ACME CamOne Gravity Air 2D Gimbal User guide

CamOne Gravity Air 2D Gimbal
Manual
This manual is available here: www.CamOneTec.com/gimbal
"FlyCamOne" and „CamOne” are registered trademarks of ACME the game company GmbH, Germany © copyright 2014 ACME the game company GmbH This user manual is protected by international copyright laws. No part of this manual may be reproduced without the prior written permission of ACME the game company GmbH in any form or by any means, electronic or mechanical, including Photocopying, recording or storing in any information storage and retrieval system, reproduced, distributed, translated, or transmitted.
Safety advice
SERVICE & SUPPORT
WARNING:
ACME the game company GmbH PLEASE NOTE THE FOLLOWING ADVICES TO AVOID SHOCKS OR DAMAGES ON THE PRODUCT:
- DON’T USE THE PRODUCT WHEN RAINING, OR AT WET PLACES
- KEEP THE DEVICE AWAY FROM WATER
- ONLY USE ORIGINAL SPARE PARTS
Tel: +49 2944 9738 30
service@camonetec.com DO NOT DISMANTLE THE DEVICE. INSIDE ARE NO PARTS THAT CAN BE REPAIRED BY THE USER. THE
http://www.camonetec.com SERVICE SHALL BE PERFORMED BY THE SUPPLIER OR PRODUCER.
Information on the contained LiPo- Battery
Risk of fire, explosions and
Attention If a battery is incorrectly replaced, there is danger of explosion. Replace the battery only with the same manufacturer's recommended battery or an equivalent type. Dispose of used batteries according to the manufacturer's instructions.
CE Declaration
We hereby declare that this model meets the essential requirements and other relevant provisions of Directive 2004/108/EC. A copy of the Declaration of Conformity can be obtained at the above address.
This product contains a LiPo- battery. Bring used batteries to a designated collection point..
burns. Do not dismantle the battery. Do not exceed the below quoted temperature and do not burn the battery.
LiPo-Battery <50°C
WEEE Reg. Nr.: DE64989527
Information for Users on Disposal of electrical and electronic equipment
According to the company principles of ACME the game company GmbH high-quality reusable components have been installed in this product. This symbol on the products and / or accompanying documents means that the product must be disposed of separately at the end of life from household waste. Bring these products, even the battery for proper and environmentally friendly disposal of your nearest collection (or recycling).
Boikweg 24
33129 Delbrück
Germany
or
2
Content
Please check the completeness before using the product!
Gimbal Camerabail 2x Small parts, screws etc.
Connection cables 2x Mountingbail Bellows 8x
Retaining bracket 2x Mounting plate big Mounting plate small
Required tool
Allen 1,5 + 2,0mm Screwdriver
Important note!
More information, adjustments and tips are available 0n the CamOneTec webpage (http://www.CamOneTec.com).
Please strictly follow this manual to mount this device!
3
Index
Safety advice……..………………...……………………………………………………………………………………..2
Content / Required components............………………………………….………………….….………………………3
Important notes....…………………………………………………………………………………… ………….…….…..3
Index....................…………………………………………………………………………………………………….……4
Disclaimer and warnings.......................…………..………………...…………………………………….…………….4
Connection / Mounting advice..……………………………….……………………………………………………….…5 Mounting………...…………………………………………..……………………….……………………………….…….5 Cable connection…………………………………………………………………………………… ……………..……...7
First use....................…………………………..………………………………………………………………………….7
Setting the tilt position.........………………………………………………………………………..……………………..8
Technical Details………………...………………….……………………...……………………………………………...9
Warranty............................……………………………………………………………………….……………………..11
Disclaimer and warnings
Read these instructions before commissioning and use of the article and its components! With the start of the article, you agree to the terms of the disclaimer and agree to the instructions.
Assemble the items according to the instructions. Any changes to this or uses of third-party products / spare parts can cause damage. This excludes the acquisition of warranty claims! The article is already in a functional state after delivery. Take your time before you start. There is no responsibility for damage or injury from the manufacturer, importer or distributor acquired, resulting from the use of the product.
Make sure prior to attachment to your flight model which can optionally consist requirements and recommendations of the manufacturer for the use of gimbal system.
Operating voltage 7.0V -17.0V (2-3S LiPo recommended) Use only with inserted camera! Outer influences while operation may damage the Gimbal! Please note that the flight time of your model decreases as soon as you connect a Gimbal and further FPV- equipment!
When using video transmitters, make sure that its connection cables do not interfer the Gimbal.
4
