ACTi PCDK-0001 Installation Guide
PCDK Camera Demo Kit
Product Manual
Ver. 2013/07/03
www.acti.com
User Manual
Table of Contents
Precautions ............................................................................. 3
Safety Instructions ........................................................................... 4
What is the Camera Demo Kit? ............................................. 5
What’s in the Box? ................................................................. 6
How to Prepare for a Demo? ................................................. 8
Must Have’s ....................................................................................... 8
Optional Items ................................................................................... 8
How to Use the Demo Kit? ..................................................... 9
Step 1: Open the Demo Kit ................................ ............................... 9
Step 2: Mount the Accessories ...................................................... 10
Step 3: Attach the Mount ................................................................ 13
Step 4: Install the Camera .............................................................. 15
Using PMAX-0110 ........................................................................ 15
Using PMAX-0101 ....................................................................... 16
Step 5: Connect the PoE Injector .................................................. 18
Step 6: Configure the Notebook for Demo ................................... 19
Step 7: Do the Demo ....................................................................... 20
Step 8: Repack the Demo Kit ......................................................... 22
2
www.acti.com
User Manual
Precautions
Read these instructions
You should read all the safety and operating instructions before using this product.
Heed all warnings
You must adhere to all the warnings on the product and in the instruction manual. Failure to
follow the safety instruction given may directly endanger people, cause damage to the system
or to other equipment.
Servicing
Do not attempt to service this product yourself. Refer all servicing to qualified service
personnel.
Trademarks
All names used in this manual are probably registered trademarks of respective companies.
Liability
Every reasonable care has been taken during the writing of this manual. Please inform your
local office if you find any inaccuracies or omissions. We cannot be held responsible for any
typographical or technical errors and reserve the right to make changes to the product and
manuals without prior notice.
On Warranty
All mounting accessories and the PoE injector in the demo kit have a warranty of one (1) year.
The travel suitcase is not covered under warranty.
3
www.acti.com
User Manual
Safety Instructions
Cleaning
Disconnect the built-in power injector in this product from the power supply before cleaning.
Attachments
Do not use attachments not recommended by the manufacturer.
Water and Moisture
Do not store this product near water, for example, near a bathtub, washbowl, kitchen sink, or
laundry tub, in a wet basement, or near a swimming pool and the like.
Servicing
Do not attempt to service this product yourself. Refer all servicing to qualified service
personnel.
Damage Requiring service
Disconnect the built-in power injector from the power supply and the camera immediately and
refer servicing to qualified service personnel under the following conditions.
1) When the power-supply cord or plug is damaged.
2) If liquid has been spilled, or objects have fallen into the built-in power injector.
3) If the product has been directly exposed to rain or water.
4
www.acti.com
Ceiling Mount Installation
Wall Mount Installation
User Manual
What is the Camera Demo Kit?
The Camera Demo Kit is a portable heavy duty travel suitcase with built-in demo stand and
related accessories for the purpose of doing a quick and convenient demonstration of the best
features of PTZ, hemispheric or dome cameras.
The Camera Demo Kit makes it possible to simulate both ceiling and wall installations right on
the desk.
5
www.acti.com
User Manual
Travel Suitcase
Gooseneck Mount
Extension Tube
PMAX-0101 Mount Kit
PMAX-0110 Mount Kit
Universal Plug Converter
Ethernet Cable
(Male-to-Male) x 2
Ethernet Cable “Pigtail”
(Male-to-Female) x 3
Key x 6
* (1) cable pre-installed on
the PoE injector
* (1) cable pre-installed on
the Gooseneck
* (1) cable pre-installed on
the PoE injector
Mount Base
PoE Injector
Power Cord
* Comes built-in in the demo
kit base
* Comes built-in in with the
mount base
* Comes pre-installed on the
PoE injector
What’s in the Box?
6
www.acti.com
Screw Pack x 6
For Mount Kit
For Extension Tube
For Use with PMAX-0110
For Use with PMAX-0101
For Use with PMAX-0101
For Use with PMAX-0101
User Manual
7
