Acer C738T, CB5-132T User Manual

User’s Manual

2 -

Note

Important

Acer Chromebook R 11

Covers: CB5-132T / C738T

This revision: August 2015

1. Ensure you are connected to the Internet.

2. Open www.acer.com and select your country.

3. Select Support > REGISTER A PRODUCT.

4. Sign up for an Acer ID or sign in if you already have an Acer ID.

Register your Acer product

After we receive your product registration, you will be sent a confirmation email with important data. Keep this email in a safe place.

Manage your registered products

Once you have completed the registration process, you can log onto account.acer.com using your Acer ID and password to see and manage all your registered products.

It may take a few days for your information to be updated to the database.

This manual contains proprietary information that is protected by copyright laws. The information contained in this manual is subject to change without notice. Images provided herein are for reference only and may contain information or features that do not apply to your computer. Acer Group shall not be liable for technical or editorial errors or omissions contained in this manual.

Model number: _________________________________

Serial number: _________________________________

Date of purchase: ______________________________ Place of purchase: ______________________________

TABLE OF CONTENTS

Table of contents - 3

Manage your registered products ............... 2

Getting started 4

Turn on your Chromebook....................... 4

Select your language settings ................. 4

Connect to a network............................... 4

Accept the Terms of Service....................... 4

First-time sign-in ...................................... 4

Create a new Google Account .................... 4

Browse as a guest ...................................... 5

Your Acer Chromebook tour 6

Front view ................................................ 6

Keyboard view ......................................... 7

Function keys .............................................. 8

Touchpad .................................................... 8

Left side view........................................... 9

Right side view ........................................ 9

Bottom view .......................................... 11

The Chrome OS Desktop 12

Window controls ................................... 12

Shelf ...................................................... 13

Launcher................................................... 13

Pinned apps.............................................. 13

Status area................................................ 14

Apps & extensions 15

Managing apps ...................................... 15

Installing new apps from the Chrome Web

Store ........................................................ 15

Removing apps from Chrome OS ............. 15

Pin an app to the shelf .............................. 16

Unpin an app from the shelf...................... 16

Google Drive ......................................... 16

Difference between Drive and Files apps . 16

Creating a new document ......................... 17

Sync files from Downloads to Google

Drive.......................................................... 17

Enable offline access to Google Drive files 18

Gmail .................................................... 19

Composing an email ................................. 19

YouTube ............................................... 19

Playing video or audio files .................... 19

Other Supported File Types................... 19

Chrome OS tips and tricks 20

Documents............................................. 20

How to create documents ......................... 20

Finding your documents............................ 21

How to share documents with other users 21

How to start a video chat ....................... 22

How to listen to music............................ 22

How to watch videos, TV, or movies...... 23

Working with Microsoft Office (Word,

Excel, and Powepoint) documents ........ 23

Open and edit Microsoft Office files using

Google’s office compatibility mode ........... 23

Convert Microsoft Office files to Google

Drive formats............................................. 24

Export Google Drive documents as

Microsoft Office files.................................. 24

Opening Microsoft Office files using Microsoft’s Office Online apps from the

Chrome Web Store ................................... 24

How to use your Chromebook when

there’s no internet .................................. 25

Gmail Offline ............................................. 25

Google Drive ............................................. 26

Settings 27

Changing the language settings ............ 27

Changing the clock settings................... 28

Customizing appearance ....................... 28

Customizing the wallpaper........................ 28

Customizing the theme ............................. 28

Setting up a printer ................................ 29

Updating Chrome OS ............................ 29

Automatic update...................................... 29

Manual update .......................................... 30

Reseting your Chromebook ................... 30

Help 31

Online and offline help ........................... 31

4 - Getting started

GETTING STARTED

Turn on your Chromebook

On the Chromebook, the power button is located at the upper-right corner of the keyboard. A "welcome" screen will appear when the Chromebook first boots up.

Select your language settings

Use the "Select your language" drop-down list to choose your default language setting. If there is more than one way to type in your language, you may be prompted to select a keyboard input method as well.

Connect to a network

Select a wireless network from the "Select a network" list to connect to the Internet. If network access is protected, you will need an access password to connect to it.

Accept the Terms of Service

Once connected to a network, accept the Terms of Service. Your Chromebook will then download any available system updates, so you automatically get the latest Chrome OS features.

First-time sign-in

Create a new Google Account

You can create a new Google Account if you don’t already have one. Select Create a Google Account to set up a new account. A Google Account gives you access to useful web services developed by Google, such as Gmail, Google Drive, and Google Calendar.

Browse as a guest

Important

You can also use the Chromebook without a Google Account by selecting Browse as a Guest.

Sign in to your Google Account

If you already have a Google Account, enter your username and password in the sign-in box that appears and select the Sign in button.

Getting started - 5

Sign in with your primary Google Account. This account will be set as the owner and is the only account that will be able to change certain Chrome settings.

6 - Your Acer Chromebook tour

YOUR ACER CHROMEBOOK TOUR

Now that you are done setting it up, let us show you around your new Acer Chromebook.

Front view

# Icon Item Description

1 Microphone

2 Webcam

3 Touchscreen

Internal microphone for sound recording.

Web camera for video co

mmunication.

A light next to the webcam indicates

the webcam is active.

that

Displays computer output, supports mu

lti-touch input.

# Icon Item Description

Keyboard view

Power indicator

Battery indicator

Your Acer Chromebook tour - 7

Indicates the computer's power status.

Indicates the computer's battery

atus.

1. Charging: The light shows ambe when the battery is charging.

2. Fully charged: The light shows blue when in AC mode.

# Icon Item Description

1 Keyboard For entering data into your computer.

Touch-sensitive pointing device wh

ich functions like a computer

mouse.

Touchpad / click

utton

Pressing down anywhere on the pad

ions like the left button of a

funct mouse. Pressing down anywhere with two

rs functions like the right button

finge of a mouse.

8 - Your Acer Chromebook tour

Function keys

The computer uses function keys or key combinations to access some hardware and software controls, such as screen brightness and volume. The dedicated function keys each have a specific function.

Icon Function Description

Previous Go to the previous page.

Next Go to the next page.

Reload Reload the current page.

Full-screen Open the page in full-screen mode.

Next window Switch to the next window.

Brightness down Decreases the screen brightness.

Brightness up Increases the screen brightness.

Mute Turns off audio output.

Volume down Decreases the volume.

Volume up Increases the volume.

Touchpad

The built-in touchpad is a pointing device that senses movement on its surface. This means the cursor responds as you move your fingers across the surface of the touchpad.

Action Gesture

Click Press down on any part of the touchpad.

Tapping the touchpad with two fingers or pressing Two-finger tap (or alt-click)

Two-finger swipe

(and holding) Alt on the keyboard and tapping the

touchpad with one finger both equal a "right-click"

on a computer mouse.

Place two fingers on the touchpad and move

them up and down to scroll vertically, left and right

to scroll horizontally.

5123 4

512

Action Gesture

Drag and drop

Left side view

# Icon Item Description

Your Acer Chromebook tour - 9

Select the item you want to move with one finger.

With a second finger, move the item. Release

both fingers to drop the item. (This gesture works

for files, not windows or icons.)

5 Speaker Delivers stereo audio output.

DC-in jack Connects to an AC adapter.

HDMI port

USB port

SD™ card reader

Right side view

# Icon Item Description

1 Speaker Delivers stereo audio output.

Supports high-definition digital video

ctions.

conne Connects to USB devices.

If a port is black it is USB 2.0

atible, if it is blue it is also USB

comp

3.0 compatible.

Accepts Secure Digital (SD

Note: card. The card reader uses one card at a time.

Push to remove/install the

™

) cards.

10 - Your Acer Chromebook tour

# Icon Item Description

2 Power button Turns the computer on and off.

Headset/speaker jack

Connects to audio devices (e.g., speakers, headphones), or

dset with microphone.

a hea Connects to USB devices.

USB port

If a port is black it is USB 2.0

atible, if it is blue it is also

comp USB 3.0 compatible.

Connects to a Kensingtoncompatible computer security

Kensington lock slot

lock.

Note: Wrap the computer security lock cable around an immovable object such as a table or handle of a locked drawer. Insert the lock into the notch and turn the key to secure the lock. Some keyless models are also available.
