Aastra DT288 User Guide

DT288

Cordless Telephone for MD110

User Guide

DT288

Welcome

Welcome to the User Guide for the DT288 cordless phone in the Ericsson Enterprise business communication system MD110.

It is a state-of-the-art business communications system. Its alliance of features and facilities effectively improves communications for virtually any kind of organization.

To take full advantage of these advanced features and facilities there is a line of telephones, designed for ease of use in every situation. Your phone is menu driven. By use of the Scroll keys and the CLR, YES and NO keys you get access to frequently used functions and numbers. Step-by-step instructions in the display assist your actions on the phone.

Some markets use differing codes for some functions. In this guide, all functions are described using the most common code for every specific function. As a note the markets and their differing code is shown.

The User Guide describes the facilities of the Ericsson Enterprise communication system and the DT288 phone as it is programmed at delivery from the factory. There may be some differences in the way your system is programmed. Please consult your system administrator if you need further information.

DT288

Table of Contents

page

Important ................................................4

Description ................................................6

Switching On/Off ....................................11

Free Seating (optional) ............................12

Incoming Calls ........................................13

Outgoing Calls ........................................14

During Calls ............................................17

When You Receive a Busy Tone ............22

Call Forwarding ......................................25

Internal Messages ..................................33

Voice Mail ..............................................35

Information ............................................38

Abbreviated Numbers ............................41

Phone Book ..........................................43

Group Facilities ......................................49

Other Useful Facilities ............................51

Paging (optional) ....................................56

Authority ................................................60

Settings and Adjustments ......................64

Audible Signals ......................................72

Display Information ................................76

Installation ..............................................79

TroubleShooting ....................................82

Index ......................................................84

EN/LZT 103 06 R1B

stored in retrieval system,or transmitted in any form or by any

means, electronic, mechanical, photocopying, recording or

otherwise, without prior written permission of the publisher.

Important

DT288

Important

IPEI code

Your telephone has an International Portable part Equipment Identity (IPEI) code. This code is needed for your system administrator to enable network subscription.

Furthermore you may need the IPEI code to unblock your telephone if an incorrect PIN code has been entered three times (=telephone is blocked).

To find the IPEI of your phone:

Select

Information and press

Select

ShowIPEI and press

Enter your PIN code and press

(Default code: 0000) The IPEI number is displayed.

Note: Once the phone is blocked it is impossible to read the IPEI code in the phone. Therefore, write down the IPEI code but keep the code secret to prevent misuse of your phone.

Important

DT288

Guidelines

Consider these suggestions and guidelines to keep your telephone in good shape and working properly.

Intrinsic safety

The telephone is not specified as intrinsically safe, so do not use these telephones in areas with a danger of explosion.

Battery handling

The battery contains environmental polluting material. If defect, return it to a collecting point.

Cleaning

Clean your telephone only with a soft, water dampened cloth. Using soap or any other cleaning materials may discolour or damage the telephone.

Treatment

Do not expose your telephone to direct sunlight for long periods. Keep the telephone away from excessive heat and moisture.

WWoorrkk 112233 1166--MMaarr 1100::2222

Description

DT288

Description

Antenna

Volume Up

Off hook: raise earpiece volume.

See section “Adjustments”.

Volume Down

Off hook: lower earpiece volume.

See section “Adjustments”.

Off hook / Yes

Answer call, accept.

Cancel key

Delete latest entered digit.

Backspace when editing text.

Cancel a menu option.

Microphone-, ringer- and

warning on/off, see sections

“During calls” and

“Adjustments”.

Control key (up)

Scroll up through menus or

name list.

Move left in choices.

1 / Space

Space, hyphen, etc.,

when editing text.

Battery

See section “Installation”.

Star / Pause / Text case

Insert a dial tone pause.

Upper/lower case in text mode.

Charging connectors

See section “Installation”.

Warning Light

Ringing, message waiting, battery low, exit cover area.

Earpiece

Display (3 rows)

Display at rest. Work is the network name and 123 is (your) extension number. See section ”Description/ Display info”.

On/Off / On hook / No

Switch on/off, end call, one menu back. Cancel a menu option.

Control key (down)

Scroll down through menus, name list. Move right in choices.

Keypad

Internal call key

Connect to other portables when used in a home environment. Not used in the MD110 system.

R-key

Put call on hold (inquiry), take call off hold. See section “During calls”.

Microphone

Description

DT288

Display info

The display gives you visual feedback on all actions that you perform, and also textual warnings. The upper two rows are text rows (12 possible characters in each row), showing menus that you can access, names and numbers that you edit or dial, your telephone id etc. The lower row displays different states, visualized by icons. For more information see section “Display information”.

Text row signs

Menu pointer / Diversion indicator

Shows the menu that can be accessed by pressing yes. When displayed before a name or number it indicates that the telephone is diverted to another extension.

Number too long for display

There are more digits to the left.

Dash

Indicates that a pause is programmed in the telephone number.

Exclamation Mark

Marks an unread entry in an entry list.

–

Description

DT288

Icon row signs

Signal strength

On when your telephone is locked to the system. The bars indicate reception quality. Four bars indicate optimal reception.

Ringer off

On when the ringer is suppressed or switched off.

Message

Flashes when messages are received.

Call

On when your telephone is off hook and flashes during ringing.

Battery charging indicator

The battery cells are flashing sequentially when the battery is being charged and is on when charging is completed. Indicates the amount of talk and standby time left.

Key lock

Indicates that the key pad is automatically locked 1 minute after being used.

Who Called list indicator

Indicates a new unanswered entry in the Who Called list.

Description

DT288

Display menu

Your cordless telephone is menu-driven. Each menu forms a loop.

Navigating the menus

You can activate the menus by pressing the Control up key or the Control down key. These keys are also used to scroll through the menu structure.

The CLR, YES and NO keys are used to reach the desired option.

Confirm Cancel Cancel

Control up Control down

Description

DT288

Menu structure

New Call

DialMode

Options available when:

On hook

AddNew AddWhoCall* AddLastDial*

PhoneBook

Voice:X*

Handset

Networks

Information

AutoKeyLock Alerts

PhoneLock DirectCall MasterReset Language Display AutoIntern

Off hook

Applicable only if entries are available

Internal External CallBack Message Page

Click Silent

PowerOn Subscript ChangePIN

SelectNet* Priority* Rename* Delete* ReSubscribe Subscribe

WhoCalled* LastDialled* LastCall TotalCalls ShowIPEI

Find&Call WhoCalled* LastDialled*

GotoDTMF SendTones SendPause

Find&Call Store

Find&Edit DeleteAll

Edit Delete

RingVolume RingType

KeySound DiscreetRng

Light Contrast

Switching On/Off

DT288

Switching On/Off

Switch on

Press until the display lights up

If your telephone does not switch on or the battery icon starts flashing, the battery is low. Charge the battery. While charging, you can use your telephone normally.

Note: If the signal strength icon is off and the message

No Network is displayed you cannot make or answer

calls. See section “Troubleshooting”.

Switch off

Press until the display turns blank

Note: During calls, you cannot switch off your telephone.

Free Seating

DT288

Free Seating (optional)

The free seating function is used for persons who have an office extension number but no telephone set of their own. For example, flexible office workers, persons mostly working outside the office, etc. As a free seating user and working from the office, you logon to any free telephone set that temporarily will be assigned with your extension number and your system authorities.

To log on:

Press

Enter the authorization code and press

Enter your telephone number and press

Wait for the call timer to start in the display

Press to finish the procedure

The display shows your telephone number.

To log off:

Press

Wait for the call timer to start in the display

Press to finish the procedure

Note: An earlier version of the free seating function use

other procedures: To log on, press *10*extension No. #. To log off, press #10#.

Incoming Calls

DT288

Incoming Calls

Answer calls

A ringing signal indicates an incoming call and the warning light flashes quickly. The ringing type tells you whether the call is an internal, external or call back call and the display indicates an incoming call.

Display example:

Press to answer

If the telephone rings at an inconvenient moment:

Press to suppress ringing for the moment

Note: Calls can be answered at any time, no matter if

you are programming, or keying in a number etc.

Press to end the call

For another extension

You can answer a call to another telephone. When the telephone rings and there is nobody to answer the call:

Call the ringing extension and press

Busy tone.

Press

Note: France-press 4; Sweden-press 6

4736

Outgoing Calls

DT288

Outgoing Calls

Make calls

How to make internal and external calls.

Notes:

- Correct a wrong entry by pressing the CLR key.

- If you decide not to make the call while keying in the number, press NO to stop.

- If you receive a call while keying in the number, simply press YES to answer.

- You can make your calls faster by using abbreviated numbers or call-by-name.

Internal calls

Dial the extension number and press

External calls

Dial the digit or digits to get an external line

Dial the external number and press

To insert a pause if you have to wait for dial tone:

Press

Your telephone will go off hook and dial the number. On the display the duration of the call is shown.

Outgoing Calls

DT288

Off hook dialling

If you prefer to dial a number off hook:

Press

Dial tone.

Dial the number

To end calls

Press

Last external number redial

When you initiate an external call the system automatically stores all the dialled digits, irrespective of whether the call was successful or not.

***

Press to redial the saved number

The last external number is automatically redialled.

Note: Sweden and Finland-press **0 YES.

Redial number from LastDialled list

The last twenty dialled numbers are memorised by your telephone. You can redial one of these numbers by selecting the number from the LastDialled list.

Select Information and press

Select LastDialled and press

Scroll, select number and confirm

A number marked with a ! means a new number. You can store numbers permanently by adding them to your phone book. See section “Phone book”.

Note: The LastDialled list will be cleared if the power of your telephone is lost (e.g. if you remove the battery).

Outgoing Calls

DT288

Call number from WhoCalled list

Your phone keeps a list of people who have called you (if supported by the network). Whenever there are entries in the list, you can view or call back a number with the WhoCalled option. If the “Who Called list indicator” is shown in the display, there are one or more new numbers added since the last time you entered the WhoCalled list.

When the phone is switched off, the WhoCalled list is erased.

Numbers in the WhoCalled list can be added to your Phone Book, see section “Phone Book”.

To call

Select Information and press

Select

WhoCalled and press

The last caller’s number is displayed. If the number is in your Phone Book, the associated name is displayed instead.

Scroll to find the number or name you want to call back and press

Press to end the call

Note: If

Check Who Called? is shown in the display,

you can view the last caller’s number by pressing YES. To call the number, press YES once again.

During Calls

DT288

During Calls

Mute microphone

To mute the microphone during an ongoing conversation:

Press and hold

The caller will not hear what is being said in your room.

Press shortly, to turn the microphone off

Short beeps confirm that the microphone is off.

Press again, to turn the microphone back on

Mute warning signal

If a warning sounds during an ongoing call, e.g. when the battery runs low, you can turn off the signal temporarily.

Press shortly

Note: When a warning occurs during a call and you want

to mute the microphone, the first press always mutes the warning sound. The second press mutes the microphone.

During Calls

DT288

Inquiry

You have speech connection and want to make an inquiry to an internal or external party.

Press

Dial tone.

Call the second party

The first party is put on hold. When the other party answers you can switch between the calls (refer back), transfer the call, create a conference or end the call.

Press to end the inquiry call

The second party is disconnected.

Press to return to the first party

Refer back

Press to refer back to the other party

The party you talked to is put on hold, the other party is connected.

Note: Sweden - press R to refer back to the other party.

During Calls

DT288

Inquiry via the PhoneBook

If you don’t know the number by heart, you can make an inquiry to a second party in the Phone Book during a call.

Select

NewCall and press

Select

Find&Call and press

(name) Enter the first letters of the name and press

Scroll to find the name and press

The first party is put on hold and the second party is dialled. When the second party answers, you can switch between the calls (refer back), transfer the calls, create a conference and end one of the calls.

Press to end the inquiry call

The second party is disconnected.

Press to return to the first party

Transfer

You want to transfer an ongoing call.

Press

Dial tone.

Call the second party

Press before or after answer

The ongoing call is transferred.

Note: If you have put more than one call on hold the last call that was put on hold will be transferred. If the dialled extension is busy or transfer is not allowed, your telephone will ring again.

During Calls

DT288

Conference

With this procedure you can include up to seven parties in a conference. Only the conference leader can admit participants. During the conference a tone will be heard every 15th second.

Note: The conference tone might be disabled for your system.

You have an ongoing conversation and want to establish a telephone conference. You will become the conference leader.

Press

Dial tone.

Call the second party

Wait for answer.

Press to establish a conference

Repeat the procedure to add more conference members

Press to leave the conference

On hold

You can temporarily put the ongoing call on hold. Calls put on hold can be resumed on your own telephone or another.

Press

Dial tone.

Press

To resume the call

Press within 30 seconds

If not resumed within 30 seconds you will be called back. An unanswered external call will be re-routed to the operator after another 30 seconds.

During Calls

DT288

To resume on another extension

Call the extension where the call was put on hold and press

Busy tone.

Press

Note: France - press 4; Sweden - press 6.

Dialling during a connected call

When calling interactive tele-services, e.g. telephone banks, you need to use Dual Tone Multi Frequency (DTMF) signals. If your exchange is not already programmed to automatically convert your entered digits into DTMF signals, you need to activate the function during the call.

During an ongoing call:

Press and dial the required digits

Note: Finland - press 1 and dial the required digits.

When You Receive a Busy Tone

DT288

When You Receive a Busy Tone

Busy extension or external line

If you call an extension and receive a busy tone or get no answer or all external lines are busy, you can use these methods:

Automatic callback, extension

If a called extension is busy or there is no answer:

Press

Note: France, Sweden and Finland - press 5.

Press to finish the procedure

You are called back (recall ringing signal) when the ongoing call is finished or the next time a new call is finished. You have to answer within eight seconds, otherwise the callback service is cancelled.

Press when you are called back

The system calls the extension.

Note: Callbacks can be activated on several extensions at the same time.

When You Receive a Busy Tone

DT288

Automatic callback, external line

If all external lines are busy when YES is pressed after dialling the digit or digits to get a line and the external number (Onhook dialling):

Press

Notes:

- France, Sweden and Finland - press 5#.

- If you were dialling Offhook (YES was pressed before the digit or digits to get a line), you are required to add the external number now.

Press to finish the procedure

When an external line becomes free you will be called back (special ringing signal). You have to answer within eight seconds otherwise the callback service is cancelled.

Press when you are called back

The system calls the external number.

Note: Only one callback can be activated on a busy external line.

Cancel any single callback

Press and dial the extension number

Note: To cancel a single callback on a specific external

line, dial the digit or digits to get a line instead of the extension number.

Press

Wait for the call icon to stop flashing

Press to finish the procedure

When You Receive a Busy Tone

DT288

Cancel all callbacks

Press

Wait for the call icon to stop flashing

Press to finish the procedure

Activate call waiting

If you urgently wish to contact a busy extension or a busy external line, you can notify it by a call waiting signal.

Press

Note: France and Finland - press 6; Sweden - press 4.

Keep your telephone off-hook

When the called extension or the external line becomes free, it will be called automatically.

Note: The call waiting function might be blocked for use on your extension (programmed by system administrator). If call waiting is not allowed you will continue to receive a busy tone.

Intrusion on a busy extension

You can intrude on an ongoing call on a busy extension.

Press

Note: France and Sweden - press 8.

Before the intrusion is executed a warning tone is sent to the parties in the ongoing call. A three party call is established and a warning tone is heard.

Notes:

- The warning tone might be disabled for your system.

- The intrusion function might be blocked for use on your extension (programmed by system administrator). If intrusion is not allowed you will continue to receive a busy tone.

Call Forwarding

DT288

Call Forwarding

Internal follow-me

All calls to your extension are diverted to an extension of your choice (within the private network). During follow-me the display shows a

> after your number. On the next row the answering

position number is shown. You will also hear a special dial tone that indicates that your line has follow-me. You can still make calls as usual

Order

Press and dial the answering position number

Note: U.K..- press *2*and number.

Press

Wait for the call icon to stop flashing

Press to finish the procedure

Display example:

4736 > 4321

Call Forwarding

DT288

Cancel

Press

Note: U.K. - press #2#YES.

Wait for the call icon to stop flashing

Press to finish the procedure

External follow-me

If external follow-me is allowed you can have all calls to your extension diverted to an external number of your choice. During follow me the display shows a

> after your number. You will also

hear a special dial tone that indicates that your line has follow me. You can still make calls as usual.

Order

Press

Dial the digit or digits to get a line and the external number

Press

Wait for the call icon to stop flashing

Press to finish the procedure

Display example:

4736 >

Call Forwarding

DT288

Cancel

Press

Wait for the call icon to stop flashing

Press to finish the procedure

Bypass diversion

If bypass diversion is allowed from your extension, you can bypass an activated diversion/follow-me on a specific extension.

Press

Dial the extension number

Press and wait for answer

+ 61 hidden pages
