ABB Potentiometer, buzzer & reset actuator Catalog Page
CBK-KSP5K
Pilot Devices
Non-illuminated
Type CBK 22
Potentiometer, buzzer & reset actuator
mm
8
Potentiometer – with terminal block & leads, UL Type 1
number price
0 – 5 kilohm CBK-KSP5K
0 – 10 kilohm CBK-KSP10K
Note: Both trimmers have resistive elements made from cermet. These types of trimmers are excellent for commercial applications. The cermet
element provides a continuous contact surface for the wiper. A continuous contact surface allows the resistance value to be set closer to the
desired value than a typical wire-wound resistor.
Technical data 1
Resistance range 0 to 5 kilohm for 5 kilohm potentiometer
0 to 10 kilohm for 10 kilohm potentiometer
Resistance tolerance +/- 10%
Power rating 2W
Potentiometer – without terminal block & leads, UL Type 1, 3R, 4, 4X, 12, 13
number price
0 - 5 Kilohm, Black plastic CBK-KSP5K4XP $ 90.00
0 - 5 Kilohm, Chrome metal CBK-MSP5K4XP 95.00
0 - 10 Kilohm, Black plastic CBK-KSP10K4XP 90.00
0 - 10 Kilohm, Chrome metal CBK-MSP10K4XP 95.00
Catalog List
Resistance
Catalog List
Resistance
$ 110.00
8
CBK-KSP5K4XP
CBK-BZ1
Potentiometer without nameplate
Bezel 5 kΩ 10 kΩ List
catalog number catalog number price
CBK 22mm
Black plastic CBK-KSP5K4X CBK-KSP10K4X $ 80.00
Metal CBK-MSP5K4X CBK-MSP10K4X 85.00
Operating knob – without resistor
number price
Black plastic CBK-KKNOB $ 15.00
Chrome metal CBK-MKNOB 20.00
Catalog List
Item
Name plate
number price
Name plate CBK-NPE/SP $ 10.00
Catalog List
Item
Buzzer – UL Type 1, 3R, 4, 4X, 12, 13
type number price
24VAC/DC Continuous CBK-BZ8
115VAC/DC Continuous CBK-BZ1 $ 75.00
230VAC Continuous CBK-BZ2
24VAC/DC Pulsating CBK-BZP8
115VAC/DC Pulsating CBK-BZP1 85.00
230VAC Pulsating CBK-BZP2
Note: Frequency: Approximately 2400 Hz. Loudness: Min 80 dB(A)/10cm, Rated current: ≤8mA. Service life>5000h
Sound Catalog List
Voltage
KPR3-104B
number price
1 At room ambient: +25°C nominal and 50% relative humidity nominal
Discount schedule CA
