ADTRAN 2FXS-DPO PM User Manual

Section 61109403L2-5
Issue 3, November 1997
CLEI Code: D4F1DFJ_ _ _
PRACTICES
C A U T I O N !
SUBJECT TO ELECTROSTATIC DAMAGE
OR DECREASE IN RELIABILITY.
HANDLING PRECAUTIONS REQUIRED.
2FXS/DPO PM
FOREIGN EXCHANGE STA TION/DIAL PULSE ORIGINATE DATAPORT
WITH PERFORMANCE MONITORING INSTALLATION AND MAINTENANCE

CONTENTS

1. GENERAL ...................................................................1
2. INSTALLATION...........................................................2
3. CONNECTIONS..........................................................4
4. TESTING.....................................................................4
5. MAINTENANCE ..........................................................5
6. WARRANTY AND CUSTOMER SERVICE ................5

FIGURES

Figure 1. 2FXS/DPO...........................................................1
Figure 2. Circuit Path..........................................................3
Figure 3. Connector............................................................4
SW 7
SW 4
SW 3
SW 2
SW 1
2FXS/DPO
1109403L2
PM
AP
REM
PM
TEST
BUSY

TABLES

Table A. SW1 (Receive) and SW2 (Transmit) ...................2
Table B. SW3, SW4, and SW5 Option Settings ................2
Table C. Manual Configuration Guide................................3
Table D. Electronic Provisioning Settings ..........................3
Table E. 2FXS/DPO Faceplate Indicators .........................4

1. GENERAL

This practice provides installation and maintenance information for the ADTRAN® Intelligent 2-Wire Foreign Exchange Station/Dial Pulse Originate (2FXS/DPO PM) Dataport with Performance Monitoring, part number 1109403L2. It is a D4 compatible channel unit and operates in any standard D4 channel bank. Intelligent features requires the unit to be used in the ADTRAN ACT 2300, ACT 1900 , or standard WECO® D4 channel bank using the ADTRAN LIU-3/PM common unit. The 2FXS/ DPO PM provides an interface between a D4 channel bank Pulse Code Modulation (PCM) backplane interface and a 2-wire voice frequency (VF) transmission and signaling facility. Figure 1 is an illustration of the 2FXS/ DPO PM. The unit is multifunctional and can be provisioned to operate in the following modes:
• 2-Wire Foreign Exchange Station (2FXS)
• Dial Pulse Originate (DPO)
• Tandem FXS Mode
• Private Line Auto Ringdown (PLAR)

Figure 1. 2FXS/DPO

Using the FXS/DPO PM in an intelligent channel bank provides additional features and functions such as:
• Local and Remote Provisioning using either the craft interface or ADTRAN Site Manager through a menu driven program called EASYMENU™
• Performance monitoring of the loop
• Network and customer side monitoring and analysis
• Enhanced Test Capabilities
Revision History
Revisions to this practice include CLEI code and dip switch settings.
Features
• Backplane interface to the Pulse Code Modulation (PCM) bus.
• On board coder/decoder (CODEC) uses µ-law encoding/decoding.
• Nominal 600 ohm or 900 ohm 2-Wire VF interface with DC isolation.
Trademarks: Any brand names and product names included in this document are trademarks, registered trademarks, or trade names
of their respective holders.
1Section 61109.403L2-5, Issue 361109.403L2-5C
• Tandem or private line automatic ringdown mode with D3 or D4 signaling.
• Transmit and receive gain/attenuation adjustable in
0.1 dB increments.
• Transmit input range of -4.5 to 1.8 dBm.
• Receive output range of -6.3 to 0.0 dBm.
• Complies with AT&T Publications 43801, 41008, 41009, and Bellcore GR-1089-CORE requirements for Type 1 Equipment.
• Supports Calling Number Delivery and other common (CLASSTM) service offerings according to TR TSY 000030 section 3.3.1.1.

2. INSTALLATION

After unpacking the unit, immediately inspect it for possible shipping damage. If damage is discovered, file a claim immediately with the carrier and then contact ADTRAN customer service (see
Customer Service
).
section 6, Warranty and

Table A. SW1 (Receive) and SW2 (Transmit)

Attenuation Options.
Function
Add Attenuation
Note 1: Factory default setting for all switches is "off." Note 2: Multiple switch activation causes a cumulative effect
on the amount of attenuation added.
Note 3: The largest transmit attenuation value in 2-Wire
mode is 6.3 dB.
Selection/Setting
Amount in dB
0.1 dB SW1,2 - 6
0.2 dB SW1,2 - 5
0.4 dB SW1,2 - 4
0.8 dB SW1,2 - 3
1.6 dB SW1,2 - 2
3.2 dB SW1,2 - 1
Activate
Switch to
"On" Position
The 2FXS/DPO PM plugs directly into an ADTRAN ACT 2300/1900 or standard D4 channel bank. No installation wiring is required. To install, grasp the 2FXS/DPO PM by the faceplate and insert it into the backplane connector until firmly seated.
Provisioning Options
Most options on the 2FXS/DPO are provisionable either manually, using internal slide switches, or electronically using a menu-driven program called EASYMENU. The trunk processing options are found on internal slide Switch 7 (SW7) and can only be provisioned manually.
Manual provisioning should be completed before the 2FXS/DPO is inserted into the channel bank. Electronic provisioning should be completed following installation.
Manual Provisioning
Internal slide switches SW1,2, 3, 4, and SW7 are used to manually provision and set the operational modes and options of the unit. Figure 1 displays switch locations.
Slide switches SW1 and SW2 are used to set, receive, and transmit attenuation. Table A displays the available options.
Slide switches SW3-1, 2, 3, 4, and SW3-5 are used to provision the desired operation mode of the unit.
Slide switch SW4 is used to provision the trunk processing (SD), dial pulse correction (DPC), loop or ground start (GS), PLAR mode (PD3), tandem battery mode (TRB), tandem start mode (TWS), dial tone (DTG), and ringback tone (RTG).
Slide switch SW7 is used to provision the trunk processing options: make busy lead (1G), make busy closure (L), and busy trunk sleeve (S). Table B summarizes the option settings for SW3, SW4, and SW7.

Table B. SW3, SW4, and SW5 Option Settings

Function Switch Selection Setting
Operational Mode
Impedance
TNDM Mode
PLAR Mode
FXS Mode
DPO Mode
Ringback T one
Dial T one
Tandem Mode
Signaling
Tandem Mode
Battery
PLAR Mode
T runk Type
Start Mode
Dial Pulse
Correction
Busy T runk
During CFA
Make Busy
Lead 1 Ground
Make Busy
Closure
Busy T runk Sleeve Option during CFA
SW3-1 (Z900)
SW3-2
(TNDM)
SW3-3
(PLAR)
SW3-4
(FXS)
SW3-5 (DPO)
General Parameters SW4-1 (RTG)
SW4-2 (DTG)
SW4-3 (TWS)
SW4-4
(TRB)
SW4-5
(PD3)
SW4-6
(GS)
SW4-7 (DPC)
SW4-8
(SD)
Trunk Processing
SW7-2
(1G)
SW7-3
(L)
SW7-4
(S)
900 ohms 600 ohms
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Wink
Immediate
Reverse
Normal
D3 D4
Group
Loop
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
Enabled
Disabled
ON
OFF
On Off
On Off
On Off
On Off
On Off
On Off
On Off
On Off
On Off
On Off
On Off
On Off
On Off
On Off
On Off
2 Section 61109403L2-5, Issue 3 61109.403L2-5C
The trunk processing options are provisioned only by switch SW7. Electronic provisioning is not available.
Table C provides a guide to ensure proper provisioning of the desired channel unit mode.

Table C. Manual Configuration Guide

FXS
FXS Gnd
Start
X
X
X
X
X
On
On/Off
On/Off
Off
Off
On
Off
TANDEM
RTG
DTG
TWS
TRB
PD3
GS
DPC
SD
TNDM
PLAR
FXS
DPO
Loop Start
X
X
X
X
X
Off
On/Off
On/Off
Off
Off
On
Off
Options
(SW4-1)
(SW4-2)
(SW4-3)
(SW4-4)
(SW4-5)
(SW4-6)
(SW4-7)
(SW4-8)
(SW3-2)
(SW3-3)
(SW3-4)
(SW3-5)
Note: X = Switch position is ignored.
Loop Start
On/Off
On/Off
On/Off
On/Off
X
Off
X
On/Off
On
Off
Off
Off
TANDEM
Gnd
Start
On/Off
On/Off
On/Off
On/Off
X
On
X
On/Off
On
Off
Off
Off
PLAR
On
X
X
X
On/Off
X
X
On/Off
Off
On
Off
Off
DPO
X
X
X
X
X
X
X
On/Off
Off
Off
Off
On
Before provisioning the unit electronically, access the channel unit by selecting:
Channel Unit Menus (3)
Desired slot (1-24)
Provisioning (2) Select current operational mode (1-4) Select desired provisioning option (1-*)
For additional information on EASYMENU operation or the ADTRAN Site Manager, refer to the EASYMENU User Manual, document number 61150.055L1-1 (found in the ACT 2300/1900 System Manual, document number
2150.050-3), or the Site Manager User Manual, document number 64150.075L1-1. For additional information about the LIU-3/PM see the LIU-3/PM User Manual, part number 61151.001L2-1.
Initial Turn-up
Refer to the desired operational mode in Table C for the correct provisioning options.
Transmit Attenuation
Determine the input TLP. Then use the following formula to calculate the amount of transmit attenuation to add to the circuit:
Tx Attenuation=Input TLP + Internal Tx TLP of 4.5 dBm
Electronic Provisioning
ADTRAN EASYMENU is used to electronically provision the unit. Connect a VT 100 terminal or a computer running a terminal emulation program to the faceplate ADMIN port or REMOTE port using a standard male-to­male RS-232 cable. The settings for the ADMIN and REMOTE ports are shown in Table D.
A null modem cable is required to connect the REMOTE port directly to a terminal.

Table D. Electronic Provisioning Settings

ADMIN Port REMOTE Port
Settings
9600 baud SW2 baud No Parity No Parity 8 bits 8 bits 1 stop bit 1 stop bit
Once connected, enter the password. The factory default
password is PASSWORD in all capital letters. The password may be changed by selecting:
Common Module Menus (2) BCU (1) Configuration (1) Read/Write Password (9)
For example, if an input TLP level of -3 dB is to produce a level of 0dBm0 at TLP0, then the Transmit Attenuation should be set to 1.5 dB.
Receive Attenuation
Determine the output TLP. Then use the following formula to calculate the amount of receive attenuation to add to the circuit:
Rx Attenuation=Internal Rx TLP of 0 dBm) - Output TLP
For example, if 0dBm0 at TLP0 is required to produce an Output TLP level of -3 dB, then the Receive Attenuation should be set to 3 dB. Figure 2 provides an illustration of attenuation settings.
Transmit Path
Tx Atten
0- 6.3 dB TLPO
Rx Atten
0- 6.3 dB
Receive Path
TDATA
0 dBm0
RNPCM 0 dBm0
TLPO
-4.5 to +1.8 dB Input TLP
0 to -6.3 dB
Output TLP
T
R

Figure 2. Circuit Path

3Section 61109.403L2-5, Issue 361109.403L2-5C

3. CONNECTIONS

The 2FXS/DPO PM occupies one card position in the D4 channel bank. The connector pin assignments are detailed in Figure 3.

4. TESTING

The 2FXS/DPO performs a self test after power on. During this time all four indicators turn
On
in a predefined sequence while the 2FXS/DPO verifies proper operation of critical circuits in the design. After successful completion of the self test, all indicators function in their normal mode.
Digital Loopback Test
The Digital Loopback Test is used to test loopback data coming from the network. Received data, or RNPCM, is latched in
+5V
TDATA
RFB
RCLK
RWD
RSQ
-48F
IN
-48SD
BT
20HZ
28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50
R
51 52 53 54
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27
FRM GND
-12V 12V GND +12V 5V GND TWD TSP TSQ RNPCM RFA TDCLK
RSP RNDIS
-48 FRT
-48 SPRT
TFCC 2N
T RT
RG
during the appropriate receive time slot. This data is then placed on the TDATA bus during the

Figure 3. Connector

Pin Assignments
unit's transmit time slot.
Network On-hook/Off-hook Test
The Network On-hook/Off-hook test is used to test signaling sent to the network by the unit. When On-hook Test is selected, On-hook signaling is sent to the network. When Off-hook Test is selected, Off-hook signaling is sent to the Network. The customer loop is forced On­hook while this test is active.
When the option BOTH is selected, tone is placed on both the loop and the network.
Accessing Tests Through EASYMENU
Once the unit is in normal operation, these test features are accessed by selecting:
Channel Unit Menus (3)
Desired slot (1-24)
Test (4)
These tests are service affecting.
Faceplate Indicators
The 2FXS/DPO faceplate indicators and descriptions are explained in Table F.

Table E. 2FXS/DPO Faceplate Indicators

2FXS/DPO
1109403L2
PM
AP
REM
PM TEST BUSY
Indicator
REM
PM
TEST
BUSY
Switch
AP Depressed
Indication Description
Off
Green Flashing
Off
Green
Off
Yellow
Off
Green
Unit is manually provisioned. Unit is remotely provisioned. Configuration/provisioning error.
PM mode is not operating. PM mode is operating.
All tests are inactive. Test is active.
Network and Loop On-hook. Network, Loop, or both are Off­hook.
Selection Description
Alternate provisioning switch. Changes provisioning source from manual to remote or remote to manual.
The 2FXS/DPO PM has four faceplate indicators and a depressed provisioning switch. The front panel PM (Performance Monitoring) indicator
Flashes
during control link establishment and remains ON after the channel unit has been remotely provisioned.
Customer Ringing Test
The Customer Ringing Test will activate the unit's ring relay in a 2-on/4-off ring cadence, providing ringing to the customer loop when a ring generator is properly connected to the channel bank.
1004 Hz DRS Tone Generation Test
The 1004 Hz DRS (Digital Reference Signal) Tone Generation test is used to send the DRS signal to the network, loop, or both. When Network is selected, the DRS is sent to the network from the unit. The far end unit should measure a 1004 Hz tone at a level determined by
If the channel unit has been remotely provisioned, the operator can alternate between the remote configuration data stored in nonvolatile memory or manual switch settings by pressing the momentary AP (Alternate Provisioning) switch located on the front panel.
The REM indicator remains ON when the channel unit is operating based on Remote Provisioning, and is
OFF
when based on manual switches. If the channel unit has never been remotely provisioned, the AP switch has no effect and the REM indicator remains LED
Flashes
when an invalid operation mode is selected.
OFF
. The REM
the circuit gain of the far end unit. When Loop is selected, the DRS is placed on the receive path. The loop receive level is determined by the following equation:
Receive Level = 0dB - Attenuation
4 Section 61109403L2-5, Issue 3 61109.403L2-5C

5. MAINTENANCE

The ADTRAN 2FXS/DPO requires no routine maintenance to operate properly.
ADTRAN recommends that repairs on the unit not be performed in the field. Repair services may be obtained by returning damaged units to ADTRAN (see section 6,
Warranty and Customer Service
).

6. WARRANTY AND CUSTOMER SERVICE

ADTRAN will replace or repair this product within ten years from the date of shipment if it does not meet its published specifications or fails while in service (see ADTRAN Equipment Warranty, Repair, and Return Policy and Procedure).
Return Material Authorization (RMA) is required prior to returning equipment to ADTRAN.
For service, RMA requests, or further information, contact one of the following numbers:
ADTRAN Technical Support ..................(800) 726-8663
Standard support hours, Monday-Friday, 7am-7pm CST
Emergency Support:, 7 days/week, 24 hours/day
ADTRAN Sales ........................................(800) 827-0807
ADTRAN Repair/RMA .............................(205) 963-8722
Repair and Return Address
ADTRAN, Inc. Customer Service Department 901 Explorer Boulevard Huntsville, Alabama 35806-2807
5Section 61109.403L2-5, Issue 361109.403L2-5C
Loading...
