THE KEY INGREDIENT IN INDUSTRIAL BAKING SINCE 1962
INDUSTRIAL ROLL LINES
– with
Capacity from 3,600 to 30,000 pcs/hour • Scaling range from 1 to 19 oz. • Larger when combined with Glimek equipment
NDR
and
VDR
Dividers
Adamatic Roll Lines, the industry standard for roll production,
have earned a reputation for being trouble-free, easy to run, and
flexible enough to accomodate multiple products with simple
changeovers.
Adamatic Roll Lines are PLC controlled and can operate with
Adamatic NDR or VDR divider rounders with 2 to 10 pockets, at
speeds up to 30,000 pieces/hour. Roll Lines can accomodate round
rolls, moulded rolls, hot dog and hamburger buns, large sub rolls and
small baguettes up to 19 oz.
Adamatic industrial bakery equipment is manufactured in the USA
with parts, customer service, parts and technical support all available
within North America and just a phone call away.
WWW.ADAMATIC.COM • INFO@ADAMATIC.COM • 206.322.5474 / 800.578.2547 TOLL FREE
PART OF BELSHAW ADAMATIC BAKERY GROUP • 814 44TH STREET NW, SUITE 103, AUBURN, WA 98001 USA
Industrial Roll Lines
2 – 10 pockets • 3,600 – 30,000 pieces/hour • Scaling range 1–19 oz. • Larger when combined with Glimek equipment
Divider Rounder
• Adamatic VDR or NDR Divider Rounder
(see following page for dividing ranges
and other specs)
• 2 to 10 pocket dividing
• Capacity up to 30,000 pcs/hr
• Hydraulic systemw
Turret Head Roll Stamper
• Stamps five types of roll - Kaiser, split,
cross, clover, Portuguese leaf roll
• Individually adjustable discharge belts
• Mounted on base
• Seam control available
Intermediate Proofer
• Capacity up to 600 trays
• Synchronized central drive with magnetic
clutch coupling
• Equipped with direct drive from Divider
Rounder and timing gate to assure perfect
synchronization and flawless depositing of
dough balls into the proofer pockets
• Sliding inspection windows
• High impact plastic trays with nylon mesh
inserts
Bypass Conveyor
• Bypasses intermediate proofer for round
roll seam control
Molding Conveyor Table
• Variable speed
• 32”, 36”, 55” and 62” widths
• Removable and interchangeable pressure
plate assembly w/ single point adjustment
• Adjustable pressure plates, front and back
• Automatic aligning device for accurate
panning
• Automatic belt tracking system
Wetting and Seeder
(optional)
• Automatic seeder for wetting and topseeding rolls
• Wetting package with water tank
Panner & Straightening Out
Sheeter
• Mounted on variable speed moulding table
• Pre-flattening roller with with timing gate
• Two sets of adjustable sheeting rollers
• High speed coiling and discharge belts
• For rolls and small breads from
4” to 12” long
• Custom infeed boxes to align centers with
pressure plates
WWW.ADAMATIC.COM • INFO@ADAMATIC.COM • 206.322.5474 / 800.578.2547 TOLL FREE
PART OF BELSHAW ADAMATIC BAKERY GROUP • 814 44TH STREET NW, SUITE 103, AUBURN, WA 98001 USA
Device
• Automatic operation
• Automatically deposits any pattern on
peel boards, pans or conveyor belt
• Variable speed
• Fully adjustable panning stroke
• Reverse curl extender
• Straightening out device straightens
seam on moulded product
• Stainless steel mesh conveyor
• Catch tray for the collection of excess
seeds
• Driven by molding table
Control System
• PLC touch screen or Analog control
panel
• Fully interwired at factory
• Servo weight controls available
• UL listed
NDR
and
VDR
Dividers
3,600 to 30,000 pieces/hour
2–10 Pockets
Scaling range from 1 to 19 oz *
NDR Divider
Specifications in brief
• Up to 50 strokes per minute
• 30,000 pieces per hour (NDR), 18,000 pieces per hour (VDR)
• Extremely accurate scaling and rounding
• Minimal dough punishment
• Simple weight adjustments
• No divider oil required
• Adjustable height flattening roller on discharge belt
• Variable frequency drive control
• Durable design and construction
• Optional dough chunker, variable frequency rounding control &
more
Dividing Range (NDR Divider, 2 sizes)
Model Size > NDR 6/8 NDR 8/10
4 Pocket 5 - 10 oz 5 - 10 oz
6 Pocket 1 - 7 oz 3 - 9 oz
8 Pocket 1 - 3 oz 1 - 7 oz
10 Pocket N/a 1 - 3 oz
Dividing Range (VDR divider)
2 Pocket (bread) 10 - 19 oz
4 Pocket (bread & rolls) 1.5 - 10 oz
6 Pocket (rolls) 1.25 - 4.5 oz
Scaling and production
weights may vary with
dough consistency.
VDR Divider
PART OF BELSHAW ADAMATIC BAKERY GROUP • 814 44TH STREET NW, SUITE 103, AUBURN, WA 98001 USA
*For larger bread sizes, be sure to ask your Adamatic rep about GLIMEK dividers.
