Please DO NOT return product to the retail store.
For technical assistance and product return information, please call
Customer Care: 877-221-1252
Mon. - Fri. 8:00 A.M. to 4:45 P.M. (CST)
www.chaneyinstrument.com
LIMITED ONE YEAR WARRANTY
Chaney Instrument Company warrants that all products it manufactures to be of good material and workmanship and to be free of
defects if properly installed and operated for a period of one year from date of purchase. REMEDY FOR BREACH OF THIS
WARRANTY IS EXPRESSLY LIMITED TO REPAIR OR REPLACEMENT OF DEFECTIVE ITEMS. Any product which, under normal use
and service, is proven to breach the warranty contained herein within ONE YEAR from date of sale will, upon examination by
Chaney, and at its sole option, be repaired or replaced by Chaney. In all cases, transportation costs and charges for returned
goods shall be paid for by the purchaser. Chaney hereby disclaims all responsibility for such transportation costs and charges.
This warranty will not be breached, and Chaney will give no credit for products it manufactures which shall have received normal
wear and tear, been damaged, tampered, abused, improperly installed, damaged in shipping, or repaired or altered by others than
authorized representatives of Chaney.
THE ABOVE-DESCRIBED WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, AND ALL
OTHER WARRANTIES ARE HEREBY EXPRESSLY DISCLAIMED, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTY OF
MERCHANTABILITY AND THE IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE. CHANEY EXPRESSLY DISCLAIMS
ALL LIABILITY FOR SPECIAL, CONSEQUENTIAL OR INCIDENTAL DAMAGES, WHETHER ARISING IN TORT OR BY CONTRACT FROM
ANY BREACH OF THIS WARRANTY. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. CHANEY FURTHER DISCLAIMS
ALL LIABILITY FROM PERSONAL INJURY RELATING TO ITS PRODUCTS TO THE EXTENT PERMITTED BY LAW. BY ACCEPTANCE
OF ANY OF CHANEY’S EQUIPMENT OR PRODUCTS, THE PURCHASER ASSUMES ALL LIABILITY FOR THE CONSEQUENCES
ARISING FROM THEIR USE OR MISUSE. NO PERSON, FIRM OR CORPORATION IS AUTHORIZED TO ASSUME FOR CHANEY ANY
OTHER LIABILITY IN CONNECTION WITH THE SALE OF ITS PRODUCTS. FURTHERMORE, NO PERSON, FIRM OR CORPORATION IS
AUTHORIZED TO MODIFY OR WAIVE THE TERMS OF THIS PARAGRAPH, AND THE PRECEDING PARAGRAPH, UNLESS DONE IN
WRITING AND SIGNED BY A DULY AUTHORIZED AGENT OF CHANEY. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND
YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
For in-warranty repair, please contact:
Customer Care Department
Chaney Instrument Company
965 Wells Street
Lake Geneva, WI 53147
Chaney Customer Care
877-221-1252
Mon-Fri 8:00 a.m. to 4:45 p.m. CST
www.chaneyinstrument.com
INST - 00823 102308
Forecaster
with Wireless Thermometer
#00823
Instruction Manual
Package Contents:
(A) Main Unit
(B) Wireless Sensor
(1) Hardware Bag
(1) Instruction Manual
What You Need:
• Philips Screwdriver
• (4) AA batteries
A. Main Unit B. Wireless Sensor
Thank You for purchasing this ACURITE® product. Please read this manual in it’s
entirety to fully enjoy the benefits and features of this product. Please keep this
manual for future reference.
NOTE: A clear film is applied to the LCD at the factory that must be removed prior
to using this product. Locate the clear tab and simply peel to remove.
1 • OVERVIEW OF FEATURES
-see “Install Batteries”
on page 2
This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions:
1- This device may NOT cause harmful interference, and
2- This device must accept any interference received, including
interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, There is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user authority to operate the
equipment.
Patent numbers: 5,978,738; 6,076,044; 6,597,990
Maximum
& Minimum
Records
Maximum
& Minimum
Records
Future Weather
Forecast with
Learning Mode
Outdoor Temperature Trend
Outdoor Temperature
Indoor Temperature Trend
Indoor Temperature
- 1 -
2 • SETUP
3 • PLACEMENT
Install Batteries
NOTE: Install all batteries in both
units within a 6 minute period to
ensure proper wireless functionality.
A. Wireless Sensor
Remove the battery
compartment cover and
install 2 fresh “AA”
batteries as shown here.
Always install batteries
into the wireless sensor
FIRST to ensure proper
wireless synchronization
with the main unit.
B. Main Unit
Remove the battery
compartment cover and
install 2 fresh “AA”
batteries as shown here.
40
REMOVE
BATTERY
COMPARTMENT
COVER
Extended periods of cold temperatures ( below -4ºF / -20ºC )
can cause alkaline batteries to function improperly. This will
cause the outdoor wireless sensor to stop transmitting
temperature readings. Use lithium batteries in these low
temperature conditions to ensure continued operation for
wireless sensors placed outdoors.
REMOVE
BATTERY
COMPARTMENT
COVER
MIN
RE-SYNCºC/ºF
MAX
INSTALL
2 “AA”
BATTERIES
Now that setup is complete, you must choose a location to place the wireless
sensor and the main unit. The wireless sensor MUST be placed less than 100
feet away from the main unit.
This wireless thermometer uses radio frequency for communication, which is
susceptible to interference from other electronic devices and large metallic
items or thick walls. Always place both units at least 3 feet away from
appliances ( TV, microwave, radios, etc. ) or objects ( large metal surfaces, thick
stone walls, etc. ) that may interfere with the wireless communication.
TV
3
Placement of Main Unit
Place the main unit in a dry area free of dirt and dust. To help ensure
an accurate indoor temperature measurement, be sure to place the
main unit out of direct sunlight, and away from any heat sources or
vents in your home.
There are 2 placement options for the main unit. You may hang the
main unit on a wall using the integrated hang hole. Alternatively, you
may place the main unit on a table top or other flat surface.
Basic Setup is Now Complete
The wireless sensor will soon send a signal to the main unit and the two
units will be synchronized. The wireless sensor features a red light on the
front which will illuminate briefly once a minute to indicate it is sending a
signal. It may take a few minutes for synchronization to be complete. If both
or one of the units appear to be functioning improperly, refer to the
troubleshooting section in this manual.
Placement of Sensor
The wireless sensor MUST BE PLACED OUTDOORS to observe
outdoor temperatures and relay the outdoor temperature to the main
unit display. The wireless sensor must be placed less than 100 feet
from the main unit.
The wireless sensor is water resistant and is designed for outdoor
use. However, to extend the life of the product, place the wireless
sensor in an area protected from direct weather elements. To ensure
an accurate outdoor temperature measurement, be sure the wireless
sensor is placed out of direct sunlight and away from any heat
sources.
- 3 -- 2 -
4 • OPERATION
5 • TROUBLESHOOT I N G
After the main unit and the wireless sensor are both powered on and wirelessly
synchronized, no further input is required. If you have problems receiving the
outdoor temperature, please refer to the troubleshooting section of this manual.
A
14 Day Learning Mode
This weather station has a patent pending
fourteen day learning mode calibration process.
During this learning mode, the weather station
A
B
D
will make altitude calculations that may affect
the accuracy of the forecast icon. After the initial
14 day learning period, the forecast feature will
be ready for superior operation.
C
B
C
C
Minimum/Maximum Recorded Temperatures
The main unit has a memory function for storing minimum and maximum recorded indoor
and outdoor temperatures. You may view the MIN and MAX recorded temperatures by
pressing the “MIN/MAX” button on the back of the main unit.
D
Forecast Icon
This feature gives you the predicted weather
forecast for the next 12 to 24 hours based on an
advanced algorithm that includes barometric
pressure and temperature. This weather station
will provide the most accurate forecast that a
single station weather instrument can provide.
This product features a low power wireless signal, so it does not interfere
with other wireless devices in your location. Occasionally, there will be a
temporary disconnection to the wireless sensor. In most cases, the
temperature will show again if the main unit and wireless temperature
sensor are able to re-connect automatically. If the disconnection lasts longer
than a few hours, refer to this troubleshooting guide.
Problem
Bad Temperature
Reception
FLASHING TEMPERATURE
Relocate the main unit and/or the wireless
sensor. Both units must be within 100 feet
from each other. Make sure both units are
placed at least 3 feet from other electronic
appliances and devices that may interfere
with the wireless communication (such as
TV’s, microwaves, computers etc).
You may need to press the “RE-SYNC”
button on the back of the main unit.
NOTE: It may take up to 20 minutes for the
main unit to re-synchronize with the sensor
when batteries are replaced.
Possible Solutions
D
Trend Indicator Icons
The main unit features arrow icons for indicating a falling, steady or rising temperature.
This feature is shown for the outdoor and indoor temperatures.
E
Re-Synchronize Wireless Signal
This weather station features a button for
C
F
MIN
MAX
E
RE-SYNCºC/ºF
re-synchronizing the wireless signal with the
outdoor temperature sensor. Press this button to
attempt to re-synchronize in the event you lose
connection with the outdoor sensor due to
interference or battery changes.
F
ºC/ºF Selection
Press this button to switch between ºC or ºF
temperature scale selections.
Main Unit
Make certain that the batteries are installed
correctly. The batteries may need replacing.
Display Not Working
If none of the above solutions resolve the
problem, you may need to reset both units
by removing and re-installing the batteries
in both unit.
Extended periods of cold temperatures ( below -4ºF / -20ºC )
40
can cause alkaline batteries to function improperly. This will
cause the outdoor wireless sensor to stop transmitting
temperature readings. Use lithium batteries in these low
temperature conditions to ensure continued operation for
wireless sensors placed outdoors.
Product Registration
To receive product information, register
your product online. It’s quick and easy!
Log on to http://www.chaneyinstrument.com/product_reg.htm
- 5 -- 4 -
5 • PRODUCT S P E C I F I C AT I O N S
Measurement Ranges
Temperature
Main Unit: 32ºF to 122ºF / 0ºC to 50ºC
Wireless Sensor: -40ºF to 158ºF / -40ºC to 70ºC
Specifications
Power Requirements
Main Unit: 2 x “AA” alkaline or lithium batteries
Wireless Sensor: 2 x “AA” alkaline or lithium batteries
Wireless Communication
Radio Frequency: 433 mhz
Transmission Intervals: every 16 seconds
- 6 -
