4IPNET SDS200W Users Manual
User Guide
Wireless Network Ticket Generator
(SDS200W and POS Printer)
V1.00
User
User Guide
Guide
UserUser
Guide Guide
Wireless Network Ticket Generator (SDS200W and POS Printer) ENGLISH
Copyright Notice
This document is protected by USA copyright laws and other laws and is the property of
4IPNET, INC. You may not copy, reproduce, distribute, publish, display, perform, or
modify any part of this publication in any form or by any means without prior written
permission from 4IPNET, INC. You may not alter or remove any copyright or other notice
from copies of the content. All other brand and product names are claimed or
registered marks of their respective companies or organizations.
All rights reserved.
To download up-to-date version, please visit www.4ipnet.com.
Copyright © 4IPNET, INC. All rights reserved.
i
User
User Guide
Guide
UserUser
Guide Guide
Wireless Network Ticket Generator (SDS200W and POS Printer) ENGLISH
FCC CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment has been tested and proven to comply with the limits for a class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
---Reorient or relocate the receiving antenna.
---Increase the separation between the equipment and receiver.
---Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
---Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s
authority to operate the equipment.
This device meets the government’s requirements for exposure to radio waves. This device is
designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF)
energy set by the Federal Communications Commission of the U.S. Government.
The device contains a low power transmitter which will send out Radio Frequency (RF) signal when
transmitting. This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with a minimum distance
of 20 centimeters between the radiator and your body.
Copyright © 4IPNET, INC. All rights reserved.
ii
User
User Guide
Guide
UserUser
Guide Guide
Wireless Network Ticket Generator (SDS200W and POS Printer) ENGLISH
CE CAUTION
Declaration of Conformity with Regard to the 1999/5/EC (R&TTE Directive) for
European Community, Switzerland, Norway, Iceland, and Liechtenstein
Model: SDS200W
For 2.4 GHz radios, the device has been tested and passed the requirements of the following standards,
and hence fulfills the EMC and safety requirements of R&TTE Directive within the CE marking
requirement.
• Radio: EN 300.328:
• EMC: EN 301.489-1, EN 301.489-17,
• Safety: EN 60950-1 + A11,
Caution:
This declaration is only valid for configurations (combinations of software, firmware, and hardware)
provided and supported by 4ipnet Inc. The use of software or firmware not provided and supported
by 4ipnet Inc. may result in the equipment no longer being compliant with the regulatory
requirements.
European standards dictate maximum radiated transmit power of 100mW EIRP and frequency range
2.400-2.4835 GHz. This equipment is intended to be used in all EU and EFTA countries.
Taiwan NCC Statement
根據 NCC 低功率電波輻射性電機管理辦法 規定:
第十二條
第十四條
經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或
變更原設計之特性及功能。
低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時應立即停用，並改善至
無干擾時方得繼續使用。
前項合法通信，指依電信法規定作業之無線電通信。
低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之擾。
Copyright © 4IPNET, INC. All rights reserved.
iii
User
User Guide
Guide
UserUser
Guide Guide
Wireless Network Ticket Generator (SDS200W and POS Printer) ENGLISH
1. Introduction
Overview of Network Ticket Generator
SDS200W is an innovative product 4ipnet offers to facilitate the communication between 4ipnet hotspot
gateway and serail POS printer. It is mainly used to have the connected printer fast-print necessary
account information extracted from a 4ipnet hotspot gateway for a user who would like to access the
Internet or managed networks, making provisioning of wired or wireless connection easier and more
user-friendly. What is noteworhty is that, SDS200W supports wireless connectibity to the uplink gateway.
That is, operators now can deploy a network with lesser physical wires.
Here lists some deployment examples:
Copyright © 4IPNET, INC. All rights reserved.
1
Wireless Network Ticket Generator (SDS200W and POS Printer) ENGLISH
of the
ticket.
ENTER
2. Device Overview
Keypad Panel Overview
User
User Guide
Guide
UserUser
Guide Guide
Useful Shortcut Keys
Combination Function
‘Number’ + ENTER
‘Number 1’ +
‘asterisk (*)’ +
‘Number 2’ + ENTER
FUNC + ‘1’ +
FUNC + ENTER
To create and print out an on-demand account of an enabled billing plan
uplink Hotspot gateway mainly for the user who purchased an account.
Print a ticket of billing ‘Number 1’ with ‘Number 2’ units. For example, ‘8’ +
asterisk(*) + ‘3’ + ENTER is equal to create an on-demand account of billing
plan 8 with 3 units and have the POS printer print out the corresponding
That is, the quota that billing plan 8 grants is multiplied by 3.
To print out the information of SDS200W, including (1) its IP address (2) the
firmware version and the build number (3) the current listening port (4) uplink
connection status (5) the IP address of the uplink 4ipnet gateway (HSG/WHG).
To clear what is pressed. This is used when the operator pressed a wrong
button or combination. The system will also clear it automatically after five
seconds.
FUNC + ‘0’ + ENTER
Copyright © 4IPNET, INC. All rights reserved.
To activate Safe Mode – disabling the FUNC + ‘1’ + ENTER shortcut key in
- 2 -
