Unimode9600
Addressable Fire Alarm Control Panel
Programming, Installation, Maintenance
and Operating Instruction Manual
IMPORTANT! The Signaling Line Circuit Wiring Manual Document #51520 must be referenced in addition to this manual when installing or servicing the Fire Alarm Control Panel.
Document #51336 C
11/06/01 Revision:
P/N 51336:C |
ECN 01-535 |
Fire Alarm System Limitations
An automatic fire alarm system–typically made up of smoke detectors, heat detectors, manual pull stations, audible warning devices, and a fire alarm control with remote notification capability–can provide early warning of a developing fire. Such a system, however, does not assure protection against property damage or loss of life resulting from a fire.
The Manufacturer recommends that smoke and/or heat detectors be located throughout a protected premise following the recommendations of the current edition of the National Fire Protection Association Standard 72 (NFPA 72), manufacturer's recommendations, State and local codes, and the recommendations contained in the Guide for Proper Use of System Smoke Detectors, which is made available at no charge to all installing dealers. A study by the Federal Emergency Management Agency (an agency of the United States government) indicated that smoke detectors may not go off in as many as 35% of all fires. While fire alarm systems are designed to provide early warning against fire, they do not guarantee warning or protection against fire. A fire alarm system may not provide timely or adequate warning, or simply may not function, for a variety of reasons:
Smoke detectors may not sense fire where smoke cannot reach the detectors such as in chimneys, in or behind walls, on roofs, or on the other side of closed doors. Smoke detectors also may not sense a fire on another level or floor of a building. A second-floor detector, for example, may not sense a first-floor or basement fire.
Particles of combustion or "smoke" from a developing fire may not reach the sensing chambers of smoke detectors because:
•Barriers such as closed or partially closed doors, walls, or chimneys may inhibit particle or smoke flow.
•Smoke particles may become "cold," stratify, and not reach the ceiling or upper walls where detectors are located.
•Smoke particles may be blown away from detectors by air outlets.
•Smoke particles may be drawn into air returns before reaching the detector.
The amount of "smoke" present may be insufficient to alarm smoke detectors. Smoke detectors are designed to alarm at various levels of smoke density. If such density levels are not created by a developing fire at the location of detectors, the detectors will not go into alarm.
Smoke detectors, even when working properly, have sensing limitations. Detectors that have photoelectronic sensing chambers tend to detect smoldering fires better than flaming fires, which have little visible smoke. Detectors that have ion- izing-type sensing chambers tend to detect fast-flaming fires better than smoldering fires. Because fires develop in different ways and are often unpredictable in their growth, neither type of detector is necessarily best and a given type of detector may not provide adequate warning of a fire.
Smoke detectors cannot be expected to provide adequate warning of fires caused by arson, children playing with matches (especially in bedrooms), smoking in bed, and violent explosions (caused by escaping gas, improper storage of flammable materials, etc.).
While a fire alarm system may lower insurance rates, it is not a substitute for fire insurance!
Heat detectors do not sense particles of combustion and alarm only when heat on their sensors increases at a predetermined rate or reaches a predetermined level. Rate-of-rise heat detectors may be subject to reduced sensitivity over time. For this reason, the rate-of-rise feature of each detector should be tested at least once per year by a qualified fire protection specialist. Heat detectors are designed to protect property, not life.
IMPORTANT! Smoke detectors must be installed in the same room as the control panel and in rooms used by the system for the connection of alarm transmission wiring, communications, signaling, and/or power. If detectors are not so located, a developing fire may damage the alarm system, crippling its ability to report a fire.
Audible warning devices such as bells may not alert people if these devices are located on the other side of closed or partly open doors or are located on another floor of a building. Any warning device may fail to alert people with a disability or those who have recently consumed drugs, alcohol or medication. Please note that:
•Strobes can, under certain circumstances, cause seizures in people with conditions such as epilepsy.
•Studies have shown that certain people, even when they hear a fire alarm signal, do not respond or comprehend the meaning of the signal. It is the property owner's responsibility to conduct fire drills and other training exercise to make people aware of fire alarm signals and instruct them on the proper reaction to alarm signals.
•In rare instances, the sounding of a warning device can cause temporary or permanent hearing loss.
A fire alarm system will not operate without any electrical power. If AC power fails, the system will operate from standby batteries only for a specified time and only if the batteries have been properly maintained and replaced regularly.
Equipment used in the system may not be technically compatible with the control. It is essential to use only equipment listed for service with your control panel.
Telephone lines needed to transmit alarm signals from a premise to a central monitoring station may be out of service or temporarily disabled. For added protection against telephone line failure, backup radio transmission systems are recommended.
The most common cause of fire alarm malfunction is inadequate maintenance. To keep the entire fire alarm system in excellent working order, ongoing maintenance is required per the manufacturer's recommendations, and UL and NFPA standards. At a minimum, the requirements of Chapter 7 of NFPA 72 shall be followed. Environments with large amounts of dust, dirt or high air velocity require more frequent maintenance. A maintenance agreement should be arranged through the local manufacturer's representative. Maintenance should be scheduled monthly or as required by National and/ or local fire codes and should be performed by authorized professional fire alarm installers only. Adequate written records of all inspections should be kept.
LimWarLg.p65 01/10/2000
Installation Precautions
WARNING - Several different sources of power can be connected to the fire alarm control panel. Disconnect all sources of power before servicing. Control unit and associated equipment may be damaged by removing and/or inserting cards, modules, or interconnecting cables while the unit is energized. Do not attempt to install, service, or operate this unit until this manual is read and understood.
CAUTION - System Reacceptance Test after Software Changes. To ensure proper system operation, this product must be tested in accordance with NFPA 72 Chapter 7 after any programming operation or change in site-specific software. Reacceptance testing is required after any change, addition or deletion of system components, or after any modification, repair or adjustment to system hardware or wiring.
All components, circuits, system operations, or software functions known to be affected by a change must be 100% tested. In addition, to ensure that other operations are not inadvertently affected, at least 10% of initiating devices that are not directly affected by the change, up to a maximum of 50 devices, must also be tested and proper system operation verified.
This system meets NFPA requirements for operation at 0-49° C/32-120° F and at a relative humidity of 85% RH (noncondensing) at 30° C/86° F. However, the useful life of the system's standby batteries and the electronic components may be adversely affected by extreme temperature ranges and humidity. Therefore, it is recommended that this system and all peripherals be installed in an environment with a nominal room temperature of 15-27° C/60-80° F.
Verify that wire sizes are adequate for all initiating and indicating device loops. Most devices cannot tolerate more than a 10% I.R. drop from the specified device voltage.
Adherence to the following will aid in problem-free installation with long-term reliability:
Like all solid state electronic devices, this system may operate erratically or can be damaged when subjected to light- ning-induced transients. Although no system is completely immune from lightning transients and interferences, proper grounding will reduce susceptibility. Overhead or outside aerial wiring is not recommended, due to an increased susceptibility to nearby lightning strikes. Consult with the Technical Services Department if any problems are anticipated or encountered.
Disconnect AC power and batteries prior to removing or inserting circuit boards. Failure to do so can damage circuits.
Remove all electronic assemblies prior to any drilling, filing, reaming, or punching of the enclosure. When possible, make all cable entries from the sides or rear. Before making modifications, verify that they will not interfere with battery, transformer, and printed circuit board location.
Do not tighten screw terminals more than 9 in-lbs. Over-tightening may damage threads, resulting in reduced terminal contact pressure and difficulty with screw terminal removal.
Though designed to last many years, system components can fail at any time. This system contains static-sensitive components. Always ground yourself with a proper wrist strap before handling any circuits so that static charges are removed from the body. Use static-suppressive packaging
to protect electronic assemblies removed from the unit.
Follow the instructions in the installation, operating, and programming manuals. These instructions must be followed to avoid damage to the control panel and associated equipment. FACP operation and reliability depend upon proper installation by authorized personnel.
FCC Warning
WARNING: This equipment generates, uses, and can |
Canadian Requirements |
|
radiate radio frequency energy and if not installed and |
This digital apparatus does not exceed the Class A |
|
used in accordance with the instruction manual, may |
limits for radiation noise emissions from digital |
|
cause interference to radio communications. It has |
apparatus set out in the Radio Interference Regulations |
|
been tested and found to comply with the limits for class |
of the Canadian Department of Communications. |
|
A computing device pursuant to Subpart B of Part 15 of |
Le present appareil numerique n'emet pas de bruits |
|
FCC Rules, which is designed to provide reasonable |
||
radioelectriques depassant les limites applicables aux |
||
protection against such interference when operated in a |
||
appareils numeriques de la classe A prescrites dans le |
||
commercial environment. Operation of this equipment in |
||
Reglement sur le brouillage radioelectrique edicte par le |
||
a residential area is likely to cause interference, in which |
||
ministere des Communications du Canada. |
||
case the user will be required to correct the interference |
||
|
||
at his own expense. |
|
LimWarLg.p65 01/10/2000
Notes
4 |
Unimode 9600 PN 51336:C 11/06/01 |
Table of Contents
SECTION 1: Product Description ........................................................................................................................ |
12 |
1.1: Inventory ..................................................................................................................................................... |
12 |
1.2: Features and Options................................................................................................................................... |
12 |
1.3: Specifications .............................................................................................................................................. |
14 |
1.3.1: Current Availability........................................................................................................................... |
15 |
1.4: Controls and Indicators ............................................................................................................................... |
16 |
1.5: Circuits ........................................................................................................................................................ |
17 |
1.6: Components................................................................................................................................................. |
17 |
1.6.1: Intelligent Addressable Detectors: Newer Series.............................................................................. |
18 |
1.6.2: Intelligent Addressable Modules: Newer Series............................................................................... |
19 |
1.6.3: 300 Series Intelligent Addressable Devices...................................................................................... |
20 |
1.6.4: Addressable Device Accessories....................................................................................................... |
20 |
1.7: Optional Modules........................................................................................................................................ |
20 |
1.8: Accessories.................................................................................................................................................. |
21 |
1.8.1: PK-9600 Programming Utility.......................................................................................................... |
21 |
1.8.2: Dress Panel........................................................................................................................................ |
21 |
1.8.3: Battery Box ....................................................................................................................................... |
21 |
1.8.4: ADT-CHG-120 Battery Charger....................................................................................................... |
22 |
1.8.5: Annunciators ..................................................................................................................................... |
22 |
1.9: Getting Started............................................................................................................................................. |
23 |
SECTION 2: Installation ....................................................................................................................................... |
24 |
2.1: Mounting ..................................................................................................................................................... |
24 |
2.2: Power........................................................................................................................................................... |
27 |
2.2.1: AC Power and Earth Ground Connection......................................................................................... |
27 |
2.2.2: Battery Power.................................................................................................................................... |
27 |
2.2.3: DC Power Output Connection .......................................................................................................... |
27 |
2.3: Relays .......................................................................................................................................................... |
28 |
2.4: Notification Appliance Circuits .................................................................................................................. |
28 |
2.5: UL Power-limited Wiring Requirements .................................................................................................... |
29 |
2.6: Optional Modules and Devices ................................................................................................................... |
30 |
2.6.1: 4XTMF Transmitter Module Installation.......................................................................................... |
31 |
2.6.2: Auxiliary Trouble Input (J16 & J17)................................................................................................. |
32 |
2.6.3: SLC-2 Expander Module .................................................................................................................. |
33 |
2.6.4: Printer/PC.......................................................................................................................................... |
34 |
2.6.5: Digital Communicator and Annunciators ......................................................................................... |
35 |
2.6.5.1 ADT-UDACT Digital Alarm Communicator/Transmitter ..................................................... |
35 |
2.6.5.2 ADT-ACM-8R Relay Control Module ................................................................................... |
35 |
2.6.5.3 BRKT-9600 Universal Bracket Installation ............................................................................ |
35 |
2.6.5.4 ADT-ACS and ADT-AFM Series Annunciators .................................................................... |
37 |
SECTION 3: Programming ................................................................................................................................... |
38 |
3.1: Programming Data Entry ............................................................................................................................ |
38 |
3.2: User Programming ...................................................................................................................................... |
39 |
3.3: Initial Power-up........................................................................................................................................... |
40 |
3.4: Programming Screens Description.............................................................................................................. |
40 |
3.5: Programming and Passwords ...................................................................................................................... |
40 |
3.6: Master Programming Level......................................................................................................................... |
42 |
3.6.1: Point Program ................................................................................................................................... |
43 |
3.6.1.1 Detector Programming ............................................................................................................ |
43 |
3.6.1.1.1 Add Detector ........................................................................................................................ |
43 |
3.6.1.1.2 Delete Detector .................................................................................................................... |
44 |
3.6.1.1.3 Edit Detector ........................................................................................................................ |
44 |
3.6.1.2 Module Programming ............................................................................................................. |
53 |
Unimode 9600 P/N: 51336:C 11/06/01 |
5 |
Table of Contents |
|
3.6.1.2.1 Add Module ......................................................................................................................... |
53 |
3.6.1.2.2 Delete Module ...................................................................................................................... |
54 |
3.6.1.2.3 Edit Module Screen for Monitor Module ............................................................................. |
54 |
3.6.1.2.4 Edit Module Screen for Control Modules ............................................................................ |
63 |
3.6.2: Zone Setup......................................................................................................................................... |
70 |
3.6.2.1 Enable ...................................................................................................................................... |
70 |
3.6.2.2 Disable ..................................................................................................................................... |
71 |
3.6.2.3 Zone 97, 98 and 99 .................................................................................................................. |
71 |
3.6.2.4 Zones Installed ........................................................................................................................ |
72 |
3.6.2.5 Zones Enabled ......................................................................................................................... |
72 |
3.6.2.6 Zones Disabled ........................................................................................................................ |
72 |
3.6.2.7 Zone Type ............................................................................................................................... |
73 |
3.6.3: Loop Setup ........................................................................................................................................ |
74 |
3.6.3.1 Style ......................................................................................................................................... |
74 |
3.6.3.2 Loop Protocol .......................................................................................................................... |
74 |
3.6.4: System Setup ..................................................................................................................................... |
75 |
3.6.4.1 Trouble Reminder ................................................................................................................... |
75 |
3.6.4.2 Banner ..................................................................................................................................... |
76 |
3.6.4.3 Time-Date ............................................................................................................................... |
77 |
3.6.4.3.1 Time ..................................................................................................................................... |
77 |
3.6.4.3.2 Date ...................................................................................................................................... |
78 |
3.6.4.3.3 Clock Format ........................................................................................................................ |
78 |
3.6.4.3.4 Daylight Savings Time ......................................................................................................... |
78 |
3.6.4.4 Timers ..................................................................................................................................... |
79 |
3.6.4.4.1 PAS (Positive Alarm Sequence) Delay ................................................................................ |
79 |
3.6.4.4.2 Pre-signal Delay ................................................................................................................... |
80 |
3.6.4.4.3 Waterflow Delay .................................................................................................................. |
80 |
3.6.4.4.4 AC Loss Delay ..................................................................................................................... |
81 |
3.6.4.5 NAC (Notification Appliance Circuit) .................................................................................... |
81 |
3.6.4.5.1 Enabled ................................................................................................................................. |
82 |
3.6.4.5.2 Type ...................................................................................................................................... |
83 |
3.6.4.5.3 Silenceable ........................................................................................................................... |
83 |
3.6.4.5.4 Auto Silence ......................................................................................................................... |
84 |
3.6.4.5.5 Coding .................................................................................................................................. |
84 |
3.6.4.5.6 Zone ...................................................................................................................................... |
85 |
3.6.4.5.7 Silence Inhibited ................................................................................................................... |
85 |
3.6.4.5.8 Synced Type ......................................................................................................................... |
85 |
3.6.4.6 Relays ...................................................................................................................................... |
86 |
3.6.5: Autoprogram ..................................................................................................................................... |
87 |
3.6.6: Verify Loops...................................................................................................................................... |
88 |
3.6.7: History............................................................................................................................................... |
88 |
3.6.7.1 View Events ............................................................................................................................ |
89 |
3.6.7.2 Erase History ........................................................................................................................... |
89 |
3.6.8: Walktest ............................................................................................................................................. |
90 |
3.6.9: Option Modules................................................................................................................................ |
91 |
3.6.9.1 Annunciators/UDACT ............................................................................................................ |
91 |
3.6.9.2 Printer/PC ................................................................................................................................ |
92 |
3.6.10: Password Change ............................................................................................................................ |
93 |
3.6.11: Clear Program.................................................................................................................................. |
94 |
3.6.12: Program Check................................................................................................................................ |
95 |
3.7: Maintenance Programming Level ............................................................................................................... |
97 |
3.7.1: Disable Point ..................................................................................................................................... |
98 |
3.7.2: History............................................................................................................................................... |
99 |
3.7.3: Program Check.................................................................................................................................. |
100 |
3.7.4: Walktest ............................................................................................................................................. |
101 |
6 |
Unimode 9600 P/N: 51336:C 11/06/01 |
Table of Contents |
|
3.7.5: System............................................................................................................................................... |
101 |
3.7.6: Zone Setup ........................................................................................................................................ |
103 |
SECTION 4: Operating Instructions .................................................................................................................... |
105 |
4.1: Panel Control Buttons ................................................................................................................................. |
105 |
4.1.1: Acknowledge/Step ............................................................................................................................ |
105 |
4.1.2: Alarm Silence.................................................................................................................................... |
105 |
4.1.3: Drill/Hold 2 Sec ................................................................................................................................ |
105 |
4.1.4: Reset.................................................................................................................................................. |
105 |
4.2: LED Indicators ............................................................................................................................................ |
106 |
4.3: Normal Operation........................................................................................................................................ |
107 |
4.4: Trouble Operation ....................................................................................................................................... |
107 |
4.5: Alarm Operation.......................................................................................................................................... |
109 |
4.6: Supervisory Operation................................................................................................................................. |
110 |
4.7: Process Monitor Operation.......................................................................................................................... |
111 |
4.8: Hazard Condition Operation ....................................................................................................................... |
111 |
4.9: Medical Alert Condition Operation............................................................................................................. |
111 |
4.10: NAC Operation ......................................................................................................................................... |
111 |
4.11: Programmed Zone Operation .................................................................................................................... |
112 |
4.12: Disable/Enable Operation ......................................................................................................................... |
112 |
4.13: Waterflow Circuits Operation ................................................................................................................... |
112 |
4.14: Detector Functions .................................................................................................................................... |
112 |
4.15: Time Functions: Real-Time Clock ............................................................................................................ |
112 |
4.16: Synchronized NAC Operation .................................................................................................................. |
113 |
4.17: Coded Operation ....................................................................................................................................... |
113 |
4.18: Presignal .................................................................................................................................................... |
113 |
4.19: Positive Alarm Sequence .......................................................................................................................... |
114 |
4.20: Special System Timers .............................................................................................................................. |
115 |
4.20.1: Silence Inhibit Timer....................................................................................................................... |
115 |
4.20.2: Autosilence Timer ........................................................................................................................... |
115 |
4.20.3: Trouble Reminder ........................................................................................................................... |
115 |
4.20.4: Waterflow Retard Timer.................................................................................................................. |
115 |
4.20.5: Alarm Verification (None or Two Minutes).................................................................................... |
116 |
4.21: Walktest ..................................................................................................................................................... |
116 |
4.22: Read Status................................................................................................................................................ |
117 |
4.22.1: System Point ................................................................................................................................... |
118 |
4.22.2: Zones............................................................................................................................................... |
119 |
4.22.3: Power............................................................................................................................................... |
120 |
4.22.4: Trouble Reminder ........................................................................................................................... |
120 |
4.22.5: Timers.............................................................................................................................................. |
121 |
4.22.6: NAC ................................................................................................................................................ |
121 |
4.22.7: Relays.............................................................................................................................................. |
122 |
4.22.8: Program Check................................................................................................................................ |
122 |
4.22.9: History............................................................................................................................................. |
122 |
4.22.10: Annunciators ................................................................................................................................. |
123 |
4.22.11: Printer/PC ...................................................................................................................................... |
123 |
4.22.12: Print............................................................................................................................................... |
124 |
4.22.13: Time-Date...................................................................................................................................... |
126 |
SECTION 5: Power Supply Calculations ............................................................................................................. |
127 |
5.1: Overview ..................................................................................................................................................... |
127 |
5.2: Calculating the AC Branch Circuit ............................................................................................................. |
127 |
5.3: Calculating the System Current Draw......................................................................................................... |
128 |
5.3.1: Overview........................................................................................................................................... |
128 |
5.3.2: How to Use Table 5.3 on page 129 to Calculate System Current Draw ........................................... |
128 |
5.4: Calculating the Battery Size........................................................................................................................ |
130 |
Unimode 9600 P/N: 51336:C 11/06/01 |
7 |
Table of Contents |
|
5.4.1: NFPA Battery Requirements ............................................................................................................. |
130 |
5.4.2: Selecting and Locating Batteries....................................................................................................... |
130 |
APPENDIX A: Software Zones ............................................................................................................................ |
131 |
A.1: Correlations ............................................................................................................................................... |
131 |
APPENDIX B: Default Programming ................................................................................................................. |
139 |
APPENDIX C: Wire Requirements ..................................................................................................................... |
140 |
8 |
Unimode 9600 P/N: 51336:C 11/06/01 |
It is imperative that the installer understand the requirements of the Authority Having Jurisdiction (AHJ) and be familiar with the standards set forth by the following regulatory agencies:
•Underwriters Laboratories Standards
•NFPA 72 National Fire Alarm Code
•CAN/ULC - S527M Standard for Control Units for Fire Alarm Systems
Before proceeding, the installer should be familiar with the following documents.
NFPA Standards
NFPA 72 National Fire Alarm Code
NFPA 70 National Electrical Code
Underwriters Laboratories Documents:
UL 38 Manually Actuated Signaling Boxes
UL 217 Smoke Detectors, Single and Multiple Station
UL 228 Door Closers–Holders for Fire Protective Signaling Systems
UL 268 Smoke Detectors for Fire Protective Signaling Systems
UL 268A Smoke Detectors for Duct Applications
UL 346 Waterflow Indicators for Fire Protective Signaling Systems
UL 464 Audible Signaling Appliances
UL 521 Heat Detectors for Fire Protective Signaling Systems
UL 864 Standard for Control Units for Fire Protective Signaling Systems
UL 1481 Power Supplies for Fire Protective Signaling Systems
UL 1610 Central Station Burglar Alarm Units
UL 1638 Visual Signaling Appliances
UL 1971 Signaling Devices for Hearing Impaired
CAN/ULC - S524M Standard for Installation of Fire Alarm Systems
CAN/ULC S527M Standard for Control Units for Fire Alarm Systems
Other:
EIA-232E Serial Interface Standard
EIA-485 Serial Interface Standard
NEC Article 250 Grounding
NEC Article 300 Wiring Methods
NEC Article 760 Fire Protective Signaling Systems
Applicable Local and State Building Codes
Requirements of the Local Authority Having Jurisdiction (LAHJ)
ADT Documents: |
|
ADT Device Compatibility Document |
Document #51352 |
ADT-SLC Wiring Manual |
Document #51520 |
ADT-AFM-16AT & AFM-32A |
Document #A15048 |
ADT-AFM-16A Annunciator |
Document #A15207 |
ADT-ACS Series Annunciators |
Document #51353 |
ADT-UDACT Communicator/Transmitter |
Document #50934 |
ADT-CHG-120 Battery Charger |
Document #50938 |
ADT-LDM Series Lamp Driver Modules |
Document #51351 |
LCD-80F Remote Fire Annunciator |
Document #51338 |
ADT-ACM-8R Relay Control Module |
Document #51356 |
Unimode 9600 PN 51336:C 11/06/01 |
9 |
10
11/06/01 51336:C PN 9600 Unimode
MS-9600 Basic System Connections |
Notification Appliance Circuits |
|
|
|
|
NAC #1 |
NAC #2 |
EIA-232 |
|
|
|
|
Style Y (shown) |
Style Y or |
|
|
|
|
or Style Z |
Style Z (shown) |
to printer or |
13 12 11 10 9 8 7 6 5 4 |
3 2 1 |
|
3.0 amps max. |
3.0 amps max. |
personal computer |
25 24 23 22 21 20 19 18 17 16 |
15 14 |
DC Power Outputs (24 VDC) |
|
|
ELR 4.7K, ½W |
|
|
|
|
|
|
For EDP-listed equipment or |
|
|
|
|
|
|||||||||||||
|
|
|
+ |
+ |
|
2 Programmable Relays & |
personal computer with FACP |
|
|
|
|
|
||||||||||||||||
Supervise with a power supervision relay A77-716B |
|
|
|
Upload/DownloadableUtility. |
|
|
|
|
|
|
||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
1 Fixed Trouble Relay |
|
|
|
|
|
|
|
n |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
50 foot maximum within same room. |
|
|
|
|
||||||||||||
Nonresettable Power #2 - 24 VDC filtered, |
6 |
|
|
|
|
|
|
Contact Ratings: |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
T R D G |
||||
power-limited (3.00 amps maximum) |
|
|
|
|
|
|
2.0 amps @ 30 VDC (resistive) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
Supervision required. Suitable for |
|
|
5 |
|
|
|
|
|
|
0.5 amps @ 30 VAC (resistive) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
X C T N |
|||
powering annunciators. |
|
|
|
|
|
+ |
+ |
|
|
Contacts shown below in normal |
|
|
|
|
|
|
|
|
OR |
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
condition (AC power with no alarm, |
5 |
4 |
3 |
2 |
|
1 |
|
|
|
|
|
|
|
|
|
||
Nonresettable Power #1 - 24 VDC filtered, |
4 |
|
|
|
|
|
|
|
trouble or supervisory activity). |
|
9 |
8 |
7 |
6 |
|
|
|
|
|
|
|
|
|
|
||||
power-limited (3.00 amps maximum) |
|
|
|
|
|
|
|
|
|
|
|
|
DB9F |
|
|
|
|
TERM |
|
|
||||||||
Supervision required. Suitable for |
|
3 |
|
|
|
|
|
|
|
A Fail Safe Trouble |
NC NO C |
|
|
|
|
|
|
|
Red |
|
|
(EIA-485) |
|
|
||||
powering annunciators. |
|
|
|
|
|
|
+ |
+ |
|
|
relay switches to the |
|
|
ACS (EIA-485) |
|
|
White |
|
|
to LCD-80F |
|
TB7 (option to DB-25) |
||||||
|
|
|
|
|
|
|
|
|
NO position during |
|
|
to ACS Annunc. Green |
|
|
|
|||||||||||||
|
|
|
|
|
|
|
|
|
|
|
trouble conditions and |
|
or UDACT-F |
|
|
Black |
|
|
|
|
|
|
|
|
||||
Resettable Power - 24 VDC filtered, power-limited |
2 |
|
|
|
|
|
|
|
|
|
(power-limited, |
|
|
D |
G |
I |
I |
O O |
|
|
||||||||
(3.00 amps maximum) to smoke detectors (IDC). |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
X C |
T |
N |
N |
N |
U |
U |
|
|
|
Supervision required. |
|
1 |
+ - |
+ - |
+ - |
B A A B B A A B |
|
Alarm* Trouble |
Supervisory* |
+ - |
|
|
|
|
V |
R |
D |
+ |
- |
T |
T |
B A B A A B |
||||||
|
|
|
+ + - - |
+ + |
- - |
|
NO NC C NC NO C NO NC C |
|
|
|
|
|
|
|
|
|
|
+ |
- |
+ + |
- - |
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
shield |
|
|
|
TB3 |
|
|
|
|
|
|
TB4 |
TB5 |
|
|
TB6 |
|
|
|
TB7 |
|
|
|
|
|
|
|
TB8 |
||
|
|
|
JP3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
(*Factory default relay programming |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
CUT TO |
|
|
Cut this jumper to disable the |
as shown on circuit board) |
|
Cut this jumper to e |
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
FACP battery charger when |
CUT TO |
|
|
|
|
|
|
|
|
|
|
||||||||||||
|
|
|
DISABLE |
|
|
using external charger. |
|
JP5 |
|
|
|
|
|
|
|
|
||||||||||||
|
|
|
LOCAL |
|
|
|
|
|
|
MONITOR 4XTMF |
|
|
|
|
|
|
|
|
||||||||||
|
|
|
CHARGER |
|
|
|
|
|
|
|
JP6 |
|
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
J10 |
4XTMF OPT BD |
|
J11 |
|
|
|
|
|
|
|
|
|
|
||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||
|
|
|
|
|
|
Connectors for 4XTMF option module |
|
|
|
Supervisory relay when |
|
|
|
|
|
|
|
|
||||||||||
|
|
|
|
|
|
|
|
|
4XTMF module is installed |
|
|
|
|
|
|
|
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
Cut this jumper to supervise |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
the 4XTMF module when |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
J |
|
J |
|
|
|
|
installed (see JP10 & JP11) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
17 |
|
16 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
To disable ground fault detection, |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
remove jumper/shunt from JP2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
JP2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Connector for Optional 2nd |
||||||
|
|
|
DISABLE |
|
|
|
|
|
|
J2 |
|
|
|
|
|
|
|
|
|
|
Signalling Line Circuit Module |
|||||||
|
|
|
GND |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
FLT |
|
|
|
|
|
|
|
OPT DACT |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
OPT SLC |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
J6 |
J8 |
SW1 Flash Memory Load Enable Switch. |
|
|
|
|||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
UP is normal position for switch. |
|
|
|
|
||||||||||
|
|
|
|
|
|
|
LCD DISPLAY |
|
KEYPAD I/F |
|
|
DOWN position allows loading of |
|
|
|
|
||||||||||||
|
|
|
|
|
|
|
TB1 |
|
TB2 |
|
|
factory software upgrades |
|
|
|
|
|
|
||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
J3 |
|
|
|
|
|
CB1 |
HOT NEUT EARTH |
+BATTERY- |
|
|
|
J7 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
9600lay3.cdr |
|
|
|
|
|
|
|
|
Battery |
|
|
|
|
|
|
|
|
PS2 Keyboard Interface |
|
|||||||||
CAUTION! |
HIGH VOLTAGE |
|
120 VAC, 60 HZ, 3.2 amps |
24 VDC, 25 Amp Hour maximum |
|
|
|
|
|
|
|
|
||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SLC Loop
Refer to the SLC Wiring Manual for detailed information on wiring addressable devices for Style 4, 6 and 7.
Peripheral Devices and Their Documents:
ADT-AFM-16AT &
ADT-AFM-32A
Doc. # A15048
ADT-ACS Series |
ADT-ACM-8R |
|
Doc. # 51353 |
||
Doc. # 51356 |
||
|
ACS (EIA-485)
Annunciators
ADT-UDACT |
ADT-AFM-16A |
|
Doc. # A15207 |
||
Doc. # 50934 |
||
|
ADT-LDM-32
Doc. # 51351
Unimode 9600
Doc. # 51336
TERM (EIA-485) |
Annunciators |
SLC Loop
Ack/Step |
Silence |
Drill |
Reset |
Hold 2sec. |
ADT-LCD-80F
Doc. # 51589
1 |
9600peri.cdr |
Addressable Devices and SLC Wiring
Doc. # 51309
Battery Connector
ADT-CHG-120 Charger
Doc. # 50938
Unimode 9600 PN 51336:C 11/06/01 |
11 |
SECTION 1
Product Description
The ADT Unimode 9600 is a compact, cost effective, intelligent addressable FACP (Fire Alarm Control Panel) with an extensive list of powerful features. The combination of newer series devices and legacy 300 Series devices, along with the Unimode 9600 FACP, offer the latest in fire protection technology. The power supply and all electronics are contained on a single circuit board housed in a metal cabinet, providing a complete fire control system for most applications. Optional modules, which plug into the main circuit board, are available for special functions. Available accessories include LED, graphic and LCD annunciators, reverse polarity/city box transmitter, digital alarm communicator/ transmitter, SLC expansion module, local and remote upload/download software and remote power expansion.
1.1 Inventory
When the Unimode 9600 shipment is received, check to make certain that all parts have been included in the shipment. The Unimode 9600 shipment should consist of one of each of the following:
main circuit board with display
backbox with door
plastic bag containing screws, cables, key, etc.
manual
1.2Features and Options
•Single standard addressable SLC loop which meets NFPA Style 4, 6 and 7 requirements
•Optional module for adding a second SLC loop which meets NFPA Style 4, 6 and 7 requirements
•318 addressable device capacity for each SLC loop (159 detectors and 159 control/ monitor modules)
•99 software zones
•Two onboard NACs (Notification Appliance Circuits) with additional NAC capability using control modules
•6.0 amps total power for NACs and 24 VDC auxiliary power outputs
•7.2 amps total system power (includes battery charger)
•Two programmable relay outputs and one fixed trouble relay
•EIA-232 Printer/PC interface (variable baud rate)
•80-character LCD display (backlit)
•Real-time clock/calendar with daylight savings time control
•History file with 1,000 event capacity
•Advanced fire technology features:
Automatic drift compensation
Maintenance alert
Detector sensitivity test capability (NFPA 72 compliant)
Automatic device type-code verification
Point trouble identification
•Waterflow selection per module point
•Alarm verification selection per detector point
•Walktest, silent or audible
•PAS (Positive Alarm Sequence) and Pre-signal per point (NFPA 72 compliant)
|
|
Features and Options |
Product Description |
•Annunciators:
ADT-AFM-LED Zone Annunciator Series
ADT-LDM Graphic Annunciator Series
ADT-LCD-80F Liquid Crystal Display point annunciator
ADT-ACM-8R Relay Module
•Silence inhibit timer option per NAC
•Autosilence timer option per NAC
•Continuous, March Time, Temporal or California code for main circuit board NACs with two-stage capability
•Selectable strobe synchronization per NAC
•Remote Acknowledge, Alarm Silence, Reset and Drill via addressable modules, ADT-AFM annunciators or ADT-LCD-80F Remote annunciator
•Auto-program (learn mode) reduces installation time. Reports two devices set to the same address
•Password and key-protected nonvolatile memory
•User programmable password
•Fully programmable from local keypad or keyboard or local PC
•SLC operates up to 10,000 ft. (3,000 m) with twisted, shielded wire or 3,000 ft (900 m) with untwisted, unshielded wire
•Compatible with newer series devices (CLIP Mode)
CP350: addressable Ionization Smoke Detector
SD350(T): addressable Photo Smoke Detector (T= with Thermal Sensor)
H350(R): Fast Response Heat Detector (R=Rate-of-Rise option)
D350P(R): addressable Photo Duct Detector (R=alarm relay option)
B501BH & B501BHT Sounder Bases
BB224RB Relay Base
BB224BI Isolator Base
MMF-300: Monitor Module
MDF-300: Dual Monitor Module (uses two consecutive SLC addresses)
MMF-301: Miniature Monitor Module
MMF-302: 2-wire Detector Module
CMF-300: Control Module
CRF-300: Relay Module
ADT-BG-12LX: Manual Pull Station
I300: Isolator Module
•Compatible with legacy 300 Series devices (CLIP Mode only):
CP300: addressable Ionization Smoke Detector
SD300(T): addressable Photoelectric Smoke Detector (T= Thermal Sensor)
C304: Control Module
M300: Monitor Module
M301: Miniature Monitor Module
M302: 2-wire Detector Module
ADT-BG-10LX: Manual Pull Station
•Optional 4XTMF module (conventional reverse polarity/city box transmitter)
Unimode 9600 PN 51336:C 11/06/01 |
13 |
Product Description |
Specifications |
1.3 Specifications
AC Power - TB1
120 VAC, 60 Hz, 3.2 amps
Wire size: minimum 14 AWG (2.00 mm2) with 600 V insulation
Battery (Lead Acid Only) - TB2
Maximum Charging Circuit: Normal Flat Charge - 27.6 VDC @ 1.00 amp Maximum Battery Charger Capacity: 25 Amp Hour (Unimode 9600 cabinet holds
maximum of two 18 Amp Hour batteries. For greater than 25 Amp Hour up to 120 Amp Hour batteries, use the ADT-CHG-120 Battery Charger and BB-55F Battery Box.
Note: Jumper JP3, on the FACP main circuit board, must be cut to disable the FACP battery charger when using the ADT-CHG-120.
Communication Loop - (Standard ) TB8 and (Optional SLC Expander Module) J3
24 VDC nominal, 27.6 VDC maximum
Maximum length is 10,000 ft. (3,000 m) total twisted, shielded pair length Maximum loop current is 400 mA (short circuit) or 100 mA (normal) Maximum loop resistance is 40 ohms
Supervised and power-limited
Refer to SLC Loop manual for wiring information
Notification Appliance Circuits - TB4
Power-limited circuitry
Maximum voltage drop in wiring: 2.0 VDC
Nominal operating voltage: 24 VDC
Current-limit: fuseless, electronic, power-limited circuitry
Maximum signaling current per circuit: 3.00 amps (see Figure 1.1 on page 15)
End-of-Line Resistor: 4.7 kΩ, ½ watt (P/N 71252 UL listed) for NACs
Refer to ADT Device Compatibility Document for listed compatible devices
Two Programmable and One Fixed Output Relay - TB5
Contact rating: 2.0 amps @ 30 VDC (resistive), 0.5 amps @ 30 VAC (resistive) Form-C relays
Refer to Figure 2.5 on page 28 for information on power-limited wiring for relay circuits
Four-Wire Resettable Smoke Detector Power (24 VDC nominal) - TB3,
Terminals 1 (+) & 2 (-)
Maximum ripple voltage: 10 mVRMS
Up to 3.0 amps is available for powering 4-wire smoke detectors (see Figure 1.1)
Power-limited circuit
Refer to ADT Device Compatibility Document for listed compatible devices
Nonresettable Power #1 (24 VDC Nominal) - TB3, Terminals 3 (+) & 4 (-)
Maximum ripple voltage: 10mVRMS
Total DC current available from each output is up to 3.00 amps (see Figure 1.1)
Power-limited circuit
Nonresettable Power #2 (24 VDC Nominal) - TB3, Terminals 5 (+) & 6 (-)
Maximum ripple voltage: 10mVRMS
Total DC current available from each output is up to 3.00 amps (see Figure 1.1)
Power-limited circuit
14 |
Unimode 9600 PN 51336:C 11/06/01 |
Specifications |
Product Description |
EIA-485 (ACS) - TB6
ACS annunciator connector, Terminal 1 (+) and Terminal 2 (-)
EIA-485 (TERM) - TB7
Terminal Mode annunciator connector, Terminal 5 (In +), 6 (In -), 7 (Out +), 8 (Out -)
EIA-232 (ACS) - TB7
PC/Printer Connector, Terminal 1 (Transmit), 2 (Receive), 3 (DTR), 4 (Ground)
Auxiliary Trouble Inputs - J16 & J17
Two-pin connectors which can be used to monitor trouble conditions on auxiliary equipment. They can be connected to the trouble bus of a peripheral such as the ADT- CHG-120 or to the normally-open dry contacts of a trouble relay.
CAUTION! Do not connect power to these connectors since circuit damage may result.
1.3.1 Current Availability
The following figure illustrates the maximum current that is possible for each panel circuit and the total current available from the FACP power supply.
TB3
Resettable Power for 4-Wire
Smoke Detectors
Nonresettable
Power # 1
Nonresettable
Power # 2
NAC # 1
NAC # 2
1 2 3 4 5 6
1 2 3 4 5 6 7 8
TB4
3 amps max
per circuit
3 amps max
per circuit
3 amps max
per circuit
3 amps max
per circuit
3 amps max
per circuit
Standby 6 amps max
per panel
Alarm
7 amps max
per panel
Refer to the battery calculations section for additional information.
Figure 1.1 Current Availability
Unimode 9600 PN 51336:C 11/06/01 |
15 |
Product Description |
Controls and Indicators |
1.4 Controls and Indicators
LCD Display
The FACP uses an 80-character (4 lines X 20 characters) high viewing angle LCD display. The display includes a long life LED backlight that remains illuminated. If AC power is lost and the system is not in alarm, the LED
backlight will turn off to conserve batteries.
SYSTEM ALL NORMAL 10:00A 010101
LED Indicators
LED indicators are provided to annunciate the following conditions:
•AC Power (green)
•Fire Alarm (red)
•Supervisory (yellow)
•Trouble (yellow)
•Maintenance/presignal (yellow)
•Alarm Silenced signals (yellow)
•Disabled (yellow)
•Battery fault (yellow)
•Ground fault (yellow)
Key Panel
Mounted on the main circuit board, the key panel includes a window for the LCD display and LED indicators as listed above. The key panel, which is visible with the cabinet door closed, has 25 keys, including a 16 key alpha-numeric pad similar to a telephone keypad.
Function keys: |
|
|
|
|
|
|
||
• |
Acknowledge/Step |
|
|
|
|
AC POWER |
MAINTENANCE |
|
• |
Alarm Silence |
|
|
|
|
|||
|
|
|
|
FIRE ALARM |
ALARM |
|||
|
|
|
|
|
|
SILENCED |
||
• |
Drill |
|
|
|
|
SUPERVISORY |
DISABLED |
|
|
|
|
|
TROUBLE |
BATTERY |
|||
|
|
|
|
|
|
|||
• |
Reset (lamp test) |
|
|
|
|
|
GROUND |
|
1 |
2 |
3 |
1st |
ACK/STEP |
||||
Service/program keys: |
||||||||
|
|
|||||||
|
ABC |
DEF |
EVENT |
|
ALARM |
|||
• Keys labeled 1 to 9 |
4 |
5 |
6 |
CLR |
ENTER |
SILENCE |
||
GHI |
JKL |
MNO |
|
|
||||
|
|
|
|
|||||
|
|
|
|
|
||||
• |
* key |
7 |
8 |
9 |
ESC |
|
DRILL |
|
PRS |
TUV |
WXY |
|
|
HOLD 2 SEC |
|||
• |
# key |
* |
0 |
# |
MODE |
|
RESET |
|
|
|
|
|
|
|
|
||
• |
0 (recall) key |
QZ |
|
-/. |
|
|
|
|
|
RECALL |
|
|
|
|
•1st Event key
• Clear key |
Figure 1.2 Membrane/Display Panel |
•Escape key
•Mode key
•Four cursor keys (up, down, left and right)
•Enter key
Local Piezo Sounder
A piezo sounder provides separate and distinct pulse rates for alarm, trouble and supervisory conditions.
9600kypd.cdr
16 |
Unimode 9600 PN 51336:C 11/06/01 |
Circuits |
Product Description |
1.5 Circuits
Reference
Manual
SLC Communication Loop
One SLC loop is provided standard on the FACP main circuit board. A second SLC loop is available by plugging the optional SLC module into connector J3 on the main circuit board. SLC loops, configurable for NFPA Style 4, 6 or 7, provide communication to addressable detectors, monitor (initiating device) and control (output device) modules. Refer to the ADT SLC Wiring Manual for information on wiring devices.
Output Circuits
The following output circuits are available on the FACP:
•24 VDC Resettable (smoke detector power) output - 3.00 amps maximum
•24 VDC Nonresettable power output #1 - 3.00 amps maximum
•24 VDC Nonresettable power output #2 - 3.00 amps maximum
•24 VDC Battery Charger (up to 25 AH batteries)
NAC (Notification Appliance Circuits)
Two NACs, configurable for Style Y (Class B) or Style Z (Class A), are provided with various programmable features.
Relays
One fixed and two fully programmable Form-C dry contact relays are provided. The fixed fail-safe relay monitors system trouble and the two programmable relays are factory default programmed for system alarm and system supervisory. Contacts are rated 2.0 amps @ 30 VDC (resistive) and 0.5 amps @ 30 VAC (resistive). The programmable relays can be programmed for the following operations:
•fire alarm
•trouble
•supervisory
•supervisory auto-resettable
•DACT communication failure
•process monitor
•process monitor auto-resettable
•hazard alert
•medical alert
•AC loss
Auxiliary Trouble Inputs
Auxiliary Trouble Inputs can be connected to trouble bus outputs from auxiliary equipment, such as power supplies, or normally-open dry contacts of a trouble relay to allow monitoring by the Unimode 9600.
1.6 Components
Main Circuit Board
The main circuit board contains the system’s CPU, power supply, other primary components and wiring interface connectors. Optional modules plug in and are mounted to the main circuit board. The circuit board is delivered in the Unimode 9600 kit and must
be mounted to the backbox. Refer to the circuit board illustration on Page 10.
See Page
Unimode 9600 PN 51336:C 11/06/01 |
17 |
Product Description
Cabinet
The Unimode 9600 cabinet is red with a navy blue front overlay. The backbox provides space for two batteries (up to 18 Amp Hour). Ample knockouts are provided for system wiring. Also included is a standard dress panel, which mounts to the inside of the cabinet (required on the ULC version). The dress panel must be installed to meet FM requirements.
Batteries
The Unimode 9600 cabinet provides space for two batteries (up to
18 Amp Hour). Batteries larger than 18 Amp Hour up to 25 Amp Hour require use of UL listed battery cabinet. The ADT-CHG-120 can be used for charging 25 to 120 AH batteries and the BB-55F can be used for housing the batteries. Batteries must be ordered separately.
1.6.1 Intelligent Addressable Detectors: Newer Series
Intelligent, addressable detectors provide information to the control panel on an SLC Signaling Line Circuit (refer to the ADT SLC Wiring Manual for detailed information on device installation, wiring and operation). This allows the control panel to continually process the information to determine the status (alarm, trouble, maintenance or normal) of each detector. Each detector responds to an SLC address that is set in the detector head using built-in rotary decimal switches with the ability to select up to 159 addresses. Note that a blinking LED on an intelligent detector indicates communication between the detector and the control panel. Refer to the ADT Device Compatibility Document for a list of approved detectors.
Smoke Detectors (Photoelectric)
The SD350 is an intelligent, addressable low profile photoelectric smoke detector which provides smoke sensing technology. The SD350T includes a 135o fixed thermal sensor.
Smoke Detector (Ionization)
The CP350 is an intelligent, addressable low profile ionization smoke detector which measures the level of combustion products in its chamber using the ‘ionization principle.’
Smoke Detector (Duct)
The D350P is an intelligent, addressable photoelectric duct smoke detector. The D350RP includes an alarm relay.
Heat Detectors
The H350 is an intelligent heat detector with a thermistor sensing circuit for fast response, designed to provide open area protection with 50 foot (15 m) spacing capability. The H350R incorporates a thermal Rate-of-Rise circuit of 15oF (9.4oC).
Detector Bases
The B501BH is a standard sounder base and the B501BHT is a temporal tone sounder base for intelligent, addressable smoke detectors.
The B224RB is a relay base with one Form-C relay for intelligent, addressable smoke detectors. It may be used to control auxiliary functions.
The B224BI is an isolator base for intelligent, addressable smoke detectors. It functions similar to the I300 isolator module which allows loops to operate under fault conditions and automatically restore when the fault is removed.
18 |
Unimode 9600 PN 51336:C 11/06/01 |
Components |
Product Description |
Reference
Manual
1.6.2 Intelligent Addressable Modules: Newer Series
The newer series of Control Modules and Monitor Modules provide an interface between the control panel and conventional notification and initiating devices. Each module can be set to respond to an address with built-in rotary switches with the ability to select up to 159 addresses (a tab on the address switch must be broken off to use addresses 100-159). A blinking LED on a monitor module indicates communication between the module and the control panel. These devices can also be used in CLIP Mode (Classic Loop Interface Protocol) when installed on older systems. Refer to the ADT Device Compatibility Document for a list of approved notification and initiating devices.
Monitor Modules
The MMF-300, MDF-300 and MMF-302 are addressable monitor modules for monitoring conventional initiating devices. The MMF-300 is used for normally open contact alarm initiating devices, such as manual pull stations, four-wire smoke detectors, heat detectors, waterflow, security contacts and supervisory devices. The MDF-300 is a dual monitor module (Class B only) which occupies two consecutive SLC addresses, with each module functionally the same as the MMF-300. The MMF-302 is used primarily for two-wire smokes detectors in addition to normally open contact devices. The supervised IDCs (Initiating Device Circuits) can be wired to the modules as NFPA Style B (Class B) or Style D (Class A) circuits. The modules are supplied with a thermoplastic cover for mounting to a 4-inch mounting box.
Monitor Module (miniature)
The MMF-301 is an addressable module that is functionally similar to an MMF-300 but offered in a smaller package for mounting directly in the electrical box of the device being monitored.
Control Module
The CMF-300 is an addressable Control Module used to connect NACs (Notification Appliance Circuits) to power and supervise compatible, UL-listed notification appliances. The NACs can be wired to the module as supervised NFPA Style Y (Class B) or Style Z (Class A) circuits. The modules are supplied with a thermoplastic cover for mounting to a 4-inch square mounting box.
Relay Module
The CRF-300 is a Control Relay Module which is functionally similar to the CMF-300 but used as a Form-C relay module.
Isolator Module
The I300 loop isolator module is an automatic switch which opens the circuit voltage to the SLC loop branch(es) whenever a wire-to-wire short circuit is detected on that loop. The remainder of the communications loop leading up to the I300 will continue to operate, unaffected by the short. The isolator module is bidirectional, meaning that it can detect a fault condition between the input SLC terminals or output SLC terminals. The I300 is required to meet NFPA Style 7 requirements.
Detector Annunciator
The RA400Z is a remote single LED annunciator that can be wired directly to an addressable detector for annunciation of that detector’s alarm status.
Manual Pull Station
The ADT-BG-12LX is an addressable manual pull station featuring a key-lock reset. The pull station responds to an address set by the installer using the built-in rotary decimal switches on the pull station. The manual pull station includes an ADT key.
Unimode 9600 PN 51336:C 11/06/01 |
19 |
Product Description |
Optional Modules |
1.6.3 300 Series Intelligent Addressable Devices
ADT’s 300 Series Intelligent Addressable Devices are fully compatible with the Unimode 9600 FACP. The devices must be configured for CLIP Mode operation if the control panel is installed in an existing system with 300 Series devices. The address of 300 Series devices cannot be set above 99. Compatible devices include:
•SD300 Photoelectric Detector
•SD300T Photoelectric Detector with Thermal Sensor
•CP300 Ionization Detector
•M300 Monitor Module
•M301 Miniature Monitor Module
•M302 2-wire Monitor Module
•C304 Control/Relay Module
•ADT-BG-10LX Manual Pull Station
1.6.4 Addressable Device Accessories
End-of-Line Resistor Assembly P/N R-47K
The 47 kΩ End-of-Line Resistor assembly (P/N: R-47K) is used to supervise the MMF300, MDF-300, MMF-301 and CMF-300 module circuits. The 3.9 kΩ End-of-Line Resistor assembly is used to supervise the MMF-302 module circuit. The resistors are included with each module.
Power Supervision Relay
The UL listed End-of-Line power supervision relay is used to supervise the power to 4- wire smoke detectors and notification appliances.
N-ELR Mounting Plate
The N-ELR is a single End-of-Line resistor plate which is required for use in Canada. An ELR, which is supplied with each module and fire alarm control panel, is mounted to the ELR plate. Resistors mounted to the N-ELR plate can be used for the supervision of a monitor and control module circuit.
1.7 Optional Modules
The Unimode 9600 main circuit board includes option module connectors for the following modules:
4XTMF Transmitter Module
The 4XTMF provides a supervised output for local energy municipal box transmitter, alarm and trouble reverse polarity. It includes a disable switch and disable trouble LED. A jumper on the module is used to select an option which allows the reverse polarity circuit to open with a system trouble condition if no alarm condition exists. The module plugs into connectors J10 and J11 which are located near the top center of the main circuit board. When the 4XTMF module is installed, Jumper JP6, on the main circuit board, must be cut to allow supervision of the module.
SLC-2 Expander Module
The SLC-2 Expander Module allows expansion of the Unimode 9600 from one SLC circuit to two SLC circuits. The module plugs into connector J3 which is located in the lower right corner of the main circuit board. The wiring for the second SLC connects to terminals located on the expander module.
20 |
Unimode 9600 PN 51336:C 11/06/01 |
Accessories |
Product Description |
1.8Accessories
1.8.1PK-9600 Programming Utility
The PK-9600 Programming Utility can be used to program an Unimode 9600 directly from most IBM compatible computers, including laptops and portables, equipped with a serial port. Unimode 9600 program files can also be created and stored on the PC and then downloaded to the control panel. The PK-9600 Kit includes the Windows-based Programming Utility software on CD-ROM with on-line help file. A serial cable (P/N: PRT/PK-CABLE), which must be purchased separately, is required for connection of the PC to the RS-232 (PC/Printer) terminals at TB7 of the Unimode 9600 main circuit board. Refer to the illustration on page 10 and the section titled "Printer/PC" on page 34, for the location and connections to this terminal.
1.8.2 Dress Panel
A dress panel is provided standard with the Unimode 9600 (required for Canadian installations). The dress panel restricts access to the system wiring while allowing access to the key panel.
Note that the Unimode 9600 FACP, installed with the dress panel, has received Factory Mutual (FM) approval. FM approval is contingent on the proper installation of the dress panel.
CAUTION: HIGH VOLTAGE UNDER PANEL
!! WARNING !!
SEVERAL DIFFERENT SOURCES OF POWER
CAN BE CONNECTED TO THIS CONTROL UNIT DISCONNECT ALL SOURCES OF POWER BEFORE SERVICING
dp9600.cdr
1.8.3 Battery Box
BB-17F
The BB-17F battery box may be used to house up to two 18 AH batteries in the event that room is not available in the main cabinet due to the use of a ADT-UDACT, 411UD, etc. The battery box mounts directly below the FACP cabinet. The battery box is red and is provided with knockouts.
bb-17f.cdr
Unimode 9600 PN 51336:C 11/06/01 |
21 |
Product Description |
Accessories |
BB-55F
The BB-55F battery box may be used to house two 25 AH batteries, two 60 AH batteries or one 100 AH battery. When the ADT-CHG-120 is mounted in the BB-55F, two 25 AH or one 60 AH battery may also be housed in the battery box.
bb-55f.cdr
Reference
Manual
Reference
Manual
1.8.4 ADT-CHG-120 Battery Charger
The ADT-CHG-120 is capable of charging up to 120 AH lead-acid batteries with the Unimode 9600 FACP. The FACP battery charger must be disabled when using the ADT-CHG-120. The batteries and charger can be housed in the BB-55F battery box which can be mounted up to 20 feet away from the control panel. Note that when using the BB-55F for housing the charger and batteries greater than 25AH, multiple BB-55Fs are required. Refer to the ADT-CHG-120 Manual for additional information.
1.8.5 Annunciators
ADT-ACS Series LED Zone Type Annunciators
The ADT-ACS Series Annunciators remotely display alarm and trouble status as well as system status. In addition, they can provide remote Acknowledge, Silence, Reset and Drill functions. For more detailed information, refer to the appropriate ADT-ACS annunciator manual. Following is a list of annunciators which can be used with the Unimode 9600.
•ADT-ACM-16AT Annunciator Control Module annunciates 16 zones with 16 red alarm LEDs and 16 yellow trouble LEDs. In addition, it has a System Trouble LED, an On Line/Power LED and a local piezo sounder. It also has switches for FACP Acknowledge, Silence, Reset and Drill. It has rotary address switches and will accept up to three AEM-16AT Expanders
•AEM-16AT Annunciator Expander Module annunciates 16 zones with 16 red alarm LEDs and 16 yellow trouble LEDs
•ADT-AFM-16AT Annunciator Fixed Module annunciates 16 zones with 16 red alarm LEDs and 16 yellow trouble LEDs. In addition, it has a System Trouble LED, an On Line/Power LED and a local piezo sounder. It also has switches for FACP Acknowledge, Silence, Reset and Drill. It is fixed at address ‘1’
•ADT-ACM-32A Annunciator Control Module annunciates 32 alarm zones with 32 red LEDs. In addition, it has a System Trouble LED, an On Line/Power LED and a local piezo sounder. It also has a switch for local piezo silence. It has rotary address switches and will accept one AEM-32A Expander
•AEM-32A Annunciator Expander Module annunciates 32 alarm zones with 32 red LEDs
•ADT-AFM-16A Annunciator Fixed Module annunciates 16 alarm zones with 16 red alarm LEDs. In addition, it has a System Trouble LED, an On Line/Power LED and a local piezo sounder. It also has a switch for local piezo silence. It is fixed at address ‘1’
•ADT-AFM-32A Annunciator Fixed Module annunciates 32 alarm zones with 32 red LEDs
22 |
Unimode 9600 PN 51336:C 11/06/01 |
Getting Started
Reference
Manual
Reference
Manual
Product Description
ADT-LCD-80F Remote Fire Annunciator
The ADT-LCD-80F annunciator is a compact 80-character backlit LCD remote fire annunciator that is capable of displaying English language text. It mimics the display on the control panel and will annunciate device type, point alarm, trouble or supervisory condition, zone assignment plus any custom alpha labels programmed into the FACP. The annunciator also provides system status LEDs to display AC Power, Alarm, Trouble, Supervisory and Alarm Silenced conditions. Additionally, the ADT-LCD-80F is capable of remotely performing critical system functions such as Acknowledge, Silence, Reset and Drill.
Communications between the control panel and the annunciator is accomplished over a serial interface employing the EIA-485 communication standard. Up to 32 ADT-LCD- 80F annunciators may be connected to the EIA-485 circuit. The annunciators may be powered from the host FACP or a remote UL listed filtered power supply such as the FCPS Series. For more detailed information, refer to the ADT-LCD-80F manual.
ADT-LDM Series Lamp Driver Modules (Graphic Annunciator)
The ADT-LDM Series Lamp Driver Modules, which consist of the ADT-LDM-32 master and ADT-LDM-E32 expander modules, are used to provide an interface to a custom graphic LED annunciator. The master module provides power and control for a maximum of three expander modules. The ADT-LDM-32 and ADT-LDM-E32 have output connectors which are used to drive lamps or LEDs and input connectors which are used for remote switch functions. Refer to the ADT-LDM Series Lamp Driver Modules manual for a complete description.
1.9 Getting Started
The following is a brief summary of the minimal steps involved in bringing an Unimode 9600 on-line:
•Install Backbox and Main Circuit Board (refer to "Mounting" on page 24)
•Address and Install Intelligent Devices (refer to the SLC Wiring Manual)
•Enter Autoprogramming (refer to "Autoprogram" on page 87)
•Resolve Programming Conflicts
Go to Point Program to Enter Specific Data (refer to "Point Program" on page 43). Use the right and left arrow keys to navigate between devices.
Unimode 9600 PN 51336:C 11/06/01 |
23 |
Installation
SECTION 2
Mounting
Installation
2.1 Mounting
!
See Page
The cabinet may be either semi-flush or surface mounted. The cabinet mounts using two key slots and two 0.250” (6.35 mm) diameter holes located in the backbox. The key slots are located at the top of the backbox and the two securing holes at the bottom.
Carefully unpack the system and check for shipping damage. Mount the cabinet in a clean, dry, vibration-free area where extreme temperatures are not encountered. The area should be readily accessible with sufficient room to easily install and maintain the panel. Locate the top of the cabinet approximately 5 feet (1.5 m) above the floor with the hinge mounting on the left. Determine the number of conductors required for the devices to be installed. Sufficient knockouts are provided for wiring convenience. Select the appropriate knockout(s) and pull the conductors into the box. All wiring should be in accordance with the National and/or Local codes for fire alarm systems.
The circuit board contains static-sensitive components. Always ground yourself with a proper wrist strap before handling any boards so that static charges are removed from the body. Use static suppressive packaging to protect electronic assemblies.
Mark and predrill holes in the wall for the top two keyhole mounting bolts using the dimensions illustrated in Figure 2.2 on page 25
Install two upper fasteners in the wall with the screw heads protruding
Using upper ‘keyholes,’ place backbox over the two screws, level and secure
Mark and drill the lower two holes
Mount backbox, install remaining fasteners and tighten
Screw supplied standoffs onto mounting studs in locations indicated below
When the location is dry and free of construction dust, install the main circuit board by aligning the 10 mounting holes in the circuit board with the 10 mounting standoffs in the backbox as illustrated below
Secure the circuit board to the standoffs with the supplied screws and male/ female standoff as indicated in following figure
IMPORTANT!
Secure circuit board to this standoff with supplied male/female standoff
Unimode 9600 Main Circuit Board
TB3 |
|
|
TB4 |
TB5 |
TB6 |
TB7 |
TB8 |
|
JP3 |
|
|
|
|
|
|
|
|
CUT TO |
|
|
|
|
|
|
|
|
DISABLE |
|
|
|
|
JP5 |
|
|
|
LOCAL |
|
|
|
|
|
|
|
|
CHARGER |
|
|
|
|
|
|
|
|
|
|
4XTM OPT BD |
JP11 |
|
|
|
|
|
|
JP10 |
|
|
|
|
|||
JP2 |
|
|
|
|
|
|
|
96brdmnt.cdr |
DISABLE |
|
|
|
J2 |
|
|
|
|
GND |
|
|
|
|
|
|
|
|
FLT |
|
|
|
OPT DACT |
|
|
OPT SLC |
|
|
|
CUT TO |
|
|
|
|
|
|
|
|
MONITOR 4XTM |
|
|
|
|
|
|
J17 |
J16 |
JP6 |
J6 |
J8 |
SW1 |
|
|
|
|
|
|
|
|
|
|||
|
|
LCD DISPLAY |
|
KEYPAD I/F |
|
|
|
|
|
|
TB1 |
TB2 |
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
J3 |
|
|
CB1 |
HOT NEUTEARTH |
+BATTERY- |
|
J7 |
|
|
|
mounting studs |
mounting studs |
|
Unimode 9600 Backbox
Figure 2.1 Unimode 9600 Main Circuit Board Installation
24 |
Unimode 9600 PN 51336:C 11/06/01 |
Mounting |
Installation |
|
|
|
|
|
5.1 cm |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4.45 cm |
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||
1.75“ |
|
|
|
|
2.00“ |
|
|
|
|
2.00“ |
|
|
|
|
2.00“ |
|
|
|
|
2.00“ |
|
|
|
|
2.00“ |
|
|
|
|
2.00“ |
|
|
|
|
1.75“ |
|
1.50“ (3.81 cm)
3.79 cm |
15.5“ (39.37 cm) |
3.81 cm |
|
1.49“ |
1.62“ (4.11 cm) |
||
1.50“ |
|||
|
12.00“ (30.48 cm) |
||
4.1 cm |
1.453“ (3.69 cm) |
4.1cm |
|
1.62“ |
1.62“ |
||
|
|||
|
10.0“ |
|
|
|
25.4 cm |
|
|
|
|
47.0cm |
|
|
|
18.5“ |
|
|
|
4.45cm |
|
17.35 cm |
|
1.75“ |
|
|
|
||
6.83“ |
|
|
|
|
|
4.45cm |
|
|
|
1.75“ |
|
|
|
4.1cm |
|
|
|
1.583“ |
|
1.50“ |
|
4.37“ |
|
3.81 cm |
|
||
|
11.1 cm |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
11.1 cm |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
4.37“ |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
9600encl.cdr |
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
1.75“ |
|
|
|
||||||||
1.50“ (3.81 cm) |
|
|
|
|
|
||||||||||
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
4.45 |
|
|
|
|
|
||||||
|
|
|
|
cm |
|
|
|
|
Figure 2.2 Unimode 9600 Cabinet Mounting
Unimode 9600 PN 51336:C 11/06/01 |
25 |
Installation |
Mounting |
Top |
|
Depth = 4.37" (11.1 cm) |
|
|
|
|
Door = 15.78" (40.08 cm) |
Depth = |
|
4.425" |
|
|
Backbox = 15.5" (39.37 cm) |
|
|
(11.24 cm) |
|
|
|
Door = 18.67" (47.43 cm)
Backbox = 18.5" (47.0 cm)
Left Side |
|
|
|
Bottom |
|
18.620" |
|
|
(47.3 cm) |
|
|
15.625" |
|
|
(39.688 cm) |
|
|
18.625" |
21.620" |
|
(54.92 cm) |
||
(47.308 cm) |
||
|
||
Trim Ring |
Battery Box = 14.34" (36.42 cm) |
|
P/N:FC-TR |
|
Right Side
Battery Box = 8.5" (21.59 cm)
Depth = 4.75" (12.07 cm)
9600cab.cdr
Figure 2.3 Unimode 9600 Cabinet Dimensions
26 |
Unimode 9600 PN 51336:C 11/06/01 |
Power |
Installation |
2.2 Power
WARNING: Several different sources of power can be connected to this panel. Disconnect all sources of power before servicing. The panel and associated equipment may be damaged by removing and/or inserting cards, modules or interconnecting cables while this unit is energized.
2.2.1 AC Power and Earth Ground Connection
Primary power required for the FACP is 120 VAC, |
LCD DISPLAY |
|
60 Hz, 3.2 amps. Overcurrent protection for this |
TB1 |
TB2 |
circuit must comply with Article 760 of the National |
|
|
Electrical Code (NEC) and/or local codes. Use 14 |
|
|
AWG (2.00 mm2) or larger wire with 600 volt |
CB1 HOT NEUT EARTH |
+BATTERY- |
insulation rating. Make certain that the AC mains |
circuit breaker is off before making any wiring
connections between the mains and the control panel. Connect the wiring from the AC mains to TB1 on the FACP, being careful to observe proper connections.
Connect a wire from the grounding stud in the cabinet to a known solid earth ground. This connection is vital for maintaining the control panel’s immunity to unwanted transients generated by lightning and electrostatic discharge. Apply AC power to the panel only after the system is completely installed and visually checked. Note that AC power must be applied to the panel before installing the battery interconnect cable (refer to the following section).
2.2.2 Battery Power
Before connecting the batteries to the FACP, make certain that the interconnect cable between the batteries is not connected. Do not connect the interconnect cable until the system is completely installed. Observe polarity when connecting the batteries. Connect the
See Page battery cable to TB2 on the main circuit board. Refer "Power Supply Calculations" on page 127, for
calculation of the correct battery rating.
Interconnect Cable
- |
+ |
|
|
+ |
- |
|
WARNING: Battery contains sulfuric acid which can cause severe burns to the skin and eyes and can destroy fabrics. If contact is made with sulfuric acid, immediately flush the skin or eyes with water for 15 minutes and seek immediate medical attention.
2.2.3 DC Power Output Connection
All DC power outputs are power-limited.
Power-limited Resettable Power
3.0 amperes max., 24 VDC nominal filtered, resettable power can be drawn from TB3 Terminals 1(+) and 2(-)
Power-limited Nonresettable Power #1
3.0 amperes max. , 24 VDC nominal filtered, nonresettable power can be drawn from TB3 Terminals 3(+) and 4(-)
Power-limited Nonresettable Power #2
3.0 amperes max. , 24 VDC nominal filtered, nonresettable power can be drawn from TB3 Terminals 5(+) and 6(-)
+ - + - + -
1 |
2 |
3 |
4 |
5 |
6 |
9600tb3.cdr |
|
|
|
|
|
|
Figure 2.4 Power Outputs - 24 VDC
Unimode 9600 PN 51336:C 11/06/01 |
27 |
Installation |
Relays |
2.3 Relays
The FACP provides two programmable Form-C relays and one fixed fail-safe Form-C trouble relay, all with contacts rated for 2.0 amps @ 30 VDC (resistive) or 0.5 amps @ 30 VAC (resistive). The Alarm and Supervisory silk-screen labels reflect the factory default programming for the two programmable relays.
Note that relay connections may be power-limited or nonpower-limited, provided that 0.25” spacing is maintained between conductors of power-limited and nonpower-limited circuits. Refer to UL Power-limited wiring requirements.
Note that the relays labeled as Alarm Relay (Relay 1) and Supervisory Relay (Relay 3) reflect the factory default programming for these relays which are programmable.
The relay labeled Trouble Relay (Relay 2) is fixed and cannot be changed. It is a failsafe relay which will transfer on any trouble or total power failure.
ALARM TROUBLE SUPV
RELAY RELAY RELAY
TB5 |
NO NC C NC NO C NO NC C |
|
9600reyp.cdr
Relay contacts shown with power applied to panel and no active troubles, alarms or supervisories
Figure 2.5 Relay Terminals
2.4 Notification Appliance Circuits
See Page
Reference
Manual
The control panel provides two NAC (Notification Appliance Circuits) configurable for Style Y/Class B or Style Z/Class A. Each circuit is capable of 3.0 amps of current. Total system current cannot exceed 7.2 amps (refer to "Calculating the System Current Draw" on page 128). Use UL listed 24 VDC notification appliances only. Circuits are supervised and power-limited. Refer to the ADT Device Compatibility Document for a listing of compatible notification appliances. The two NACs, which are located on the main circuit board, may be expanded via the FCPS Series field charger/power supplies. Surge protection for notification appliances may be provided by using one of the UL listed compatible surge suppressors listed in the ADT Device Compatibility Document.
Style Y (Class B) Notification Appliance Circuit, supervised and power-limited - 4.7 kohm, ½ watt P/N:71252 UL listed
Style Z (Class A) Notification Appliance Circuit, |
|
|
supervised and power-limited |
|
|
Polarized Bell |
+ |
+ |
Polarized Strobe |
|
+ |
Polarized Horn |
+ |
+ |
Polarized Bell
Polarized Horn
Polarized Horn
Notification Appliance Circuit |
TB4 |
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
|
|
|
|
|
|
|
Dummy Load all unused circuit |
||
polarity shown in alarm state |
|
B+ A+ A- B- B+ A+ A- B- |
Figure 2.6 NAC Connections
9600nac.cdr
28 |
Unimode 9600 PN 51336:C 11/06/01 |
UL Power-limited Wiring Requirements |
Installation |
2.5 UL Power-limited Wiring Requirements
|
AC P |
|
No |
o |
wer |
n |
||
|
p |
|
|
o |
|
|
we |
|
|
r-limi |
|
|
|
te |
|
|
d |
Power-limited and nonpower-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring must remain at least 0.25” (6.35 mm) away from any nonpower-limited circuit wiring and nonpower-limited circuit wiring must enter and exit the cabinet through different knockouts and/or conduits. A typical wiring diagram for the Unimode 9600 is shown below.
Power-limited Circuits
N |
|
|
|
||
|
o |
|
|
|
|
|
|
n |
|
|
|
|
|
p |
|
|
|
|
|
owe |
|
|
|
|
|
|
r- |
|
|
|
|
|
limi |
|
|
|
|
Ci |
rcuits |
te |
d |
|
|
|
|
P |
|
|
|
|
|
|
owe |
|
|
|
|
|
r- |
|
|
|
|
|
limi |
|
|
|
|
|
ted Ci |
|
|
|
|
|
rcuits |
|
|
|
|
|
|
4XTMF
|
|
|
|
|
|
|
|
|
|
P |
|
|
|
|
|
|
|
|
|
|
|
|
|
owe |
|
||
To |
E |
|
|
|
|
|
|
Ci |
rc |
r-li |
mited |
||
I |
A- |
|
|
|
|
ui |
|||||||
|
|
|
|
|
|
|
|
||||||
2 |
4 |
V |
|
4 |
8 |
5 a |
n |
d |
|
ts |
|
||
DC p |
|
|
|
||||||||||
|
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
||||
ro |
|
|
|
|
|
o |
|
|
|
|
|
||
|
|
|
|
|
|
we |
r |
|
|
|
|
||
|
u |
ted |
|
|
|
|
|
|
|
||||
|
|
b |
|
|
behi |
n |
|
|
|
|
|
||
|
|
oar |
|
|
d |
|
SLC-2 |
|
|
|
|||
|
|
|
|
|
d |
|
|
|
|
|
|
To Batteries
ADT-UDACT
ms-9600wireroute.cdr
No |
|
|
|
|
|
n |
|
|
|
|
p |
|
|
|
|
|
owe |
||
|
Ci |
|
r- |
|
|
|
limited |
||
|
|
|
rcuits |
|
P |
|
|
|
|
owe |
|
|
|
|
Circ |
r-lim |
ited |
||
ui |
|
|
||
|
ts |
|
|
|
Figure 2.7 Typical UL Power-limited Wiring Requirements
Unimode 9600 PN 51336:C 11/06/01 |
29 |
Installation |
Optional Modules and Devices |
2.6 Optional Modules and Devices
WARNING! Disconnect all sources of power (AC and DC) before installing or removing any modules or wiring.
Unimode 9600 Keypad/Display Removal
Removal of the keypad/display is normally not necessary. If, however, it becomes necessary to replace the keypad/display, access the auxiliary trouble bus connectors at J16 and J17 or install future option modules, the Keypad/Display can be removed by inserting a Phillips screwdriver into each of the three holes located in the flexible covering of the Keypad/Display and loosening the three mounting screws. Note that it is not necessary to disconnect the cables between the Keypad/Display and the main circuit board unless the unit itself is being replaced. Carefully lift the Keypad/Display and rest the unit at the bottom of the main circuit board.
|
|
|
|
Mounting Screw Access Hole |
|
|
|||||
TB3 |
|
|
|
|
|
TB4 |
TB5 |
|
TB6 |
TB7 |
TB8 |
JP3 |
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
||
CUT TO |
|
|
|
|
|
|
JP6 |
|
|
|
|
DISABLE |
|
|
|
|
|
|
JP5 |
|
|
||
LOCAL |
|
|
|
|
|
|
|
|
|
|
|
CHARGER |
|
|
4XTM OPT BD |
|
|
|
|
|
|
||
|
|
JP10 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
AC POWER |
|
MAINTENANCE |
|
|
|
|
|
|
|
|
|
FIRE ALARM |
|
ALARM |
|
|
|
|
|
|
|
|
|
|
|
SILENCED |
|
|
|
|
|
|
|
|
|
SUPERVISORY |
|
DISABLED |
|
|
|
|
|
|
|
|
|
TROUBLE |
|
BATTERY |
|
|
|
|
|
|
|
|
|
|
|
GROUND |
|
|
JP2 |
|
|
|
|
|
ACK/STEP |
|
|
|||
|
1 |
|
2 |
3 |
JP8 |
1st |
|
|
|||
|
|
|
|
|
|
|
|||||
DISABLE |
|
|
ABC |
DEF |
EVENTJP7 |
J2 |
ALARM |
|
|
||
GND |
|
|
|
|
|
|
|
|
|
||
FLT |
4 |
|
5 |
6 |
|
CLR |
|
SILENCE |
|
OPT SLC |
|
|
|
OPT DACT |
|
|
|||||||
|
|
GHI |
|
CUT TO |
MNO |
|
ENTER |
|
|
|
|
|
|
|
JKL |
|
|
|
|
|
|
||
|
|
|
|
MONITOR 4XTM |
|
|
|
|
|
|
|
J177 |
J168 |
9 JP6 |
ESC |
J8 |
DRILL |
|
|
||||
|
|
PRS |
|
TUV |
WXY |
J6 |
HOLD 2 SECJP4 |
|
|
||
|
|
|
|
|
|
1 |
|
|
|||
|
|
|
|
LCD DISPLAY MODE |
|
|
|
|
|||
|
* |
|
0 |
|
|
2 |
|
|
|||
|
|
# TB1 |
TB2 |
KEYPAD I/F |
|
RESET3 |
|
|
|||
|
|
QZ |
|
|
-/. |
|
|
|
|
|
J3 |
|
|
|
RECALL |
|
|
|
|
|
|
||
|
|
CB1 |
HOT NEUT EARTH |
+BATTERY- |
|
|
J7 |
|
|
Mounting Screw Access Holes
Figure 2.8 Keypad/Display Removal
96dact1.cdr
30 |
Unimode 9600 PN 51336:C 11/06/01 |
