ABBYY FlexiCapture - 8.0 User Manual

ABBYY FlexiCapture 8.0

Professional

User’s Guide

Dear User,

This guide explains the core principles behind ABBYY FlexiCapture 8.0 Professional. Please read this guide carefully before using the program.

For more information, please consult the following documentation:

• Online help can be accessed from the menu or by pressing F1. The help file can also be accessed from

Start > Programs > ABBYY FlexiCapture 8.0 Professional > Helps.

• The ABBYY FlexiCapture 8.0 Professional System Administrator’s Guide can be accessed from Start >

Programs > ABBYY FlexiCapture 8.0 Professional > Guides > Administrator's guide.

• The operator’s guide can be accessed from Start > Programs > ABBYY FlexiCapture 8.0 Professional >

Guides > Operator's guide.

• The guide for creating machine readable forms can be accessed from Start > Programs > ABBYY

FlexiCapture 8.0 Professional > Guides > Creating a Machine-Readable Form.

• Online help for FlexiLayout Studio 8.0 and FormDesigner 8.0 can be accessed from the menu of the

corresponding application or by pressing F1. The help file can also be accessed from Start > Programs > ABBYY FlexiCapture 8.0 Professional > Helps.

• The ABBYY FlexiLayout Studio tutorials can be accessed from Start > Programs > ABBYY

FlexiCapture 8.0 Professional > Guides > Tutorials.

To learn how to use the program effectively, we recommend that, in addition to reading the help files, you also set

up a project for processing documents of a certain type. As an example, you can use a special User Questionnaire, a copy of which is located on the <disk name>:\Documents and Settings\All Users\Application Data\ ABBYY\FlexiCapture\ 8.0\Samples\FormDesigner\English\Questionnaire (For

<disk name>:\\Users\Public\ABBYY\FlexiCapture8.0\Samples

you go through this guide, you will see instructions in boxes. These will teach you the main steps involved in program set-up and document processing, and allow you to view the results once the completed questionnaire has been processed. If you experience difficulties setting up the project, open a ready-made project called

Questionnaire.fcproj, which can be found in <disk name>:\Documents and Settings\All Users\Application Data\ABBYY\ FlexiCapture\8.0\Samples\FlexiCapture\English\Questionnaire (For Microsoft Windows Vista

<disk name>:\\Users\Public\ABBYY\FlexiCapture8.0\Samples\FormDesigner\English\Questionnaire).

Microsoft Windows Vista

\FormDesigner\English\Questionnaire). As

This and other project samples can be accessed from Start > Programs > ABBYY FlexiCapture 8.0 Professional > Helps > FlexiCapture sample projects.

Please export the results to XML format and send them to us. Your feedback will help us learn more about our users and improve the product to better meet your requirements.

We trust that you will find our program pleasant to work with and enjoy using it.

Table of Contents

1. Introduction ........................................................................................................................................................................4

1.1. The aim of document and data capture .....................................................................................................................4

1.2. Automated document and data capture .....................................................................................................................4

2. Administrator and Operator Functions ...............................................................................................................................5

3. What Documents Can Be Processed with ABBYY FlexiCapture 8.0 Professional?..........................................................5

4. Setting Up the System for Capturing Fixed Forms.............................................................................................................7

4.1. Creating a fixed form template..................................................................................................................................7

4.1.1. Form elements .................................................................................................................................................8

4.1.2. Marking of data fields......................................................................................................................................9

4.2. Creating a project....................................................................................................................................................11

4.3. Creating a document template.................................................................................................................................12

4.3.1. Document Template Editor............................................................................................................................13

4.3.2. Using elements to mark objects on the form .................................................................................................14

4.3.2.1. Field groups .........................................................................................................................................15

4.3.2.2. Fields without marking ........................................................................................................................15

4.3.2.3. Marking of Tables................................................................................................................................16

4.3.2.4. Fields with multiple regions.................................................................................................................16

4.3.2.5. Fields with multiple instances..............................................................................................................17

4.3.2.6. Excluding a region from recognition ...................................................................................................17

4.3.2.7. Deleting fields......................................................................................................................................18

4.3.3. Static elements...............................................................................................................................................18

4.3.3.1. Peculiarities of barcodes ......................................................................................................................19

4.3.4. Field properties..............................................................................................................................................19

4.3.4.1. Common field properties......................................................................................................................19

4.3.4.2. Data types.............................................................................................................................................20

4.3.4.2.1. Data types of a text entry field..........................................................................................................21

4.3.4.2.2. Data types for checkmarks ...............................................................................................................23

4.3.4.2.3. Data types for a checkmark group....................................................................................................24

4.3.4.3. Field recognition properties .................................................................................................................25

4.3.4.3.1. Recognition properties of a text entry field ......................................................................................25

4.3.4.3.2. Recognition properties of checkmarks and checkmark groups ........................................................27

4.3.4.3.3. Barcode recognition properties.........................................................................................................29

4.3.4.3.4. Picture recognition properties...........................................................................................................29

4.3.4.4. Verification parameters........................................................................................................................29

4.3.4.5. Picture export options ..........................................................................................................................30

4.3.4.6. Rule-based checks................................................................................................................................31

4.3.5. Creating a template for a multi-page document.............................................................................................33

4.3.6. Creating a template for a document with annex pages ..................................................................................35

4.3.7. Setting up data export....................................................................................................................................36

4.3.7.1. Export to files.......................................................................................................................................36

4.3.7.2. Export to a database .............................................................................................................................37

4.3.7.3. Export to a SharePoint library..............................................................................................................39

4.3.7.4. Custom export......................................................................................................................................41

4.3.8. Setting up the recognized data view ..............................................................................................................42

4.3.9. Editing and publishing a template .................................................................................................................42

4.1.10. Testing the template.......................................................................................................................................42

4.4. Setting up image import..........................................................................................................................................43

5. Setting Up the System for Processing Flexible Documents .............................................................................................44

6. Peculiarities of Capturing Non-Structured Documents ....................................................................................................45

7. Working with a Set-Up Project.........................................................................................................................................46

7.1. Adding images ........................................................................................................................................................46

7.2. Recognition.............................................................................................................................................................47

7.3. Verification .............................................................................................................................................................48

7.4. Export......................................................................................................................................................................52

8. Conclusion........................................................................................................................................................................53

1. Introduction

1.1. The aim of document and data capture

All sorts of different documents are now used everywhere, by businesses, industries, and services alike. Applications, surveys, and invoices are an important part of the work of every enterprise or institution. The current standard of information technology makes it impossible to operate with paper documents only: most data must be converted into electronic format for storage, analysis, and further processing.

The main difficulty in processing a paper document is in entering the data into a computer system. Traditional manual data input can only be justified if the volume of information is relatively small. If the volume of information is large, manual input is inefficient because it is far too labor-intensive, slow, and expensive. Manual input cannot be made more efficient overnight and the time and expense incurred by an increase in manual input is more or less equivalent to the cost of starting the entire process cycle from scratch.

Manual data input is clearly far from ideal. The alternative is much less problematic and much more efficient – an automated data and document capture system. ABBYY FlexiCapture 8.0 Professional is exactly such a system.

1.2. Automated document and data capture

ABBYY FlexiCapture 8.0 Professional is a software system for capturing data from documents of various types: fixed forms, semi-structured documents, and non-structured documents.

Automated data capture involves the following steps:

• Scanning of a batch of pages using a scanner;

• Automatic assembly of scanned pages into documents;

• Automatic character recognition;

• If the program has generated multiple hypotheses about certain characters (i.e. the recognition of

these characters is uncertain), the characters are sent to the verification operator;

• Export of verified data to a file or database and saving of document images to the specified

folder. Images may be saved in graphical format or searchable PDF;

ABBYY FlexiCapture 8.0 Professional is an efficient solution for automated data capture that allows

you to monitor and manage data processing and to control the quality of input data.

The benefits of using ABBYY FlexiCapture 8.0 Professional

• Low cost. The system can be set up so that most operations are performed automatically, almost

completely without human intervention. The operator need only enter batches of documents into the scanner feeder and verify uncertain characters. Instead of several workplaces devoted to manual data input, you therefore only need one workplace equipped with ABBYY FlexiCapture

8.0 Professional.

• Faster input. Automating the entire process can significantly speed up document processing.

• High recognition quality. ABBYY award-winning technologies allow fast, high quality

character recognition. It is extremely difficult to achieve comparable quality with manual data input without a significant drop in processing speed.

• Convenient to use and easy to learn. ABBYY FlexiCapture 8.0 Professional offers a user-

friendly interface, both for the system administrator and document-processor. No lengthy

training courses are required to work with the program. Users can master the program easily with the help of our technical documentation and reference materials.

• Scalability. Unlike a manual input system, ABBYY FlexiCapture 8.0 Professional is easily

scalable. To increase output, you need only install the system at an additional workplace.

2. Administrator and Operator Functions

To capture data using ABBYY FlexiCapture 8.0 Professional, you need to set up the system to process a certain document type. Administrators specify the necessary settings and operators capture the documents themselves. The number of workstations depends on the volume of documents to be processed.

Administrators specify the system settings and monitor the system. Their duties include:

• Creating new forms (this may also be undertaken by a designer);

• Setting up image import and scanning parameters;

• Preparing document templates, including:

− Setting up recognition parameters;

− Specifying verification and document assembly rules;

− Setting up data export;

• Monitoring the process of data input in the set-up system, advising operators;

Operators are responsible for inputting documents. Using the system as set up by the administrator, they

process completed documents of a certain type. Their duties include:

• Scanning and importing documents;

• Verifying data;

• Exporting data;

Document recognition is automatic.

The program has two modes: Administrator mode and Operator mode. The Administrator has full access to all program functions. Administrator mode can be password-protected. An Operator cannot access template creation and editing or import profile creation. An Operator can work with only one project or only one batch.

When you install the program you can choose between installing only the Operator Station or the complete program. If you select complete installation, you will be able to switch between administrator and operator mode. To select one of the modes, select either

8.0 Professional > ABBYY FlexiCapture 8.0 Professional

> ABBYY FlexiCapture 8.0 Professional Administrator Station or Start > Programs

> ABBYY FlexiCapture 8.0 Professional Operator Station.

Start > Programs > ABBYY FlexiCapture

3. What Documents Can Be Processed with

ABBYY FlexiCapture 8.0 Professional?

ABBYY FlexiCapture 8.0 Professional is a software system used to capture data from documents of various types.

Documents of various types can be processed in a single batch, and you can set up the system for processing documents of a mixed type. A document type only affects the method by which the document template is created. The type of processed documents does not affect the work of an operator.

Let us analyze the various document types that can be processed using ABBYY FlexiCapture 8.0 Professional.

• Structured documents. Structured documents are documents containing a certain number of

specific data fields whose location and marking are identical on all copies of the document. Such documents are called “fixed forms”. Questionnaires, surveys, and application forms are usually fixed forms and are typically paper forms that must be filled out by hand. To identify a specific form from a flow of various documents and to extract data from such a form, you need to create a uniform fixed template that tells the program where to find the necessary data fields. Certain fixed forms are processed more efficiently because they were created to meet specific data capture requirements. Such forms are called “machine-readable forms”. ABBYY FormDesigner

8.0 is an efficient tool for creating machine-readable forms and is supplied together with ABBYY FlexiCapture 8.0 Professional. For more information on creating forms using ABBYY FormDesigner 8.0, please read the ABBYY FormDesigner 8.0 Help file and other documentation. The main steps for creating a template are described specifically for structured documents.

• Semi–structured documents. These are documents containing a number of data fields whose

quantity, marking, and location may vary on different copies of the document. For example, invoices are semi-structured documents because invoices received from different companies often differ with regard to the number of data fields and their format. All invoices have an invoice number and a total payment amount, but these data fields may be located in different places on the document. To identify semi-structured documents and to extract data from them, ABBYY FlexiCapture 8.0 Professional uses flexible templates (FlexiLayouts). To create a flexible template, you must use the special ABBYY FlexiLayout Studio module. For detailed information about this module, please refer to the ABBYY FlexiLayout Studio Help file and User Guide. Flexible document processing differs from fixed document processing only with regard to the creation and attachment of a template.

• Non-structured documents. ABBYY FlexiCapture 8.0 Professional can be used to process non-

structured documents such as contracts, letters, or orders, where the information is presented in a free-form style. The program can automatically identify non-structured documents as attachments to fixed or semi-structured documents, or with the help of a flexible template. These documents can then be exported to searchable PDF files or to graphical files. Data from the index fields of non-structured documents can be extracted manually, or automatically using a flexible template. A typical scenario in which non-structured documents are processed is the conversion of a paper archive into electronic format and the extraction of several index fields for subsequent quick attribute search.

The following chapters describe how to set up ABBYY FlexiCapture 8.0 Professional to process documents of various types, including the automated data capture process, how to improve recognition quality, and how to organize data export.

The capture of structured documents is described in great detail. All processing stages are described using fixed forms as an example. The peculiarities of other document types and the differences concerning the creation of templates for such documents are also explained.

4. Setting Up the System for Capturing Fixed

Forms

ABBYY FlexiCapture 8.0 Professional allows you to capture and process fixed forms quickly and efficiently. The process of working with fixed forms is as follows:

• Designing forms or making existing forms machine-readable;

• Creating a template: describing the geometrical layout of objects, specifying object properties,

creating verification and document assembly rules, setting up data export;

• Setting up the method for adding images and creating image import profiles;

• Document capture, which can start once all the necessary settings are in place.

4.1. Creating a fixed form template

The design of a paper form is very important because its appearance determines whether it is convenient for a user to fill out this form and if the form is suitable for automated data capture. It must be clear to the user where he or she is required to enter the necessary data, and such clarity significantly reduces the risk of errors. When designing a form, you must try to make it as intuitive as possible to fill out. The data entered should also be clearly discernable and easily recognizable.

If a form meets all data capture requirements it is machine-readable. Such forms have the following

properties:

• They possess anchors (or reference marks). These are special auxiliary elements, which help the

program determine the form orientation, match the template, and deskew the scanned image where necessary. Anchors can be represented by black squares, crosses, or corners.

• All fields and graphic elements (separators, anchors, etc.) must be located in exactly the same

place on all copies of the form. All the forms of a given print batch must be created using a single master copy.

• All explanatory information is positioned so as not to hinder the extraction of information from

data fields.

For more information about machine-readable form requirements, please see the ABBYY FlexiCapture

8.0 Professional Help file and the "Guide to Creating Machine-Readable Forms".

ABBYY FormDesigner 8.0 is a special tool for creating machine-readable forms and is supplied with ABBYY FlexiCapture 8.0 Professional. For information on creating machine-readable forms in ABBYY FormDesigner, please refer to the ABBYY FormDesigner Help file and User Guide. ABBYY FormDesigner allows you to create machine-readable forms simply and easily. A form template created in ABBYY FormDesigner can be imported into ABBYY FlexiCapture 8.0 Professional. You will then have a complete layout of all data fields and graphical elements and only need specify the properties of the fields and set up the export.

To make an existing form machine-readable, you need only make some slight design changes and add certain element (in particular anchors). If you cannot change the blank forms for any reason, you can set up the program so that it can process forms without anchors. You can use other form elements as anchors, for example, vertical and horizontal lines, explanatory text, or barcodes. Template matching will however be most efficient if you use standard anchors.

4.1.1. Form elements

Let us analyze the main form elements. (Figure 1)

Figure 1. Sample of a machine-readable form containing the main elements

• Data fields. All forms designed for information gathering contain data fields. These fields are

usually accompanied by an explanatory text. Data fields can be of the following type:

Text fields used to enter text information. Such fields are groups of character cells for

entry of characters. The design of a text field prompts the person filling out the form to use separate characters.

Checkmarks are also designed for information gathering. However, users need not write

any text but only mark the necessary items. A checkmark usually has a closed contour (a square, circle, or polygon), and the information is entered by entering a certain sign (for example, a tick or cross) inside the contour. Sometimes a checkmark does not have a contour, in which case the user must position the sign against the white background in the specified place on the page. If you wish to allow correcting checkmarks, select the corresponding option when creating the template. In such cases an inked-out checkmark will be considered unchecked.

Checkmark groups. A checkmark group consists of several checkmarks located close to

each other and connected logically. As a rule, answers corresponding to checkmarks within a single group are mutually exclusive. In other words, only one checkmark in a group may be checked.

Data fields can also be represented by tables.

• Anchors. Anchors are used to determine page orientation and to match the template. The

program also uses reference elements to monitor and correct (deskew) image distortions that may appear during scanning. Anchors can be represented by black squares (preferably), crosses, or corners. We recommend that you use 5 anchors on a form: four at each corner and one at one of the sides, in order for the page orientation to be reliably detected. Template matching will then be fast and accurate. In addition, you will be able to capture in a single stream forms printed using different printers and even those received by fax.

• Identifiers. Identifiers are used to detect the form to which a page belongs and to select the

necessary template if there are several templates with similar sets of reference elements in the batch. If you process several forms in a single stream, you must put a unique element on each page of a form. This element will tell the program to which form the page belongs. Identifiers can be barcodes, anchors, separators, or static text (for example, a form title or a piece of explanatory text).

• Graphical images. You may need to save certain objects as images such as pictures, signatures,

seals, or stamps, for example. ABBYY FlexiCapture 8.0 Professional can save image objects and export them to files or databases.

• Decorative elements. A form can contain certain decorative elements, for example a company

logo.

4.1.2. Marking of data fields

All machine-readable forms can be divided into the following groups by arranging and marking character cells: color drop-out forms, raster forms, and black-and-white linear forms.

• Color drop-out forms. Character cells on such forms are white rectangles against a color or

grayscale background. Each character cell is intended for one character. You must select the

background color and saturation so that the program can easily remove the background during scanning. Ideally, only anchors and filled-out data fields are retained after scanning and despeckling: all other elements must be removed. For this type of processing, you must use a monochrome scanner with a color lamp (red or green), or a color scanner that has a setting to allow the background color to be removed.

• Raster forms. To draw character cells, raster forms use dots spaced an equal distance apart. After

scanning, these dots are removed from the image using the “Despeckle” option, without any loss of information in filled-out data fields. Character cells can be rectangles with borders made up of raster lines, i.e. sequences of small black dots, or white rectangles on a raster background made up of individual dots.

• Black-and-white linear forms. In the case of black-and-white linear forms, field borders are

simple lines which remain on the scanned image. During recognition, the program therefore has to first separate the field border from the field content, and then recognize the content. Based on the information about the number of character cells in the data field and the method of separating the cells from each other, the program detects vertical and horizontal lines on the layout and separates them from the field content.

The questionnaire that you have created in ABBYY FlexiCapture 8.0 Professional is a good example of a machine-readable fixed form and is clearly identifiable as a color drop-out form. Please analyze the arrangement of the main elements on this form.

4.2. Creating a project

A project contains all of the necessary document capture settings: document templates, image import

profiles, program settings, and processed documents.

Documents are grouped into batches. The number of batches depends on your processing approach: you

can process all documents in one batch, or you can sort documents into batches according to their date of import or scanning date.

Documents are processed in work batches. Only work batches are accessible in operator’s mode. Test batches are used by the administrator to test and adjust templates. The main difference between the two

types of batches is that local templates are used to process documents from test batches while published templates are used to process documents from work batches.

A document contains images of one or several pages (single-page and multi-page documents) and data

extracted from these pages.

A project can contain several templates, in which case documents of different types will be processed within a single project. As a result, you will not have to sort the document to be processed because documents of different types can be captured in a single stream. If, however, document streams do not intersect, you can create a separate project for them.

To begin with, the administrator must create a project and at least one document template.

To create a project, click Create New… in the Open Pro ject dialog box which appears when you start the program. Alternatively, select File > New Project… in the program main window. Specify the

folder to which the project is to be stored and enter the project name.

To add batches to the project, right-click in the program main window containing the list of batches

(Figure 2) and from the context menu select New Batch. You can load images without creating a batch,

in which case the program will create a batch automatically.

To view documents added to the batch, double-click the batch name. To return to the list of batches,

select Project > Work Batches List or press Ctrl+B.

Figure 2. ABBYY FlexiCapture 8.0 Professional main window

Start ABBYY FlexiCapture 8.0 Professional. To create a project, click Create New… in the Open Project dialog box, which appears when you start the program. Alternatively, select File > New Project… in the program main window. Specify the folder to which the project is to be saved and enter the project name. When you click Create, the new project will open.

4.3. Creating a document template

The most important step in setting up a project is the creation of a template. The quality of data received after forms have been processed depends on the correctness of the template. To create a template, you must specify the:

• Static elem ents on the image: anchors, separators, static text, and barcodes. Select which of these

elements are to be used for template matching and document identification. Anchors are detected and marked automatically.

• Location of all fields. Fields must correspond to the areas of the image from which data is to be

extracted.

• Properties of each field: select the data types to be searched for in every field (this significantly

improves the recognition quality) specify which fields must be sent to the operator for verification, etc.

• Rules by which field values are to be checked. Such rules help the program detect documents

whose values do not conform to certain conditions, for example where a field value does not correspond to the values of the necessary database.

• Method of data export. Data can be exported to a file or database, or in accordance with a script

procedure.

Once the template is created, it must be published in order to use it for subsequent document recognition.

To create a new template, from the menu select Project > Document Templates… Click New… in the dialog box that opens. This will start the Document Template Creation Wizard. In the Create New Document Template dialog box you can specify the template’s main properties: its name, description, locale, and writing style. Select the text type: ICR (hand-printed) if most document fields are filled out by hand, or OCR (printed) if the values in most document fields are printed. In the latter case, select the

print type from the drop-down list. The text type specified at this stage will be the default text type, but you will be able to change the text type for individual fields.

Next, load or scan the image on the basis of which the template is created. If your document consists of several pages, load the first page. When adding the rest of the pages, please refer to the recommendations of the section Creating a template for a multi-page document of a blank page or load it from a file. If you are going to process semi-structured documents, you must

use a flexible description when creating a template. If this is the case, select the Load FlexiLayout

option and specify the path to the AFL file containing the flexible description created in ABBYY FlexiLayout Studio.

You can now select the field types that are to be automatically detected. You can specify checkmarks and text entry fields. Searching automatically for text fields with marking and rectangular checkmarks is highly efficient. However, if text fields on your form contain no marking and checkmarks need to be made against a plain white background, we recommend that you mark such fields manually.

If there are anchors on the image, these will be detected and marked automatically.

. You can scan the image

1. In the program main window, select Project > Document Templates… Click New… in the Document Templates dialog box.

2. In the dialog box that opens, specify the parameters for the template, its name and description. In the Language(locale) field, specify the language in which the form will be filled out. In the Writing style field, select the relevant country. This is because th e shape of certain characters, for example, dig its, may differ between countries. Select the text type: ICR (hand-printed). Click Next.

3. Select the Scan option and scan the blank form without any filters so that the background color is retained. This will make it easier for you to mark data fields on the image of the form (later, when you scan page images for data recognition, you will select a scanning mode which removes the background). The page templ ate will be created on the basis of this image. You can also select the Load from file(s) option and load the image from a file. (You can find an image of a questionn aire in <disk name>:\Documents and Settings\All Users\Application Data\ABBYY\FlexiCapture\8.0\ Samples\FormDesigner\English\Questionnaire, for Microsoft Windows Vista <disk name>:\\Users\ Public\ABBYY\FlexiCapture8.0\Samples\FormDesigner\English\Questionnaire). Click Next.

4. Select the Text and Checkmarks option for automatic marking of text fields and checkmarks. Click Finish.

5. Once the Wizard has completed its work, the Document Template Editor window will open. The questionnaire will be displayed in the window , and all text fields and checkmarks will b e marked. The names of automatically detected template fields will b e displayed in the Document Structure window.

If you switch to Static elements mode (the button), you will see the layout of st atic elements. Anchors will also be marked automatically.

4.3.1. Document Template Editor

All the main actions for creating and editing a template are performed in the Document Template Editor window (Figure 3), which opens once the Template Creating Wizard, has finished. To open the

Document Template Editor from the program main window, select Project > Document Templates…, then select the name of the necessary template and click Edit…

Figure 3. The Document Template Editor

4.3.2. Using elements to mark objects on the form

Once the Template Creating Wizard has finished, the loaded image will be displayed in the Template Editor window. Anchors and data fields of the types you selected during the previous step of template creation will already be marked.

You can automatically mark objects later on by selecting the

tool and clicking on the area of the

element to be marked. The program will automatically detect the type and location of the element.

The Document Template Editor provides intuitive and convenient tools to mark fields and static elements. The Editor has two modes:

• Field marking mode (the

• Static elements mode (the

tool), and

tool).

To create a static element or data field manually, switch to Field marking or Static elements mode and click the corresponding button on the toolbar. To create a corresponding element, drag the cursor to draw a rectangle around the necessary object on the form. Alternatively, select the necessary tool and Shift-Click near the object. The area of the data field or static element will now be detected automatically.

Next, follow the list of tools for creating elements of different types:

Fields:

- text entry field

- checkmark

Static elements:

- anchor

- separator

- checkmark group

- barcode

- static text

- barcode

- graphical element (picture)

- table

- group field

A barcode can be both a recognition field and a static element. You must be careful when selecting the marking mode: if data is to be extracted from the barcode, use Field-marking mode. If the barcode is used for document identification and template matching, mark it in Static elements mode.

Created fields appear in the list on the Fields tab of the Document Structure window. By default, they

are assigned names corresponding to the explanatory text. You can rename a field by selecting it in the document structure and pressing F2. To give the field a name corresponding to the explanatory text,

select the field, right-click on it, and select Get Name From Image… from the context menu. After

this, drag your cursor to draw a rectangle over the explanatory text on the image.

The type of field is marked by an icon in the list of fields and by the color of the frame on the image. Static elements are not included in the list.

You can copy elements (even to other document sections), delete, move elements, or change their sizes. If you copy fields, numbers are automatically added to the names of the fields.

To select several elements simultaneously, use Ctrl-Click. The action performed will then be applied to

all selected elements. To select elements, use the

1. Text entry fields are already automatically marked on the form. If you did not select the Text option

during the final st age of t emplat e cre ation , or if you wish to mark text fields manually, select the tool followed by the fields in which you want to enter text. A field must include all character cells and some additional space o n all sid es. In clude f ields for the fill-in date, name, occupation, country, e-mail address, company name, number of pages processed daily, and the 4 field s for additional information.

2. Please mark the “Your comments and wishes” field. This field has not been detected automatically because it is not marke d.

3. If the checkmarks have not been marked automatically, select the tool and mark all those checkmark boxes that do not belong to any groups. Do not forget to include a litt le extra space on all sides of the checkboxes. The checkmarks that belong to a group need not be marked individually.

Select the tool to draw a r ectangle around all checkmarks that must belong to the group. Each individual checkmark will be automatically marked and assigned a name, following which all these checkmarks will be united in the group.

4. Switch to Static elements mode. Anchors are already marked on the form. Select the tool and mark the barcode on the image.

tool.

4.3.2.1. Field groups

Fields can be grouped to optimize the document structure and to create repetitive field groups. For example, the city, street, and building number can be combined to form the “Home Address”. If you wish to create fields for the work address, you can simply copy the “Home Address” field group.

To combine fields to form a group, use the

tool.

If a document has repetitive field groups, you can create only one group and then create several

instances of this group. All field properties and all rules specified within the original group will be

inherited by all instances of the group. For more information, please see the Fields with multiple instances

section.

You can also copy a field group. In this case, however, the new group will be independent.

4.3.2.2. Fields without marking

Some fields can have no corresponding regions on the image. The names of unmarked fields are marked with a red asterisk. Such fields can be used to store interim results of calculations, which use values from recognition fields.

Unmarked fields possess all the properties typical of their type: they can be sent to the operator for verification, their format can be checked, and the values of such fields can be exported.

There are two methods of creating a field without marking:

1. In the Template Editor window, select Template > Create Field from the menu and create a

field of the necessary type. The name of the field will appear in the list and will be marked with an asterisk. A document structure field is created, but not its region on the image.

2. The second method is by removing the marking of a standard field. Select the necessary fields

on the image or in the list and from the context menu select Delete Region. The marking will

be removed and the name of the field will be marked with a red asterisk.

To create a region on the image for a field without marking, select the

tool from the toolbar and frame the necessary region. If there are any fields marked with an asterisk in the list, the program will prompt you to select a name for one of these fields (for example, if you create the list of document fields first and only subsequently specify their location).

4.3.2.3. Marking of Tables

ABBYY FlexiCapture 8.0 Professional allows you to work with tables. Creating fields of the type “Table” makes it much easier to set up, extract, and export data from tables. A Table field is a set of columns of a single type which contains repetitive rows.

The program has special tools for marking tables in a fixed template. These tools will help you draw a table and mark its columns and rows.

Select the header of the table. Once the table has been created on the image, table-marking tools will appear in the

toolbar. To add separators, mark the table cells using the the pointer inside the table region, drag the dotted separator to the desired location, and click once. Horizontal separators are created in the same manner while holding down the ALT key. You can also detect separators automatically. To detect separators, select the table you have created and then select

either Autodetect Vertical Separators or Autodetect Horizontal Separators from the context menu.

You can delete any separator using the

tool to draw the region of the table. Please note that this region must not include the

tool. To create vertical separators, place

tool. Once you have added the number of separators

required, mark the columns of the table. To do so, select the

tool and use your cursor to specify the region of a column. Each column contains cells of a single type: text, checkmarks, graphical elements or barcodes. The program will prompt you to select the type of column during marking.

Once the table has been marked, you must specify the recognition properties, verification properties, and data type for each column. Column properties are specified just like the properties of standard document fields.

4.3.2.4. Fields with multiple regions

If your form has data fields whose region consists of multiple parts (for example, tables which start on one page and end on the next page), you can create fields with multiple regions to process such objects on the form.

Values from all regions of a field are joined and exported together as one field. Line folding is used as a separator.

To create a field with multiple regions, create the region of one of the fields, select this region and then

select Continue R egion… from the context menu. Move the created region to the desired location on

the page. Select the area on the page where the created region should continue and repeat the procedure as many times as may be necessary.

+ 37 hidden pages
