Instructions and Parts List

Back

Important Safety

Information

™

3M-Matic

a20 Type 10700 Adjustable Case Sealer

with

™

AccuGlide 2+

BEFORE INSTALLING OR OPERATING THIS EQUIPMENT Read, understand, and follow all safety and operating instructions.

Spare Parts

It is recommended you immediately order the spare parts listed in the

Taping Heads

Serial No.

3M Industrial Adhesives and Tapes

3M Center, Building 220-5E-06 St. Paul, MN 55144-1000

"Spare Parts/Service Information" section. These parts are expected to wear through normal use, and should be kept on hand to minimize

For reference, record machine serial number here.

production delays.

"3M-Matic"and "AccuGlide" are Trademarks of, 3M St. Paul, MN 55144-1000 Printed in U.S.A.

This instruction manual covers safety aspects, handling and transport, storage, unpacking, preparation, installation, operation, adjustments, maintenance, troubleshooting, repair work and servicing plus parts list of the 3M-MaticTM a20 Adjustable case sealer.

3M Industrial Adhesives and Tapes 3M Center, Building 220-5E-06 St. Paul, MN 55144-1000

Edition April 2011

The manufacturer reserves the right to change the product at any time without notice.

Replacement Parts and Service Information

To Our Customers:

This is the 3M-Matic™/AccuGlide™/Scotch

equipment you ordered.

It has been set up and tested in the factory with Scotch® tapes.

Included with each machine is an Instructions and Parts List manual.

Technical Assistance / Replacement Parts and Additional Manuals:

For technical assistance, contact our help line at 1-800-328-1390. Provide the customer support coordinator with the model/machine name, machine type, and serial number that are located on the identiﬁ cation plate (For example: Model a20 - Type 10700 - Serial Number 13282).

To order replacement parts, contact us:

CSPD division of Combi Packaging Systems LLC. 5365 East Center Dr. N.E. Canton, OH 44721

Identiﬁ cation Plate

For Industrial Use Only

1-800-344-9883 e-mail: CSPD-CSR@combi.com www.combi.com

3M Industrial Adhesives and Tapes

3M Center, Building 220-5E-06 St. Paul, MN 55144-1000

3M-Matic™, AccuGlide™ and Scotch™ are Trademarks of 3M St. Paul, MN 55144-1000 Printed in U.S.A.

THIS PAGE IS BLANK

TABLE OF CONTENTS - MANUAL 1: a20 Adjustable Case Sealer

(For Taping Head Information - See MANUAL 2: AccuGlide™ 2+ STD 2 Inch Taping Heads)

a20 Adjustable Case Sealer Page

Cover Page

Replacement Parts and Service Information ........................................................................ i - ii

Table of Contents ................................................................................................................. iii - v

Acronyms and Abbreviations ................................................................................................ vi

1. Introduction

1.1 Manufacturing Speciﬁ cations / Description / Intended Use ......................................... 1 - 2

1.2 How to Read and Use the Manual / Reference Documents ......................................... 2

1.2.1 Importance of the Manual .................................................................................. 2

1.2.2 Manual Maintenance ......................................................................................... 2

1.2.3 Consulting the Manual ........................................................................................ 2

1.2.4 How to Update the Manual in Case of Modiﬁ cations ........................................... 2

2. General Information

2.1 Identiﬁ cation Data ......................................................................................................... 3

2.2 Warranty / Contents ...................................................................................................... 4

3. Safety

3.1 General Safety Information ........................................................................................... 5

3.2 Signal Words Explanation ............................................................................................. 5

3.3 Table of Warnings .......................................................................................................... 6 - 7

3.4 Operator’s Qualiﬁ cations Deﬁ nition .............................................................................. 8

3.5 Number of Operators .................................................................................................... 8

3.6 Safe Use of the Machine Instructions ........................................................................... 8

3.7 Residual Hazards .......................................................................................................... 8

3.8 Prevent Other Hazards - Recommendations and Measures ........................................ 8

3.9 Personal Safety Measures ........................................................................................... 8

3.10 Incorrect / Predictable Actions Not Allowed .................................................................. 8

3.11 Operator's Required Skill Levels .................................................................................. 9

3.12 Component Locations .................................................................................................. 10

3.13 Table of Warnings and Replacement Labels ................................................................ 11

4. Technical Specifications

4.1 Power Requirements .................................................................................................... 12

4.2 Operating Rate

4.3 Operating Conditions .................................................................................................... 12

4.4 Tape .............................................................................................................................. 12

4.5 Tape Width .................................................................................................................... 12

4.6 Tape Roll Diameter ....................................................................................................... 13

4.7 Tape Application Leg Length - Standard .......................................................................13

Tape Application Leg Length - Optional

4.8 Box Board ..................................................................................................................... 13

4.9 Box Weight and Size Capacities ................................................................................... 13

4.10 Machine Noise Levels ................................................................................................... 13

4.11 Machine Dimensions ..................................................................................................... 14

4.12 Setup Recommendations .............................................................................................. 14

............................................................................................................. 12

a20-NA

iii

2011 April

THIS PAGE IS BLANK

TABLE OF CONTENTS (continued)

5. Shipment, Handling, and Storage

5.1 Packed Machine Shipment and Handling ........................................................................... 15

5.2 Overseas Shipment Packaging (Optional) .......................................................................... 15

5.3 Handling and Transportation of Uncrated Machine ............................................................. 15

5.4 Machine Storage ................................................................................................................. 15

6. Unpacking

6.1 Uncrating ............................................................................................................................. 16

6.2 Packaging Materials Disposal ............................................................................................. 16

7. Installation

7.1 Operating Conditions .......................................................................................................... 17

7.2 Space Requirements for Machine Operation and Maintenance ......................................... 17

7.3 Tool Kit Supplied with the Machine ..................................................................................... 17

7.4 Machine Positioning ............................................................................................................ 17

7.5 Plastic Ties Removal ........................................................................................................... 18

7.6 Assembly Completion .......................................................................................................... 18

7.7 Taping Heads Completion ................................................................................................... 19

7.8 Preliminary Electric Inspection ............................................................................................ 19

7.9 Main Power Machine Connection and Inspection ............................................................... 19

7.10 Inspection of Phases ........................................................................................................... 19

8. Theory of Operation

8.1 Working Cycle Description .................................................................................................. 20

8.2 Running Mode Deﬁ nition ..................................................................................................... 20

8.3.1 Normal Stop Procedure .............................................................................................20

8.3.2 Emergency Stop ....................................................................................................... 20

9. Controls

9.1 Box Width Adjusting Knobs ................................................................................................. 21

9.2 Box Height Adjusting Crank ................................................................................................ 21

9.3 Start / Stop Main Rotary Switch ........................................................................................... 21

9.4 Emergency Stop Button (Latching) ..................................................................................... 21

10. Safety devices

10.1 Blade Guards ..................................................................................................................... 22

10.2 Emergency Stop Button ..................................................................................................... 22

10.3 Electric System ................................................................................................................... 22

11. Setup and Adjustments

11.1 Box Width Adjustment ........................................................................................................ 23

11.2 Box Height Adjustment ....................................................................................................... 23

11.3 Top Flap Compression Roller Adjustment .......................................................................... 23

11.4 Changing the Tape Leg Length .......................................................................................... 23

11.5 Run Boxes to Check Adjustment ........................................................................................ 24

a20-NA

2011 April

THIS PAGE IS BLANK

TABLE OF CONTENTS (continued)

12. Operation

12.1 Operator’s Correct Working Position .............................................................................. 25

12.2 Starting the Machine ....................................................................................................... 25

12.3 Starting Production ......................................................................................................... 25

12.4 Tape Replacement .......................................................................................................... 25

12.5 Box Size Adjustment ....................................................................................................... 25

12.6 Cleaning .......................................................................................................................... 25

12.7 Table of Adjustments ....................................................................................................... 25

12.8 Safety Devices Inspection ............................................................................................... 25

12.9 Troubleshooting .............................................................................................................. 26

13. Maintenance

13.1 Safety Measures (see section 3) .................................................................................... 27

13.2 Tools and Spare Parts Supplied with Machine ................................................................ 27

13.3 Maintenance Operations - Recommended Inspections and Frequency .......................... 27

13.4 Inspections to be Performed Before and After Every Maintenance Operation ................ 27

13.5 Safety Features (Inspection Efﬁ ciency) .......................................................................... 27

13.6 Machine Cleaning ........................................................................................................... 28

13.7 Cutter Blade Cleaning ..................................................................................................... 28

13.8 Lubrication ...................................................................................................................... 28

13.9 Lubrication Products ....................................................................................................... 28

13.10 Drive Pulley Ring and Drive Belt Replacement .............................................................. 29

13.11 Box Drive Belt Tension .................................................................................................... 30

13.12 Maintenance Work Log ................................................................................................... 31

14. Additional Instructions

14.1 Machine Disposal Information ......................................................................................... 33

14.2 Fire emergency ............................................................................................................... 33

15. Enclosures and Special Information

15.1 Statement of Conformity ................................................................................................. 33

15.2 Hazardous Substances Emission ................................................................................... 33

15.3 Safety Features List ........................................................................................................ 33

15.4 Copies of Test Reports, Certiﬁ cation, etc ......................................................................... 33

16. Technical Documentation and Information

16.1 Electric Diagrams ............................................................................................................ 35

16.2 Spare Parts / Ordering .................................................................................................... 37 - 39

Drawings and Parts Lists ....................................................................................................... 41 - End of Manual

TAPING HEAD INFORMATION MANUAL 2: AccuGlide™ 2+ STD 2 Inch Taping Heads (See MANUAL 2 for Table of Contents)

a20-NA

2011 April

ABBREVIATIONS AND ACRONYMS

LIST OF ABBREVIATIONS, ACRONYMS

3M-Matic - Trademark of 3M St. Paul, MN 55144-1000

AccuGlide - Trademark of 3M St. Paul, MN 55144-1000

Scotch - Trademark of 3M St. Paul, MN 55144-1000

Drw. - drawing

Ex. - for example

Figure - exploded view ﬁ gure no. (spare parts)

Figure - Illustration

Max. - maximum

Min. - minimum

Nr. - number

N/A - not applicable

OFF - machine not operating

ON - machine operating

PLC - Programmable Logic Control

PP - Polypropylene

PU/PU Foam - Polyurethane Foam

PTFE - Polytetraﬂ ourethelene

PVC - Poly-vinyl chloride

W - Width

H - Height

L - Length

a20-NA

2011 April

1-INTRODUCTION

1.1 Manufacturing Specifications / Description / Intended Use

The 3M-MaticTM a20 Adjustable Case Sealer with AccuGlideTM 2+Taping Heads is designed to apply a “C” clip of Scotch® pressure-sensitive ﬁ lm box sealing tape to the top and bottom center seam of regular slotted containers. The a20 is manually adjustable to a wide range of box sizes (see "Speciﬁ cations Section – Box Weight and Size Capacities").

3M-MaticTM a20 Adjustable Case Sealer, Type 10700

a20-NA

2011 April

1-INTRODUCTION (continued)

1.1 Manufacturing Specifications / Description / Intended Use (continued)

The 3M-MaticTM case sealing machines have been designed and manufactured in compliance with the legal requirements at the date of inception.

1.2 How to Read and Use the Instruction Manual

This instruction manual covers safety aspects, handling and transport, storage, unpacking, preparation, installation, operation, Setup and adjustments, technical and manufacturing speciﬁ cations, mainte- nance, troubleshooting, repair work and servicing, electric diagrams, warranty information, disposal (ELV), a deﬁ nition of symbols, plus a parts list of the 3M-MaticTM a20 Adjustable case sealer 3M Industrial Adhesives and Tapes Division 3M Center, Bldg. 220-5E-06 St. Paul, MN 55144-1000 (USA) Edition April 2011 Copyright 3M 2011 All rights reserved. The manufacturer reserves the right to change the product at any time without notice. Publication © 3M 2011 44-0009-2060-1.

1.2.2 Manual Maintenance

Keep the manual in a clean and dry place near the machine. Do not remove, tear, or rewrite parts of the manual for any reason. Use the manual without damaging it. In case the manual has been lost or damaged, ask your after-sale service for a new copy.

1.2.3 Consulting the Manual

The manual is composed of:

- Pages which identify the document and the machine

- Index of the subjects

- Instructions and notes on the machine

- Enclosures, drawings and diagrams

- Spare parts (last section)

All pages and diagrams are numbered. The spare parts lists are identiﬁ ed by the ﬁ gure identiﬁ cation number. All the notes on safety measures or possible dangers are identiﬁ ed by the symbol:

1.2.1 Importance of the Manual

The manual is an important part of the machine; all information contained herein is intended to enable the equipment to be maintained in perfect condition and operated safely. Ensure that the manual is available to all operators of this equipment and is kept up to date with all subsequent amendments. Should the equipment be sold or disposed of, please ensure that the manual is passed on. Electrical and pneumatic diagrams are included in the manual. Equipment using PLC controls and/or electronic components will include relevant schematics or programs in the enclosure and in addition, the relevant documentation will be delivered separately.

a20-NA

1.2.4 How to Update the Manual in Case of Modifications to the Machine

Modiﬁ cations to the machine are subject to manufacturer’s internal procedures. The user receives a complete and up-to-date copy of the manual together with the machine. Afterwards, the user may receive pages or parts of the manual which contain amendments or improvements made after its ﬁ rst publication. The user must use them to update this manual.

2011 April

2-GENERAL INFORMATION

2.1 Data Identifying Manufacturer and Machine

For Industrial Use Only

4000563

a20-NA

2011 April

2-GENERAL INFORMATION (continued)

2.2 Warranty

Equipment Warranty and Limited Remedy: THE FOLLOWING WARRANTY IS MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY, THE IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE AND ANY IMPLIED WARRANTY ARISING OUT OF A COURSE OF DEALING, A CUSTOM OR USAGE OF TRADE:

3M sells its 3M-Matic™ a20 Adjustable Case Sealer, Type 10700 with the following warranties:

1. The drive belts and the taping head knives, springs and rollers will be free from all defects for ninety (90) days after delivery.

2. All other taping head parts will be free from all defects for three (3) years after delivery.

3. All other parts will be free from all defects for two (2) years after delivery.

If any part is proved to be defective within its warranty period, then the exclusive remedy and 3M’s and seller’s sole obligation shall be, at 3M’s option, to repair or replace the part, provided the defective part is returned immediately to 3M’s factory or an authorized service station designated by 3M. A part will be presumed to have become defective after its warranty period unless the part is received or 3M is notiﬁ ed of the problem no later than ﬁ ve (5) calendar days after the warranty period. If 3M is unable to repair or replace the part within a reasonable time, then 3M at its option, will replace the equipment or refund the purchase price. 3M shall have no obligation to provide or pay for the labor required to install the repaired or replacement part. 3M shall have no obligation to repair or replace (1) those parts failing due to operator misuse, carelessness, or due to any accidental cause other than equipment failure, or (2) parts failing due to non-lubrication, inadequate cleaning, improper operating environment, improper utilities or operator error.

Limitation of Liability: 3M and seller shall not be liable for direct, indirect, special, incidental or consequential damages based upon breach of warranty, breach of contract, negligence, strict liability or any other legal theory.

The foregoing Equipment Warranty and Limited Remedy and Limitation of Liability may be changed only by a written agreement signed by authorized ofﬁ cers of 3M and seller.

Contents—a20 Adjustable Case Sealer

(1) a20 Adjustable Case Sealer, Type 10700 (1) Upper Assembly Height Adjustment Crank Hardware (1) Tool and Spare Parts Kit (1) Instruction and Parts Manual

a20-NA

2011 April

3-SAFETY

1.1 Manufacturing Specifications / Description / Intended Use (continued)

The 3M-MaticTM case sealing machines have been designed and manufactured in compliance with the legal requirements at the date of inception.

1.2 How to Read and Use the Instruction Manual

This instruction manual covers safety aspects, handling and transport, storage, unpacking, preparation, installation, operation, set-up and adjustments, technical and manufacturing speciﬁ ca- tions, maintenance, troubleshooting, repair work and servicing, electric diagrams, warranty information, disposal (ELV), a deﬁ nition of symbols, plus a parts list of the 3M-MaticTM a20 Adjustable case sealer 3M Industrial Adhesives and Tapes Division 3M Center, Bldg. 220-5E-06 St. Paul, MN 55144-1000 (USA) Edition April 2011 Copyright 3M 2010 All rights reserved. The manufacturer reserves the right to change the product at any time without notice. Publication © 3M 2011 44-0009-2060-1.

1.2.2 Manual Maintenance

1.2.3 Consulting the Manual

The manual is composed of:

- Pages which identify the document and the machine

- Index of the subjects

- Instructions and notes on the machine

- Enclosures, drawings and diagrams

- Spare parts (last section)

1.2.1 Importance of the Manual

1.2.4 How to Update the Manual in Case of Modifications to the Machine

Modiﬁ cations to the machine are subject to manufacturer’s internal procedures. The user receives a complete and up-to-date copy of the manual together with the machine. Afterwards the user may receive pages or parts of the manual which contain amendments or improvements made after its ﬁ rst publication. The user must use them to update this manual.

a20-NA

(continued on next page)

2011 April

3-SAFETY (continued)

3.3 Table of Warnings

WARNING

• To reduce the risk associated with

mechanical and electrical hazards:

− Read, understand, and follow all safety and

operating instructions before operating or servicing the case sealer.

− Allow only properly trained and qualiﬁ ed

personnel to operate and service this equipment.

WARNING

• To reduce the risk associated with

hazardous voltage:

− Position electrical cord away from foot and

vehicle trafﬁ c.

Figure 3-2

WARNING

• To reduce the risk associated with

pinch, entanglement and hazardous voltage:

− Turn electrical supply off and disconnect

before performing any adjustments, maintenance or servicing the machine or taping heads.

WARNING

• To reduce the risk associated with

pinch and entanglement hazards:

− Do not leave the machine running while

unattended.

− Turn the machine off when not in use.

− Never attempt to work on any part of the

machine, load tape, or remove jammed boxes from the machine while the machine is running.

Figure 3-3

Figure 3-4

a20-NA

2011 April

3-SAFETY (continued)

WARNING

• To reduce the risk associated with sharp

blade hazards:

− Keep hands and ﬁ ngers away from tape

cutoff blades under orange blade guards. The blades are extremely sharp.

IPSRUWDQW! Tape cutting blade. Never remove

the safety device which covers the blade on the top and bottom taping units. Blades are extremely sharp. Any error may cause serious injuries (Figure 3-5).

WARNING

• To reduce the risk associated with fire

and explosion hazards:

− Do not operate this equipment in potentially

ﬂ ammable/explosive environments.

Figure 3-5

WARNING

Sharp Blade

WARNING

• To reduce the risk associated with

muscle strain:

− Use the appropriate rigging and material

handling equipment when lifting or repositioning this equipment.

− Use proper body mechanics when

removing or installing taping heads that are moderately heavy or may be considered awkward to lift.

CAUTION

• To reduce the risk associated with

pinch hazards:

− Keep hands clear of the upper head support

assembly as boxes are transported through the machine.

− Keep hands, hair, loose clothing, and jewelry

away from box compression rollers.

− Always feed boxes into the machine by

pushing only from the end of the box.

− Keep hands, hair, loose clothing, and jewelry

away from moving belts and taping heads.

Figure 3-6

Figure 3-7

Figure 3-8

a20-NA

2011 April

3-SAFETY (continued)

3.4 Operator's Qualifications

- Machine Operator

- Mechanical Maintenance Technician

- Electrical Maintenance Technician

- Manufacturer’s Technician/Specialist

3.5 Number of Operators

The operations described below have been analyzed by the manufacturer; the recommended number of operators for each operation provides the best and safest work performance.

WARNING

• To reduce the risk associated with

mechanical and electrical hazards:

− Read, understand, and follow all safety and

operating instructions before operating or servicing the case sealer.

− Allow only properly trained and qualiﬁ ed

personnel to operate and service this equipment.

3.9 Personal Safety Measures

Note: A smaller or greater number of operators could be unsafe.

3.6 Instructions for a Safe Use of the Machine / Definition of Operator's Qualifications

Only persons who have the skills described in the skill levels section should be allowed to work on the machine. It is the responsibility of the user to appoint the operators having the appropriate skill level and the appropriate training for each category of job.

3.7 Residual Hazards

The case sealer a20 has been designed and incorporates various safety protections which should never be removed or disabled. Notwithstanding the safety precautions conceived by the designers of the machine, it is essential that the operator and service personnel be warned that the following residual hazards exist which cannot be eliminated.

Safety glasses, safety gloves, safety helmet, safety shoes, air ﬁ lters, ear muffs - None is required except when recommended by the user.

3.10 Predictable Actions which are Incorrect and Not Allowed

- Never try to stop/hold the box while being driven by the the belts. Only use the EMERGENCY STOP BUTTON.

- Never work without the safety protections.

- Never remove or disable the safety devices.

- Only authorized personnel should be allowed to carry out the adjustments, repairs or main tenance which require operation with reduced safety protections. During such operations, access to the machine must be restricted. When the work is ﬁ nished, the safety protections must immediately be reactivated.

- The cleaning and maintenance operations must be performed after disconnecting the electric power.

3.8 Recommendations and Measures to Prevent Other Hazards which Cannot be Eliminated

- The operator must stay on the working position shown in the Operation Section. Never touch the running driving belts or put his hands inside any cavity.

- The operator must pay attention to the blades during the tape replacement.

a20-NA

- Do not modify the machine or any part of it. The manufacturer will not be responsible for any modiﬁ cations.

- Clean the machine using only dry cloths or light detergents. Do not use solvents, petrols, etc.

- Install the machine following the suggested layouts and drawings. The manufacturer will not be respon sible for damages caused by improper installation.

2011 April

3-SAFETY (continued)

3.11 Operator's Skill Levels Required to Perform the Main Operations on the Machine

The Table shows the minimum operator's skill for each machine operation.

Important: The factory manager must ensure that the operator has been properly trained on all the machine functions before starting work.

Skill 1: Machine Operator

This operator is trained to use the machine with the machine controls, to feed cases into the machine, make adjustments for different case sizes, to change the tape and to start, stop and restart production.

Skill 2: Mechanical Maintenance Technician

This operator is trained to use the machine as the MACHINE OPERATOR and in addition is able to:

• Work with the safety protection disconnected

• Check and adjust mechanical parts

• Carry out machine maintenance operations/repairs He is not allowed to work on live electrical components

Operator's Skill Levels Required to Perform the Main Operations on Machine

Skill 2a: Electrical Maintenance Technician

This operator is trained to use the machine as the MACHINE OPERATOR and in addition is able to:

• Work with the safety protection disconnected

• Check and adjust mechanical parts

• Carry out machine maintenance operations / repairs / adjustments / repair electrical components

He is allowed to work on live electrical panels, connector blocks, control equipment, etc.

Skill 3: Specialist from the Manufacturer

Skilled operator sent by the manufacturer or its agent to perform complex repairs or modiﬁ cations (on agreement with the customer).

WARNING

• To reduce the risk associated with

mechanical and electrical hazards:

− Allow only properly trained and qualiﬁ ed

personnel to operate and service this machine

Operation Machine Status

Machine installation and setup Running with safety

protections disabled

Adjusting box size

Tape replacement

Blade replacement Electric power

Drive belt replacement Electric power

Ordinary maintenance Electric power

Stopped by pressing the EMERGENCY STOP button

disconnected

Required Operator

Skill

2 and 2a 2

Number of

Operators

Extraordinary mechanical maintenance

Extraordinary electrical maintenance

a20-NA

Running with safety protections disabled

2a 1

2011 April

3-SAFETY (continued)

3.12 Component Locations

Refer to Figure 3-9 below to acquaint yourself with the various components and controls of the case sealer. Also refer to Manual 2 for taping head components.

Upper Taping Head

Height

Adjustment

Handle

Machine Bed

Emergency Stop Switch

Compression Roller Assembly (Optional)

Upper Head Assembly

Adjustable Side Guides

a20-NA

Drive

Assembly

Figure 3-9—a20 Case Sealer Components (Left Front View)

Power

Switch

Assembly

Lower Tape Roll Mount

2011 April

3-SAFETY (continued)

3.13 Table of Warnings and Replacements Labels (continued)

78-8070-1336-8

• Pinch Point

• Hands can be injured

• Keep hands away

• from rollers

78-8095-1141-9

STOP

78-8137-0226-9

78-8070-1318-6

78-8113-6717-2

78-8137-1330-8 (2)

78-8070-1329-3

78-8137-1331-6

78-8137-0886-0

78-8060-8481-6

Leg Height Adjustment Label (not shown)

78-8070-1339-2

3M Logo (not shown)

Figure 3-9 - Replacement Labels / 3M Part Numbers

a20-NA

2011 April

4-SPECIFICATIONS

4.1 Power Requirements:

Electrical: 120 Volt, 60Hz, 1Ph

The machine is equipped with a 2.4m [8 foot] standard neoprene covered power cord and a grounded plug.

Contact your 3M Representative for power requirements not listed.

4.2 Operating Rate:

Up to 30 cases per minute, depending on box length. Box drive belt speed is approximately 0.38m/s

[75 feet per minute].

Actual production rate is dependent on operator's dexterity. Boxes must be 18 inches (455mm apart minimum).

4.3 Operating Conditions:

Use in dry, relatively clean environments at 4.4

Note: Machine should not be washed down or subjected to conditions causing moisture

IMPORTANT SAFEGUARD

condensation on components.

C to 48.9oC [40oF to 120oF] with clean, dry boxes.

WARNING

IMPORTANT SAFEGUARD

• To reduce the risk associated with fire

and explosion hazards:

− Do not operate this equipment in

potentially ﬂ ammable or explosive environments.

4.4 Tape:

Scotch

4.5 Tape Width:

36mm [1 1/2 inches] minimum to 48mm [2 inches] maximum

a20-NA

pressure-sensitive ﬁ lm box sealing tapes.

(Speciﬁ cations continued on next page)

2011 April

4-SPECIFICATIONS (continued)

4.6 Tape Roll Diameter:

Up to 405mm [16 inches] maximum on a 76mm [3 inches] diameter core.

(Accommodates all system roll lengths of Scotch

ﬁ lm tapes.)

4.7 Tape Application Leg Length—Standard:

70mm ± 6mm [2.75 inches ± 0.25 inches ]

Tape Application Leg Length—Optional: 50mm ± 6mm [2 inches ± 0.25 inches] See "Removing Taping Heads Procedure—Changing the Tape Leg Length".

4.8 Box Board:

Style: regular slotted containers, RSC

125–275P.S.I. bursting test, single wall or double wall B or C ﬂ ute. 23–44 lbs. per inch of width Edge Crush Test (ECT)

4.9 Box Weight and Size Capacities:

A. Filled Box Weight: 5 lbs.–65 lbs. [2.3kg–29.5kg]. Contents must support ﬂ aps.

B. Box Size: Minimum Maximum

Length: 152mm [6.0 inches] Unlimited Width: 152mm [6.0 inches]* 546mm [21.5 inches] Height: 110mm [4.4 inches]** 546mm [21.5 inches]

* Cartons narrower than 250mm [10 inches] in width may require more frequent belt replacement because of limited contact area. ** 90mm [3.5 inches] height with heads adjusted to apply 50mm [2 inches] tape leg lengths. See "Removing Taping Heads Procedure—Changing the Tape Leg Length".

Note: The case sealer can accommodate most boxes within the size range listed above.

However, if the box length (in direction of seal) to box height ratio is 0.6 or less, test-run

several boxes to ensure proper machine performance.

DETERMINE THE BOX LIMITATIONS BY COMPLETING THIS FORMULA:

BOX LENGTH IN DIRECTION OF SEAL = SHOULD BE GREATER THAN 0.6 BOX HEIGHT

Any box ratio approaching this limitation should be test run to ensure performance. Test-run any box ratio approaching this limitation to ensure performance.

4.10 Machine Noise Level: Acoustic pressure measured at a distance of 1m. from machine with

Scotch PVC adhesive tape in operation; 78dB Acoustic radiation pressure at 1.6m. height with Scotch PVC adhesive tape in operation; 73dB Measurement taken with appropriate instrument: (Type SPYRI-MICROPHON 11).

a20-NA

2011 April

4-SPECIFICATIONS (continued)

F F

MinMax

G G

4.11 Machine Dimensions:

W L H A* B C** F G

Minimum

mm 813 1000 1355 460 545 106 620 130 [Inches] [32.0] [39.4] [53.5] [18.1] [21.5]** [4.2] [24.5] 5.1

Maximum

mm 2038 800 [Inches] - - - - [80.25]** - - [31.5]** - - - -

* Infeed/Exit conveyors are optional ** Casters are optional

Weight: 175kg [385 lbs] crated (approximate) 162kg [334 lbs] uncrated (approximate)

4.12 Setup Recommendations:

• Machine must be level.

• Customer supplied infeed and exit conveyors (if used) should provide straight and level box entry and exit.

• Exit conveyors (powered or gravity) must convey sealed boxes away from machine.

a20-NA

2011 April

5-SHIPMENT-HANDLING-STORAGE, TRANSPORT

5.1 Shipment and Handling of Packed Machine

- The machine is ﬁ xed on the pallet with four bolts and can be lifted by using a fork truck.

- The package is suitable to travel by land and by air.

- Optional sea freight package is available.

Packaging Overall Dimensions (Figure 5-1)

See Speciﬁ cations.

During the shipment it is possible to stack a maximum of 2 machines (Figure 5-2).

5.2 Packaging for Overseas Shipment (Optional - Figure 5-3)

The machines shipped by sea freight are covered by an aluminum/polyester/polythene bag which contains dehydrating salts.

5.3 Handling and Transportation of Uncrated Machine

The uncrated machine should not be moved except for short distances and indoors ONLY. Without the supporting pallet, the machine is exposed to damage and may cause injuries. To move the machine, use belts or ropes, paying attention to place them in the points indicated using care to not interfere with the lower taping head (Figure 5-4).

Figure 5-1

Figure 5-2

Figure 5-3

5.4 Storage of the Packed or Unpacked Machine

If the machine is not used for a long period, please take the following precautions:

- Store the machine in a dry and clean place.

- If the machine is unpacked it is necessary to protect it from dust.

- Do not stack anything over the machine.

- It is possible to stack a maximum of two (2) machines (if they are in their original packing).

a20-NA

Figure 5-4

2011 April

6-UNPACKING

6.1 Uncrating

The envelope attached to the shipping box contains the uncrating instructions of the machine (Figure 6-1).

Figure 6-1

Cut straps. Cut out staple positions along the bottom of the shipping box (or remove staples with an appropriate tool - Figure 6-2)

Removal of Pallet

Using a 10mm combination wrench, remove the fasteners that secure the case sealer legs to pallet at each leg (as shown in Figure 6-4).

Fasteners

Figure 6-4

Remove the leg height adjustment cap screws and replace with the cap screws from the tool kit. Loosen both cap screws. Remove and replace them one at a time to keep the inner threaded plate in position.

Using a 3mm hex wrench, remove the Height Adjustment Handle and reinstall it with the handle pointing upward as shown in Figure 6-5.

Figure 6-2

After cutting out or removing the staples, lift the shipping box in order to clear the machine (two persons required).

Figure 6-3

Transport the machine with a fork-lift truck to the operating position. Lift the pallet at the point indicated in Figure 6-3 (weight of machine + pallet = see Section 4).

Figure 6-5

6.2 Disposal of Packaging Materials

The a20 package is composed of:

- Wooden pallet

- Cardboard shipping box

- Wooden supports

- Metal ﬁ xing brackets

- PU foam protection

- PP plastic straps

- Dehydrating salts in bag

- Special bag of laminated polyester/aluminium/ Polyethylene (sea freight package only)

- Polyethylene protective material

For the disposal of the above materials, please follow the environmental directives or the law in your country.

a20-NA

2011 April

7-INSTALLATION

7.1 Operating Conditions

(see Section 4).

7.2 Space Requirements for Machine Operation and Maintenance Work

Minimum distance from wall (Figure 7-1):

A = 1.0m. (39.4 inches) B = 0.7m. (27.6 inches) Minimum height = 2.7m. (106.3 inches)

Figure 7-1

7.4 Machine Positioning / Bed Height

Figure 7-2

WARNING

• To reduce the risk associated with

muscle strain:

− Use the appropriate rigging and material

handling equipment when lifting or repositioning this equipment.

− Use proper body mechanics when

removing or installing taping heads that are moderately heavy or may be considered awkward to lift.

WARNING

• To reduce the risk associated with

mechanical and electrical hazards:

− Read, understand, and follow all safety and

operating instructions before operating or servicing the case sealer.

7.3 Tool Kit Supplied with the Machine

A tool kit containing some tools are supplied with the machine. These tools should be adequate to set-up the machine, however, other tools supplied by the customer will be required for machine maintenance.

1 - Lift the machine with belts or ropes paying attention to place the belts in the points (Figure 7-2).

To set the machine bed height, do the following:

2 - Adjust machine bed height. The case sealer is equipped with four adjustable legs that are located at the corners of the machine frame.

The legs can be adjusted to obtain different machine bed heights (Figure 7-3). Also refer to the "Speciﬁ cations" section.

3 - Lock the screws.

4 - Repeat the operation for all legs. (It is not necessary to ﬁ x or anchor the machine to the ﬂ oor).

Figure 7-3

a20-NA

2011 April

7-INSTALLATION (continued)

7.5 Removal of Plastic Ties

Cut the plastic which attaches the top head to the frame and remove the polystyrene blocks (Figure 7-4).

Figure 7-4

7.6 Assembly Completion

1. Using a 6mm hex wrench, loosen the four (4) screws (Figure 7-5) in the column without the height adjustment handle.

2. Raise the column by hand until it reaches the stop at the bottom end of the column.

3. Fasten the four (4) column screws.

4. Using a 6mm hex wrench, loosen the four (4) screws that secure the column (with the handle) to the machine bed.

5. Turn the height adjustment handle counterclock wise to raise the column until it reaches the stop.

6. Fasten the four (4) column screws.

7. Raise the upper head by turning the height adjustment handle clockwise and remove the polystyrene blocks.

Figure 7-6

8. Cut the plastic ties holding the upper and lower taping heads in position. Hold taping head buff ing roller while cutting the plastic tie. Allow buff ing/applying arms to extend slowly. (Figure 7-6).

9. Verify that the upper and lower taping heads move freely by pushing the bufﬁ ng roller into the taping head.

10. Ensure that the tape drum bracket assembly (located on the upper and lower taping heads) is mounted vertically, as shown in Figure 7-7.

Column Screws

Figure 7-5

WARNING

• To reduce the risk associated with

sharp blade hazards:

− Keep hands and ﬁ ngers away from tape

cutoff blades under orange blade guards. The blades are extremely sharp.

a20-NA

Note: The tape drum bracket assembly may be pivoted

to provide tape roll clearance if necessary.

Figure 7-7

2011 April

7-INSTALLATION (continued)

WARNING

• To reduce the risk associated with sharp

blade hazards:

− Keep hands and ﬁ ngers away from tape

cutoff blades under orange blade guards. The blades are extremely sharp.

7.7 Completion of Taping Heads

See Manual 2 for Complete Instructions.

Important – Do not cut against the apply roller - roller damage could occur.

7.9 Machine Connection to the Mains

- Push the LATCHING EMERGENCY STOP BUTTON.

- The main switch is normally turned OFF.

Connect the power cord supplied with the machine to a wall socket using a plug which complies with the safety regulations of your country.

7.10 Inspection of Phases (For Three-Main Phases Only)

WARNING

• To reduce the risk associated with

mechanical and electrical hazards:

− Read, understand, and follow all safety

and operating instructions before operating or servicing the case sealer.

• To reduce the risk associated with

hazardous voltage:

− Position electrical cord away from foot

and vehicle trafﬁ c.

7.8 Preliminary Electric Inspection

Before connecting the machine to the mains, please carry out the following operations:

7.8.1 Make sure that the socket is provided with an earth protection circuit and that both the mains voltage and the frequency match the speciﬁ - cations on the name plate.

7.8.2 Check that the connection of the machine to the mains meets the safety regulations in your country.

7.8.3 The user will be responsible for testing the short-circuit current in its facility and should check that the short-circuit amperage setting of the machine is compatible with all the components of the mains system.

(N/A for this machine)

a20-NA

2011 April

8-THEORY OF OPERATION

8.1 Description of the Working Cycle

After having closed the top ﬂ aps of the carton, the operator pushes it under the top infeed end in order to avoid the opening of the top ﬂ aps. Further pushing causes the two top and bottom belts to drive the box through the taping heads which automatically seal the top and bottom seams. The carton is then expelled on the exit conveyor.

8.2 Definition of Running Mode

The case sealer a20 has only one (automatic) operating mode with:

- The EMERGENCY STOP BUTTON unlocked (Figure 8-1)

- The main rotary switch start switch “ON” (Figure 8-2)

Figure 8-1

8.3.1 Normal Stop Procedure

When the main switch is turned OFF, the machine stops immediately at any point of the working cycle. The same thing happens in case of electrical failure or when the machine is disconnected from the mains.

8.3.2 Emergency Stop

The LATCHING EMERGENCY STOP BUTTON is located on the top center of the machine (This part is not produced by the machine manufacturer Figure 8-1).

Figure 8-2

E-Stop Location

Belt Direction

a20-NA

Figure 8-3

2011 April

9-CONTROLS

9.1 Box Width Adjusting Knobs

9.2 Box Height Adjusting Crank

Figure 9-1

9.3 Start / Stop Rotary Switch

9.4 Latching Emergency Stop Button

Figure 9-2

Figure 9-3

E-Stop Location

a20-NA

Figure 9-4

2011 April

10-SAFETY DEVICES OF THE MACHINE

10.1 Blade Guards

Both the top and bottom taping units have a blade guard (See Manual 2: AccuGlide™ 2+ STD 2 Inch Taping Heads).

Important!

Use care when working near blades as blades are extremely sharp. If care is not taken, severe injury to personnel could result.

10.2 Emergency Stop Button

The box drive belts are turned on and off with the electrical switch on the side of the machine frame.

The machine electrical supply can be turned off by pressing the latching emergency stop switch. To restart machine, rotate the emergency stop switch clockwise to release the switch latch. Restart machine by pushing the Start button

(Figure 10-1)

Stop

Figure 10-1

10.3 Electric System / Circuit Breaker

The electric system is protected by a ground wire whose continuity has been tested during the ﬁ nal inspection. The system is also subject to insulation and dielectric strength tests.

Circuit Breaker

The case sealer is equipped with a circuit breaker which trips if the motors are overloaded. Located inside the electrical enclosure on the side of the machine frame just below the machine bed, the circuit breaker has been pre-set and requires no

further maintenance.

Important!

All adjustments and tape loading require that the machine is stopped and the emergency stop button is locked.

Main electric switch "OFF". Severe injury to personnel could result by lack of observing these elementary rules

WARNING

• To reduce the risk associated with

hazardous voltage:

− Position electrical cord away from foot and

vehicle trafﬁ c.

WARNING

• To reduce the risk associated with mechanical and electrical hazards:

− Allow only properly trained and qualiﬁ ed personnel to operate and service this equipment.

If circuit is overloaded and circuit breaker trips, unplug machine from electrical power:

1. Determine cause of overload and correct.

2. Plug in machine.

3. Press machine "On" button to resume case sealing.

Important: The use of an extension cord is not

recommended. However, if one is needed for temporary use, it must:

• Have a wire size of 1.5mm diameter [AWG 16]

• Have a maximum length of 30.5m [100 ft]

• Be properly grounded.

a20-NA

2011 April

11 - SET UP AND ADJUSTMENTS

11.1 Box Width Adjustment

Place box on infeed end of frame bed and align top ﬂ ap center seam with arrows on front of upper frame. Move in and lock the side by tightening the appropriate knobs (Figure 11-1).

11.2 Box Height Adjustment

Lower top head by turning the height adjustment crank clockwise until it lightly presses the case

(Figure 11-2).

11.3 Adjustment of Top Flap Compression Rollers (Optional)

Note: This step applies to machines with the optional box compression rollers.

For machines with the optional box compression rollers, move the top ﬂ ap compression rollers until they contact the sides of the box. Tighten knobs to secure rollers in operating position (Figure 11-3).

11.4 Changing the Tape Leg Length

Taping heads are preset to apply 70mm [2.75 inches] long tape legs. To change tape leg length to 50mm [2.0 inches], refer to Instructions below and also to Manual 2, "Removing Taping Heads Procedure Changing the Tape Leg Length".

1. Remove tape from upper taping head and raise upper assembly to a convenient working height.

2. Loosen the upper taping head clamp thumb screws. Move the clamp away from the taping head (Figure 11-4).

Figure 11-1

Figure 11-2

Figure 11-3

Figure 11-4

3. Slide head forward and lift upward to remove

4. Raise upper assembly to provide working room around lower taping head and remove tape from taping head.

5. Lift the lower taping head straight up to remove it from the case sealer bed (Figure 11-5).

6. Refer to Manual 2, "Adjustments—Changing Tape Leg Length", for taping head setup.

7. Replace taping heads in the reverse order of disassembly.

a20-NA

2011 April

11 - SET UP AND ADJUSTMENTS (continued)

11.5 Run Boxes to Inspect Adjustment (Figure 11-6)

Important: Before starting the machine, verify that no tools or other objects are on the conveyor bed.

Turn electrical switch to On to start drive belts. Move box forward under upper taping head until it is taken away by the drive belts. Always push at the end of the box. If box is hard to move under head or is crushed, raise the head slightly. If box movement is jerky or stops under upper head, lower the upper head slightly to add more pressure between box and drive belts.

CAUTION

• To reduce the risk associated with

pinch hazards:

Figure 11-5

 Keep hands clear of the upper head support

assembly as boxes are transported through the machine.

 Keep hands, hair, loose clothing, and jewelry

away from box compression rollers.

 Always feed boxes into the machine by

pushing only from the end of the box.

 Keep hands, hair, loose clothing, and jewelry

away from moving belts and taping heads.

Note – The upper head has a unique feature for overstuffed boxes. The head will raise up to 13mm [0.5 inches] to compensate for this condition.

Important – If drive belts are allowed to slip on

box, excessive belt wear will occur.

Refer to Figure 11-7 and adjust belt tension as follows (for belt replacement and tension speciﬁ cations - refer to Section 13 / Maintenance

and Repairs):

Figure 11-6

1. Using a 17mm open end wrench, loosen, but do not remove, the M10 lock nut.

2. Reset the tension on the drive belts as needed. Adjust the M8 tension screws in (clockwise) to increase tension or out (counterclockwise) to decrease tension. Tighten lock nut to secure tension setting.

a20-NA

Figure 11-7

2011 April

12-OPERATION

12.1 Operator's Correct Working Position and

Operational Flow (Figure 12-1).

Figure 12-1

Once the box has been ﬁ lled, close its top ﬂ aps and push it between the top and bottom drive belts. Always keep hands in position as shown in

Figure 12-2.

The box will be automatically sealed with adhesive tape on the top and bottom box seams. Then the box will be expelled on the exit conveyor.

12.4 Tape Replacement and Threading

See Manual 2: AccuGlide™ 2+ STD 2 Inch Taping Heads.

Press the LATCHING EMERGENCY STOP BUTTON.

Figure 12-3

Figure 12-2

Hand

Position

12.2 Starting the Machine

Important: Before starting the machine, verify that

no tools or other objects are on the conveyor bed.

Turn the main rotary switch ON after the EMERGENCY BUTTON is released (Figure 12-3).

12.5 Box Size Adjustment

Repeat all the operations shown in

Section 11 - Setup and Adjustments.

12.6 Cleaning

Before carrying out any cleaning or maintenance operation stop the machine by turning the OFF rotary switch on the main and disconnect the electric power (Figure 12-3).

12.7 Table of Operation Adjustments Operator Qualifications

1 Tape loading and threading 1 2 Tape web alignment 1 3 Adjustment of one way tension roller 1 4 Adjustment to box size (H and W) 1 5 Top ﬂ ap compression rollers 1 6 Adjustment of tape applying spring 1 7 Conveyor bed height adjustment 1 8 Special Adjustment-Changing tape leg length 2 9 Special Adjustment-Column re-positioning 2

12.3 Starting Production

After having adjusted the machine according to the box dimensions (height-width), let the machine run without cartons and check its safety devices. Then start the working cycle.

a20-NA

12.8 Safety Devices Inspection

1 Taping units blade guard 2 Latching emergency stop button 3 STOP (OFF) main rotary switch

2011 April

12-OPERATION (continued)

12.9 Troubleshooting Guide

12-OPERATION

PROBLEM CAUSE CORRECTION

Drive belts do not convey boxes

Drive belts do not turn

Narrow boxes

Worn drive belts or friction rings

Top taping head does not apply enough pressure

Top ﬂ ap compression roller too tight

Taping head applying spring holder missing

Taping head applying spring set too high

Worn or missing friction rings

Drive belt tension too low

Electrical disconnect

Motor not turning Motor capacitor Motor fan cover dented

Check machine speciﬁ cations. Boxes are narrower than recommended causing slippage and premature belt wear

Replace drive belts or friction rings

Adjust the box height adjustment using the crank handle

Readjust compression rollers

Replace spring holder

Reduce spring pressure

Replace friction rings

Adjust belt tension

Check power and electrical plug

Evaluate and correct

a20-NA

Upper and lower taping head mechanisms interfere with each other

Drive belts break

Light boxes tip back on exit

Squeaking noise as boxes pass through machine

Machine's minimum height stop does not match tape head leg length setting

Worn belt

Improper setup causing boxes to jam

Upper head assembly down too far

Dry compression rollers

Dry column bearings

Defective column bearings

Check manual to make sure taping heads match machine setting

Replace belt

Carefully adjust upper head assembly

Lubricate compression rollers

Lubricate column bearings

Replace column bearings

2011 April

13-MAINTENANCE AND REPAIRS

13.1 Safety Measures (see section 3)

Carrying out maintenance and repairs may imply the necessity to work in dangerous situations. (See Section 3)

WARNING

• To reduce the risk associated with

mechanical and electrical hazards:

− Read, understand, and follow all safety and

operating instructions before operating or servicing the case sealer.

− Allow only properly trained and qualiﬁ ed

personnel to operate and service this equipment.

• To reduce the risk associated with

pinch, entanglement and hazardous voltage:

− Turn electrical supply off and disconnect

before performing any adjustments, maintenance or servicing the machine or taping heads.

13.2 Tools and Spare Parts Supplied with the Machine

See Spare Parts Order Section.

13.3 Recommended Frequency of Inspection and Maintenance Operations

Operation Frequency Qualification Sections

Inspection safety features daily 1 13.4 Cleaning of machine weekly 1 13.5 Cleaning of cutter blade weekly 2 13.6 Oiling of felt pad weekly 2 13.7 Lubrication monthly 2 13.7-13.8 Blade replacement when worn 2 See Manual 2 Drive belt replacement when worn 2 13.10

13.4 Inspections to be Performed Before and

After Every Maintenance Operation

Before every maintenance operation, turn the main rotary switch OFF and disconnect the plug from the control panel. During the maintenance operation only the operator responsible for this duty must work on the machine. At the end of every maintenance operation, check the safety devices.

13.5 Check Efficiency of Safety Features

1. Blade guard assembly upper taping head

2. Blade guard assembly lower taping head

3. Latching Emergency stop button with mechanical lock (interrupt supply of electrical power)

4. Turn the main rotary switch STOP/OFF

5. Safety guards - drive belts

a20-NA

2011 April

13-MAINTENANCE AND REPAIRS (continued)

13.6 Cleaning of Machine

Qualification / Skill 1

A weekly cleaning with dry rags or diluted detergents is necessary. Cardboard boxes produce a signiﬁ cant quantity of dust and paper chips when processed or handled in case sealing equipment. If this dust is allowed to build up on machine components, it can cause component wear and overheating of drive motors. The dust buildup is best removed from the machine with a vacuum cleaner. Depending on the number of cartons processed, this cleaning should be done weekly. Excessive buildup that cannot be removed by vacuuming should be removed with a damp cloth.

13.7 Cleaning of Cutter Blade

Qualification / Skill 2

- Should tape adhesive buildup occur, carefully

wipe clean with oily cloth or brush. Oil prevents the buildup of tape adhesive (Figure 13-1).

- Worn or damaged cutter blades must be replaced

promptly in order to guarantee a perfect cut of the tape. Lubricate the felt pad on the blade guard without saturating it.

13.8 Lubrication

Most of the machine bearings, including the drive motor, are permanently lubricated and sealed and

do not require additional lubricant.

Figure 13-1

WARNING

• To reduce the risk associated with sharp

blade hazards:

− Keep hands and ﬁ ngers away from tape

cutoff blades under orange blade guards. The blades are extremely sharp.

Figures illustrate the taping head and frame points which should be lubricated every 250 hours of operation. Lubricate the rotating and pivoting points noted by the arrows with a synthetic lubricant. At the same time, a small amount of Silicone should be applied to the end of each spring where the loop is secured to an eyelet

(Figures 13-2).

Note: Wipe off excess Silicone. It will attract

dust which can cause premature equipment wear and jamming. Take care that Silicone is not left on the surface of rollers around which tape is threaded, as it can contaminate

the tape's adhesive.

13.9 Lubrication Products

• Synthetic Silicone Spray may be used on Lead Screw (Figure 13-2).

Height Adjustment Handle

Lead Screw

Figure 13-2

a20-NA

2011 April

13-MAINTENANCE AND REPAIRS (continued)

WARNING

• To reduce the risk associated with

mechanical and electrical hazards:

- Turn electrical supply off and disconnect

before performing any adjustments, maintenance or servicing the machine / taping heads.

13.10 Drive Pulley Ring and Drive Belt Replacement

Drive Pulley Rings

Box Drive Belt Replacement

Note – 3M recommends the replacement of drive belts in pairs, especially if belts are unevenly worn.

Replacing Drive Belts

1. Using a 17mm open-end wrench, loosen, but do not remove the lock nut as shown in

Figure 13-4.

2. Using a 6mm hex wrench, loosen tension screw until all belt tension is removed as shown in

Figure 13-4.

3. Pull out belt splicing pin.

Before installing a new belt, check the orange plastic drive pulley rings for wear. If torn, broken, or worn smooth, replace the rings (Figure 13-3).

Figure 13-3

Tip: The old belt may be used to install the

new belt. Attach the new belt to the old belt and pull the new belt into the position while simultaneously removing the old belt.

4. If using the old belt, continue with the next step. If the old belt cannot be used to install a new belt, remove the lower cover between the belts).

5. Place new belt over pulleys with laced splice at top.

6. Insert splicing pin.

Important: Pin must not extend beyond edge of belt.

7. Adjust belt tension as explained on the following page and in "Setup and AdjustmentsBox Drive Belt Tension."

a20-NA

Figure 13-4 Lower Drive Belt Replacement

2011 April

13-MAINTENANCE AND REPAIRS (continued)

WARNING

• To reduce the risk associated with mechanical and electrical hazards:

 Turn electrical supply off and disconnect before performing any adjustments,

maintenance or servicing the machine or taping heads.

13.11 Box Drive Belt Tension

The two (2) continuously moving drive belts convey boxes through the tape applying mechanism. The box drive belts are powered by an electric gear motor.

Tension adjustment of these belts may be required during normal operation (for Belt Tension Adjustment - refer to Section 11 / Setup and Adjustments). Belt tension must be adequate to positively move the box through the machine and the belts should run fully on the surface of the pulleys at each end of the frame. The idler pulleys on the infeed end are adjusted in or out to provide proper belt tension. Each belt is adjusted separately.

Belt tension is obtained by tightening the adjustment screw so that a moderate pulling force of

3.5kg [7 lbs.] applied at the mid span, as shown in Figure 13-5, will deﬂ ect the belt 25mm [1 inch]. This will assure positive contact between the belt and the drive pulley on the discharge end of the drive assembly.

Box Drive Belt

Discharge End Infeed End

Figure 13-5 Box Drive Belt Tension Adjustment

a20-NA

3.5kg (7 lbs) Pull Force with 25mm (1 inch) at Mid-span

2011 April

13-MAINTENANCE AND REPAIRS (continued)

13.12 List of the Maintenance Operations

Date: Description of Operation

________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________ ________ ________________________________________________________________

a20-NA

2011 April

THIS PAGE IS BLANK

14-ADDITIONAL INSTRUCTIONS 15-ENCLOSURES / SPECIAL INFO.

14.1 Information for Disposal of Machine

The machine is composed of the following materials:

- Steel structure

- Nylon rollers

- Drive belts in PVC

- Nylon pulleys

For machine disposal, follow the regulations published in each country.

14.2 Emergency Procedures

In case of danger/ﬁ re: Disconnect plug of power cable from power supply.

(Figure 14-1)

IN CASE OF FIRE

Use a ﬁ re extinguisher containing CO2 (Figure 14-2).

15.1 Statement of Conformity

See Section 1.1.

15.2 Emission of Hazardous Substances

Nothing to report

15.3 List of Safety Features

List of components/assemblies with safety functions

- LATCHING EMERGENCY STOP BUTTON

- Thermal cut-out relay

- Fixed guards upper drive belts

- Blade guard assemblies on both taping heads

- Important: Install earth wire protection on

electrical installation.

All safety features/components must be explained and highlighted to all operators and to the person responsible for spare parts in order to ensure that these components are always on hand or ordered as a priority procedure.

Figure 14-1

Figure 14-2

ONLY USE ORIGINAL REPLACEMENT PARTS

15.4 Copies of Test Reports, Certifications (etc.)

Required by User

a20-NA

2011 April

THIS PAGE IS BLANK

16-TECHNICAL DIAGRAMS

16.1 Electric Diagram

1 Phase

a20-NA

2011 April

THIS PAGE IS BLANK

16-TECHNICAL DOCUMENTATION AND INFORMATION (continued)

16.2 Spare Parts Order

Replacement Parts Ordering Information and Service

Refer to the ﬁ rst page of this instruction manual "Replacement Parts and Service Information".

Order parts by quoting the following information: (Refer to the Identiﬁ cation Plate on the Machine)

• MACHINE MODEL

• SERIAL NUMBER

• FIGURE NO.

• POSITION

• 3M PART NO. (11 DIGITS)

• DESCRIPTION

• QUANTITY

Refer to Manual 2 for recommended taping head spare parts.

Important!

The machine is constantly revised and improved by our designers. The spare parts catalogue is also periodically updated. It is very important that all the orders of spare parts make reference to the serial number of the machine (located on the identiﬁ cation plate on the machine).

The manufacturer reserves the right to modify the machine at any time without notice.

It is suggested that the following spare parts be ordered and kept on hand.

a20

Qty. 3M-Part Number Description

Tool Kit

78-8070-1531-4 Belt, Drive with Pin

A tool kit, part number 78-8060-8476-6, is available as a stock item. The kit contains the necessary open-end and hex socket wrenches for use with the metric fasteners on the case sealer. The threading tool, part number 78-8076-4726-4, contained in above kit is also available as a replacement stock item.

Labels

In the event that any labels are damaged or destroyed, they must be replaced to ensure operator safety. Refer to Section 3 - Safety.

a20-NA

2011 April

THIS PAGE IS BLANK

a20 Adjustable Case Sealer, Type 10700 Frame Assemblies

To Order Parts:

1. Refer to ﬁ rst illustration, Frame Assemblies, for the Figure Number that identiﬁ es a speciﬁ c portion

of the machine.

2. Refer to the appropriate Figure or Figures to determine the parts required and the parts reference number.

3. The Parts List that follows each illustration, includes the Reference Number, Part Number and Part Description for the parts on that illustration.

Note – The complete description has been included for standard fasteners and some commercially available components. This has been done to allow obtaining these standard parts locally, if desired.

4. Order parts by Part Number, Part Description and Quantity required. Also include the model/machine name, machine type, and serial number that are located on the identiﬁ cation plate.

5. Refer to the ﬁ rst page of this instruction manual “Replacement Parts and Service Information” for replacement parts ordering information.

Important – Not all the parts listed are normally stocked items. Some parts or assemblies shown are available only on special order. Contact 3M/Tape Dispenser Parts to conﬁ rm item availability.

Options and Accessories

For additional information on the options and accessories listed below, contact your 3M Representative.

Part Number Option/Accessory

70-0064-2997-4 Box Hold-Down Attachment, Model 10700

70-0064-2998-2 Caster Kit Attachment

70-0064-2999-0 Conveyor Extension Attachment

70-0064-0353-2 AccuGlide™ 2+ STD 2 Inch Upper Taping Head, Type 10500

70-0064-0354-0 AccuGlide™ 2+ STD 2 Inch Lower Taping Head, Type 10500

70-0064-3000-6 Compression Roller Kit

78-8060-8476-6 Tool and Parts Kit

a20-NA

2011 April

THIS PAGE IS BLANK

a20

Figure 10672

Figure 10674

(optional)

Figure 10673

Figure 10669

Figure 10676

Figure 10677

Figure 10670

Figure 10671

Frame Assemblies

a20-NA

2011 April

a20 Adjustable Case Sealer

Figure

10673



Figure 10669

a20-NA

2011 April

a20

Figure 10669

Ref. No. 3M Part No. Description

10669-1 78-8137-0640-1 Inner Leg

10669-2 78-8137-0641-9 Foot

10669-3 78-8137-0635-1 Plate - Leg

10669-4 78-8129-6100-7 Bracket

10669-5 78-8017-9318-9 Washer - Plain M8

10669-6 26-1003-7963-0 Screw - Special, M8

10669-7 78-8137-0636-9 Housing - Wire

10669-8 26-1000-0010-3 Washer - Flat - M6

10669-9 78-8010-7210-5 Screw - Special - M6

10669-10 78-8137-0637-7 Plate - Housing

10669-11 78-8137-0638-5 Cover - Housing

10669-12 78-8005-5741-1 Washer - Flat - M5

10669-13 26-1003-7949-9 Screw - Special - M5

10669-14 78-8137-0795-3 Plate - Side Cover

10669-15 78-8046-8217-3 Washer - Special

10669-16 78-8010-7417-6 Nut

10669-17 78-8060-8488-1 Screw - M5

10669-18 78-8137-0651-8 Union - PG 11 10669-19 78-8137-0652-6 Union Nut - PG 11

10669-20 78-8137-0650-0 Sleeve - 16 mm

10669-21 78-8076-4702-5 Grommet

a20-NA

2011 April

a20 Adjustable Case Sealer

17 16

17 10

17 9

17 4

17 17

17 10

17 9

17 3

17 5

17 4

17 17

Figure 10670

a20-NA

2011 April

a20

Figure 10670

Ref. No. 3M Part No. Description

10670-1 78-8091-0565-9 Bushing

10670-2 78-8137-0642-7 Spacer

10670-3 78-8137-0643-5 Guide - L/H

10670-4 78-8137-0644-3 Spacer

10670-5 78-8137-0645-0 Lever - L/H

10670-6 78-8137-0646-8 Spacer

10670-7 78-8017-9074-8 Washer - Nylon 15 mm

10670-8 26-1004-5510-9 Washer - Plain - M10

10670-9 26-1000-0010-3 Washer - Flat M6

10670-10 78-8091-0418-1 Nut - Self-Locking - M6

10670-11 78-8137-0647-6 Shaft

10670-12 78-8076-5477-3 Washer - Special

10670-13 26-1002-5830-5 Screw - M6

10670-14 26-1003-6918-5 Nut - Plastic Insert M10

10670-15 78-8070-1549-6 Knob M10

10670-16 78-8137-0648-4 Guide - R/H

10670-17 78-8137-0649-2 Lever - R/H

a20-NA

2011 April

a20 Adjustable Case Sealer

7 3

17 4

17 6

17 11

17 14

17 15

Figure 10671

a20-NA

2011 April

a20

Figure 10671

Ref. No. 3M Part No. Description

10671-1 78-8137-0601-3 Box - Switch

10671-2 78-8137-0602-1 Cover

10671-3 78-8137-0606-2 Lockable Twist Knob - Allen Bradley

10671-4 78-8137-0603-9 Switch - Terminal - Allen Bradley 2.5-4

10671-5 78-8137-0604-7 Coil - Under Voltage 120V 60 Hz

10671-6 78-8094-6384-3 Terminal

10671-7 78-8094-6145-8 Screw - Phillips - M5

10671-8 78-8005-5741-1 Washer - Flat - M5

10671-9 78-8129-6469-6 Nut - Special - M20

10671-10 78-8137-0607-0 Grip - Cord - Skintop St 20

10671-11 78-8060-8053-3 Wire

10671-12 78-8028-7909-4 Power Cord - U.S.A.

10671-13 78-8137-0796-1 Grommet - EZ DG16

10671-14 26-1000-0010-3 Washer - Flat M6

10671-15 26-1003-7957-2 Screw - M6

10671-16 26-1003-7943-2 Screw - M4

10671-17 78-8137-0609-6 Switch - E-Stop - 40 800FM-MT44

10671-18 78-8137-0797-9 Terminal Switch

10671-19 78-8137-0611-2 Washer - Special

10671-20 78-8060-8488-1 Screw - M5

10671-21 78-8137-0608-8 Box - E-Stop, Yellow - Allen Bradley

10671-22 78-8010-7417-6 Nut - M5

a20-NA

2011 April

a20 Adjustable Case Sealer

17 7

17 8

17 9

17 11

17 6

17 12

a20-NA

Figure 10672

2011 April

a20

Figure 10672

Ref. No. 3M Part No. Description

10672-1 78-8137-0620-3 Column - Inner

10672-2 78-8137-0515-5 Bushing

10672-3 78-8137-0621-1 Bearing - Ball

10672-4 78-8076-5477-3 Washer - Special - 6.5 x 20 x 4

10672-5 78-8137-0622-9 Screw M6

10672-6 26-0001-5862-1 Screw - Flat Soc. Hd - M5 x 12

10672-7 78-8060-8073-1 Washer - Motor

10672-8 78-8129-6118-9 Handle

10672-9 78-8129-6142-9 Nut

10672-10 26-1003-7946-5 Screw - Soc. Hd. - M4 x 25

10672-11 78-8060-8125-9 Bushing

10672-12 78-8129-6141-1 Screw - Leading

10672-13 78-8129-6124-7 Screw - Cup Hd. - M8 x 16

10672-14 78-8137-0617-9 Plate - Column

10672-15 78-8129-6143-7 Bushing

10672-16 78-8054-8586-5 Pin

10672-17 78-8137-0614-6 Column - Outer

10672-18 78-8137-0615-3 Plate - Column

10672-19 10-0000-0030-3 Set Screw M8 x 10

10672-20 26-1003-7963-0 Screw - Soc. Hd. - M8 x 16

10672-21 78-8017-9318-9 Washer Plain Metric 8 mm

10672-22 78-8129-6125-4 Nut

10672-23 78-8054-8969-3 Spring

10672-24 78-8114-4703-2 Plug / 17

10672-25 78-8137-0620-3 Column, Inner

10672-26 78-8137-0516-3 Plate, Column

a20-NA

2011 April

a20 Adjustable Case Sealer

a20-NA

Figure 10673

2011 April

a20

Figure 10673

Ref. No. 3M Part No. Description

10673-1 78-8137-0623-7 Support - Upper Head - with Insert

10673-2 78-8137-0626-0 Plate - Cover

10673-3 78-8137-0624-5 Bracket - Upper with Insert

10673-4 78-8137-0628-6 Plate - Lock

10673-5 78-8137-0625-2 Plate

10673-6 78-8052-6659-6 Grommet

10673-7 78-8094-6145-8 Screw - Phillips, M5 x 12

10673-8 78-8137-0803-5 Plug /17

10673-9 78-8137-0627-8 Screw - M6 x 10

10673-10 26-1003-7964-8 Screw - Soc. Hd. Hex Soc. Dr. - M8 x 20

10673-11 78-8017-9318-9 Washer - Plain - 8 mm

10673-12 26-1003-6904-5 Nut - Hex - M8

10673-13 78-8137-0629-4 Knob

a20-NA

2011 April

a20 Adjustable Case Sealer

13 *

a20-NA

Figure 10674

2011 April

a20

Figure 10674

Ref. No. 3M Part No. Description

10674-1 78-8070-1599-1 Tube - Roller Support

10674-2 78-8137-0631-0 Assembly - Pressure Roller - L/H

10674-3 78-8137-0632-8 Assembly - Pressure Roller - R/H

10674-4 78-8137-0613-8 Support - Roller - L/H

10674-5 78-8137-0612-0 Support - Roller - R/H

10674-6 78-8054-8648-3 Roller - Pressure

10674-7 78-8055-0622-3 Bushing

10674-8 78-8137-0799-5 Screw - M8 x 35

10674-9 26-1004-5507-5 Washer M8

10674-10 26-1003-6904-5 Nut M8

10674-11 78-8137-0633-6 Knob

10674-12 26-1003-7969-7 Screw - Hex Soc. Hd. - M8 x 45 (a20)

10674-13 26-1003-7964-8 Screw - Hex Soc. Hd. - M8 x 20 (a70)

10674-14 78-8017-9318-9 Washer - Plain - 8 mm

10674-15 78-8052-6652-1 Cap End

a20-NA

2011 April

a20 Adjustable Case Sealer

Figure 10676/2

Figure 10676 / 1

a20-NA

2011 April

a20

Figure 10676 / 1

Ref. No. 3M Part No. Description

10676-1 78-8137-0653-4 Frame - L/H Gearbox 10676-2 78-8054-8977-6 Spacer 10676-3 78-8054-8975-0 Spacer 10676-4 26-1003-5820-4 Screw - Special - M5 10676-5 78-8137-0654-2 Frame - R/H Gearbox 10676-6 78-8054-8980-0 Pulley Timing Belt 10676-7 78-8054-8979-2 Housing - Bearing 10676-8 78-8054-8577-4 Washer - Special 10676-9 26-1001-9843-6 Screw - Flat - M6 10676-10 78-8028-8244-5 Key 10676-11 78-8054-8981-8 Sprocket 10676-12 78-8054-8877-8 Washer 10676-13 26-0001-5862-1 Screw - M5 10676-14 78-8054-8978-4 Pulley - with Bearing 10676-15 78-8076-4531-8 Shaft - Timing Pulley 10676-16 78-8016-5855-6 E-Ring 10676-17 78-8005-5741-1 Washer - Flat - M5 10676-18 78-8032-0382-3 Screw - Special - M5 10676-19 78-8010-7193-3 Screw - Special - M6 10676-20 78-8042-2919-9 Washer - Triple - M6 10676-21 78-8046-8267-8 Motor - 110V 60 Hz 10676-22 26-1004-5507-5 Washer - M8 10676-23 78-8017-9301-5 Screw - M8 10676-24 78-8005-5736-1 Lockwasher, - M8 10676-25 26-1003-6904-5 Nut - M8 10676-26 78-8054-8982-6 Pulley - Timing 10676-27 26-1003-8816-9 Screw - Set - M5 x 6 10676-28 78-8057-5808-9 Belt - Timing - 187L100 10676-29 78-8057-5724-8 Belt - Timing - 187L050 10676-30 78-8137-0655-9 Cover - Front 10676-31 78-8137-0656-7 Cover - Rear 10676-32 78-8076-4580-5 Nut - Self-Locking - M8 10676-33 78-8054-8987-5 Chain

a20-NA

2011 April

a20 Adjustable Case Sealer

Figure 10676 / 2

a20-NA

2011 April

a20

Figure 10676 / 2

Ref. No. 3M Part No. Description

10676-34 78-8137-0657-5 Drive Shaft

10676-35 78-8076-5105-0 Pulley Assembly - Drive

10676-36 78-8060-8416-2 Nut - Special - M20 x 1

10676-37 78-8076-4581-3 Shaft - Gear Box

10676-38 78-8054-8984-2 Bushing

10676-39 78-8054-8986-7 Sprocket - 3/8" Pitch - 28 Teeth

10676-40 78-8057-5811-3 Key - 6 x 6 x 20 mm

10676-41 78-8054-8983-4 Flange - Radial Ball Bearing

10676-42 78-8057-5739-6 Key - M5 x 5 x 30 mm 10676-43 78-8052-6713-1 Ring - Polyurethane

a20-NA

2011 April

a20 Adjustable Case Sealer

Detail - Part #7

Figure 10677

a20-NA

2011 April

a20

Figure 10677

Ref. No. 3M Part No. Description

10677-1 78-8137-0658-3 Conveyor

10677-2 78-8137-0659-1 Tension Belts - Assembly

10677-3 78-8017-9318-9 Washer - 8 mm

10677-4 78-8094-6145-8 Screw - Phillips M5

10677-5 78-8010-7209-7 Screw - Hex. Soc. Hd. - M6 x 12

10677-6 78-8137-0660-9 Cover

10677-7 78-8137-0661-7 Gear Box - Assembly

10677-8 78-8070-1531-4 Belt - with Hook

10677-9 26-1003-7964-8 Screw - M8

10677-10 78-8114-4633-1 Screw - Hex. Soc. Hd. - M8 x 100

10677-11 78-8137-0663-3 Support - Belt Tension

10677-12 78-8137-0664-1 Plate

10677-13 78-8137-0665-8 Shaft - Pulley

10677-14 78-8137-0666-6 Nut - Special, M25

10677-15 78-8052-6710-7 Roller

10677-16 78-8137-0667-4 Washer - Flat, M25

10677-17 78-8070-1518-1 Spacer - Shaft

10677-18 26-1004-5510-9 Washer - Flat, M10

10677-19 26-1003-6918-5 Nut - Plastic Insert M10

10677-20 78-8052-6709-9 Washer - Special

10677-21 78-8010-7435-8 Washer - M6

10677-22 26-1003-7957-2 Screw - M6

a20-NA

2011 April

THIS PAGE IS BLANK

Instructions and Parts List

Important Safety

Information

™

3M-Matic

™

AccuGlide 2+

STD 2 Inch

Upper and Lower

Taping Heads

BEFORE INSTALLING

OR OPERATING THIS

EQUIPMENT

Read, understand, and

follow all safety and

operating instructions.

Spare Parts

It is recommended you

Type 10500

Serial No._____________________________________

For reference, record taping head(s) serial number(s) here.

3M Industrial Adhesives and Tapes

3M Center, Building 220-5E-06 St. Paul, MN 55144-1000

immediately order the

spare parts listed in the

"Spare Parts/Service

Information" section.

These parts are expected

to wear through normal

use, and should be kept

on hand to minimize

production delays.

AccuGlide™ is a Trademark of 3M, St. Paul, MN 55144-1000 Printed in U.S.A.

Replacement Parts and Service Information

To Our Customers:

This is the 3M-Matic™/AccuGlide™/Scotch

equipment you ordered. It has been set up and tested in the factory with Scotch® tapes. If technical assistance or replacement parts are needed, call or fax the appropriate number listed below.

Included with each machine is an Instructions and Parts List manual.

Technical Assistance / Replacement Parts and Additional Manuals:

Call the 3M-Matic™ Help line at 1-800 328-1390. Provide the customer support coordinator with the model/ machine name, machine type, and serial number that are located on the identification plate (For example: Model 200a / Accuglide 2+ / 2 inch - Type 10500 - Serial Number 13282).

United States -

Identification Plate

3M Tape Dispenser Parts

241 Venture Drive

For Industrial Use Only

1-800-344-9883

Amery, WI 54001-1325

Fax: 1-715-268-8153

Minimum billing on parts orders will be $25.00. Replacement part prices available on request.

$10.00 restocking charge per invoice on returned parts

Note : Outside the U.S., contact the local 3M subsidiary for

parts ordering information.

4000563

3M Industrial Adhesives and Tapes

3M Center, Building 220-5E-06 St. Paul, MN 55144-1000

3M-Matic™, AccuGlide™ and Scotch™ are Trademarks of 3M St. Paul, MN 55144-1000 Printed in U.S.A.

THIS PAGE IS BLANK

Replacement Parts And Service Information

To Our Customers:

This is the 3M-Matic™/AccuGlide™/Scotch® equipment you ordered. It has been set up

and tested in the factory with Scotch® tapes. If any problems occur when operating this equipment and

you desire a service call or phone consultation, call, write, or fax the appropriate number listed below.

Included with each machine is an Instructions and Parts List manual.

SERVICE, REPLACEMENT PARTS, AND ADDITIONAL MANUALS

AVAILABLE DIRECT FROM:

Order parts by part number, part description, and quantity required. Also, when ordering parts

or additional manuals, include model/machine name, machine type, and serial number that are

located on the identiﬁ cation plate.

3M Industrial Adhesives and Tapes

3M Center, Building 220-5E-06 St. Paul, MN 55144-1000

3M-Matic™, AccuGlide™ and Scotch™ are Trademarks of 3M, St. Paul, MN 55144-1000 Printed in U.S.A.

THIS PAGE IS BLANK

Instruction Manual

AccuGlide

™

2+ STD 2 Inch Upper and Lower Taping Heads Type 10500

Table of Contents Page

Replacement Parts and Service Information ............................................................................................ i - ii

Table of Contents...................................................................................................................................... iii

Equipment Warranty and Limited Remedy ............................................................................................... iv

Intended Use ............................................................................................................................................ 1

Taping Head Contents / How to Use Manual............................................................................................ 3

Important Safeguards ............................................................................................................................... 4 - 5

Speciﬁ cations ........................................................................................................................................... 6 - 7

Dimensional Drawing .................................................................................................................... 7

Installation ................................................................................................................................................ 8

Receiving and Handling ................................................................................................................ 8

Installation Guidelines ................................................................................................................... 8

Tape Leg Length ........................................................................................................................... 8

Tape Width Adjustment ................................................................................................................. 8

Operation .................................................................................................................................................. 9 - 11

Tape Loading – Upper Taping Head .............................................................................................. 10

Tape Loading – Lower Taping Head .............................................................................................. 10 - 11

Maintenance ............................................................................................................................................. 12 - 13

Blade Replacement ....................................................................................................................... 12

Blade Guard .................................................................................................................................. 12

Blade Oiler Pad ............................................................................................................................. 12

Cleaning ........................................................................................................................................ 13

Applying/Bufﬁ ng Roller Replacement ............................................................................................ 13

Adjustments .............................................................................................................................................. 14 - 16

Tape Latch Alignment .................................................................................................................... 14

Tape Drum Friction Brake ............................................................................................................. 14

Applying Mechanism Spring .......................................................................................................... 15

One-Way Tension Roller ............................................................................................................... 15

Tape Leg Length ........................................................................................................................... 16

Leading Tape Leg Length Adjustment ............................................................................ 16

Changing Tape Leg Length From 70 to 50 mm [2-3/4 to 2 Inch] .................................... 16

Troubleshooting Guide ............................................................................................................................. 17 - 18

Spare Parts/Service Information............................................................................................................... 19

Recommended Spare Parts .......................................................................................................... 19

Replacement Parts and Service .................................................................................................... 19

Replacement Parts Illustrations and Parts List ................................................................ Yellow Section 20 - 37

2+ STD 2" Taping Head - NA

iii

2011 December

General Information - Warranty

Equipment Warranty and Limited Remedy: THE FOLLOWING WARRANTY IS MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE AND ANY IMPLIED WARRANTY ARISING OUT OF A COURSE OF DEALING, CUSTOM OR USAGE OF TRADE:

3M sells its AccuGlide™ 2+ STD 2 Inch Upper and Lower Taping Heads, Type 10500 with the following warranty:

1. The Taping Head blade, springs and rollers will be free from defects in material and manufacture for ninety (90) days after delivery.

2. All other Taping Head parts will be free from defects in material and manufacture for three (3) years after delivery.

If any part is defective within this warranty period, your exclusive remedy and 3M’s and seller’s sole obligation shall be, at 3M’s option, to repair or replace the part. 3M must receive actual notice of any alleged defect within a reasonable time after it is discovered, but in no event shall 3M have any obligation under this warranty unless it receives such notice within ﬁ ve (5) business days after the expiration of the warranty period. All notices required hereunder shall be given to 3M solely through the 3M-Matic™ Help line (800-328-1390). To be entitled to repair or replacement as provided under this warranty, the part must be returned as directed by 3M to its factory or other authorized service station designated by 3M. If 3M is unable to repair or replace the part within a reasonable time after receipt thereof, 3M, at its option, will replace the equipment or refund the purchase price. 3M shall have no obligation to provide or pay for the labor required to remove any part or equipment or to install the repaired or replacement part or equipment. 3M shall have no obligation to repair or replace those parts failing due to normal wear, inadequate or improper maintenance, inadequate cleaning, non-lubrication, improper operating environment, improper utilities, operator error or misuse, alteration or modiﬁ cation, mishandling, lack of reasonable care, or due to any accidental cause.

Limitation of Liability: Except where prohibited by law, 3M and seller will not be liable for any loss or damage arising from this 3M equipment, whether direct, indirect, special, incidental, or consequential, regardless of the legal theory asserted, including breach of warranty, breach of contract, negligence, or strict liability.

Note: The foregoing Equipment Warranty and Limited Remedy and Limitation of Liability may be changed only by

a written agreement signed by authorized representatives of 3M and seller.

AccuGlide™, Scotch™, and 3M-Matic™ are Trademarks of 3M, St. Paul, Minnesota 55144-1000

2+ STD 2" Taping Head - NA

iv 8

2011 December

Intended Use

The intended use of the AccuGlide™ 2+ STD 2 Inch Upper and Lower Taping Heads is to apply

a "C" clip of Scotch

pressure-sensitive ﬁ lm box sealing tape to the top and/or bottom center seam of regular slotted containers.

These taping heads are incorporated into most standard 3M-Matic™ case sealers. The compact

size and simplicity of the taping head also makes it suitable for mounting in box conveying systems other than 3M-Matic™ case sealers. This includes replacement of other types of taping, gluing or stapling heads in existing case sealing machines. The AccuGlide™ 2+ STD Taping Heads have been designed and tested for use with Scotch® pressuresensitive ﬁ lm box sealing tape.

AccuGlide™ 2+ STD 2 Inch Upper Taping Head, Type 10500

2+ STD 2" Taping Head - NA

2011 December

THIS PAGE IS BLANK

Taping Head Contents

AccuGlide

™

2+ STD 2 Inch Upper and Lower Taping Heads consist of:

Qty. Part Name

1 Taping Head Assembly 1 Tape Drum and Bracket Assembly 1 Hardware and Spare Parts Kit 1 Threading Tool

General Information

This instruction manual covers safety aspects, handling and transport, storage, unpacking, preparation, installation, operation, set-up and adjustments, technical and manufacturing speciﬁ cations, maintenance, troubleshoot- ing, repair work and servicing, electric diagrams, warranty information, disposal (ELV), a glossary with a deﬁ nition of symbols, plus a parts list of the 3M-Matic™ Accugllide 2+ (2 inch) 3M Industrial Adhesives and Tapes Division 3M Center, Bldg. 220-5E-06 St. Paul, MN 55144-1000 (USA) Edition December 2011/Copyright 3M 2011. All rights reserved The manufacturer reserves the right to change the product at any time without notice.

How to use this Manual

Electrical and pneumatic diagrams are included in the manual. Equipment using PLC controls and/or electronic components will include relevant schematics or programs in the enclosure (or will be delivered separately as needed)

Keep the manual in a clean and dry place near the machine. Do not remove, tear or rewrite parts of the manual for any reason. Use the manual without damaging it. However, if the manual has been lost or damaged, ask your after sale service for a new copy (if it is possible, please have the manual name, part number, and revision information and/or model/machine name, machine type, and serial number) that are located on the identiﬁ cation plate (For example: Accuglide 2+/2 inch - Type 10500 - Serial Number 13282).

Note:

All the important warning notes related to the operation of the machine are identiﬁ ed by the symbol:

Updating the Manual

Modiﬁ cations to the machine are subject to manufacturer's internal procedures. The user may receive pages or parts of the manual which contain amendment made after its ﬁ rst publication. The user must use them to update this manual.

2+ STD 2" Taping Head - NA

2011 December

Important Safeguards

This safety alert symbol identif es important safety messages in this

manual. READ AND UNDERSTAND THEM BEFORE INSTALLING OR OPERATING THIS EQUIPMENT.

Explanation of Signal Word Consequences

CAUTION:

WARNING:

Indicates a potentially hazardous situation, which, if not avoided, may result in minor or moderate injury and/or property damage.

Indicates a potentially hazardous situation, which, if not avoided, could result in death or serious injury and/or property damage.

WARNING

• To reduce the risk associated with

mechanical hazards:

CAUTION

• To reduce the risk associated with muscle

strain:

 Use proper body mechanics when

removing or installing taping heads that are moderately heavy or may be considered awkward to lift

• To reduce the risk associated with impact

hazards:

 Place the taping head on a smooth level

surface when maintaining or servicing this equipment

− Read, understand and follow all safety

and operating instructions before operating or servicing the case sealer

− Allow only properly trained and qualiﬁ ed

personnel to operate and/or service this equipment

• To reduce the risk associated with

shear, pinch, and entanglement hazards:

− Turn air and electrical supplies off on

associated equipment before perform ing any adjustments, maintenance, or servicing the taping heads

− Never attempt to work on the taping

head or load tape while the box drive system is running

• To reduce the risk associated with

sharp blade hazards:

− Keep hands and ﬁ ngers away from tape

cutoff blades under orange blade guards. The blades are extremely sharp

2+ STD 2" Taping Head - NA

(Important Safeguards continued on next page)

2011 December

Important Safeguards (continued)

Important - In the event the following safety labels are damaged or destroyed, they must be replaced to

ensure operator safety. See "Replacement Parts Illustrations and Parts Lists" for label part numbers.

78-8133-9605-4

78-8070-1335-0

Figure 1-1 Replacement Labels/3M Part Numbers

2+ STD 2" Taping Head - NA

78-8133-9606-2 Tape Threading Label (not shown)

2011 December

Specifications

1. Tape:

For use with Scotch® pressure-sensitive ﬁ lm box sealing tapes.

2. Tape Width:

36mm or 1-1/2 inches minimum to 48mm [2 inches] maximum.

3. Tape Roll Diameter:

Up to 405mm [16 inches] maximum on a 76.2mm [3 inch] diameter core. (Accommodates all system roll lengths of Scotch® ﬁ lm tapes.)

4. Tape Application Leg Length - Standard:

70mm ± 6mm [2-3/4 inches ±1/4 inch]

Tape Application Leg Length - Optional:

50mm ± 6mm [2 inches ± 1/4 inch] (See "Adjustments – Tape Leg Length.")

5. Box Size Capacities:

For use with center seam regular slotted containers.

Minimum Maximum

Length – 150mm [6 inches] Unlimited Height – 120mm [4-3/4 inches] (most “3M-Matic” Case Sealers) 90mm [3-1/2 inches] (with optional 2 inch leg length)

Width – 115mm [4-1/2 inches]

When upper and lower taping heads are used on “3M-Matic” case sealers, refer to the respective instruction

manual speciﬁ cations for box weight and size capacities.

6. Operating Rate:

Conveyor speeds up to 0.40m/s [80FPM] maximum.

7. Operating Conditions:

Use in dry, relatively clean environments at 5° to 40°C [40° to 105°F] with clean dry boxes.

Important – Taping heads should not be washed down or subjected to conditions causing moisture

condensation on components.

8. Taping Head Dimensions:

Length – 457mm [18 inches] Height – 560mm [22 inches] (with tape drum) Width – 105mm [4-1/8 inches] (without mounting spacers) Weight – Packaged: 7.7kg [17 lbs.] Unpackaged: 6.7kg [15 lbs.]

Limited by Case Sealer

2+ STD 2" Taping Head - NA

(Speciﬁ cations continued on next page.)

2011 December

Specifications (continued)

76mm [3 in.] 50mm Tape Leg

76mm [3 in.]

13mm

13 mm

[1/2 in.]

58 mm

58mm [2 9/32 in.

[2 9/32 in.]

Side View

M6 Mounting Holes

457mm

[18 in.]

396 mm

396mm

[15-19/32 in.]

350mm

[13-3/4 in.]

278mm

278 mm

[10-15/16 in.]

405mm [16 in.]

Maximum Roll

Diameter

105mm [4-1/8 in.]

End View

405mm [16 in.]

405 mm

Maximum Roll Diameter

6mm [1/4 in.] Maximum

18mm [11/16 in.]

18 mm [11/16 in.]

95mm [3 3/4 in.]

*120mm [4 3/4 in.] Minimum Standard Head Spacing

445 mm

445mm

[17-1/2 in.]

648 mm [25-1/2 in.]

* This dimension can be reduced to 90mm [3-1/2 in.] when both heads are converted to 50mm [2 in.] tape leg lengths.

2+ STD 2" Taping Head - NA

142mm [5-5/8 in.]

Box Feed Direction

18 mm [11/16 in.]

18mm [11/16 in.]

6mm [1/4 in.] Maximum

Optional Mounting Position

405mm [16 in.]

405 mm

Maximum Roll Diameter

Figure 2/1 Dimensional Drawing Figure 2-1 – Dimensional Drawing

Figure 2/1 Dimensional Drawing

Figure 2-1 – Dimensional Drawing



2011 December

Installation

- Keep hands and ﬁ ngers away from tape cutoff blades under orange blade guards.

The blades are extremely sharp

WARNING

• To reduce the risk associated with sharp blade hazards:

Receiving And Handling

After the taping head assembly has been unpackaged, examine the unit for damage that might have occurred during transit. If damage is evident, ﬁ le a damage claim immediately with the transportation company and also notify your 3M Representative.

Installation Guidelines

The taping head assembly can be used in converting existing or in custom made machinery. It can be mounted for top taping or bottom taping. Refer to "Box Size Capacities," as well as Figure 2-1 in the Speciﬁ cations section, for the following points in making such installations:

CAUTION

• To reduce risk associated with muscle

strain:

- Use proper body mechanics when

removing or installing taping heads

that are moderately heavy or may be

considered awkward to lift

Important – Always conduct a hazard review to

determine appropriate guarding requirements when the installation is in an application other than 3M-Matic™ equipment

3. Figure 2-1 illustrates the typical mounting

relationship for opposing taping head assemblies to allow taping of box heights down to 90mm [3-1/2 inches]. To tape box heights down to 70mm [2-3/4 inches], the taping heads must be completely staggered so only one tape seal is being applied at one time.

Note – AccuGlide™ 2+ STD Upper Taping

Head is supplied with a bufﬁ ng arm guard. Adjustments to this guard may be required to install the taping head into some older design 3M-Matic™ case sealers.

4. Mounting studs are provided with the taping head, but special installations may require alternate means for mounting.

5. Box hold-down or guide skis should be provided and the taping head mounted so that the side plates are 6mm [1/4 inch] maximum away from the ski surface on which the box rides.

Tape Leg Length

Taping heads are factory set to apply standard 70mm [2-3/4 inch] tape legs. The heads can be converted to apply 50mm [2 inch] tape legs if desired but both upper and lower heads must be set to apply the same tape leg length. See "Adjustments – Changing Tape Leg Length From 70 to 50mm [2-3/4 to 2 Inches]."

1. The box conveying system must positively propel the box in a continuous motion, not exceeding 0.40 m/s [80 feet per minute], past the taping head assembly since the box motion actuates the taping mechanism.

2. If a pusher or cleated conveyor is being used, steps should be taken in the conveyor design to prevent the pusher from contacting the applying or bufﬁ ng roller arms resulting in damage to the taping head.

2+ STD 2" Taping Head - NA

Also, the conveyor speed at which the product moves through the taping heads, affects the leading and trailing tape leg length. See "Adjustments section – Leading Tape Leg Length Adjustment."

Tape Width Adjustment

Taping heads are factory set to apply 48mm [2 inch] wide tape. If it is necessary to align the tape or to apply narrower tapes, refer to "Adjustments – Tape Web Alignment" for set-up procedure.

2011 December

Operation

Figure 3-1 Taping Head Components/Threading Diagram - Upper Head (Left Side View)

Orange Knife Guard

Tape Cut-Off Knife

Buffing

Roller

Buffing Arm

Cover

Applying

Mechanism

Spring

Applying Roller

Threading Needle

Wrap Roller

Knurled Roller

Tension Wrap Roller

One-Way Tension Roller

Tape Adhesive Side

Tape Supply Roll

Tape Drum

Figure 3-2 Taping Head Components/Threading Diagram - Lower Head (Left Side View)

2+ STD 2" Taping Head - NA

(Operation continued on next page)

2011 December

Operation (continued)

WARNING

• To reduce the risk associated with shear, pinch, and entanglement hazards:

− Turn air and electrical supplies off on associated equipment before performing any adjustments,

maintenance, or servicing the machine or taping heads

− Never attempt to work on the taping heads or load tape when the box drive system is running

• To reduce the risk associated with sharp blade hazards:

− Keep hands and ﬁ ngers away from tape cutoff blades under orange blade guards.

The blades are extremely sharp

It is recommended that the detailed instructions and sketches in this manual be referred to the ﬁ rst few times the taping head is loaded/threaded until the operator becomes thoroughly familiar with the tape loading operation.

Note – Remove tape roll before removing taping

head from machine to minimize weight.

CAUTION

•

muscle strain:

− Use proper body mechanics when

removing or installing taping heads that are moderately heavy or may be considered awkward to lift

To reduce the risk associated with

• To reduce the risk associated with

impact hazards:

− Place the taping head on a smooth level

surface when maintaining or servicing this equipment

Tape Loading – Upper Taping Head

1. Place the upper taping head in a convenient working position.

2. Use Figures 3-3 to 3-5 and tape threading la- bel. Position the tape supply roll so the adhesive side of tape is facing the front of the taping head as it is pulled from the supply roll.

3. Attach the threading needle to the end of the roll. Guide the threading needle around the wrap roller (Position 1) then back around the one-way tension roller (Position 2).

5. Pull the threading needle down until the tape travels between the apply plate and the ears of the apply arm (Position 4) until it extends past the applying roller. When properly threaded the adhesive side of the tape should be facing the knurled rollers at position 2 and also position 3.

6. Cut away any excess tape.

Important – Do not cut against the apply roller -

roller damage could occur.

Tape Loading – Lower Taping Head

1. Remove the lower taping head from the conveyor bed or associated equipment and place it a convenient working position.

2. The lower taping head is loaded and threaded in the same manner as the upper head. Follow the upper taping head tape loading/threading procedure.

Figure 3-3

Insert threading needle through rollers in direction indicated by arrows.

One-Way Tension Roller

Tension Wrap Roller

Knurled

Roller

Wrap Roller

Applying

Roller

4. Continue pulling the threading needle down and guide it between the two rollers on the apply arm (Position 3).

2+ STD 2" Taping Head - NA

Figure 3-3 – Tape Loading/Threading

2011 December

Operation (continued)

Figure 3-4

Place tape roll on tape drum to dispense tape with adhesive side forward. Seat tape roll fully against back ﬂ ange of drum. Adhere tape lead end to threading needle as shown.

WARNING

Figure 3-4 – Tape Loading/Threading

• To reduce the risk associated with

sharp blade hazards:

- Keep hands and ﬁ ngers away from

tape cutoff blades under orange blade guards. The blades are extremely sharp.

Manually turn tape roll to create slack tape while pulling threading needle through tape applying mechanism until needle is through and tape is in alignment with applying roller.

Excess tape can be cut with a scissors at applying roller.

Figure 3-5 – Tape Loading/Threading

2+ STD 2" Taping Head - NA

2011 December

Maintenance

WARNING

• To reduce the risk associated with shear, pinch, and entanglement hazards:

− Turn air and electrical supplies off on associated equipment before performing any adjustments,

maintenance, or servicing the taping heads

− Never attempt to work on the taping head or load tape while the box drive system is running

• To reduce the risk associated with sharp blade hazards:

− Keep hands and ﬁ ngers away from tape cutoff blades under orange blade guards.

The blades are extremely sharp

The AccuGlide™ 2+ STD 2 Inch Taping Head has been designed for long, trouble free service. The taping head will perform best when it receives routine maintenance and cleaning. Taping head components that fail or wear excessively should be promptly repaired or replaced to prevent damage to other portions of the head or to the product.

Blade Replacement, Upper and Lower Taping Heads – Figure 4-1

WARNING

• To reduce the risk associated with

sharp blade hazards:

- Keep hands and ﬁ ngers away from tape

cutoff blades under orange blade guards. The blades are extremely shar

1. Loosen, but do not remove, the blade screws (A). Remove and discard old blade.

2. Mount the new blade (B) with the beveled side away from the blade holder.

3. Bottom the blade slots against the screws. (This will position the blade at the correct angle.) Tighten the blade screws to secure the blade.

Note – Check the blade position to insure proper

clearance between blade and guard by slowly pivoting the blade guard back.

Blade Guard

The blade guard covers the blade whenever a box is not being taped. Periodically check to be sure the blade guard is functioning properly and returning to cover the blade. Replace any defective parts.

Blade Oiler Pad

WARNING

• To reduce the risk associated with

sharp blade hazards:

- Keep hands and ﬁ ngers away from tape

cutoff blades under orange blade guards. The blades are extremely sharp

Knife Guard

Figure 4-1 – Blade Replacement

2+ STD 2" Taping Head - NA

Knife Holder

To reduce adhesive build-up, the taping heads are equipped with a factory pre-lubricated felt oiler pad that provides a ﬁ lm of oil on the cutting edge of the blade. Blade maintainance should include keeping the felt oiler pad saturated with SAE #30 nondetergent oil.

Should tape adhesive build-up occur on blade, carefully wipe the blade clean with an oily cloth.

(Maintenance continued on next page.)

2011 December

Maintenance (continued)

• To reduce the risk associated with shear, pinch, and entanglement hazards:

− Turn air and electrical supplies off on associated equipment before performing any adjustments, maintenance, or servicing the taping heads

− Never attempt to work on the taping head or load tape while the box drive system is running

• To reduce the risk associated with sharp blade hazards:

− Keep hands and ﬁ ngers away from tape cutoff blades under orange blade guards.

The blades are extremely sharp

WARNING

Cleaning

Regular slotted containers produce a great deal of dust and paper chips when conveyed through taping heads. If this dust is allowed to build-up on the heads, it can cause wear on the moving parts. Excessive dirt build-up should be wiped off with a damp cloth. Cleaning should be done once per month, depending on the number and type of boxes used. If the boxes used are dirty, or if the environment in which the heads operate is dusty, cleaning on a more frequent basis may be necessary.

Note – Never attempt to remove dirt from taping

heads by blowing it out with compressed air. This can cause the dirt to be blown inside the components onto sliding surfaces. Dirt in these areas can cause serious equipment damage. Never wash down or subject taping heads to conditions causing moisture condensation on components.

Serious equipment damage could result.

Applying/Buffing Roller Replacement

Replacing roller requires removal of shaft and mounting screws. With no area on the shaft to grip, the shaft often turns when attempting to remove the second screw.

To ease removal of second screw, a 4mm hex socket has been provided at the bottom of the threads in both ends of the shaft. Insert a 4mm hex key wrench into this socket after removing one screw to hold the shaft for removal of the second screw (Figure 4-2).

Hex Socket

Section View of

4mm Hex Key Wrench

Roller/Shaft

2+ STD 2" Taping Head - NA

Figure 4-2 – Roller Shaft Section View

2011 December

Adjustments

WARNING

• To reduce risk associated with shear,

pinch, and entanglement hazards:

- Turn air and electrical supplies off associated equipment before performing any adjustments, maintenance, or servicing the machine or taping heads.

- Never attempt to work on the taping head or load tape while the box drive system is running.

Tape Latch Alignment – Figure 5-1 The Latching tape drum assembly is pre-set to

accommodate 48mm [2 inch] wide tape. The tape drum assembly is adjustable to provide alignment of narrower tapes.

To move the latch to a position that corresponds to a new tape core width (Figure 5-1):

Figure 5-1 – Tape Latch Alignment

1. Remove screw from the latch.

2. Move to the latch to the position that corresponds to the tape core width.

3. Replace screw in the new latch location.

To adjust or center the tape width on the centerline of the taping head, and therefore box center seam,

(Figure 5-2):

1. Loosen the locking hex nut behind tape drum bracket on tape drum shaft. Use an adjustable wrench or 25mm open end wrench.

2. Turn tape drum shaft in or out to center the tape web (use 5mm hex wrench).

3. Tighten locking hex nut to secure the adjustment.

No other components require adjustment for tape web alignment.

Tape Drum Friction Brake – Figure 5-3

The tape drum friction brake on each taping head is pre-set for normal operation to prevent tape roll over travel. Should tension adjustment be required, turn the self-locking nut on the shaft to vary compression of the spring. Turn the nut clockwise to increase the braking force, and counterclockwise to decrease the braking force. Adjust brake to minimum tension to prevent excessive tape roll over travel.

25mm Hex Wrench

5mm Hex

Wrench

Shaft

Figure 5-2 – Tape Web Alignment

Adjustment Nut, Tape Drum Brake

Note – Excess braking force will cause poor tape

application and may lead to tape tabbing on the trailing tape leg.

2+ STD 2" Taping Head - NA

Figure 5-3 – Tape Drum Friction Brake

(Adjustments continued on next page.)

2011 December

Adjustments (continued)

WARNING

• To reduce risk associated with

shear, pinch, and entanglement hazards:

- Turn air and electrical supplies off associated equipment before performing any adjustments, maintenance, or servicing the machine or taping heads.

- Never attempt to work on the taping head or load tape while the box drive system is running.

Applying Mechanism Spring

To obtain access to the spring, remove the taping head cover (four mounting screws). Replace cover when ﬁ nished.

The applying mechanism spring, shown in Figures 5-4A and 5-4B, controls applying and bufﬁ ng roller pressure on the box and returns the mechanism to the reset position. The spring pressure is pre-set, as shown in Figure 5-4A for normal operation, but is adjustable.

Figure 5-4 – Applying Mechanism Spring

If a tape gap appears on the trailing surface of the box increase spring pressure. If the front of the box is being crushed by the applying roller decrease spring pressure.

Removing the spring end loop from the spring holder and placing loop in other holes provided, as shown in Figure 5-4B, will adjust the spring pressure.

One-Way Tension Roller Figure 5-5

The one-way tension roller is factory set. When replacing this assembly, the roller must have 0,5 kg [1 lb.] minimum tangential force when turning.

To Adjust Tension:

1. Wrap a cord or small strap (non-adhesive) 4-6 turns around the tension roller.

2. Attach a spring scale to the end of the cord or strap.

3. Turn the adjusting nut with the socket wrench provided, until a force of approximately 0.5 kg to

0.9 kg [1 to 2 lbs.] is required to turn the roller by pulling on the spring scale.

2+ STD 2" Taping Head - NA

0.5 - 0.9kg [1/2 lbs.]

Adjusting Nut

Figure 5-5 – One-Way Tension Roller

(Adjustments continued on next page.)

2011 December

Adjustments (continued)

WARNING

• To reduce the risk associated with

shear, pinch, and entanglement hazards:

- Turn air and electrical supplies off

associated equipment before perform ing any adjustments, maintenance, or servicing the machine or taping heads.

- Never attempt to work on the taping head or load tape while the box drive system is running.

Tape Leg Length

WARNING

• To reduce the risk associated with

sharp blade hazards:

- Keep hands and ﬁ ngers away from tape

cutoff blades under orange blade guards. The blades are extremely sharp

Leading Tape Leg Length Adjustment – Figure 5-6

One-Way Tension Roller

Tape Leg 50 or 70mm ± 6mm [2 or 2-3/4in. ± 1/4in.

Figure 5-6 – Leading Tape Leg Length

The one-way tension roller position is adjustable to control the leading tape leg length.

Moving this roller farther away from the box top or bottom surface will decrease the leading leg length. Moving it closer to the box top or bottom surface will increase the leading leg length.

Changing Tape Leg Length from 70 to 50mm to 2 Inches] – Figure 5-7

Note – When changing tape leg length, both

upper and lower heads must be adjusted to apply the same leg lengths.

1. Remove and retain two hex head screws and remove the brush from normal position “A” on side frame.

2. Remount and secure brush in position “A-A” on side frame forward of normal location using original fasteners.

3. Remove cut-off bracket extensions from position "B".

4. Remount cut-off bracket extensions in forward position “B-B”.

5. Remove and retain the one-way tension roller assembly from slot “C” in frame.

6. Remount tension roller assembly near top of slot “C-C” in frame using original fasteners.

7. Adjust tension roller according to "Leading Tape Leg Length Adjustment" above.

[2-3/4

One-Way Tension Roller

Position A

Position A-A

Position B

Brush

Position B-B

Figure 5-7 – Changing Tape Leg Length

Assembly

Slot C-C

Cut-Off Bracket Extension

Slot C

2+ STD 2" Taping Head - NA

2011 December

Troubleshooting

Troubleshooting Guide

Problem

The tape leg on the front of the case is too long

Cause

The tape is threaded incorrectly

The tape tension is too low

The knurled roller drags

Tape tracks to one side or drags on the support tabs of applying frame

The one-way tension roller is not correctly positioned

Taping head is not set up properly

Correction

The tape must go around the wrap roller before going around the one-way tension roller

Adjust the one-way tension roller

Check for adhesive build-up between the knurled roller and its shaft. Clean and lubricate shaft. Remove all lubricant from roller surfaces.

Adjust the tape web alignments

Position the roller in its mounting slot so that the tape extends just beyond the centerline of the applying roller

Check leg length adjustments

The blade does not cut tape or the tape end is jagged or shredded

The blade is dull and/or has broken teeth

Tape tension is insufﬁ cient

Adhesive has built up on the blade

The blade is not positioned properly

The blade is dry

The blade is in backwards

One or both cutter springs are missing or stretched

Tension roller surface is not fully contacting the taping head frame

Replace the blade

Increase tape tension by adjusting the one-way tension roller

Clean and adjust the blade

Make sure the blade is bottomed out against the mounting bolts

Lubricate the blade oiler pad on the blade guard

Mount the blade so that the beveled edge is away from the entrance of the head

Replace the defective spring(s)

Make sure one-way bearing is below the surface of the tension roller. If not, press bearing further into roller or replace roller.

2+ STD 2" Taping Head - NA

2011 December

Troubleshooting (continued)

Troubleshooting Guide

Problem

Tape is tabbing on the trailing leg on the back of the box

The tape end does not stay in application position in front of the applying roller

Cause

There is excess tension on the tape drum assembly and/or the one-way tension roller assembly

Rollers in the tape path do not rotate freely

The blade is not cutting tape properly

The tape is threaded incorrectly

Applying mechanism spring has too little tension

The tape is incorrectly threaded

Flanged knurled roller overruns on return of applying mechanism to its rest position

Correction

Adjust the one-way tension roller and/or the tape drum assembly

Clean adhesive deposits from the surface, ends, and shafts of the rollers. Then lubricate roller shafts. Remove all lubricant from roller surfaces.

Refer to tape cutting problems

Re thread the tape

Move spring hook to next tighter hole

Re thread the tape

Adjust tension roller position in mounting slot to lengthen tape leg

Tape not centered on box seam

2+ STD 2" Taping Head - NA

Applying roller overruns on return of applying mechanism to its rest position

The one-way tension roller is not correctly positioned

The one-way tension roller is defective

Tape drum not centered

Centering guides not centered

Box ﬂ aps not of equal length

There should be a slight drag when rotating the applying roller. If not, check friction springs and/ or friction pins and replace if necessary

Position roller in it mounting slot so that tape end extends beyond centerline of applying roller

Replace the one-way tension roller

Reposition tape drum

Adjust centering guides

Check box speciﬁ cations

2011 December

Spare Parts/Service Information

Recommended Spare Parts

Listed are a set of spare parts that will periodically require replacement due to normal wear. These parts should be ordered to keep the taping heads in production:

AccuGlide™ 2+ STD 2 Inch Upper Taping Head

Qty. Part Number Description

4 78-8076-4500-3 Stud – Mounting 1 78-8070-1274-1 Spring – Upper Extension (Silver) 1 78-8017-9173-8 Blade – 65 mm/2.56 Inch 2 78-8052-6602-6 Spring – Cutter 1 78-8076-4726-4 Tool – Tape Threading

AccuGlide™ 2+ STD 2 Inch Lower Taping Head

Qty. Part Number Description

1 78-8017-9173-8 Blade – 65 mm/2.56 Inch 2 78-8052-6602-6 Spring – Cutter 4 78-8076-4500-3 Stud – Mounting 1 78-8070-1273-3 Spring – Lower Extension (Black) 1 78-8076-4726-4 Tool – Tape Threading

In addition to the above set of spare parts supplied with the taping head, it is suggested that the following spare parts be maintained which will require replacement under normal wear of the taping head.

Qty. Part Number Description

1 78-8057-6179-4 Roller – Applying 1 78-8057-6178-6 Roller – Bufﬁ ng 1 78-8113-7030-9 Spring – Torsion

Replacement Parts and Service

Refer to the ﬁ rst page of this instruction manual “Replacement Parts and Service Information".

2+ STD 2" Taping Head - NA

2011 December

Replacement Parts Illustrations and Parts Lists AccuGlide™ 2+ STD 2 Inch Upper Taping Head, Type 10500 AccuGlide™ 2+ STD 2 Inch Lower Taping Head, Type 10500

1. Refer to the Taping Head Assemblies Figure to ﬁ nd all the parts illustrations identiﬁ ed by f gure numbers.

2. Refer to the ﬁ gure or ﬁ gures to determine the individual parts required and the parts reference number.

3 . The replacement parts list, that follows each illustration, includes the part number and part description

for the parts in that illustration.

Note – The complete description has been included for standard fasteners and some commercially

available components. This has been done to allow obtaining these standard parts locally, should the customer elect to do so.

4. Refer to the ﬁ rst page of this instruction manual "Replacement Parts and Service Information" for replacement parts ordering information.

Important – Not all the parts listed are normally stocked items. Some parts or assemblies shown

are available only on a special order basis. Contact 3M/Tape Dispenser Parts to conﬁ rm item availability.

2+ STD 2" Taping Head - NA

2011 December

AccuGlide

™

2+ STD 2 Inch

Figure 10401

Figure 10397 (Upper)

Figure 10399 (Lower)

Figure 10395

Figure 10393

Figure 10387 (Upper)

Figure 10389 (Lower)

STD 2" Taping Head - NA

Figure 10391

Taping Head Assemblies - AccuGlide™ 2+ STD 2 Inch

20111RYHPEHU

AccuGlide

™

2+ STD 2 Inch

27 28

Figure 10397 – Upper Head

STD 2" Taping Head - NA

2011 1RYHPEHU
