM-6541 and ADAM-6542 provide three LED indicators: power, LNK/ACT, and 10/100 Mbps, which eases troubleshooting.

The ADAM-6541/6542 can work normally at -10 to 70° C and accept wide unregulated voltage ranges from +10 ~ 30 VDC. Besides, the ADAM-6541/6542 also provide 3,000 VDC surge protection to protect them from being damaged by over-voltage. Suitable for any harsh operating environment.
