Aspire 2000
Service Guide
Service guide files and updates are available
on the ACER/CSD web; for more information,
please refer to http://csd.acer.com.tw
Service CD P/N.: VD.A20V5.001
PRINTED IN TAIWAN
Revision History
Please refer to the table below for the updates made on Aspire 2000 service guide.
Date Chapter Updates
II
Copyright
Copyright © 2003 by Acer Incorporated. All rights reserved. No part of this publication may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in
any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without
the prior written permission of Acer Incorporated.
Disclaimer
The information in this guide is subject to change without notice.
Acer Incorporated makes no representations or warranties, either expressed or implied, with respect to the
contents hereof and specifically disclaims any warranties of merchantability or fitness for any particular
purpose. Any Acer Incorporated software described in this manual is sold or licensed "as is". Should the
programs prove defective following their purchase, the buyer (and not Acer Incorporated, its distributor, or its
dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential
damages resulting from any defect in the software.
Acer is a registered trademark of Acer Corporation.
Intel is a registered trademark of Intel Corporation.
Pentium and Pentium II/III are trademarks of Intel Corporation.
Other brand and product names are trademarks and/or registered trademarks of their respective holders.
III
Conventions
The following conventions are used in this manual:
SCREEN MESSAGES Denotes actual messages that appear
on screen.
NOTE Gives bits and pieces of additional
information related to the current
topic.
WARNING Alerts you to any damage that might
result from doing or not doing specific
actions.
CAUTION Gives precautionary measures to
avoid possible hardware or software
problems.
IMPORTANT Reminds you to do specific actions
relevant to the accomplishment of
procedures.
IV
Preface
Before using this information and the product it supports, please read the following general information.
1. This Service Guide provides you with all technical information relating to the BASIC CONFIGURATION
decided for Acer's "global" product offering. To better fit local market requirements and enhance product
competitiveness, your regional office MAY have decided to extend the functionality of a machine (e.g.
add-on card, modem, or extra memory capability). These LOCALIZED FEATURES will NOT be covered
in this generic service guide. In such cases, please contact your regional offices or the responsible
personnel/channel to provide you with further technical details.
2. Please note WHEN ORDERING FRU PARTS, that you should check the most up-to-date information
available on your regional web or channel. If, for whatever reason, a part number change is made, it will
not be noted in the printed Service Guide. For ACER-AUTHORIZED SERVICE PROVIDERS, your Acer
office may have a DIFFERENT part number code to those given in the FRU list of this printed Service
Guide. You MUST use the list provided by your regional Acer office to order FRU parts for repair and
service of customer machines.
V
Table of Contents
Chapter 1 System Specifications 1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
System Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Board Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Top View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Rear View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Outlook View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Open View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Top Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Left Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Right Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Special keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Embedded Numberic Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Windows Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Hot Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
The Euro Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Touchpad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Touchpad Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Launch Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Hardware Specifications and Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Chapter 2 System Utilities 37
BIOS Setup Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Navigating the BIOS Setup Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Main . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Advanced . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Boot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
BIOS Flash Utility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
System Diagnostic Diskette . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Chapter 3 Machine Disassembly and Rep lacemen t 49
General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
Disassembly Procedure Flowchart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Disassemble the Battery and HDD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Disassemble the Wireless . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Disassemble the RAM and ODD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
Disassemble the Middle Cover Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Disassemble the Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Disassemble the LCD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Disassemble the MDC and RAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Disassemble the Upper Case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Disassemble the Main Unit(Touchpad, Bluetooth and LCM Board) . . . . . . . . . .55
Disassemble the Main Unit(Speakers, Fan, Thermal and CPU) . . . . . . . . . . . .56
Disassemble the Main Unit(VGA, Card Reader, Sub-Woofer and M/B) . . . . . . .57
Disassemble the LCD Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Disassemble the ODD Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Disassemble the HDD Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
VII
Table of Contents
Chapter 4 Troubleshooting 61
System Check Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
External Diskette Drive Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
External CD-ROM Drive Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Keyboard or Auxiliary Input Device Check . . . . . . . . . . . . . . . . . . . . . . . . .63
Memory Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Power System Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Touchpad Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Display Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Sound Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Insyde MobilePro BIOS POST Beep code and POST Messages . . . . . . . . . . .67
Index of Symptom-to-FRU Error Message . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69
Intermittent Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Undetermined Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74
Chpater 5 Jumper and Connector Locations 75
Top View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
Bottom View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76
Chapter 6 FRU (Field Replaceable Unit) List 77
Aspire 2000 series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77
Exploded Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78
Appendix A Model Definition and Configuration 88
Appendix B Test Compatible Components 89
Microsoft Windows XP (Home) Environment Test . . . . . . . . . . . . . . . . . . . . . . .90
Appendix C Online Support Information 92
VIII
System Specifications
Features
This computer was designed with the user in mind. Here are just a few of its many features:
Performance
! Intel
! Intel 855PM + Intel ICH4-M
! PC2700 DDR SDRAM, Maximum memory up to 2GB (with two 1024MB SO-DIMM when
! Internal slot-in optical drive
! High-capacity , Enhanced-IDE hard disk
! Li-Ion main battery pack
! Power management system with ACPI (Advanced Configuration Power Interface)
Display
! Thin-Film Transistor (TFT) liquid-crystal display (LCD) displaying 32-bit high true colour up to 16.7
! 3D graphics engine
! Simultaneous LCD and CRT display support
! S-video for output to a television or display device that supports S-video input
! Dual display capability
®
Pentium M processor at 1.4 ~ 1.7 GHz or higher
available)
million colours at 1280x800 eXtended Graphics Array (WXGA) resolution
Chapter 1
Multimedia
! 16-bit high-fidelity AC’97 Codec stereo audio
! Built-in dual speakers with subwoofer
! High-speed optical drive
Connectivity
! High-speed fax/data modem port
! Ethernet/Fast Ethernet port
! Fast infrared wireless communication
! 3 USB 2.0 (Universal Serial Bus) ports
! IEEE 1394 port
! Intel 802.11b or 802.11a/b wireless LAN (manufacturing optional)
! Bluetooth ready (manufacturing optional)
Expansion
! One type II CardBus PC Card slot
! Upgradeable memory
I/O Ports
! One Infrared (FIR)
! One RJ-11 modem jack
Chapter 1 1
! One RJ-45 network jack
! 4-1 Card Reader
! One DC-in jack for AC adapter
! One ECP/EPP-compliant parallel port
! One external monitor port
! One headphone/speaker/line-out jack (3.5mm mini jack)
! One microphone/line-in jack (3.5mm mini jack)
! One S-video-out (NTSC/PAL) port
! Three Universal Serial Bus (USB) ports
! One IEEE 1394 port
2 Chapter 1
System Block Diagram
IEEE 1394
TSB43AB21A
Mini PCI
socket
RTC CKT.
Power OK CKT.
Power On/Off CKT.
DC/DC Interface CKT.
CRT & TV-OUT Conn.
VGA Board Connector
LAN
RTL 8101L
RJ45/11 CONN
Touch Pad
EC I/O Buffer
Fan Control
AGP BUS
CardBus Controller
ENE CB1410
Slot 0
ENE KB910Q
Int.KBD
BIOS
Mobile Banias/Dothan
uFCBGA-479/uFCPGA-478 CPU
PSB
H_A#(3..31)
400MHz
Intel ODEM RevB
MCH-M
uFCBGA-593
Hub-Link
Int el IC H4- M
BGA-421
LPC BUS
H_D#(0..63)
Memory BUS(DDR)
SMsC LPC47N227
PARALLEL
Thermal Sensor
ADM1032AR
2.5V DDR- 200/26 6/333
USB2.0
AC-LINK
Primary IDE
ATA-100
Secondary IDE
ATA-100
Super I/O
Clock Generator
ICS 95 0810
DDR-SO-DIMM X2
BANK 0, 1, 2, 3
USB conn
Audio CKT
ALC2 02
MDC & BT Conn
Mini-PCI slot
HDD
Connector
CDROM
Connector
FIR
AMP & Aud io Jack
Power Circuit DC/DC
Chapter 1 3
Board Layout
Top View
Rear View
4 Chapter 1
ITEM DESCRIPTION ITEM DESCRIPTION
JP1 CRT JP19 L-SPK CONN.
JP2 P ARALLE L PORT JP20 T/P CONN.
JP3 TV-OUT CONN. JP21 KB CONN.
JP4 RJ11/45 CONN. JP22 SO-DIMM1 CONN.
JP5 1394 CONN. JP23 CD-ROM CONN.
JP6/7/8 USB CONN. JP25 HDD CONN.
JP9 MODEM CONN. JP28 MINI-PCI CONN.
JP11 PCMCIA CONN JP30 SO-DIMM CONN.
JP12/13 AGP CONN JP32 CARDREADER CONN.
JP15 FAN CONN. JP34 SUBWOOFER CONN.
JP16 MDC CONN. JP35 BLUETOOTH CONN.
JP17 SYSTEM CONN. JP9 CPU
JP18 R-SPK CONN. U12 NORTH BRIDGE
U8 SOUTH BRIDGE
Chapter 1 5
Outlook View
A general introduction of ports allow you to connect peripheral devices, as you would with a desktop PC.
Open View
# Item Description
1 Display Wide screen display provides visual
output.
2 Launch keys 4 buttons that can be programmed to
start frequently used applications.
3 Stereo Speakers Produce stereo sound
4 Touchpad Touch sensitive pad that functions like
a computer mouse.
5 Click buttons &
scroll key
Right and left buttons that provide the
same functions as the buttons on a
computer mouse. The scroll key
scrolls the contents of a window up
and down.
6 Chapter 1
Front Panel
# Item Description
1 Headphone-in Jack Connects headphones for audio
2 Microphone-in Jack Connects an external microphone for
3 4 in 1 Card Reader Supports MS/MMC/SD/SM kinds of
4 Latch Locks and releases the lid
5 Bluetooth Button Stares (optional) Bluetooth
6 Wireless Button Turns an optional inte rn al wi re l es s
output
audio input
memory sticks
functionality
device on or off
Chapter 1 7
Top Panel
# Item Description
1 Status Indicator LEDs that turn on and off to show the
2 Arcade Multimedia button
3 Console Display Panel control display
4 Stop Button Stop the Arcade application
5 Media Contrl Button Multimedia Button
status of the computers. It’s function
and components.
8 Chapter 1
Left Panel
# Item Description
1 PC Card Slot The slot supports a standard Type II
2 PC card eject button Press the eject button to remove a PC
3 Eject Button Ejecting a Disc
4 Slot Loading Support an optical disc.
PC card (PCMCIA or CardBus).
card from the PC card slot.
Chapter 1 9
Right Panel
# Item Description
1 Infrared Port Interfaces with infrared devices (e.g.,
2 DC-in Jack Connect the AC adapter
3 Kensington lock slot For attaching a security connector.
4 Ventilation Hole Enables the computer to stay cool,
infrared printer, IR-aware computer)
even after prolonged use.
10 Chapter 1
Rear Panel
# Item Description
1 S-Video Connects to a television or display
2 External display port Connects an external (VGA) display
3,4,8 USB Ports Three USB2.0 ports for connecting
5 Network Jack Connects the computer to an Etherne t
6 Modem Jack Connects the built-in fax/data modem
7 Parallel Port Co nnects a parallel device, such as a
9 IEEE 1394 Port Connects IEEE 1394 devices.
device with S-video input.
monitor.
USB devices.
10/100-based network.
to a phone line.
printer.
Chapter 1 11
Bottom View
# Item Description
1 Mini-PCI Slot Slot for adding mini-PCI cards
2 Hard disk bay Removable cover provides access to
the computer’s hard drive.
3 Memory
Compartment
4 Battery Pack The computer’s removable battery.
5 Sub-Woofer Speaker to output base sound
Removable cover provides access to
the memory slots for upgrading the
computer’s memory.
12 Chapter 1
Indicators
Your computer provides an array of three indicators located above the keyboard, in addition to four
indicators positioned at the front of the palm rest area. These indicators show the status of the computer
and its componetns.
The three indicators located above the keyboard provide the following status information:
Icon Description
Caps Lock activity
Num Lock activiy
Scroll Lock activity
NOTE: The keypad lock must be turned on to use the embedded numeric keypad.
Chapter 1 13
The four indicators located at the front of the unit provide the following status information:
Icon Item Description
Power mode
! Steady green --Power on
! Flashing oragne --Standby mode
! Orange --Hibernation mode
Hard Disc mode ! Lights to Indicate when the hard disc
drive is reading or writing data.
Battery mode ! Blue -- fully charged
! Flashing orange -- being charged
! Orange -- low on power
Bluetooth mode
Wireless LAN mode
! Lights to indicate that Bluetooth
(optional) is enabled.
! Lights to Indicate status of wireless
LAN (optional) communication.
14 Chapter 1
Keyboard
The keyboard features full-size keys with an embedded keypad, separated cursor keys, two Windows
keys, and twelve function keys (hot keys).
Special keys
Lock keys
The computer features three lock keys, each with its own status indicator light.
Lock Key Description
Caps Lock When Caps Lock is on, all alphabetic characters are typed in
uppercase. Toggle on and off by pressing the Caps Lock key on
the left side of the keyboard.
Num lock When Num Lock is on, the embedded numeric keyboard can be
used. Toggle on and off by pressing the Fn+tkeys
simultaneously.
Scroll lock When Scroll Lock is on, the screen toggles up or down one line
at a time when the up and down cursor control keys are pressed.
NOTE: Scroll Lock doesn’t work in all applications. Toggle on and off by pressing the Fn+F12 keys
simultaneously.
Chapter 1 15
Embedded Keypad
The embedded keypad functions like a desktop numeric keypad. It is indicated by small blue numbers and on
the applicable keys.
To use the the embedded numeric keys, toggle the Num Lock on by pressing the Fn + F11 keys
simultaneously.
With the embedded keypad turned on, the following actions are possible:
Desired Access Num Lock On Num Lock On
Number keys on
embedded keypad
Cursor-control keys on
embedded keypad
Main keyboard keys Hold down the Fn key
Type numbers using
embedded keypad in the
normal way.
Hold down the jkey
while using the cursor
keys on the embedded
keypad.
while typing letters using
the embedded keypad
keys. Simultaneously
press the j key for for
capital letters.
Hold Fn key while using
cursor-control keys.
Type lett ers in the normal
way.
16 Chapter 1
Windows Keys
The keyboard features two keys that perform Windows-specific functions.
Key Description
Windows logo key Pressed alone, this key has the same effect as clicking on the
Windows Start button; it launches the Start menu. It can also be
used with other keys to provide a variety of functions:
+ Tab (Activates the next Taskbar button)
+ E (Opens the My Computer window)
+ F1 (opens Help and Support)
+ F (opens the Find: All Files dialog box)
+ M (minimizes all windows)
j + Windows logo key + M (undoes the minimize all windows
action)
+ R (opens the Run dialog box)
Application key This key has the same effect as clicking the right mouse button; it
opens the application’s context menu.
Chapter 1 17
Hotkeys
Using the Fn key with another key creates a hot key, providing a quick and convenient method for controlling
various functions.
To use a hot key, first hold down the Fn key. Next, press the second key in combination. Finally, release
both keys.
Your computer provides the following hot keys:
Hot Key Function Description
Fn+F1 Hot key help Displays help on hot keys
Fn+F2 Setup Access the computer’s
configuration utility.
Fn+F3 Power management scheme
toggle
Fn+F4 Sleep Puts the computer in Sleep mode.
Fn+F5 Display toggle Switches display output between
Fn+F6 Screen blank Turns the display screen backlight
Fn+F7 Touchpad toggle Turns the internal touchpad on
Fn+F8 Speaker toggle Turns the speaker on and off.
Fn+Sub-
woofer key
Fn+w Volume up Increases the speaker volume.
Fn+y Volume down Decreases the speaker volume.
Fn+x Brightness up Increases the screen brightness.
Fn+z Brightness down Decreases the screen brightness.
Sub-woofer Turns the sub woofer on and off
Switches the power management
scheme used by the computer
(function available if supported by
operating system).
the display screen, external
monitor ( if connected) and both
the display screen and external
monitor.
off to save power. Press any key
to return.
and off.
NOTE: When activating hotkeys, press and hold the Fn key before pressing the other key in the hotkey
combination.
18 Chapter 1
Euro key
Your computer supports the new Euro currency character. First, hold down the Alt Gr key, and then press the
Euro key.
Chapter 1 19
Touchpad
The build-in touchpad is a PS/2 compatible pointing device that senses movement on its surface.
The cursor responds to your finger movements on the touchpad. In addition, the two click buttons provide
the same functionality as a computer mouse, while the scroll key enables easy up and down scrolling in
documents and web pages.
The touchpad is located in the middle of the palm rest area, providing maximum comfort and efficiency.
Touchpad Basics
Use the touchpad as follows:
! Slide your finger over the surface of the touchpad to control the movement of the cursor. Tap the
touchpad to perform selection and execution functions.
! Press the left (1) and right (3) buttons to perform selection and execution functions, just as you
would use the buttons on a computer mouse.
! Use the scroll key (2) to scroll through long documents and web pages. Press the top of the key to
scroll up, and the bottom to scroll down; left to scroll left, and right to scroll right.
Function Left Button Righ Button 4-Way Scroll Way Tap
Execute Click twice quickly Tap twice (at the
same speed as
double-clicking the
mouse button)
Select Click once Tap once
20 Chapter 1
Function Left Button Righ Button 4-Way Scroll Way Tap
Drag Click and hold.
Then slide your
finger across the
touchpad to drag
the cursor over the
selection.
Access
context
menu
Scroll Click and hold the
NOTE: Keep your fingers, as well as the surface of the touchpad dry and clean. The touchpad is sensitive to
your finger movements: the lighter the touch, the better the response. Tapping hard will not increase the
touchpad’s responsiveness.
Click once
up/down/left/right
button
Tap twice quickly.
On the second tap,
slide your finger
across the
touchpad to drag
the cursor over the
selection.
Chapter 1 21
Launch Keys
Located at the top of the keyboard are four buttons, in addition to the power button. These buttons are
called launch keys. They are designed as key 1, key 2, key 3 and key 4, from right to left. By default,
key 1 is used to launch the email application and key 2 is used to launch the Internet browser. Key 3
and key 4 start the Launch Manager application. The first four launch keys can be set by the user. To set
the launch keys, run the Acer Launch Manager.
# Description
Email Launches your email application.
Web browser Launches your Internet browser
P1 User-programmable
P2 User-programmable
22 Chapter 1
Hardware Specifications and Configurations
Processor
Item Specification
CPU type Intel Mobile Pentium M processor at 1.4~1.7 GHz or higher
CPU package uFCPGA package
CPU core voltage Support automatic selection of power supply voltage
CPU I/O voltage 1.05V
BIOS
Item Specification
BIOS vendor Insyde
BIOS Version Insyde MobilePRO BIOS 4.0
BIOS ROM type Flash ROM
BIOS ROM size 512KB
BIOS package 32 lead of TSSOP
Bupported protocols ACPI 1.0b,PC Card 95, SM BIOS 2.3, EPP/IEEE 1284, ECP/IEEE
1284 1.7 & 1.9, PCI 2.2, PnP 1.0a, DMI 2.0, USB, VGA BIOS, CDROM bootable
BIOS password control Set by setup manual
Second Level Cache
Item Specification
Cache controller Built-in CPU
Cache size 1MB or 2MB
1st level cache control Always enabled
2nd level cache control Always enabled
Cache scheme control Fixed in write-through
System Memory
Item Specification
Memory controller Intel 855PM GMCH
Memory size 128MB/256MB/512MB/1GB
DIMM socket number 2 sockets
Supports memory size per socket 1024MB
Supports maximum memory size 2GB (by two 1024MB SO-DIMM module)
Supports DIMM type DDR Synchronous DRAM
Supports DIMM Speed 200/2 66/333MHz
Supports DIMM voltage 2.5V
Supports DIMM package 200-pin SO-DIMM
Memory module combinations You can install memory modules in any combinations as long as
they match the above specifications.
Chapter 1 23
Memory Combinations
Slot 1 Slot 2 Total Memory
256/512MB 0 MB 256MB/512MB
256/512MB 256MB 512MB/768MB
256/512MB 512MB 768MB/1024MB
NOTE: Above table lists some system memory configurations. You may combine DIMMs with various
capacities to form other combinations.
.
LAN Interface
Item Specification
Supports LAN protocol 10/100 Mbps
LAN connector type RJ45
LAN connector location Rear side
.
Modem / Bluethooth Interface
Item Specification
Data modem data baud rate (bps) 56K
Supports modem/bluetooth protocol V.90 for MDC / Bluetooth 1.1 standard for BT
modem
Modem connector type RJ11
Modem connector location Rear side
Hard Disk Drive Interface
Item Specification
Vendor &
Model
Name
Capacity
(MB)
Bytes per
sector
Data heads 2 2 3 4 1 2 2 3
Drive Format
Disks11221112
Spindle
speed
(RPM)
Performance Specifications
Buffer size 2048KB 2048KB 2048KB 2048KB 2048KB 2048KB 2048KB 8192KB
Interface ATA-5 ATA-5 ATA-5 ATA-5 ATA-5 ATA-5 ATA-5 ATA-5
Toshiba
20G
MK2023
GAS
20000 30000 40000 60000 20000 30000 40000 60000
512 512 512 512 512 512 512 512
4200
RPM
Toshiba
30G
MK3021
GAS
4200
RPM
Toshiba
40G
MK4021
GAS
4200
RPM
Toshiba
60G
MK6021
GAS
4200/
5400
RPM
Hitachi
20G
IC25N02
0ATMR04
4200
RPM
Hitachi
30G
IC25N03
0ATMR04
4200
RPM
Hitachi
40G
IC25N04
0ATMR04
4200
RPM
Hitachi
60G
IC25N06
0ATMR04
4200/
5400
RPM
24 Chapter 1
Hard Disk Drive Interface
Item Specification
Max. media
transfer
rate (diskbuffer,
Mbytes/s)
Data
transfer
rate
(host~buffe
r, Mbytes/s)
DC Power Requirements
Voltage
tolerance
Optical Drive Interface
Vendor & model name Panasonic UJ-815
Performance S pecification CD-R/RW DVD-ROM
Transfer rate (KB/sec) (Mode1)
Data Buffer Capacity 2 MBytes
Interface IDE ( ANSI ATA/ATAPI-5)
Applicable disc format DVD: DVD-ROM (DVD-5, DVD-9, DVD-10),
Loading mechanism Load: The disc can be loaded semi-automatically ( T o load the disc in the
Power Requirement
Input Voltage +5 V +/- 5 %
Audio Interface
164.6~
257.1
100 MB/
Sec.
Ultra
DMA
mode-5
5V(DC)
+/- 5%
Item Specification
154.3~
298.0
100 MB/
Sec.
Ultra
DMA
mode-5
5V(DC)
+/- 5%
154.3~
298.0
100 MB/
Sec.
Ultra
DMA
mode-5
5V(DC)
+/- 5%
10.3X-24X CAV mode 3600KByte/s
(Mode2)
10.3X-24X CAV 1769-4104KByte/s
DVD-R (3.95G/4.7G),
DVD-RAM (2.6G/4.7G),
DVD-RW
CD: CD-Audio,
CD-ROM(mode 1 and mode 2),
CD-ROM XA ( mode2, form 1 and form 2),
CD-I ( Ready)
CD-I ( Bridge)
CD-WO
CD-RW
Photo CD
Video CD
Enhanced Music CD
CD-TEXT
drive, it is needed to push the disc manually)
Unload: The disc can be unloaded automatically by motor powered
mechanism. The disc unloading can be operated by the Eject button or
Eject Command through the IDE interface.
154.3~
298.0
100 MB/
Sec.
Ultra
DMA
mode-5
5V(DC)
+/- 5%
350 350 350 350
100 MB/
Sec.
Ultra
DMA
mode-5
5V(DC)
+/- 5%
3.3X-8X CAV 4.3MB/s-10.5 MB/s
100 MB/
Sec.
Ultra
DMA
mode-5
5V(DC)
+/- 5%
100 MB/
Sec.
Ultra
DMA
mode-5
5V(DC)
+/- 5%
100 MB/
Sec.
Ultra
DMA
mode-5
5V(DC)
+/- 5%
Item Specification
Audio Controller Realtek ALC202A, AC97 Codec
Chapter 1 25
Audio Interface
Item Specification
Audio onboard or optional Built-in
Mono or Stereo Stereo
Resolution 20 bit stereo Digital to analog converter
18 bit stereo Analog to Ditial converter
Compatibility Microsoft PC99, AC97 2.2 & WHQL
Mixed sound source CD
Sampling rate 48 KHz
Internal microphone No
Internal speaker / Quantity Yes / 2
Video Interface
Item Specification
Video vendor ATI
Video name M9+X
Chip voltage Core/1.5V
Supports ZV (Zoomed Video) port No
Video Resolution Mode (for both LCD and CRT)
Resolution 16 bits (High color) 32 bits (True color)
1024*768 Yes Yes
1400*1050 (SXGA) Yes Yes
1600*1200 (UXGA) Yes Yes
1280*1024 (Monitor) Yes Yes
Parallel Port
Item Specification
Parallel port controller SMSC LPC47N227
Number of parallel port One
Location Rear side
Connector type 25-pin D-type connector, in female type
Parallel port function control Enable/Disable/Auto (BIOS or operating system chooses
configuration) by BIOS setup
Note: Depending on your operating system, disabling an unused
device may help free systen resources for other devices.
Supports ECP/EPP/Bi-directional
(PS/2 compatible)
Optional ECP DMA channel (in
BIOS setup)
Optional parallel port I/O address
(in BIOS setup)
Optional parallel port IRQ (in
BIOS setup)
Yes (set by BIOS setup)
Note: When Mode is selected as EPP mode, “3BCh” will not be
available.
DMA channel 1
378h, 278h
IRQ7, IRQ5
26 Chapter 1
USB Port
Item Specification
USB compliancy level 2.0
OHCI USB 2.0
Number of USB port 3
Location Rear side
Serial port function control Enable/Disable by BIOS setup
PCMCIA Port
Item Specification
PCMCIA controller ENE CB1410 CardBus
Supports card type Type II
Number of slots One type-II
Access location Left panel
Supports ZV (Zoomed Video) port No ZV support
Supports 32 bit CardBus Yes
System Board Major Chips
Item Controller
System core logic Intel 855PM and ICH4-M
Super I/O controller SMSC 47N227, LPC interface
Audio controller Realtek ALC202A Codec
Video controller ATI M9+X
Hard disk drive controller ICH4-M
Keyboard controller ENE KB910
RTC ICH4-M
Keyboard
Item Specification
Keyboard controller ENE KB910
Keyboard vendor & model name Standard keyboard w/o launch button embeded
Total number of keypads 85 keys with 101/102 key emulation
Windows logo key Yes
Internal & external keyboard work
simultaneously
Yes
Battery
Item Specification
Vendor & model name Panasonic/Samsung
Battery Type Li-ion
Pack capacity 63Wh
Chapter 1 27
Battery
Item Specification
Cell voltage 3.7V/cell
Number of battery cell 8
Package configuration Pin 1: BATT+: Battery positive power pin
Pin 2: N/A
Pin 3: B/I: Enable Li-ion battery output, connect to 1k
resistor to GND in system.
Pin 4: TS: Detector Battery
Pin 5: EC_SMD1: N/A
Pin 6: EC_SMC1: SMbus CLOCK
Pin 7: GND> EC_SMD1=SMbus DATA
Package voltag Pin8: GND> Battery Ground Power Pin
LCD Inverter Speci f ic ation
No. Supplier Model Type
1 CMO NI54I1-L02 15.4” WXGA
2 LG LP154W01-A3 15.4”WXGA
3 Samsung LTN154X1-L02 15.4” WXGA
4 LG LP154W02-A1 15.4”WSXGA+
Ω
There are two control signals that come form system to control lamp brightness. One signal is
named DAC_BRIG, which limits current to meet LCD lamp current specification. Another one is
named PWM, which adjusts lamp brightness. This inverter brightness is adjusted by PWM burst
mode. The PWM burst mode is that turning on and off the lamp at rate of 150Hz. The effective
brightness is a function of the duty cycle.
Features
1. Wide range 9V to 21V input voltage.
2. Birghtness adjustment by PWM duty mode.
3. Close loop controls lamp current.
28 Chapter 1
Electrical Characteristics
No.Paramete
r
Input
1
voltage
Input
2
current
3 Lamp
current
4 Lamp
current
4 FrequencyF 455565KHz* Note 3
Symbol Min. Typ. Max. Unit Comment
NV_PWR9 14.8 21 V 7.5V (continuous) can
work
*Note 1
Iin -- 0.33 -- A
IL 3.0 -- 6.8 mA DAC=0V
*Note 2
IL 2.7 -- 6.3 mA DAC=1V
5 Output
power
6 Efficiency
7Starting
voltage
8Starting
time
9 Dispoff# 2.8 3.3 3.6 V Backlight on/off signal
10 Limited
lamp
maximum
current
11 PWM
signal
*Note 4
12 Lamp
current
over-
shoot
13 Current
Wavefor
m factor
Pout -- -- 4.5 W
η
Vs 1600 -- --- V At 0’C
Tvs 1 -- 1.5 Sec
DACBRIG
INV_PWM142 150 158 Hz PWM signal frequency
I zeroPK
I
p
I
rms
80% -- -- --
0 0.5 0.8 V Low level
0 3.3 V *Note 2
3.0 3.3 3.6 V PWM signal amplitude
30 -- 100 %
Ton
−
rms
p
------------------ -
=
Period
Duty
-- -- 10 % Line transient (10.8V to
21V/100us) and turn
on transient
1.27 1.56 Multipl
2
e
I
I
or *10
14 Unbalanc
e Rate
II
−
I
rms
15 Turn off
current
(Hight
side)
Chapter 1 29
IHl----0APWM=30%
-10% 0 +10% Mulitpl
pp
−
e
No.Paramete
r
15 Turn off
voltage
(Low
side)
16 Voltage
Rise time
(Low
side)
17 Voltage
fall time
(Low
side)
NOTE:
Symbol Min. Typ. Max. Unit Comment
Voff -- -- 150Vp-pV PWM=30%
Trise -- -- 300us us PWM=30%
Tfall -- -- 300us us PWM=30%
*1. The inverter can work in 7.5V input voltage (continuous), but 7.5V electronic characteristic will
not be care.
*2. Limited lamp maximum current by DAC_BRIC signal:
When DAC_BRIG voltage is 0V and INV_PWM enables (100%), lamp has max. current.
When DAC_BRIG voltage is 3.3V and INV_PWM enables (100%), lamp has min. current.
When add 1V DAC, the 100% Lamp current will decrease 0.5mA.
DAC_BRIG signal comes from system chipset with internal resistance of 3K
Ω
*3. Inverter operating frequency should be within specification (45~65kHz) at max. and min.
brightness load.
*4. INV_PWM enable implies INV_PWM signal is High level (On duty cycle is 100%). It is a square
wave of 150Hz to adjust backlight brightness that is a function of PWM duty cycle. Backlight
brightness is maximum value under INV_PWM at 100% and brightness is minimum under
INV_PWM at 30%.
*5.The system interface signals belong to 3.3V.
*6. Please make sure open lamp output voltage should be within starting voltage specification.
*7. Inverter should pass human body safety test.
*8. Inverter should be no smoking by any component open/short test.
*9. Transformer voltage stress should not be over 85% under any condition.
(turn on overshoot transient and line transient.)
*10. Audio noise should be less than 36dB at 10cm distance.
30 Chapter 1
.
Electrical specification
No
1 V oper* -- 650 -- Vrms Lamp operating voltage
Symbol Min. Typ. Max. Unit Comment
.
(650+/-50)
Il 6.2 6.5 6.8 mArms
DAC_BRIG: 0 V , PWM:
100%
Il 3.0 3.3 3.6 mArms
DAC_BRIG: 0 V,
PWM:30%
Il 5.7 6.0 6.3 mArms DAC_BRIG: 0V, PWM:100%
Il 2.7 3.0 3.3 mArms DAC_BRIG: 1V, PWM:30%
F 455565kHz
h
80% -- -- --
Thermal
All components on inverter board should follow below rules:
1. Component using conditions (component stress) must be within component specification including voltage
rating, current rating, temperature etc.
2. Component temperature should follow below:
! ∆T <=450 degree C, at 25, 35 degree C.
! Component temperature should be less than 80 degree C inside system at 35 degree C.
LCD
Item Specification
Vendor & model name CMO N154I1-
L02
Samsung
LTN154X1L02
LG
LP154W01-
A3
LG
LP154W02A1
Mechanical Specifications
LCD display area (diagonal,
15.4” 15.4” 15.4” 15.4”
inch)
Display technology TFT TFT TFT TFT
Resolution WXGA (1280*
800)
WXGA (1280*
800)
WXGA (1280*
800)
WSXGA+
(1650* 1050)
Supports colors 262K 262K 262K 262K
Optical Specification
Brightness control keyboard
hotkey
keyboard
hotkey
keyboard
hotkey
keyboard
hotkey
Contrast control No No No No
Suspend/Standby control Yes Yes Yes Yes
Electrical Specification
Supply voltage for LCD display
3.3 3.3 3.3 3.3
(V)
Supply voltage for LCD
650 690 690 690
backlight (Vrms)
Chapter 1 31
AC Adapter
Item Specification
Vendor & model name Delta ADD-65DB
Liteon DA-1650-02CR
Input Requirements
Maximum input current (A,
@100Vac, full load)
Nominal frequency (Hz) 47 - 63
Frequency variation range
(Hz)
Nominal voltages (Vrms) 90 - 264
Inrush current The maximum inrush current will be less than 50A and 100A when
Efficiency High efficiency 85% minimum, at 100~240Vac AC input, full load,
Output Ratings (CV mode)
DC output voltage Offers constant voltage 19.0V output source with 65W max output
Noise + Ripple 300mvp-pmax (20MHz bandwidth) for resistor load
Output current 0 A (min.) 3.5A (max.)
Output Ratings (CC mode)
DC output voltage 18.0 ~ 20.0
Constant output 3.5A
Dynamic Output Characteristics
Start-up time 3 sec. (@115 Vac and 230Vac full load)
Hold up time 5ms min. (@115 Vac input, full load)
Over Voltage Protection
(OVP)
Short circuit protection Output can be shorted without damage, and auto recovery
Electrostatic discharge
(ESD)
Dielectric Withstand Volt age
Primary to secondary 4242 Vdc for 1 second
Leakage current 60uA at 240Vac/60Hz
Regulatory Requirements 1. FCC class B requirements (USA)
1.5A max@3.5A/100Vac and 240 Vac
47 - 63
the adapter is connected to 100Vac(60Hz) and 240Vac(50Hz)
respectively.
warm-up condition.
power capacity .
25V
15kV (at air discharge)
8kV (at contact discharge)
2. VDE class B requirements (German)
3. VCCI classII requirements (Japan)
Power Management
ACPI Mode Power Management
Mech. Off (G3) All devices in the system are turned off completely.
Soft Off (G2/S5) OS initiated shutdown. All devices in the system are turned
off completely.
Working (G0/S0) Individual devices such as the CPU and hard disk may be
power managed in this state.
32 Chapter 1
Power Management
ACPI Mode Power Management
Sleeping State (S3) CPU Power Down
VGA Power Down
PCMCIA Suspend
Audio Power Down
Hard Disk Power Down
Super I/O Power Down
Sleeping State (S4) Also called Hibernate state. System saves all system
states and data onto the disk prior to power off the whole
system.
Environmental Requirements
Item Specification
Temperature
Operating +5 ~ +35°C
Non-operating -20 ~ +65°C
Non-operating -20 ~ +65°C (storage package)
Humidity
Operating 10% to 90% without condensation
Non-operating 10% to 90% RH, non-condensing (unpacked)
Non-operating 10% to 90% RH, non-condensing (storage package)
Vibration
Operating (unpacked) 5 ~ 500Hz: 0.9G
Non-operating (unpacked) 5 ~ 500Hz: 1.3G
Mechanical Specification
Item Specification
Dimensions 330mm (W) x 273mm (D) x 31.7mm (H) for 14.1/15.0 inch model
Weight 6.11lb (2.77kg) for 14.1 inch model (8 cell battery)
6.41lb (2.9kg) for 15.0 inch model (8 cell battery)
I/O Ports One type II CardBus slots, One RJ-11 modem jack,One RJ-45 network
jack, One DC-in jack for AC adapter, One ECP/EPP-compliant parallel
port, One external monitor port, One headphone/speaker/line-out jack
(3.5mm mini jack), One microphone/line-in jack (3.5mm mini jack), One
S-video-out (NTSC/PAL) port, Three Universal Serial Bus (USB) ports,
One IEEE 1394 port.
Drive Bays One
Material Recycle plastic PC+ABS 94V0
Indicators Power, Media activity, Battery charge, Wireless/Bluetooth
communication, Caps lock, Pad lock, Num lock and Scroll lock
indicators
Switch Power switch
Lid switch
User define switch 1, 2
Wireless ON/OFF switch
Chapter 1 33
Memory Address Map
Memory Address Size Function
000E0000h-000FFFFFh 128KB System BIOS
000C0000h-000CFFFFh 64KB VGA BIOS
000A0000h-000BFFFFh 128KB Video memory (VRAM)
00000000h-0009FFFFh 640KB Conventional memory
I/O Address Map
I/O Address Function
0000-001F Direct memory access controller
0000-0CF7 PCI bus
0010-001F Motherboard resources
0020-0021 Programmable interrupt controller
0024-0025 Motherboard resources
0028-0029 Motherboard resources
002C-002D Motherboard resources
002E-002F Motherboard resources
0030-0031 Motherboard resources
0034-0035 Motherboard resources
0038-0039 Motherboard resources
003C-003D Motherboard resources
0040-0043 System timer
004C-004F Motherboard resources
0050-0053 Motherboard resources
0060-0060 Standard 101/102-Key or Microsoft Natural PS/2 Keyboard
0061-0061 System speaker
0062-0062 Microsoft ACPI-Compliant Embedded Controller
0064-0064 Standard 101/102-Key or Microsoft Natural PS/2 Keyboard
0066-0066 Microsoft ACPI-Compliant Embedded Controller
0070-0071 System CMOS/real time clock
0072-0077 Motherboard resources
0080-0080 Motherboard resources
0081-008F Direct memory access controller
0090-009F Motherboard resources
00A0-00A1 Programmable interrupt controller
00A4-00A5 Motherboard resources
00A8-00A9 Motherboard resources
00AC-00AD Motherboard resources
00B0-00B5 Motherboard resources
00B8-00B9 Motherboard resources
00BC-00BD Motherboard resources
00C0-00DF Direct memory access controller
00F0-00FE Numeric data processor
0170-0177 Secondary IDE Channe l
34 Chapter 1
I/O Address Map
I/O Address Function
01F0-01F7 Primary IDE Channel
0200-020F Motherboard resources
0274-0277 ISAPNP Read Data Port
0279-0279 ISAPNP Read Data Port
0376-0376 Secondary IDE Channe l
0378-037B ECP Printer Port (LTP1)
03B0-03BB Intel(R) 82852/82855 GM/GME Graphics Controller
03C0-03DF Intel(R) 82852/82855 GM/GME Graphics Controller
03F6-03F6 Primary IDE Channel
03F8-03FF SMC IrCC - Fast Infrared Port
04D0-04D1 Motherboard resources
0778-077B ECP Printer Port (LTP1)
07F8-07FF SMC IrCC - Fast Infrared Port
0A79-0A79 ISAPNP Read Data Port
0D00-FFFF PCI bus
1000-107F Motherboard resources
11 00-110F Intel(R) 82801DBM Ultra ATA Storage Controller - 24CA
1200-121F Intel(R) 82801DB/DBM USB Universal Host Controller - 24C2
1300-133F Motherboard resources
1400-141F Intel(R) 82801DB/DBM SMBus Controller - 24C3
1600-161F Intel(R) 82801DB/DBM USB Universal Host Controller - 24C4
1700-171F Intel(R) 82801DB/DBM USB Universal Host Controller - 24C7
C000-C0FF Realtek RTL8139/810x Family Fast Ethernet NIC
C100-C17F VIA OHCI Compliant IEEE 1394 Host Controller
E000-E007 Intel(R) 82852/82855 GM/GME Graphics Controller
E100-E1FF Realtek AC’97 Audio
E200-E23F Realtek AC’97 Audio
E300-E3FF Agere Systems AC’97 Modem
E400-E47F Agere Systems AC’97 Modem
FD00-FDFF ENE CB1410 Cardbus Controller
FE00-FE00 Motherboard resources
FF00-FFFF ENE CB1410 Cardbus Controller
IRQ Assignment Map
Interrupt Channel Function(Hardware)
IRQ00 SystemTimer
IRQ01 Standard 101/102-Key or Microsoft Natural PS/2 Keyboard
IRQ04 SMC IrCC - Fast Infrared Port
IRQ08 System CMOS/real time clock
IRQ09 Microsoft ACPI-Compliant System
IRQ12 Alps Pointing-device
IRQ13 Numeric data processor
IRQ14 Primary IDE controller
Chapter 1 35
IRQ Assignment Map
Interrupt Channel Function(Hardware)
IRQ15 Secondary IDE controller
IRQ10 Agere Systems AC’97 Modem
ENE CB1410 Cardbus Controller
Intel(r) 82801DB/DBM USB 2.0 Enhanced Host Controller - 24CD
Intel(R) 82801DB/DBM USB Universal Host Controller - 24C2
Intel(R) 82801DB/DBM USB Universal Host Controller - 24C4
Intel(R) 82801DB/DBM USB Universal Host Controller - 24C7
Intel(R) 82852/82855 GM/GME Graphics Controller
Realtek AC’97 Audio
Realtek RTL8139/810x Family Fast Ethernet NIC
VIA OHCI Compliant IEEE 1394 Host Controller
DMA Channel Assignment
DMA Channel Function(Hardware)
1 ECP Printer Port (LPT1)
3 SMC IrCC - Fast Infrared Port
4 Direct memory access controller
36 Chapter 1
System Utilities
BIOS Setup Utility
The BIOS Setup Utility is a hardware configuration program built into your computer’s BIOS (Basic Input/
Output System).
Your computer is already properly configured and optimized, and you do not need to run this utility. However,
if you encounter configuration problems, you may need to run Setup. Please also refer to Chapter 4
Troubleshooting when problem arises.
Chapter 2
To activate the BIOS Utility, press
on the bottom of screen).
The setup screen displays BIOS as follows:
Function Item
Screen Display system information
Main Set Date and Time
Advanced Allow users to set FIR ports
Security Set User passwords&Set Supervisor passwords
Boot Allow users to change boot up devices priorities
Exit Exit and save settings
m during POST (when “Press <F2> to enter Setup” message is prompted
Enable/Disable Quiet Boot Logo
Enable/Disable LCD auto DIM
Enable/Disable PXE boot from LAN
Enable/Disable F12 Boot Menu
Allow users to set LPT ports
Allow users to enable/disable legacy USB
Navigating the BIOS Utility
There are five menu options: Main, Advanced, Security, Boot and Exit.
Follow these instructions:
! To choose a menu, use the cursor left/right keys (zx).
! To choose a parameter, use the cursor up/down keys ( wy).
! To change the value of a parameter, press p or q.
! Press ^ while you are in any of the menu options to go to the Exit menu.
! In any menu, you can load default settings by pressing t. You can also press u to save any
changes made and exit the BIOS Setup Utility.
NOTE: You can change the value of a parameter if it is enclosed in square brackets. Navigation keys for a
particular menu are shown on the bottom of the screen. Help for parameters are found in the Item
Specific Help part of the screen. Read this carefully when making changes to parameter values.
Chapter 2 37
Insyde Software SCU May 20, 2003 5:40:09
Main Advanced Security Boot Exit
----Devices--------------------------------------------------- -----System-------------------------
Product Name = Aspire 2000
Manufacture Name = Acer
System BIOS Version =
VGA BIOS Version =
Internal Hard Disk = HITACHI_DK23EA-40-(PM)
HDD Serial Number = 8D4648
DVD/CD-Rom Drive = UJDA740 DVD/CDROM-(SM)
Serial Number = ( 32 bytes)
Asset Tag Number = (32 bytes)
UUID = (16 bytes)
CPU = Intel® Pentium ®
CPU speed = 1400Mhz
----Memory------------------------
Base = 640 KB
Extended = 127MB
VGA Memory = 32MB
Setup system date, time. Enable boot logo and get system information.
Parameter Description
Product Name This field will show product name.
Manufacture Name This field will show manufacturer name.
BIOS Version This field reports the BIOS version of system.
VGA Version This field reports the VGA version of the system.
Internal Hard Disk This item will show the size of HDD installed on
Primary IDE master. The hard disk size is
automatically detected by the system. If there is no
hard disk present or unknown type, “None” should
be shown on this field.
DVD/CD-ROM Drive This item will show the model name of DVD/CD-
ROM drive installed on system. The DVD/CD-ROM
model name is automatically detected by the
system. If there is no DVD/CD-ROM model present
or unknown type, “None” should be shown on this
field.
Serial Number This item will show the Serial number of system.
Asset Tag This item will show the Asset Tag number of the
system.
UUID This number only valid when there is an internal LAN
device presents, otherwise, zero will be display in
this field.
System First field reports the model name of processor.
Second field reports CPU Speed.
38 Chapter 2
Memory
Parameter Description
Base This field reports the base memory size of system.
Extended This field reports the extended memory size of the
system.
VGA BIOS Version This field reports the VGA BIOS version of system.
Chapter 2 39
Main
This menu provides you the information of the system.
Insyde Software SCU May 20, 2003 5:40:09
Main Advanced Security Boot Exit
Date and Time
ԩ Quiet Bootʳ
ԩ F12 Boot Menu
˲ʳ ʳ LCD Auto DIM
ԩ PXE Boot From LAN
Ye a r 2003 Second 9
OK Cancel
<Tab> <Right> <Left> for block select. <Up> <Down> for item select.
< Enter> for accept. <Cancel> <Esc> for reject. <Alt> activates accelerators.
<Space> for Enable or Disable.
----------------------------Date and Time------------------------
Day 20 Hour 8
Month 5 Minute 35
Parameter Description
Date and Time The hours are displayed with 24 hours format. The values set in these two fields
take effect immediately.
Quiet Boot Customer Logo display will be shown during POST when it is selected.
F12 Boot Menu When this is selected, users can modify device boot priority by pressing F12 key
during POST. When this is not selected, device boot priority will not be
adjustable during POST.
LCD Auto DIM When this is selected, brightness of the LCD will be reduced for power saving
when adaptor has been removed from the system.
When this is not selected, brightness of the LCD will remain the same after
adaptor has been removed from the system.
PXE Boot From LAN When this is selected, Boot from LAN feature is enabled. When this is not
selected, Boot from LAN feature is then disabled.
40 Chapter 2
ʳʳ
˲ʳ ʳ
ԩʳ
ԩʳ
ԩ
Advanced
The Advanced screen contains parameters involving your hardware devices. It also provides advanced
settings of the system.
FIR Ports
Configure the system’s infrared port using options: Disabled and Enabled.
Insyde Software SCU May 20, 2003 5:40:09
Main Advanced Security Boot Exit
--DMA Setting For Fast IR--
( ) DMA2
( ) DMA3
<Tab> <Right> <Left> for block select. <Up> <Down> for item select.
< Enter> for accept. <Cancel> <Esc> for reject. <Alt> activates accelerators.
<Space> for Enable or Disable.
\
FIR Ports
LPT Port
ԩLegacy USB
---------------------------------FIR Ports--------------------------------
-----FIR I/O settings--- -Mode Setting for IRDA-
( ) Disabled ( ) Normal (16550)
( ) COM1,3F8,IRQ4 ( ) IrDA (HPSIR)
( ) COM2,2F8,IRQ3
( ) COM3,3E8,IRQ4
(Ԧ) COM4,2E8,IRQ3
( ) ASK IR
(Ԧ) FAST IR
( ) DMA1
OK
Cancel
The table below describes the parameters in the screen. Settings in boldface are the default and suggested
parameter settings.
Description Option
FIR I/O Settings Sets the base I/O address and IRQ for
Infrared port.
DMA Setting for Fast IRSets a DMA channel for the printer to
operate in ECP mode. This parameter is
enabled only if Mode is set to ECP.
Mode Setting Normak (16550), IrDA
COM1, 3F8, IRQ4/ COM2,
2F8, IRQ3/ COM3, 3E8,
IRQ4/ COM4, 2E8, IRQ3
DMA1, DMA2, DMA3,
(HPSIR), ASK IR, FAST IR
Chapter 2 41
LPT Port
Configure the system’s parallel port using options: Disabled and Enabled.
Insyde Software SCU May 20, 2003 5:40:09
Main Advanced Security Boot Exit
\
FIR Ports
---------------------------------FIR Ports--------------------------------
-----Port Address------- -------Port Definition------------
( ) None ( ) Standard AT (Centronics)
LPT Port
(Ԧ) LPT1, 378, IRQ7
( ) Bidirectional (PS-2)
( ) LPT2, 278, IRQ5 ( ) Enhanced Parallel (EPP)
ԩLegacy USB
( ) LPT3, 3BC, IRQ7
(Ԧ) Extended Capabilities(ECP)
--DMA Setting For Fast IR--
(Ԧ) DMA1
( ) DMA3
OK
Cancel
<Tab> <Right> <Left> for block select. <Up> <Down> for item select.
< Enter> for accept. <Cancel> <Esc> for reject. <Alt> activates accelerators.
<Space> for Enable or Disable.
The table below describes the parameters in the screen. Settings in boldface are the default and
suggested parameter settings.
Description Option
Port Address Sets the base I/O address for the parallel
port. When Mode is selected as EPP mode,
“3BC” will not be available.
None/ LPT1, 378, IRQ7/
LPT2, 278, IRQ5/ LPT3, 3BC,
IRQ7
Port Definition Sets the mode for the parallel port.
Standard AT: Normal mode (AT compatible)
Bi-directional: Bi-directional mod (PS/2
compatible)
Enhanced Parallel (EPP): EPP mode
Extended Compabilities (ECP): ECP mode
(requires DMA channel)
DMA Setting for Fast IRIf ECP mode has been selected, then DMA
default is DMA1.
42 Chapter 2
Standard AT (Centronics),
Bidirectional (PS-2),
Enhanced Parallel (EPP),
Extended Capabilities(ECP)
DMA1, DAM3
Legacy USB Support
ԩ
Disabled: Disable support for Legacy Universal Serial Bus.
Enabled: Enable support for Legacy Universal Serial Bus.
Insyde Software SCU May 20, 2003 5:40:09
Main Advanced Security Boot Exit
\
FIR Ports
LPT Port
ԩLegacy USB
( ) DMA1
Legacy USB keyboard Floppy Disk USB Mouse Support
<Space> for Enable or Disable
Chapter 2 43
Security
The Security screen contains parameters that help safeguard and protect your computer from
unauthorized use.
Insyde Software SCU May 20, 2003 5:40:09
Main Advanced Security Boot Exit
Set User Password
Set Supervisor Password
HDD Drive Lock
Password On Boot
------------Set Supervisor password----------------
Enter old Supervisor password: . . . . . . . .
Enter new Supervisor Password: . . . . . . . ..
Verify new Supervisor Password: . . . . . . .
OK Cancel
Enter new password. Password will NOT be displayed
The table below describes the parameters in this screen. Settings in boldface are the default and
suggested parameter settings.
Set Supervisor/User Password
If password on boot is required, the password must be set otherwise it cannot be enabled.
The formats of the password are as follows:
Length No more than 8 characters
Characters 0-9,A-Z (not case sensitive)
Parameter Description Option
Set User Password Press Enter to set the user password.
When set, this password protects the
BIOS Setup Utility from unauthorized
access.
Set Supervisor Password Press Enter to set the administrator
password. When set, this password
protects the BIOS Setup Utility from
unauthorized access.
HDD Drive Lock This allows users to protect their Hard
Drive being accessed by enabling HDD
security to their hard drive.
Disabled/Enabled
44 Chapter 2
Parameter Description Option
Password on Boot Defines whether a password is required
or not while the events defined in this
group happened. The following suboptions are all requires the Supervisor
password for changes and should be
grayed out if the user password was used
to enter setup.
Allows the user to specify whether or not
a password is required to boot.
Disabled/Enabled
Chapter 2 45
Boot
This menu allows the user to decide the order of boot devices to load the operating system. Bootable
devices includes the distette drive in module bay, the onboard hard disk drive and the CD-ROM
in module bay.
Please select the order of the boot devices
Insyde Software SCU May 20, 2003 5:40:09
Main Advanced Security Boot Exit
Boot Device
---------------------------------------Boot Device--------------------------------------
---1st Boot Device--- ---2nd Boot Device--- --3rd Boot Device----
( ) Hard Disk C
( ) CD-ROM Drive ( ) CD-ROM Drive
( ) Network Boot ( ) Network Boot ( ) Network Boot
OK Cancel
<Tab> <Right> <Left> for block select. <Up> <Down> for item select.
< Enter> for accept. <Cancel> <Esc> for reject. <Alt> activates accelerators.
<Space> for Enable or Disable.
.
(Ԧ) Diskette A
(Ԧ) Hard Disk C
( ) Diskette A (ʳʳ) Diskette A
( ) Hard Disk C
(Ԧ) CD-ROM Drive
46 Chapter 2
Exit
Ԧ
Ԧ
Ԧ
ʳʳ
The Exit screen contains parameters that help safeguard and protect your computer from unauthorized use.
Insyde Software SCU May 20, 2003 5:40:09
Main Advanced Security Boot Exit
Exit Saving Changes
--------------Exit Saving Changes------------------- Exit Discarding Changes
Press <OK> to save the current Load Setup Default
Setup parameters to CMOS RAM. Discard Changes
The computer will be rebooted!!!
OK Cancel
<Tab> <Right> <Left> for block select. <Up> <Down> for item select.
< Enter> for accept. <Cancel> <Esc> for reject. <Alt> activates accelerators.
<Space> for Enable or Disable.
The table below describes the parameters in this screen.
Parameter Description
Exit Saving Changes Allows the user to save changes to CMOS and reboot the system.
Exit Discarding
Changes
Load Setup Default Loads default settings for all parameters (same as t ).
Discard Changes Allows the user to discard previous changes in CMOS Setup.
Allows the user Discards changes made and exits System Setup.
Chapter 2 47
BIOS Flash Utility
The BIOS flash memory update is required for the following conditions:
! New versions of system programs
! New features or options
! Restore a BIOS when it becomes corrupted.
Use the Flash utility to update the system BIOS flash ROM.
NOTE: If you do not have a crisis recovery diskette at hand, then you should create a Crisis Recovery
Diskette before you use the Flash utility.
NOTE: Do not install memory-related drivers (XMS, EMS, DPMI) when you use the Flash utilities.
NOTE: Please use the AC adaptor power supply when you run the Flash utility. If the battery pack does
not contain enough power to finish BIOS flash, you may not boot the system because the BIOS is not
completely loaded.
Fellow the steps below to run the Flash.
1. Prepare a bootable diskette.
2. Copy the Flash utilities to the bootable diskette.
3. Then boot the system from the bootable diskette. The Flash utility has auto-execution function.
System Diagnostic Diskette
This diagnostic diskette is for the Acer Aspire 2000 series notebook machine. However, system
diagnostic utility is not ready as service CD released. Acer HQ CSD will upload the utility to CSD website
as soon as it is ready.
48 Chapter 2
Machine Disassembly and Replacement
This chapter contains step-by-step procedures on how to disassemble the notebook computer for
maintenance and troubleshooting.
To disassemble the computer, you need the following tools:
! Wrist grounding strap and conductive mat for preventing electrostatic discharge
! small Philips screwdriver
! flat head screwdriver
! Philiips screwdriver
! nut screwdriver
! tweezers
NOTE: The screws for the different components vary in size. During the disassembly process, group the
screws with the corresponding components to avoid mismatch when putting back the components.
When you remove the stripe cover, please be careful not to scrape the cover.
Chapter 3
Chapter 3 49
General Information
Before You Begin
Before proceeding with the disassembly procedure, make sure that you do the following:
1. Turn off the power to the system and all peripherals.
2. Unplug the AC adapter and all power and signal cables from the system.
3. Remove the battery pack.
50 Chapter 3
Disassembly Procedure Flowchart
System
ODD M odule
LCD Co axial
Cable
Jx1 Hx1
Mini Door Assy
Lx2
Ax16
Display Assy Logic Assy
Hinge L Assy Hinge R Assy
RAM Door Assy
HDD Door
Sub-Assy
Bx2
Keyboard
Cx2
K/B Support
Plate Assy
Px4
Logic Locu Assy VGA Board MDC Board
Logic up
Sub-Assy
Ix2
HDD Door
Bus-Assuy
HDD Cover HDD ModuleOD D M o d uile ODD Panel Assy
Ex1 Fx2
Mx2
Sub-Woofer SD Board M/B Board
Strip Cover Door
Kx4
Dx13
Assy
Logic Up
Ox2Nx1
Assy
Gx21
LCD Panel
Speaker L Speaker R Deco Plate
LCD Cover
Sub-Assy
LCM Board AssyTHML Fan AssyTP Board
LCD Bezel
Sub-Assy
TP Support
Assy
Hinge Saddle R
Fro n t B u tto n
Board
Assy
Hinge Saddle L
Front Button
Board FFC
Assy
TP FPC Assy
Logic Up
Sub-Assy
Item Description
A M2.5x5
M2.0x4
B M2.5x3
C M2.5x4
D M2.5x10
M2.5x4
Chapter 3 51
Item Description
E M2.5x14
F M2.0x4
G M2.5x4
H M2.5x14
I M2.5x10
J M2.5x5
K M3.0x3
L M2.0x3
M2.5x4
N M2.5x4
O M2.5x5
P M2.5x4
52 Chapter 3
Aspire 2000 Disassembly Procedure
This section will guide you how to disassemble the system when you need to perform system service.
Please also refer to the disassembly video, if availabled.
CAUTION: Before you proceed,make sure you have turned off the system and all peripherals connected.
Disassemble the Battery and HDD
1. Release the battery lock and slide the battery latch.
2. Then remove the battery pack.
3. Remove the two screws to release the hard drive door.Then take it away.
Disassemble the Wireless
1. Remove the one screw to release the mini door, and take it away.
2. Disconnect the two wireless cables.
3. Then take the wireless board from the base.
Disassemble the RAM and ODD
1. Remove the one screw to release the RAM door and remove it.
2. Press down the both side latches to release the RAM board.
3. Remove the one screw to release the ODD module.
4. Then push the inner position to remove the ODD from the base.
5. Pull the entire ODD moudle from the system.
Chapter 3 53
Disassemble the Middle Cover Board
1. Remove the one screw.
2. Detach the middle cover from the unit with the flat screw driver.
3. Disconnect the system cable from the middle cover board.
4. Remove the two screws to release the middle cover board.
5. Then detach the middle cover board from cover.
Disassemble the Keyboard
1. Remove the screws on each side.
2. Pull up both sides of the latches to disconnect the FFC from the mainboard.
3. Remove the screws on each side to release the keyboard bracket.
4. Then take the keyboard supporter bracket from the system.
54 Chapter 3
Disassemble the LCD
1. Remove the one screw from the LVDS board.
2. Pull the LCD coaxial board and the cable from the system.
3. Remove the two screws from the hinge on each side to release the LCD panel.
4. Pull the entire LCD module from the system.
Disassemble the MDC and RAM
1. Remove the two screws to release the MDC board.
2. Disconnect the MDC cable before you take the MDC board.
3. Press down the both sides latches to release the RAM.
4. Disconnect the right and left speaker cables from the mainboard.
5. Disconnect the touchpad FPC connector and CPU fan cable.
Disassemble the Upper Case
1. Remove the thirteen screws located on the base case.
2. Remove the two screws on the other side to located on the rear panel.
3. Remove the three screws to release the upper case.
4. Detach the upper case from the system.
Chapter 3 55
Disassemble the Main Unit ( Touchpad, Bluetooth and LCM Board)
1. Remove the seven screws to release the touchpad supporter bracket.
2. Disconnect the touchpad FPC connector.
3. Disconnect the cable as highlights.
4. Then detach the touchpad bracket from the position.
5. Detach the touchpad PC from the module.
6. Disconnect the bluetooth board FFC connector.
7. Remove the two screws to release the bluetooth board.
8. Take the bluetooth board from the system.
9. Remove the one screw to release the LCM board.
10. Detach the LCM board from the system.
56 Chapter 3
Disassemble the Main Unit ( Speakers, Fan, Thermal and CPU)
1. Remove the one screw to release the up hinge saddle.
2. Remove the three screws to release the bottom hinge saddle.
3. Detach the right hinge saddle from the case.
4. Remove the two screws to release the right hinge saddle.
5. Take the right speaker from the opsition.
6. Remove the one screw to release the CPU fan from the hinge saddle.
7. Take the CPU fan from the hinge saddle.
8. Remove the three screws to release the left hinge saddle.
9. Detach the left hinge saddle from the system.
10. Remove the one screw to release the left speaker from the base cover.
11. Then detach the left speaker.
12. Remove the four screws to release the thermal module.
13. Detach the thermal module from the system.
14. Remove the one screw to release the CPU.
15. Detach the CPU fan from the socket.
Chapter 3 57
Disassemble the Main Unit ( VGA, Card Reader, Sub-Woofer and Mainboard)
1. Remove the one screw to release the VGA bracket.
2. Detach the VGA module from the mainboard.
3. Separate the VGA bracket and the VGA board.
4. Remove the ground screw to release the card reader.
5. Disconnect the card reader cables on each side.
6. Disconnect the sub-woofer cable
7. Remove the screws on each side to release the sub-woofer.
8. Detach the sub-woofer from the case.
9. Detach the card reader board from the case.
10. Remove the one screw to release the mainboard.
11. Press the PCMCIA button and hold the position to release the mainboard from the case.
58 Chapter 3
Disassemble the LCD Module
1. Remove the screws on each side.
2. Detach the bezel from the LCD panel.
3. Remove the screws located on the different side.
4. Detach the LCD panel from the cover.
5. Take the antenna away from the position to release the inverter board.
6. Disconnect the LCD coaxial cables.
7. Remove the four screws to release the left LCD bracket.
8. Take the left LCD bracket from the panel.
9. Remove the four screws to release the right LCD bracket.
10. Take the right LCD bracket from the panel.
Chapter 3 59
Disassemble the ODD Module
1. Remove the two screws to separate the ODD drive.
2. Detach the ODD bracket.
3. Detach the ODD door.
Disassemble the HDD Module
1. Remove the two screws on each side.
2. Separate the hard disk top cover and take the hard drive from the carrier.
3. Remove the hard disk connector from the rear position.
60 Chapter 3
Troubleshooting
Use the following procedure as a guide for computer problems.
1. Obtain the failed symptoms in as much detail as possible.
2. Verify the symptoms by attempting to re-create the failure by running the diagnostic test or by
repeating the same operation.
3. If any problem occurs, you can perform visual inspection before you fellow this chapter’s instructions.
You can check the following:
power cords are properly connected and secured;
there are no obvious shorts or opens;
there are no obviously burned or heated components;
all components appear normal.
4. After you perform visual inspection you can also verify the following:
ask the user if a password is registered and, if it is, ask him or her to enter the password.
verify with the customer that Wndows XP is installed on the hard disk. Operating systems that
were not preinstalled by Acer can cause malfunction.
make sure all optional equipment is removed from the computer.
make sure the floppy disk is empty.
5. Use the following table with the verified symptom to determine which page to go to.
Chapter 4
Symptoms (Verified) Go To
Power failure. (The power indicator does
not go on or stay on.)
POST does not complete. No beep or error
codes are indicated.
POST detects an error and displayed
messages on screen.
Other symptoms (i.e. LCD display problems
or others).
Symptoms cannot be re-created
(intermittent problems).
“Power System Check”
“Insyde MobilePro BIOS POST Beep Code
and POST Messages”
“Undetermined Problems”
“Insyde MobilePro BIOS POST Beep Code
and POST Messages”
“Insyde MobilePro BIOS POST Beep Code
and POST Messages”
Use the customer-reported symptoms and
go to “Insyde MobilePro BIOS POST Beep
Code and POST Messages” on page 67
“Intermittent Problems”
“Undetermined Problems”
Chapter 4 61
System Check Procedures
External Diskette Drive Check
Do the following steps to isolate the problem to a controller, driver, or diskette. A write-enabled, diagnostic
diskette is required.
NOTE: Make sure that the diskette does not have more than one label attached to it. Multiple labels can cause
damage to the drive or cause the drive to fail.
Do the following to select the test device.
1. The FDD heads can become dirty over time, affecting their performance. Use an FDD cleaning kit to clean
the heads. If the FDD still does not function properly after cleaning, go to next step.
2. Boot from diagnostic program.
3. If an error occurs with the internal diskette drive, reconnect the diskette connector on the main board.
If the error still remains:
1. Reconnect the external diskette drive module.
2. Replace the external diskette drive module.
3. Replace the main board.
External CD-ROM/DVD-ROM Drive Check
Do the following to isolate the problem to a controller, drive, or CD-ROM/DVD-ROM. Make sure that the CDROM does not have any label attached to it. The label can cause damage to the drive or can cause the drive to
fail.
Do the following to select the test device:
1. Insert an audio CD into the CD/DVD drive. If the CD/DVD drive can read the data from the audio CD. The
drive does not have problem, then go to next step. If the CD/DVD LED on the front panel does not emit
light as it read the data from the audio CD, then go to next step. However, if the CD/DVD drive can not
read data from the audio CD, you may need to clean the CD/DVD drive with a CD/DVD drive cleaning
disk.
2. Make sure that the appropriate driver has been installed on the computer for the CD/DVD drive.
3. Boot from the diagnostics diskette and start the diagnostics program
4. See if CD-ROM Test is passed when the program runs to CD-ROM/DVD-ROM Test.
5. Follow the instructions in the message window.
If an error occurs, reconnect the connector on the main board. If the error still remains:
1. Reconnect the CD-ROM/DVD-ROM module.
2. Replace the CD-ROM/DVD-ROM module.
3. Replace the main board.
62 Chapter 4
Keyboard or Auxiliary Input Device Check
Remove the external keyboard if the internal keyboard is to be tested.
If the internal keyboard does not work or an unexpected character appears, make sure that the flexible cable
extending from the keyboard is correctly seated in the connector on the main board.
If the keyboard cable connection is correct, run the Keyboard Test.
If the tests detect a keyboard problem, do the following one at a time to correct the problem. Do not replace a
non-defective FRU:
1. Reconnect the keyboard cables.
2. Replace the keyboard.
3. Replace the main board.
The following auxiliary input devices are supported by this computer:
! Embedded Numeric Keypad
! External keyboard
If any of these devices do not work, reconnect the cable connector and repeat the failing operation.
Memory Check
Memory errors might stop system operations, show error messages on the screen, or hang the system.
Currently, we do not provide memory test program. However, if you need to check memory but have no testing
program or diagonositc utility at hand, please go to http://www.passmark.com to download the shareware
“BurnIn Test V.3.0”. You may test the memory with this program under Window XP environment.
NOTE: Make sure that the DIMM is fully installed into the connector. A loose connection can cause an error.
Power System Check
To verify the symptom of the problem, power on the computer using each of the following power sources:
1. Remove the battery pack.
2. Connect the power adapter and check that power is supplied.
3. Disconnect the power adapter and install the charged battery pack; then check that power is supplied by
the battery pack.
If you suspect a power problem, see the appropriate power supply check in the following list:
! “Check the Power Adapter”
! “Check the Battery Pack”
Chapter 4 63
Check the Power Adapter
Unplug the power adapter cable from the computer and measure the output voltage at the plug of the power
adapter cable. See the following figure
Pin 1: 19V
Pin 2: 0V, Ground
1. If the voltage is not correct, replace the power adapter.
2. If the voltage is within the range, do the following:
! Replace the main board.
! If the problem is not corrected, see “Undetermined Problems”.
! If the voltage is not correct, go to the next step.
NOTE: An audible noise from the power adapter does not always indicate a defect.
3. If the DC-IN indicator does not light up, check the power cord of the power adapter for correct continuity
and installation.
4. If the operational charge does not work, see “Check the Power Adapter” .
64 Chapter 4
Check the Battery Pack
To check the battery pack, do the following:
From Software:
1. Check out the Power Options in control Panel
2. In Power Meter, confirm that if the parameters shown in the screen for Current Power Source and Total
Battery Power Remaining are correct.
3. Repeat the steps 1 and 2, for both battery and adapter.
4. This helps you identify first the problem is on recharging or discharging.
From Hardware:
1. Power off the computer.
2. Remove the battery pack and measure the voltage between battery terminals 1(+) and 6(ground).
3. If the voltage is still less than 7.5 Vdc after recharging, replace the battery.
4. If the voltage is within the normal range, run the diagnostic program.
To check the battery charge operation, use a discharged battery pack or a battery pack that has less than 50%
of the total power remaining when installed in the computer.
If the battery status indicator does not light up, remove the battery pack and let it return to room temperature.
Re-install the battery pack.
If the charge indicator still does not emit, replace the battery pack. If the charge indicator still does not light up,
replace the DC/DC charger board.
Touchpad Check
If the touchpad doesn’t work, do the following actions one at a time to correct the problem. Do not replace a
non-defective FRU:
1. After rebooting, run Touch pad/PS2 Mode Driver.
2. Run utility with the PS/2 mouse function and check if the mouse is working.
3. If the PS/2 mouse does not work, then check if the main board to switch board FPC is connected well.
4. If the main board to switch board FPC is connected well, then check if the touch pad FPC connects to the
main board properly.
5. If there is still an error after you have connected the touch pad FPC to the main board properly, then
replace the touch pad or touch pad FPC. The touch pad or touch pad FPC may be damaged.
6. Replace switch board.
7. If the touch pad still does not work, then replace the FPC on Track Pad PCB.
After you use the touchpad, the pointer drifts on the screen for a short time. This self-acting pointer movement
can occur when a slight, steady pressure is applied to the touchpad pointer. This symptom is not a hardware
problem. No service actions are necessary if the pointer movement stops in a short period of time.
Display Check
1. Connect an external display to the computer’s external monitor port, the boot the computer. The computer
can automatically detect the external display. Press Fn+ p to switch to the external display.
2. If the external display works fine, the internal LCD may be damaged. Then perform the following steps:
Make sure the DDRRAM module is seated properly. Then run the diplay test again. If the problem
still exists, go to next step.
Replace the inverter board, then run the display test program again. If the problem still occurs, go
on next step.
Replace the LCD module with a new one then run the display test again. If the probelm still
happens, continue next step.
Replace LCD/FL cable with a new one then execute the display diagnostic again. If the problem
Chapter 4 65
still occurs, continue next step.
Replace the CPU with another of the same specifications. If the problems still occurs, go to next
step.
The main board may be damaged. Replace main board.
3. If the external monitor has the same problem as the internal monitor, the main board may be damaged.
Please insert the diagnostic disk and run the display test program and go through the sub-steps under
step 2.
Sound Check
To determine if the computer’s built-in speakers are functioning properly, perform the following steps. Before
you start the steps below, adjust the speaker volume to an appropriate level.
1. Try different audio sources. For example, employ audio CD and ditital music file to determine whether the
fault is in the speaker system or not. If not all sources have sound problem, the problem is in the source
devices. If all have the same problem, continue next step.
2. Connect a set of earphone or external speakers. If these devices work fine, go to next step. If not, then the
main board may be defective or damaged. Replace the main board.
3. Follow the disassembling steps in Chapter 3. Esure the speaker cable is firmly connected to the main
board. If the speaker is still a malfunction, go on next step.
4. If the speakers do not sound properly, the speakers may be defective or damaged. Replace the speakers.
If the problem still occurs, then replace the main board.
66 Chapter 4
Insyde MobilePro BIOS POST Beep Code and POST Messages
The POST error message index lists the error message and their possible causes. The most likely cause is
listed first.
NOTE: Perform the FRU replacement or actions in the sequence shown in FRU/Action column, if the FRU
replacement does not solve the problem, put the original part back in the computer. Do not replace a
non-defective FRU.
This index can also help you determine the next possible FRU to be replaced when servicing a computer.
If the symptom is not listed, see “Undetermined Problems” on page 73.
The following lists the error messages that the BIOS displays on the screen and the error symptoms classified
by function.
NOTE: Most of the error messages occur during POST. Some of them display information about a hardware
device, e.g., the amount of memory installed. Others may indicate a problem with a device, such as the
way it has been configured.
NOTE: If the system fails after you make changes in the BIOS Setup Utility menus, reset the computer, enter
Setup and install Setup defaults or correct the error.
Beep Code Message Description
short, short, short; short,
short, long
short, short, short; short,
long, short
short, short, short; short,
long, long
short, short, short; long,
short, short
short, short, short; long,
short, long
short, short, short; long,
long short
short, short, short; long,
long, long
short, short, long; short,
short, short
short, short, long; short,
short, long
N/A “KEYBOARD CONTROLLER
N/A “KEYBOARD FAILURE”
N/A “CMOS FAILURE - RUN SCU”
N/A “CMOS CHECKSUM INVALID -
N/A
“FAULTY DMA PAGE
REGISTERS”
“FAULTY REFRESH CIRCUIT” RAM refresh circuit does not function
“ROM CHECKSUM INCORRECT” BIOS ROM checksum failed.
“CMOS RAM TEST FAILED” CMOS RAM test failed.
“DMA CONTROLLER FAULTY” DMA controller does not work properly.
“INTERRUPT CONTROLLER
FAILED”
N/A
N/A No video device found.
N/A No RAM installed.
FAILURE”
RUN SCU”
“RAM ERROR AT LOCATION
xxxxxx:
WROTE: xxxx
READ: xxxx”
DMA page registers do not function
properly.
properly.
The interrupt controller does not work
properly.
Keyboard controller failed to respond with
the self-test command.
Keyboard controller failed during system
inquiry about connected devices.
The keyboard fails to respond or no keyboard is connected.
CMOS data error, probably due to battery
power loss.
CMOS checksum error.
The RAM failed during memory test at the
indicated location.
Chapter 4 67
Beep Code Message Description
N/A
N/A “PARITY ERROR A T LOCATION
N/A “NO INTERRUPTS FROM TIMER 0”Timer 0 of the clock timer controller does
N/A “UNEXPECTED AMOUNT OF
N/A “CLOCK NOT TICKING
N/A “TIME/DATA CORRUPT - RUN
N/A “MACHINE IS LOCKED - TURN
N/A “BOOT SECTOR 0 HAS
N/A Suspend-to-Disk partition
N/A “Hard Disk ERROR!” Access to the Suspend-to-Disk partition
N/A “Suspend-to-Disk partition
N/A “Suspend-to-Disk partition size
N/A “MEMORY SIZE HAS CHANGED
“PARITY ERROR AT UNKNOWN
LOCATION”
XXXXXX”
MEMORY - RUN SCU”
CORRECTLY”
SCU”
KEY”
CHANGED”
MISSING!”
signature NOT FOUND!”
TOO SMALL!”
-- REBOOTING”
Parity error during memory test at unknown
location.
Parity error during memory test at the
indicated location.
not generate system interrupts correctly.
The system memory size does not match
with the CMOS record.
The system clock does not working
correctly.
The time/date information in CMOS is
invalid.
The keyboard operation is locked.
The boot sector of the hard disk has been
changed, probably because of a virus
attack.
No Suspend-to-Disk partition found.
failed.
No Suspend-to-Disk partition signature
found.
The capacity of the Suspend-to-Disk
partition is not enough.
The memory size has changed after
previous Suspend-to-Disk operation.
68 Chapter 4
Index of Symptom-to-FRU Error Message
LCD-Related Symptoms
Symptom / Error Action in Sequence
LCD backlight doesn't work
LCD is too dark
LCD brightness cannot be adjusted
LCD contrast cannot be adjusted
Unreadable LCD screen
Missing pels in characters
Abnormal screen
Wrong color displayed
LCD has extra horizontal or vertical lines
displayed.
Enter BIOS Utility to execute “Load Setup Defaults” on Exit
screen, then reboot system.
Reconnect the LCD connectors.
Keyboard (if contrast and brightness function key doesn't
work).
LCD cable
LCD inverter
LCD
Main board
Reconnect the LCD connector
LCD cable
LCD inverter
LCD
Main board
LCD inverter
LCD cable
LCD
Main board
Indicator-Related Symptoms
Symptom / Error Action in Sequence
Indicator incorrectly remains off or on, but
system runs correctly
Power-Related Symptoms
Symptom / Error Action in Sequence
Power shuts down during operation Power source (battery pack and power adapter). See “Power
The system doesn’t power-on. Power source (battery pack and power adapter). See “Power
The system doesn’t power-off. Power source (battery pack and power adapter). See “Power
Battery can’t be charged See “Check the Power Adapter”.
Reconnect the inverter board
Inverter board
Main board
System Check” .
Battery pack
Power adapter
Hard drive & battery connection board
Main board
System Check” .
Battery pack
Power adapter
Hard drive & battery connection board
Main board
System Check” .
Hold and press the power switch for more than 4 seconds.
Main board
Battery pack
Main board
Chapter 4 69
PCMCIA-Related Symptoms
Symptom / Error Action in Sequence
System cannot detect the PC Card
(PCMCIA)
PCMCIA slot pin is damaged. PCMCIA slot assembly
Memory-Related Symptoms
Symptom / Error Action in Sequence
Memory count (size) appears different from
actual size.
Speaker-Related Symptoms
Symptom / Error Action in Sequence
In Windows, multimedia programs, no
sound comes from the computer.
Internal speakers make noise or emit no
sound.
PCMCIA slot assembly
Main board
DIMM
Main board
See “Sound Check” on page 66
Audio driver
Speaker
Main board
See “Sound Check” on page 66
Speaker
Main board
Power Management-Related Symptoms
Symptom / Error Action in Sequence
The system will not enter hibernation Keyboard (if control is from the keyboard)
Hard disk drive
Main board
The system doesn't enter hibernation mode
and four short beeps every minute.
The system doesn’t enter standby mode
after closing the LCD
The system doesn't resume from
hibernation mode.
The system doesn't resume from standby
mode after opening the LCD.
Battery fuel gauge in Windows doesn’t go
higher than 90%.
Press Fn+F4 and see if the computer enters hibernation
mode.
Touchpad
Keyboard
Hard disk connection board
Hard disk drive
Main board
LCD cover switch
Main board
Hard disk connection board
Hard disk drive
Main board
LCD cover switch
Main board
Remove battery pack and let it cool for 2 hours.
Refresh battery (continue use battery until power off, then
charge battery).
Battery pack
Main board
70 Chapter 4
Power Management-Related Symptoms
Symptom / Error Action in Sequence
System hangs intermittently. Reconnect hard disk drives.
Hard disk drive connector
Main board
Peripheral-Related Symptoms
Symptom / Error Action in Sequence
System configuration does not match the
installed devices.
External display does not work correctly. See if there is an error beep. If there is an erro beep, then
USB does not work correctly USB device cable is firmly connected into the USB ports.
Print problems. Ensure the “Parallel Port” in the “System Devices” of BIOS
Enter BIOS Setup Utility to execute “Load Setup defaults”,
then reboot system.
Reconnect hard disk/CD-ROM/diskette drives.
change main board.
Power off. Then check if RAM CPU BIOS are well-
connected.
Press Fn+F5 three times slowly
LCD FPC
LCD inverter
LCD
Test one USB port each time.
USB socket is firmly secured to the main board.
Main board
Setup Utility is set to Enabled.
Onboard Devices Configuration
Run parallel port test
Printer driver
Printer cable
Printer
Main board
Keyboard/Touchpad-Related Symptoms
Symptom / Error Action in Sequence
Keyboard (one or more keys) does not
work.
Touchpad does not work. Reconnect touch pad cable. Modem port is secured to the
Chapter 4 71
Reconnect the keyboard cable.
Keyboard
Main board
main board
Touch pad FPC
Audio/Touch pad board
Main board
Modem-Related Symptoms
Symptom / Error Action in Sequence
Internal modem does not work correctly. Ensure the telephone cable is firmly plugged into the
telephone wall socket and the modem port of the computer.
Modem phone port is secured to the main board.
modem combo board
Main board
72 Chapter 4
Intermittent Problems
Intermittent system hang problems can be caused by a variety of reasons that have nothing to do with a
hardware defect, such as: cosmic radiation, electrostatic discharge, or software errors. FRU replacement
should be considered only when a recurring problem exists.
When analyzing an intermittent problem, do the following:
1. Run the diagnostic test for several times to isolate the problem.
2. If no error is detected, do not replace any FRU.
3. If any error is detected, replace the FRU. Rerun the test to verify that there are no more errors.
Chapter 4 73
Undetermined Problems
The diagnostic problems does not identify which adapter or device failed, which installed devices are incorrect,
whether a short circuit is suspected, or whether the system is inoperative.
Follow these procedures to isolate the failing FRU (do not isolate non-defective FRU).
NOTE: Verify that all attached devices are supported by the computer.
1. Power-off the computer.
2. Visually check them for damage. If any problems are found, replace the FRU.
3. Remove or disconnect all of the following devices:
! Non-Acer devices
! Printer, mouse, and other external devices
! Battery pack
! Hard disk drive
! DIMM
! CD-ROM/Diskette drive Module
! PC Cards
4. Power-on the computer.
5. Determine if the problem has changed.
6. If the problem does not recur, reconnect the removed devices one at a time until you find the failing FRU.
7. If the problem remains, replace the following FRU one at a time. Do not replace a non-defective FRU:
! Main board
! LCD assembly
74 Chapter 4
Jumper and Connector Locations
Top View
Chapter 5
Item Description
JP1 CRT
JP2 Parallel Port
JP3 TV-Out Connector
JP4 RJ11/45 Connector
JP5 1394 Connector
JP6/7/8 USB Connector
JP9 Modem Connector
JP1 1 PCMCIA Connector
JP12/13 AGP Connector
JP15 FAN Connector
JP16 MDC Connector
JP17 System Connector
JP18 R-SPK Connector
JP19 L-SPK Connector
JP20 T/P Connector
JP21 KB Connector
JP22 SO-DIMM1 Connector
JP23 CD-ROM Connector
JP25 HDD Connector
JP32 Cardreader Connector
Chapter 5 75
Item Description
JP34 Subwoofer Connector
JP35 Bluetooth Connector
U9 CPU
U12 North Bridge
U8 South Bridge
PCN2 AC Jack
PCN3 Battery Connector
76 Chapter 5
Bottom View
Item Description
JP28 Mini-PCI Connector
JP30 SO-DIMM0 Connector
Chapter 5 77
FRU (Field Replaceable Unit) List
This chapter gives you the FRU (Field Replaceable Unit) listing in global configurations of Aspire 2000.
Refer to this chapter whenever ordering for parts to repair or for RMA (Return Merchandise Authorization).
Please also note that there are some common parts for Aspire 2000, yet the LCD modules are different
in two model.
Please note that WHEN ORDERING FRU PARTS, you should check the most up-to-date information
available on your regional web or channel. For whatever reasons a part number change is made, it
will not be noted on the printed Service Guide. For ACER AUTHORIZED SERVICE PROVIDERS,
your Acer office may have a DIFFERENT part number co de from those given in the FRU list of this
printed Service Guide. You MUST use the local FRU list provided by your regional Acer office to
order FRU parts for repair and service of customer machines.
NOTE: To scrap or to return the defective parts, you should follow the local government ordinance or
regulations on how to dispose it properly, or follow the rules set by your regional Acer office on how to
return it.
Chapter 6
Chapter 6 77
Exploded Diagram
78 Chapter 6
Chapter 6 79
ADAPTER
BATTERY
BOARDS
Picture No. Part Name/ Description Part Number
N/A ADAPTER W/LED -DELTA 65W ADP-65B
ADAPTER W/O LED - LITEON 65W PA1650-02CR
BATTERY LI-ION 12 CELLS-PANASONIC
GC86503PAJ0
BATTERY LI-ION 12 CELLS-SAMSUNG
GC86508SMG0
MODEM BOARD AMBIT T60M283 54.A14V5.001
AP.A1401.001
AP.T3503.001
BT.A1405.001
BT.A1401.001
MINI PCI WIRELESS BOARD (802.11b)
INTEL
N/A MINI PCI WIRELESS BOARD (802.11a+b)
INTEL
LAUNCH BOARD 55.A14V5.002
N/A WIRELESS & B/T SWITCH BOARD 55.A14V5.003
VGA BOARD 55.A14V5.004
LCM BOARD 55.A14V5.005
54.A14V5.002
54.A14V5.003
80 Chapter 6
CABLES
Picture No. Part Name/ Description Part Number
LCD INVERTER 19.A14V5.001
CARD READER WIRE SET 50.A14V5.001
LAUNCH BOARD CABLE 50.A14V5.002
MODEM CABLE 50.A14V.003
TOUCHPAD FFC CABLE 50.A14V5.004
BLUETOOTH CABLE 50.A14V5.005
LCD COAXIAL CABLE-15.4” WXGA
LCD COAXIAL CABLE-15.4” WSXGA
N/A POWER CORD US
POWER CORD EC
POWER CORD AUS
POWER CORD UK
POWER CORD SWISS
POWER CORD CHINA
POWER CORD ITALIAN
POWER CORD DENMARK
50.A14V5.007
50.A14V5.008
27.A14V5.001
27.A14V5.002
27.A14V5.003
27.A14V5.004
27.A14V5.005
27.A14V5.006
27.A14V5.007
27.A14V5.008
Chapter 6 81
Picture No. Part Name/ Description Part Number
COVER/CASE/BRACKET ASSSEMBLY
MIDDLE COVER 42.A14V5.001
LOWER COVER 60.A14V5.001
N/A DIMM COVER 42.A14V5.002
UPPER CASE ASSY 60.A14V5.002
MINI PCI COVER 42.A14V5.003
TOUCHPAD BRACKET W/FPC 33.A14V5.001
K/B SUPPORT PLATE 33.A14V5.002
VGA BRACKET 33.A14V5.003
LCD PANEL WITH LOGO 60.A14V5.003
82 Chapter 6
Picture No. Part Name/ Description Part Number
N/A PCMCIA SLOT 22.A14V5.001
COMMUNICATION MODULE
LCD BEZEL 42.A14V5.008
LCD BRACKET L 33.A14V5.006
LCD BRACKET R 33.A14V5.007
ANTENNA ASSY 50.A14V5.006
CPU/PROCESSOR
N/A INTEL PENTIUM-M(BANIAS)1.4GHZ
DVD/CDRW DRIVE
N/A DVD/CDRW COMBO MODULE HLDS
1M/400MHZ FSB
INTEL PENTIUM-M(BANIAS)1.5GHZ
1M/400MHZ FSB
INTEL PENTIUM-M(BANIAS)1.6GHZ
1M/400MHZ FSB
INTEL PENTIUM-M(BANIAS)1.7GHZ
1M/400MHZ FSB
INTEL PENTIUM-M(BANIAS)1.8GHZ
1M/400MHZ FSB
(SLOT IN)(GCC4241N)
DVD/CDRW COMBO DRIVE HLDS (SLOT
IN)(GCC4241N)
KC.BS001.14G
KC.BS001.15G
KC.BS001.16G
KC.BS001.17G
KC.BS001.18G
6M.A14V5.001
KO.02406.003
Chapter 6 83
Picture No. Part Name/ Description Part Number
HDD/HARD DISK DRIVE
N/A HDD 2.5” HGST MORAGA
DVD/CDRW COMBO BEZEL FOR
HLDS(TRAY)
OPTICAL DEVICE BRACKET 33.A14V5.004
IC25N030ATMR04-0 08K0910 30G
4200RPM
HDD 2.5” HGST MORAGA
IC25N040ATMR04-0 08K0633 30G
4200RPM
HDD 2.5” HGST MORAGA
IC25N060ATMR04-0 08K0634 60G
4200RPM
HDD 2.5” HGST MORAGA
IC25N080ATCS04-0 08K0635 80G
4200RPM
HDD 2.5” HGST MORAGA
HTS548060M9AT00 08K0638 60G
5400RPM
HDD 2.5” HGST MORAGA
HTS548080M9AT00 08K0638 60G
5400RPM
HDD 2.5” TOSHIBA NEPTUNE
MK3021GAS 30GB 4200RPM
HDD 2.5” TOSHIBA NEPTUNE
MK4021GAS 40GB 4200RPM
HDD 2.5” TOSHIBA NEPTUNE
MK6021GAS 60GB 4200RPM
HDD 2.5” FUJITSU V-40 MHT2030AT 30G
4200RPM
HDD 2.5” FUJITSU V-40 MHT2040AT 40G
4200RPM
HDD 2.5” FUJITSU V-40 MHT2060AT 60G
4200RPM
42.A14V5.004
KH.03007.002
KH.04007.004
KH.06007.002
KH.08007.002
KH.06007.003
KH.08007.003
KH.33004.001
KH.34004.001
KH.36004.001
KH.03006.002
KH.04006.002
KH.06006.002
HDD CARRIER 42.A14V5.007
84 Chapter 6
Picture No. Part Name/ Description Part Number
KEYBOARD
LCD MODULE
LCD
HDD TOP COVER 33.A14V5.005
HDD CONNECTOR 20.A14V5.001
KEYBOARD ARABIC
KEYBOARD BELGIUM
KEYBOARD CHINESE
KEYBOARD CZECH
KEYBOARD DANISH
KEYBOARD FRENCH
KEYBOARD GERMAN
KEYBOARD IT ALIAN
KEYBOARD NORWEGIAN
KEYBOARD PORTUGUESE
KEYBOARD SPANISH
KEYBOARD SWEDEN
KEYBOARD SWISS/G
KEYBOARD THAI
KEYBOARD UK
KEYBOARD US INTERNALTION
KEYBOARD HUNGAIAN
KEYBOARD CANADIAN FRENCH
KEYBOARD RUSSIAN
ASSY LCD MODULE 15.4” WXGA
SAMSUNG (L TN154I1-L02)
ASSY LCD MODULE 15.4” WXGA CMO
(L TN154X1-L02)
ASSY LCD MODULE 15.4” WXGA LG
(L TN154W01-A3)
ASSY LCD MODULE 15.4” WXGA CPT
(CLAA154WA01)
ASSY LCD MODULE 15.4” WSXGA LG
(LP154W02-A1)
ASSY LCD MODULE 15.4” WSXGA
SAMSUNG (L TN154P1-L02)
KB.A1402.011
KB.A1402.013
KB.A1402.005
KB.A1402.015
KB.A1402.018
KB.A1402.006
KB.A1402.003
KB.A1402.004
KB.A1402.017
KB.A1402.010
KB.A1402.009
KB.A1402.014
KB.A1402.008
KB.A1402.012
KB.A1402.002
KB.A1402.001
KB.A1402.016
KB.A1402.007
KB.A1402.019
6M.A14V5.004
6M.A14V5.005
6M.A14V5.006
6M.A14V5.007
6M.A14V5.008
6M.A14V5.009
Chapter 6 85
Picture No. Part Name/ Description Part Number
MAINBOARD
MEMORY
N/A 256MB DDR333 HYS64D32020GDL-6-B
FAN
LCD 15.4” WXGA SAMSUNG
(LTN154I1-L02)
LCD 15.4” WXGA CMO
(L TN154X1-L02)
LCD 15.4” WXGA LG
(LP154W01-A3)
LCD 15.4” WXGA CPT
(CLAA154WA01)
LCD 15.4” WSXGA LG
(LP154W02-A1)
LCD 15.4” WSXGA SAMSUNG
(L TN154P1-L02)
MAINBOARD W/PCMCIA SLOT, W/O
CPU, MEMORY
INFINEON
256MB DDR333 HYS64D64020GBDL-6-B
INFINEON
256MB DDR333 MT8VDDT3264HDG-
335C3 MICRON
512MB DDR333 MT16VDDS6464HDG-
335C3 MICRON
256MB DDR333 NT256D64SH8BAGM-6K
NANYA
512MB DDR333 NT512D64S8HBAFM-6K
NANYA
FAN 23.A14V5.001
LK.15406.001
LK.1540D.001
LK.15408.001
LK.1540A.001
LK.15408.002
LK.15406.002
MB.A1402.001
KN.25602.009
KN.51202.007
KN.25604.009
KN.51204.006
KN.25603.009
KN.51203.005
HEATSINK
THERMAL MODULE 60.A14V5.004
86 Chapter 6
Picture No. Part Name/ Description Part Number
POINTING DEVICE
READER
SPEAKER
TOUCHPAD 56.A14V5.001
4 IN 1 CARD READER BOARD 55.A14V5.006
SPEAKER SET (R&L) - VECO 6K.A14V5.001
SUB-WOOFER-FORTUNE 23.A14V5.002
MISCELLANEOUS
N/A LCD RUBBER
SCREW LIST
N/A SCREW,JIM M2.0X4
LCD SCREW PAD
RUBBER FOOT
SCREW,JIM M2.5X4
SCREW,JIM M2.5X5
SCREW,JIM M2.5X10
SCREW,JIM M2.5X14
SCREW,JIM M3.0X3
SCREW,JPM M2.0X8 (Ni)
SCREW,JPM M2.0X6 (Ni)
SCREW,JACK SCREW
SCREW,M2.5X5
SCREW,SPECIAL SCREW
47.A14V5.001
47.A14V5.002
47.A14V5.003
86.A14V5.001
86.A14V5.002
86.A14V5.003
86.A14V5.004
86.A14V5.005
86.A14V5.006
86.A14V5.007
86.A14V5.008
86.A14V5.009
86.A14V5.010
86.A14V5.011
Chapter 6 87
Model Definition and Configuration
Aspire 2000 series
Appendix A
Model
Number
AS2001WLCi PM1.4G 15.4
AS2001WLMi PM1.4G 15.4
AS2003WLMi PM1.6G 15.4
2001WLCi PM1.4G 15.4
2001WLMi PM1.4G 15.4
2002WLCi PM1.5G 15.4
2002WLMi PM1.5G 15.4
2003WLMi PM1.6G 15.4
CPU LCD Memory HDD Optical
WXGA
WXGA
WXGA
WXGA
WXGA
WXGA
WXGA
WXGA
1x256M/
2x256M
1x256M 40G 2X DVD-
2x256M 60G 2X
1x256M
2x256M
2x256M 40G/
2x256M 40G 24X
2x256M 60G
2x256M 60G
40G/
60G
(4200rp
m)
40G 24X
60G
(4200rp
m)
(4200rp
m)
(4200rp
m)
DVD+C
D-RW
DVD+C
D-RW
DVD+C
D-RW
2X DVD-
DVD+C
D-RW
2X DVD-
2X DVD-
24X
RW
RW
RW
RW
Card
Reader
4 in 1 11b Li-ion
4 in 1 11b Li-ion
4 in 1 11b Li-ion
4 in 1 11b Li-ion
4 in 1 11b Li-ion
4 in 1 11b Li-ion
4 in 1 11b Li-ion
4 in 1 11b Li-ion
Mini
PCI
Battery
Appendix A 88
Appendix B
Test Compatible Components
This computer’s compatibility is tested and verified by Acer’s internal testing department. All of its system
functions are tested under Windows XP Home environment.
Refer to the following lists for components, adapter cards, and peripherals which have passed these tests.
Regarding configuration, combination and test procedures, please refer to the Aspire 2000 Compatibility
Test. Report released by the Acer Mobile System Testing Department.
Appendix B 89
Microsoft Windows XP (Home) Environment Test
Component Manufacturer Specifications
Banias 1.4 GHz
Banias 1.5 GHz
Banias 1.6 GHz
Banias 1.7GHz
256MB DDR-333 Infineon
512MB DDR-333 Micro
Intel 400 MHz FSB RH80535GC0171M
400 MHz FSB RH80535GC0211M
400 MHz FSB RH80535GC0251M
400 MHz FSB RH80535GC0291M
HYS64D32020GDL-6-B
Micro
Infineon
MT8VDDT3264HDG-335C3(13u)
MT16VDDF6464HG-335C2(13u)
HYS64D64020GBDL-6-B
ATI VRAM Hynix
Infineon
Samsung
15.4” WXGA TFT Samsung
LG
CMO
15.4” WSXGA+TFT LG LP154W02-A1
15.4” WXGA LCD CABLE Hannstar
Hightek
Wanshih
15.4” WSXGA +LCD CABLE Hannstar
Hightek
Wanshih
86-Key Keyboard Zippy
Jing Mold
Inverter Ambit
Sumida
Trackpad Synaptics TM42puf1372
30GB HDD ATA-100 (4200RPM) HGST
Toshiba
40GB HDD ATA-100 (4200RPM) HGST IC25N040 ATMR04-0
60GB HDD ATA-100 (4200RPM) HGST
Toshiba
80GB HDD ATA-100 (4200RPM) HGST
Toshiba
60GB HDD ATA-100(5400RPM) HGST HTS548060M9AT00
80GB HDD ATA-100(5400RPM) HGST HTS548080M9AT00
DVD/RW (COMBO) Panasonic(slot-in)
HLDS (Tray)
DVD/Multi Panasonic (slot-in) UJ-8 15 (HW/FW)
8-Cell Li-Ion Samsung(2200)
Panasonic(2200)
802.11b/a+b Antenna WNC
WNC
4M32AF-3.6/550
4M32-3.3/600
4M32E-3.6/550
LTN154X1-L02
LP154W01-A3
N154I1-L02
COMMON T51I056.03
COMMON TWS-442-132
IC25N030ATMR04-A
MK3021 GAS
IC25N060ATMR04-0
MK6021GAS
IC25N080ATMR04-0
MK8021GAS
CW-8122 (HW/FW)
GCC-4241N (HW/FW)
ICR18650-22
CGR18650C
81.EBF15.001
81.EBF15.002
90 Appendix B
Component Manufacturer Specifications
802.11b (Mini-PCI) Intel Centrion WM3B2100NA_MOW
Modem(MDC) Ambit T60M283
Windows XP Home
Windows XP Pro
Slimline 65W AC Adapter LITEON
Microsoft
Microsoft
Delta
w/SP1
w/SP1
PA-1650-02CR
ADP-65B
Appendix B 91
Appendix C
Online Support Information
This section describes online technical support services available to help you repair your Acer Systems.
If you are a distributor, dealer, ASP or TPM, please refer your technical queries to your local Acer branch
office. Acer Branch Offices and Regional Business Units may access our website. However some information
sources will require a user i.d. and password. These can be obtained directly from Acer CSD Taiwan.
Acer's Website offers you convenient and valuable support resources whenever you need them.
In the Technical Information section you can download information on all of Acer's Notebook, Desktop and
Server models including:
! Service guides for all models
! User's manuals
! Training materials
! Bios updates
! Software utilities
! Spare parts lists
! TABs (Technical Announcement Bulle tin)
For these purposes, we have included an Acrobat File to facilitate the problem-free downloading of our
technical material.
Also contained on this website are:
! Detailed information on Acer's International Traveler's Warranty (ITW)
! An overview of all the support services we offer, accompanied by a list of telephone, fax and email
contacts for all your technical queries.
We are always looking for ways to optimize and improve our services, so if you have any suggestions or
comments, please do not hesitate to communicate these to us.
Appendix C 92
Loading...
