Adler 745-34-2 Programming Manual

Manual, complete

745 - 34 - 2

Sewing unit for runstitching of piped flap

and welt pocket openings and pocket corners

Working methods: A, B, D, F

Operating Instructions

Installation Instructions

Service Instructions

Instructions for Programming DAC

1

2

3

4

Postfach 17 03 51, D-33703 Bielefeld • Potsdamer Straße 190, D-33719 Bielefeld
Telefon + 49 (0) 5 21 / 9 25-00 • Telefax + 49 (0) 5 21 / 9 25 24 35 • www.duerkopp-adler.com

Ausgabe / Edition: 02/2005 Printed in Federal Republic of Germany Teile-Nr./Part.-No.: 0791 745181

745 - 34 - 2

Manual, complete

Contents

Operating Instructions

Installation Instructions

Service Instructions

Instructions for Programming DAC

Interconnection-diagram

9870 745154 B

9890 745002 B

Pneumatic circuit plan

9770 745005

Contents page:

Part 4: Instructions for Programming DACIII, class 745-34-2

Program version A 01

1. General ................................................... 3

2. Operating terminal ............................................ 4

3. Selecting the language ......................................... 5

4. Memory dongle

4.1 Transferring data from the memory dongle to the control...................... 6

4.2 Transferring data from the control to the memory dongle...................... 6

5. Main operating screen

5.1 Sewingandtestprograms:menustructure.............................. 8

5.2 Changing parameter values ....................................... 9

6. Sewing programs

6.1 Calling sewing-program parameter screens ............................. 10

6.2 Running a machine program....................................... 11

6.3 Mainscreen................................................. 12

6.4 Pocketprograms.............................................. 14

6.5 Blowermode................................................ 34

6.6 Pocket sequence ............................................. 36

7. Setting and test programs

7.1 Callingsettingandtestprograms.................................... 38

7.2 Machineparameters ........................................... 40

7.3 Machine-specificsettingandtestprograms ............................. 46

7.3.1 Adjusting the looper-thread monitor .................................. 47

7.3.2 Initializingmemory............................................. 48

7.3.3 Checkingthesmootherfunction .................................... 49

7.3.4 Aligningthelightbarriers......................................... 50

7.3.4.1 Preparingthesewingunitandfeedclamps.............................. 51

7.3.4.2 Sewing unit with two light barriers for automatic angle recognition ............... 53

7.3.4.3 Sewingunitwithtwolightbarriers,leftorrightflappositioning.................. 55

7.3.4.4 Sewingunitwithonelightbarrier.................................... 57

7.3.4.5 ErrorDisplay................................................ 58

7.3.5 Checkingthecorner-bladesettings .................................. 59

7.3.5.1 Checkingthecorner-bladestation................................... 60

7.3.5.2 Checkingthefrontleftcornerblade .................................. 60

7.3.5.3 Checkingtherearleftcornerblade................................... 60

7.3.5.4 Checkingcorner-blademotion ..................................... 61

7.3.5.5 Corner-blademachineparameters................................... 62

4

Contents page:

7.3.6 Testing needle and centre-blade activation .............................. 64

7.3.7 Checkingthetapefeed.......................................... 65

7.3.8 Checking the gripper folder without feed clamp ( versions B and F only)............. 66

7.3.9 Checkingtheinsertionprocesswithfeedclamp........................... 67

7.3.10 Checkingandadjustingthepipingknives............................... 68

7.3.10.1 Checkingthepipingknifemotion.................................... 68

7.3.10.2 Settingthepipingknifereferenceposition .............................. 69

7.3.11 Step-by-stepmode ............................................ 70

7.3.12 Determiningthecycletime........................................ 71

7.3.13 Dongle Menu ................................................ 71

7.4 Multitestsystem.............................................. 72

7.4.1 Displaying the program version and checksum............................ 73

7.4.2 TestingRAM ................................................ 74

7.4.3 Selecting input elements ......................................... 75

7.4.4 Checking input elements ......................................... 77

7.4.5 Selectingoutputelements........................................ 78

7.4.6 CANtest................................................... 81

7.4.7 Checkingthesewingdrive........................................ 82

7.4.8 Errorlist................................................... 83

7.5 Terminalself-test ............................................. 84

7.6 Displaycontrastvalue .......................................... 85

7.7 Editing menus ............................................... 86

7.8 Adjustingtheserialinterface ...................................... 87

8. Error messages

8.1 Sewing motor controller error messages ............................... 88

8.2 Stepping motor error messages ..................................... 89

8.3 Operating indicator error messages .................................. 89

1. General

This manual contains important information on the safe and correct use
of the “DACIII” (Dürkopp Adler Control) new-generation controller.

Screen images in this brief description

The symbol display on the various screens depends on the s ewing
machine’s equipment and settings. The screen images illustrated in
this brief description may therefore not always correspond exactly with
the screens appearing in the controller display.

Operating terminal with graphic user guide

The operating terminal is fitted with an LCD display and a keyboard.
The user guide employs only internationally intelligible symbols,
supplemented with textual information in the selected language. The
various symbols are arranged in groups in the menu structure of the
sewing and test programs.
Simplicity of operation ensures rapid familiarisation.

Ease of programming

99 freely programmable pocket programs are available to the user,
which can be combined with any number of seam patterns.
20 pocket sequences.
Each pocket s equence can be composed of a maximum of 8
pocket programs in any order.
On the “slanting-pocket version” of the class 745-34-2 all practical
angles can be programmed by the operator,
who can thus dispense with the need to spend time and effort
readjusting the corner blades and programming seam displacements.

Setting and test programs

The MULTITEST comprehensive testing and monitoring system is
integral to the DACIII control.
A microcomputer carries out the control functions, monitors the sewing
process and displays incorrect operations and faults.

Errors and test results are shown in the LCD display.
If the machine is operating normally the display shows information
relating to operation and sewing.
In the event of an operating error or fault the function sequence is
interrupted. The display indicates the cause by means of the
appropriate error symbol.
In most cases the error symbol disappears once the error has been
rectified.
In some cases the main switch must be switched off for safety reasons
when the error is rectified.

Special programs facilitate mechanical settings and enable receiver
and transmitter elements to be rapidly tested without additional
measuring devices.

Memory dongle

The dongle is used to memorize sewing programs and machine
parameters and to transfer these data to other sewing units.

4

3

2. Operating terminal

Colour display

Data input and output is done via an operating terminal with a colour
LCD display and a multipurpose keyboard.

RST (reset)
key

Decimal
keypad

Cursor keys

ESC key Function keys

Key/key group Function

Function keys Call sewing-program parameter screens

(from the main screen).
Call test programs (after pressing the RST key)
Switch functions on and off.
Leave test programs and parameter screens.

Cursor keys Change parameter values.

Change parameter values.

ï, ð : select the symbol of the required parameter
ñ, ò : switch the parameter function on and off,

select the previous/next parameter-value stage,
activate the test program

Decimal keypad Enter parameter values.

: change the parameter-value sign

OK key

Escape key Display the old parameter value again.

OK key Open window to set the selected parameter.

Accept the set parameter value.

RST key Leave machine program.

Halt current program.

4

3. Selecting the language

–
–

–
–

–

Switch on the main switch and keep pressing the “ñ” key or
Press the keys “RST” and “ñ” in order to activate the language

selection
The different languages are memorized in the control.
By pressing the cursor keys “ñ“or”ò” the desired language can be

selected (it w ill appear white on black).
With the “F5” key the language that will be activated when

switching on the automat the next time is marked with an asterisk.

4

5

4. Memory dongle

The dongle is used to memorize sewing programs and machine
parameters and to transfer these data to other sewing units.

The transfer direction is selected with the keys ”F2” and “F4”. The data
transfer is started with the “F5”key.

4.1 Transferring data from the memory dongle to the control

–

Use the “ð ”or“ï” cursor keys, to select the required parameter
(machine parameter, sequences or seam program).

–

The pictogram representing the required parameter will then
appear white on black.

–

Start the data transfer by pressing the “F5”key.

F1 F2 F3 F4 F5

4.2 Transferring data from the control to the memory dongle

–

When saving data on the dongle, all parameters, machine
parameters, sequences and seam programs are memorized.

–

After pressing the “F5” key, appears the question whether the
dongle is to be overwritten.

F1 F2 F3 F4 F5

–

The current type of the dongle being plugged in is determined and
indicated on the display.

–

Data transfer can be started by pressing the “F5” key and stopped
with the “ESC”key.

–

If no data dongle 745-34-2 is indicated but e. g. Boot 745-34-2, the
dongle will first be formatted after pressing the “F5” key before the
data are saved on the dongle.

6

–

The dongle is formatted

–

The data is saved onto the dongle

4

7

5. Main operating screen

5.1 Sewing and test programs: menu structure

The user interface exclusively employs internationally intelligible
symbols.

In addition each function is briefly explained in an information line.
The individual parameters and setting and test programs are arranged

in various groups.

Turn on

main switch

Main screen

Sewing programs Setting and test programs

Calling sew ing programs

–

Turn on the main switch.
The controller is initialised.
The DÜRKOPP-ADLER logo briefly appears in the display.

–

The display switches to the main screen.
Sewing-program parameter menus are called by pressing one of
the function keys F1 and F2.

Calling setting and test programs

–

Turn on the main switch.
The controller is initialised.
The DÜRKOPP-ADLER logo briefly appears in the display.

–

While the logo is displayed press one of the function keys F1 to

F5 or cursor up, cursor down.

or with the machine switched on:
–

press the RST key, then hold down one of the function keys F1 to
F5 or cursor up, cursor down.
The display switches to the corresponding group of setting or test
programs.

8

5.2 Changing parameter values

Parameter values are changed in the individual parameter screens.

–

–

–
–

Select the required parameter with the “ï”or“ð”cursorkeys.
A black background appears behind the symbol of the selected
paramet er.

Press the OK key.
The settings window appears with the current values or to enable
values to be entered.

Change the parameters as described under 1 to 4 below.
Press the OK key.

The new parameter settings are saved.

(on) (off)

20

Entry:

10, 12, 14, 16, 18, 20, 22, 24, 26, 30

[-20 ...+20]

When changing parameter values we must distinguish among four
groups of parameters:

1. Functions that are switched on and off

–

Switch the parameter function on and off with the “ð”or“ï”cursor
keys.

2. Parameters with various functions

–

Set the required parameter function with the “ð”or“ï”cursor
keys.

3. Parameters whose values are changed in stages

–

Select the previous or next parameter-value stage with the “ñ”or
“ò”cursorkeys.

4. Parameters whose values are entered with the decimal keypad

–

Enter the required parameter value on the decimal keypad.

CAUTION:

The value must be within the set limits.
If the value entered is too large or too small, the upper or lower
limit is displayed when the Enter key is pressed.

–

If a plus or minus sign appears in front of the parameter value, it
can be changed with the “ ” key.

4

9

6. Sewing programs

With Class 745-34-2 you can program up to 99 different sewing
programs.
The individual sewing programs (pocket programs) are freely
programmable.

20 independent pocket sequences are available. Each pocket
sequence can be composed of a maximum of 8 pocket programs in any
order.

6.1 Calling sewing-program parameter screens

You can switch from the main screen to the various sewing-program
parameter screens with function keys F1 and F2. Function key F5
resets the piece counter to “0". Press F4 for the tape feed (if present).

Pocket Program Sequence

PP Seq

Parameters and sewing-program parameter screens

Pocket Program (PP) : parameters for programming the

Sequence (Seq) : programming pocket sequences
Piece counter : daily piece counter

Piece counter

seam and the
associated additional functions.

10

6.2 Running a machine program

–

Turn on the main switch.
The controller is initialised.

–

The Dürkopp Adler Logo briefly appears in the display.

–

The controller checks the position of the transport carriage.
The following display appears:

Info line:

Reference run

–

Start the reference run by pushing the left pedal back.

–

The display switches to the main screen of the sewing unit.
You can switch from the main screen to the various parameter
screens with function keys F1 or F2.

–

Press the RST key to leave the machine program.
The controller is re-initialised.

4

11

6.3 Main screen

The main screen displays the seam pattern, sewing program, selected
pocket sequence and important parameters.

Parameters can be individually selected by the user.

Info line

Seam pattern

The left half of the display shows the seam pattern of the selected
pocket program.

Sequence

A box indicating the sequence appears in the top right-hand corner.

Selecting program number and pocket sequence

The selected pocket sequence is displayed in the top right-hand
corner.
If automatic pocket-program switching is on, arrows are displayed
between the individual pocket programs of the sequence.

–

Select a pocket sequence with cursor keys “ñ”or“ò”.

“ò” : select next pocket sequence
“ñ” : select previous pocket sequence.

12

Selecting a pocket program in the current pocket sequence

In the pocket sequence the selected pocket program is shown in
reverse video.

–

Select a pocket program with cursor keys “ð”or“ï”.
“ð” : select next pocket program
“ï” : select previous pocket program.

Parameters

The symbols in the centre of the right half of the display give rapid
access to important parameters.
Up to ten parameters can be selected by the operator for display on
the main screen (see also section 6.7).

Parameters can be changed directly on the decimal keypad.
The number of the key to be pressed is displayed to the right of the
parameter symbol.

Example:

0: carriage-return to stand-by position

1: slide-in velocity

2: flap sequence

3: holder

4: vacuum

5: breast welt

6: pocket-program name

7: save pocket program

8: smoother

9: smoother time

The functions and settings of individual parameters are described in
more detail in section 5.4: Pocket programs.

The selection of the parameter symbols is described in section 6.7.

Info line

Text explaining the selected function is displayed in the information
line.

4

Piece counter

The current piece count is displayed at bottom right
(e.g. ).

The piece counter shows the number of pieces completed since the
counter was last reset.
The piece counter can be reset to “0" by pressing function key F5.

13

6.4 Pocket programs ( )

This menu item contains the parameters for programming the various
pocket programs.

They are used to program the seam and its associated additional
functions.

Info line:

Select pocket program

Pocket-program number

–

While the main screen is displayed press function key F1.

The display switches to the pocket-program screen.
–

The pocket program currently selected is shown in the upper part

of the display (e.g. “PP : 01”).

The program name, if any, appears behind it (e.g. “<SAKKO>”).
–

Select the required parameter with cursor keys “ï”or“ð”.

A black box appears under the symbol of the selected parameter.
–

Change the selected parameter as described in section 4.2.
–

Press function key F1 to switch back to the main screen.

This parameter selects the pocket program that is to be changed.
On completion of the entry the new pocket program and its program

name appear in the top left-hand corner of the display.
Entry: 1 .. 99

14

Programming the seam pattern

The actual pocket form is programmed under this menu item. The
programmed pocket is shown with the corresponding information in the
left half of the display.

The corresponding parameter symbols appear in the right half.

–

Select the required parameter with cursor keys “ï”, “ð”, “ñ”or
“ò”.
The symbol of the parameter selected appears in reverse video.

–

Press the OK key.
The corresponding submenu is called.

Seam-start flap shape

This parameter is used to select the shape of the flap at the seam start.
Three variants are available:

Straight flap

Slanting flap (left)

Slanting flap (right)

–

Select the required flap s hape with cursor keys “ï”or “ð”.

–

Press the “OK”key.
The flap-angle entry window appears.

Flap angle

Entry: 01 … 13 [mm]

4

15

Seam-start pattern

This parameter selects the form of the seam pattern at the seam start.

Straight seam pattern

Slanting seam pattern (left)

Slanting seam pattern (right)

–

Select the required seam form with cursor keys “ï”or “ð”.
–

Press the “OK”key.

The seam-angle entry window appears:

Seam angle

Entry: 01 … 13 [mm]

Seam-end flap shape

This parameter selects the form of the flap at the seam end. Three
variants are available:

Straight flap

Slanting flap (left)

Slanting flap (right)

–

Select the required flap s hape with cursor keys “ï”or “ð”.
–

Press the “OK”key.

The flap-angle entry window appears:

Flap angle

Entry: 01 … 13 [mm]

16

Seam-end pattern

This parameter selects the form of the seam pattern at the seam end.

Straight seam pattern

Slanting seam pattern (left)

Slanting seam pattern (right)

–

Select the required seam form with cursor keys “ï”or “ð”.

–

Press the “OK”key.
The seam-angle entry window appears:

Seam angle

Entry: 01 … 13 [mm]

NB:

The seam-angle entry is checked.
If the fixed sewing length and the values entered
cannot be sewn on the machine, an
automatic adjustment of the seam angle
is carried out for the seam end.

Sewing-length measurement

Three different possibilities can be selected.
Distance measurement, automatic recognition by light barrier and
automatic recognition of the flap angle.
An interlock system prevents more than one possibility from being
selected. The other are blocked.

Distance measurement

In distance measurement the sewing length is
displayed on the main screen.

Automatic recognition of flap beginning and flap end

In this setting the reflecting light barrier for the
recognition of the flap beginning and flap end is switched
on for sewing with flaps.

Maximum flap length
Entry: 020 … 180 [mm] optional 220 mm

Automatic flap-angle recognition

Sewing with two light barriers for automatic
flap-angle recognition.

Maximum flap length
Entry: 020 … 180 [mm] optional 220 mm

4

Stitch length

Entry: 2.0 … 3.0 [mm]

17

Select flap side

The sewing length is equipped with a reflecting light barrier for the
recognition of the seam start and end when sewing with flaps.
The parameter indicates which side the flap is attached.
When the parameter is changed the flap side of the seam pattern
automatically switches in the display.

Flap left

Flap right

Seam-start mode left/right needle

Four different seam locks are available for the seam start. They can
be set separately for the right and left needles.

Single bartack

Stitch compaction

Number of bartack stitches

Entry: 01 … 05 [stitches]

Number of stitch-compaction stitches

Entry: 01 … 10 [stitches]

Stitch-compaction stitch length / or bartack

Entry: 0.5 … 3.0 [mm]

18

Seam-end mode left/ right needle

Four different seam locks are available for the seam end. They can be
set separately for the right and left needles.

Single bartack

Stitch compaction

Number of bartack stitches

Entry: 01 … 05 [stitches]

NB:

In zip-fastener mode the bartack length at the seam end
is limited to a maximum of 3 mm.

Number of stitch-compaction stitches

Entry: 01 … 10 [stitches]

Stitch-compaction stitch length/ bartack

Entry: 0.5 … 3.0 [mm]

NB:

In a straight seam pattern only the left seam lock needs to be changed.

4

19

Selecting the positioning point

Depending on the type of piece being sewn, positioning takes place at
the rear, centre or front positioning point.

Rear positioning point (with respect to the operator)

Centre positioning point

Front positioning point (w ith respect to the machine)

head)

Distance from the centre positioning point to the rear
positioning point

Entry: 10 … 170 [mm]

NB:

The entry is checked.
If the fixed sewing length and the value entered
cannot be sewn on the machine, suitable values
are automatically used.

Initialising program memory

The program function is to load standardised factory setting for the
seam-pattern parameters.

–

Press function key F3.

“Initialise sewing program?” appears in the display.
–

Press function key F5.

The parameters are reset to the factory-set values.

20

Light-barrier adjustment

This parameter is used to adjust the light barrier for the seam start and
seam end.

Seam-start adjustment

Seam-end adjustment

Entry: -20.0 … + 20.0 mm

Selecting laser markings

A maximum of 16 lasers can be assigned to each pocket program.

With the number keys 1 to 8 on the numerical display the respective
laser (1-8) can be switched on (with asterisk) or off (no asterisk).

With the “+” key and the number keys 1 to 8 on the number keypad the
respective laser (+1-+8) can be switched on (with asterisk) or off (no
asterisk).

1= * +1=*

2= * +2=*
3= +3=
4= +4=
5= +5=
6= * +6=
7= +7=
8= +8=

4

21

Sewing head

This parameter is used to change values affecting the sewing head.

Sewing speed

Entry: 2000 … 3000 [rpm]

Soft start

Entry: on/off

Soft-start speed

Entry: 0500 … 900 [rpm]

Number of soft-start stitches

Entry: 01 … 20 [stitches]

Reselect icon

Thread-clamp release stitches

Entry: 01 - 99

Sewing mode

Intermittent sewing

Continuous sewing

22

Centre blade

Centre blade

Entry: on/off

CAUTION:

Switching off the centre blade automatically switches off
the corner blades too.
However, switching the centre blade back on does not
automatically switch the corner blades back on again.
They must be switched on separately.

Centre-blade rpm

Entry: 1700...3000 [rpm]
Select with the “ñ”or“ò”keys.

+ Adjusting the centre-blade incision at the seam start

- Changing this value carries out the
fine adjustment of the centre-blade incision at the
seam start.

Entry: - 9.9 … + 9.9 0 = no adjustment

+ = switch on centre blade

sooner

- = switch on centre blade
later

+ Adjusting the centre-blade incision at the seam end

Entry: - 9.9 … + 9.9 0 = no adjustment

+ = switch off centre blade

sooner

- = switch off centre blade
later

4

23

Corner blades

Manual corner-blade station

Switching c orner blades on/off

Entry: on/off

Info line:

Corner blades on/off

All four corner blades on/off

Left corner-blade incision at seam start
on/off

Right corner-blade incision at seam start
on/off

Left corner-blade incision at seam end
on/off

Right corner-blade incision at seam start
on/off

Adjusting the corner-blade incision at the seam start

Changing this value carries out the fine adjustment of the
corner-blade incision at the s eam start.

Entry: -20,0 … +20,0 0 = no adjustment

+ = corner-blade position

sooner

- = corner-blade position
later

Adjusting the corner-blade incision at the seam end

Changing this value carries out the fine adjustment of the
corner-blade incision at the s eam end.

Entry: -20,0 … +20,0 0 = no adjustment

+ = corner-blade position

sooner

- = corner-blade position
later

24

Automatic corner-blade station

Switching c orner blades on/off

Entry: on/off

Info line:

Corner blades on/off

All four corner-blades on/off

Left corner-blade incision at seam start
on/off

Right corner-blade incision at seam start
on/off

Left corner-blade incision at seam end
on/off

Right corner-blade incision at seam end
on/off

4

25

+ Adjusting the left-corner-blade incision at the seam

start

Changing this value carries out the fine adjustment
of the left-corner-blade incision at the seam start.

Entry: - 20.0 … + 20.0 0 = no adjustment

+ = corner-blade position

sooner

- = corner-blade position
later

+ Adjusting the right-corner-blade incision at the seam

start

Changing this value carries out the fine adjustment
of the right-corner-blade incision at the seam start.

Entry: - 20.0 … + 20.0 0 = no adjustment

+ = corner-blade position

sooner

- = corner-blade position
later

+ Adjusting the left-corner-blade incision at the seam

end

Changing this value carries out the fine adjustment
of the left-corner-blade incision at the seam end.

Entry: - 20.0 … + 20.0 0 = no adjustment

+ = corner-blade position

sooner

- = corner-blade position
later

+ Adjusting the right-corner-blade incision at the seam

end

Changing this value carries out the fine adjustment
of the r ight-corner-blade incision at the seam end.

Entry: - 20.0 … + 20.0 0 = no adjustment

+ = corner-blade position

sooner

- = corner-blade position
later

26

Tape feed

Switching t he tape feed on/off

Entry: on/off

Seam-start tape-length

Entry: 00.0 … 99.9 mm

Seam-end tape-length

Entry: 00.0 … 99.9 mm

Flap sequence

No flap clamps

Close left flap clamp first, then right

Close right flap clamp first, then left

Close both flap clamps simultaneously

Only right flap clamp present

Only left flap clamp present

Switching t he holder on/off

Entry: on/off

Switching t he vacuum on/off

Entry: on/off

Smoother

Switching t he smoother on/off

Entry: on/off

4

Smoother time

Entry: 010 … 1000 [strokes]

1 stroke = 0.001 s

Smoother velocity

Entry: 1 … 15
1 = minimum
15 = maximum

27

Transport-carriage settings

Info line:

Return velocity

Return velocity (after sew ing)

The return velocity from the needles to the insertion station
can be reduced.

Entry: 010 … 100 %]

NB:

Even if work is interrupted the carriage moves backwards
at the same velocity.

Slide-in velocity

The slide-in velocity from the insertion station to the
needle and corner station can be reduced.

Entry: 010 … 100 %]

Carriage return with material feed

Info line:

Carriage return to insertion position

28

No material feed after corner incision

Material feed/ Stacker position

After the corner incision the
feed clamps transport the material to the set
position.

Entry: 001 - 100 [mm]

Hint:

The smaller the entry, the further the carriage
moves to the rear.
1 = rear position
100 = cutting position

Carriage return with material feed

After the corner incision the feed clamps
automatically transport the material back to the
positioning area.

Hint:

The icon is only active when the stacker/smoother
is switched off.

Info line:

Return to insertion position

Carriage return to stand-by position

measured from the rear reference switch
Entry: 001 - 515 [mm]

No carriage return

4

29

Switching t he flap feed on/off (versions B and F only)

Entry: on/off

Mode 1

Flap feeders swivel out.

Mode 2

Flap feeders remain swivelled in.

Sewing patterned or plain material (versions “D” and “F” only)

Patterned material

Plain material

Switching t he piping blade on/off (versions B and F only)

Entry:

on/off

Cutting depth at the seam beginning

Cutting depth at the seam end

Selecting pedal mode

Two different variants of the insertion process with vacuum and / or
holder can be selected.

Pedal mode 1

In this mode the insertion process is carried out
by pressing and holding down the left pedal while operating
the right pedal.

Pedal mode 2

For insertion, the pedal must be brought to its initial
position, between the steps.

Pedal mode 3

The clamp goes in sewing position after actuating
the pedal.

30

Breast-welt mode

Entry: on/off

Rapid clamp adjustment

Info line:

Rapid clamp adjustment

Rapid clamp adjustment

Clamp left outer, right outer

Clamp left outer, right inner

Clamp left inner, right outer

4

Clamp left inner, right inner

CAUTION: danger of breakage

If the single-piping folder is fitted do not select a double-piping
program, i.e. do not select clamp left inner and right inner.

31

Feed-clamp sequence right/left

Both clamps descend simultaneously

Lower left clamp first

Lower right clamp first

Entering the program name

This parameter assigns a name to any pocket program.
The program name is limited to 18 letters.

–

Select the parameter with cursor keys “ð ”or“ï”.

–

Function keys F2 and F3 browse the alphabet.

F2:forwards
F3: backwards

0..9: digit entry

–

Pressing cursor keys “ï”or“ð” moves the cursor one place to the
left or right.

–

Press the “OK”key
to terminate entry.
The program name entered is assigned.
Press the “ESC” key to use the old program name again.
Press F5 to delete the name.

Copying pocket programs

This parameter is used to copy the selected pocket program into
another program.

The number that must be entered is that of the sewing program into
which the selected pocket program is to be copied.

On completion of the entry the number and name of the pocket
program appear in the display.

Entry: 1 … 99

32

Switching t he zip-fastener scissors on/off

Entry: on/off

Initialising program memory

The program loads a standardised factory setting, including seam
pattern, for the sewing-program parameters.

–

Press function key F3.
“Initialise sewing program?” appears in the display.

–

Press function key F5.
The parameters are restored to the factory settings.

Switching t he w aistband clamp on/off

Entry: on/off

Fabric holder mode (versions A and B only)

The choice of fabric holder, vacuum and waistband clamp sequence is
selected when loading the fabric holder mode.

Mode Fabric Holder Vacuum Waistband clamp

11 2 1

21 1 2

31 2 3

41 1 0

51 3 2

62 3 1

72 1 2

82 2 1

4

33

6.5 Blower mode

Entry:
0, 1, 2, 3, 4. 5. 6, 7

Valve YC108 Valve YC109 Application

Position blowing on blowing off Position blowing on blowing off

Mode 0 -active -activefunction of f

Mode 1 blower pipe

in flap
clamps

Mode 2 blower pipe

in flap
clamps

Mode 3 blower pipe

in flap
clamps

Mode 4 blower pipe

in flap
clamps

flap clamps
closed

flap clamps
closed

flap clamps
closed

flap clamps
closed

needles on needles on

needles on blower pipe

in the

folding sheet
closed

folding sheet

needles onneedles on flap clamp

needles on blower pipe

in the

folding sheet
closed

closed

folding sheet

10 mm after
the loading
position

blower pipe
in the
folding sheet

needles on blower pipe

in the

Stamp sinkup10 mm after

Feeding­position

Stamp sinkupflap clamp

closed

folding sheet

Blow pocket bag
and/or piping to
the seam
beginning
simultaneously

Blow pocket bag
and piping to the
seam beginning
alternately

Shortly blow
pocket bag
and/or piping
simultaneously.
Blow piping
during the
lowering of the
stamp already

Blow pocket bag
and piping to the
seam beginning
alternately . Blow
piping during the
lowering of the
stamp already

Mode 5 Short

blower pipe
in left flap
clamp

Mode 6 blower pipe

in flap
clamps

Mode 7 blower pipe

in flap
clamps

5mmafter
the loading
position

flap clamps
closed

10 mm after
the loading
position

needles on blower pipe

in right flap
clamp

needles on blower pipe

in the
folding sheet

180 mm
after the
loading

blower pipe
in the
folding sheet

position

flap clamp
closed

folding sheet
closed

20 mm after
the loading
position

needles on

180 mm
after
Feeding­position

180 mm
after
Feeding­position

Blow pocket bag
on flap

Blow pocket bag
and/or piping
simultaneously.
Blow piping after
path.

Blow pocket bag
and/or piping
after paths.

34

Notes:

4

35

6.6 Pocket sequence ( )

This menu item is used to assemble individual pocket programs into
callable sequences.

A total of 20 independent pocket sequences are available.
Each pocket s equence can consist of up to 8 pocket programs in any
order.

Info line:

Sequence programming

Programming a pocket sequence

–

When the main screen is displayed press function key F2.
The display switches to the pocket-sequence screen.

–

Move the cursor to the required pocket sequence with the “ ñ”or
“ò”keys.
The number of the s elected pocket sequence appears in reverse
video.

–

Programming a pocket sequence.
Enter the numbers (01 ...99) of the required pocket programs one
after another using the decimal keypad.
Single-digit pocket-program numbers must be preceded by a zero.
Once the eighth pocket program has been entered the programmed
pocket sequence is automatically stored.

–

Press the “OK”key
to store the pocket sequence.
Pressing the “ESC ” k ey during programming restores the old
pocket sequence.

–

Press function key F1.
The display switches back to the main screen.

36

Switching automatic pocket-program sequencing on/off

If this function is switched on, when one pocket program has been
completed the controller automatically moves to the next pocket
program in the sequence.

–

Automatic pocket-program sequencing is switched on and off by
pressing function key F5.
Automatic sequencing is indicated in the display by arrows
between the individual pocket programs of the sequence.

Entering a sequence name

–

While the sequence screen is displayed press function key “F2”.
The display switches to the sequence-name screen.

Info line:

Entering sequence name

–

Press function key “F2”or“F3” to enter the first letter.

–

Press the “ð” key to move to the next position.

–

Press function key “F2”or“F3” to enter the next letter.

–

Press “OK” to store the name.

Pressing function key “F5” erases the whole name.

4

37

7. Setting and test programs

The machine software includes various machine-specific setting and
test programs, together with the well-known MULTITEST system.
A terminal self-test checks the individual components of the operating
terminal.

7.1 Calling setting and test programs

Once the machine has been switched on, pressing certain keys opens
the various groups of setting and test programs.

Turn on the main

switch

Main screen

Functions when keys are pressed and held down:

“F1” Machine parameters
“F2” Machine test and setting programs
“F3” MULTITEST
“F4” Terminal self-test
“F5” Contrast value of the display
“Cursor-up” Language selection
“Cursor-dow n” Edit menu

38

–

The key for the required setting or test program should be pressed
and held down.

–

Turn on the main switch.
The controller is initialised.
The DÜRKOPP-ADLER logo briefly appears in the display.
The display switches to the corresponding group of setting and test
programs.

or

–

Press the “RST”key.

–

Press and hold down the key for the required setting or test
program.

4

39

7.2 Machine parameters ( + or main switch on + )

Code

The machine parameters describe the machine’s technical
configuration as well as its settings and their adjustment values.

CAUTION:

Changes to machine settings usually entail mechanical conversion.
For this reason this program section is only accessible after the entry
of code number “25483”.

Info line:

with/without automatic corner blade

–

Press the “RST” key or turn the main s witch on and press function
key “F1”.
The code-number entry box appears in the display.

–

Enter code number “25483” on the decimal keypad.
Once the correct code number has been entered the display
switches to the machine-parameter screen.
If an incorrect code number is entered the display switches to the
main screen.

–

Select the required parameter with cursor keys “ð”, “ï”, “ò”or
“ñ”.
A black background appears behind the symbol.

–

Activate the selected parameter with the “OK”key.

–

Change the selected parameter as described in section 4.2.

–

To leave machine parameters press the “RST” key or turn off the
main switch.

40

Corner-blade settings for angles

This parameter tells the c ontroller whether the c orner blades are to be
set manually or automatically.

Manual corner-blade positioning

Automatic corner-blade positioning

Maximum sewing length

*

Entry: 180, 200, 200

, 220 [mm]

Select with the “ò”or“ñ”keys.

Folder unit

Entry: A, B, D, F

A: piped pockets,

manual positioning of piping strip,
flaps and other items

B: piped pockets,

automatic piping-strip feed
with incision of the ends

D: breast-welt pockets,

automatic breast-welt feed and alignment

F: piped pockets,

automatic piping-strip feed,
automatic flap feed and alignment,
incision of piping ends

4

Needle distance

Entry: 10, 12, 14, 16, 18, 20, 22, 24, 26, 28, 30 [mm]

Switching t he thread monitor on/off

This parameter switches the needle-thread and looper-thread monitor
on and off.

Entry: on/off

41

Selecting the flap feed mode (versions B and F only)

Info line:

without flap feed

without Flap Feed

Flap Feed switched off

Flap Feed Mode 1

Step forward on the right pedal,

flap feed opens.

left
Step back on the right pedal,
right flap feed opens.

Tape Feed

Flap Feed Mode 2

Step forward on the right pedal,
flap feed on both sides
Step back on the right pedal,
right flap feed opens.

open.

42

Info line:

with/without tape feed

without Tape Feed

Tape feeding switched off

Tape Feed with Step Motor

Equipment: electromotor driven tape feeder

Electro-pneumatic Tape Feeding

Equipment: electro-pneumatic driven tape feeder

Switching t he vacuum system on/off

This parameter tells the c ontroller w hether the machine is fitted with a
vacuum system.
The vacuum system is switched on and off in the pocket-program menu
item (F1) on the main screen.

Entry: on/off

Switching t he holder on/off

This parameter tells the c ontroller w hether the machine is fitted with a
holder.
The holder is switched on and off in the pocket-program menu item
(F1) on the main screen.

Entry: on/off

Switching t he stacker/blow er pipe on/off

This parameter tells the c ontroller w hether the machine is fitted with a
stacker/ blower pipe.
The stacker/ blower pipe is switched on and off in the pocket-program
menu item (F1) on the main screen.

Entry: on/off

4

43

Switch w aistband clamp on/off

This parameter s ignalizes the control w hether the sewing unit is
equipped with a waistband clamp or not.

Pocket bag over flap mode

Any change concerning the pocket bag over flap mode should be done
here i.e. in which position the raised feed clamp goes for the inserting
position.

Info line:

Pocket bag over flap

Switch piping cutter on/off

This parameter signals the control whether the sewing unit is equipped
with a piping incision device.

Entry:

on/off

left piping cutter, with motor

right piping cutter, with motor

44

Activating the smoother

This parameter tells the controller whether the machine is fitted with a
smoother.
The smoother is switched on and off in the pocket-program menu item
(F1) on the main screen.

Entry: on/off

Selecting light barriers for flap scanning

Info line:

distance measurement… mm

No light barrier present

Flap scanning with one light barrier

Two light barriers for flap side left/right

NB:

Flap side left/right is determined by the seam program.

Automatic angle recognition

Tape cutter present

Entry: on/off

4

45

7.3 Machine-specific setting and test programs
( + or main switch on + )

The machine-specific test programs test and adjust individual machine
components.

Info line:

Adjusting the looper-thread monitor

–

Press the “RST” key or turn the main switch on and press function
key “F2”.
The display switches to the machine-specific test-program screen.

–

Select the required test program with cursor keys “ð”, “ï”, “ò”or
“ñ”.
A black background appears behind the symbol.

–

Press “OK” to run the selected test program.

–

Change the selected parameter as described in section 4.2.

–

To leave machine parameters press the “RST” key or turn off the
main switch.

46

7.3.1 Adjusting the looper-thread monitor

This program aligns the reflecting light barriers of the looper-thread
monitor.

Info line:

Adjusting the looper-thread monitor

–

Press OK to run the test program.
Two looper-thread bobbins and the light-barrier reflecting heads
appear in the display.

When the light barriers are correctly aligned a reflection occurs when
an empty bobbin turns.
The black bar and a figure between 1 and 15 will show the intensity of
the reflection.
If the minimal value (=8) is shown, an arrow will be displayed between
the reflecting head and the looper-thread bobbin. You will hear a beep
at the same time.

Hint:

If the light-barrier is set properly, the maximal value of 15 must be
attained when the infrared beam reaches the bobbin (black bar in the
green zone).

–

To leave test programs press function key F1.

4

47

7.3.2 Initializing memory

The program loads a standardised factory setting for the
sewing-program parameters,
e.g. for a new controller:

Info line:

Initializing memory

Code

CAUTION:

Once one of these three programs has been run the parameters set
are overwritten with a standardised factory setting.

For this reason this program section can only be run after the entry of
code number “25483”.

–

Press OK to run the test program.
The code-number entry box appears in the display.

–

Enter code number “25483” on the decimal keypad.
Once the correct code number has been entered the display
switches to the four parameters listed below.
If an incorrect code number is entered, the display switches to the
machine-specific parameter screen.

Initializing the machine parameters

Initializing pocket programs

Initializing pocket sequences

48

Initializing all programs and parameters

Hint:

After initialization, the machine parameters (RST + F1)mustbe
rechecked.

–

–
–

7.3.3 Checking the smoother function

This program tests the function of the smoother.

Select the required test program with cursor keys “ï”or“ð”.
A black background appears behind the symbol.

Press OK to run the selected program.
To leave machine parameters press the “RST” key or turn off the

main switch.

Info line:

Testing smoother

–

Press OK to run the test program.
The symbol appears with the entry fields.

smoother time (t)

smoother velocity (v)

–

Enter the required values for “t” and “v”.

Entry:

Active period: t = 10...1000

Increment: 1 stroke = 0.001 s

Velocity stage: v = 1...15

–

Press the “F5“key.
The smoother runs for the selected period at the set velocity.

–

To leave the test program press function key F1.

4

49

7.3.4 Aligning the light barriers

First light barrier

Second light barrier for
flap scanning

This program aligns the reflecting light barriers for recognition of the
seam start and end.

Info line:

Aligning the light barriers

The light barriers are adjusted with two templates.
Left template = for straight pockets.
Right template = for slanting pockets.

50

7.3.4.1 Preparing the sewing unit and feed clamps

Caution: danger of injury

The light barriers are adjusted with the machine switched on.
The utmost care must be taken when carrying out adjustments and

function-testing.

321

CAUTION: danger of breakage

It is essential for the folder station to be swivelled out for the light
barriers to be adjusted.

–

Swivel out the folder station 1.

–

Lay material under the feed clamps.

–

Run the test program.
Close the flap clamp and folding plates,
the feed clamps descend.

–

Pull the feed clamps forwards.

–

Align the light barriers to the centre of the reflecting foils 2.
The area from seam start to seam end must be checked on the
clamp.
Orange LED: on = reflection available

off = no reflection
Green LED: on = stable switching signal
If the green LED does not shine, the light-barrier should be
cleaned, readjusted, replaced or a new reflecting foil should be
fitted.

Proceed as follows:

- Attach a reflecting strip 2 on the left and on the right over the

whole length so that a strip of approx. 2 mm remains uncovered
in the middle.

- Push the feeding clamps to the back until they are centrally

underneath the light barriers.

- Loosen screws 3 and align the light barriers to the strip of the

reflecting foils 2. Tighten screws 3.

- Push the feeding clamps in the rear and front position and check

the alignment of the light barriers.

4

51

1

Check of the light barrier position with swung-in folder

–

When the feeding clamps are in the rear position, swing the folding
station 1 in.

–

Press key “7“.
Folder (A) or pick-up folder (B/F) are made pressureless.

–

Press the folder on the sliding sheet manually and pull the feeding
clamps to the front.
Make sure that the folder sole is guided under the folding sheets.

–

Check switching of the light barriers with swung-in folder.

–

Swing the folding station out again.

Hint:

If the light barriers do not switch at the seam beginning and seam
end, the parallel position of the feeding clamps has to be checked
(see Service Instructions).

–

Remove adhesive tapes from the reflecting strips.

52

Danger of breakage !

When the light barrier adjustment has been finished, the folding
station has to be swung out again in any case.

7.3.4.2 Sewing unit with two light barriers for automatic angle recognition

32 1

Caution: danger of injury

During the reference run the feed clamps move forwards or
back and forth several times.

Do not reach into the path of the feed clamps.
Folding station must be swinged out

–

–

–

–

–

–

–
–

–

65 4

Press function key “F3”.
The reference run is carried out.

4

Press “8” and select clamp position (see page 33).
Hint:

The light barriers must be aligned to the clamp position.

Press “9”.
The flap clamp opens.

Press function key “F4”.
The needles are switched on.

Turn the hand-wheel in the direction of rotation to lower the
needles to about 2 mm above the material.

Insert the straight-pocket template 1 so that line 2 points to the left
needle and is parallel to the right feed clamp.

Press “9”toclosetheflapclamp.
Stick the left, proud side of the template to the clamp with a strip of

adhesive tape 3.
Press function key “F4”.

The needles are switched off.

–

Turn the handwheel in the opposite direction to the direction of
rotation to bring the needle back to top dead centre.

53

Caution: danger of injury

During template scanning the feed clamps move back
and forth several times.

Do not reach into the path of the feed clamps.

–

Press function key “F5”.
The straight-pocket template is scanned.
The scanned parameters appear in the display. They are
automatically passed to the controller.

789

Info line:

Aligning light barriers

–

Press “9”.
The flap clamp opens.

–

Remove the straight-pocket template.
Insert the slanting-pocket template 4 so that line 5 points to the left
needle and is parallel to the right feed clamp.

–

Press “9”.
Theflapclampcloses.

–

Stick the left, proud side of the template to the clamp with a strip of
adhesive tape 3.

–

Press function key “F2”.
The slanting-pocket template is scanned.
The scanned parameters appear in the display. They are
automatically passed to the controller.

–

Press “9”.
The flap clamp opens.

–

Remove the slanting-pocket template.

–

Press function key “F1” to terminate the test program.

–

Push feed clamps backwards by hand.

–

Swivel folding station back and lock in place.

–

Press the “RST” key or switch the machine off and on again.

54

7.3.4.3 Sewing unit with two light barriers, left or right flap positioning

321

Caution: danger of injury

During the reference run the feed clamps move forwards or back
and forth several times.

Do not reach into the path of the feed clamps.
Folding station must be swinged out

–

Press function key “F3”.
The reference run is carried out.

–

Press “8” and select the clamp position (see page 33).

Hint:

The light barriers must be aligned to the clamp position

–

Press “9”.
The flap clamp opens.

–

Press function key “F4”.
The needles are switched on.

–

Turn the hand-wheel in the direction of rotation to lower the
needles to about 2 mm above the material.

–

Insert the straight-pocket template 1 so that line 2 points to the left
needle and is parallel to the right feed clamp. Both reflecting foils
must be covered.

–

Press “9”toclosetheflapclamp.

–

Stick the left, proud side of the template to the clamp with a strip of
adhesive tape 3.

–

Press function key “F4”.
The needles are switched off.

4

–

Turn the hand-wheel in the opposite direction to the direction of
rotation to bring the needle back to upper dead center.

55

Caution: danger of injury

During template scanning the feed clamps move back and
forth several times.

Do not reach into the path of the feed clamps.
Folding station must be swinged out

–

Press function key “F5”.
The template is scanned.
The scanned parameters appear in the display. They are
automatically passed to the controller.

789

Info line:

aligning light barriers

–

Press “9”.
The flap clamp opens.

–

Remove the template.

–

Press function key “F1” to terminate the test program.

–

Push feed clamps backwards by hand.

–

Swivel folding station back.

–

Press the “RST” key or switch the machine off and on again.

Hint:

Light barrier S1 for left clamp
Light barrier S2 for right clamp

56

7.3.4.4 Sewing unit with one light barrier

Caution: danger of injury

During the reference run the feed clamps move forwards or
back and forth several times.

Do not reach into the path of the feed clamps.
Folding station must be swinged out

321

–

Press function key “F3”.
The reference run is carried out.

–

Press “8” and select the clamp position (see page 33).

Hint:

The light barriers must be aligned to the clamp position

–

Press “9”.
The flap clamp opens.

–

Press function key “F4”.
The needles are switched on.

–

Turn the hand-wheel in the direction of rotation to lower the
needles to about 2 mm above the material.

–

Insert the straight-pocket template 1 so that line 2 points to the left
needle and is parallel to the right feed clamp. Both reflecting foils
must be covered.

Hint:

Place the template under the clamp on which the light barrier is
mounted, left or right.

–

Press “9”toclosetheflapclamp.

–

Stick the left, proud side of the template to the clamp with a strip of
adhesive tape 3.

–

Press function key “F4”.
The needles are switched off.

4

–

Turn the hand-wheel in the opposite direction to the direction of
rotation to bring the needle back to upper dead center.

57

Caution: danger of injury

During template scanning the feed clamps move back and
forth several times.

Do not reach into the path of the feed clamps.
Folding station must be swinged out

–

Press function key “F5”.
The template is scanned.
The scanned parameters appear in the display. They are
automatically passed to the controller.

789

7.3.4.5 Error Display

Info line:

Aligning light barriers

–

Press “9”.
The flap clamp opens.

–

Remove the template.

–

Press function key “F1” to terminate the test program.

–

Push feed clamps backwards by hand.

–

Swivel folding station back.

–

Press the “RST” key or switch the machine off and on again.

Error 1:
–

Incorrect alignment of the light barrier.

–

Incorrect sensitivity setting.

–

Template inserted in a wrong way.

Error 2:
–

Wrong / Damaged template for “straight pockets”.

58

Error 3:
–

Wrong / Damaged template for “slanting pockets”.

7.3.5 Checking the corner-blade settings

This program checks the corner-blade distances.

Info line:

Adjusting corner blades

–

Select the required parameter with cursor keys “ï”or“ð”.
A black background appears behind the symbol.

–

Press OK to run the selected program.

Corner-blade machine parameters

Corner-blade distance

Seam-start corner-blade adjustment
(automatic corner-blade station only)

Seam-end corner-blade adjustment
(automatic corner-blade station only)

Corner-blade frames reference run

4

59

7.3.5.1 Checking the corner-blade station

1

Caution: danger of injury

Serious cuts may result from reaching into the vicinity of the corner
blades.
The utmost care must be taken when carrying out tests on the machine
when it is running.

–

Press function key “F3”.
The corner-blade frames carry out a reference run.

–

Select the “corner-blade distance” symbol with cursor keys “ï”or
“ð”.

–

Enter a corner-blade distance and press the “OK” key to move the
corner blade.
Example:
corner-blade distance entry = 100 mm.

–

Check the distance between the corner-blade frames 1 and 6.

7.3.5.2 Checking the front left corner blade (automatic corner-blade station only)

–

Select the “seam-start corner-blade correction” symbol with
cursor keys “ï”or“ð”.

–

Enter a correction value (+ or -) and press the “OK”keytomove
the corner blades.

–

Check the distance between corner blades 2 and 3.

54 32

7.3.5.3 Checking the rear left corner blade (automatic corner-blade station only)

–

Select the “seam-end corner-blade correction” symbol with
cursor keys “ï”or“ð”.

–

Enter a correction value (+ or -) and press the “OK”keytomove
the corner blades.

–

Check the distance between corner blades 4 and 5.

60

7.3.5.4 Checking corner-blade motion

Caution: danger of injury

Do not reach into the vicinity of the corner blades.
When rising they can inflict serious cuts.
The utmost care must be taken when testing the corner blades when
the machine is in operation.

The individual corner blades are tested in sequence.
The test sequence is commenced by pressing function key “F5” and

then continued by pressing it again.
Pressing function key “F4” moves back one step in the test sequence.

–

·

·

·

·

Press function key “F5”.
The following steps are carried out:

step 1 = front corner blades rise and stay up

step 2 = rear corner blades rise and stay up

step 3 = only front left corner blade rises and stays up

step 4 = front right corner blade rises and stays up

step 5 = rear left corner blade rises and stays up

·

step 6 = rear right corner blade rises and stays up

·

step 7 = complete cut with all four blades

·

4

61

7.3.5.5 Corner-blade machine parameters

Code

Basic positioning of the corner blades to the seam is carried out in the
machine-parameter program.

–

Select “corner-blade machine parameters ”withcursorkeys“ï ”
or “ð”.
A black background appears behind the symbol.

–

Press OK to start the program.
The code-number entry box appears in the display.

–

Enter code number “25483” on the decimal keypad.
The corner-blade correction screen appears.

Info line:

Seam-end corner-blade correction value

To correct the corner incisions and the centre-blade cut a sewing piece
should first be prepared and sewn. The procedure is as follows:

–

Set up a test program on the controller and set all corner- and
centre-blade corrections to “0".

–

Iron a piece of Vlieseline
This shows up the corner incisions better.

–

Sew a test seam.

–

Check the seam and cut pattern.

–

To leave the test program press function key F1.

â

onto the sewing piece.

62

Seam-end corner-blade correction value

Entry: -99.9 … 99.9

Seam-start corner-blade correction value

Entry: -99.9 … 99.9

Hint:

The value entered is valid for all pocket programs.
If the seam-end value is changed, the seam-start value is automatically

corrected.

Distance from the centre-blade incision to the seam ends (x)

(see the illustration at the foot of page 62)
Entry: - 99.9 … 99.9

Hint:

This value depends on the needle distance and the relevant corner blade.

Left-corner-blade seam-start zero-point correction
(automatic corner-blade station only)

Entry: -13 … 13

Hint:

The blade brackets 1 and 2 must be parallel.

4

Left corner blade seam-end zero-point correction
(automatic corner-blade station only)

Entry: - 13 … 13

Hint:

The blade brackets 3 and 4 must be parallel.

4

1

3

2

63

7.3.6 Testing needle and centre-blade activation

This program tests the activation of the needles and the centre blade
with the machine running.

Info line:

Activating needle, centre blade

–

Press OK to start the program.

–

Press function key F3:
once to start the sewing drive at 1000 rpm,
a second time to increase the sewing-drive speed to 3000 rpm
and a third time to stop in position 2 (thread lever up)

–

The centre blade is switched on and off with function key F4.

–

The needles are switched on and off with function key F5.

–

Press function key F1 to leave the test program.

CAUTION:

Before leaving the program the machine head must be run for a short
time with the needles and centre blade switched off
otherwise the next seam will not be properly executed.

64

7.3.7 Checking the tape feed

This program tests the feed and trimming function of the tape feed

Info line:

Checking tape feed

–

Press OK to run the test program.

–

Press function key F4.
The tape feed starts.
The tape is fed and the brake released.
The key is blocked.

–

Press function key F5.
The tape is automatically cut, advanced and clamped.

–

Press function key F1 to leave the test program.

4

65

7.3.8 Checking the gripper folder without feed clamp (versions B and F only)

This program tests the function of the gripper folder.
The feed clamps remain in their rear end position.

Info line:

Testing gripper folder

–

Press OK to run the test program.

–

Press function key F3.
The gripper folder swivels to the vertical position.

–

Press function key F5.
The gripper folder swivels to the vertical position and descends
onto the material slide plate.

–

For setting purposes, the gripper folder can be swayed to the
vertical position, pivoted and unpressurized above the piping
support table, through the key 9.

–

Press function key F1 to leave the test program.

66

7.3.9 Checking the insertion process with feed clamp

This program tests the insertion process.

–

Press OK to run the test program.
A reference run must be executed.
The following appears in the display:

Info line:

Testing insertion process

–

Push the left pedal down.
The feed carriage moves to the insertion station.
The insertion process is executed as in a sewing program.
After the last pedal stage has been completed an arrow appears in
the display.

–

Push down the right pedal in inching mode.
The feed carriage moves to its rear position.
The feed carriage waits in this position until the pedal is in its rest
position.
The feed clamps rise, the flap clamps open.

–

Push the left pedal down.
The program restarts.

–

To leave the test program press the RST key or switch the machine
off.

4

67

7.3.10. Checking and adjusting the piping knives

In the test program “Checking and adjusting the piping knives” you can
check the knife and step motor motion and adjust the reference
position of the piping knives.

–

Press key “F3“:
Make reference run.
The reference run has to be made before the further functions are
accessible.

–

Press key “F1“:
Quit the test program for piping knives.

7.3.10.1 Checking the piping knife motion

Caution: Danger of injury !

Danger of cuts !
Do not reach in the piping knife zone.

Exercise utmost caution when making tests with the machine running.

Check the knife motion

–

Press key “F2“:
Switch both piping knives on and off again.

–

Press key “F4“:
Switch the piping knife for the seam beginning on and off again.

–

Press key “F5“:
Switch the piping knife for the seam end on and off again

Check the step motor

–

Press key “F3“:
The reference run is carried out.

Select the symbol with the cursor keys “ï” and “ð”
Enter the path (max. 120 mm) via the numeric keyboard and confirm
with the OK-key.
The cutting unit moves to the entered position.

68

7.3.10.2 Setting the piping knife reference position

Code

–

Select the symbol with the cursor keys “ï” and “ð”

–

Start the program with the OK-key.
The display shows the input prompt for the code number.

Enter the code number “25483" via the numeric keyboard.
The screen menu for the piping knife reference position appears.

12

–

Loosen 4 screws and remove the lower cover at the piping cutter.

Select icon , enter the correction value “Piping knife
reference” via the numeric keyboard and confirm with the OK-key.
The cutting unit moves to the entered reference position.

Set the reference position in such a way that the distance between
roller guide 1 and plate 2 is 0.7 +/- 0.2 mm (measure with feeler
gauge).

–

Quit the menu (key F1), move the cutting unit by 120 mm (see
chapter 6.3.12.1 “Checking the step motor”) and check the
distance between the roller guide and the plate at the opposite.

–

Fasten the lower cover at the piping cutter again.

4

69

7.3.11 Step-by-step mode

In the step-by-step mode the sewing cycle is halted at important
positions so that individual processes can be checked.

–

Press OK to run the test program.
The main screen appears with a reminder to execute a reference
run.

Info line:

Reference run

–

Push the left pedal down.
The feed carriage moves to the insertion position.

–

The insertion process is completed as in the set program. After the
final stage of the insertion process the following screen appears.

–

Press the right pedal to call the next step. After the final step in
inching mode the program can be restarted with the left pedal.

–

To leave the test program press the RST key or
switch the machine off.

70

7.3.12 Determining the cycle time

This program determines the machine’s cycle time.

–

Press OK to run the test program.
The cycle time appears on the main screen.

7.3.13 Dongle-Menu

Info line: Cycle time

Reference run

–

Execute a reference run.

–

When the set sewing program has been completed the cycle time
appears in the display.

–

To leave the test program press the RST key or
switch the machine off.

The dongle is used to memorize sewing programs, sequences and
automat parameters and to transfer these data to other sewing
automats.

The transfer direction is selected with the keys ”F2” and “F4”.
The data transfer is started with the “F5”key.

4

The exact procedure is described in chapter 4 “Memory dongle”.

71

7.4 MULTITEST system ( + or main switch on + )

The MULTITEST system programs enable input and output elements to
be tested quickly.
No additional instruments are required.

–

Press and hold down key “F3”.

–

Press the “RST”key.
The controller is re-initialised and the MULTITEST system screen
loaded.

–

Select the required test program with cursor keys “ï”or“ð”.
A black background appears behind the symbol.

–

Press “OK” to run the selected test program.

72

7.4.1 Displaying the program version and checksum

This program tests the microcomputer’s read-only memory (ROM).

Program version

Where program versions are of the same class and have the same
code letter the higher version replaces all lower versions.

Checksum

The checksum is only intended for factory servicing.
It enables our specialists to establish whether the controller’s program
memory (EPROM) contains the whole program with no errors.

–

To leave the test program press function key F1.

Hint:

Verifying the checksum takes some considerable time.

4

73

7.4.2 Testing RAM (Random-Access Memory)

This program tests the microcomputer’s working memory (RAM).

–

Press OK to run the test program.
The test result appears in the display.

Display Explanation

RAM OK random-access memory is operating perfectly

RAM ERROR error in random-access memory

Hint:

If the message RAM ERROR occurs during the RAM test, the control
must be replaced.

74

7.4.3 Selecting input elements

This program adjusts the input elements.

CAUTION:

The input elements are factory-set with great care.
Adjustment and correction may only be undertaken by trained service
personnel.

–

Press OK to run the test program.

–

Use the key to select between the basic module and the CAN
node.

–

Enter the code number of the required input element on the
decimal keypad.
The code numbers are the abbreviations used in the circuit
diagram (see table below).

–

The display shows the circuit-diagram designation and the
switching status of the input element selected (e.g. “+S17").
The display changes if the switching status of the input element is
altered.

A switching status of ”-" means:

proximity switch = metal in front of the switch
reflecting light barrier = reflection

–

Move the input element until the display shows the required
switching status.

–

To leave the test program press function key F1.

4

75

Input Function Insertion method
element ABDF

S01 Needle-thread monitor left XXXX
S02 Needle-thread monitor right XXXX
S05 Folderdown XXXX
S06 Foldingstationswungin XXXX
S07 Simple piping right X X X
S08 Simple piping left X X X
S09 Blade-bracket monitoring XXXX
S10 Removematerial/ XXXX

cover monitoring
S11 Pressuremonitor XXXX
S12 Right pedal forward XXXX
S14 Left pedal forward XXXX
S15 Left pedal back XXXX
S16 Right pedal back XXXX
S17 Flap scanning 1 XXXX
S20 Flap scanning 2 X X X
S21 Tapecontrol XXXX
S24 Piping knife adjustment reference X X
S111 Residual-thread monitor right XXXX
S101 Feed-device reference XXXX
S102 Seam-startcorner-bladereference XXXX
S110 Residual-thread monitor left XXXX
S100 Sewingmotorreference XXXX

*) Input elements can only be tested by means of the test program 6.3.1 “Adjusting the

looper-thread monitor”

Input elements CAN node 0

Input Function Insertion method
element ABDF

SC001 Seam-start blade-adjustment reference XXXX
SC002 Seam-end blade-adjustment reference XXXX

Input elements CAN node 1

Input Function Insertion method
element ABDF

SC001 Folder on top X X

SC002 Folder on piping table X X
SC003 Folder vertical X X
SC004 Folder inclined X X

76

7.4.4 Checking input elements

This program tests automatically the input elements.

–

Press OK to run the test program.

–

Select the input element to be tested.

–

The display shows the circuit diagram designation and the
switching status of the input element selected (e.g. “+s17”).
The display changes if the switching status is altered or another
input element is changed. A change in the switching status is
indicated by an audible signal.

–

To leave the test program press the function key F1.

4

77

7.4.5 Selecting output elements

This program checks the function of the output elements.

One (single mode) or several (multi-mode) output elements can be

tested simultaneously.

Caution: danger of injury !

Do not reach into the machine while it is running and the function

of the output elements is under test.

–

Press Enter to run the test program.

–

Use the decimal keypad to select between single mode and
multi-mode .

1 = single mode: only one output element

is tested.

2 = multi-mode: a group of output elements

is tested.

–

Press the “F5” key to switch from DACIII control to the output
elements of the CAN node.

DACIII

CAN 1

DACIII = maximum of 16 outputs from YC001 to YC016

CAN 1 = maximum of 56 outputs from YC101 to YC156

78

–

Enter the code number of the required output element with “F3”
(forwards) or “F2” (backwards).
The code numbers are the abbreviations used in the circuit
diagram (see tables below).

–

The display shows the switching status (ON/OFF) of the output
element selected.

–

Switch the selected output element on (ON) and off (OFF)by
pressing function key “F4”.

–

To leave the test program press function key F1.

Output elements head unit (DACIII)

Output Function Insertion method
element ABDF

Y1 Upper thread cutter on/ XXXX

Close thread clamp
Y2 Centrebladeon XXXX
Y3 Blowawayfluff/advancethread XXXX
Y4 Openthreadclamp XXXX
Y5 Lowerthreadcutteron XXXX
Y6 Threadtensionon XXXX
Y7 Needle left on XXXX
Y8 Needle right on XXXX

Output elements transport unit (DACIII)

Output Function Insertion method
element ABDF

Y9 Folderlowered XXXX
Y10 Folderliftoff XXXX
Y11 Empty
Y12 Empty
Y13 Knifebracketseam-startleft XXXX
Y14 Knifebracketseam-startright XXXX
Y15 Knifebracketseam-endleft XXXX
Y16 Knifebracketseam-endright XXXX

4

Output elements method module system (CAN-node1)

Output Function Insertion method
element ABDF

YC101 Openleftflapclamp XXXX
YC102 Openrightflapclamp XXXX
YC103 Closefoldingplate XXXX
YC104 Lowerleftfeedclamp XXXX
YC105 Lowerrightfeedclamp XXXX
YC106 Turnleftfeedclampinside XXXX
YC107 Turnrightfeedclampinside XXXX
YC108 Blowon(flapclamp) XXXX
YC109 Blowon(foldingplate) XXXX
YC110 Vacuumon XXXX
YC111 Stackeron XXXX
YC112 Lowersmoother XXXX
YC113 R(onlycableharness) XXXX
YC114 R(onlycableharness) XXXX

79

Output Function Insertion method
element ABDF

YC119 Closetapecutter XXXX
YC120 Pulltapetothefront XXXX
YC121 Loosen tape XXXX
YC122 Zip-fastener scissors forward X

Piping knife forward X X

YC123 Open zip-fastener scissors X

Piping knife forward X X
Swivel positioning device X

YC124 Lift stop motion device X X

Swivel positioning device X

YC125 Drive out waistband-clamp needles X X

Lift pocket bag X
Swivel flap-turning device X

YC126 Open waistband-clamp X X

Feed pocket bag X
Lower flap-turning device X

YC127 Close waistband-clamp X X

Clamp breast welt X
Close flap-turning clamp X

YC128 Close fabric holder X X

Lateral shift on X
YC129 Spread needles X X X
YC130 Lift folder X X X
YC131 Swivel folder X X
YC132 Blow tube X X
YC133 Swivel in flap feed X X
YC134 Open left flap feed X X
YC135 Open right flap feed X X
YC136 Close left flap feed X X
YC137 Close right flap feed X X
YC138 Lift flap feed X X
YC139 R (only cable harness) X

Lift right flap feed X
YC140 R (only cable harness) X

Output elements laser lamp

Output Function Insertion method
element ABDF

YC141
to Laserlamp XXXX
YC142

80

7.4.6 CAN test

Press OK to run the test program.

Hint:

CAN modules work with no errors.
Displaying the OK message takes some considerable time.

4

81

7.4.7 Checking the sewing drive

This program tests the needle position and the various speed stages of

thesewingdrive.

–

Press OK to run the test program.

–

Select the required parameter with cursor keys “ï”or“ð”.
A black background appears behind the symbol.

–

Set the parameter with cursor keys “ñ”or“ò”.

Show sew ing-drive program version.

Select needle position

Needle in down position

Needle in up position

82

Needle in any position

Set sew ing-drive speed

minimum = 70 rpm
maximum = 3000 rpm

Checking the sewing drive

key F2 = start
key F3 = stop

7.4.8 Error list

–

To leave the test program press function key F1.

The program shows the 10 last error messages.

–

Press OK to run the test program.

–

To leave the test program press function key F1.

4

83

7.5 Terminal self-test ( + or turn on main switch + )

Service personnel use the terminal self-test to check the individual

components of the operating terminal.

–

RAM test

The RAM test checks the operating terminal’s working memory
(“video RAM”).
On completion of the RAM test the self-test automatically switches
to the EPROM test.

–

EPROM test

The EPROM test checks the controller’s program memory.

–

RAM-card test

RAM-cards are no longer used with the present machine.

–

Keyboard test

The keyboard test checks the operating terminal’s keyboard.
Press any key, and if it is working properly a tick appears beside it
in the display.
Pressing the “ESC” key terminates the keyboard test.
The display switches to the interface test.

–

Interface test

The interface test checks the operating terminal’s interface (a
special cable is required!)
On completion of this test the self-test automatically switches to
the display test.

–

Display test

The display test shows the available character set and graphics.
Pressing function key F2 switches the display to the main screen of
the terminal self-test (see illustration above).

–

Main screen

When the main screen is displayed pressing function key F2
generates a full test report.
To leave the terminal self-test press the “RST”key.

84

7.6 Display contrast value ( + or turn on main switch + )

This program sets the contrast value of the display.

–

Set the contrast value with cursor keys “ñ”or“ò”.

–

Press the “ESC” key to store the value and leave the program.

4

85

7.7 Editing menus ( + or turn on main switch + )

This determines which parameters can be directly edited on the main

screen with keys 0 to 9.

–

Pressing function key F5 switches to the next screen with other
parameters.

86

–

Select the required parameter with cursor keys
“ï”, “ð”, “ñ”or“ò”.
A black background appears behind the symbol.

–

Select the required position by pressing keys 0 to 9.

–

Select the next parameter.

–

To leave the menus press function key F1.

Hint:

Do not define a symbol twice with the numeric keys.

7.8 Adjusting the serial interface ( + )

This test program sets the correct transfer speed (baud rate) for the
serial interface.

The correct baud rate for the serial interface is:
Com 0 = n, 8, WA, 1 - 125 K Baud

CAUTION:

If the machine is switched on with one of the following keys pressed,
baud rates incompatible with the operating panel of the controller will
be set:
key “0"
key ”1"
key “2"
key ”3"
key “4"
key ”5"
key “6"
key ”7"
key “8"
key ”9".

4

87

8. Error messages

In the event of an error in the control system or the machine program

the error number appears in the display.

The following tables will enable the cause of the error to be identified

and remedied.

8.1 Sewing motor controller error messages

Error number Meaning Remedy

Error 1051 Sewing motor timeout

Error 1052 Sewing motor excess current

Error 1053 Too high mains voltage

Error 1055 Sewing motor overload

Error 1056 Sewing motor overheat

Error 1058 - Sewing motor speed

Error 1062 - Failure sewing motor IDMA

Error 1302

Error 1342

­Error 1344

- Faulty cable to the sewing motor
reference switch

- Faulty reference switch

- Faulty sewing motor cable

- Faulty sewing motor

- Faulty control

- Sewing motor blocked / seized up

- Faulty sewing motor

- Control faulty

- Sewing motor seized up

- Faulty sewing motor

- Faulty control

- Faulty sewing motor

Autoincrement
Sewing motor error

- Control receives no impulse from

the impulse transmitter in the motor

Sewing motor error

Internal error

- Replace the cable

- Replace the reference switch

- Replace the sewing motor cable

- Replace the sewing motor

- Replace the control
Check the mains voltage

- Eliminate the blocking / seizing

- Replace the sewing motor

- Replace the control

- Eliminate seizing

- Replace sewing motor

Replace control

- Replace sewing motor

- Switch the machine off/on again

- Check the cable from the impulse
transmitter in the motor to the control

- Switch the machine off/on again

- Software update

- Inform the DA-Service

88

8.2 Stepping motors error messages

Error number Meaning Remedy

Error 2101 Step motor X-axis timeout reference

- Faulty cable to the reference switch

- Faulty reference switch

Error 2103 Step motor feed clamp has step loss

Error 2152 Step motor X-axis excess current

Error 2153 Step motor X-axis excess voltage

- Too high mains voltage

Error 2156 Step motor X-axis overheat

- Step motor X-axis seized up

- Faulty step motor X-axis

- Faulty control

Error 2162 - Failure step motor X-axis IDMA

Autoincrement IDMA

Error 2201 Step motor X-axis timeout reference

- Faulty cable to the reference switch

- Faulty reference switch

Error 2252 Step motor Y-axis excess current

Error 2253 Step motor Y-axis excess voltage

- Too high mains voltage

Error 2256 Step motor Y-axis overheat

- Step motor Y-axis seized up

- Faulty step motor Y-axis

- Faulty control

Error 2262 - Failure step motor Y-axis IDMA

Autoincrement IDMA

Error 2301 Step motor Z-axis timeout reference

- Faulty cable to the reference switch

- Faulty reference switch

Error 2352 Step motor Z-axis excess current

Error 2353 Step motor Z-axis excess voltage

- Too high mains voltage

Error 2356 Step motor Z-axis overheat

- Step motor Z-axis seized up

- Faulty step motor Z-axis

- Faulty control

Error 2362 - Failure step motor Z-axis IDMA

Autoincrement IDMA

- Replace cable

- Replace reference switch

- Check seizing of the feed clamp

- Replace step motor X-axis

- Replace control

Check the mains voltage

- Eliminate seizing

- Replace step motor X-axis

- Replace control

- Switch the machine off/on again

- Replace cable

- Replace reference switch

- Replace step motor Y-axis

- Replace control

Check the mains voltage

- Eliminate seizing

- Replace step motor Y-axis

- Replace control

- Switch the machine off/on again

- Replace cable

- Replace reference switch

- Replace step motor Z-axis

- Replace control

Check the mains voltage

- Eliminate seizing

- Replace step motor Z-axis

- Replace control

- Switch the machine off/on again

4

8.3 Operating indicator error messages

Error number Meaning Remedy

Error 3100 Machine Control Voltage

- Temporary mains voltage drop

Error 3101 Machine Power Voltage

- Temporary mains voltage drop

Error 3102 Machine Voltage Sewing Motor

- Temporary mains voltage drop

Error 3103 Machine Voltage Step Motors

- Temporary mains voltage drop

Error 3107 Machine Temperature

- Vent holes closed
Ventilation grid soiled

- Check the mains voltage

- Check the mains voltage

- Check the mains voltage

- Check the mains voltage

- Check the vent holes

- Clean the ventilation grid

89

Error number Meaning Remedy

Error 3500

­3507
3520

­3530
3540
3545
3721
3722

Info 4301 Dongle missing

Info 4304 Wrong dongle type

Error 6551

­6554
6651

­6653
6751

­6761

Error 6952 Error step motor driver

Error 7260 General failure in the CAN - Modules

Error Command Interpreter /
Motor synchronization
Internal error

Error machine head position /
AD-Converter / Processor error
Internal error

Internal error

- Switch the machine off/on again

- Software update

- Inform the DA-Service

- Switch the machine off/on again

- Software update

- Inform the DA-Service

- Switch the machine off/on again

- Software update

- Inform the DA-Service
Check cable

Error 7551

­7555
7558
7559

Error 7556

7557

Error 8151

8156

­8159

Error 8152

­8154

Error 8151

8155

Error 8252

8257
8258
/
8253
8256
8254

Error 8351

8801

­8805
8806
8890
8891

Communication Control Panel
interface

- Internal error

Communication Control Panel
interface

- Interference

- Faulty control panel interface cable
IDMA error

- Failure

- Faulty control

IDMA error

- Internal error

Error booting ADSP / Booting Xilinx /
Booting

Booting ADSP / Booting Xilinx /
Booting
Failure

Error Testpins / Signals / Event
processing / Memory Wrapper / List
of functions
Internal error

- Switch the machine off/on again

- Software update

- Inform the DA-Service

- Switch off the source of interference

- Replace the cable

- Switch the machine off/on again

- Replace the control

- Switch the machine off/on again

- Software update

- Inform the DA-Service

- Switch the machine off/on again

- Software update

- Inform the DA-Service

- Switch the machine off/on again

- Switch the machine off/on again

- Software update

- Inform the DA-Service

90

Error number Meaning Remedy

Info 9000 Reminder to execute the reference

run after switching on

Info 9001 Corner-blade station is swivelled out

Error 9001 Corner-blade station swivelled out

during sewing.

Push the left pedal backwards: the
feed carriages moves backwards and
a reference run is executed.

Info 9002 Folder station is swivelled out

Error 9002 Folder station swivelled out during

sewing.

Push the left pedal backwards: the
feed carriage moves backwards and
a reference run is executed.

Info 9013 Tape missing

Info 9014 The adjusted position for the feed

clamp does not fit the built-in stamp.

Push left pedal backwards

Swivel corner-blade station in

Check/adjust the fastening of the
corner-blade station.

Swivel folder station in

Check/adjust the fastening of the folder
station.

Insert tape

Adjust the position of the feed clamp to
match the one displayed in the pocket
parameters.

Info 9015 Incorrect setting of the flap scanning

in the pocket program

Error 9600 Insufficient or missing air pressure Turn up and stabilize the pressure of the

Error 9601 Left pedal pushed backwards during

sewing

Error 9602 Empty bobbin

Error 9603 Thread breakage

Error 9604 Light barrier (s10) for material

removal not active

Error 9700 Folder not up Correct the folder setting (mechanical

Error 9701 Folder not down

Error 9710 Limit switch for feed clamp active

Correct the pocket program

compressed air
To clear this error, operate the pedal

again; the feed clamp then moves to its
rear position

Insert full bobbin

Re-thread the machine again

Adjust the light barrier (s10) for material
removal

impact; check switch S17)

Correct the folder setting (mechanical
impact; check switch S17)

Check material feed and limit switch S101

4

Error 9711 Limit switch for corner blade block

active

Check corner blade drive and limit switch
S102

91

Error number Meaning Remedy

Info 9720 Error at the light barrier for flap

scanning

Info 9721 Flap has been positioned in front of

the front positioning point

Info 9722 Flap protrudes from the maximum

sewing area (behind the rear
positioning point)

Info 9723 Fluff at the flap beginning

Info 9725 Flap angle is too great

Info 9726 Flap too large or reflecting foil dirty or

faulty

Info 9727 Stop section insufficient for the flap

angle

Error 9800 Center blade not ready for use Check cable

Error 9810 Smoother not ready for use

Error 9900 Defective Machine Parameters

(Checksum error)

Error 9901 Defective Pocket Sequences

(Checksum error)

Check the reflecting foil; check the
alignment of the light barriers

Position the flap correctly

Check the flap size; Position the flap
correctly

Feed flaps with smooth edges; Check the
reflecting foil

Check flap angle; check light barrier
alignment

Check the flap size and reflecting foil

Reduce the slide-in speed

Check cable

Re-initialize machine parameters (test
program); set machine parameters or read
them from the dongle

Re-initialize pocket sequences (test
program); set pocket sequences or read
them from the dongle

Error 9902 Defective Pocket Programs

(Checksum error)

Re-initialize the defective pocket programs
(test program); set pocket programs or
read them from the dongle

92
