3M CFS8000-SK User Manual
3M™ Water Filtration Products
SPEC#
QUANTITY
application:
CUNO Systems
model:
8000 Series Cartridges
The 3M™ Water Filtration Products line of 8000 Series cartridges
provide the continuing benefits of CUNO filtration in a user-friendly
design. A choice in medias such as graded density carbon and
granular activated carbon with micron ratings from 0.5 to 5, as well
as optional integrated scale inhibition, provide solutions for varying
water conditions. The 8000 Series cartridges do not require activation for functionality, allowing an operator to change the cartridge
in seconds.
PRODUCT BENEFITS
• 1.3 gpm (4.9 lpm), 1.5 gpm (5.7 lpm) and 1.67 gpm (6.3 lpm) flow
rates specifically designed to exceed water consumption on single
application equipment.
• Sanitary Quick Change (SQC) encapsulated cartridges reduce contamination during change-outs.
• FDA CFR-21 and/or NSF compliant materials.
PRODUCT SPECIFICATIONS
Model
Number
CFS8110 55720-01 5 N/A Sediment Reduction
CFS8112 55817-05 1 10,000 gal. (37,854 lit.) Sediment Reduction
CFS8812X 56011-01 0.5 9,000 gal. (34,069 lit.) Cyst Reduction
CFS8720 55893-03 5 4,800 gal. (18,170 lit.) Sediment Reduction
CFS8110-S 55720-03 5 N/A Sediment Reduction, Scale Inhibition
CFS8112-S 55817-08 1 10,000 gal. (37,854 lit.) Scale Inhibition
CFS8812X-S 56011-03 0.5 9,000 gal. (34,069 lit.) Cyst Reduction, Scale Inhibition
CFS8720-S 55893-01 5 4,800 gal. (18,170 lit.) Sediment Reduction, Scale Inhibition
CFS517LS 55584-01 5 3,500 gal. (13,249 lit.) Sediment Reduction 1.3 gpm (4.9 lpm)
CFS8112EL 55817-25 1 12,600 gal. (47,696 lit.) Sediment Reduction
CFS8812ELX 56011-05 0.5 14,000 gal. (52,996 lit.) Cyst Reduction
CFS872-EL 55893-06 5 5,500 gal. (20,820 lit.) Sediment Reduction
CFS8112-ELS 55817-27 1 12,600 gal. (47,696 lit.) Sediment Reduction
CFS8812ELX-S 56011-07 0.5 14,000 gal. (52,996 lit.) Cyst Reduction, Scale Inhibition
CFS8720-ELS 55893-08 5 5,500 gal. (20,820 lit.) Sediment Reduction, Scale Inhibition
CFS517 55600-01 5 3,500 gal. (13,249 lit.) Sediment Reduction, Scale Inhibition 1.3 gpm (4.9 lpm)
CFS8000-S 55854-01 N/A N/A Scale Inhibition N/A
CFS8000-SK 55854-06 N/A N/A Scale Inhibition (Keyed Cartridge) N/A
Part
Number
Micron Rating
Chlorine Reduction
Capacity
Claims Flow Rate
1.5 gpm (5.7 lpm)
1.67 gpm (6.3 lpm)
SPEC#
3 3/16"
(8.1 cm)
Standard -
12 7/8"
(32.7 cm)
3 3/16"
(8.1 cm)
CFS517 -
9 9/16"
(24.3 cm)
3 3/16"
(8.1 cm)
Extended -
17 1/8"
(43.5 cm)
QUANT ITY
MODEL NU MB ER
PART NUMBER
3M™ Water Filtration Products8000 Series Replacements
PHYSICA L SP EC IF ICATIONS
• System maximum operating pressure of 125 psi (862 kPa) and operating temperatures of 100°F (37.8°C).
• System materials are FDA CFR-21 and/or NSF compliant.
• Filter cartridges requires no pre-activation.
WARNING: To reduce the risk associated with the ingestion of
contaminants:
• Do not use with water that is microbiologically unsafe or of unknown
quality without adequate disinfection before or after the system.
Systems certified for cyst reduction may be used on disinfected water
that may contain filterable cysts. EPA Establishment #070595-CT-001
CUNO Incorporated recommends regularly scheduled maintenance and
replacement of the filter cartridge(s) in order for the product to perform
as advertised/sold. CUNO shall not be liable for system failures due to
improper maintenance.
IMPORTANT: INSTALLATION TIPS
These installation tips are for informational purposes only and are not intended to be
used as actual installation instructions. CAUTION: To reduce the risk associated with
property damage due to water leakage:
• Read and follow Use Instructions before installation and use of this system.
• Installation and use MUST comply with all state and local plumbing codes.
• Protect from freezing, remove filter cartridge when temperatures are expected to drop
below 40°F (4.4°C).
• Do not install on hot water supply lines. The maximum operating water temperature
of this filter system is 100°F (37.8°C).
• Do not install if water pressure exceeds 125 psi (862 kPa). If your water pressure
exceeds 80 psi (552 kPa), you must install a pressure limiting valve. Contact a plumbing
professional if you are uncertain how to check your water pressure.
• Do not install where water hammer conditions may occur. If water hammer conditions
exist you must install a water hammer arrester. Contact a plumbing professional if you are
uncertain how to check for this condition.
• The disposable filter cartridge MUST be replaced every 12 months, at the rated capacity
or if a noticeable reduction in flow rate occurs.
3M is trademark of 3M Company.
© 2008 3M Company. All rights reserved.
LITFS243 0808
70-0201-9381-2
CUNO Incorporated
400 Research Parkway
Meriden, CT 06450 U.S.A.
Toll Free: 1.800.222.7880
Worldwide: 203.237.5541
Fax: 203.238.8701
www.cuno.com
