Zadro Digital Imaging
Camera Wand
User Manual
Innovative Ideas That Make Life Easier
™
Read these instructions before use.
Model No.: DICW01
Congratulations on purchasing the Zadro Digital Imaging Camera
Wand which can be used to capture photos or video to easily examine
your skin and body in hard or impossible to see places. View and
document your health concerns. Save those images on your computer
for future comparison of shape, size and color.
Use Zadro Digital Imaging Camera Wand to magnify small objects or
text and see them on the computer screen allowing for easier reading
or viewing.
Product Features and Function:
The Zadro Digital Imaging Camera Wand can be used to view images
and easily capture pictures or video on your computer screen with
one-click media capturing.
With a comfortable hand held design, the camera wand has four LED
lights built into the wand tip illuminating the subject for optimal viewing.
The on/off light switch and light intensity adjustment wheel are located
on the camera cord. It is powered directly by the computer through
the USB port.
Included in Digital Imaging Camera Wand Package:
Digital Imaging Camera Wand, Model: DICW01
Stand for wand tip
Mini-CD for software installation
Applications:
Note:
Use of the Digital Imaging Camera Wand is not a substitute for a
visit or consultation with your doctor. This device is not intended
for medical use.
• Inspection of body surfaces such as:
- Skin or epidermis including moles or blemishes
- Hair, scalp, back, or hard to view areas
- Intra-oral, gums, throat or teeth
- Bottom of feet for easier viewing
• Any healthcare concerns can be captured in a photo and saved on
your computer. The grid scale in the camera wand can be used when
picture is taken to help estimate size. Pictures can either be emailed
to your physician or saved for comparison over time for any changes
in shape, size or color.
• Magnifying feature in camera allows you to better view and
manipulate difcult to see objects, such as a sliver embedded under
skin.
• Easier to inspect between narrow spaces as focal distance from tip
of camera wand is about 1” or 2 cms. and magnifying feature allows
better viewing into hard to see areas.
• Easier to work with small items when doing arts & craft work.
• Easier when working with small parts in work applications which can
be viewed for assembly. Pictures or video can be captured on the
computer if discrepancies need to be documented.
• Magnies small writing so that it can be easily read on computer
screen. Perfect for prescription bottles, serial numbers, or any small text.
Installing Software:
The Digital Imaging Camera Wand is designed for computer interface
compatible with USB 2.0.
1. Plug the USB cable on the Digital Imaging Camera Wand into the
computer USB port.
2. Place the mini CD included with the camera wand into the CD-ROM
drive on the computer.
3. Click the install button to launch the Installation Wizard. Follow the
directions selecting “next” and “continue” to complete the installation.
Note: The following computer screen seen below may appear. Click
“Continue Anyway”.
4. Follow the computer installation steps, which are completed by
clicking “Finish”.
How To Use:
1. After the computer program for the Digital Imaging Camera Wand
has been installed, the “Imaging Wand” will appear as a shortcut on
your desktop, double click the imaging wand icon or open the
program Imaging Wand from ZHS Imaging Wand in your start menu.
2. Place the removable stand provided onto the camera wand so that
a xed distance from the object can be obtained when using.
Light Adjustment
Wheel
Capture Button
LED Lights
Camera
Removable Stand
g. 1-1
3. Turn light adjustment wheel on cable until light quality is optimal
for viewing.
4. To take a picture with the Digital Imaging Camera Wand, obtain the
desired image on your computer screen, then either click the capture
button on the camera wand (g. 1.1) or from the “Capture(R)” drop
down menu, click “Still Image Capture” (g.1-2).
5. After you take the picture, the “Save As” menu will pop up on your
computer screen so you can indicate where to store the image.
6. To designate the size of the image, click on “Capture(R)” from the
menu options. Then click on “Still Capture Size” which ranges from
2M to 20M. A smaller size le (2M) will give you a smaller picture
than a larger size le (20M).
g. 1-2
7. To take videos, click on Capture(R) menu bar. Then click on “Start
Capture(S)” from the pull down menu. The video will record until
“Stop Capture(S)” is clicked or for maximum of 30 seconds (default).
To change the default record time, click on the “Record Time
Limit(L)” and indicate record time.
To designate a location on your computer to store video les, click the
“File(F)” from the menu bar, click on “Set Capture File Folder...(S)”.
8. To change options on how pictures are taken, click on the
“Options(O)” menu, then click on the “Video Capture Filter” then on
general setting. This will give you the Properties page. (g.2-1)
• If you want to ip a picture, you can check “horizontal ip” or “vertical
ip”. (g.2-1)
g. 2-1
9. If you want a grid to show on the picture to estimate size and to be
able to track changes in size over time, then click on “scale”. (g. 2-2)
g. 2-2
Troubleshooting:
• If you see the webcam view on the computer, then you may need to
temporarily disable your webcam or video camera in order for the
Digital Imaging Camera Wand to take priority.
• If your computer screen is black and you don’t see any images, you
will need to do the following:
- On the menu bar, go to “Options(O)”, and make sure
“Preview(P)” is checked.
Note – If you don’t have preview checked, you will not see an image
on the screen.
• If you receive an error while installing the software notifying you that
this product has not passed Windows logo testing, press “Continue
Anyway” to complete the installation in order to use your digital
imaging camera wand.
Specications:
Sensor: BW101V (VGA), BW101S (2M)
Lens: 4P 3M resolution FF lens,
Cover Lens: 0.7 mm optical lens with lm coating
Frame Rate: VGA mode 30f/s 600 Lux
Light source: 4 white LED lights
Brightness Control: on/off, auto w/b by software
Zoom: Sequence mode digital zoom
Interface: USB 2.0 STD
Operating System: Win98, XP, Vista & Win 7
Snap: Hardware & Software available
Unit size: 8.25” L x 1.25” W x 1.5” H or
21 cm L x 3.5 cm W x 4 cm H
Net Weight: 100 +/- 1 g
Power Supply: 5V (USB port)
Power Consumption: 60mA
Cable: USB 2.0 cable, 200cm
Cleaning and Maintenance:
active forever
• Keep the Digital Imaging Camera Wand clean and dry after use.
• If necessary, clean the wand before and after use. The wand is
water resistant but it should not be soaked in water. It should be
cleaned with a damp cotton cloth or with cotton swabs. Under no
circumstances should abrasive cleaning products be used.
• The lens is made of high transmission glass coating. Please use
professional lens cleaning paper or soft cloth to avoid lens surface
scratching.
Caution:
• Avoid extreme temperatures, exposure to direct sunlight or excessive
humidity.
• The camera lens is located on the tip of the camera wand. Do not
• The warranty is voided if the camera wand is disassembled. Do not
take the device apart.
Warranty:
90 day limited warranty against defects in material and workmanship at
the time of original purchase by the consumer.
Thank you for your purchase!
