A4 Tech PK-335 User Manual

ViewCam

User’s manual

Model :PK-335

www.a4tech.com

Contents page

Introduction 2
System’s Requirements 2
Package Include 2
USB PC Camera 3
Specification 3
Installing Camera’s Driver 4
Checking connection of your camera 10
Uninstalling Driver 11
VP-EYE program 11
Troubleshooting 19

1

l Introduction

Welcome to the World of Digital Imaging.
The following information will guide you to install and use the PC
Camera to its full capabilities.

l System’s requirements

Personal Computer, Laptop, Desktop, or IBM Compatible
Computer with Pentium 166MHz minimum, and with an active
USB (universal serial bus) port.
Windows 98/ME/2000/XP, CD-ROM drive, color monitor, mouse
and keyboard. For videoconference, Internet connection must
be equipped.

l Package includes

PC Camera
(With USB cable and Mic. Jack)

CD Installation Disc

2

l USB PC Camera

30fps@640x480, @600x800, @320x240,

5-Layer
Lens

l Specification

Image Sensor:
Frame Rate:

Lens:
View Angle:
Focus Range:
Exposure Control:
White Balance:
Still Image Capture
Res.:
Flicker Control:

1/4〃CMOS, 640×480pixels

@160x120
F=2.0, f=3.6mm
72 degree
Automatic focus, 10cm to infinity
Automatic
Automatic

800x600，640X480，352x288，320x240，176x144，
160x120

50Hz, 60Hz and None

Microphone

3

Microphone Built in Microphone

Computer Port

USB port

● Installing camera’s driver

Driver’s Installation Instruction for Windows 98/ME/2000/XP

NOTE: Please Uninstall All Previous Installed WEBCAM BEFORE Installing A4 TECH
ViewCAM. DO NOT CONNECT A4 TECH ViewCAM TO THE COMPUTER UNTIL ITS
DRIVER IS INSTALLED!

1. Insert the included CD into the CD-ROM: The Autorun Menu
Window will popup, move the mouse cursor to and click on
“Install viewCAM”.

4

2. Please select your ViewCAM model and click on the product
image to install (As the right image). Then dialogue box will
appear on the computer screen as below:

3. Follow the on screen instruction to complete the installation
process

5

4. When the Installation Process is completed, restart the
Computer.

6

6. Click “Finish” to complete installation. Now, the shortcut

Amcap image will appear on the computer desktop

7. Plug the PC Camera’s USB cable to the computer’s USB
Port, and restart your computer.

Amcap Usage

After installation of ViewCAM driver, you can pre-view image
and set the adjustments for the properties sheet through the
included image application software.

Image-preview

Click on the icon on the
desktop and the Amcap image

application will pop-up.
Or click on “start”, select “Program”,
then select “A4TECH USB PC
Camera”, and select “Amcap” to
open the Amcap application. (you
may follow the image on the right)

7
