ADA instruments TemPro 300 User Manual

Operating manual

Infrared Thermometer

Model:TemPro 300

Manufacturer

Address: WWW. ADAINSTRUMENTS.COM

TemPro 300

Table of contents

1. Review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

2. Measurement considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

3. Complete set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

4. Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

4.1. Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

4.2. Speciﬁcations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

5. Safety requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

6. Description of the instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

6.1. Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

7. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

8. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

9. Speciﬁc reasons of instrument malfunctions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

10 . Storage and transportation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

11. Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

12. Exceptions from responsibility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

13. “Certiﬁcate of acceptance and sale”

14. “Warranty card” Appendix 1- “Emessivity table (ЕТ)”Emessivity table (ЕТ)”

TemPro 300

1. Review

TemPro 300 is IR Thermometer for non-contact temperature measurements at the touch of button. The built-in laser pointer increases target accuracy while the backlight LCD and handy push-buttons combine for convenient, ergonomic operation. TemPro 300 can be used to measure the temperature of objects’ surface that is improper to be measured by traditional (contact) thermometer (such as moving object, the surface with electricity current or the objects which are uneasy to be touched).

2. Measurement considerations

Holding the meter by its handle, point the IR Sensor toward the object whose temperature is to be measured. The meter automatically compensates for temperature deviations from ambient temperature. Infrared thermometers measure the surface temperature of an object. The unit’s optics sense emitted, reﬂected, and transmitted energy, which is collected and focused onto detector. The unit’s electronics translate the information into a temperature reading, which is displayed on the unit. The laser is used for aiming purposes only.

Reflected energy

Transmitted energy

Absorbed energy

Object

Pic.1

MEASUREMENT FOUNDATION

3. Complete set

Thermometer TemPro 300 Battery 9V Plastic blister Operating manual

4. Technical data

4.1. Functions

Rapid detection function

• Precise non-contact measurements

• Built-in laser sighting

•

Unique ﬂat surface, modern housing design

• Automatic Data Hold

• Backlight LCD display

• Low battery indicator

•

TemPro 300

MEASUREMENT FOUNDATION

4.2. Speciﬁcations

IR temperature range -32°С to +350°С

Optical resolution, D:S 12:1

Resolution 0.1°С

Accuracy ±1,5°С at 0<t≤350°С

±3°С at t≤0°С

Response time 0.5 sec.

Spectral response, um 8 ~ 14

Emissivity 0.95

Backlight yes

Data hold yes

TemPro 300

MEASUREMENT FOUNDATION

TemPro 300

Working temperature/relative humidity

Power supply 9V (krona)

Dimensions, mm 175x100x49

Weight, gr 130

0..40°С / 10-95% at 30°С

MEASUREMENT FOUNDATION

TemPro 300

5. Safety requirements

Inaccurate readings will result from measuring shiny or polished metal surfaces (stainless steel, aluminium, etc.). To compensate, cover the measuring surface with masking tape or ﬂat black paint. Allow time for the tape to reach the same temperature as the material under it. Measure the temperature of the tape or painted surface. The unit cannot measure through transparent surfaces such as glass. It will measure the surface temperature of the glass instead. Steam, dust, smoke, etc., can prevent accurate measurement by obstructing the unit’s optics. Make sure that the target is larger than the unit’s spot size. The smaller the target, the closer you should be to it. When accuracy is critical, make sure the target is at least twice as large as the spot size.

MEASUREMENT FOUNDATION

TemPro 300

6. DESCRIPTION OF THE INSTRUMENT

6.1. Features (Pic.2)

Laser pointer

1. IR sensor

2. LCD display

3. MEASUREMENT trigger

4. Battery compartment

5. °C/°F button

6. Laser pointer On/Off button

7. Backlight On/Off button

6.2. LCD display (Pic.3)

A - Data hold icon (HOLD) B - Scanning icon (SCAN) C - Laser “ON” icon D - Backlight ON icon E - Low power symbol F - °C/°F symbol G - Current temperature value

Pic.2

Pic.3

MEASUREMENT FOUNDATION

TemPro 300

7. Operation

Preparation before operation

Read the operating manual before use the instrument. Take the instrument out of case. Open battery cover and put 9V battery.

Thermometer On/Off

Pull and hold the trigger (4) to turn the meter on and begin testing. The display will light if the battery is good. Replace the battery if the display does not light. The meter will automatically power down after approximately 20 seconds after the trigger is released.

°C/°F

To choose the measuring unit press button (6).

EMS adjustment

The emissivity (EMS) - 0.95. To obtain more accurate values see appendix 1.

Laser pointer

Laser pointer is on when you turn on the unit. To turn off the laser pointer, press button (7) LASER.

MEASUREMENT FOUNDATION

TemPro 300

Backlight

Backlight is on when you turn on the unit. To turn off the backlight, press button (8) BACKLIT.

Measurement operation

Hold the meter by its handle grip and point it towards the surface to be measured. Pull and hold the trigger (4) to turn the meter on and begin testing. Release the trigger (4) and HOLD display icon will appear on display indicating that the reading is being held.

Distance to spot size

When take measurement, pay attention to the Distance to Spot Size. As the Distance (D) from the target surface increases, the spot size (S) of the area measured by the unit becomes larger. The Distance to Spot size of the unit is 12:1. This unit is equipped with a laser, which is used for aiming.

MEASUREMENT FOUNDATION

TemPro 300

38mm 300mm

75mm 900mm

132mm 1500mm

Pic.4

MEASUREMENT FOUNDATION

TemPro 300

8. Maintenance

The maintenance of the thermometer includes the replacement of power supply, cleaning the unit with dry cloth and also debugging. Periodically, one time per year it is necessary to check settings in authorized service center.

9. Speciﬁc reasons of instrument malfunctions

Malfunction Possible reason of malfunction Way of debugging

After pressing and holding the button MEASUREMENT (5) the instrument doesn’t turn on.

Contact with authorized service center if you have another malfunctions.

1.Fully discharged battery

2.Bad contact of battery and jack of the thermometer

3. Broken jack wire in battery compartment

Change battery

Recover contacts

Recover power lead

MEASUREMENT FOUNDATION

TemPro 300

10. Storage and transportation

Storage and transportation of the instrument should be only in case. Take out the battery if you are not going to use the instrument for a log time. Don’t expose the instrument to mechanical effects (heating, hits, strong vibrations, humidity, dust ...). Store the instrument in normal conditions (temperature/humidity).

MEASUREMENT FOUNDATION

TemPro 300

WARRANTY

This product is warranted by the manufacturer to the original purchaser to be free from defects in material and workmanship under normal use for a period of two (2) years from the date of purchase. During the warranty period, and upon proof of purchase, the product will be repaired or replaced (with the same or similar model at manufactures option), without charge for either parts of labour. In case of a defect please contact the dealer where you originally purchased this product. The warranty will not apply to this product if it has been misused, abused or altered. Withiut limiting the foregoing, leakage of the battery, bending or dropping the unit are presumed to be defects resulting from misuse or abuse.

EXCEPTIONS FROM RESPONSIBILITY

The user of this product is expected to follow the instructions given in operators’ manual. Although all instruments left our warehouse in perfect condition and adjustment the user is expected to carry out periodic checks of the product’s accuracy and general performance. The manufacturer, or its representatives, assumes no responsibility of results of a faulty or intentional usage or misuse

including any direct, indirect, consequential damage, and loss of proﬁts. The manufacturer, or its representatives, assumes no responsibility for consequential damage, and loss of proﬁts by any disaster (earthquake, storm, ﬂood ...), ﬁre, accident, or an act of a third party and/or a usage in other than usual

conditions. The manufacturer, or its representatives, assumes no responsibility for any damage, and loss of proﬁts due to a change of data, loss of data and interruption of business etc., caused by using the product or an unusable product. The manufacturer, or its representatives, assumes no responsibility for any damage, and loss of proﬁts caused by usage other thsn explained in the users’ manual. The manufacturer, or its representatives, assumes no responsibility for damage caused by wrong movement or action due to connecting with other products.

MEASUREMENT FOUNDATION

WARRANTY CARD

Name and model of the product ________________________________________________

Serial number ________________date of sale_______________________

Name of commercial organization _____________________stamp of commercial organization

Warranty period for the instrument explotation is 24 months after the date of original retail purchase. It extends to the equipment, imported on the RF territory by ofﬁcial importer.

During this warranty period the owner of the product has the right for free repair of his instrument in case of manufacturing defects.

Warranty is valid only with original warranty card, fully and clear ﬁlled (stamp or mark of thr seller is obligatory).

Technical examination of instruments for fault identiﬁcation which is under the warranty, is made only in the authorized service center.

In no event shall manufacturer be liable before the client for direct or consewuential damages, loss of proﬁt or any other damage which

occur in the result of the instrument outage.

The product is received in the state of operability, without any visible damages, in full completeness. It is tested in my presence. I have no complaints to the product quality. I am familiar with the conditions of qarranty service and i agree.

purchaser signature _______________________________

If you have any questions about the warranty service and technical support contact seller of this product

Before operating you should read service instruction!
