FX-i SERIES

FX-120i / FX-200i / FX-300i

X-1200i / FX-2000i / FX-3000i

Precision Balance

INSTRUCTION MANUAL

WM+PD4001199

No part of this publication may be reproduced, transmitted, transcribed, or translated

into any language in any form by any means without the written permission of A&D

Company Ltd.

The contents of this manual and the specifications of the instrument covered by this

manual are subject to change for improvement without notice.

Windows, Word and Excel are the registered trademarks of the Microsoft Corporation.

CONTENTS

Basic Operation

1. INTRODUCTION .............................................................................................................................3

1-1 About This Manual.............................................................................................................................. 3

1-2 Features ............................................................................................................................................. 3

1-3 Compliance......................................................................................................................................... 3

2. UNPACKING THE BALANCE ........................................................................................................4

2-1 Unpacking........................................................................................................................................... 4

2-2 Installing the Balance ......................................................................................................................... 5

3. PRECAUTIONS ..............................................................................................................................6

3-1 Before Use.......................................................................................................................................... 6

3-2 During Use.......................................................................................................................................... 6

3-3 After Use .................................................................................................................. ........................... 7

3-4 Power Supply ..................................................................................................................................... 7

3-5 Display Symbols and Key Operation.......................................................................................... ........ 8

4. WEIGHING UNITS ..........................................................................................................................9

4-1 Units.................................................................................................................................................... 9

4-2 Storing Units ......................................................................................................................................11

5. WEIGHING ....................................................................................................................................12

5-1 Basic Operation (Gram Mode) ......................................................................................................... 12

5-2 Counting Mode (PCS) ...................................................................................................................... 13

5-3 Percent Mode (%)............................................................................................................................. 15

5-4 Statistical Calculation Mode ............................................................................................................. 16

5-5 Statistical Calculation Mode (Example of Use) ................................................................................ 20

Adapting to the Environment

6. RESPONSE ADJUSTMENT .........................................................................................................22

7. CALIBRATION ..............................................................................................................................23

7-1 Calibration Mode .............................................................................................................................. 23

7-2 Calibration Using an External Weight............................................................................................... 24

7-3 Calibration Test Using an External Weight....................................................................................... 26

8. FUNCTION SWITCH AND INITIALIZATION.................................................................................28

8-1 Permit or Inhibit ................................................................................................................................ 28

8-2 Initializing the Balance...................................................................................................................... 29

Functions

9. FUNCTION TABLE .......................................................................................................................30

9-1 Structure and Sequence of the Function Table ................................................................................30

9-2 Display and Keys.............................................................................................................................. 30

9-3 Details of the Function Table ............................................................................................................ 31

9-4 Description of the Class “Environment, Display”.............................................................................. 34

9-5 Description of the Item “Data Output Mode”..................................................................................... 36

9-6 Description of the Item “Data Format” ...................................................................................... ........ 37

9-7 Data Format Examples..................................................................................................................... 39

9-8 Description of the Item “Application Function”.................................................................................. 40

9-9 Comparator Function........................................................................................................................ 41

10. ID NUMBER AND GLP REPORT ...............................................................................................42

10-1 Setting the ID Number ..................................................................................................... ............... 42

10-2 GLP Report................................................................................................................ ..................... 42

11. UNDERHOOK.............................................................................................................................45

12. PROGRAMMABLE-UNIT ...........................................................................................................46

RS-232C Serial Interface

13. RS-232C SERIAL INTERFACE ..................................................................................................47

14. CONNECTION TO PERIPHERAL EQUIPMENT ........................................................................48

14-1 Connection to the AD-8121B Printer .............................................................................................. 48

14-2 Connection to a Computer.............................................................................................................. 49

14-3 Using Windows Communication Tools (WinCT) ............................................................................. 49

15. COMMANDS...............................................................................................................................51

15-1 Command List................................................................................................................................. 51

15-2 Acknowledge Code and Error Codes ............................................................................................. 52

15-3 Settings Related to RS-232C ......................................................................................................... 53

Maintenance

16. MAINTENANCE..........................................................................................................................54

17. TROUBLESHOOTING ................................................................................................................55

17-1 Checking the Balance Performance and Environment................................................................... 55

17-2 Error Codes .................................................................................................................................... 56

17-3 Asking For Repair ........................................................................................................................... 57

18. OPTIONS ....................................................................................................................................58

19. SPECIFICATIONS.......................................................................................................................60

20. EXTERNAL DIMENS IONS ........................................................................................................61

21. TERMS/INDEX............................................................................................................................62

1. INTRODUCTION

This manual describes how the FX-i series balance works and how to get the most out of it in terms of performance.

Read this manual thoroughly before using the balance and keep it at hand for future reference.

1-1 About This Manual

This manual consists of the following five parts:

Basic operation ........................ Describes precautions on handling the balance, balance

construction and basic balance operation.

Adapting to the environment.... Describes response adjustment and calibration.

Functions ................................. Describes various functions of the balance.

RS-232C serial interface.......... Describes the interface which transmits data and controls the balance.

Maintenance ............................ Describes maintenance, error codes, troubleshooting,

specifications and options.

1-2 Features

 Compact general-purpose balance, can be installed almost anywhere.  Casing construction, strong protection against dust and moisture.  Stabilization time of one second. When FAST is selected for the response rate, a stabilization

time of one second, to read a displayed value after a sample is placed on the pan, has been achieved.

 Multiple weighing units with most of the common units used around the world.  Standard RS-232C serial interface to communicate with a computer and to output the Good

Laboratory Practice (GLP) data

 Statistical calculation mode to statistically calculate the weight data, and display or output the

sum, maximum, minimum, range (maximum-minimum), average, standard deviation and coefficient of variation.

 Comparator Indicators, displaying the comparison results.  Hold Function, provided for weighing a moving object such as an animal.  Breeze break, provided for the FX-120i/200i/300i, for more accurate weighing.  Underhook, provided for suspended weighing.

 As options, the USB interface (FXi-02), the Ethernet interface (Fxi-08) and the built-in battery

unit (Fxi-09) are available.

1-3 Compliance

Compliance with FCC Rules

Please note that this device generates, uses and can radiate radio frequency energy. This device has been tested and has been found to comply with the limits of a Class A computing device pursuant to Subpart J of Part 15 of FCC rules. These rules are designed to provide reasonable protection against interference when this device is operated in a commercial environment. If this unit is operated in a residential area, it may cause some interference and under these circumstances the user would be required to take, at his own expense, whatever measures are necessary to eliminate the interference. (FCC = Federal Communications Commission in the U.S.A.)

2. UNPACKING THE BALANCE

2-1 Unpacking

 The balance is a precision instrument. Unpack the balance carefully. Keep the packing

material to be used for transporting the balance in the future.

 The packing contents depend on the balance model. See the illustrations to confirm that

everything is contained.

How to assemble the breeze break (Only for FX-120i/200i/300i)

Assemble the breeze break as shown below. Follow the numbered sequence.

Display

Bubble spirit level

Weighing pan

Pan support

Main unit

AC adapter jack

RS-232C serial interface

AC adapter plug

Keys

Leveling foot

Grounding terminal

Main unit rear side

The AC adapter plug is protected against dust and may be difficult to insert. When inserting the plug, turn the plug

hile pushing on it.

AC adapter

ID label

Main unit cover

Note

Please confirm that the AC adapter type is correct for your local voltage and receptacle type.

2-2 Installing the Balance

Install the balance as follows:

1. Place the balance on a solid weighing table. Refer to “3. PRECAUTIONS” for installing the balance.

2. FX-120 Assemble the pan support, weighing pan and breeze break, on the balance as shown in the

illustration on page 4.

FX-1200 Assemble the pan support and weighing pan on the balance as shown in the illustration on page 4.

3. Adjust the leveling feet to level the balance. Confirm it using the bubble spirit level.

4. Confirm that the AC adapter type is correct for the local voltage and power receptacle type.

5. Connect the AC adapter to the balance. Warm up the balance for at least 30 minutes with nothing on the weighing pan.

Note The AC adapter plug is protected against dust and may be difficult to insert. When inserting the plug, turn the plug while pushing on it.

i /200i /300i

i /2000i /3000i

3. PRECAUTIONS

To get the optimum performance from the balance and acquire accurate weight data, note the

following:

3-1 Before Use

 Install the balance in an environment where the

temperature and humidity are not excessive. The best operating temperature is about 20°C / 68°F at about 50% relative humidity.

 Install the balance where it is not exposed to direct

sunlight and it is not affected by heaters or air conditioners.

 Install the balance where it is free of dust.

 Install the balance away from equipment which

produces magnetic fields.

 Install the balance in a stable place avoiding vibration

and shock. Corners of rooms on the first floor are best, as they are less prone to vibration.

 The weighing table should be solid and free from

vibration, drafts and as level as possible.

 Level the balance by adjusting the leveling feet and

confirm it using the bubble spirit level.

 Ensure a stable power source when using the AC

adapter.

 Plug in the AC adapter and warm up the balance for at

least 30 minutes.

 Calibrate the balance before use or after having

moved it to another location.

Caution

Do not install the balance where flammable or corrosive gas is present.

3-2 During Use

 Discharge static electricity from the material to be

weighed (hereinafter referred to as the sample). When

a sample could have a static charge, the weight data is

influenced. Ground the balance and try the following:

Eliminate static electricity using the optional

AD-1683 DC static eliminator. Try to keep the ambient humidity above 45%RH. Use a metal shield case for a charged sample. Wipe charged plastic samples with a moistened

cloth.

 This balance uses a strong magnet as part of the

balance assembly, so please use caution when weighing magnetic materials such as iron. If there is a problem, use the underhook on the bottom of the balance to suspend the material away from the influence of the magnet.

 Eliminate the temperature difference between a sample and the environment. When a sample

is warmer (cooler) than the ambient temperature, the sample will be lighter (heavier) than the true weight. This error is due to a rising (falling) draft around the sample.

 Make each weighing gently and quickly to avoid errors caused by the evaporation of moisture

from the sample or the absorption of moisture by the sample.

 Do not drop things upon the weighing pan, or place a sample on the pan that is beyond the

balance weighing capacity. Place a sample in the center of the weighing pan.

 Do not use a sharp instrument such as a pencil to press the keys. Use your finger only.

 Press the RE-ZERO key before each weighing to eliminate possible errors.

 Calibrate the balance periodically so as to eliminate possible errors.

 Take into consideration the affect of air buoyancy on a sample when more accuracy is

required.

 Keep the balance interior free of dust and foreign materials.

 The breeze break (FX-120i /200i /300i only) is provided as an accessory. An anti-static

treatment has been applied to the breeze break components, but they may be charged with static electricity when they are unpacked or when the humidity is low. If the weight value is unstable even when there are no drafts or the balance has a problem with repeatability, remove the breeze break. Or wipe the clear plates with a moistened cloth, use the optional AD-1683 DC static eliminator or apply an anti-static spray.

3-3 After Use

 Avoid mechanical shock to the balance.

 Do not disassemble the balance. Contact the local A&D dealer if the balance needs service or

repair.

 Do not use organic solvents to clean the balance. Clean the balance with a lint free cloth that

is moistened with warm water and a mild detergent.

 The edge of the weighing pan is sharp. Use much care when cleaning the pan.

 Avoid dust and water so that the balance weighs correctly. Protect the internal parts from liquid

spills and excessive dust.

3-4 Power Supply

 When the AC adapter is connected, the balance is in the standby mode if the standby

indicator is on (refer to “3-5 Display Symbols and Key Operation”). This is a normal state and does not harm the balance. For accurate weighing, warm up the balance for at least 30 minutes before use.

3-5 Display Symbols and Key Operation

Key operation

Key operation affects how the balance functions. The basic key operations are:

 “Press and release the key immediately” or “Press the key” = normal key operation during measurement

 “Press and hold the key”

Display symbols

Each key, when pressed or when pressed and held, functions as follows:

Key When pressed When pressed and held

Turns the display on or off. The standby indicator is displayed when the display is turned off. The weighing mode is enabled when the display is turned on.

This key is available anytime. Pressing the key during operation will interrupt the operation and turn the display off.

In the weighing mode, turns the minimum weighing value on or off.

In the counting or percent mode, enters the sample storing mode.

Switches the weighing units stored in the function table. Refer to “4. WEIGHING UNITS”.

Cancels the operation when performing settings.

Enters the function table mode. Refer to “9. FUNCTION TABLE”.

Enters the response adjustment mode.

Enters the calibration mode.

Outputs the weight data to a printer or personal computer using the RS-232C serial interface, depending on the function table settings.

Confirms the operation when performing settings.

Sets the display to zero.

No function at the factory setting

By changing the function table: Outputs “Title block” and “End block” for GLP report.

4. WEIGHING UNITS

4-1 Units

With the FX-i series balance, the following weighing units and weighing modes are available:

A unit or mode can be selected and stored in the function table as described on page 11. If a weighing mode (or unit of weight) has been turned off, that mode or unit will be missing in the sequence. Tael has four varieties, one of which can be selected and installed at the factory.

To select a unit or mode for weighing, press the MODE key.

For details about the units and modes, see the table below:

Name (unit, mode) Abbrev. Display Function table

(Storing mode)

Conversion factor

1 g =

Gram g g g 1 g

Counting mode pcs pcs pcs

Percent mode % % %

Ounce (Avoir) oz oz oz 28.349523125 g

Pound lb lb lb 453.59237 g

Pound/Ounce

L OZ

Troy Ounce OZt ozt ozt 31.1034768 g

Metric Carat ct ct ct 0.2 g

Momme mom 3.75 g

Pennyweight dwt dwt dwt 1.55517384 g

Grain (UK) GN GN GN 0.06479891 g

Tael (HK general, Singapore) 37.7994 g

Tael (HK jewelry) 37.429 g

Tael (Taiwan) 37.5 g

Tael (China)

Loz

tl tl

1Lb=16 oz,

1 oz=28.349523125 g

31.25 g

Tola (India) tol tol tol 11.6638038 g

Messghal mes 4.6875 g

Programmable-unit (Multi-unit) Mlt MLT MLT

The tables below indicate the weighing capacity and the minimum display for each unit, depending

on the balance model.

Unit

FX-120

Gram 122.000 220.000 320.000 0.001

Ounce (Avoir) 4.30340 7.76025 11.28765 0.00005

Pound 0.268965 0.485015 0.705480 0.000005

Pound/Ounce 0L 4.30oz 0L 7.76oz 0L 11.29oz 1L 0.01oz

Troy Ounce 3.92240 7.07315 10.28825 0.00005

Metric Carat 610.000 1100.000 1600.000 0.005

Momme 32.2535 58.6665 85.3335 0.0005

Pennyweight 78.621 141.776 206.220 0.001

Grain (UK) 1882.74 3395.12 4938.34 0.02

Tael (HK general, Singapore) 3.22755 5.82020 8.46575 0.00005

Tael (HK jewelry) 3.25950 5.87780 8.54950 0.00005

Tael (Taiwan) 3.25330 5.86670 8.53330 0.00005

Tael (China) 3.90400 7.04000 10.24000 0.00005

Tola (India) 10.4597 18.8618 27.4353 0.0001

Messghal 26.0265 46.9335 68.2665 0.0005

i FX-200i FX-300i

Minimum display

Capacity

Unit

FX-1200

Gram 1220.00 2200.00 3200.00 0.01

Ounce (Avoir) 43.0340 77.6025 112.8765 0.0005

Pound 2.68965 4.85015 7.05480 0.00005

Pound/Ounce 2L 11.03oz 4L 13.60oz 7L 0.88oz 1L 0.01oz

Troy Ounce 39.2240 70.7315 102.8825 0.0005

Metric Carat 6100.00 11000.00 16000.00 0.05

Momme 322.535 586.665 853.335 0.005

Pennyweight 786.21 1417.76 2062.20 0.01

Grain (UK) 18827.4 33951.2 49383.4 0.2

Tael (HK general, Singapore) 32.2755 58.2020 84.6575 0.0005

Tael (HK jewelry) 32.5950 58.7780 85.4950 0.0005

Tael (Taiwan) 32.5330 58.6670 85.3330 0.0005

Tael (China) 39.0400 70.4000 102.4000 0.0005

Tola (India) 104.597 188.618 274.353 0.001

Messghal 260.265 469.335 682.665 0.005

i FX-2000i FX-3000i

Minimum display

Capacity

4-2 Storing Units

The units or modes can be selected and stored in the function table. The sequence of displaying the units or modes can be arranged in the function table so as to fit the frequency of use.

Select a unit or mode and arrange the sequence of display as follows:

1 Press and hold the SAMPLE key until ba5fnc of the

function table is displayed.

2 Press the SAMPLE key several times to display

1Unit .

3 Press the PRINT key to enter the unit selection mode.

4 Specify a unit or mode in the order to be displayed

using the following keys.

SAMPLE key To sequentially display the units.

RE-ZERO key To specify a unit or mode. The

stabilization indicator appears when the displayed unit or mode is specified.

5 Press the PRINT key to store the units or modes. The

balance displays end and then displays the next menu of the function table.

6 Press the CAL key to exit the function table. Then the

balance returns to the weighing mode with the unit specified first in step 4.

Notes When the power is turned on, the scale displays the unit specified first in step 4.

In the weighing mode, to select a unit or mode for weighing, press the MODE key.

5. WEIGHING

5-1 Basic Operation (Gram Mode)

1 Place a container on the weighing pan, if necessary. Press the RE-ZERO key to cancel the weight (tare). The

balance displays 0.00 g. (The decimal point position depends on the balance model.)

2 Place a sample on the pan or in the container.

3 Wait for the stabilization indicator to be displayed. Read

the value.

While the stabilization indicator is on, pressing the PRINT key will output the weight value, using the RS-232C serial interface.

Note Peripheral equipment, that is sold separately , such as a printer or a personal computer is required.

4 Remove the sample and container from the pan.

Notes To use other units, press the MODE key and select an appropriate unit.

Press the SAMPLE key to turn on or off the minimum weighing value.

When the ON:OFF key is pressed with a container placed on the weighing pan, the balance displays 0.00 g and weighing is started,

5-2 Counting Mode (PCS)

This is the mode to determine the number of objects in a sample based on the standard sample unit mass. Unit mass means the mass of one sample. The smaller the variables in each sample unit mass are, the more accurate the counting will be. The FX-i series balance is equipped with the Automatic Counting Accuracy Improvement (ACAI) function to improve the counting accuracy.

Note If the sample unit mass variable is too large, it may cause a counting error.

Selecting the counting mode

1 Press the MODE key to select 1pcs (counting mode).

Storing a sample unit mass

2 Press the SAMPLE key to enter the sample unit mass

storing mode.

Even in the storing mode, pressing the MODE key will

switch to the next mode.

3 To select the number of samples, press the SAMPLE key

several times. It may be set to 5, 10, 25, 50 or 100.

Note A greater number of samples will yield more accurate counting result.

4 Place a container on the weighing pan, if necessary.

Press the RE-ZERO key to cancel the weight (tare). The number specified in step 3 appears.

e.g.: 25 0 is displayed if 25 is selected in step 3.

5 Place the number of samples specified on the pan. In this

example, 25 pieces.

6 Wait for the stabilization indicator to come on. Press the

PRINT key to calculate and store the unit mass. The balance displays 25 count samples with this unit mass. (The sample unit mass stored, even if the AC adapter is removed, is maintained in non-volatile memory.)

To improve the accuracy of the unit mass, proceed to

step 8.

Notes If the balance judges that the mass of the samples is too light and is not adequate to be used as the unit mass, it displays lo . In that case, store the mass by some quantity. For example, when the model with the minimum weighing value of 0.01 g is used and 10 pieces of samples weigh 0.05 g. Store 100 pieces of samples as 10 and multiply the weighing result by 10.

pcs

(counting mode) and is set to

If the balance judges that the mass of the samples is too light to aquire accurate weighing, it displays an error requiring the addition of more samples to the specified number. In the

PCS

example above, 150-

appears, requiring 25 more samples. Add 25 samples and press the PRINT key. When the unit mass is stored correctly, the balance proceeds to the counting mode.

Counting operation

7 Place the samples to be counted on the pan.

While the stabilization indicator is on, pressing the PRINT key will output the weight value, using the RS-232C serial interface.

Note Peripheral equipment, that is sold separately , such as a printer or a personal computer is required.

Counting mode using the ACAI function

The ACAI is a function that improves the accuracy of the unit mass automatically by increasing the number of samples and averaging the unit mass variable to minimize the weighing error, as the counting process proceeds.

8 If a few more samples are added, the processing indicator turns on. To prevent an error, add

three or more. The processing indicator does not turn on if overloaded. Try to add the same number of samples as displayed.

9 The balance re-calculates the unit mass while the processing indicator is blinking. Do not

touch the balance or samples on the pan until the processing indicator turns off.

10 Counting accuracy is improved when the processing indicator turns off.

Each time the above operation is performed, a more accurate unit mass will be obtained.

There is no definite upper limit of ACAI range for the number of samples exceeding 100. Try to add the same number of samples as displayed.

11 Remove all the samples used in ACAI and proceed with the counting operation using the

improved unit mass.

5-3 Percent Mode (%)

This is the mode to display the weight value in percentage compared to a 100% reference mass and

is used for target weighing or checking the sample variable.

Selecting the percent mode

1 Press the MODE key to select % (percent mode).

Storing the 100% reference mass

2 Press the SAMPLE key to enter the 100% reference

mass storing mode.

Even in the storing mode, pressing the MODE key will

switch to the next mode.

3 Place a container on the weighing pan, if necessary.

Press the RE-ZERO key to cancel the weight (tare). The balance displays 100 0 % .

4 Place the sample to be set as the 100% reference mass

on the pan or in the container.

5 Press the PRINT key to store the reference mass. The

balance displays 100.00 % . (The decimal point position depends on the reference value. The reference mass stored, even if the AC adapter is removed, is maintained in non-volatile memory.)

Note If the balance judges that the mass of the sample is too light to be used as a reference, it displays lo . Do not use the sample.

6 Remove the sample.

Reading the percentage

7 Place a sample to be compared to the reference mass on

the pan. The displayed percentage is based on the 100% reference mass. While the stabilization indicator is on, pressing the PRINT key will output the weight value, using the RS-232C serial interface.

Note Peripheral equipment, that is sold separately , such as a printer or a personal computer is required.

5-4 Statistical Calculation Mode

The statistical calculation mode statistically calculates the weight data, and displays or outputs the results. To use the statistical calculation mode, set the "Application function (apf)" parameter of “Application (ap fnc)” in the function table to “2”, as described below. Statistical items available are number of data, sum, maximum, minimum, range (maximum-minimum), average, standard deviation and coefficient of variation. What statistical items to output can be selected from the three modes in the function table.

 The wrong data input can be canceled by the key operation, if immediately after the input.

 Turning the balance off will delete the statistical data.

 The standard deviation and coefficient of variation are obtained by the equation below:

Standard deviation=

Standard deviation

Coefficient of variation (CV)=

where Xi is the i-th weight data,

N is number of data.

x 100 (%)

Average

5-4-1 Getting Started

Switching to the Statistical Function Mode (Changing The Function Table)

1 Press and hold the SAMPLE key until ba5fnc of

the function table is displayed, then release the key.

2 Press the SAMPLE key several times to display

1ap fnc .

3 Press the PRINT key to display apf 0 .

4 Press the RE-ZERO key to display apf 2 .

To select statistical items to output, go to step 5. To store the statistical function mode setting, go to

step 7.

To disable the statistical calculation mode, press the

RE-ZERO key to select apf 0 .

Selecting the statistical items to output

5 Press the SAMPLE key to display 5taf 0 .

6 Press the RE-ZERO key to select the output items. In the example, 5taf 1 is selected to output the

number of data, sum, maximum, minimum, range (maximum-minimum) and average.

Parameter Description

7 Press the PRINT key to store the setting.

Note The statistical calculation mode will be enabled using the ON:OFF key or when the power is turned on.

8 Press the CAL key to return to the weighing mode.

Number of data, sum Number of data, sum Maximum, minimum, range (maximum – minimum), average Number of data, sum Maximum, minimum, range (maximum – minimum), average, Standard deviation, coefficient of variation

Selecting the unit

9 Press the MODE key to select the unit to be used for

the statistical calculation mode.

Notes Selecting the unit using the MODE key is not available after the data is entered. In this case, clear the data as described on page 19 and select the unit using the MODE key.

When the statistical calculation mode is to be enabled upon power-on, select the unit in “Unit (Unit)” of the function table beforehand.

5-4-2 Using The Statistical Calculation Mode

Entering data for statistical calculation

Use the following keys to operate the statistical calculation mode.

MODE key

SAMPLE key ............ Turns the minimum display on or off, in the weighing mode.

RE-ZERO key PRINT key

CAL key

...............

...........

................

....................

When the data is entered, moves between the displaying items (weighing mode,

statistical results and data operation) each time the key is pressed.

When no data has been entered, selects the unit.

Sets the display to zero in the weighing mode.

Outputs the data number and the weight data and includes the weight data to

statistical calculation in the weighing mode. (Output is not in the data format specified in the function table because of the data number added.)

Outputs the statistical results while the statistical results are displayed. (Output

is not in the data format specified in the function table.)

Returns to the weighing mode.

1 Press the RE-ZERO key to set the display to zero.

2 Place the sample on the weighing pan and wait for

the stabilization indicator to turn on.

3 Press the PRINT key to add the data displayed to

statistical calculation. The number of data on the upper left of the display increases by 1.

4 Repeat steps 1 to 3 for each weighing.

Outputting the statistical results

5 Each time the MODE key is pressed, the display changes:

the results as selected in “Statistical function mode output items (5taf)”, CanCel and Clear .

Notes When the number of data is 1, the standard deviation and coefficient of variation are displayed as - - - - - - - .

When the average is 0, the coefficient of variation is displayed as - - - - - - - .

Statistical items are indicated on the upper left of the display using the following symbols.

Symbol Statistical item

SUM Sum MAX Maximum MIN Minimum

R Range (Maximum – minimum)

AVE Average

SD Standard deviation CV Coefficient of variation

6 While the results are displayed, press the

PRINT key to output the results.

Output example

Deleting the latest data

When the wrong data is entered, it can be deleted and excluded from statistical calculation. Only the latest data can be deleted.

1 In the weighing mode, press the MODE key, and then

press the SAMPLE key several times to display

1CanCel .

2 Press the PRINT key to display Can no .

3 Press the RE-ZERO key to display Can go .

4 Press the PRINT key to delete the latest data and

exclude it from statistical calculation.

The number of data decreases by 1 when the balance

returns to the weighing mode.

Clearing the statistical data

All the statistical data will be deleted and the number of data will be 0 (zero).

1 In the weighing mode, press the MODE key,

and then press the SAMPLE key several times to display Clear .

2 Press the PRINT key to display Clr no .

3 Press the RE-ZERO key to display Clr go .

4 Press the PRINT key to delete the statistical

data.

The number of data becomes 0 (zero) when the

balance returns to the weighing mode.

5-5 Statistical Calculation Mode (Example of Use)

Here, as an example of use of the statistical calculation mode, mixing of the multiple formulae such as medicine is described. The mixing process is recorded using the balance and the printer. In the example, the FX-3000i and the AD-8121B (dump print mode) are connected using the RS-232C serial interface.

5-5-1 Getting Started

Changing the function table

Changes : ●To enable the statistical calculation mode

●To enable “Zero after output”

Enabling the statistical calculation mode

1 Enter the function table menu.

Press and hold the SAMPLE key until ba5fnc of

the function table is displayed, then release the key.

2 Select the application function.

Press the SAMPLE key several times to display

1ap fnc . Then, press the PRINT key to display 1°apf 0 .

3 Change the application function parameter to “2”.

Press the RE-ZERO key to display apf 2 . Press the

PRINT key to confirm the change. After end ,

1ba5fnc1 is displayed.

Enabling “Zero after output”

4 Select “Zero after output”.

Press the SAMPLE key several times to display 1dout .

Then, press the PRINT key to display °prt 0 , and press the SAMPLE key several times to display 1°ar-d 0 .

5 Enable “Zero after output”.

Press the RE-ZERO key to display ar-d 1 . Then,

press the PRINT key to confirm the change. After

1end , 5if is displayed.

Returning to the weighing mode

6 Press the CAL key to return to the weighing mode.

5-5-2 Using The Statistical Calculation Mode

1 Press the RE-ZERO key to set the display to zero.

2 Place a container on the weighing pan. Press the PRINT key to cancel the weight (tare). The

balance displays 0.00 g. (Storing the tare value)

The tare value data is output when the peripheral

output equipment is connected.

3 Weigh formula 1 and press the PRINT key. The

balance displays 0.00 g. (Storing the weight value of formula 1)

The weight value data is output when the peripheral

output equipment is connected.

4 Weigh formula 2 and press the PRINT key. The

balance displays 0.00 g. (Storing the weight value of formula 2)

The weight value data is output when the peripheral

output equipment is connected.

5 When there are some more formulae to be added,

repeat step 4.

6 After mixing is complete, press the MODE key to

display the statistical results.

7 Press the PRINT key to output the number of data

saved including the tare value and the total weight.

Output example

6. RESPONSE ADJUSTMENT

This function stabilizes the weight value, reducing the influence on weighing that is caused by drafts and vibration at the place where the balance is installed.

The function has three stages as follows and can be changed by simple key operation.

Indicator Description

FAST

MID.

SLOW

Operation

1 Press and hold the MODE key until RESPONSE is

displayed. And then, release the key.

2 Press the MODE key to select a rate of the response

adjustment. Either FAST, MID. or SLOW can be selected.

Fast response, but prone to drafts and vibration. Good for target weighing.

Slow response, but strong against drafts and vibration Good for weighing which requires a stable display.

3 After a few seconds of inactivity, or when the PRINT

key is pressed, the balance displays eend . Then, it returns to the weighing mode and displays the updated response indicator. The response indicator remains displayed for a while.

Note Setting the response rate automatically changes the “Condition (Cond)” and “Display refresh rate (5pd)” parameters of “Environment, Display (ba5fnc)” in the function table, as shown below:

Indicator Cond (Condition)

FAST 0 2 MID. 1 0 SLOW 2 0

When the balance is to be used with other setting combinations, set each parameter in the function table.

5pd (Display refresh rate)

7. CALIBRATION

7-1 Calibration Mode

The FX-i series balance has the following two modes.

 Calibration using an external weight  Calibration test using an external weight (Calibration test does not perform calibration.)

Terms

The following terms are defined as follows: External weight = A weight that you have. Referred to as a calibration weight when used for

calibration. Calibration weight = A weight used for calibration Target weight = An external weight used for calibration test

Caution

 Calibration adjusts the balance for accurate weighing. Besides periodic calibration and before each use, perform calibration when:

• The balance is installed for the first time.

• The balance has been moved.

• The ambient environment has changed.

 Do not allow vibration or drafts to affect the balance during calibration.

 To output the data for GLP using the RS-232C serial interface, set “GLP output ( info )” of

“Data output ( dout )”. For details, refer to “9. FUNCTION TABLE”.

 Calibration test is available only when “GLP output ( info )” of “Data output ( dout )” is set to “1” or “2”.

Caution on using an external weight

 The accuracy of an external weight will influence the accuracy of weighing. Select an

appropriate weight as listed below:

Model Usable calibration weight Adjustable range

FX-120i 100 g, 50 g FX-200i 200 g, 100 g FX-300i 300 g, 200 g, 100 g FX-1200i 1000 g, 500 g, FX-2000i 2000 g, 1000 g FX-3000i 3000 g, 2000 g, 1000 g

The calibration weight in bold type: factory setting The calibration weight value can be adjusted within the range above.

-0.050 g to +0.050 g

-0.50 g to +0.50 g

Display

 This indicator means “the balance is measuring calibration data”.

Do not allow vibration or drafts to affect the balance while this indicator is displayed.

7-2 Calibration Using an External Weight

This function calibrates the balance using an external weight.

Operation

1 Connect the AC adapter and warm up the balance

for at least 30 minutes with nothing on the pan.

2 Press and hold the CAL key until Calout is

displayed, and then release the key.

3 The balance displays Cal 0 .

 If you want to change the calibration weight (a

list of usable weights is shown on page 23), press the SAMPLE key and proceed to step 4.

 If you use the calibration weight value stored in

the balance, proceed to step 5.

4 Specify the calibration weight value as follows:

SAMPLE key To switch the display condition

to: “All of the segments blinking” (calibration weight selection mode) or “The last two digits blinking” (value adjustment mode).

RE-ZERO key (To increase the value) MODE key (To decrease the value)

To select the calibration

weight or adjust the value.

PRINT key To store the new weight

value. Even if the AC adapter is removed, the data is maintained in non-volatile memory.

CAL key To cancel the operation and

return to Cal 0 .

5 Confirm that there is nothing on the pan and

press the PRINT key. The balance measures the zero point. Do not allow vibration or drafts to affect the balance.

The balance displays the calibration weight value.

6 Place the displayed calibration weight on the pan

and press the PRINT key. The balance measures the calibration weight. Do not allow vibration or drafts to affect the balance.

7 The balance displays end . Remove the weight

from the pan.

8 When the GLP output is set, the balance displays

1 glp and outputs “Calibration Report”.

9 The balance will automatically return to the

weighing mode.

10 Place the calibration weight on the pan and confirm

that the value displayed is within ±2 digits of the specified value. If it is not within the range, check the ambient conditions such as breeze and vibration, also check the weighing pan. Then, repeat steps 1 to 9.

7-3 Calibration Test Using an External Weight

This function tests the balance weighing accuracy using an external weight and outputs the result. This is available only when the “GLP output (info)” parameter is set to “1” or “2”. (Calibration test does not perform calibration.)

Operation

1 Connect the AC adapter and warm up the balance

for at least 30 minutes with nothing on the pan.

2 Press and hold the CAL key until CCout is

displayed, and then release the key.

3 The balance displays CC 0 .

 If you want to change the target weight (a list of

usable weights is shown on page 23), press the SAMPLE key and proceed to step 4.

 If you use the target weight value stored in the

balance, proceed to step 5.

4 Specify the target weight value as follows:

SAMPLE key To switch the display

condition to: “All of the segments blinking” (target weight selection mode) or “The last two digits blinking” (value adjustment mode).

RE-ZERO key (To increase the value) MODE key (To decrease the value)

To select the target weight or

adjust the value.

PRINT key To store the new weight

value. Even if the AC adapter is removed, the data is maintained in non-volatile memory.

CAL key To cancel the operation and

return to CC 0 .

5 Confirm that there is nothing on the pan and press the

PRINT key. The balance measures the zero point and displays the measured value. Do not allow vibration or drafts to affect the balance.

The balance displays the target weight value.

6 Place the displayed target weight on the pan and press

the PRINT key. The balance measures the target weight and displays the measured value. Do not allow vibration or drafts to affect the balance.

7 The balance displays end . Remove the weight from the

pan.

8 When the GLP output is set, the balance displays glp1

and outputs “Calibration Test Report”.

9 The balance will automatically return to the weighing

mode.

8. FUNCTION SWITCH AND INITIALIZATION

8-1 Permit or Inhibit

The balance stores parameters that must not be changed unintentionally. There are two switches for the purpose of protecting these parameters. Each switch can select either “permit” or “inhibit”. The “inhibit” protects parameters against unintentional operations.

Switches

Operation

1 Press the ON:OFF key to turn off the display.

2 While pressing and holding the PRINT key and the SAMPLE key, press the ON:OFF key.

The balance displays p5 .

3 Press the PRINT key. Then the balance displays the function switches.

4 Set the switches using the following keys.

SAMPLE key To select the switch to change the parameter.

RE-ZERO key To change the parameter of the switch selected.

0:To inhibit changes. 1:To permit changes

PRINT key To store the new parameter and return to the weighing mode.

CAL key To cancel the operation ( Clr is displayed.) To return to the

weighing mode, press the CAL key once again.

8-2 Initializing the Balance

This function returns the following parameters to factory settings.

 Calibration data

 Function table

 The sample unit mass value (counting mode), 100% reference mass value (percent mode)

 External calibration weight

 Function switch settings

 Statistical data

Note Be sure to calibrate the balance after initialization.

Operation

1 Press the ON:OFF key to turn off the display.

2 While pressing and holding the PRINT key and the

SAMPLE key, press the ON:OFF key. The balance displays p5 .

3 Press the SAMPLE key to display Clr .

4 Press the PRINT key.

To cancel this operation, press the CAL key.

5 Press the RE-ZERO key.

6 Press the PRINT key to initialize the balance.

The balance will automatically return to the weighing

mode.

9. FUNCTION TABLE

The function table reads or rewrites the parameters that are stored in the balance. These parameters stored, even if the AC adapter is removed, are maintained in non-volatile memory.

9-1 Structure and Sequence of the Function Table

The function table menu consists of two layers. The first layer is the “Class” and the second layer is the “Item”. Each item stores a parameter.

Example

This example sets “Auto print mode A” for “Data output mode” and “100 digits” for “Auto print

difference”.

9-2 Display and Keys

Display/Key Description

The symbol “ ” indicates that the parameter displayed is in effect.

When pressed and held in the weighing mode, enters the function table mode.

Selects the class or item in the function table mode.

Changes the parameter.

When a class is displayed, moves to an item in the class.

When an item is displayed, stores the new parameter and displays the next class.

When an item is displayed, cancels the new parameter and displays the next

class. When a class is displayed, exits the function table mode and returns to the weighing mode.

9-3 Details of the Function Table

Class Item and Parameter Description

ba5fnc

Environment Display

Cp fnc

Comparator

Cp Hi

Upper limit

Cp lo

Lower limit

Cond

Condition

5t-b

Stability band width

Hold

Hold function

trc

Zero tracking

5pd

Display refresh rate

pnt

Decimal point

p-on

Auto display-ON

poff

Auto display-OFF

rng

Display at start

beep

Beep

Comparator mode

bep

LO buzzer

bep-

OK buzzer

bep

HI buzzer

Fast response, sensitive value

Slow response, stable value

Stable range is ±1 digit

Stable range is ±3 digits

OFF

Normal

Strong

Very strong

5 times/second

10 times/second

20 times/second

Point (.)

Comma (,)

OFF

ON (10 minutes)

Displays

Does not display

Does not sound

Sounds No comparison

Comparison, excluding "near zero" when stable value or overloaded

Comparison, including "near zero" when stable value or overloaded

Continuous comparison, excluding "near zero"

Continuous comparison, including "near zero"

OFF

Refer to “9-9 Comparator Function”.

FAST

MID.

SLOW

With “

Hold 1

”, sets the averaging

time.

The stabilization indicator illuminates

when the display fluctuation is within the range. With “Hold 1”, sets the stabilization range.

Holds the display when stable in animal mode. With “

Keeps zero display by tracking zero drift.

Period to refresh the display

Decimal point format

Turns on the weighing mode display when the AC adapter is connected.

Turns off the display after 10 minutes of inactivity.

Select whether or not to display the minimum weighing value at weighing start.

Select whether or not to sound the beep when operating on keys.

Hold 1

”, ANIMAL turns on.

Factory settings. Digit is a unit of minimum weighing value

Class Item and Parameter Description

Key mode

Auto print mode A

(Reference = zero) Auto print mode B

prt

Data output mode

ap-p

Auto print polarity

ap-b

Auto print difference

dout

Data output

int

Interval time

pU5e

Data output pause

at-f

Auto feed

info

GLP output

ar-d

Zero after output

(Reference = last stable value)

Stream mode

Key mode B (Immediately)

Key mode C (When stable)

Interval output mode

Plus only

Minus only

Both

10 digits

100 digits

1000 digits

Every measurement

2 seconds

5 seconds

10 seconds

30 seconds

1 minute 2 minute

6 7

5 minute

10 minute

No pause

Pause (1.6 seconds)

Not used

Used

No output

AD-8121 format

General data format

Not used

Used

Accepts the PRINT key only when the display is stable.

Outputs data when the display is stable and conditions of and the reference value are met.

Outputs data continuously. Accepts the PRINT key regardless

of the display condition. Accepts the PRINT key immediately when the display is stable, or waits for the display to be stable when not.

Uses interval output mode.

Displayed value>Reference

Displayed value<Reference

Regardless of displayed value

Difference between reference value and displayed value

Interval time for the interval output mode (With

prt 6

)

Selects the data output interval.

Selects whether or not automatic feed is performed.

Selects GLP output method.

Adjusts zero automatically after data is output

ap-p,ap-b

Factory settings. Digit is a unit of minimum weighing value

Class Item and Parameter Description

600 bps

1200 bps

bp5

Baud rate

btpr

Data bit, parity bit

5if

Serial

Crlf

Terminator

interface

type

Data format

t-Up

Timeout

erCd

AK, Error code

mltMLT

Programmable-unit (Multi-unit)

Unit

2400 bps

4800 bps

9600 bps

19200 bps

7 bits, even

7 bits, odd

8 bits, none

CR LF

A&D standard format

DP format

KF format

MT format

NU format

CSV format

No limit

1 second

No output

Output

Sets an arbitrary coefficient.

Refer to “4. WEIGHING UNITS”.

Unit

Refer to “10. ID NUMBER AND GLP REPORT”

ID number

Normal weighing mode

Capacity indicator

Statistical calculation mode

Number of data, sum Number of data, sum, maximum, minimum, average, range

(maximum-minimum) Number of data, sum, maximum, minimum, average, range

(maximum-minimum), standard deviation, coefficient of variation

ap fnc

Application

apf

Application function

5taf

Statistical function mode output items

CR: ASCII code 0Dh LF: ASCII code 0Ah

Refer to “9-6 Description of the Item “Data Format””.

Selects the wait time to receive a command.

AK:ASCII code 06h

Available only when programmableunit mode is selected.

Factory settings.

Caution

The balance may not transmit the data completely at the specified refresh rate, depending on the baud rate. When a refresh rate of 20 times/second is used, set the baud rate to 4800 bps or higher.

9-4 Description of the Class “Environment, Display”

Condition ( Cond )

Cond 0 This parameter is for sensitive response to the fluctuation of a weight value.

Used for powder target weighing, weighing a very light sample or when quick response weighing is required.

After setting, the balance displays FAST.

Cond 2 This parameter is for stable weighing with slow response. Used to prevent a

weight value from drifting due to vibration or drafts. After setting, the balance displays SLOW.

Note With “Hold function (Hold)” set to “ON (1)”, this item is used to set the averaging time.

Stability band width ( 5t-b )

This item controls the width to regard a weight value as a stable value. When the fluctuation per second is less than the parameter, the balance displays the stabilization indicator and outputs the data. The parameter influences the “Auto print mode”

5t-b 0 This parameter is for sensitive response of the stabilization indicator. Used

for exact weighing.

5t-b 2 This parameter ignores slight fluctuation of a weight value. Used to prevent

a weight value from drifting due to vibration or drafts.

Note With “Hold function (Hold)” set to “ON (1)”, this item is used to set the stabilization range.

Hold function ( Hold ) (Animal weighing mode)

This function is used to weigh a moving object such as an animal. When the weight data is over the weighing range from zero and the display fluctuation is within the stabilization range for a fixed period of averaging time, the processing indicator illuminates and the balance displays the average weight of the animal. When the animal is removed from the weighing pan, the display returns to zero automatically. This function is available only when the hold function parameter is set to “1” (the animal mode indicator ANIMAL illuminates) and any weighing unit other than the counting mode is selected.

The stabilization range and averaging time are set in “Condition (Cond)” and “Stability band width (5t-b)”.

Weighing range Averaging time FX-120 i /200 i / 300 i FX-1200 i /2000 i / 3000 i Cond 2

0.200 g or over Cond 0 5t-b 0

2.00 g or over Cond 1 5t-b 1

2 seconds Faster 4 seconds | 8 seconds More accurate

Stabilization range

5t-b 2

Lesser

Greater

Zero tracking ( trc )

This function tracks zero point drift caused by changes in the environment and stabilizes the zero point. When the weight data is only a few digits, turn the function off for accurate weighing.

Note Digit, when used for the FX-i series balance, indicates a unit of minimum weighing value.

trc 0 The tracking function is not used. Used for weighing a very light sample. trc 1 The tracking function is used. Normal zero tracking. trc 2 The tracking function is used. Strong zero tracking. trc 3 The tracking function is used. Very strong zero tracking.

Display refresh rate ( 5pd )

Period to refresh the display. This parameter influences “Stream mode” along with “Baud rate” and “Data output pause”

Note This item is selected automatically when the response rate is changed.

Decimal point ( pnt )

The decimal point format can be selected.

Auto display-ON ( p-on )

When the AC adapter is connected, the display is automatically turned on in the weighing mode, without the ON:OFF key operation. Used when the balance is built into an automated system. 30-minute warm up is necessary for accurate weighing.

Auto display-OFF ( poff )

When the AC adapter is connected and no operation is performed (inactivity state) for 10 minutes, the display is automatically turned off and the standby indicator is illuminated.

9-5 Description of the Item “Data Output Mode”

The parameter setting of the “Data output mode ( prt )” applies to the performance when the data is transmitted using the RS-232C serial interface.

Key mode

When the PRINT key is pressed with the stabilization indictor turned on, the balance outputs the weight data and the display blinks one time.

Required setting dout prt 0 Key mode

Auto print modes A and B

When the displayed value is stable and the conditions of “Auto print polarity”, “Auto print difference” and reference value are met, the balance outputs the weight data. When the PRINT key is pressed with the stabilization indictor turned on, the balance outputs the data and the display blinks one time.

Mode A: Required setting dout prt 1 Auto print mode A (reference = zero)

dout ap-p Auto print polarity dout ap-b Auto print difference

Example “For outputting the weight value each time a sample is added, with

“ar-d” set to “1” (to adjust zero after the data is output).”

Mode B: Required setting dout prt 2 Auto print mode B (

dout ap-p Auto print polarity dout ap-b Auto print difference

reference = last stable value

)

Example “For outputting the weight value while a sample is added.”

Stream mode

The balance outputs the weight data continuously regardless of the display condition. The display does not blink in this mode.

Required setting dout prt 3 Stream mode ba5fnc 5pd Display refresh rate 5if bp5 Baud rate

Example “For monitoring data on a computer”

Caution

The balance may not transmit the data completely at the specified refresh rate and baud rate. Set the baud rate higher.

Key mode B

When the PRINT key is pressed, the balance outputs the weight data, regardless of the display condition. The display does not blink in this mode.

Key mode C

When the PRINT key is pressed with the stabilization indictor turned on, the balance outputs the weight data. When the stabilization indicator is not on, the balance waits for the indicator to turn on and outputs the data. The balance blinks one time in this mode.

Interval output mode

The weight data is periodically output. When the PRINT key is pressed, the balance starts to output the weight data at a preset interval time. When the PRINT key is pressed again, the balance stops outputting the weight data.

Required setting dout prt 6 Interval output mode

dout int Interval time

Example “For outputting the weight data periodically."

Caution

The balance may not transmit the data completely at the specified interval times and baud rate. Set the baud rate higher.

9-6 Description of the Item “Data Format”

A&D standard format 5if type 0

This format is used when the peripheral equipment can receive the A&D format. If an AD-8121B is used, set the printer to MODE 1 or 2.

 This format consists of fifteen characters excluding the terminator.

 A header of two characters indicates the balance condition.

 The polarity sign is placed before the data with the leading zeros. If the data is zero, the plus

sign is used.

 The unit, consisting of three characters, follows the data.

DP (Dump print) format 5if type 1

This format is used when the peripheral equipment can not receive the A&D format. If an AD-8121B is used, set the printer to MODE 3.

 This format consists of sixteen characters excluding the terminator.

 A header of two characters indicates the balance condition. No overload header is used.

 The polarity sign is placed before the data, with spaces in place of leading zeros, if the data is

not zero or overloaded.

 The unit, consisting of three characters, follows the data.

KF format 5if type 2

This is the Karl-Fischer moisture meter format and is used when the peripheral equipment can only communicate using this format.

 This format consists of fourteen characters excluding the terminator.

 This format has no header characters.

 The polarity sign is placed before the data, with spaces in place of leading zeros, if the data is

not zero or overloaded.

 This format outputs the unit only for a stable value.

MT format 5if type 3

 A header of two characters indicates the balance condition.

 The polarity sign is used only for negative data.

 The weight data uses spaces in place of the leading zeros.

 The character length of this format changes dependent upon the unit

NU (numerical) format 5if type 4

This format outputs only numerical data.

 This format consists of nine characters excluding the terminator.

 The polarity sign is placed before the data with the leading zeros. If the data is zero, the plus

sign is used.

CSV format 5if type 5

 Separates the data of A&D standard format and the unit by a comma (,).

 Outputs the unit even when the data is overloaded.

9-7 Data Format Examples

Note When “Pound Ounce” is selected, the data is output with the unit of ounce (oz).

9-8 Description of the Item “Application Function”

Capacity indicator ( apf 1)

In the weighing mode, the indicator displays the weight data relative to the weighing capacity in percentage. (Zero = 0%, maximum capacity = 100%)

Statistical calculation mode ( apf 2)

The mode statistically calculates the weight data, and displays or outputs the results. For details, refer to “5-4 Statistical Calculation Mode”.

9-9 Comparator Function

The results of the comparison are indicated by HI OK LO on the display.

Operating conditions:  No comparison  Comparison when the weight data is stable or overloaded, excluding “near zero”

 Comparison when the weight data is stable or overloaded, including “near zero”  Continuous comparison, excluding “near zero”  Continuous comparison, including “near zero” To compare, use:  Upper limit value and lower limit value Input method:  Digital input

Note "Near zero" means that the weight value is within ±10 digits of the minimum weighing value. For example, using a FX-3000i in gram mode, the range of ±0.10 g is “near zero”.

For the description of “Comparator (Cp fnc)”, refer to “9-3 Details of the Function Table”.

Setting example

(Continuous comparison, excluding “near zero”, upper limit and lower limit values, digital input)

Selecting a comparator mode

1 Press and hold the SAMPLE key until ba5fnc of the function table is displayed.

2 Press the SAMPLE key several times to display Cp fnc .

3 Press the PRINT key.

4 Press the RE-ZERO key several times to display Cp 3 .

5 Press the PRINT key to store the selected mode.

Entering the upper limit value

6 With Cp Hi displayed, press the PRINT key. The current setting of the upper limit value is

displayed with all the digits blinking.

 When the current setting is not to be changed, press the PRINT or CAL key to proceed to step 7.  When the current setting is to be changed, press the RE-ZERO key. Change the setting

using the following keys.

SAMPLE key To select the digit to change the value. RE-ZERO key To change the value of the digit selected. MODE key To switch the polarity. PRINT key To store the new setting and go to step 7. CAL key To cancel the new setting and go to step 7.

Entering the lower limit value

7 With Cp lo displayed, press the PRINT key. The current setting of the lower limit value is

displayed with all the digits blinking.

 When the current setting is not to be changed, press the PRINT or CAL key to proceed to step 8.  When the current setting is to be changed, press the RE-ZERO key. Change the setting

using the following keys.

SAMPLE key To select the digit to change the value. RE-ZERO key To change the value of the digit selected. MODE key To switch the polarity. PRINT key To store the new setting and go to step 8. CAL key To cancel the new setting and go to step 8.

8 Press the CAL key to exit the comparator function and return to the weighing mode.

10. ID NUMBER AND GLP REPORT

 The ID number is used to identify the balance when Good Laboratory Practice (GLP) is used.

 The ID number is maintained in non-volatile memory even if the AC adapter is removed.

 The GLP output format is selected at “GLP output (info)” of the function table and can be

output to a personal computer or printer using the RS-232C serial interface.

 The GLP output format includes the balance manufacturer, model, serial number, ID number

and space for signature for weight data, and the weight used and results for calibration or calibration test data.

When the AD-8121B is used, the date and time can be printed using the AD-8121B clock and

calendar function. In this case, set the “GLP output ( info )” parameter to “1”.

 The balance can output the following reports for GLP. “Calibration report” of the calibration, using an external weight. “Calibration test report” of the calibration test, using an external weight. “Title block” and “End block” for the weight data.

10-1 Setting the ID Number

1 Press and hold the SAMPLE key until ba5fnc of the function table is displayed.

2 Press the SAMPLE key several times to display id .

3 Press the PRINT key. Set the ID number using the following keys.

SAMPLE key To select the digit to change the value.

RE-ZERO key To set the character of the digit selected. Refer to the display character

set shown below.

PRINT key To store the new ID number and display ap fnc

CAL key To cancel the new ID number and display ap fnc

4 Press the CAL key to return to the weighing mode.

Display character set

10-2 GLP Report

Set the following parameters to output the report.

 To print the report, set the “GLP output ( info )” parameter to “1” and use MODE 3 of the

AD-8121B. For details on using the printer, refer to “14-1 Connection to the AD-8121B Printer”.

If the time and date are not correct, adjust the AD-8121B clock and calendar.

 To output the report to a personal computer using the RS-232C serial interface, set the “GLP

output ( info )” parameter to “2”.

Note

For operational details about calibration and calibration test, refer to “7. CALIBRATION”.

Calibration report using an external weight

When the setting is “info 1”: When the setting is “info 2”:

Calibration test report using an external weight

(Calibration test does not perform calibration.)

When the setting is “info 1”: When the setting is “info 2”:

Title block and end block

When a weight value is recorded as the GLP data, “Title block” and “End block” are inserted at the beginning and at the end of a group of weight values, in the GLP report.

Note

To output the report to an AD-8121B , use MODE 3 of the AD-8121B.

Operation

1 With the weight data displayed, press and hold the PRINT key until S5tart is displayed.

The “Title block” is output.

2 The weight data is output according to the parameter setting of the data output mode.

3 Press and hold the PRINT key until recend is displayed. The “End block” is output.

When the setting is “info 1”: When the setting is “info 2”:

11. UNDERHOOK

The underhook can be used for magnetic materials or density measurement. The built-in underhook is revealed by removing the plastic cap on the bottom of the balance. Use the underhook as shown below.

Bottom of the balance

Underhook

Cap

Caution

Do not apply excessive force to the underhook. When not in use, attach the plastic cap to prevent dust from getting into the balance.

12. PROGRAMMABLE-UNIT

This is a programmable unit conversion function. It multiplies the weight data in grams by an arbitrary coefficient set in the function table and displays the result.

The coefficient must be within the range between the minimum and maximum shown below. If the coefficient set is beyond the range, an error is displayed and the balance returns to the coefficient setting mode, prompting to enter an appropriate value. A coefficient of 1 was set at the factory.

Model Minimum coefficient Maximum coefficient FX-120i /200i /300i FX-1200i /2000i /3000i

0.000001

Operation

1 Press and hold the SAMPLE key until ba5fnc of the function table is displayed.

2 Press the SAMPLE key several times to display mltj .

3 Press the PRINT key. The balance enters the mode to confirm or set the coefficient.

Confirming the coefficient

4 The current coefficient is displayed with the first digit blinking.

 When it is not to be changed, press the CAL key and proceed to step 6.  When it is to be changed, press the RE-ZERO key

and proceed to step 5.

Setting the coefficient

1000

100

5 Set the coefficient using the following keys.

SAMPLE key To select a digit to change the

value. The selected digit blinks. RE-ZERO key To change the value. MODE key To change the decimal point

position. Each time the switch is pressed,

the decimal point position

changes as follows:

PRINT key To store the new setting,

display end and go to step 6. CAL key To cancel the new setting and

go to step 6.

Quitting the operation

6 The balance displays Unit . Press the CAL key to exit the programmable-unit function and

return to the weighing mode.

Using the function

Press the MODE key to select the programmable-unit (no display on the unit section). Perform weighing as described in “5-1 Basic Operation (Gram Mode)”. After weighing, the balance displays the result (weight data in grams x coefficient).

13. RS-232C SERIAL INTERFACE

The balance is a Data Communication Equipment (DCE) device. Connect the balance to a personal computer (DTE) using a straight through cable.

Transmission system : EIA RS-232C (D-Sub 9-pin, female connector) Transmission form : Asynchronous, bi-directional, half duplex Transmission rate :

20 times/second, 10 times/second or 5 times/second (same as data refresh rate)

Data format : Baud rate : 600, 1200, 2400, 4800, 9600, 19200 bps Data bits : 7 or 8 bits Parity : Even, Odd (Data bits 7 bits) None (Data bits 8 bits) Stop bit : 1 bit Code : ASCII

LSB MSB

0123456

Data bits

Start bit

Stop bit

Parity bit

D-Sub 9-pin assignments

Pin No. Signal name Direction Description

2 TXD Output Transmit data

3 RXD Input Receive data

5 SG - Signal ground

6 DSR Output Data set ready

7 RTS Input Request to send

8 CTS Output Clear to send

Signal names of the balance side are the same as the DTE side with TXD and RXD reversed.

No connection

#4-40UNC

RS-232C

-5V to -15V

+5V to +15V

Balance side

Approx.5V

Inside of balance

DCE

TXD

RXD

RTS

CTS

DSR

Computer side

DTE

RXD

TXD

RTS

CTS

DSR

Terminals sample

14. CONNECTION TO PERIPHERAL EQUIPMENT

14-1 Connection to the AD-8121B Printer

Set the following parameters to use the AD-8121B printer.

Example of use AD-8121B mode setting

To print A&D standard format weight data, using the FX-i PRINT key or FX-i auto print mode. (The time and date can be added.)

To print A&D standard format weight data, using the AD-8121B DATA key or AD-8121B built-in timer. (The time and date can be added.)

To print, using the AD-8121B chart printing function. To print the FX- i statistical data. MODE 3 To print GLP output. MODE 3

Class Item and Parameter

prt

dout

Data output

Data output mode

pU5e

Data output pause

bp5

Baud rate

5if

Serial interface

btpr

Data bit, parity bit

Crlf

Terminator

type

Data format

*1 Set appropriate parameters for “

Factory settings

0 0,1,2,4,5 *1 3 0,1,2,4,5 *1

0 0 0 0,1 *2

2 2 2 2

0 0 0 0

0 0 0 1

ap-p

(Auto print polarity)” and “

AD-8121B

MODE 1

AD-8121B

MODE 2

ap-b

(Auto print difference) “ w

auto print mode A or B (prt 1 or 2) is selected.

Set the AD-8121B DIP switch No.3 to ON when unstable data is printed with “prt 4“.

*2 Set 1 when multiple lines are printed in the FX- i statistical calculation mode.

MODE 1

MODE 2

AD-8121B

MODE 3

hen

Notes Refer to "10-2 GLP Report" for print samples.

Settings of AD-8121B DIP switches

MODE

MODE 1

MODE 2

MODE 3

AD-8121B

DIP switch

MODE

1 2 3 4

MODE

1 2 3 4

MODE

1 2 3 4

Print at receiving data. Standard mode, statistical calculation mode

Print by the AD-8121B DATA key operation or AD-8121B built-in timer. Standard mode, interval mode, chart mode

Print at receiving data. Dump print mode

DIP switch No.3 : Handling unstable data ON Print OFF Not printed

Set the DIP switch No.4 to OFF.

MODE

Description

1 2 3 4

14-2 Connection to a Computer

The FX-i series balance can be connected to a personal computer using the RS-232C serial interface. As an option, the FXi –02 USB interface is available to transmit the balance data to a personal computer.

The FX-i series balance is a DCE. Use a straight through cable. If purchasing the RS-232C cable on the market, check the interface connections and type.

D-Sub 9-pin Female connector Inch screw thread

14-3 Using Windows Communication Tools (WinCT)

When Windows is used as an operating system in a personal computer, the WinCT software, that is downloaded from the A&D website, can be used to transmit the weight data to the personal computer. The WinCT has two communication methods: “RsCom” and “RsKey”.

RsCom

 Can transmit commands to control the balance.

 Can make bi-directional communication between the balance and a personal computer using

the RS-232C serial interface.

 Can display or store the data using a text file format. Can also print the data using a printer

connected to the personal computer.

 When several ports of a personal computer have balances connected, can communicate with

each balance simultaneously.

 Can share a personal computer with other application software.

RsKey

 Can transmit the weight data output from the balance directly to other application software

such as Microsoft Excel.

 Can be used with most application software.

Using the WinCT software, the balance can do the following:

1 Analyzing the weight data and the statistics with “RsKey” The weight data can be input directly into an Excel worksheet. Then, Excel can analyze the

data to obtain sum, average, standard deviation, maximum and minimum value, and display them in a graph.

2 Controlling the balance using commands from a personal computer By using “RsCom”, the personal computer sends commands such as “re-zero” or “send weight

data” to the balance and controls the balance.

3 Printing the balance GLP report using your printer The balance GLP report can be printed using a printer connected to the personal computer.

4 Receiving weight data at a certain interval The weight data can be received at a certain interval and data characteristic with elapsed time

can be obtained.

5 Using a personal computer as an external indicator With the “RsKey” test mode function, a personal computer can be used as an external weight

indicator for the balance. (To do this, set the balance data output mode to stream mode.)

15. COMMANDS

15-1 Command List

Note A command has a terminator added, that is specified using the "Terminator (Crlf)" parameter of “Serial interface ( 5if )” in the function table, and is sent to the balance.

Commands to query weight data

C Cancels the S or SIR command. Q Requests the weight data immediately. S Requests the weight data when stabilized. SI Requests the weight data immediately. SIR Requests the weight data continuously.

P Requests the weight data when stabilized.

Note: The “Q” and “SI” commands, the “S” and “

Commands to control the balance

CAL

OFF Turns the display off. ON Turns the display on. P

PRT

SMP

T Tare key Z

?ID Requests the ID number. ?SN Requests the serial number. ?TN Requests the model name. ?PT Requests the tare weight. PT: ∗∗∗∗∗. ∗ g

Note: The “R”, “Z” and “

   

ASCII code 1Bh

Same as the CAL key.

Same as the ON:OFF key

Same as the PRINT key

Same as the RE-ZERO key

Same as the SAMPLE key.

Same as the RE-ZERO key

Same as the MODE key

Changes the tare weight. The unit added is the current weighing unit in A&D standard format.

T” commands behave the same.

P” commands behave the same.

15-2 Acknowledge Code and Error Codes

When the “AK, Error code (erCd)” parameter of “Serial interface ( 5if )” is set to “1”, the balance outputs <AK> code or an error code for each command as follows:

<AK> (06h) Acknowledge in ASCII code.

 When the balance receives a command to request data and can not process it, the balance

transmits an error code (EC, Exx).

When the balance receives a command to request data and can process it, the balance

outputs the data.

 When the balance receives a command to control the balance and can not process it, the

balance transmits an error code (EC, Exx).

When the balance receives a command to control the balance and can process it, the balance

transmits the acknowledge code.

Among commands to control the balance, the following transmit the acknowledge code both

when the balance receives the command and when the balance has accomplished the command. If the command can not be processed properly, the balance transmits an error code (EC, Exx). This error can be released using the CAL command.

CAL command (Calibration command) ON command (Display ON command)

P command (Display ON/OFF command) R command (RE-ZERO command)

R command example

T command example

PT command example

 When a communication error has occurred due to external noise, or a parity error has

occurred due to transmission error, the balance transmits an error code. In this case, send the command again.

15-3 Settings Related to RS-232C

Concerning the RS-232C, the balance has two functions: “Data output ( dout )” and “Serial interface ( 5if )”. Set each function as necessary.

16. MAINTENANCE

 Do not use organic solvents to clean the balance. Clean the balance with a lint free cloth that

is moistened with warm water and a mild detergent.

 Do not disassemble the balance. Contact the local A&D dealer if the balance needs service or

repair.

 Use the original packing material for transportation.

17. TROUBLESHOOTING

17-1 Checking the Balance Performance and Environment

The balance is a precision instrument. When the operating environment or the operating method is

inadequate, correct weighing can not be performed. Place a sample on the pan and remove it, and

repeat this several times. If the balance seems to have a problem with repeatability or to perform

improperly, check as described below. If improper performance persists after checking, contact the

local A&D dealer for repair.

Checking that the balance performs properly

 Check the balance repeatability using an external weight. Be sure to place the weight in the

center of the weighing pan.

 Check the balance repeatability, linearity and calibrated value using external weights with a

known value.

Checking that the operating environment or weighing method is proper

Operating environment

 Is the weighing table solid enough (especially for the FX-120i /200i /300i, the balance with a

minimum weighing value of 0.001 g)?

 Is the balance level? Refer to “3-1 Before Use”.

 Is the operating environment free from vibration and drafts? For the FX-120i /200i /300i, has

the breeze break been installed?

 Is there a strong electrical or magnetic noise source such as a motor near the balance?

Weighing method

 Is the weighing pan installed correctly?

 Is the RE-ZERO key pressed before placing a sample on the weighing pan?

 Is the sample placed in the center of the weighing pan?

 Has the balance been calibrated using an external weight?

 Has the balance been warmed up for 30 minutes before weighing?

Sample and container

 Has the sample absorbed or lost moisture due to the ambient conditions such as temperature

and humidity?

 Has the temperature of the container been allowed to equalize to the ambient temperature?

Refer to “3-2 During Use”.

 Is the sample charged with static electricity? Refer to “3-2 During Use”.

The FX-120i /200i /300i is prone to be charged with static electricity when the relative humidity is low.

 Is the sample of magnetic material such as iron? Caution is required for weighing magnetic

materials. Refer to “3-2 During Use”

17-2 Error Codes

Display Error code Description

EC, E11 Stability error

The balance can not stabilize due to an environmental problem. Prevent vibration, drafts, temperature changes, static electricity and magnetic fields.

Refer to “3. PRECAUTIONS” for details on the operating environment and “6. RESPONSE ADJUSTMENT” about adapting the balance to the environment.

To return to the weighing mode, press the CAL key.

Out of range error

The value entered is beyond the settable range. Re-enter the value.

EC, E20 Calibration weight error

The calibration weight is too heavy. Confirm that the weighing pan is properly installed.

Confirm the calibration weight value. Press the CAL key to return to the weighing mode.

EC, E21 Calibration weight error

The calibration weight is too light. Confirm that the weighing pan is properly installed.

Confirm the calibration weight value. Press the CAL key to return to the weighing mode.

Overload error

A sample beyond the balance weighing capacity has been placed on the pan.

Remove the sample from the pan.

Weighing pan Error

The weight value is too light.

Confirm that the weighing pan is properly installed and calibrate the balance.

Sample mass error

The balance can not store the sample for the counting mode or for the percent mode because it is too light.

Use a sample that is heavier.

Unit mass error

The sample unit mass for the counting mode is too light. Storing and using it for counting will cause a counting error.

Add samples to reach the specified number and press the PRINT key.

Pressing the PRINT key without adding samples will shift the balance to the counting mode. But, to acquire accurate weighing, be sure to add samples.

Display Error code Description

EC, E00 Communications error

A protocol error occurred in communications.

Confirm the format, baud rate and parity.

EC, E01 Undefined command error

An undefined command was received.

Confirm the command.

EC, E02 Not ready

A received command can not be processed.

e.g. The balance received a Q command, but not in the

weighing mode.

e.g. The balance received a Q command while

processing a RE-ZERO command.

Adjust the delay time to transmit a command.

EC, E03 Timeout error

If the timeout parameter is set to “t-Up1”, the balance did not receive the next character of a command within the time limit of one second.

Confirm the communication.

EC, E04 Excess characters error

The balance received excessive characters in a command.

Confirm the command.

EC, E06 Format error

A command includes incorrect data.

e.g. The data is numerically incorrect.

Confirm the command.

EC, E07 Parameter setting error

The received data exceeds the range that the balance can accept.

Confirm the parameter range of the command.

Other errors If the errors described above can not be released or

other errors are displayed, contact the local A&D dealer.

17-3 Asking For Repair

If the balance needs service or repair, contact the local A&D dealer.

The balance is a precision instrument. Use much care when handling the balance and observe the following when transporting the balance.

 Use the original packing material.

 Remove the weighing pan from the main unit

18. OPTIONS

–

Note The FXi-02, FXi-08 and FXi-09 can not be used at the same time.

FXi-02 USB interface (Installed in the balance, Applicable OS: Windows 98 OSR2 or later)

 Used to transmit the balance weight data (numerical

value only) uni-directionally to a personal computer via USB.

 Can transmit the balance weight data (numerical value

only) directly to other application software such as Microsoft Excel, Word and memo pad.

 Driver installation is not necessary.

02Example of use

FXi-08 Ethernet interface

 Used to connect the balance to a LAN.  The "WinCT-Plus" data communication software is

provided as an accessory and can perform the following.

Acquire data from multiple balances connected to a

LAN. Control these balances with commands. Acquire data transmitted from balances.

Example: When pressing the PRINT key of the balance,

data is output and is acquired by the computer. The stored data can be used with Microsoft Excel (if

installed).

FXi-09 Built-in battery unit (Ni-HM rechargeable battery pack)

FXi-10 Small breeze break

08 Example of use

 Provided for FX-120i /200i /300i as standard. Can be used for FX-1200i /2000i /3000i.

FXi-11 Large breeze break

 Breeze break with greater height. Can be used for all models. Convenient when a large beaker

or measuring cylinder is used and requires more height.

AX-FXi-31 Main unit cover

 Main unit protective cover provided as standard.

AD-1683 DC static eliminator

 Used to minimize weighing errors due to static electricity on the material.

AD-8920 Remote display

 Connected to the FX-i series balance using the RS-232C serial interface to display the weight

data away from the balance.

AD-8922 Remote controller

 Connected to the FX-i series balance using the RS-232C serial interface to display the weight

data and to remotely control the balance.

 Analog output and comparator output available as an option to be installed.

AD-8121B Printer

 Compact dot-matrix printer  Statistical function, clock and calendar function, interval

print function, graphic print function, dump print mode

 5 x 7 dots, 16 characters per line  Print paper (AX-PP143, 45 (W) x 50 (L) mm , ø65 mm)  AC adapter or alkaline battery.

19. SPECIFICATIONS

Weighing capacity

Maximum display

Minimum weighing value (1 digit)

Repeatability (Standard deviation)

Linearity

Stabilization time (typical at FAST)

Sensitivity drift (10°C-30°C/50

Operating environment

Display refresh rate

Counting mode

Percent mode

External calibration weight

Weighing pan diameter

F-86°F )

Minimum unit mass

Number of samples

Minimum 100% reference mass

Minimum 100% display

FX-120i FX-200i FX-300iFX-1200iFX-2000iFX-3000

122 g 220 g 320 g 1220 g 2200 g 3200 g

122.084 g 220.084 g 320.084 g 1220.84 g 2200.84 g 3200.84 g

0.001 g 0.01 g

0.002 g

Approx. 1 second

±2 ppm/°C

5°C to 40°C (41°F to 104°F)

85%RH or less (No condensation)

5 times/second, 10 times/second or 20 times/second

0.001 g 0.01 g

5, 10, 25, 50 or 100 pieces

0.100 g 1.00 g

0.01%, 0.1%, 1% (Depends on the reference mass stored.)

100 g 50 g

200 g 100 g

130 mm 150 mm

300 g 200 g 100 g

1000 g

500 g

0.02 g

2000 g 1000 g

3000 g 2000 g 1000 g

Net weight

External dimensions

AC adapter

Power consumption

Interface

Approx. 2.5 kg

193 (W) x 262.5 (D) x 84.5 (H) mm

Confirm that the adapter type is correct for the local voltage and power receptacle type

Approx. 11VA (supplied to the AC adapter)

RS-232C

20. EXTERNAL DIMENSIONS

FX-120i / 200i / 300i

262.5

193

184

115 (* 1)

171.5 (*2)

130(*3)

84.5 85 (*4)

162

*1: Width of the opening when a clear plate is removed *2: Inside dimension *3: Weighing pan diameter *4: Height from the weighing pan up to the cap of the breeze break (Inside dimension) *5: Height of the opening when a clear plate is removed

FX-1200i / 2000i / 3000i

184

168.5

175

81 83.5 (*5)

61.5 194.5

115 (*1)

171.5



(*2)

70.5

262.5

193

150

168.5

84.5

70.5

162

61.5

194.5

Unit: mm

21. TERMS/INDEX

Terms

Stable value The weight data when the stabilization indicator appears.

Environment Ambient conditions such as vibration, drafts, temperature, static electricity and

magnetic fields which affect the weighing operation.

Calibration Adjustment of the balance so that it can weigh accurately.

Output To output the weight data using the RS-232C serial interface.

Zero point A weighing reference point or the zero display. Usually refers to the value

displayed when nothing is on the weighing pan.

Digit Unit of digital resolution. Used for the balance, a unit of minimum weighing value.

Tare To cancel the weight of a container which is not included in the weight data.

Mode Balance operational function.

Re-zero To set the display to zero.

GLP Good Laboratory Practice.

Repeatability Variation in measured values obtained when the same weight is placed and

removed repetitively. Usually expressed as a standard deviation.

e.g. Standard deviation=1 digit: This means that measured values fall within ±1

digit in the frequency of about 68%.

Stabilization time Time required after a sample being placed, until the stabilization indicator

illuminates and the weight data is displayed.

Sensitivity drift An affect that a change in temperature causes to the weight data. Expressed as

temperature coefficient.

e.g. Temperature coefficient = 2 ppm/°C : If a load is 300 g and the temperature

changes by 10°C, the value displayed changes by the following value.

0.0002%/°C x 10°C x 300 g = 6 mg

Index

Keys and symbols

ON/OFF key ..............................8

SAMPLE key .............................8

MODE key .............................8, 9

CAL key .........................8, 24, 26

PRINT key .................................8

RE-ZERO key..................7, 8, 12

Stabilization indicator..............8

Interval output mode active indicator Interval output mode standby indicator

....8

..8

Processing indicator ...............8

CR ..........................................39

LF ...........................................39

Space .....................................39

100% reference mass.........................15

- A -

A&D standard format ....................33, 37

AC adapter ...........................................4

AC adapter ID label ..............................4

ACAI ............................................14

AD-1683 ........................................6, 59

AD-8121B ............................... 44, 48, 59

AD-8920 ............................................59

AD-8922 ............................................59

AK ............................................52

Animal mode indicator ..........................8

ap fnc Application ....................16, 33

ap-b Auto print difference............ 32

apf Application function.......16, 33

ap-p Auto print polarity ..........32, 48

Application ....................................16, 33

Application function ......................16, 33

ar-d at-f

Zero after output .................32

Auto feed ............................32

Auto display-OFF..........................31, 35

Auto display-ON ...........................31, 35

Auto print difference............................32

Auto print mode A.........................32, 36

Auto print mode B.........................32, 36

Auto print polarity................................32

AVE Average ..............................18

Average ................................16, 18, 33

AX-FXi-13 ...........................................59

- B -

ba5fnc Environment display .....11, 31

Baud rate ................................33, 47, 48

beep Beep ...................................31

bep

buzzer.............................31

bep- LO buzzer ...........................31

bep- OK buzzer...........................31

bp5 Baud rate ......................33, 48

Breeze break ..................................4, 58

btpr Data bit, parity bit ..........33, 48

Built-in battery unit..............................58

- C -

Cal e

Calibration weight error.......56

Cal e

Calibration weight error.......56

CAL key ..............................................8

Calibration ......23, 24, 25, 29, 42, 56, 62

Calibration report ..........................25, 42

Calibration test..............................26, 42

Calibration test report ...................27, 42

CanCel ............................................ 18

Capacity indicator .....................8, 33, 40

Clear ............................................18

Coefficient of variation ............16, 18, 33

Command list......................................51

Comparator function ...........................41

Comparator indicators ..........................8

Cond

Condition.......................31, 34

Counting mode ...................................13

Cp Comparator mode ...............31

Cp fnc Cp Hi Cp lo

Comparator.........................31

Upper limit...........................31

Lower limit...........................31

Crlf Terminator.....................33, 48

CSV format ...................................33, 38

CV Coefficient of variation........18

- D -

Data bits ............................................47

Data format.........................................33

Data output mode ...............................32

Data output pause ..............................32

DC static eliminator.............................59

DCE ......................................47, 49

Decimal point .............................. 31, 35

Digit ................................31, 35, 62

Display at start ....................................31

Display refresh rate.......................31, 35

dout Data output .........................32

DP format......................................33, 37

DTE ............................................47

- E -

-e ............................................56

EC, E00 ............................................57

EC, E01 ............................................57

EC, E02 ............................................57

EC, E03 ............................................57

EC, E04 ............................................57

EC, E06 ............................................57

EC, E07 ............................................57

EC, E11 ............................................56

EC, E20 ............................................56

EC, E21 ............................................56

End block ............................................44

erCd Error code ...........................33

error1 ............................................56

error2 ............................................56

Ethernet interface ...............................58

External dimensions .....................60, 61

Hold

Hold function .................31, 34

Hold function.................................31, 34

- I -

ID number .......................................... 42

info

Inhibit ........................................... 28

Initializing the balance........................ 29

int Interval time ........................... 32

Interval output mode .....................32, 37

Interval output mode active indicator ... 8

Interval output mode standby indicator

Interval time ....................................... 32

- K -

Key mode......................................32, 36

Key mode B ..................................32, 36

Key mode C ..................................32, 36

KF format ......................................33, 38

- L -

Leveling foot ........................................ 4

Linearity ........................................... 60

lo ........................................... 56

Lower limit value ................................ 41

GLP output............................. 32

... 8

- F -

FAST ............................................22

Function table .....................................30

FXi-02 ............................................58

FXi-08 ............................................58

FXi-09 ............................................58

FXi-10 ............................................58

FXi-11 ............................................58

- G -

GLP ............................................42

GLP output..................23, 25, 26, 32, 42

Grounding terminal .............................. 4

- H -

- M -

Main unit cover .............................. 4, 59

MAX Maximum ........................... 18

Maximum ................................16, 18, 33

Maximum display ............................... 60

MID. ........................................... 22

MIN Manimum ........................... 18

Minimum ................................16, 18, 33

Minimum 100% reference mass ........ 60

Minimum unit mass............................ 60

Minimum weighing value.................... 60

MODE key ..................................8, 9, 11

MT format .....................................33, 38

- N -

NET indicator ....................................... 8

NU format .....................................33, 38

Number of data.............................16, 33

- O -

ON:OFF key ...................................8, 28

Operating environment .......................60

- P -

Pan support ..........................................4

Parity ............................................47

pcs ............................................13

Percent Mode .....................................15

Permit ............................................28

pnt Decimal point ................31, 35

poff Auto display-OFF..........31, 35

p-on Auto display-ON............31, 35

PRINT key ...................................... 8, 11

Printer ......................................48, 59

Processing indicator .............................8

Programmable unit .............................46

prt Data output mode .........32, 48

pU5e

Data output pause ........32, 48

- R -

R Range ...................................18

Range ................................ 16, 18, 33

Remote controller ...............................59

Remote display...................................59

Repeatability.......................................60

Response indicators .......................8, 22

RE-ZERO key ..................................7, 8

rng Display at start........................31

RS-232C ......................................47, 49

RsCom ............................................ 49

RsKey ............................................49

- S -

SAMPLE key .................................. 8, 11

SD Standard deviation ..............18

Sensitivity drift ....................................60

5if Serial interface....................33

SLOW ............................................22

5pd Display refresh rate......31, 35

Stability band width .............................34

Stabilization indicator ...................... 8, 11

Stabilization time.................................60

Standard deviation ..................16, 18, 33

Standby indicator ..................................8

5taf

Statistical calculation mode Statistical function mode output items

5t-b Stability band width..........31, 34

Stop bit ............................................47

Stream mode ................................32, 36

SUM Sum ....................................18

Sum ................................16, 18, 33

- T -

Tare .......................... 12, 13, 15, 21

Terminator...........................................33

Timeout ............................................33

Title block............................................44

Transmission form ..............................47

Transmission rate ...............................47

Transmission system..........................47

trc Zero tracking.................31, 34

t-Up Timeout...............................33

type Data format ...................33, 48

- U -

Underhook ..........................................45

Units .................................... 8, 9, 11

Upper limit value.................................41

USB interface .....................................58

- W -

Weighing ............................................12

Weighing capacity...............7, 40, 56, 60

Weighing pan........................................4

Weighing pan diameter.......................60

Weighing units ......................................9

WinCT ............................................49

- V -

Zero tracking.......................................35

Statistical function mode output items

.....3, 16, 33, 40

17, 33

.......33

MEMO

3-23-14 Higashi-Ikebukuro, Toshima-ku, Tokyo 170-0013 JAPAN Telephone: [81] (3) 5391-6132 Fax: [81] (3) 5391-6148

http://www.aandd.co.jp/

A&D ENGINEERING, INC.

1555, McCandless Drive, Milpitas, CA. 95035 U.S.A. Telephone: [1] (408) 263-5333 Fax: [1] (408)263-0119

A&D INSTRUMENTS LTD.

Unit 24/26 Blacklands Way, Abingdon Business Park, Abingdon, Oxon OX14 1DY United Kingdom Telephone: [44] (1235) 550420 Fax: [44] (1235) 550485

Große Straße 13 b 22926 Ahrensburg GERMANY Telephone: [49] (0) 4102 459230 Fax:[49] (0) 4102 459231

A&D MERCURY PTY. LTD.

32 Dew Street, Thebarton, South Australia 5031 AUSTRALIA Telephone: [61] (8) 8301-8100 Fax: [61] (8) 8352-7409

A&D KOREA Limited

8th Floor, Manhattan Bldg. 36-2 Yoido-dong, Youngdeungpo-ku, Seoul, KOREA Telephone: [82] (2) 780-4101 Fax: [82] (2) 782-4280

BackCover WM+PD4000058C

A&D FX-i SERIES User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
