Acu-Rite 2007 User Manual

Instruction Manual

Weather Station

model 02007

CONTENTS

Unpacking Instructions ........... 2

Package Contents .................. 2

Product Registration ............... 2

Features & Benets: Sensor ..... 2

Features & Benets: Display.. .. 3

Setup .................................... 6

Sensor Setup ......................... 6

Display Setup ........................ 7

Setup Preferences .................. 8

Intelli-Time Clock .................... 8

Backlight Settings ................... 9

Placement Guidelines ............10

Using the Weather Station ..... 11

Troubleshooting ....................12

Care & Maintenance .............13

Replace Intelli-Time® Battery

Calibration ...........................14

Specications ........................15

FCC Information ...................15

Customer Support ................. 16

Warranty..............................16

....14

Questions? Contact Customer Support at

(877) 221-1252 or visit www.AcuRite.com.

SAVE THIS MANUAL FOR FUTURE REFERENCE.

Congratulations on your new AcuRite product. To ensure the best possible product performance, please read this manual in its entirety

and retain it for future reference.

Unpacking Instructions

Remove the protective lm that is applied to the LCD screen prior to using this product. Locate the tab and peel off to remove.

Package Contents

1. Display unit

2. Outdoor sensor

3. Power adapter

4. Instruction Manual

PRODUCT MUST BE REGISTERED

IMPORTANT

PRODUCT REGISTRATION

to receive 1 year

warranty protection

www.AcuRite.com

TO RECEIVE WARRANTY SERVICE

►

Features & Benets

OUTDOOR SENSOR

1. Integrated Hanger For easy placement.

2. Wireless Signal Indicator Flashes when data is being

sent to the display unit.

3. Battery Compartment

4. A-B-C Switch

ID code that must match display’s A-B-C switch to ensure units synchronize.

5. Battery Compartment Cover

Features & Benets

10 118 9 16

151412

BACK OF DISPLAY UNIT

6. A-B-C Switch

ID code that must match sensor’s A-B-C switch to ensure units synchronize.

7. Battery Compartment

8. RESET Button

Full reset to factory defaults.

9. Integrated Hang Hole

for easy mounting.

10. GEO Button

Set geographic region preference.

11. ZONE Button

Set time zone preference.

12. Plug-in for Power Adapter

13. Battery Compartment Cover

(not shown)

FRONT OF DISPLAY UNIT

14. HISTORY CHART Mode

Press to toggle between pressure,

outdoor temperature or outdoor

humidity on History Chart. Press and hold for 4 seconds to enter auto-cycle

mode (5 second rotation).

15. ”T”, ” ” & ”V” Buttons

for setup preferences.

16. Backlight Button

(top of display unit)

Features & Benets

282931 30 27 26 25

5 6

7 8

23 22 21

19 18

12 14 1513 16

DISPLAY UNIT

1. Day of the Week

2. Current Outdoor Temperature

Arrow icon indicates direction

temperature is trending.

3. Outdoor High Temperature Record

Indicates highest outdoor temperature recorded since midnight.

4. Outdoor Low Temperature Record

Indicates lowest outdoor temperature recorded since midnight.

5. Current Outdoor Humidity

Arrow icon indicates direction humidity is trending.

6. Outdoor High Humidity Record

Indicates highest outdoor humidity recorded since midnight.

7. Outdoor Low Humidity Record

Indicates lowest outdoor humidity recorded since midnight.

8. Outdoor Sensor Signal Strength

9. Low Sensor Battery Indicator

10. Forecasted High Temperature

11. Forecasted Low Temperature

12. Up to 4 Hour Weather Forecast

Precision Forecasting combines regional trends with data from your outdoor sensor to generate your personal forecast.

13. GEO SET Icon

Flashes to indicate Geo Zone setup

mode.

14. Geographic Region Selection

for setup preferences.

15. 4 to 8 Hour Weather Forecast

16. 8 to 12 Hour Weather Forecast

17. Barometric Pressure

Arrow icon indicates direction pressure is trending.

18. Indoor High Humidity Record

Indicates highest indoor humidity recorded since midnight.

19. Indoor Low Humidity Record

Indicates lowest indoor humidity recorded since midnight.

20. Current Indoor Humidity

Arrow icon indicates direction

humidity is trending.

21. Multi-Variable History Chart

Displays the past 12 hours of data for pressure, outdoor temperature or outdoor humidity.

22. Indoor High Temperature Record

Indicates highest indoor temperature recorded since midnight.

23. Indoor Low Temperature Record

Indicates lowest indoor temperature recorded since midnight.

24. Current Indoor Temperature

Arrow icon indicates direction

temperature is trending.

25. Date

26. SET Icon

Flashes to indicate setup mode.

27. Display Unit Low Battery Indicator

28. Intelli-Time® Clock

29. Auto-Cycle Mode Indicator

30. AUTO DIM Indicator

31. Time Zone & Daylight Saving Time

for setup preferences, shown only

during setup.

SETUP

Sensor Setup

Set the A-B-C Switch

The A-B-C switch is located inside the battery compartment. It can be set to A, B or C. However, you must select the same letter choices for both the sensor and the display unit in order for the units to synchronize.

Install or Replace Batteries

AcuRite recommends high quality alkaline or lithium batteries in the outdoor sensor for the best product performance. Heavy duty or rechargeable batteries are not

recommended.

The sensor requires lithium

batteries in low temperature conditions. Cold temperatures can cause alkaline batteries to function improperly. Use lithium batteries in the sensor for temperatures below -4ºF / -20ºC.

1. Slide off the battery compartment cover. Take note of the A-B-C switch setting inside the battery compartment for display unit setup.

2. Insert 2 x AA batteries into the battery compartment, as shown. Follow the polarity (+/-) diagram in the battery

compartment.

3. Replace the battery cover.

A-B-C Switch

set to match display unit

A B C

Install Batteries

2 AA batteries

+ 14 hidden pages
