ABB Power supply CP-T 24/40.0 Data Sheet

Data sheet

Power supply CP-T 24/40.0

Primary switch mode power supply

The CP-T range of three-phase power supply units is

the youngest member of ABB’s power supply family. In

terms of design and functionality, the new range perfectly

supplements the existing products and extends the

range appropriately. The devices can be supplied with

a three-phase voltage as well as with two-phase mains.

Here, ABB offers a power supply unit with 24 V DC

output with 40 A and efficiency of up to 92 %. As in the

case of all products, they are designed for an ambient

temperature of up to 70 °C.

2CDC 271 048 S0009

Characteristics

– Rated output voltage 24 V DC
– Output voltage adjustable via front-face rotary

potentiometer "OUTPUT Adjust"
– Active current balancing for parallel mode
– Rated output current 40 A
– Rated output power 960 W
– Wide supply voltage range 3 x 400-500 V AC

(340-575 V AC, 480-820 V DC)
– Two-phase supply with a derating of the output to 75 %

possible / permitted
– High efficiency of up to 92 %
– Low power dissipation and low heating
– Free convection cooling (no forced cooling with

ventilators)
– Ambient temperature range during operation -40...+70 °C
– Open-circuit, overload and short-circuit stable
– Integrated input fuse
– Redundancy unit CP-A RU offering true redundancy,

available as accessory
– Signalling contact "13-14" (solid-state) for output

voltage OK

Order data

Approvals

UL 508, CAN/CSA C22.2 No.14

A

ANSI/ISA-12.12 (Class I, Div. 2, Hazardous Locations),

H

CAN/CSA C22.2 No. 213

UL 60950, CAN/CSA C22.2 No. 60950

H

GB4943, GB9254, GB17625.1

R

GOST

D

1)

Approvals refer to rated input voltage U

Marks

CE

a

C-Tick pending

b

1)

in

1)

1)

Power supply

Type Rated input voltage

CP-T 24/40.0 340-575 V AC

Accessory

Type Description Order code

CP-A RU

range

480-820 V DC

The redundancy unit CP-A RU provides decoupling of two 24 V DC CP power supply units.

Rated output voltage Rated output current Order code

24 V DC 40 A 1SVR 427 057 R0000

1SVR 427 071 R0000

2CDC 271 048 S0009

1 Wide input range

INPUT L1, L2, L3, PE: terminals - input

Optimised for worldwide applications: The CP-T
power supply units can be supplied for a wide range
of AC and DC voltages. Both kinds of power supply
(three-phase and two-phase) are possible.

2 Circuit diagram

3 Adjustable output voltage

OUTPUT Adjust: potentiometer

The CP-T range types feature a continuously
adjustable output voltage. Thus, they can be optimally
adapted to the application, e.g. compensating the

1

2 3 4 6 75

voltage drop caused by a long cable length.

4 Indication of operational states

OUTPUT LOW: red LED - output voltage too low
OUTPUT OK: green LED - output voltage OK

5 Signalling contact

OUTPUT 13-14: terminals - signalling contact

6 Current balancing

Current balance CB+, CB-

For active current balancing in parallel operation

7 Output

OUTPUT L+, L+, L-, L-: terminals - output

Application

The primary switch mode power supply offers a three-phase supply voltage range of 3 x 400-500 V AC. A two-phase power
supply is also possible and it can also be supplied by 480-820 V DC. Furthermore, this power supply unit is equipped with
two generous capacitors, which ensure mains buffering of at least 15 ms. That is why the devices can be used worldwide
also in high fluctuating networks and battery-powered plants.

Operating mode

By means of the potentiometer "OUTPUT Adjust" the output voltage can be adjusted within a range of 22.5-28.5 V DC.
Thus, the power supply can be optimally adapted to the application, e.g. compensating the voltage drop caused by a long
line length.

The green LED "OUTPUT OK" is lightening during proper operation, i. e. when the output voltage exceeds 75 %.

The red LED "OUTPUT LOW" is lightening when the output voltage is less than 70 % of the rated output voltage.

Two-phase supply is permissible with a derating of the output to 75 %.

Signalling contact "13-14" (max. 60 V DC / 0.3 A) is ON when the output voltage exceeds 19.4 V.

2 - Power supply CP-T 24/40.0 | Data sheet

Installation

The device must be installed by qualified persons only and in accordance with the specific national regulations (e.g. VDE, etc.).
The devices are maintenance-free chassis-mounted units.

Before installation

DANGER!

Components with high stored energy and circuits with high voltage

Danger to be electrocuted!

► Disconnect the system from the supply network and protect against switching on before any installation,

maintenance or modification work.

► Do not introduce any objects into the unit and do not open the unit.

► Ensure that the service personnel is protected against inadvertent contact with parts carrying energy.

Mounting

The switch mode power supply can be snapped on a DIN rail (TH 35-15 or TH 35-7.5 according to IEC/EN 60715) as
shown in the accompanying picture. For that the device is set with its mounting rail slide on the upper edge of the mounting
rail and locked by lifting it downwards.

2CDC 272 016 F0010

Demounting

Remove the switch mode power supply as shown in the accompanying picture. For that the latching lever is pulled
downwards by means of the screwdriver. Alternatively you can press the unlock button to release the device. Then in both
cases the device can be unhinged from the mounting rail edge and removed.

2CDC 272 017 F0010

Mounting position

The devices have to be mounted horizontally with the input terminals on the bottom. In order to ensure a sufficient
convection, the minimum distance to other modules should not be less than 25 mm (0.98 in) in vertical and horizontal
direction.

[B]

[A]

L1 L2 L3

[B]

L2

L3

L+L1

PWM

L+
L­L-

CP-T 24/40.0

13 14

L+ L+ L- L-

[A]

2CDC 272 012 F0010

Data sheet | Power supply CP-T 24/40.0 - 3
