Acclaim Lighting AL Panel Pro Frame User Manual

AL Panel Pro Frame
Indoor Fixtures
-xxx-xxxx
APL
Control:
2 = DMX
Housing:
1 = Black Color
Cover:
4 = No Cover
Model number
LED Config:
A = 12x25 LEDs
System
Beam angle:
A = Open beam
100-240Vac + DMX-1000
1 Compleet Frame AC Power-cable + 1 DMX Cable DMX-1000 300 40 mm Controled by 900 DMX Channels XB-R1 Setup Tool 24Vdc 4,8A 300 x SMD 5050 120W 300 gr / 480 gr Metal Frame and Polycarbonate Panels
50.000 hours
-0 °C ~ +37 °C
-20 °C ~ +60 °C 1 x Frame and 1 x X-PD-150 and 12 x AL Panel Pro and link cables
Version:
Color:
C
= WW 3200k
G
= CW 6000k
H
= RGB
N
= Red
P
= Green
Q
= Blue
E = 240Vac ( VDE plug ) U = 100Vac ( UL plug )
Model Number
APL-214-AAHE APL-214-AAHU
Product name
AL Panel Pro Frame (VDE) AL Panel Pro Frame (UL)
800mm [2'-7.5"]
500mm [1'-7.7"]
Luminous Intensity
520 cd/m² 520 cd/m²
652mm [2'-1.7"]
600mm [1'-11.6"]
Beam
120º 120º
Dimensions
400mm [1'-3.7"]
Projects
Color
RGB RGB
Delivery including
12 x AL Panel Pro and 1 x X-PD-150 (VDE) 12 x AL Panel Pro and 1 x X-PD-150 (UL)
730mm [2'-4.7"]
650mm [2'-1.6"]
147mm [5.8"]
www.acclaimlighting.com
** All rights reserved. Improvements changes to specifications, design, and all contents in this catalog may be made at any time without prior notice.
