Selection tables

S800S-B

High performance MCBs - S800 series
with ring terminal connection

S800S-B characteristic

Function: protection and control of the circuits against overloads and short-circuits when a high
breaking capacity is required; protection for people and big length cables in TN and IT systems; very
useful when selectivity is needed vs an MCCB or back-up vs other MCBs wired downstream.

Applications: commercial and industrial.
Standard: IEC/EN 60898, IEC/EN 60947-2
Icn=25 kA
Icu=50 kA

50000

Number
of poles

1

2CCC413001F00022CCC413001F0002

2

Rated
current

In A Type code Order code EAN kg pc.

6
8
10
13
16
20
25
32
40
50
63
80
100
125

6
8
10
13
16
20
25
32
40
50
63
80
100
125

Order
details

S801S-B6-R*
S801S-B8-R*

S801S-B10-R

S801S-B13-R

S801S-B16-R

S801S-B20-R

S801S-B25-R

S801S-B32-R

S801S-B40-R

S801S-B50-R

S801S-B63-R

S801S-B80-R

S801S-B100-R

S801S-B125-R

S802S-B6-R*

S802S-B8-R*

S802S-B10-R

S802S-B13-R

S802S-B16-R

S802S-B20-R

S802S-B25-R

S802S-B32-R

S802S-B40-R

S802S-B50-R

S802S-B63-R

S802S-B80-R

S802S-B100-R

S802S-B125-R

2CCS861002R0065
2CCS861002R0085
2CCS861002R0105
2CCS861002R0135
2CCS861002R0165
2CCS861002R0205
2CCS861002R0255
2CCS861002R0325
2CCS861002R0405
2CCS861002R0505
2CCS861002R0635
2CCS861002R0805
2CCS861002R0825
2CCS861002R0845

2CCS862002R0065
2CCS862002R0085
2CCS862002R0105
2CCS862002R0135
2CCS862002R0165
2CCS862002R0205
2CCS862002R0255
2CCS862002R0325
2CCS862002R0405
2CCS862002R0505
2CCS862002R0635
2CCS862002R0805
2CCS862002R0825
2CCS862002R0845

Bbn
7612271

408268
411480

209636

209643

209650

209667

209674

209681

206826

206833

206840

206857

206864

206871

408275

411497

209698

209704

209711

209728

209735

209742

206888

206895

206901

206918

206925

206932

Price
1 piece

Price
group

Weight
1 piece

0,245 1
0,245 1
0,245 1
0,245 1
0,245 1
0,245 1
0,245 1
0,245 1
0,245 1
0,245 1
0,245 1
0,245 1
0,245 1
0,245 1

0,49 1
0,49 1
0,49 1
0,49 1
0,49 1
0,49 1
0,49 1
0,49 1
0,49 1
0,49 1
0,49 1
0,49 1
0,49 1
0,49 1

Pack
unit

* Standard: EN/IEC 60947-2

Technical details ............................ pag. 11/2 Overall dimensions ........................ pag. 13/5
