6304W ONU Gateway Configuration Guide
Version 1.01
ubiQuoss Inc.
www.ubiQuoss.com
Specifications and product availability are subject to change without notice.
© 2017 ubiQuoss. All rights reserved.
Contents
CHAPTER 1 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
CHAPTER 2 Logging into the Web GUI . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
CHAPTER 3 Viewing Device Information . . . . . . . . . . . . . . . . . . . . . . . . . 7
CHAPTER 4 Viewing WAN Interface Information . . . . . . . . . . . . . . . . . . . 9
CHAPTER 5 Configuring WAN Interfaces . . . . . . . . . . . . . . . . . . . . . . . .11
CHAPTER 6 Configuring Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
CHAPTER 7 Viewing Wi-Fi Information . . . . . . . . . . . . . . . . . . . . . . . . . 19
CHAPTER 8 Configuring Voice Service . . . . . . . . . . . . . . . . . . . . . . . . . . 21
CHAPTER 9 Configuring NTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
CHAPTER 10 Configuring Static Routing. . . . . . . . . . . . . . . . . . . . . . . . . . 27
CHAPTER 11 Restarting the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
CHAPTER 12 Reverting to the Default Setting . . . . . . . . . . . . . . . . . . . . . .33
CHAPTER 13 Upgrading Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
CHAPTER 14 Configuring Backups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
6304W Configuration Guide
Contents
CHAPTER 15 Restoring Configuration Files . . . . . . . . . . . . . . . . . . . . . . . 39
CHAPTER 16 Performing Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
ii 6304W Configuration Guide
CHAPTER 1 Getting Started
Default Settings
The following table lists the default settings for the four WAN interfaces to provide
triple play services.
TABLE 1-1. Default Settings
Interface Type VLAN Binding LAN Ports Service
1_TR069_R_VID_400 IPoE 400 TR-069
2_VOICE_R_VID_200 IPoE 200 PHONE1, PHONE2 Voice
3_INTERNET_R_VID_100 IPoE 100 LAN1, Wireless(2.4G/
5G)
4_OTHER_B_VID_300 Bridge 300 LAN2, LAN3, LAN4 IPTV
6304W Configuration Guide 1
Internet
Getting Started
FIGURE 1-1. Rear View
2 6304W Configuration Guide
CHAPTER 2 Logging into the Web GUI
Logging into the Web GUI
Follow these steps to log into the web GUI.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. User names and passwords are case-sensi-
tive.
TABLE 2-1. User Names and Default Passwords
Administrator User
User Name admin useradmin
Default Password admin useradmin
6304W Configuration Guide 3
Logging into the Web GUI
FIGURE 2-1. Login Screen
Changing Passwords
Follow these steps to change a password.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Management > User Info > User Info.
4 6304W Configuration Guide
Changing Passwords
FIGURE 2-2. User Info
6 Select whether to change the user or admin password.
7 Enter the user name, the new password, and then confirm the password.
8 Click Save/Apply.
6304W Configuration Guide 5
CHAPTER 3 Viewing Device Information
Viewing Device Information
Follow these steps to view device information.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Status > Device Info > Device Basic Info. You can view the device type,
device ID, hardware version, and software version.
6304W Configuration Guide 7
Viewing Device Information
FIGURE 3-1. Device Basic Info
8 6304W Configuration Guide
CHAPTER 4 Viewing WAN Interface Information
Viewing WAN Interface Information
Follow these steps to view WAN interface information.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Status > WAN Info > IPv4 Info. You can view the interface description,
type, state, DNS address, and IPv4 address.
6304W Configuration Guide 9
Viewing WAN Interface Information
FIGURE 4-1. IPv4 Info
10 6304W Configuration Guide
CHAPTER 5 Configuring WAN Interfaces
Configuring WAN Interfaces
Follow these steps to configure a WAN interface.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Network > WAN > WAN Connection. You can add, modify or delete
WAN connection settings.
6304W Configuration Guide 11
Configuring WAN Interfaces
FIGURE 5-1. WAN Connection
12 6304W Configuration Guide
Configuring WAN Interfaces
• Connection Name
To add a new WAN connection, select Add new WAN.
To modify or delete a WAN connection, select the WAN connection.
• Service Mode
Select from Internet (nat), VoIP (voice), and Other (bridge).
• Binding Port
Select the LAN port to bind to the WAN interface.
6304W Configuration Guide 13
Configuring WAN Interfaces
14 6304W Configuration Guide
CHAPTER 6 Configuring Wi-Fi
Configuring Wi-Fi
Follow these steps to configure Wi-Fi.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Network > WLAN > WLAN. You can configure basic Wi-Fi features.
6304W Configuration Guide 15
Config uring Wi-Fi
FIGURE 6-1. WLAN
16 6304W Configuration Guide
Configuring Wi-Fi
Changing the Wi-Fi Password
Follow these steps to change the Wi-Fi password.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Network > WLAN > WLAN.
6 Click Advance. Security Settings are displayed.
7 Select the SSID to change the password for.
The following table lists the default Wi-Fi passwords.
6304W Configuration Guide 17
Config uring Wi-Fi
TABLE 6-1. Default Wi-Fi Passwords
Wi-Fi Password
5GHz 1234567890
2.4GHz 12345678
FIGURE 6-2. Wi-Fi Security Settings
18 6304W Configuration Guide
CHAPTER 7 Viewing Wi-Fi Information
Viewing Wi-Fi Information
Follow these steps to configure Wi-Fi.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Network > LAN Info> WLAN Info.
6304W Configuration Guide 19
Viewing Wi-Fi Information
FIGURE 7-1. WLAN Info
• WLAN Interface Info
Displays Wi-Fi interface information.
• WPS Device Info
Displays wireless devices connected to the ONU using the WPS button.
20 6304W Configuration Guide
CHAPTER 8 Configuring Voice Service
Configuring Voice Service
Follow these steps to configure voice service.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Application > VoIP > Basic Setup. You can configure SIP parameters and
enable or disable SIP accounts.
6304W Configuration Guide 21
Configuring Voice Service
FIGURE 8-1. Vo IP > B a s i c S e t u p
22 6304W Configuration Guide
Configuring Voice Service
Configuring Dial Plans
Follow these steps to configure a dial plan.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Application > VoIP > Digitmap Setup.
6304W Configuration Guide 23
Configuring Voice Service
FIGURE 8-2. Vo IP > D i g itmap S e t u p
24 6304W Configuration Guide
CHAPTER 9 Configuring NTP
Configuring NTP
Follow these steps to configure NTP.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Network > SNTP > NTP Server. You can configure the ONU to
synchronize local time with internet time servers.
6304W Configuration Guide 25
Configuring NTP
FIGURE 9-1. SNTP
26 6304W Configuration Guide
CHAPTER 10 Configuring Static Routing
Configuring Static Routing
Follow these steps to configure static routing.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Network > Route > Static Routing. You can configure or delete a static
route.
6304W Configuration Guide 27
Configuring Static Routing
FIGURE 10-1. Route > Static Routing
28 6304W Configuration Guide
Configuring Static Routing
6304W Configuration Guide 29
CHAPTER 11 Restarting the Device
Restarting the Device
Follow these steps to restart the device.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Management > Device> Device Restart.
6 Click Restart.
6304W Configuration Guide 31
Restarting the Device
FIGURE 11-1. Device Restart
32 6304W Configuration Guide
CHAPTER 12 Reverting to the Default Setting
Reverting to the Default Setting
Follow these steps to revert to the default setting.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Management > Device> Factory Default.
6 Click Recovery Factory Set.
6304W Configuration Guide 33
Reverting to the Default Setting
FIGURE 12-1. Factory Default
34 6304W Configuration Guide
CHAPTER 13 Upgrading Software
Upgrading Software
Follow these steps to upgrade software.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Management > Device> Firmware Upgrade.
6 Choose the file, and then click Upgrade Software.
6304W Configuration Guide 35
Upgrading Software
FIGURE 13-1. Firmware Upgrade
36 6304W Configuration Guide
CHAPTER 14 Configuring Backups
Configuring Backups
Follow these steps to configure backups.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Management > Device> Configuration Backup.
6 To save the current configuration to a backup file, click Backup Settings.
6304W Configuration Guide 37
Configuring Backups
FIGURE 14-1. Configuration Backup
38 6304W Configuration Guide
CHAPTER 15 Restoring Configuration Files
Restoring Configuration Files
Follow these steps to restore a configuration file.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Management > Device> Configuration Update.
6 To restore a previously saved configuration file, choose the file, and then click
Update Settings.
6304W Configuration Guide 39
Restoring Configuration Files
FIGURE 15-1. Configuration Update
40 6304W Configuration Guide
CHAPTER 16 Performing Diagnostics
Performing Diagnostics
Follow these steps to perform diagnostic testing.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Diagnosis> Network Diagnosis> Line Test. You can view the current sta-
tuses of LAN and Wi-Fi connections.
6 To refresh, click Re-run Diagnostic Tests.
6304W Configuration Guide 41
Performing Diagnostics
FIGURE 16-1. Line Test
Performing Ping Tests
Follow these steps to perform a ping test.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Diagnosis> Network Diagnosis> Ping Test.
6 Select the Interface.
7 Enter the Destination IP address or Host Name.
8 Click Start.
42 6304W Configuration Guide
Performing Tracert Tests
FIGURE 16-2. Ping Test
Performing Tracert Tests
A tracert test traces the route of packets from an interface to the destination host.
Follow these steps to perform a tracert test.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Diagnosis> Network Diagnosis> Tracert Test.
6 Select the Interface.
7 Enter the Destination IP address or Host Name.
6304W Configuration Guide 43
Performing Diagnostics
8 Click Start.
FIGURE 16-3. Tr a c ert Tes t
Performing Inform Tests
An inform test sends an inform message to the ACS server.
Follow these steps to perform an inform test.
1 Connect your device to LAN 1 or Wireless.
2 Launch a web browser.
3 Connect to 192.168.1.1. A login screen displays.
4 Enter the user name and password. The home screen displays.
5 Select Diagnosis> Network Diagnosis> Inform Test.
6 Click Test.
44 6304W Configuration Guide
Performing Inform Tests
FIGURE 16-4. Inform Test
6304W Configuration Guide 45
6304W ONU Gateway
Installation Guide
Version 1.01
ubiQuoss Inc.
www.ubiQuoss.com
Specifications and product availability are subject to change without notice.
© 2017 ubiQuoss. All rights reserved.
Contents
CHAPTER 1 Pre-Installation Considerations . . . . . . . . . . . . . . . . . . . . . . . 1
Electric Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Device Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
CHAPTER 2 LED Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
CHAPTER 3 Buttons and Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
CHAPTER 4 Installing the ONU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Connecting the Fiber . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connecting the Power Adapter and Power Cord. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connecting the Ethernet Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Connecting the POTS Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
CHAPTER 5 Configuring the ONU. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Accessing the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Setting up WLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Setting Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Downloading to a USB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Managing the ONU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
CHAPTER 7 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
[Problem 1] The Power LED does not light. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
[Problem 2] The Link LED does not light.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
[Problem 3] The Voice LED does not light. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
APPENDIX A Product Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6304W Installation Guide i
CHAPTER 1 Pre-Installation Considerations
This chapter provides pre-installation considerations that the user should note
before installing and using the ONU.
Electric Safety
• Ensure that there are no inflammable, conductive or moist objects near the
ONU.
• It is recommended to plug the optical interface into the jacket when it is not in
use. Avoid direct eye exposure to the laser emitted from the optical interface.
Wear safety glasses to protect your eyes.
Device Position
• A running electric device easily generates heat. Ensure that the device is placed
in a well-ventilated environment.
• Keep the device away from heat and water.
6304W Installation Guide 1
Pre-Installation Considerations
• Ensure that the power supply is reliable. The input voltage fluctuation range
should be lower than 10%. The power plug should not share one socket with a
hair drier, an iron or a refrigerator.
Safety Cautions
• Read the user manual carefully before using the ONU.
• Do not use any accessory that is not shipped with the ONU without prior con-
sent of the manufacturer. This may cause fire or product damage.
• Use the power adapter that is shipped with the ONU.
• Do not place any object on top of the ONU.
• Keep the ONU dry, ventilated, and clean.
• If lightning occurs, unplug the power plug and all connection cables to protect
the ONU against lightning effects.
• Clean the ONU using a soft and dry cloth rather than liquid or atomizers. Turn
off the ONU before cleaning it.
• Turn off the ONU when it is not in use.
• Keep ventilation holes clean and prevent any object from entering ventilation
holes. This may cause short circuit and further cause product damage or fire. Do
not spray liquid on the surface of the ONU.
• Do not open the case of the ONU, especially when it is turned on.
• Before plugging or unplugging the ONU, ensure that the power is off. This is to
avoid surge.
• Be careful when unplugging the ONU, as the transformer may be very hot.
2 6304W Installation Guide
CHAPTER 2 LED Descriptions
This chapter describes conditions indicated by LEDs on the front panel of the ONU.
FIGURE 2-1. Front Panel
TABLE 2-1. LED Descriptions
LED Status Description
Power On Power is on and working.
Off Power is off or there is a power failure.
BAT On Battery is disconnected.
Off Battery is connected.
Internet On Internet is connected and operational.
Off Internet is disconnected.
6304W Installation Guide 3
LED Descriptions
TABLE 2-1. LED Descriptions
LED Status Description
Link 1-4 On Link is connected and operational.
Blinking Data is being transmitted.
Off Link is disconnected.
Voice 1-2 On Voice is connected and operational.
Blinking Data is being transmitted.
Off Voice is disconnected.
USB On USB is connected and operational.
Blinking Data is being transmitted.
Off USB is disconnected.
4 6304W Installation Guide
CHAPTER 3 Buttons and Interfaces
This chapter describes the buttons and interfaces on the rear panel of the ONU.
FIGURE 3-1. Rear Panel
TABLE 3-1. LED Descriptions
Interface/Button Description
PON Fiber port.
RESET Reboots ONU and restores factory default configuration.
POWER DC power connector.
ON/OFF Switch Turns power supply on/off.
POTS 1-2 Telephone interface.
GE 1-4 Ethernet interface.
WLAN Turns WLAN on/off.
WPS-2.4G Connects to Wi-Fi.
6304W Installation Guide 5
Buttons and Interfaces
TABLE 3-1. LED Descriptions
Interface/Button Description
WPS-5G Connects to Wi-Fi.
USB USB port.
UPS UPS port.
6 6304W Installation Guide
CHAPTER 4 Installing the ONU
This chapter provides instructions on how to install the ONU.
Connecting the Fiber
Before connecting the product to the fiber, you need to install the fiber. Follow these
steps to install the fiber.
1 Remove the dust cap from the optical interface.
2 Insert the fiber into the flange plate.
3 Connect the fiber from the flange plate to the optical interface on the wall.
Note
• When a fiber is not in use, cover the optical interface of the ONU and put the dust
cap back on the optical fiber. Prevent dust pollution or water immersion, as this
may cause damage to the fiber and optical interface of the ONU.
• If fibers need to be fixed during parallel cabling, do not fasten the fibers too tightly.
Avoid fiber extrusion, as this may cause fiber damage.
6304W Installation Guide 7
Installing the ONU
Connecting the Power Adapter and Power Cord
Follow these steps to connect the power adapter to the ONU.
1 Insert one end of the power cord attached with the power adapter into the
POWER connector.
2 Press the ON/OFF button to ensure that the power status is ON.
3 Check whether the Power LED is on. If it is on, the power supply is normal.
Otherwise, check whether the power cord and the power adapter are correctly
connected.
Follow these steps to connect the UPS to the ONU.
1 Insert one end of the power cord attached with the UPS device into the UPS slot.
2 Press the ON/OFF button to ensure that the power status is ON.
3 Check whether the Power LED is on. If it is on, the power supply is normal. Oth-
erwise, check whether the power cord and the UPS device are correctly connected.
Connecting the Ethernet Port
Follow these steps to connect to the Ethernet port.
1 Insert one end of a network cable with an RJ-45 connector into the Ethernet
port.
2 Insert the other end of the cable to a PC or Switch.
3 Check whether the Link LED is on. If it is on, the link is connected and
operational. Otherwise, check whether the cable is plugged in properly.
Connecting the POTS Port
Follow these steps to connect to the POTS port.
1 Insert one end of a cable with an RJ-11 connector into the POTS port.
2 Insert the other end of the cable to a telephone.
8 6304W Installation Guide
Connecting the POTS Port
3 Check whether the Voice LED is on. If it is on, voice is connected and
operational. Otherwise, check whether the cable is plugged in properly.
6304W Installation Guide 9
CHAPTER 5 Configuring the ONU
This chapter provides instructions on how to configure the ONU.
Accessing the Internet
After you have successfully connected the ONU, you need to configure the ONU so
that it can obtain an IP address.
If the ONU only uses a serial number to access the Internet:
• After connecting the fiber to the ONU, wait approximately two minutes for an
Internet connection to be established.
If the ONU uses a serial number and EPON password to access the Internet:
1 Type 192.168.1.1 in the address field of a web browser. A login screen appears.
2 Enter the user name and password.
3 Click Network > TR069 > EPON Password. A dialog box appears.
4 Enter your EPON password in the text box and the click SAVE.
5 Wait approximately one minute for an Internet connection to be established.
6304W Installation Guide 11
Configuring the ONU
Setting up WLAN
Follow these steps to set WLAN parameters.
1 Type 192.168.1.1 in the address field of a web browser. A login screen appears.
2 Enter the user name and password.
3 Click Network > WLAN. A dialog box appears.
The following table provides a brief description of WLAN parameters.
TABLE 5-1. WLAN Parameters
Parameter Description
Select SSID Select a WLAN you want to modify.
Network Authentication Select the authentication method. Mixed WPA2/WPA-
PSK is recommended.
WPA Pre-shared Key Enter the WLAN password.
WPA Encryption Select the encryption method. TKIP+AES is
recommended.
Setting Security
Follow these steps to set security.
1 Type 192.168.1.1 in the address field of a web browser. A login screen appears.
2 Enter the user name and password.
3 Click Network > Security. A dialog box appears.
The following table provides a brief description of the available Security features.
12 6304W Installation Guide
Downloading to a USB
TABLE 5-2. Security Features
Feature Description
URL Filter Permit or forbid access to specified addresses.
MAC Filter Permit or forbid access to the Internet.
Firewall Level Select from low, middle, high.
DDOS Setup Set up DDOS to enhance security.
Downloading to a USB
Follow these steps to download files to a USB.
1 Type 192.168.1.1 in the address field of a web browser. A login screen appears.
2 Enter the user name and password.
3 Click Network > Family Storage. A dialog box appears.
The following table provides a brief description of the settings required for USB
usage.
TABLE 5-3. USB Settings
Setting Description
User Name User name authorized by the file server that permits the download of
files.
Password User password.
Port Port used.
Remote URL URL that indicates the position of the file.
Managing the ONU
Follow these steps to manage the ONU.
6304W Installation Guide 13
Configuring the ONU
1 Type 192.168.1.1 in the address field of a web browser. A login screen appears.
2 Enter the user name and password.
3 Click Network > Management. A dialog box appears.
The following table provides a brief description of the Management features.
TABLE 5-4. Management Features
Feature Description
User Info You can change your password.
Device You can restart the ONU.
14 6304W Installation Guide
CHAPTER 7 Troubleshooting
This chapter lists some typical symptoms and check points.
[Problem 1] The Power LED does not light.
Check points:
1 Check whether the power cord is properly connected to the POWER connector
and the outlet.
2 Check whether the proper power adapter is connected.
[Problem 2] The Link LED does not light.
Check points:
1 Check whether the ONU is authorized by the carrier.
2 Check whether the proper network cables are used.
3 Check whether the network cable connection is working.
6304W Installation Guide 15
Troubleshooting
[Problem 3] The Voice LED does not light.
Check points:
1 Check whether the telephone line connection is working.
2 Check whether the ONU is on.
16 6304W Installation Guide
APPENDIX A Product Specifications
TAB LE A-1 . Physical Dimensions
Description Specification
Dimensions
(H x W x D)
Weight Max. 1.10 lbs (0.5 kg)
1.45 in x 5.58 in x 9.60 in
(37 mm x 141.8 mm x 243.9 mm)
TAB LE A-2 . Electrical Specifications
Specification Operational
Power Adapter Input 12 V/2A, Output power 24W
Power Consumption Max. 15 W
6304W Installation Guide 17
Product Specifications
TAB LE A-3 . Environmental Specifications
Specification Operational
Temperature -41°F to 113°F
(-5° to 45°C)
Humidity 5 to 95% (non-condensing)
TAB LE A-4 . Interface Specifications
Description Specification
Interfaces • One optical interface (SC/APC single mode)
• Two RJ-11 interfaces
• Four RJ-45 connectors
TAB LE A-5 . Data Transmission Rates
Feature Rate
Uplink 1.25 Gbps
Downlink 1.25 Gbps
TAB LE A-6 . Standard
Feature Standard
EPON IEEE 802.3ah
18 6304W Installation Guide
N
FCC Regulations
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
OTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/ TV technician for help.
Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the
equipment.
FCC RF Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This device
and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter.
“To comply with FCC RF exposure compliance requirements, this grant is applicable to only Mobile Configurations. The
antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and
must not be co-located or operating in conjunction with any other antenna or transmitter.”
Loading...
