ADATA PD17 User Manual
Hi-Speed USB 2.0 Flash Disk
User’s Manual
Contents
Introduction................................................................................................................... 3
Features ................................................................................................................................... 3
System Requirements............................................................................................................ 4
Before Use............................................................................................................................... 4
Driver Installation.......................................................................................................... 5
Driver Installation for Windows 98/98SE............................................................................. 5
Disk Partitions and Security Function ........................................................................ 8
Format.exe
Format.exe Interface ............................................................................................... 8
Partition Function ........................................................................................................... 8
Security Function............................................................................................................ 9
Configuration Function ................................................................................................ 11
Lock.exe
Lock.exe Interface .................................................................................................... 12
Disclaimer.................................................................................................................... 15
- 2 -
Introduction
Thank you for your purchasing this Hi-speed USB 2.0 Flash Disk. This portable Plug&Play
USB Flash Disk enables you to exchange huge amount of data easily between any
computers with a USB port. With high storage capacity and blazing fast speeds, this handy
small device is the best choice to replace floppy disks, ZIP disks and hard disks. In addition,
this Hi-speed USB Flash Disk provides utility programs that you can partition the disk with
great flexibility and set Security Area with password check to secure your personal data.
With this gadget from the latest storage trend, you will enjoy its convenience in your daily
life.
Features
z Portable and secure removable mass storage for business and personal use
z Full Compliance with USB spec v2.0 and v1.1; true Plug&Play connection
z Date transfer rate up to 19MB/s for Read, 14MB/s for Write in Dual-channel mode*
z Date transfer rate up to 10MB/s for Read, 7MB/s for Write in Single-channel mode*
z USB bus powered: Powered from USB port, no external power or battery needed
z Multiple Operation Systems supported: No driver needed in Windows
Windows
Windows
z Disk partitions and Security Area with password check
z Shock resistant, noise-free and long data retention
®
2000, Windows® XP, Mac TM 9.x or later, Linux TM Kernel 2.4 or later. Only
®
98 and Windows® 98SE need the enclosed driver
®
ME,
Note: The read/write speed of the USB Flash Disk depends on the Flash memory type
inside the device and also on the computer’s system performance.
- 3 -
System Requirements
z Desktop or laptop computers with USB 1.1 or USB 2.0 port
z One of following operation systems
Windows 98/98SE
Windows ME
Windows 2000
Windows XP
Mac OS 9.x or later
Linux Kernel 2.4 or later
Before Use
1. Please keep this Hi-speed USB 2.0 Flash Disk away from heat, direct sunlight, and
water. Do not bend, flex, or drop it.
2. To prevent data loss and fatal damage to the USB 2.0 Flash Disk, please never
remove it from the USB port while data is being transferred. It is advised that user
perform “Safety Remove Hardware” by selecting “USB Mass Storage Device”
before removing the Flash Disk.
3. Due to OS security control, in Windows 2000 or Windows XP you must be logged in
with local Administrator rights to run the Disk Partitions and Security Function.
( The programs named
Administrator rights, please contact your system administrator for assistance.
4. If you re-start the computer and your USB 2.0 Flash Disk is in Unlocked mode (Have
the right to access Security Area), please unplug the USB 2.0 Flash Drive to make
sure it back to Public Area.
Format.exe
and
Lock.exe
) If your account does not have the
- 4 -
Driver Installation
To use this Hi-speed USB 2.0 Flash Disk, it is not necessary to install any driver in
Windows
later. Only Windows
Driver Installation for Windows 98/98SE
1. Please execute setup.exe to install USB Flash Disk Windows 98/98SE driver. The
®
ME, Windows® 2000, Windows® XP, Mac TM 9.x or later, Linux TM Kernel 2.4 or
®
98 and Windows® 98SE need to install the enclosed driver.
icon is shown as:
Setup.exe
2. The Setup Wizard will show up as below, please click N
ext > to continue.
- 5 -
