ADT Security Services ADT-UDACT User Manual

One Town Center Road
Security Services Inc.
Boca Raton, FL 33431 Phone: (561) 988-3600 FAX: (561) 988-3675
The ADT-UDACT
Universal Digital Alarm Communicator/Transmitter
udactnot.wmf
Product Information, Installation,
Programming and Operation Manual
Document 50934 5/15/00 Rev:
P/N 50934:B ECN 99-402
© 2000 ADT
Fire Alarm System Limitations
While a fire alarm system may lower insurance rates, it is not a substitute for fire insurance!
An automatic fire alarm system–typically made up of smoke detectors, heat detectors, manual pull stations, audible warn­ing devices, and a fire alarm control with remote notification capability–can provide early warning of a developing fire. Such a system, however, does not assure protection against property damage or loss of life resulting from a fire.
The Manufacturer recommends that smoke and/or heat detec­tors be located throughout a protected premise following the recommendations of the current edition of the National Fire Protection Association Standard 72 (NFPA 72), manufacturer's recommendations, State and local codes, and the recommendations contained in the Guide for Proper Use of System Smoke Detectors, which is made available at no charge to all installing dealers. A study by the Federal Emer­gency Management Agency (an agency of the United States government) indicated that smoke detectors may not go off in as many as 35% of all fires. While fire alarm systems are de­signed to provide early warning against fire, they do not guar­antee warning or protection against fire. A fire alarm system may not provide timely or adequate warning, or simply may not function, for a variety of reasons:
Smoke detectors may not sense fire where smoke cannot reach the detectors such as in chimneys, in or behind walls, on roofs, or on the other side of closed doors. Smoke detectors also may not sense a fire on another level or floor of a build­ing. A second-floor detector, for example, may not sense a first-floor or basement fire.
Particles of combustion or "smoke" from a developing fire may not reach the sensing chambers of smoke detectors be­cause:
• Barriers such as closed or partially closed doors, walls, or chimneys may inhibit particle or smoke flow.
• Smoke particles may become "cold," stratify, and not reach the ceiling or upper walls where detectors are located.
• Smoke particles may be blown away from detectors by air outlets.
• Smoke detectors may be drawn into air returns before reaching the detector.
The amount of "smoke" present may be insufficient to alarm smoke detectors. Smoke detectors are designed to alarm at various levels of smoke density. If such density levels are not created by a developing fire at the location of detectors, the detectors will not go into alarm.
Smoke detectors, even when working properly, have sensing limitations. Detectors that have photoelectronic sensing chambers tend to detect smoldering fires better than flaming fires, which have little visible smoke. Detectors that have ion­izing-type sensing chambers tend to detect fast-flaming fires better than smoldering fires. Because fires develop in differ­ent ways and are often unpredictable in their growth, neither type of detector is necessarily best and a given type of detec­tor may not provide adequate warning of a fire.
Smoke detectors cannot be expected to provide adequate warning of fires caused by arson, children playing with matches (especially in bedrooms), smoking in bed, and violent explosions (caused by escaping gas, improper storage of flammable materials, etc.).
Heat detectors do not sense particles of combustion and alarm only when heat on their sensors increases at a prede­termined rate or reaches a predetermined level. Rate-of-rise heat detectors may be subject to reduced sensitivity over time. For this reason, the rate-of-rise feature of each detector should be tested at least once per year by a qualified fire pro­tection specialist.
Heat detectors are designed to protect
property, not life.
IMPORTANT!
Smoke detectors must be installed in the
same room as the control panel and in rooms used by the sys­tem for the connection of alarm transmission wiring, communi­cations, signaling, and/or power.
cated, a developing fire may damage the alarm system, crip­pling its ability to report a fire.
Audible warning devices such as bells may not alert people if these devices are located on the other side of closed or partly open doors or are located on another floor of a building. Any warning device may fail to alert people with a disability or those who have recently consumed drugs, alcohol or medica­tion. Please note that:
Strobes can, under certain circumstances, cause seizures in people with conditions such as epilepsy.
Studies have shown that certain people, even when they hear a fire alarm signal, do not respond or comprehend the meaning of the signal. It is the property owner's responsibil­ity to conduct fire drills and other training exercise to make people aware of fire alarm signals and instruct them on the proper reaction to alarm signals.
In rare instances, the sounding of a warning device can cause temporary or permanent hearing loss.
A fire alarm system will not operate without any electrical power. If AC power fails, the system will operate from standby batteries only for a specified time and only if the batteries have been properly maintained and replaced regularly.
Equipment used in the system may not be technically com­patible with the control. It is essential to use only equipment listed for service with your control panel.
Telephone lines needed to transmit alarm signals from a premise to a central monitoring station may be out of service or temporarily disabled. For added protection against tele­phone line failure, backup radio transmission systems are rec­ommended.
The most common cause of fire alarm malfunction is inade­quate maintenance. To keep the entire fire alarm system in excellent working order, ongoing maintenance is required per the manufacturer's recommendations, and UL and NFPA stan­dards. At a minimum, the requirements of Chapter 7 of NFPA 72 shall be followed. Environments with large amounts of dust, dirt or high air velocity require more frequent mainte­nance. A maintenance agreement should be arranged through the local manufacturer's representative. Maintenance should be scheduled monthly or as required by National and/ or local fire codes and should be performed by authorized pro­fessional fire alarm installers only. Adequate written records of all inspections should be kept.
If detectors are not so lo-
Precau-Lg.p65 01/18/2000
Installation Precautions
Adherence to the following will aid in problem-free installation with long-term reliability:
WARNING -
nected to the fire alarm control panel.
of power before servicing. Control unit and associated equip­ment may be damaged by removing and/or inserting cards, modules, or interconnecting cables while the unit is energized. Do not attempt to install, service, or operate this unit until this manual is read and understood.
CAUTION -
Changes.
must be tested in accordance with NFPA 72 Chapter 7 after any programming operation or change in site-specific soft­ware. Reacceptance testing is required after any change, ad­dition or deletion of system components, or after any modifica­tion, repair or adjustment to system hardware or wiring.
All components, circuits, system operations, or software func­tions known to be affected by a change must be 100% tested. In addition, to ensure that other operations are not inadvert­ently affected, at least 10% of initiating devices that are not directly affected by the change, up to a maximum of 50 de­vices, must also be tested and proper system operation veri­fied.
This system meets NFPA requirements for operation at 0-49° C/32-120° F condensing) at 30° C/86° F. However, the useful life of the system's standby batteries and the electronic components may be adversely affected by extreme temperature ranges and humidity. Therefore, it is recommended that this system and all peripherals be installed in an environment with a nomi­nal room temperature of 15-27° C/60-80° F.
Verify that wire sizes are adequate for all initiating and indicating device loops. Most devices cannot tolerate more than a 10% I.R. drop from the specified device voltage.
Several different sources of power can be con-
Disconnect all sources
System Reacceptance Test after Software
To ensure proper system operation, this product
and at a relative humidity of 85% RH (non-
Like all solid state electronic devices, this system may operate erratically or can be damaged when subjected to light­ning-induced transients. Although no system is completely immune from lightning transients and interferences, proper grounding will reduce susceptibility.
Overhead or outside aerial wiring is not recommended, due to an increased sus­ceptibility to nearby lightning strikes.
cal Services Department if any problems are anticipated or encountered.
Disconnect AC power and batteries prior to removing or in­serting circuit boards. Failure to do so can damage circuits.
Remove all electronic assemblies prior to any drilling, filing, reaming, or punching of the enclosure. When possible, make all cable entries from the sides or rear. Before making modifi­cations, verify that they will not interfere with battery, trans­former, and printed circuit board location.
Do not tighten screw terminals more than 9 in-lbs. Over-tightening may damage threads, resulting in reduced terminal contact pressure and difficulty with screw terminal removal.
Though designed to last many years, system components can fail at any time. This system contains static-sensitive components. Always ground yourself with a proper wrist strap before handling any circuits so that static charges are re­moved from the body. Use static-suppressive packaging to protect electronic assemblies removed from the unit.
Follow the instructions in the installation, operating, and programming manuals. These instructions must be followed to avoid damage to the control panel and associated equipment. FACP operation and reliability depend upon proper installation by authorized personnel.
Consult with the Techni-
FCC Warning
WARNING: This equipment generates, uses, and can
radiate radio frequency energy and if not installed and used in accordance with the instruction manual, may cause interference to radio communications. It has been tested and found to comply with the limits for class A computing device pursuant to Subpart B of Part 15 of FCC Rules, which is designed to provide reasonable protection against such interference when operated in a commercial environment. Operation of this equipment in a residential area is likely to cause interference, in which case the user will be required to correct the interference at his own expense.
Canadian Requirements
This digital apparatus does not exceed the Class A limits for radiation noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.
Le present appareil numerique n'emet pas de bruits radioelectriques depassant les limites applicables aux appareils numeriques de la classe A prescrites dans le Reglement sur le brouillage radioelectrique edicte par le ministere des Communications du Canada.
Precau-Lg.p65 01/18/2000
NFPA Standards, NFPA 72 National Fire Alarm Code ................................................................... 6
Underwriters Laboratories Documents ............................................................................................ 6
1.0 Product Description ................................................................................................................ 7
1.1 Product Features ............................................................................................................... 7
Figure 1-1: ADT-UDACT Assembly ................................................................................... 8
1.2 Controls and Indicators......................................................................................................9
1.3 Compatible Panels ............................................................................................................. 9
1.4 Digital Communicator ........................................................................................................ 9
1.5 Circuits ............................................................................................................................. 10
1.5.1 Power Requirements .............................................................................................. 10
1.5.2 Communications ..................................................................................................... 10
1.5.3 Primary and Secondary Phone Lines..................................................................... 10
1.5.4 Communicator Fail Relay Driver ............................................................................ 1 0
1.5.5 Earth Ground .......................................................................................................... 10
1.6 Future Use....................................................................................................................... 10
1.7 Specifications................................................................................................................... 11
1.8 Telephone Requirements
and Warnings................................................................................................................... 11
1.8.1 Telephone Circuitry - PH1 & PH2 ......................................................................... 11
1.8.2 Digital Communicator: ........................................................................................... 11
1.8.3 Telephone Company Rights and Warnings: ........................................................ 11
1.9 Modes and Special Functions ......................................................................................... 1 2
1.9.1 Normal Mode: ......................................................................................................... 12
1.9.2 Program Mode: ....................................................................................................... 12
1.9.3 Lamp Test Mode: .................................................................................................... 1 2
1.9.4 Troubleshoot Mode:................................................................................................ 12
1.9.5 Type Mode: ............................................................................................................. 12
1.9.6 Clear Function: ....................................................................................................... 13
2.0 Installation and Wiring.......................................................................................................... 14
3.0 Programming Instructions ...................................................................................................18
4.0 Operating Instructions........................................................................................................... 30
Table of Contents
1.9.7 Manual Test Function: ............................................................................................ 13
2.1 General............................................................................................................................. 14
2.2 Output Circuits ................................................................................................................. 14
Figure 2-1: Wiring Phone Jacks ..................................................................................... 1 4
Figure 2-2: Relay Driver Connections ............................................................................. 15
Figure 2-3: Monitoring for ADT-UDACT Trouble ............................................................. 16
2.3 UL Power-
limited Wiring Requirements ........................................................................................... 1 7
Figure 2-4: Typical Wiring Diagram for UL Power-limited Requirements ..................... 17
3.1 Entering Program Mode................................................................................................... 18
3.2 Switch Functions.............................................................................................................. 19
Figure 3-1: ADT-UDACT Keypad .................................................................................... 1 9
3.3 Programming Options...................................................................................................... 19
Table 3-1: Start and End Monitoring Addresses ............................................................. 2 2
Table 3-2: Event Codes, Primary Number ...................................................................... 24
Table 3-3: Event Codes, Primary Number ...................................................................... 25
Table 3-4: Ademco Contact ID, Primary Number ........................................................... 26
Table 3-5: Event Codes, Secondary Number ................................................................. 2 7
Table 3-6: Event Codes, Secondary Number ................................................................. 2 8
Table 3-7: Ademco Contact ID, Secondary Number....................................................... 2 9
4.1 Normal Mode.................................................................................................................... 30
4.1.1 Keys ....................................................................................................................... 30
4.1.2 Displays:.................................................................................................................. 31
Figure 4-1: ADT-UDACT Phone Connectors and LEDs ................................................. 32
4.1.3 Normal Mode Operation: ........................................................................................ 32
4.1.4 Key Report Descriptions......................................................................................... 34
4.2 Type Mode ....................................................................................................................... 34
4.2.1 Disabling of Zones or Points .................................................................................. 35
4.2.2 Zone or Point Supervisory ...................................................................................... 36
4.3 Troubleshoot Mode .......................................................................................................... 3 6
Figure 4-2: Handset/Speaker Connection....................................................................... 37
4.4 Lamp Test Mode .............................................................................................................. 37
4
Document 50934 Rev B 5/15/00 PN 50934:B
5.0 Reporting Formats ................................................................................................................. 38
6.0 Compatible Receivers........................................................................................................... 42
7.0 Programming Reference Sheets .......................................................................................... 43
Appendix A: Zone Assignments
Appendix B: Point Assignments (Unimode 300*/400)............................................................. 48
Appendix C: Point Assignments (ADT-MNNA) ........................................................................ 51
Appendix D: Unimode 2020/1010................................................................................................ 5 6
Appendix E: Unimode 300/400 .................................................................................................... 59
Appendix F: ADT-MNNA............................................................................................................... 62
Appendix G: Annunciators .......................................................................................................... 65
Table 5-1: Data Reporting Structure ............................................................................... 3 8
Table 5-2: Letter Code Definitions................................................................................... 39
Table 5-3: Ademco Contact ID Reporting Structure ....................................................... 40
Table 6-1: Compatible UL Listed Receivers ................................................................... 42
(Unimode 300/400) ................................................................................................................ 47
Figure D-1: ADT-UBS-1F................................................................................................. 56
Figure D-2: ADT-UDACT Mounting in CHS-4 ................................................................. 56
Figure D-3: EIA-485 Connection to Panel Mounted ADT-UDACT.................................. 57
Figure D-4: EIA-485 Connection to Remote ADT-UDACT ............................................. 58
Figure E-1: ADT-ABS8RF ................................................................................................ 59
Figure E-2: ADT-CPU-400 Module .................................................................................. 59
Figure E-3: Unimode 400 External ADT-UDACT Mounting in ADT-ABS8RF ................ 6 0
Table of Contents
Document 50934 Rev B 5/15/00 PN 50934:B
5
This digital communicator has been designed to comply with standards set forth by the following regulatory agencies:
• Underwriters Laboratories Standard UL 864
NFPA Standards 72 National Fire Alarm Code for Local, Remote Station and Central Station Fire Alarm Systems
Before proceeding, the installer should be familiar with the following documents.
NFPA Standards, NFPA 72 National Fire Alarm Code:
• Central Station Fire Alarm Systems (Automatic, Manual and Waterflow) Protected Premises Unit.
• Local (Automatic, Manual, Waterflow and Sprinkler Supervisory) Fire Alarm Systems.
• Proprietary Fire Alarm Systems (Protected Premises Unit).
• Automatic Fire Detectors
• Installation, Maintenance, and Use of Notification Appliances for Fire Alarm Systems.
• Inspection, Testing and Maintenance for Fire Alarm Systems.
Underwriters Laboratories Documents:
UL 38 Manually Actuated Signaling Boxes UL 217 Smoke Detectors, Single and Multiple Station UL 228 Door Closers—Holders for Fire Protective Signaling Systems UL 268 Smoke Detectors for Fire Protective Signaling Systems UL 268A Smoke Detectors for Duct Applications UL 346 Waterflow Indicators for Fire Protective Signaling Systems UL 464 Audible Signaling Appliances UL 521 Heat Detectors for Fire Protective Signaling Systems UL 864 Standard for Control Units for Fire Protective Signaling Systems UL 1481 Power Supplies for Fire Protective Signaling Systems UL 1638 Visual Signaling Appliances
Other:
NEC Article 300 Wiring Methods NEC Article 760 Fire Protective Signaling Systems Applicable Local and State Building Codes Requirements of the Local Authority Having Jurisdiction
Relevant ADT Manuals:
Unimode 2020/1010 manual Document #51167 Unimode 300/400 Programming Document #50708 Unimode 300/400 Operating Document #50709 Unimode 300/400 Installation Document #50710 AFM Annunciator Document #15048 ADT-ACS Annunciator Document #51353 ADT-LCD-80 Document #51354 ADT-MNNA Document #50929
6
Document 50934 Rev B 5/15/00 PN 50934:B
1.0 Product Description
The Universal Digital Alarm Communicator/Transmitter (ADT-UDACT) may be used with a variety of ADT control panels (refer to Appendices). The ADT-UDACT transmits system status to UL Listed Central Station Receivers via the public switched telephone network. The ADT-UDACT, which is compact in size, mounts internally in some panels or externally in a separate enclosure. EIA-485 annunciator communications bus and 24 volt (nominal) connections are required.
Primary Phone Line
Secondary Phone Line
Modular Cable
1.1 Product Features
• Dual telephone lines
• Dual telephone line voltage detect
• Surface mount technology
• Compact in size: 6.75" x 4.25"
• Built-in programmer
• Built-in four character red 7-segment LED display
• Manual test report function
• Manual master transmission clear function
• Mounts in separate ADT-ABS-8RF or ADT-UBS-1 enclosure
• Communicates vital system status including:
ü Independent zone/point alarm ü Independent zone/point trouble ü Independent zone/point supervisory ü AC (mains) power loss (programmable) ü Low battery and earth fault ü System off normal ü 12 or 24 hour test signal ü Abnormal test signal per new UL requirements ü Annunciation of ADT-UDACT troubles including: loss of
phone lines, communication failure with either Central Station, total communication failure
• Troubleshoot mode converts keypad to DTMF touchpad
• Individual LEDs for:
ü Power ü EIA-485 loss ü Manual Test ü Kissoff ü Comm Fail ü Primary Line Seize ü Secondary Line Seize
• Open collector relay driver for Total Communication Failure or ADT-UDACT trouble.
• Real Time Clock
• Extensive transient protection
• Simple EIA-485 interface to host panel
P/N MCBL-7
udactfea.wmf
Document 50934 Rev B 5/15/00 PN 50934:B
7
24VDC Power in (use power-limited source)
EIA-485 Connector (use power-limited source)
DO NOT USE
Primary Phone Line
Secondary Phone Line
Modular Cables P/N MCBL-7 (Order Separately)
Comm Fail Output (power-limited)
24 VDC (power-limited)
udactfea.wmf
Figure 1-1: ADT-UDACT Assembly
8
Document 50934 Rev B 5/15/00 PN 50934:B
1.2 Controls and Indicators
Front Panel Switches
CLEAR Digits 0-9 TEST A MODE B Up Arrow C Down Arrow D 1st EVENT E ENTER/STORE F
Displays
• EIA-485 - yellow LED
• COMM. FAIL - yellow LED
• KISS OFF - green LED
• POWER - green LED
• Four, Seven Segment Displays - red
• Primary Phone Line Active - red LED
• Secondary Phone Line Active - red LED
• TEST - green LED
DO NOTUSE
udactfea.wmf
Figure 1-2: Controls and Indicators
1.3 Compatible Panels
1.4 Digital Communicator
The ADT-UDACT has been designed to be compatible with the ADT Unimode 2020/ 1010, Unimode 300/400, and the ADT-MNNA.
Two modular phone jacks allow easy connection to telephone lines. Modular jacks are labeled PH1 and PH2 for the Primary and Secondary phone lines. Telephone line 'Primary and Secondary Active' red LEDs are provided as well as a green 'Kissoff' LED. The integral digital communicator provides the following functions:
• Line Seizure - takes control of the phone lines disconnecting any premises phones.
• Off/On Hook - perform on and off-hook status to the phone lines.
• Listen for dial tone - 440 hertz tone typical in most networks.
• Dialing the Central Station(s) number - default is Touch-Tone®, programmable to rotary.
Document 50934 Rev B 5/15/00 PN 50934:B
9
• For tone burst or touchtone type formats: Discern proper 'Ack' and 'Kiss-off' tone(s) - The frequency and time duration of the tone(s) varies with the transmission format. The ADT-UDACT will adjust accordingly.
• Communicate in the following formats (refer to Section 6.0 for compatible receivers): 6 Tone Burst Types: 20 pps (3+1, 4+1, 4+2) 3 Touchtone Types: 4 + 1 Ademco Express 4 + 2 Ademco Express Ademco Contact ID
The ADT-UDACT circuit board contains a CPU, other primary components and wiring interface connectors.
1.5 Circuits
1.5.1 Power Requirements
Operating voltage for the ADT-UDACT must be power-limited, filtered, nonresettable 21.2 to 28.2 volts. The 24 VDC nominal operating power must be supplied by the Control Panel and is connected to TB1 of the ADT-UDACT.
1.5.2 Communications
Communications between the ADT-UDACT and the host control panel is accomplished over a two wire EIA-485 serial interface which is power-limited and supervised by the control panel and the ADT-UDACT. The wiring connections are made to the RS+, RS- and Shield terminals of TB1 on the ADT-UDACT.
The EIA-485 circuit cannot be T-Tapped and must be wired in a continuous fashion from the control panel to the ADT-UDACT and, if installed, annunciators. The wire must be 12AWG to 18AWG twisted shielded pair cable with a Characteristic Impedance of 120 Ohms, +/-20%. Limit the total wire resistance to 100 Ohms on the EIA-485 circuit. Do not run cable adjacent to, or in the same conduit as 120 volts AC service, noisy electrical circuits that are powering mechanical bells or horns, audio circuits above 25 volts
, motor control circuits, or SCR power circuits.
RMS
1.5.3 Primary and Secondary Phone Lines
Modular jacks are used to interface the primary and secondary phone lines to the public telephone network.
1.5.4 Communicator Fail Relay Driver
Relay driver output for Central Station communication failure is available.
1.6 Optional Device
10
1.5.5 Earth Ground
An earth ground connection to the ADT-UDACT is required for transient protection. One option allows connection via TB3 terminal 1. A second option allows connection via the upper right corner mounting hole. Using a metal standoff and screws, attach to grounded metal cabinet.
Future Use.
Document 50934 Rev B 5/15/00 PN 50934:B
1.7 Specifications
DC Power - TB1, Terminals 1 & 2
24VDC (nominal) filtered, nonresettable and power-limited. Voltage range is 21.2 to
28.2 volts. DC Power TB1 Terminals 1 (+), 2 (-) 40 mA in standby, 75 mA max.
while communicating and 100 mA with the open collector output engaged and communicating.
Data Communications - TB1, Terminals 3 - 7
EIA-485 serial interface, TB1 Terminal 3 = RS+, 4 = RS-, 5= Shield, 6 = Future use, 7 = Future use. Power-limited source must be used.
Auxiliary Output - TB3, Terminals 2 & 3
TB3-2 = Communicator Failure. Power-limited circuit. An Open Collector type output, normally high, active low which sinks up to 40 mA. TB3-3 = 21.2 to 28.2 volts, power-limited. Use UL listed relay P/N: MR-101/C or MR-201/C with this output.
Earth Ground - TB3, Terminal 1
TB3-1 = Earth Ground connection. Connect this terminal to building earth ground using solid 12 AWG wire to provide lightning protection. This connection is not required when the ADT-UDACT is mounted in a grounded metal enclosure via the upper right mounting hole.
1.8 Telephone Requirements and Warnings
1.8.1 Telephone Circuitry - PH1 & PH2
Ringer Equivalence Number (REN) = 0.6B AC Impedance 10.0 Mega Ohm Complies with FCC Part 68 Mates with RJ31X Male Connector Supervision Threshold: less than 4.0 volts for 2 minutes
The REN is used to determine the quantity of devices which may be connected to the telephone line. Excessive REN's on the telephone line may result in the devices not ringing in response to an incoming call. In most, but not all areas, the sum of the REN's should not exceed five (5.0). To be certain of the number of devices that may be connected to the line, as determined by the total REN's, contact the telephone company to determine the maximum REN for the calling area.
1.8.2 Digital Communicator:
Before connecting the ADT-UDACT to the public switched telephone network, the installation of two RJ31X jacks is necessary. The following information is provided if required by the local telephone company :
Manufacturer : Notifier Fire Systems
One Fire-Lite Place Northford, CT 06472-1653
Product Model Number: ADT-UDACT FCC Registration Number: 1W6USA-20723-AL-E Ringer Equivalence 0.6B
1.8.3 Telephone Company Rights and Warnings:
The telephone company under certain circumstances may temporarily discontinue services and/or make changes in its facilities, services, equipment or procedures which may affect the operation of this control panel. However, the telephone company is required to give advance notice of such changes or interruptions.
Document 50934 Rev B 5/15/00 PN 50934:B
11
If the control panel causes harm to the telephone network, the telephone company reserves the right to temporarily discontinue service. Advance notification will be provided except in cases when advance notice is not practical. In such cases, notification will be provided as soon as possible. The opportunity will be given to correct any problems and to file a complaint.
DO NOT CONNECT THIS PRODUCT TO COIN TELEPHONE, GROUND START, OR PARTY LINE SERVICES.
When the control panel activates, premise phones will be disconnected.
Two separate phone lines are required. Do not connect both telephone interfaces to the same telephone line.
The control panel must be connected to the public switched telephone network upstream of any private telephone system at the protected premises.
An FCC compliant telephone cord must be used with this equipment. This equipment is designed to be connected to the telephone network or premises wiring using a compatible RJ31X male modular plug which is Part 68 compliant.
1.9 Modes and Special Functions
1.9.1 Normal Mode:
Normal mode is the standard mode of operation. In this mode, the ADT-UDACT monitors host FACP status as well as monitoring telephone line voltage. The ADT­UDACT reports system status information to UL listed Central Stations. Information transmitted includes general alarm, trouble and supervisory. It also transmits either the number of zones or points activated or the specific point(s) activated, depending upon the compatible panel, programming selections and transmission format selection. Specific system trouble conditions and specific ADT-UDACT troubles are also transmitted.
1.9.2 Program Mode:
Program mode is used to program the ADT-UDACT. While the ADT-UDACT is in the program mode, it cannot receive host FACP status information. See Section 3.0 for complete programming instructions.
1.9.3 Lamp Test Mode:
This mode turns on all segments of the 4 character display plus all LEDs on the ADT­UDACT.
1.9.4 Troubleshoot Mode:
Troubleshoot mode may be used for testing the telephone line wiring. Connection from the ADT-UDACT's modular jacks, through RJ31X jacks and into the telephone network may be easily checked. In this mode, the keypad acts similar to a telephone touchpad.
12
1.9.5 Type Mode:
Type Mode is used to define the specific type of device (point) used or function of a zone. Type Mode is also used to disable the alarm report for any zone/point in the system. The feature which disables the zone/point alarm report must be used for zones/points programmed into the host FACP as remote silence, reset, drill or acknowledge switches. Note: Unimode2020/1010 and ADT-MNNA applications
restrict Type Mode programming to a maximum of 568 points. All remaining points above 568 will report as fire alarm points only.
Document 50934 Rev B 5/15/00 PN 50934:B
1.9.6 Clear Function:
When the clear function is activated, it causes the ADT-UDACT to immediately stop transmissions, hang-up from the telephone network, clear out any messages that were waiting for transmission and reset.
1.9.7 Manual Test Function:
The manual test function allows for a test report message to be sent to both Central Stations upon activation.
Document 50934 Rev B 5/15/00 PN 50934:B
13
2.0 Installation and Wiring
2.1 General
2.2 Output Circuits
(Primary Lines) Incoming Telco Phone Lines
Mounting Options
For information on mounting the ADT-UDACT in a specific fire alarm control panel, refer to the appropriate Appendix.
Telephone Circuits
Provision to connect to two independent telephone lines is available via two telephone jacks labeled PH1 (Primary) and PH2 (Secondary). Telephone line control/ command is possible via double line seizure as well as usage of an RJ31X style interconnection. (RJ31X jacks must be ordered separately).
Note: It is critical that the ADT-UDACT be located as the first device on the incoming telephone circuit to properly function.
Green Wire
Tip
Red Wire
Tip
Ring
Green Wire Red Wire
Ring
To premise phones
Tip
Note: Shorting bars inside RJ31X Jack removed during male plug insertion
Ring
Ring
To premise phones
Tip
(Secondary Lines) Incoming Telco Phone Lines
Primary Phone Line PH-1
Modular Female Connectors
7 foot Cable (MCBL-7)
Order Separately
Male Plug Connectors
Secondary Phone Line PH-2
14
UDACJAKN.WMF
Figure 2-1: Wiring Phone Jacks
Document 50934 Rev B 5/15/00 PN 50934:B
Relay Driver
The ADT-UDACT's open collector output on TB3, terminal 2 is provided for Communicator Failure and ADT-UDACT trouble. It can be used to drive UL listed relay MR-101/C or MR-201/C. The output is rated for 40 mA. The normal condition for the output is Off (deenergized).
Communicator Failure occurs when the maximum number of attempts to reach both central stations has taken place or when both phone lines are disconnected. ADT­UDACT trouble conditions include loss of telephone line voltage to the primary and/ or secondary phone lines, communication failure to the primary or secondary central stations, total communication failure, entry into program, type and troubleshoot modes.
Wiring from the ADT-UDACT terminal TB3 to the relay must be in the same room no more than 20 feet in length and enclosed in conduit. Wiring from the relay output contacts must remain in the same room as the ADT-UDACT.
When the ADT-UDACT is programmed for 'Receive Only' (typically this occurs when annunciators are also used and are set for 'Receive/Transmit'), the relay output is used to provide a ADT-UDACT trouble input to the host control panel. For Unimode 2020/1010 applications, use a monitor module to supervise the relay closure. Refer to Figure 2.3. Program the custom label field to read 'UDACT Trouble'.
When the ADT-UDACT is programmed for 'Receive/Transmit', EIA-485 supervision and ADT-UDACT trouble status are automatically handled by the host control panel. The relay output may, however, be used for ADT-UDACT communications failure if desired.
TB3
Earth Gnd
Comm Fail
+24 VDC
All wiring to relay must be in the same room within 20 feet of ADT-UDACT and in conduit.
TB3
Earth Gnd
Comm Fail
+24 VDC
Relay Energized LED
MR-201/C *
Relay Energized LED
DPDT Contacts 10 Amps @ 115 VAC
Connections must be in same room as ADT-UDACT
SPDT Contacts 10 Amps @ 115 VAC
UDACTTB3.EPS
MR-101/C *
* Note: The MR-101/C and MR-201/C include an enclosure.
Figure 2-2: Relay Driver Connections
Document 50934 Rev B 5/15/00 PN 50934:B
15
Earth Grnd Comm Fail
+24 VDC
M300 Series
Monitor Module
All wiring to relay must be in the same room within 20 feet of ADT-UDACT and in conduit.
0 18/24 115 230
ON
SLC Loop to Fire Alarm Control Panel
Wiring in same room as ADT-UDACT
3.9K EOL Resistor (included)
NC C NO
ADT-UDACT
udactrbl.wmf
MR-101/C
(MR-201/C may be used)
Note: M300 Series Monitor Module is used to supervise Normally Closed output of MR-101/C. On ADT-UDACT
trouble and Comm Fail, MR-101/C relay contact will open causing the monitor module to transmit trouble condition to FACP.
Figure 2-3: Monitoring for ADT-UDACT Trouble
16
Document 50934 Rev B 5/15/00 PN 50934:B
2.3 UL Power­limited Wiring Requirements
Power-limited and nonpower-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring must remain at least 0.25" away from any nonpower-limited circuit wiring. Furthermore, all power-limited circuit wiring and nonpower-limited circuit wiring must enter and exit the cabinet through different knockouts and/or conduits. A typical wiring diagram for the ADT-UDACT is shown below.
Use power-limited source
DO NOT USE
Power-limited circuits
UDACPWRL.WMF
Figure 2-4: Typical Wiring Diagram for UL Power-limited Requirements
Document 50934 Rev B 5/15/00 PN 50934:B
17
3.0 Programming Instructions
Programming Mode
3.1 Entering Program Mode
Programming of the ADT-UDACT is possible at any time including while the ADT-UDACT is communicating with a Central Station.
The ADT-UDACT has been designed for many different types of applications. After examining your specific application, review the programming options and choose the entries best suited for your system.
The ADT-UDACT has a built-in programmer. All programming selections are stored in nonvolatile Electrically-Erasable Programmable Read-Only Memory (EEPROM). This ensures that the ADT-UDACT will retain all entries made in programming mode even if both AC and battery power are removed.
The user must program the primary and secondary phone numbers, account numbers and 24 hour test report times for each Central Station account and the current time. The ADT-UDACT comes with factory chosen options/features already programmed. Other options/features may be programmed if desired. If all factory default settings are acceptable, programming is complete.
To enter the Program Mode, press the MODE key once, (the display will go blank) you then have ten seconds to start entering the code (7764) .
7764 spells PROG on a Touch-Tone® phone
If an incorrect key is entered, reenter the proper 4-digit code before pressing the
[ENTER/STORE] key
___7 __77
_776 7764
You are allowed a pause of up to 10 seconds in between each number while entering the code. After pressing the [ENTER/STORE] key, the ADT-UDACT will be in Program Mode and display 00_F. You are allowed up to ten minutes of idle time at this point before starting your programming, otherwise the ADT-UDACT will go back to Normal Mode. You also have a maximum of 10 minutes between any key stroke. All entries made prior to the 10 minute time-out are valid and stored.
Once in Programming Mode, the ADT-UDACT will:
Ignore the Test and Clear keys.
Continue to communicate any events not previously acknowledged at the Central Station prior to entering Programming Mode.
Location 56 is factory set to = 0, ADT-UDACT communications disabled. This keeps
the communicator off until location 56 is changed to 1, 2, 3 or 4. Refer to program selection for address 56 in this section. Once location 56 is changed from 0 and a valid phone number is entered, transmission of the "ADT-UDACT off Normal" report will occur.
Note that as you enter information into the ADT-UDACT, the digits will scroll across the display from right to left
18
Document 50934 Rev B 5/15/00 PN 50934:B
Throughout programming mode, the first three locations on the left of the display represent the memory address which can range from 00 to 208 (Alpha characters are not used). The last location (farthest right) represents the contents of the memory address. The first address displayed is shown below:
00_F
(address)(data)
3.2 Switch Functions
3.3 Programming Options
The Function of each switch in program mode is shown below:
No function in this mode
- Select operating mode
Address entry keys are 0 to 9
Data entry keys are 0 to 9 and A to F
{
- Increment memory address
- Decrement memory address
- Once = First memory address Twice = type any address
- Save data, go to next address
UDACTKEY.WMF
Figure 3-1: ADT-UDACT Keypad
Primary phone number. (00-15)
The first sixteen addresses, 00-15, are factory set to 'F' (from 00_F to 15_F). Programming is typically done as follows: If your phone # is 484-7161, type 4, the display will read 00_4, press [ENTER/STORE] to save the entry to memory and increment to the next address 01_F.
Enter the remaining numbers in their respective addresses as shown below:
4847161FFFFFFFFF
00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15.
Valid entries for both the primary and secondary phone numbers are 0 - F with the numeric digits as dialed numbers and hexadecimal digits (A-F) representing the following functions:
A= * on a Touchtone phone keypad B= # on a Touchtone phone keypad C= look for secondary dial tone for up to 2 seconds (then, dial anyway) D= 3-second pause E= 5-second pause F= end of phone number (Note: F must be entered)
Document 50934 Rev B 5/15/00 PN 50934:B
19
Primary Number Communication Format (16)
One location is needed to select the Communication Format to the primary phone number. Address 16 is used for this purpose. The default (factory setting) for this address is 16_A, which is 4+2 Standard, 1800 Hz 'Carrier', 2300 Hz 'ack'. You may enter 0, 1, 2, 4, 6, 8, C or E in place of the default, then press [ENTER/STORE]. When selecting the Format, note that Ademco Contact ID is the only format in the ADT-UDACT which identifies the specific zone or point status to the Central Station. All other formats report the number of zones or points that are active but do not identify the specific zone or point. Choose from the list of formats below:
0: 4+1 Ademco Express Standard, DTMF, 1400/2300 ACK 1: 4+2 Ademco Express Standard, DTMF, 1400/2300 ACK
2: 3+1 Standard 1800 Hz Carrier, 2300 Hz ACK 3: Not Used 4: 3+1 Standard 1900 Hz Carrier, 1400 Hz ACK 5: Not Used 6: 4+1 Standard 1800 Hz Carrier, 2300 Hz ACK 7: Not Used 8: 4+1 Standard 1900 Hz Carrier, 1400 Hz ACK 9: Not Used A: 4+2 Standard 1800 Hz Carrier, 2300 Hz ACK B: Not Used C: 4+2 Standard 1900 Hz Carrier, 1400 Hz ACK D: Not Used E: Ademco Contact ID F: Not Used
Note: Consult your Central Station for proper selection or consult our factory representatives. For any format chosen, the ADT-UDACT automatically programs all of the event codes. See Tables 3-2, 3-3, 3-4, 3-5, 3-6 and 3-7.
Primary Number Account Code (17-20) Four locations at addresses 17-20 default to all '0's. Valid entries are (0-9 and A-F). The number of digits entered must match the format selection. If programming '2 or 4' into address 16, enter 3 digits. (location 20 is ignored) If programming '0, 1, 6, 8, A, C, or E' into address 16, enter 4 digits.
Primary Number 24 Hour Test Time (21-24).
Use military time when entering the 24 hour 'test' time. The 24 hour test report to phone number 1 takes up four locations, from addresses 21-24. The default is 00:00 (12:00 midnight). The limits for each location are as follows: 21: enter 0, 1 or 2; 22: enter 0-9; 23 : enter 0-5; 24: enter 0-9. Note: Do not use A-F.
Primary Number 24/12 Hour Test Time Interval (25). The test report sent to the Primary phone number may be sent every 12 or 24 hours. If the message is to be sent every 24 hours, leave the factory default entry of zero. If 12 hour test report time is needed, enter 1=12 hours.
Secondary Phone Number (26-41). Programming is similar to programming the primary phone number located at addresses 00 - 15. The defaults are also all 'F's.
20
FFFFFFFFFFFFFFFF
26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41.
Document 50934 Rev B 5/15/00 PN 50934:B
Secondary Number Communication Format (42). Programming is the same as the primary number's Comm Format at address 16. Default entry is 'A', 4+2 Standard. When selecting the Format, note that Ademco Contact ID is the only format in the ADT-UDACT which identifies the specific zone or point status to the Central Station. All other formats report the number of zones or points that are active but do not identify the specific zone or point. Choose one entry from the list below:
0: 4+1 Ademco Express Standard, DTMF, 1400/2300 ACK 1: 4+2 Ademco Express Standard, DTMF, 1400/2300 ACK 2: 3+1 Standard 1800 Hz Carrier, 2300 Hz ACK 3: Not Used 4: 3+1 Standard 1900 Hz Carrier, 1400 Hz ACK 5: Not Used 6: 4+1 Standard 1800 Hz Carrier, 2300 Hz ACK 7: Not Used 8: 4+1 Standard 1900 Hz Carrier, 1400 Hz ACK 9: Not Used A: 4+2 Standard 1800 Hz Carrier, 2300 Hz ACK B: Not Used C: 4+2 Standard 1900 Hz Carrier, 1400 Hz ACK D: Not Used E: Ademco Contact ID F: Not Used
Secondary Number Account Code (43-46) is programmed in addresses 43 - 46 in the same manner as the primary phone number Account Code. Default entries are all '0s'.
Secondary Number 24-Hour Test Time (47-50) is programmed in addresses 47­50 in the same manner as the primary number 24-Hour Test Time. Default is 00:00 (12:00 midnight).
Secondary Number 24/12 Hour Test Time (51) The test message sent to the Secondary phone number may be sent every 12 or 24 hours. If the message is to be sent every 24 hours, leave the factory default entry of zero. If a 12 hour test report time is needed, enter 1=12 hours.
Use the Start and End Monitoring Address programming locations to set the reporting range of the ADT-UDACT.
Start Monitoring Address (52-53) is programmed to indicate the first group of zones or points to be monitored and reported to the Central Station. Valid entries are '11 through 19' for the Unimode 300/400, and '01 through 32' for the Unimode 2020/ 1010 and ADT-MNNA. The factory default setting is '01'. See Table 3-1.
End Monitoring Address (54-55) is programmed to indicate the last group of zones or points to be monitored and reported to the Central Station. Valid entries are '11 through 19' for the Unimode 300/400, and '01 through 32' for the Unimode 2020/ 1010 and ADT-MNNA. Factory default setting is '02'.
Document 50934 Rev B 5/15/00 PN 50934:B
21
)tluafeDyrotcaF(gnitropeRenoZ
TRATS
DNE
35-25.rddA
55-45.rddA
gnitropeRtnioP
TRATS
DNE
35-25.rddA
55-45.rddA
1
004edominU11
Note: For additional information on the starting and ending addresses, refer to the host
FACP Technical Manual.
1
21
senoz99otpufosutatsstropeR=1
,0101/0202edominU
ANNM-TDA
004edominU11
2
10
3
2
23
3
91
stniop040,2otpufosutatsstropeR=2
stniop483otpufosutatsstropeR=3
Table 3-1: Start and End Monitoring Addresses
ADT-UDACT Communication Selection (56)
Leaving address 56 at '0' disables communications to the Central Station(s). Enter '1' for zone reporting, receive only, '2' for zone reporting, receive/transmit, '3' for point reporting, receive only, or '4' for point reporting, receive/transmit. See Type Mode Section 4.2 for additional information on detailed reporting. Note: Use receive only
selection when using remote annunciators. Be certain to set one of the annunciators for receive/transmit for EIA-485 communications bus supervision. Use the receive/ transmit entry when annunciators are not installed or when the ADT-UDACT receive/transmit function is to be used to supervise the EIA-485 communication bus. For more information on the receive/transmit function, refer to annunciator manuals.
Backup Reporting (57) Leaving address 57 at '0' means that reports will be transmitted to the secondary phone number only if attempts to communicate to the primary phone number are unsuccessful. Programming a '1' causes all reports to be transmitted to the secondary phone number.
22
Touchtone/Rotary Select (58) A '0' programmed in this address by the factory triggers Touchtone dialing over both phone lines. Select '1' for rotary dialing.
Make Break Ratio (59) Use this address only if you have chosen '1' for address 58. The make/break ratio is factory set to '0' which is 67/33, but may be changed to '1' which is a 62/38 ratio.
Address (60) Leave default of 0.
Address (61) Leave default of 0.
AC Loss Reporting Delay (62) '1' is factory default which causes a 6 hour time
delay for AC loss reporting. Valid entries are 0 to 9 and A to F corresponding to the following reporting delay times: '1' = 6 hour, '2' = 7 hours, '3' = 8 hours, '4' = 9 hours, '5' = 10 hours, '6' = 11 hours, '7' = 15 hours, '8' = 16 hours, '9' = 17 hours, 'A' = 18 hours, 'B' = 19 hours, 'C' = 20 hours, 'D' = 21 hours, 'E' = 22 hours and 'F' = 23 hours. '0' entry causes immediate reporting of AC loss.
Host Panel ID (63)
Enter one of the following digits corresponding to the Control Panel in which the ADT-UDACT is installed. A correct entry is essential for proper operation. 0 = Do not use 1 = Do not use 2 = Do not use
3 = Do not use 4 = Do not use 5 = Do not use
6 = Do not use 7 = Unimode 2020/1010, ADT-MNNA 8 = Unimode 300/400 9 = Do not use
Document 50934 Rev B 5/15/00 PN 50934:B
Loop Number (64 - 65)
For Contact ID format only. Factory default is '00'. Maximum value is '97'. Refer to Section 5.0 for additional information.
Device/Zone Number (66 - 68)
For Contact ID format only. These entries apply to the general reports only, i.e. general alarm, general trouble, general supervisory. Factory default is '000'. Maximum value is '999'. Refer to Section 5.0 for additional information.
Note: For the Contact ID Format, Loop Number and Device Number do not directly correspond to the SLC Loop or Device Number, instead, it is a convenient way to transmit data to the Central Station. Using the default Loop Number of '00' allows the reporting of a maximum of 999 devices or zones (001-999). To report device addresses or zones higher than 999 (the Unimode 2020 can report up to 2,040 addresses), the Loop Number is incremented by one to report up to an additional 1,000 device addresses or zones on the same panel. Following is an example (using the factory defaults) of Loop Number and Device Number settings for the ADT-UDACT on a single Unimode 2020 control panel:
Loop Number '00' reports points/zones 00 001 to 00 999 Loop Number '01' reports points/zones 01 000 to 01,999 Loop Number '02' reports points/zones 02 000 to 02,040
If the Loop Number (54-65) is programmed to 10, the devices are reported as:
Loop Number '10' reports points/zones 10 001 to 10 999 Loop Number '11' reports points/zones 11 000 to 11,999 Loop Number '12' reports points/zones 12 000 to 12,040
In applications which network multiple Fire Alarm Control Panels, the group number may be used to help identify each facility being monitored. For example, each ADT­UDACT can report its panel's devices by designating different Loop Numbers for each panel. The Loop Numbers assigned to a particular panel must be sequential, but the Loop Numbers from one panel to the next need not be sequential; i.e., the Loop Numbers assigned for the ADT-UDACT on one Unimode 2020 might be 00, 01 or 02 while the Loop Numbers for another FACP might be 10, 11 or 12 or any other set of unused consecutive numbers. For additional information on the Unimode 2020/1010 control panels, refer to Appendix D.
Programming Event Codes (69-208)
The type of reports and 'event codes' that are sent to the Central Station are in Tables 3-2 through 3-7. The selections made for the Primary Central Station Number Communication Format (address 16) and the Secondary Central Station Number Communication Format (address 42) automatically program addresses 69-208 with factory default selections.
Any of the event codes may be changed. Consult your Central Station prior to altering the event codes. For the 3+1, 4+1 and 4+1 Express Formats, entering an event code of '0' will cause the communicator to NOT transmit the report. Enter two zeroes for 4+2 and 4+2 Express Formats. For Ademco Contact ID format enter three zeroes. Transmission of reports to either or both Central Station phone numbers may be disabled.
Note the special 'System Abnormal Test Report' event code. This report was added per new UL DACT requirements. This report is generated in place of the normal test report when an alarm and/or trouble condition exists at the time the test report is due to be sent.
Document 50934 Rev B 5/15/00 PN 50934:B
23
Programming the Real-Time Clock
Entering an address greater than 209 will cause a display of the current time. On initial power up, the clock will start running from the factory setting of 00:01 (military time). The far left digit will be flashing, indicating that this is the first digit to be programmed.
Hours/Minutes
Select a digit then press [ENTER/STORE]. The digit 2nd from the left will start flashing. Select a digit then press [ENTER/STORE]. Hours setting is complete. With the digit 2nd from the right flashing, select a digit then press [ENTER/
STORE]. The digit on the far right will start flashing. Select a digit then press [ENTER/STORE]. Minutes setting is complete.
End Programming
Exit Programming Mode by pressing MODE, followed by the 4-digit code corresponding to an alternate mode of operation, then press [ENTER/STORE]. During Program Mode, if no key is pressed within 10 minutes, the ADT-UDACT will revert to normal mode.
3+1, 4+1 Express and 4+1 Standard Formats If '0, 2, 4, 6 or 8' are entered for address 16, the following data is automatically programmed for the Primary phone number event codes. Enter a '0' for the data setting to disable the report. These formats do not support zone/point programming. For zone/point reporting, refer to Contact ID.
Address Description Setting
69 Primary # General Alarm Code 1 70 Primary # Zone/Point Alarm Code 0 71 Primary # General Supervisory Code 8 72 Primary # Zone/Point Supervisory Code 0 73 Primary # General Fault Code F 74 Primary # AC Fault Code F 75 Primary # Zone/Point Fault Code 0 76 Primary # Low Battery Fault Code F 77 Primary # Telco Primary Line Fault Code F 78 Primary # Telco Secondary Line Fault Code F 79 Primary # NAC Fault Code F 80 Primary # Comm. Trouble Primary # Code F 81 Primary # Comm. Trouble Secondary # Code F 82 Primary # 485 Comm. Trouble Code F 83 Primary # System Off Normal Code F 84 Primary # ADT-UDACT Off Normal Code F 85 Primary # General Alarm Restore Code E 86 Primary # Zone/Point Alarm Restore Code 0 87 Primary # General Supervisory Restore Code E 88 Primary # Zone/Point Supervisory Restore Code 0 89 Primary # General Fault Restore Code E 90 Primary # AC Fault Restore Code E 91 Primary # Zone/ Point Fault Restore Code 0 92 Primary # Low Battery Fault Restore Code E 93 Primary # Telco Primary Line Fault Restore Code E 94 Primary # Telco Secondary Line Fault Restore Code E 95 Primary # NAC Fault Restore Code E 96 Primary # Comm.Trouble Primary Number Restore Code E 97 Primary # Comm. Trouble Secondary Number Restore Code E 98 Primary # 485 Comm. Trouble Restore Code E 99 Primary # System Off Normal Restore Code E 100 Primary # ADT-UDACT Off Normal Restore Code E 101 Primary # System 24 Hour Test 9 102 Primary # System 24 Hour Test w/active event F 103 Primary # Manual Test 9
24
Note: Zero entries prevent the transmission of the report to the Central Station.
Table 3-2: Event Codes, Primary Number
Document 50934 Rev B 5/15/00 PN 50934:B
4+2 Standard and 4+2 Express Formats
If '1, A or C' are entered for address 16, the following data is automatically programmed for the Primary phone number event codes.
Enter a '0' for the data setting to disable the report. These formats do not support zone/point programming. For zone/point reporting, refer to Contact ID.
Address Description Settings
69 - 70 Primary # General Alarm Code 11 71 - 72 Primary # Zone/Point Alarm Code 00 73 - 74 Primary # General Supervisory Code 81 75 - 76 Primary # Zone/Point Supervisory Code 00 77 - 78 Primary # General Fault Code F1 79 - 80 Primary # AC Fault Code F6 81 - 82 Primary # Zone/Point Fault Code 00 83 - 84 Primary # Low Battery Fault Code F8 85 - 86 Primary # Telco Primary Line Fault Code FA 87 - 88 Primary # Telco Secondary Line Fault Code FB 89 - 90 Primary # NAC Fault Code FC 91 - 92 Primary # Comm. Trouble Primary Number Code FD 93 - 94 Primary # Comm. Trouble Secondary Number Code FE 95 - 96 Primary # 485 Comm. Trouble Code FE 97 - 98 Primary # System Off Normal Code FF 99 - 100 Primary # ADT-UDACT Off Normal Code FF 101 - 102 Primary # General Alarm Restore Code E 1 103 - 104 Primary # Zone/Point Alarm Restore Code 00 105 - 106 Primary # General Supervisory Restore Code E2 107 - 108 Primary # Zone/Point Supervisory Restore Code 00 109 - 110 Primary # General Fault Restore Code E3 111 - 112 Primary # AC Fault Restore Code E6 113 - 114 Primary # Zone/Point Fault Restore Code 00 115 - 116 Primary # Low Battery Fault Restore Code E8 117 - 118 Primary # Telco Primary Line Fault Restore Code EA 119 - 120 Primary # Telco Secondary Line Fault Restore Code EB 121 - 122 Primary # NAC Fault Restore Code EC 123 - 124 Primary # Comm. Trouble Primary # Restore Code ED 125 - 126 Primary # Comm. Trouble Secondary # Restore Code EE 127 - 128 Primary # 485 Comm. Trouble Restore Code EE 129 - 130 Primary # System Off Normal Restore Code EF 131 - 132 Primary # ADT-UDACT Off Normal Restore Code EF 133 - 134 Primary # System 24 Hour Test 99 135 - 136 Primary # System 24 Hour Test w/active events 91 137 - 138 Primary # Manual Test 92
Note: Zero entries prevent the transmission of the report to the Central Station.
Table 3-3: Event Codes, Primary Number
Document 50934 Rev B 5/15/00 PN 50934:B
25
Ademco Contact ID Format
If 'E' is entered for address 16, the following data is automatically programmed for the Primary phone number event codes.
Enter a '000' for the data setting to disable the report.
Address Description Setting
69 - 71 Primary # General Alarm Code 110 00 000 72 - 74 Primary # Zone/Point Alarm Code 75 - 77 Primary # General Supervisory Code 200 00 000 78 - 80 Primary # Zone/Point Supervisory Code
5
5
110 4 00 Note
200 00 Note
1
Group # 6 Sensor No.
81 - 83 Primary # General Fault Code 300 00 84 - 86 Primary # AC Fault Code 301 00 87 - 89 Primary # Zone/Point Fault Code
5
380 00 Note 90 - 92 Primary # Low Battery Fault Code 302 00 93 - 95 Primary # Telco Primary Line Fault Code 351 00 96 - 98 Primary # Telco Secondary Line Fault Code 35 2 00 99 - 101 Primary # NAC Fault Code 321 00 102 - 104 Primary # Comm. Trouble Primary # Code 354 00 105 - 107 Primary # Comm. Trouble Secondary # Code 354 00 108 - 110 Primary # 485 Comm. Trouble Code 300 00 111 - 113 Primary # System Off Normal Code 308 00 114 - 116 Primary # ADT-UDACT Off Normal Code 350 00 117 - 119 Primary# System 24 Hour Test 60 2 00 120 - 122 Primary # System 24 Hour Test w/active event 608 00 123 - 125 Primary # Manual Test Message 601 00
Notes:
1) Note: Zero entries prevent the transmission of the report to the Central Station.
2) Refer to Contact ID program locations 64 - 68.
3) The identification of the zone/device number is automatically transmitted by the ADT-UDACT and is added to the main event code. See Table 5-3 for more information.
4) For control panels Unimode 2020/1010, ADT-MNNA, and the Unimode 300/400 the factory default event code is 110 and reprogrammable. The Unimode 400 is unique in point reporting mode in that only the control module report codes are programmable. The factory setting of report code 111 is fixed for addressable smoke detectors and cannot be changed.
5) The Group # is automatically incremented for Unimode 2020/1010 and ADT-MNNA applications.
2
3
2
3
3
26
Table 3-4: Ademco Contact ID, Primary Number
Document 50934 Rev B 5/15/00 PN 50934:B
3+1, 4+1 Express or 4+1 Standard Formats
If '0, 2, 4, 6 or 8' are entered for address 42, the following is automatically pro­grammed for the Secondary phone number event codes. Enter a '0' for the data setting to disable the report. These formats do not support zone/point programming. For zone/point reporting, refer to Contact ID.
Address Description Setting
139 Secondary # General Alarm Code 1 140 Secondary # Zone/Point Alarm Code 0 141 Secondary # General Supervisory Code 8 142 Secondary # Zone/Point Supervisory Code 0 143 Secondary # General Fault Code F 144 Secondary # AC Fault Code F 145 Secondary # Zone/Point Fault Code 0 146 Secondary # Low Battery Fault Code F 147 Secondary # Telco Primary Line Fault Code F 148 Secondary # Telco Secondary Line Fault Code F 149 Secondary # NAC Fault Code F 150 Secondary # Comm. Trouble Primary # Code F 151 Secondary # Comm. Trouble Secondary # Code F 152 Secondary # 485 Comm. Trouble Code F 153 Secondary # System Off Normal Code F 154 Secondary # ADT-UDACT Off Normal Code F 155 Secondary # General Alarm Restore Code E 156 Secondary # Zone/Point Alarm Restore Code 0 157 Secondary # General Supervisory Restore Code E 158 Secondary # Zone/Point Supervisory Restore Code 0 159 Secondary # General Fault Restore Code E 160 Secondary # AC Fault Restore Code E 161 Secondary # Zone/ Point Fault Restore Code 0 162 Secondary # Low Battery Fault Restore Code E 163 Secondary # Telco Primary Line Fault Restore Code E 164 Secondary # Telco Secondary Line Fault Restore Code E 165 Secondary # NAC Fault Restore Code E 166 Secondary # Comm.Trouble Primary # Restore Code E 167 Secondary # Comm. Trouble Secondary # Restore Code E 168 Secondary # 485 Comm. Trouble Restore Code E 169 Secondary # System Off Normal Restore Code E 170 Secondary # ADT-UDACT Off Normal Restore Code E 171 Secondary # System 24 Hour Test 9 172 Secondary # System 24 Hour Test w/active event F 173 Secondary # Manual Test 9
Note: Zero entries prevent the transmission of the report to the Central Station.
Table 3-5: Event Codes, Secondary Number
Document 50934 Rev B 5/15/00 PN 50934:B
27
4+2 Standard and 4+2 Express Formats
If '1, A or C' are entered for address 42, the following is automatically programmed
for the Secondary phone number event codes. Enter a '0' for the data setting to disable the report. These formats do not support zone/point programming. For zone/point reporting, refer to Contact ID.
Address Description Setting
139 - 140 Secondary # General Alarm Code 11 141 - 142 Secondary # Zone/Point Alarm Code 00 143 - 144 Secondary # General Supervisory Code 81 145 - 146 Secondary # Zone/Point Supervisory Code 00 147 - 148 Secondary # General Fault Code F1 149 - 150 Secondary # AC Fault Code F6 151 - 152 Secondary # Zone/Point Fault Code 00 153 - 154 Secondary # Low Battery Fault Code F8 155 - 156 Secondary # Telco Primary Line Fault Code FA 157 - 158 Secondary # Telco Secondary Line Fault Code FB 159 - 160 Secondary # NAC Fault Code FC 161 - 162 Secondary # Comm. Trouble Primary Number Code FD 163 - 164 Secondary # Comm. Trouble Secondary Number Code FE 165 - 166 Secondary # 485 Comm. Trouble Code F E 167 - 168 Secondary # System Off Normal Code FF 169 - 170 Secondary # ADT-UDACT Off Normal Code FF 171 - 172 Secondary # General Alarm Restore Code E1 173 - 174 Secondary # Zone/Point Alarm Restore Code 0 0 175 - 176 Secondary # General Supervisory Restore Code E2 177 - 178 Secondary # Zone/Point Supervisory Restore Code 00 179 - 180 Secondary # General Fault Restore Code E3 181 - 182 Secondary # AC Fault Restore Code E6 183 - 184 Secondary # Zone/Point Fault Restore Code 0 0 185 - 186 Secondary # Low Battery Fault Restore Code E8 187 - 188 Secondary # Telco Primary Line Fault Restore Code EA 189 - 190 Secondary # Telco Secondary Line Fault Restore Code EB 191 - 192 Secondary # NAC Fault Restore Code EC 193 - 194 Secondary # Comm. Trouble Primary # Restore Code ED 195 - 196 Secondary # Comm. Trouble Secondary # Restore Code EE 197 - 198 Secondary # 485 Comm. Trouble Restore Code EE 199 - 200 Secondary # System Off Normal Restore Code EF 201 - 202 Secondary # ADT-UDACT Off Normal Restore Code EF 203 - 204 Secondary # System 24 Hour Test 99 205 - 206 Secondary # System 24 Hour Test w/active events 91 207 - 208 Secondary # Manual Test 92
28
Note: Zero entries prevent the transmission of the report to the Central Station.
Table 3-6: Event Codes, Secondary Number
Document 50934 Rev B 5/15/00 PN 50934:B
Ademco Contact ID Format
If 'E' is entered for address 42, the following data is automatically programmed for the Secondary phone number event codes.
Address Description Setting
139 - 141 Secondary # General Alarm Code 110 00 000 142 - 144 Secondary # Zone/Point Alarm Code 110 4 00 Note 145 - 147 Secondary # General Supervisory Code 200 00 000 148 - 150 Secondary # Zone/Point Supervisory Code 200 00 Note
Enter a '000' for the data setting to disable the report.
1
Group # 6 Sensor No.
2
3
2
3
151 - 153 Secondary # General Fault Code 300 00 154 - 156 Secondary # AC Fault Code 301 00 157 - 159 Secondary # Zone/Point Fault Code 380 00 Note
3
160 - 162 Secondary # Low Battery Fault Code 302 00 163 - 165 Secondary # Telco Primary Line Fault Code 351 00 166 - 168 Secondary # Telco Secondary Line Fault Code 352 00 169 - 171 Secondary # NAC Fault Code 321 00 172 - 174 Secondary # Comm. Trouble Primary # Code 354 00 175 - 177 Secondary # Comm. Trouble Secondary # Code 354 00 178 - 180 Secondary # 485 Comm. Trouble Code 300 00 181 - 183 Secondary # System Off Normal Code 308 00 184 - 186 Secondary # ADT-UDACT Off Normal Code 350 00 187 - 189 Secondary # System 24 Hour Test 602 00 190 - 192 Secondary # System 24 Hour Test w/active event 608 00 193 - 195 Secondary # Manual Test Message 601 00
Notes:
1) Note: Zero entries prevent the transmission of the report to the Central Station.
2) Refer to Contact ID program locations 64 - 68.
3) The identification of the zone/device number is automatically transmitted by the ADT-UDACT and is added to the main event code. See Table 5-3 for more information.
4) For control panels Unimode 2020/1010, ADT-MNNA, and Unimode 300/400 the factory default event code is 110 and reprogrammable. The Unimode 300 and Unimode 400 are unique in point reporting mode in that only the control module report codes are programmable. The factory setting of report code 111 is fixed for addressable smoke detectors and cannot be changed.
5) The Group # is automatically incremented for Unimode 2020/1010 and ADT-MNNA applications.
Table 3-7: Ademco Contact ID, Secondary Number
Document 50934 Rev B 5/15/00 PN 50934:B
29
4.0 Operating Instructions
UDACTKEY.WMF
4.1 Normal Mode
CLEAR
TEST
MODE
The ADT-UDACT has five Modes of operation; Normal, Program, Lamp Test, Troubleshoot and Type mode. Upon initial power up, the system will be in Normal
Mode. This section discusses operation of the ADT-UDACT in the Normal Mode.
4.1.1 Keys Below is a description of the function keys in Normal Mode:
The Clear function will cause the ADT-UDACT to:
• cease transmissions
• clear any active or pending transmissions
• reset and return to normal system processing
To perform the Clear function, press the Clear Key followed by 2, 5, 3, 2, then press the [ENTER/STORE] key.
If the Test Key is pressed three times in rapid succession the ADT-UDACT will transmit a test message to both Central Stations. The message reported is the same as the automatic test message for all formats except Ademco Contact ID.
Pressing the Mode Key followed by a valid 4-digit numerical code and [ENTER/ STORE] selects one of the four modes of operation.
30
To enter normal mode from any other mode press MODE then
6676 [ENTER/STORE]. 6676 spells NORM on a Touch-Tone® phone.
Document 50934 Rev B 5/15/00 PN 50934:B
1st EVENT
This key along with the Up Arrow and Down Arrow keys, are used to display ADT­UDACT fault conditions. Press the 1st Event key at any time to display the first event that occurred.
DOWN ARROW
UP ARROW
[ENTER/STORE]
Use the Down Arrow key to view other ADT-UDACT fault events (older) that have occurred and are active - not cleared yet.
Use the Up Arrow key to view other ADT-UDACT fault events (newer), that have occurred and are active - not cleared yet.
See individual mode descriptions in other sections.
4.1.2 Displays:
Four 7-segment red LED characters provide visual annunciation of ADT-UDACT trouble conditions. A list of messages that may appear on the display in normal mode is shown below:
PH_1 PH_2 no_1 no_2
Primary Number Communication Fault Secondary Number Communication Fault Primary Phone Line Fault Secondary Phone Line Fault
Individual LEDs are provided for:
EIA-485—A yellow LED that turns on steady when a fault on the EIA-485 circuit is detected.
Comm. Fail—This yellow LED turns on to indicate the loss of both telephone lines or that the maximum number of attempts to communicate with both Central Stations has been unsuccessful. Note: During a comm fail, the display will show either a PH1 and PH2 or no1 and no2.
Power On—A green LED that remains on while DC power is supplied to the ADT­UDACT. If this indicator fails to light under normal conditions, service the system
immediately.
Kiss-Off —A green LED that blinks when the Central Station has acknowledged receipt of each transmitted message.
Test—A green LED that turns on to indicate that a manual test message is being transmitted.
Primary Line Active—A red LED that indicates the primary phone line is active.
Secondary Line Active—A red LED that indicates the secondary phone line is
active.
Modem —A green LED that stays on steady during modem types of communications.
Document 50934 Rev B 5/15/00 PN 50934:B
31
Primary Line
Secondary Line
Primary Active
Modem LED
Secondary Active LED
Kiss-Off LED
UDACTNOT.WMF
Figure 4-1: ADT-UDACT Phone Connectors and LEDs
4.1.3 Normal Mode Operation:
Normal mode is the standard mode of operation. In this mode, the ADT-UDACT monitors host FACP status, power input, EIA-485 communications and telephone line voltage.
The four character 7-segment display is normally off and does not annunciate events that are being transmitted. The display will only annunciate ADT-UDACT trouble conditions in the normal mode.
The ADT-UDACT transmits zone/point and system status reports to a Central Station via the public switched telephone network. Two supervised telephone line connections are made to interface the ADT-UDACT to the telephone lines.
The ADT-UDACT supervises both telephone lines for proper voltage. A delay of two minutes will occur before a fault in either phone line connection is reported as a trouble. When a fault is detected, the 4 character display will show either 'no 1' or 'no 2' (depending upon which telephone line has the fault. 'no 1' = Primary Line, 'no 2' = Secondary Line) and the trouble condition will be reported to the Central Station over the remaining good phone line.
The ADT-UDACT comes with line seizure capability provided for both the primary and secondary telephone line interfaces. Any time that the ADT-UDACT needs to
make a call to the Central Station, line seizure will disconnect any local premises phones sharing the same telephone line.
32
All transmission to the Central Station will be sent over the Primary phone line. In the event of noisy phone lines, transmissions will be sent over the backup Secondary phone line.
Document 50934 Rev B 5/15/00 PN 50934:B
Two phone numbers must be programmed, the Primary phone number and the Secondary phone number. All system reports will be transmitted to the primary phone number. Reports will automatically be sent to the secondary phone number if attempts to transmit to the primary phone number are unsuccessful. If 10 total attempts to communicate are unsuccessful, the Communicator Failure output will be turned on (TB3, terminal 2). Note that as an option, all reports may also be sent to the secondary phone number. Refer to Section 3.0 Programming Instructions.
The ADT-UDACT meets NFPA 72 for Remote Station Protective Signaling Service and Central Station Signaling Service reporting requirements for: (a) the type of signal (b) condition and (c) location of the reporting premises.
Since higher priority events take precedence over lower priority events, the ADT­UDACT will transmit higher priority events before sending the lower priority events. Priorities are as follows:
Event Activations
1. General Alarm
2. Zone/Point Alarm #N
3. General Supervisory
4. Zone/Point Supervisory #N
5. General System Trouble
6. AC Power Loss
7. Zone/Point Trouble #N
8. Low Battery
9. Telco Primary Line Fault
10. Telco Secondary Line Fault
11. NAC Fault Code
12. Communication Trouble, Primary Number
13. Communication Trouble, Secondary Number
14. EIA-485 Communication Bus Trouble
15. System Off-Normal Code
16. System Automatic Test Report
17. System Abnormal Automatic Test Report
18. Manual Activated Test Report Event Restorals
19. General Alarm Restoral
20. Zone/Point Alarm #N Restoral
21. General Supervisory Restoral
22. Zone/Point Supervisory #N Restoral
23. General System Trouble Restoral
24. AC Power Loss Restoral
25. Zone/Point Trouble #N Restoral
26. Low Battery Restoral
27. Telco Primary Line Fault Restoral
28. Telco Secondary Line Fault Restoral
29. NAC Fault Code Restoral
30. Communication Trouble, Primary Number Restoral
31. Communication Trouble, Secondary Number Restoral
32. EIA-485 Communication Bus Trouble Restoral
33. System Off-Normal Code Restoral
Where #N represents the number of zones or devices in alarm or trouble. This is valid for all formats except Ademco Contact ID.
For all formats, the 'general' reports are always transmitted (unless disabled). The zone or point information may follow the general report if enabled.
Document 50934 Rev B 5/15/00 PN 50934:B
33
For all pulsed formats and both Ademco Express formats, the zone/point report is repeated per the total number of zones or points activated once factory default entries of zero are removed. See Tables 3-2, 3-3, 3-4, 3-5, 3-6 and 3-7. When Ademco Contact ID format is used, the actual zone or point activated is identified in the report.
The ADT-UDACT comes factory programmed with the reports identified above as item numbers 2, 4, 7, 20, 22 and 25 set to zero, preventing the reports from being transmitted for the pulsed and Ademco Express formats. These reports are factory programmed for active transmission when using the Ademco Contact ID.
4.1.4 Key Report Descriptions ADT-UDACT OFF Normal Report
Removing the ADT-UDACT from Normal Mode and placing it into Program or Troubleshoot Mode causes a transmission of an 'UDACT off normal' fault message. Returning the ADT-UDACT to Normal Mode causes a transmission of a 'UDACT return to normal' restoral message.
Panel OFF Normal Report
The ADT-UDACT will report a "System off normal" report when the host FACP temporarily shuts down the EIA-485 communications bus during various aspects of system programming. When the host FACP is returned to normal, restoring the fire protection, the ADT-UDACT will report a 'system off normal restoral' report.
System Test Report
The ADT-UDACT will transmit a test message to both Central Stations at programmed intervals (typically every 24 hours). Should there exist an abnormal condition in the fire alarm system (such as an alarm, trouble or supervisory condition) at the time when the test report is due to be transmitted, the ADT-UDACT will report the 'system abnormal test report.' If the system is normal, the report transmitted will be the normal 'system test report.'
4.2 Type Mode
EIA-485 Communications Trouble Report
The ADT-UDACT supervises the integrity of the information received from the FACP via the EIA-485 communications bus. Should the communications bus malfunction or be temporarily disabled, the ADT-UDACT transmits the report '485 comm trouble.' When the communications bus returns to proper operation, the ADT-UDACT will report '485 comm trouble restoral.'
Type Mode may be used to disable reports by zone or point and to identify the specific functionality of each zone or point in the system via Ademco Contact ID format. Factory default for all zones is Fire Alarm. When reporting point information, the factory default for addressable monitor modules is Fire Alarm code 110 and the default for addressable detectors is Smoke Detector code 111. The smoke detector default cannot be modified. Use Type Mode to identify the function of each zone or point as follows:
• General fire alarm • Burglary
• Supervisory • 24 hour non-burglary
• Pull stations • High temperature
• Heat detectors • Low temperature
• Waterflows • Low water pressure
• Duct detectors • Low water level
• Flame sensor • Pump failure
• Smoke zone
Note: Unimode 2020/1010 and ADT-MNNA applications restrict Type Mode program­ming to a maximum of 568 points. All remaining points above 568 will report as fire alarm points.
34
Document 50934 Rev B 5/15/00 PN 50934:B
To access Type Mode, press the MODE key followed by the 4-digit code 8973 and then press the [ENTER/STORE] key. The ADT-UDACT will display three digits. For example, initial entry will display 01 0.
The characters to the left identify the zone or point number. In this example, 01 identifies zone 01 or point address 01. The character to the right (0 in this example) identifies the type of zone or point as follows:
0 = Zone or point defined as fire alarm 1 = Disable zone or point report 2 = Zone or point defined as supervisory 3 = Zone or point defined as pull station 4 = Zone or point defined as heat detector 5 = Zone or point defined as waterflow 6 = Zone or point defined as duct detector 7 = Zone or point defined as flame sensor 8 = Zone or point defined as smoke zone (Use for group of addressable or
conventional smoke detectors. Also use for addressable monitor
modules monitoring conventional smoke detectors). 9 = Zone or point defined as burglary (Unimode 300/400 and ADT-MNNA) A = Zone or point defined as 24 hour non-burglary B = Zone or point defined as high temperature C = Zone or point defined as low temperature D = Zone or point defined as low water pressure E = Zone or point defined as low water level F = Zone or point defined as pump failure
Factory default is all zones or points set to '0' for fire alarm. The '0' setting for zone reporting allows the mixing of types of devices on a single zone. To change the type definition of the zone or point from the factory default of 0, select 2 to F corresponding to the type of device(s) used (do not mix device types for these settings), or select 1 to disable alarm reporting of any zone or point. The digit entered will appear on the far right display. Next press the [ENTER/STORE] key. This stores the entry into E2 memory and increments to the next higher address.
Use the UP, DOWN and 1st EVENT keys to move through the list of zones/points (refer to Appendices), similar to the method described in the programming section of this manual.
To define all zones or points as fire alarm (return to original factory default settings) enter zone or point 999 and then press the [ENTER/STORE] key. The display will change to 01 0, indicating a return to the factory default settings.
4.2.1 Disabling of Zones or Points
This feature is primarily used when system points have been defined as remote reset, acknowledge, silence or drill switches. Refer to the FACP technical manual for additional information. Activation of remote switches appear as alarms on the EIA-
485 bus. The ADT-UDACT will report these points as fire alarm points unless disabled in the Type Mode. Disabling zones or points also prohibits the activation
(shorted or alarm activated condition) from being reported by the ADT-UDACT. Disabling of the zone or point does not affect the reporting of the zone or point trouble condition.
Note: Type Mode '1' for zones 90-99, disables reports for these zones. To transmit reports for zones 90-99, use Type Mode entries of '0' or '2' through 'F'.
Document 50934 Rev B 5/15/00 PN 50934:B
35
4.2.2 Zone or Point Supervisory
A zone or point must be defined as supervisory to allow the ADT-UDACT to identify the correct report to transmit to the central station. Follow the programming instructions in the FACP manual to program a zone or point as supervisory. Next, program the zone or point as a code 2 for supervisory. Use the charts in Appendices to enter point and zone definitions. Note that the ADT-UDACT fire protection and
reporting capabilities are inactive while in Type Mode.
4.3 Troubleshoot Mode
To get into the Troubleshoot Mode, press MODE 8768 and [ENTER/STORE].
8768 spells TROU on a Touch-Tone® phone.
Once in this mode, the ADT-UDACT will:
• Transmit the 'UDACT off normal' message to the Central Station(s).
• Continue to communicate any events not yet acknowledged at the
Central Station prior to entering Troubleshoot Mode. The UP Arrow key, Down Arrow key and 1st EVENT keys do not function in
this mode.
Telephone Line Testing Pressing C for touchtone dialing or D for rotary dialing, followed by [ENTER/ STORE] causes seizure of the Primary phone line which in turn lights the red
LED signifying Primary phone line active. After a delay of three seconds, the ADT-UDACT goes off hook to acquire a dial tone.
The ADT-UDACT keypad may be used as a telephone touchpad for number dialing. Once the first digit is pressed, the display will move the C or D character one position to the left, while placing the digit to be dialed on the farthest right display position. Continue to press the phone numbers to be dialed. Successive depressions of the [ENTER/STORE] key hangs up and picks up the phone (places the phone on or off the hook).
36
The secondary phone line may be tested by pressing the E key for touchtone dialing or the F key for rotary dialing and then following the same procedure used for the primary phone line.
A handset may be temporarily connected across transformer T1 as indicated in Figure 4-2. The handset, when connected across T1, may be used only as an amplifier/ speaker or telephone with the ADT-UDACT used for number dialing.
Document 50934 Rev B 5/15/00 PN 50934:B
Both Primary and Secondary Lines
Figure 4-2: Handset/Speaker Connection
UDACTNOT.WMF
4.4 Lamp Test Mode
To perform a Lamp Test, press MODE then 5267 followed by [ENTER/STORE]. This will test all system LEDs. The LEDs will stay on for five seconds, then the ADT-UDACT will return to normal mode.
5267 spells LAMP on a Touch-Tone® phone.
Document 50934 Rev B 5/15/00 PN 50934:B
37
5.0 Reporting Formats
Table 5-1 shows the data reporting structure for each of the pulsed formats as well as the Ademco Express formats. Ademco Express formats allow a typical data message to be transmitted to the Central Station in under 5 seconds. Pulsed formats typically require 15 to 20 seconds in comparison. Table 5-2 defines each letter code used in Table 5-1. Table 5-3 describes the data reporting structure used for Ademco Contact ID format. Do not select any of the pulsed or Ademco Express Formats if identification of the specific zone or point is desired. Use Ademco Contact ID for specific zone or point identification.
Format #
0,2, 4, 6, 8
Report
Alarm SSS(S) A SSSS AA2
Alarm Restore SSS(S) RA SSSS RARA2
Zone Trouble
(Zone Open)
Zone Trouble Restore SSS(S) RTZ SSSS RTZRTZ2
System Trouble SSS(S) TS SSSS TSTS2
System Trouble Restore SSS(S) RTS SSSS RTSRTS2
Low Battery SSS(S) L SSSS LL2
Low Battery Restore SSS(S) RL SSSS RLRL2
AC Loss SSS(S) P SSSS PP2
3+1/4+1/Standard
4+1 Express
SSS(S) RTZ SSSS TZTZ2
Format #
1,A, C
4+2/Standard
4+2 Express
38
AC Loss Restore SSS(S) RP SSSS RPRP2
Supervisory Condition SSS(S) V SSSS VV2
Supervisory Condition
Restore
Test Report SSS(S) X SSSS XX2
Abnormal Test Report
SSS(S) RV SSSS RVRV2
SSS(S) XA SSSS XAXA2
Table 5-1: Data Reporting Structure
Refer to Table 5-2 for an explanation of each letter code in Table 5-1. Refer to Table 6-1 for a list of compatible receivers.
Document 50934 Rev B 5/15/00 PN 50934:B
Where:
SSS 0r SSSS = Subscriber ID A = Alarm (1st digit) A2 = Alarm (2nd digit) RA = Alarm Restore (1st digit) RA2 = Alarm Restore (2nd digit) TZ = Zone Trouble (1st digit) TZ2 = Zone Trouble (2nd digit) RTZ = Zone Trouble Restore (1st digit) RTZ2 = Zone Trouble Restore (2nd digit) TS = System Trouble (1st digit) TS2 = System Trouble (2nd digit) RTS = System Trouble Restore (1st digit) RTS2 = System Trouble Restore (2nd digit) L = Low Battery (1st digit) L2 = Low Battery (2nd digit) RL = Low Battery Restore (1st digit) RL2 = Low Battery Restore (2nd digit) P = AC Loss (1st digit) P2 = AC Loss (2nd digit) RP = AC Loss Restore (1st digit) RP2 = AC Loss Restore ( 2nd digit) V = Supervisory Condition (1st digit) V2 = Supervisory Condition (2nd digit) RV = Supervisory Condition Restore (1st digit) RV2 = Supervisory Condition Restore (2nd digit) X = Test Report (1st digit) X2 = Test Report (2nd digit) XA = Abnormal Test Report (1st digit) XA2 = Abnormal Test Report (2nd digit)
Table 5-2: Letter Code Definitions
(Refer to Table 5-1)
Document 50934 Rev B 5/15/00 PN 50934:B
39
The reporting structure for the Ademco Contact ID format is as follows:
SSSS 18 QXYZ GG CCC
where SSSS = Four digit Subscriber ID (addresses 17 - 20 and
43 - 46)
18 = Identifies transmission as Contact ID to the
receiver at the Central Station
Q = Event Qualifier
1 = New Event
2 = New Restore XYZ = Event code (shown in Tables 3-4 and 3-7) GG = Group number or Loop number CCC = Device or Zone number
For general reports (alarm, trouble and supervisory), the GG and CCC fields are transmitted as 00 and 000 unless changes to addresses 64-65 and 66-68 are made.
64 - 65 = Loop number (GG), (factory default is 00) 66 - 68 = Device/Zone number (CCC) for General Alarm,
Fault or Supervisory messages (factory default is 000).
A typical printout of alarm and trouble reports in the Ademco Contact ID Reporting Structure follows:
Rcvr/
Time Date SSSS QXYZ GG CCCC
Line ID
4
11:28 03/25 11 7777 E110 00 C000 - general alarm 11:28 03/25 11 7777 E111 00 C046 - alarm SD46 11:28 03/25 11 7777 E300 00 C000 - general trouble 11:28 03/25 11 7777 E380 00 C046 - trouble SD46 11:28 03/25 11 7777 R110 00 C000 - general alarm restore 11:28 03/25 11 7777 R111 00 C046 - alarm SD46 restore 11:28 03/25 11 7777 R300 00 C000 - general trbl restore 11:28 03/25 11 7777 R380 00 C046 - trouble SD46 restore
Table 5-3: Ademco Contact ID Reporting Structure
Notes:
1) In the sample report, SD46 refers to smoke detector at address 46 or on zone 46.
2) 18, which is used in the reporting structure to identify the transmission as Contact ID, is not printed out in the alarm and trouble report.
3) Q, which is the Event Qualifier for the reporting structure, is printed out in the report as an E for New Event or R for New Restore.
40
4) CCCC, the first C is not transmitted by the ADT-UDACT but is printed by the Central Station Receiver printer output.
Document 50934 Rev B 5/15/00 PN 50934:B
By using the Type Mode feature, identification of zone/point types is possible. Limits for the maximum number of zones/points reported for each panel are as follows:
Unimode 300 = 192 points / 99 zones Unimode 400 = 384 points / 99 zones Unimode 2020/1010 = 568 points ADT-MNNA = 568 points
#DIEPYTECIVEDDETAVITCA#TNIOP/ENOZTROPER
2mralAyrosivrepuS1 100C00002E
3mralAnoitatSlluP3 300C00511E
4mralArosneStaeH4 400C00411E
5mralAwolfretaW5 500C00311E
6mralArotceteDtcuD6 600C00611E
7mralArosneSemalF7 700C00711E
8mralAenoZekomS
)lanoitnevnoC(
9yralgruB8 800C00031E
Ayralgrub-noNruoH429 900C00051E
BerutarepmeThgiH01010C00851E
CerutarepmeTwoL11110C00951E
DerusserPretaWwoL21210C00102E
EleveLretaWwoL31310C00402E
FeruliaFpmuP41410C00602E
.................................................................hguorht.................................
004edominUroftimiL844
2200C00111E
ANNM-TDAdna0101/0202edominUroftimiL865
Document 50934 Rev B 5/15/00 PN 50934:B
41
6.0 Compatible Receivers
The chart below shows UL listed receivers compatible with the ADT-UDACT:
Format # (Addresses 16 & 42)
Ademco
685 (1)
Silent Knight
9000
ITI
FBI
CS-4000 (3)
CP220FB
Osborne Hoffman
Radionics
Quick Alert Models 1 & 2
Linear/Sescoa
6000/6500 (5)
3000R (7)
Surguard
MLR-2 (9)
0 4+1 Ademco Express
1 4+2 Ademco Express 2 3+1/Standard/1800/2300 3 Not Used 4 3+1/Standard/1900/1400 5 Not Used 6 4+1/Standard/1800/2300 7 Not Used 8 4+1/Standard/1900/1400 9 Not Used A 4+2/Standard/1800/2300 B Not Used C 4+2/Standard/1900/1400 D Not Used E Ademco Contact ID F Not Used
✔✔
✔✔ ✔✔
✔✔ ✔✔
✔✔
✔✔
✔✔
✔✔
✔✔
✔✔
✔✔
✔✔
✔✔
✔✔
✔✔
✔✔
✔✔
✔✔
(2)
✔✔
✔✔
(2)
✔✔
✔✔
(2)
✔✔
✔✔
(2)
✔✔
✔✔
(2)
✔✔
(2)
✔ ✔ ✔ ✔
✔ ✔(8)
✔ ✔ ✔ ✔
✔ ✔ ✔ ✔
✔ ✔ (4)
✔ ✔ ✔ ✔
(4)
✔✔
(4)
✔✔
(4)
✔✔
(4)
✔✔
(4)
✔ ✔ ✔ ✔
✔ ✔
✔ ✔ ✔ ✔
(5,6)
(5)
(5)
✔✔
✔✔ ✔✔
✔✔ ✔✔
✔✔
✔✔
✔✔
✔✔
✔✔
✔✔
✔✔
✔✔
✔✔
✔✔
✔✔
✔✔
✔✔
42
(1) With 685-8 Line Card with Rev 4.4d software. (2) With 9002 Line Card Rev 9035 software or 9032 Line Card with 9326A software. (3) Rev. 4.0 software. (4) FBI CP220FB Rec-11 Line Card with Rev 2.6 software and a memory card with Rev 3.8 software. (5) Model 6500 with Rev 600 software. (6) Model 6000 with Rev 204 software. (7) With Rev B control card at Rev 1.4 software and Rev C line card at Rev
1.5 software. (8) Model 2 only. (9) Version 1.62 software.
Table 6-1: Compatible UL Listed Receivers
Document 50934 Rev B 5/15/00 PN 50934:B
7.0 Programming Reference Sheets
--- To enter Programming, press Mode: 7 7 6 4, Enter
❑00 ❑01 ❑02 ❑03 ❑04 ❑05 ❑06 ❑07 ❑08 ❑09 ❑10 ❑11 ❑12 ❑13 ❑14 ❑
Addresses 00 to 15 store the Primary Phone Number. Enter 'F' to represent the end of the number.
❑16 Primary Comm Format: ❑17 ❑18 ❑19 ❑ ❑21 ❑22 ❑23 ❑ ❑
Primary Number Test Time Interval. Enter '0' for 24-hour; '1' - 12-hour.
25
Primary Account Code: Valid keys are 0-F.
20
Primary 24-Hour Test Time.
24
Enter 0 - F.
Enter military time (i.e. 1400 for 2 PM).
❑26 ❑27 ❑28 ❑29 ❑30 ❑31 ❑32 ❑33 ❑34 ❑35 ❑36 ❑37 ❑38 ❑39 ❑40 ❑
Addresses 26-41 store the Secondary Phone Number.
Enter 'F' to represent the end of the number.
❑42 Secondary Comm Format: Enter 0-F. ❑43 ❑44 ❑45 ❑46 Secondary Account Code: Valid keys are 0-F. ❑47 ❑48 ❑49 ❑50 Secondary 24-Hour Test Time.
Secondary Number Test Time Interval. Enter '0' for 24-hour; '1' - 12-hour.
51
❑52 ❑ ❑
54 ❑55
Start Monitoring Address. Valid entries are 01 through 32.
53
End Monitoring Address. Valid entries are 01 through 32.
Enter military time (i.e. 1400 for 2 PM)
15
41
.
ADT-UDACT Communication Selection. Enter '0' to disable ADT-UDACT communication; '1' for zone
56
reporting receive only communication; '2' for zone reporting receive/transmit communication; '3' for point reporting receive only; or '4' for point reporting receive/transmit.
Backup Reporting. Enter '0' to have secondary phone number act as backup only; '1' to have secondary
57
phone number receive all reports and messages along with primary phone number.
Touchtone/Rotary Select. Enter '0' for touchtone dialing; '1' for rotary dialing.
58
Make/Break Ratio. If rotary dialing is selected in Address 58; Enter '0' for a 67/73 make/break ratio; '1'
59
for a 62/38 make/break ratio.
Leave default of 0.
60
Leave default of 0.
61
AC Loss Reporting Delay. Enter '0' for no time delay after AC loss; '1' for 6 hour delay; '2' for 7 hour
62
delay; '3' for 8 hour delay; '4' for 9 hour delay; '5' for 10 hour delay; '6' for 11 hour delay; '7' for 15 hour delay; '8' for 16 hour delay; '9' for 17 hour delay; 'A' for 18 hour delay; 'B' for 19 hour delay; 'C' for 20 hour delay; 'D' for 21 hour delay; 'E' for 22 hour delay; or 'F' for 23 hour delay.
Host Panel ID. Enter '7' for Unimode 2020/1010 and ADT-MNNA; '8' for Unimode 300/400; all other
63
entries are invalid.
64 ❑65
Loop Number. Factory set to '00'. Valid entries are 00 through 97
66 ❑67 ❑68
through 999.
Device/Zone Number for General Reports. Factory set to '000'. Valid entries are 000
Document 50934 Rev B 5/15/00 PN 50934:B
43
Programming Reference Sheet
❑69❑70❑ ❑82❑83❑ ❑95❑96❑ ❑ ❑ ❑ ❑ ❑ ❑
108
121
134
147
160
173
❑ ❑ ❑ ❑ ❑ ❑
109
122
135
148
161
174
❑ ❑ ❑ ❑ ❑ ❑
❑72❑
71
❑85❑
84
❑98❑99❑
97
110
123
136
149
162
175
❑ ❑ ❑ ❑ ❑ ❑
111
124
137
150
163
176
❑ ❑ ❑ ❑ ❑ ❑
❑74❑
73
❑87❑
86
112
125
138
151
164
177
100
113
126
139
152
165
178
❑ ❑
❑ ❑ ❑ ❑ ❑
75
88
101
114
127
140
153
166
179
❑ ❑ ❑ ❑ ❑ ❑ ❑ ❑
❑77❑78❑
76
❑90❑91❑
89
102
115
128
141
154
167
180
❑ ❑ ❑ ❑ ❑ ❑ ❑
103
116
129
142
155
168
181
❑ ❑ ❑ ❑ ❑ ❑ ❑
104
117
130
143
156
169
182
❑ ❑ ❑ ❑ ❑ ❑ ❑
79
92
105
118
131
144
157
170
183
❑ ❑ ❑ ❑ ❑ ❑ ❑ ❑
80
93
106
119
132
145
158
171
184
❑ ❑ ❑ ❑ ❑ ❑ ❑ ❑
81
94
107
120
133
146
159
172
185
❑ ❑
186
199
❑ ❑
187
200
❑ ❑
188
201
❑ ❑
189
202
❑ ❑
190
203
❑ ❑
191
204
❑ ❑
192
205
❑ ❑
193
206
❑ ❑
194
207
❑ ❑
195
208
196
197
198
44
Document 50934 Rev B 5/15/00 PN 50934:B
Programming Reference Sheet Factory Default Settings
--- To enter Programming, press Mode: 7 7 6 4, Enter
FF
F
❑00 ❑01 ❑02 ❑03 ❑04 ❑05 ❑06 ❑07 ❑08 ❑09 ❑10 ❑11 ❑12 ❑13 ❑14 ❑
Addresses 00 to 15 store the Primary Phone Number. Enter 'F' to represent the end of the number.
A
❑16 Primary Comm Format:
0
0
❑17 ❑18 ❑19 ❑
0
0
❑21 ❑22 ❑23 ❑
0
Primary Number Test Time Interval. '0' for 24-hour.
25
F
F
❑26 ❑27 ❑28 ❑29 ❑30 ❑31 ❑32 ❑33 ❑34 ❑35 ❑36 ❑37 ❑38 ❑39 ❑40 ❑
Addresses 26-41 store the Secondary Phone Number.
A
❑42 Secondary Comm Format: (4+2 Standard 1800/2300).
0
0
❑43 ❑44 ❑45 ❑46 Secondary Account Code.
0
0
❑47 ❑48 ❑49 ❑50 Secondary 24-Hour Test Time.
0
Secondary Number Test Time Interval. '0' for 24-hour.
51
0
1
0
0
0
0
0
0
0
1
8
0
0
❑66 ❑67 ❑68 Device/Zone Number for general reports. For Ademco Contact ID only. Device number = '000'.
Start Monitoring Address
52 ❑53
2
54 ❑55
ADT-UDACT Communication Selection. '0' for ADT-UDACT Communication disabled.
56
Backup Reporting. '0' for backup.
57
Touchtone/Rotary Select. '0' for Touchtone.
58
Make/Break Ratio. '0' for 67/33 make/break ratio.
59
Leave default of zero.
60
Leave default of zero.
61
AC Loss reporting delay. '1' for 6 hour time delay.
62
Host PANEL ID. '8' for Unimode 300/400.
63
0
64 ❑65
00
FFF
0
0
0
FF
0 0
End Monitoring Address
Loop Number. For Ademco Contact ID only. Loop number = '00',
Primary Account Code.
20
0
Primary 24-Hour Test Time.
24
F
0
0
F
FFFFFF
(4+2 Standard 1800/2300).
0000 = 12:00 midnight.
F
F
F
FF
F
F
Enter 'F' to represent the end of the number.
0000 = 12:00 midnight.
F
F
F
15
FF
F
F
41
Document 50934 Rev B 5/15/00 PN 50934:B
45
Programming Reference Sheet Factory Default
11008100F1F60
0 F8FAFBFCFDFE
FEFFFFE100E20
0E3E600E8EAEB
ECEDEEEEEFEF9
9919211008100
F1F600F8FAFBF
CFDFEFEFFFFE1
❑70❑71❑72❑73❑74❑75❑76❑77❑78❑79❑80❑
69
❑83❑84❑85❑86❑87❑88❑89❑90❑91❑92❑93❑
82
❑96❑97❑98❑99❑
95
108
121
134
147
160
❑ ❑ ❑ ❑ ❑
109
122
135
148
161
❑ ❑ ❑ ❑ ❑
110
123
136
149
162
❑ ❑ ❑ ❑ ❑
111
124
137
150
163
❑ ❑ ❑ ❑ ❑
112
125
138
151
164
❑ ❑ ❑ ❑ ❑
100
113
126
139
152
165
❑ ❑ ❑ ❑ ❑ ❑
101
114
127
140
153
166
❑ ❑ ❑ ❑ ❑ ❑
102
115
128
141
154
167
❑ ❑ ❑ ❑ ❑ ❑
103
116
129
142
155
168
❑ ❑ ❑ ❑ ❑ ❑
104
117
130
143
156
169
❑ ❑ ❑ ❑ ❑ ❑
105
118
131
144
157
170
❑ ❑ ❑ ❑ ❑ ❑
106
119
132
145
158
171
❑ ❑ ❑ ❑ ❑ ❑
81
94
107
120
133
146
159
172
00E200E3E600E
8 EAEBECEDEEEE
EFEF999192
173
186
199
❑ ❑ ❑
174
187
200
❑ ❑ ❑
175
188
201
❑ ❑ ❑
176
189
202
❑ ❑ ❑
177
190
203
❑ ❑ ❑
178
191
204
❑ ❑ ❑
179
192
205
❑ ❑ ❑
180
193
206
❑ ❑ ❑
181
194
207
❑ ❑ ❑
182
195
208
❑ ❑
183
196
❑ ❑
184
197
❑ ❑
185
198
46
Document 50934 Rev B 5/15/00 PN 50934:B
Appendix A: Zone Assignments
(Unimode 300/400)
Zone No. Zone Function Zone No. Zone Function Zone No. Zone Function
1 34 67 2 35 68 3 36 69 4 37 70 5 38 71 6 39 72 7 40 73 8 41 74 9 42 75 10 43 76 11 44 77 12 45 78 13 46 79 14 47 80 15 48 81 16 49 82 17 50 83 18 51 84 19 52 85 20 53 86 21 54 87 22 55 88 23 56 89 24 57 90 25 58 91 26 59 92 27 60 93 28 61 94 29 62 95 30 63 96 31 64 97 32 65 98 33 66 99
Note: Use chart to carefully identify function of each zone in the system. Take special precaution with any supervisory zones in the system. Use Type Mode (refer to Section 4.2 Type Mode) to match the function of remaining zones in the system for proper reporting.
Caution: When selecting burglar zones, modify the general supervisory report at addresses 75-77 and 145-147, to report general burglary.
Document 50934 Rev B 5/15/00 PN 50934:B
47
Appendix B: Point Assignments (Unimode 300*/400)
.oNtnioPeciveDfoepyT
100150101151 200250201251 300350301351 400450401451 500550501551 600650601651 700750701751 800850801851 900950901951 010060011061 110160111161 210260211261 310360311361 410460411461 510560511561 610660611661 710760711761 810860811861 910960911961 020070021071 120170121171 220270221271 320370321371 420470421471 520570521571 620670621671 720770721771 820870821871 920970921971 030080031081 130180131181 230280231281 330380331381 430480431481 530580531581 630680631681 730780731781 830880831881 930980931981 040090041091 140190141191 240290241291 340390341391 440490441491 540590541591 640690641691 740790 840890841891 940990941991 050001051002
)1
pooLseludoM(
.oNtnioPeciveDfoepyT
)1
pooLseludoM(
toNoD
margorP
.oNtnioPeciveDfoepyT
pooLseludoM(
)2
741791
.oNtnioPeciveDfoepyT
pooLseludoM(
)2
toNoD
margorP
Note: Use chart to carefully identify all points in the system. Take special precaution with any supervisory points and remote switches in the system. Use Type Mode (refer to Section 4.2 Type Mode) to match the function of remaining points in the system for proper reporting. *For Unimode 300, use only Loop 1 in the chart.
48
Document 50934 Rev B 5/15/00 PN 50934:B
Appendix B (continued): Point Assignments (Unimode 300*/400)
.oNtnioPeciveDfoepyT
)1pooLsrotceteD(
102152103153 202252203253 302352303353 402452403453 502552503553 602652603653 702752703753 802852803853 902952903953 012062013063 112162113163 212262213263 312362313363 412462413463 512562513563 612662613663 712762713763 812862813863 912962913963 022072023073 122172123173 222272223273 322372323373 422472423473 522572523573 622672623673 722772723773 822872823873 922972923973 032082033083 132182133183 232282233283 332382333383 432482433483 532582533583 632682633683 732782733783 832882833883 932982933983 042092043093 142192143193 242292243293 342392343393 442492443493 542592543593 642692643693 742792 842892843893 942992943993 052003053004
.oNtnioPeciveDfoepyT
)1pooLsrotceteD(
.oNtnioPeciveDfoepyT
743793
margorPtoNoD
)2pooLsrotceteD(
.oNtnioPeciveDfoepyT
)2pooLsrotceteD(
margorPtoNoD
Note: Addressable detectors on Loops 1 and 2 may be disabled using Type Mode. The Event Code cannot be altered. *For Unimode 300, use only Loop 1 in the chart.
Document 50934 Rev B 5/15/00 PN 50934:B
49
Appendix B (continued): Point Assignments (Unimode 300*/400)
.oNtnioPeciveDfoepyT.oNtnioPeciveDfoepyT
104154 204254 304354 404454 504554 604654 704754 804854 904954 014064 114164 214264 314364 414464 514 614 714 814 914 024 124 224 324 424 524 624 724 824 924 034 134 234 334 434 534 634 734 834 934 044 144 244 344 444 544 644 744 844 944 054
Note: Event Code cannot be altered. Physical location is critical to the point number reported.
50
Document 50934 Rev B 5/15/00 PN 50934:B
Appendix C: Point Assignments (ADT-MNNA)
Note: Use the following charts to carefully identify the function of each point in the system. Take special precaution with any supervisory points in the system. For the ADT-UDACT to report a supervisory point to the central station, both the FACP and the ADT-UDACT must have the point programmed as supervisory. Failure to program the panel or ADT-UDACT correctly will result in a fire alarm signal being transmitted to the central station. All points greater than 568 can only be transmitted as fire alarm points. Use Type Mode (refer to Section 4.2 Type Mode) to match the function of points in the system for proper reporting.
Point No. Point Function Point No. Point Function Point No. Point Function
1 41 81 2 42 82 3 43 83 4 44 84 5 45 85 6 46 86 7 47 87 8 48 88 9 49 89 10 50 90 11 51 91 12 52 92 13 53 93 14 54 94 15 55 95 16 56 96 17 57 97 18 58 98 19 59 99 20 60 100 21 61 101 22 62 102 23 63 103 24 64 104 25 65 105 26 66 106 27 67 107 28 68 108 29 69 109 30 70 110 31 71 111 32 72 112 33 73 113 34 74 114 35 75 115 36 76 116 37 77 117 38 78 118 39 79 119 40 80 120
Document 50934 Rev B 5/15/00 PN 50934:B
51
Appendix C (continued): Point Assignments (ADT-MNNA)
Point No. Point Function Point No. Point Function Point No. Point Function
121 161 201 122 162 202 123 163 203 124 164 204 125 165 205 126 166 206 127 167 207 128 168 208 129 169 209 130 170 210 131 171 211 132 172 212 133 173 213 134 174 214 135 175 215 136 176 216 137 177 217 138 178 218 139 179 219 140 180 220 141 181 221 142 182 222 143 183 223 144 184 224 145 185 225 146 186 226 147 187 227 148 188 228 149 189 229 150 190 230 151 191 231 152 192 232 153 193 233 154 194 234 155 195 235 156 196 236 157 197 237 158 198 238 159 199 239 160 200 240
52
Document 50934 Rev B 5/15/00 PN 50934:B
Appendix C (continued): Point Assignments (ADT-MNNA)
Point No. Point Function Point No. Point Function Point No. Point Function
241 281 321 242 282 322 243 283 323 244 284 324 245 285 325 246 286 326 247 287 327 248 288 328 249 289 329 250 290 330 251 291 331 252 292 332 253 293 333 254 294 334 255 295 335 256 296 336 257 297 337 258 298 338 259 299 339 260 300 340 261 301 341 262 302 342 263 303 343 264 304 344 265 305 345 266 306 346 267 307 347 268 308 348 269 309 349 270 310 350 271 311 351 272 312 352 273 313 353 274 314 354 275 315 355 276 316 356 277 317 357 278 318 358 279 319 359 280 320 360
Document 50934 Rev B 5/15/00 PN 50934:B
53
Appendix C (continued): Point Assignments (ADT-MNNA)
Point No. Point Function Point No. Point Function Point No. Point Function
361 401 441 362 402 442 363 403 443 364 404 444 365 405 445 366 406 446 367 407 447 368 408 448 369 409 449 370 410 450 371 411 451 372 412 452 373 413 453 374 414 454 375 415 455 376 416 456 377 417 457 378 418 458 379 419 459 380 420 460 381 421 461 382 422 462 383 423 463 384 424 464 385 425 465 386 426 466 387 427 467 388 428 468 389 429 469 390 430 470 391 431 471 392 432 472 393 433 473 394 434 474 395 435 475 396 436 476 397 437 477 398 438 478 399 439 479 400 440 480
54
Document 50934 Rev B 5/15/00 PN 50934:B
Appendix C (continued): Point Assignments (ADT-MNNA)
Point No. Point Function Point No. Point Function Point No. Point Function
481 521 561 482 522 562 483 523 563 484 524 564 485 525 565 486 526 566 487 527 567 488 528 568 489 529 490 530 491 531 492 532 493 533 494 534 495 535 496 536 497 537 498 538 499 539 500 540 501 541 502 542 503 543 504 544 505 545 506 546 507 547 508 548 509 549 510 550 511 551 512 552 513 553 514 554 515 555 516 556 517 557 518 558 519 559 520 560
Document 50934 Rev B 5/15/00 PN 50934:B
55
Appendix D: Unimode 2020/1010
The ADT-UDACT is capable of reporting up to 2,040 points when used with the Unimode 2020/1010 (1,980 Addressable devices plus 60 zones or 1,800 Addressable devices plus 240 zones) The first 568 points can be programmed using the Type Mode feature (refer to Section 4.2). All points greater than 568 can be transmitted only as fire alarm points. For the ADT-UDACT to report a supervisory point to the central station, both the FACP and the ADT-UDACT must have the point programmed as supervisory. Failure to program the panel or ADT-UDACT correctly will result in a fire alarm signal being transmitted to the central station.
The ADT-UDACT may be mounted in the Unimode 2020/1010 control panel using the CHS-4 chassis or remotely in an ADT-ABS-8RF or ADT-UBS-1F enclosure up to 6000 feet away from the control panel. All power must be removed from the control panel before making any connections to prevent circuit damage. The EIA-485 serial interface is connected between the control panel and ADT-UDACT using twisted, shielded pair wire. Power should be wired from the control panel's main power supply 24 VDC (nominal) filtered, nonresettable output to TB1 on the ADT-UDACT.
Note: The ADT-UDACT does not support voice and burglar options when used with the Unimode 2020/1010. Refer to the Unimode 2020/1010Manual for additional restrictions.
ADT-UDACT mounting in a Unimode 2020/1010
Remove all power from the FACP by disconnecting AC and batteries. Install the three supplied nylon support posts for the top and bottom left of the ADT-UDACT, one aluminum/nylon and one aluminum standoff in the CHS-4 chassis slot in which the ADT-UDACT is to be installed (refer to Figure D-2). Position the ADT-UDACT on the standoffs and secure on aluminum standoff with a #6-32 screw.
Figure D-1:
ADT-UBS-1F
6708ubs.wmf
Connect the communication line between the EIA-485 terminal block on the Unimode 2020/1010 SIB card and TB-1 terminals 3 and 4 on the ADT-UDACT being certain to observe polarity (refer to Figure D-3). Recommended wire is 12 AWG to 18 AWG twisted pair. If no other devices are connected to the EIA-485, install a 120 ohm EOL resistor across ADT-UDACT TB1 terminals 3 and 4.
Connect the supplied Ground Strap from the ADT-UDACT Earth Ground terminal on TB3 to the CHS-4 chassis. Connect 24 VDC filtered, regulated power to TB1 terminals 1 and 2 on the ADT-UDACT.
ADT-UDACT
Nylon Support Posts
CHS-4
Aluminum Standoff and Screw
Ground Strap
Nylon and Aluminum Standoff
UDACCHS4.WMF
56
Figure D-2: ADT-UDACT Mounting in CHS-4
Document 50934 Rev B 5/15/00 PN 50934:B
TB5 Terminal 5 EIA-485 (+) Terminal 6 EIA-485 (-)
EIA-485 (Supervised and Power-limited
SIB
TB1 Terminal 3 RS+ Terminal 4 RS-
Refer to Figure I-4 for power connections to ADT-UDACT
Install 120 ohm EOL resistor (P/N:71244) across terminals 3 & 4 if last or only device on EIA-485 line. Note that Terminals 6 & 7 are not used at this time.
DO NOT USE
Figure D-3: EIA-485 Connection to Panel Mounted ADT-UDACT
ADT-UDACT
Document 50934 Rev B 5/15/00 PN 50934:B
57
Unimode 2020/1010 cabinet
SIB in Unimode 2020/1010
DO NOT USE
Install 120 ohm EOL resistor (P/N:71244) across terminals 3 & 4 if last or only device on EIA-485 line. Note that Terminals 6 & 7 are not used at this time.
(Supervised) To Phone Lines
Solid Earth Ground Connection
ADT-UDACT in
ADT-ABS8RF
Notes:
AM20ABSU.WMF
(Shown with cover removed)
1) Ferrite cores are recommended for all applications.
2) Recommended wire is 12 AWG to 18 AWG twisted pair.
3) Shielded wire is not required (unless mandated by local AHJ). If shielded wire is used, connect only one end of shield: a) shield may be connected to cabinet (earth ground) at fire alarm panel, or b) shield may be connected to TB1 Terminal 5 (Shield) at ADT-UDACT as shown in Figure D-4.
NOTE: The shield end that is not connected should be insulated to prevent accidental grounding. Do not connect both ends of shield under any circumstance since a ground fault may result.
4) Conduit is recommended for external wire runs. Consult local building codes.
5) Connect Ground Strap (supplied with ADT-ABS8RF enclosure) from Earth Ground terminal on ADT-UDACT to a solid building earth ground. Conduit alone will not provide a reliable earth ground.
6) ADT-UDACT may be located up to 6000 feet away from the host control panel.
7) Refer to Specifications for power requirements.
58
Figure D-4: EIA-485 Connection to Remote ADT-UDACT
Document 50934 Rev B 5/15/00 PN 50934:B
Appendix E: Unimode 300/400
The ADT-UDACT is capable of reporting a maximum of 99 zones or 448 points when used with the Unimode 400.
The ADT-UDACT must be mounted remotely in an ADT-ABS8RF or ADT-UBS-1 enclosure up to 6000 feet away from the control panel. All power must be removed from the Control Panel before making any connections to prevent circuit damage. The EIA-485 serial interface is connected between the Control Panel and ADT­UDACT using twisted, shielded pair wire. Power should be wired from the MPS-400 24 VDC nonresettable output to TB1 on the ADT-UDACT.
Remove all power from the control panel by disconnecting AC and batteries. Since the Unimode 400 cannot accommodate the ADT­UDACT in the control panel enclosure, the ADT-UDACT must be mounted remotely using an ADT-ABS8RF enclosure. Ferrite cores are recommended for this application. Refer to Figure E-3 and the accompanying notes for wiring alternatives.
Connect the communication line between the EIA-485 terminal block TB4 on the Unimode 300/400 and TB-1 terminals 3 and 4 on the ADT-UDACT, being certain to observe polarity (refer to Figure E-3). Recommended wire is 12 AWG to 18 AWG twisted pair. If no other devices are connected to the EIA-485, install a 120 ohm EOL resistor across ADT-UDACT TB1 terminals 3 and 4.
ABS-8R.WMF
Figure E-1:
ADT-ABS8RF
Connect the supplied ground strap from the ADT-UDACT Earth Ground terminal on TB3 to a solid building earth ground. Connect 24VDC nonresettable power to TB-1 terminals 1 and 2 on the ADT-UDACT (refer to Figure E-3).
DISABLED
SUPERVISORY
SIGNAL
SYSTEM TROUBLE
SYSTEM
RESET
POINTS
ALARM
SILENCED
LAMP TEST
ABS-8R.WMF
Figure E-2: ADT-CPU-400 Module
Document 50934 Rev B 5/15/00 PN 50934:B
59
Install 120 watt EOL resistor (PN: 71244) on TB1 terminals 3 and 4 if last or only device on EIA-485 line
Supervised and Power-limited EIA-485 and power wiring
Unimode 400 Cabinet
ADT-CPU-400
MPS-400
TB2-1 (+) TB2-2 (–) 24 VDC Nonresettable power
Ferrite cores PN 29090
To supervised phone lines
Solid earth ground
EIA-485 (ACS Mode) TB4-1 (+) TB4-2 (–)
DO NOT USE
ADT-UDACT in ADT-ABS8RF
(shown with cover removed)
Notes:
1) Ferrite cores are recommended for all applications.
2) Recommended wire is 12 AWG to 18 AWG twisted pair.
3) Shielded wire is not required (unless mandated by local AHJ). If shielded wire is used, connect only one end of shield: a) shield may be connected to cabinet (earth ground) at fire alarm panel, or b) shield may be connected to TB1 Terminal 5 (Shield) at ADT-UDACT as shown in Figure E-3.
NOTE: The shield end that is not connected should be insulated to prevent accidental grounding. Do not connect both ends of shield under any circumstance since a ground fault may result.
4) Conduit is recommended for external wire runs. Consult local building codes.
5) Connect Ground Strap (supplied with ADT-ABS8RF enclosure) from Earth Ground terminal on ADT­UDACT to a solid building earth ground. Conduit alone will not provide a reliable earth ground.
6) ADT-UDACT may be located up to 6,000 feet away from the host control panel.
7) Refer to Specifications for power requirements.
Figure E-3: Unimode 400 External ADT-UDACT Mounting in ADT-ABS8RF
60
Document 50934 Rev B 5/15/00 PN 50934:B
Type Mode Programming
To disable or identify a zone or point in Type Mode (refer to Section 4.2), the following Entries/Addresses are used:
For Zone Identification:
Zones 1 - 99 are programmed by Entries/Addresses 01 - 99. The factory default code is 'fire alarm.'
For Point Identification:
Loop 1, Modules 101 - 196 are programmed by Type Mode Entries/Addresses 01 - 96 Loop 2 Modules 201 - 296 are programmed by Type Mode Entries/Addresses 101 - 196 Loop 1, Detectors 101 - 196 are programmed by Type Mode Entries/Addresses 201 - 296 Loop 2, Detectors 201 - 296 are programmed by Type Mode Entries/Addresses 301 - 396 System 5000 output modules are programmed by Type Mode Entries/Addresses 401 - 464
CAUTION: Addresses 97 - 100, 197 - 200 and 297 - 300 must not be programmed. Refer to the CAB illustrations below.
Event Code/Report Transmission
via Ademco Contact ID Format Only
For Zone Reporting:
Zones 1 - 99 report as zone numbers 01 - 99
For Point Reporting:
Loop 1, Modules 101 - 196 report as device numbers 01 - 96 (Report defaults to '110') Loop 2, Modules 201 - 296 report as device numbers 101 - 196 (Report defaults to '110') Loop 1, Detectors 101 - 196 report as device numbers 201 - 296 (Report defaults to '111') Loop 2, Detectors 201 - 296 report as device numbers 301 - 396 (Report defaults to '111') Output Modules 1 - 64 report as device numbers 401 - 464 (Report defaults to '380', trouble only)
CAUTION: Point reports for Loop 1, Modules 197 through 199, Detectors 197 through 199 and point reports for Loop 2, Modules 297 through 299 and Detectors 297 through 299 are omitted. However, when devices are installed on either SLC Loop and the device is in alarm or trouble, the ADT-UDACT will transmit the general alarm and general trouble reports if enabled.
Following are module locations and their corresponding addresses in various cabinets:
ADT-CAB - B3
UPC004-PFA424-714234-524
ADT-CAB - C3
UPC004-PFA
ADT-CAB - 400AA
UPC004-PFA804-104
044-334844-144654-944464-754
804-104614-904424-714234-524
044-334844-144654-944464-754
Document 50934 Rev B 5/15/00 PN 50934:B
61
Appendix F: ADT-MNNA
The ADT-UDACT is capable of reporting up to 2,040 points when used with the ADT-MNNA. The first 568 points can be programmed using the Type Mode feature (refer to Section 4.2). All points greater than 568 can be transmitted only as fire alarm points. For the ADT-UDACT to report a supervisory point to the central station, both the FACP and the ADT-UDACT must have the point programmed as supervisory. Failure to program the panel or ADT-UDACT correctly will result in a fire alarm signal being transmitted to the central station.
The ADT-UDACT may be mounted in the ADT-MNNA control panel using the CHS-4 chassis or remotely in an ADT­ABS8RF or ADT-UBS-1 enclosure up to 6,000 feet away from the control panel. All power must be removed from the control panel before making any connections to prevent circuit damage. The EIA-485 serial interface is connected between the control panel and ADT-UDACT using twisted, shielded pair wire. Power should be wired from the control panel's main power supply 24 VDC (nominal) filtered, nonresettable output to TB1 on the ADT-UDACT.
Note: The ADT-UDACT does not support voice and burglar options when used with the ADT-MNNA. Refer to the ADT­MNNA Manual for additional restrictions.
ADT-UDACT mounting in an ADT-MNNA
Remove all power from the ADT-MNNA by disconnecting AC and batteries. Install the three supplied nylon support posts for the top and bottom left of the ADT-UDACT, one aluminum/nylon and one aluminum standoff in the CHS-4 chassis slot in which the ADT-UDACT is to be installed. Position the ADT-UDACT on the standoffs and secure on aluminum standoff with a #6-32 screw.
Connect the communication line between the EIA-485 terminal block on the ADT-MNNA and TB-1 terminals 3 and 4 on the ADT-UDACT being certain to observe polarity (refer to Figure F-1). Recommended wire is 12 AWG to 18 AWG twisted pair. If no other devices are connected to the EIA-485, install a 120 ohm EOL resistor across ADT-UDACT TB1 terminals 3 and 4.
Connect the supplied Ground Strap from the ADT-UDACT Earth Ground terminal on TB3 to the CHS-4 chassis. Connect 24 VDC filtered power to TB1 terminals 1 and 2 on the ADT-UDACT.
62
Document 50934 Rev B 5/15/00 PN 50934:B
TB1 Terminal 3 EIA-485 (+) Terminal 4 EIA-485 (-)
ADT-MNNA
TB1
EIA-485 (Supervised and Power-limited
power connections to ADT-UDACT
Install 120 ohm EOL resistor (P/N:71244) across terminals 3 & 4 if last or only device on EIA-485 line. Note that Terminals 6 & 7 are not used at this time.
TB1 Terminal 3 RS+ Terminal 4 RS-
DO NOT USE
ina-udac.wmf
ADT-UDACT
Figure F-1: EIA-485 Connection to Panel Mounted ADT-UDACT
Document 50934 Rev B 5/15/00 PN 50934:B
63
ADT-MNNA cabinet
ADT-MNNA
DO NOT USE
Install 120 ohm EOL resistor (P/N:71244) across terminals 3 & 4 if last or only device on EIA-485 line. Note that Terminals 6 & 7 are not used at this time.
(Supervised) To Phone Lines
Solid Earth Ground Connection
ADT-UDACT in ADT-ABS8RF
(Shown with cover removed)
Notes:
ina-absu.WMF
1) Ferrite cores are recommended for all applications.
2) Recommended wire is 12 AWG to 18 AWG twisted pair.
3) Shielded wire is not required (unless mandated by local AHJ). If shielded wire is used, connect only one end of shield: a) shield may be connected to cabinet (earth ground) at fire alarm panel, or b) shield may be connected to TB1 Terminal 5 (Shield) at ADT-UDACT.
NOTE: The shield end that is not connected should be insulated to prevent accidental grounding. Do not connect both ends of shield under any circumstance since a ground fault may result.
4) Conduit is recommended for external wire runs. Consult local building codes.
5) Connect Ground Strap (supplied with ADT-ABS8RF enclosure) from Earth Ground terminal on ADT­UDACT to a solid building earth ground. Conduit alone will not provide a reliable earth ground.
6) ADT-UDACT may be located up to 6,000 feet away from the host control panel.
7) Refer to Specifications for power requirements.
64
Figure F-2: EIA-485 Connection to Remote ADT-UDACT
Document 50934 Rev B 5/15/00 PN 50934:B
Appendix G: Annunciators
The ADT-UDACT is connected to the EIA-485 communication bus. AFM series and LDM series annunciators may also occupy the same bus. Use of an ADT-UDACT along with one of the above mentioned annunciators on the same control panel will alter the assignments of the first eight yellow LEDs on the annunciator as follows:
004/003edominU
DELrotaicnunnAwolleYtnemngissA
1
2decneliSslangiSdecneliSslangiS 3desUtoNedoMmargorP 4desUtoNyrosivrepuS 5yrosivrepuSelbuorTlleB
6mralaerP
7liaFCAyrettaBwoL 8elbuorTlenaPliaFCA
TCADUtuohtiW
elbuorTmetsyS
)ssolCAtpecxe(
tnemngissA
TCADUhtiW
elbuorTmetsyS
1elbammargorP
)ssolCAtpecxe(
2elbammargorPdesUtoN 3elbammargorPedoMmargorP
4elbammargorPyrosivrepuS
5elbammargorPdesUtoN
/mralaerP
6elbammargorP)esuerutuf(trelAecnanetniaM
trelAecnanetniaM
7elbammargorPyrettaBoN/yrettaBwoL
8elbammargorPliaFCA
DELrotaicnunnAwolleYtnemngissA
ANNM-TDA,0101/0202edominU
TCADUtuohtiW
tnemngissA
TCADUhtiW
elbuorTmetsyS
).vpus&.ttab,ssolCAssel(
Note: When using a ADT-UDACT with the Unimode 2020/1010 or ADT-MNNA, the first Red LED on an annunciator is
used to annunciate alarms while LEDs 2 through 8 are not used.
Document 50934 Rev B 5/15/00 PN 50934:B
65
66
Document 50934 Rev B 5/15/00 PN 50934:B
Document 50934 Rev B 5/15/00 PN 50934:B
67
68
Document 50934 Rev B 5/15/00 PN 50934:B
Loading...
