4IPNET EAP705 User Manual

Enterprise Access Point

Product Handbook

EAP705 V1.0

Product Handbook

EAP705 Enterprise Access Point ENGLISH

Product Handbook

Product HandbookProduct Handbook

This document is protected by USA copyright laws and other laws. Besides, the

document is the property of 4IPNET, INC. You may not copy, reproduce, distribute,

publish, display, perform, or modify any part of this publication in any form or by any

means without prior written permission from 4IPNET, INC. You may not alter or remove any

are claimed or registered marks of their respective companies or organizations.

To download up-to-date version, please visit www.4ipnet.com.

Product Handbook

EAP705 Enterprise Access Point ENGLISH

Product Handbook

Product HandbookProduct Handbook

FCC CAUTION

This equipment has been tested and proven to comply with the limits for a class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates uses and can

radiate radio frequency energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by turning the equipment off

and on, the user is encouraged to try to correct the interference by one or more of the following

measures:

---Reorient or relocate the receiving antenna.

---Increase the separation between the equipment and receiver.

---Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

---Consult the dealer or an experienced radio/TV technician for help.

The device contains a low power transmitter which will send out Radio Frequency (RF) signal when

transmitting. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled

environment. This equipment should be installed and operated with a minimum distance of 20 centimeters

between the radiator and your body.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may cause undesired

operation.

Any changes or modifications not expressly approved by the party responsible for compliance could

void the user's authority to operate this equipment.

This transmitter must not be co-located or operating in conjunction with any other antenna or

transmitter.

Product Handbook

EAP705 Enterprise Access Point ENGLISH

Product Handbook

Product HandbookProduct Handbook

CE CAUTION

Declaration of Conformity with Regard to the 1999/5/EC (R&TTE Directive) for

European Community, Switzerland, Norway, Iceland, and Liechtenstein

Model: EAP705

For 2.4 GHz radios, the device has been tested and passed the requirements of the following standards, and

hence fulfills the EMC and safety requirements of R&TTE Directive within the CE marking requirement.

• Radio: EN 300.328:

• EMC: EN 301.489-1, EN 301.489-17,

• EMC: EN 55022 Class B, EN 55024:+ A1 + A2 including the followings:

EN 61000-3-2, EN 61000-3-3.

EN 61000-4-2, EN 61000-4-3, EN 61000-4-4,

EN 61000-4-5, EN 61000-4-6, EN 61000-4-11

• Safety: EN 60950-1 + A11,

Caution:



This declaration is only valid for configurations (combinations of software, firmware, and hardware)

provided and supported by 4ipnet Inc. The use of software or firmware not provided and supported by

4ipnet Inc. may result in the equipment no longer being compliant with the regulatory requirements.

European standards dictate maximum radiated transmit power of 100mW EIRP and frequency range

2.400-2.4835 GHz. This equipment is intended to be used in all EU and EFTA countries. Outdoor use may be

restricted to certain frequencies and/or may require a license for operation. Contact your local regulatory

authority for compliance.

Taiwan NCC Statement

根據

NCC

第十二條

第十四條

低功率電波輻射性電機管理辦法規定

經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功率或

變更原設計之特性及功能。

低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時應立即停用，並改善至無干擾時方得繼續使用。前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之擾。

在5.25 ~ 5.35秭赫頻帶內操作之無線資訊傳輸設備，限於室內使用。

iii

Product Handbook

EAP705 Enterprise Access Point ENGLISH

Preface Package Contents

Product Handbook

Product HandbookProduct Handbook

The 4ipnet EAP705 Wall Jack Access Point is an

on-the-wall as well as a ceiling-mounted dual radio

Wi-Fi IEEE 802.11b/g/n + a/n/ac 2 X 2 MIMO

access point, designed to blend into a working or

a living environment practically and elegantly with

its simplistic yet sleek design.

The compact EAP705 in a small form factor lays

snug in a standard wall outlet box. Its side panel

features LED status indicators and two RJ45 ports.

It has the interfaces to serve both wireless and

wired LAN access. The RJ45 pass-through port

allows phone or IP-based devices to pass through

EAP705 without the need for additional outlets.

When coupled with the 4ipnet WHG series

Controller, the EAP705 supports Tunnel-based AP

Management, and comes with all standards

demanded by enterprise applications, including

1. 4ipnet EAP705 x 1

2. Quick Installation Guide (QIG) x 1

3. Power Adapter (DC 12V) x 1 (Optional)

4. Mounting Screws x 2

5. Mounting Panel x 1

6. Mounting Plate Lock Tool x 1

It is recommended to keep the original

packing material for possible future shipment when repair or maintenance is required. Any returned product should be packed in its original packaging to prevent damage during delivery.

business-grade security (802.1X, WPA and WPA2),

and multiple ESSIDs with VLAN tags to separate

the traffics of different departments. A centralized

WLAN management allows enterprises and

organizations to support a wide array of value

added applications, such as load balancing,

bandwidth control, and access control. The

patent-pending 4ipWES (Press-n-Connect)

technology bridges multiple EAP705s at the touch

of a button, which enables a quick and automatic

WDS Easy Setup by pressing the WES button on

EAP705. Extending wireless network coverage is a

breeze, be it across conference rooms or along

hallways.

EAP705’s high performance, security and optimal

invisibility make it a perfect choice of wireless

connectivity for your business.
