IMPORTANT!
READ CAREFULLY BEFORE USE.
KEEP THIS GUIDE FOR FUTURE REFERENCE.
Screenshots and graphics in this book may differ slightly from your product due to differences in
your product firmware or your computer operating system. Every effort has been made to ensure
that the information in this manual is accurate.
Related Documentation
•Quick Start Guide
The Quick Start Guide shows how to connect the Device and get up and running right away.
Dynamic DNS Setup .............................................................................................................................175
Interface Group .....................................................................................................................................179
USB Service ..........................................................................................................................................185
Power Management .............................................................................................................................. 193
MAC Filter .............................................................................................................................................205
Parental Control ....................................................................................................................................207
Traffic Status ........................................................................................................................................271
VoIP Status ...........................................................................................................................................275
User Account .........................................................................................................................................289
Time Settings ........................................................................................................................................301
13.1.1 What You Can Do in this Chapter ........................................................................................185
13.1.2 What You Need To Know .....................................................................................................185
13.1.3 Before You Begin .................................................................................................................187
13.2 The File Sharing Screen ...............................................................................................................188
13.2.1 The Add New Share Screen ................................................................................................189
13.2.2 The Add New User Screen ..................................................................................................190
13.3 The Media Server Screen .............................................................................................................190
13.4 Printer Server ............................................................................................................................... 191
13.4.1 Before You Begin .................................................................................................................191
13.4.2 The Printer Server Screen ................................................................................................... 192
Chapter 14
Power Management..........................................................................................................................193
15.1.1 What You Can Do in this Chapter ........................................................................................197
15.1.2 What You Need to Know ......................................................................................................198
15.2 The Firewall Screen ...................................................................................................................... 199
15.3 The Protocol Screen ....................................................................................................................199
VMG8324-B10A / VMG8324-B30A Series User’s Guide
9
Table of Contents
15.3.1 Add/Edit a Service ..............................................................................................................200
15.4 The Access Control Screen ..........................................................................................................201
15.4.1 Add/Edit an ACL Rule ........................................................................................................202
15.5 The DoS Screen ............................................................................................................................204
Chapter 16
MAC Filter..........................................................................................................................................205
Appendix A Customer Support ........................................................................................................329
Appendix B Setting up Your Computer’s IP Address.......................................................................335
Appendix C IP Addresses and Subnetting.......................................................................................357
Appendix D Pop-up Windows, JavaScripts and Java Permissions .................................................365
Appendix E Wireless LANs..............................................................................................................375
Appendix F IPv6 ..............................................................................................................................389
Appendix G Services .......................................................................................................................397
Appendix H Legal Information .........................................................................................................401
Index ..................................................................................................................................................405
14
VMG8324-B10A / VMG8324-B30A Series User’s Guide
PART I
User’s Guide
15
16
1.1 Overview
The Device is a wireless VDSL router and Gigabit Ethernet gateway . It has a DSL port and a Gigabit
Ethernet port for super-fast Internet access. The Device supports both Packet Transfer Mode (PTM)
and Asynchronous Transfer Mode (ATM). It is backward compatible with ADSL, ADSL2 and ADSL2+
in case VDSL is not available.
Only use firmware for your Device’s specific model. Refer to the label on
the bottom of your Device.
The Device has two USB ports for sharing files via a USB storage device, sharing a USB printer, or
connecting a 3G dongle for a WAN backup connection.
• The VMG8324-B10A works over the analog telephone system, POTS (Plain Old Telephone
Service).
• The VMG8324-B30A works over ISDN (Integrated Services Digital Network) or T-ISDN (UR-2).
CHAPTER 1
Introducing the Device
1.2 Ways to Manage the Device
Use any of the following methods to manage the Device.
• Web Configurator. This is recommended for everyday management of the Device using a
(supported) web browser.
• TR-069. This is an auto-configuration server used to remotely configure your device.
1.3 Good Habits for Managing the Device
Do the following things regularly to make the Device more secure and to manage the Device more
effectively.
• Change the password. Use a password that’s not easy to guess and that consists of different
types of characters, such as numbers and letters.
• Write down the password and put it in a safe place.
• Back up the configuration (and make sure you know how to restore it). Restoring an earlier
working configuration may be useful if the device becomes unstable or even crashes. If you
forget your password, you will have to reset the Device to its factory default settings. If you
backed up an earlier configuration file, you would not ha ve to totally re-configure the Device. You
could simply restore your last configuration.
VMG8324-B10A / VMG8324-B30A Series User’s Guide17
Chapter 1 Introducing the Device
ADSL / VDSL
WLAN
PPPoE
IPoE
Bridging
WAN
ADSL
IPoA
WAN
LAN
LAN
WLAN
A
A
PPPoA
IPoE
PPPoE
Bridging
1.4 Applications for the Device
Here are some example uses for which the Device is well suited.
1.4.1 Internet Access
Your Device provides shared Internet access by connecting the DSL port to the DSL or MODEM
jack on a splitter or your telephone jack. You can have multiple WAN services over one ADSL or
VDSL. The Device cannot work in ADSL and VDSL mode at the same time.
Note: The ADSL and VDSL lines share the same WAN (layer-2) interfaces that you
configure in the Device. Refer to Section 5.2 on page 47 for the Network Setting > Broadband screen.
Computers can connect to the Device’s LAN ports (or wirelessly).
Figure 1 Device’s Internet Access Application
18
You can also configure IP filtering on the Device for secure Internet access. When the IP filter is on,
all incoming traffic from the Internet to your network is blocked by default unless it is initiated from
your network. This means that probes from the outside to your network are not allowed, but you
can safely browse the Internet and download files.
VMG8324-B10A / VMG8324-B30A Series User’s Guide
1.4.2 Device’s USB Support
B
A
B
A
The USB port of the Device is used for file-sharing, media server and printer-sharing.
File Sharing
Use the built-in USB 2.0 port to share files on a USB memory stick or a USB hard drive (B). You can
connect one USB hard drive to the Device at a time. Use FTP to access the files on the USB device.
Figure 2 USB File Sharing Application
Chapter 1 Introducing the Device
Media Server
You can also use the Device as a media server. This lets anyone on your network play video, music,
and photos from a USB device (B) connected to the Device’s USB port (without having to copy them
to another computer).
Figure 3 USB Media Server Application
VMG8324-B10A / VMG8324-B30A Series User’s Guide
19
Chapter 1 Introducing the Device
2.4G5G
Printer Server
The Device allows you to share a USB printer on your LAN. You can do this by connecting a USB
printer to one of the USB ports on the Device and then configuring a TCP/IP port on the computers
connected to your network.
Figure 4 Sharing a USB Printer
1.5 LEDs (Lights)
The following graphic displays the labels of the LEDs.
Figure 5 LEDs on the Device
None of the LEDs are on if the Device is not receiving power.
Table 1 LED Descriptions
LEDCOLORSTATUSDESCRIPTION
GreenOnThe Device is receiving power and ready for use.
PWR/SYS
RedOnThe Device detected an error while self-testing, or there is a device
GreenOnThe ADSL line is up.
DSL
OrangeOnThe VDSL line is up.
BlinkingThe Device is self-testing.
malfunction.
OffThe Device is not receiving power.
BlinkingThe Device is initializing the ADSL line.
BlinkingThe Device is initializing the VDSL line.
OffThe DSL line is down.
20
VMG8324-B10A / VMG8324-B30A Series User’s Guide
Table 1 LED Descriptions (continued)
LEDCOLORSTATUSDESCRIPTION
GreenOnThe Device has an IP connection but no traffic.
Chapter 1 Introducing the Device
INTERNET
WAN
LAN
WiFi 2.4G
Phone1,
Phone2
USB1
USB2
Your device has a WAN IP address (either static or assigned by a DHCP
server), PPP negotiation was successfully completed (if used) and the
DSL connection is up.
BlinkingThe Device is sending or receiving IP traffic.
OffThere is no Internet connection or the gateway is in bridged mode.
RedOnThe Device attempted to make an IP connection but failed. Possible
causes are no response from a DHCP server, no PPPoE response, PPPoE
authentication failed.
GreenOnThe Device has a successful 1000 Mbps Ethernet connection on the
WAN.
Blinking The Device is sending or receiving data to/from the WAN at 1000 Mbps.
OrangeOnThe Device has a successful 10/100 Mbps Ethe rnet connection on the
WAN.
BlinkingThe Device is sending or receivin g data to/from the WAN at 10/100
Mbps.
OffThere is no Ethernet connection on the WAN.
GreenOnThe Device has a successful 1000 Mbps Ethernet connection with a
device on the Local Area Network (LAN).
Blinking The Device is sending o r receiving data to/from the LAN at 1000 Mbps.
OffThe Device does not have an Ethernet connection with the LAN.
GreenOnThe 2.4 GHz wireless network is activated.
BlinkingThe Device is communicating with other wireless clients.
OrangeBlinkingThe Device is setting up a WPS connection.
OffThe 2.4 GHz wireless network is not activated.
GreenOnA SIP account is registered for the phone port.
BlinkingA telephone connected to the phone port has its receiver off of the hook
or there is an incoming call.
OrangeOnA SIP account is registered for the phone port and there is a voice
message in the corresponding SIP account.
BlinkingA telephone connected to the phone port has its receiver off of the hook
and there is a voice message in the corresponding SIP account.
OffThe phone port does not have a SIP account registered.
GreenOnThe Device recognizes a USB connection through the USB1 slot.
BlinkingThe Device is sending/receiving data to /from the USB device connected
to it.
OffThe Device does not detect a USB connection through the USB1 slot.
GreenOnThe Device recognizes a USB connection through the USB2 slot.
BlinkingThe Device is sending/receiving data to /from the USB device connected
to it.
OffThe Device does not detect a USB connection through the USB2 slot.
VMG8324-B10A / VMG8324-B30A Series User’s Guide
21
Chapter 1 Introducing the Device
1.6 The RESET Button
If you forget your password or cannot access the W eb Configurator, you will need to use the RESET
button at the back of the device to reload the factory-default configuration file. This means that y ou
will lose all configurations that you had previously and the password will be reset to “1234”.
1Make sure the PWR/SYS LED is on (not blinking).
2To set the device back to the factory default settings, press the RESET button for ten seconds or
until the PWR/SYS LED begins to blink and then release it. When the PWR/SYS LED begins to
blink, the defaults have been restored and the device restarts.
1.7 Wireless Access
The Device is a wireless Access Point (AP) for wireless clients, such as notebook computers or PDAs
and iPads. It allows them to connect to the Internet without having to rely on inconvenient Ethernet
cables.
You can configure your wireless network in either the built-in Web Configurator, or using the WPS
button.
Figure 6 Wireless Access Example
1.7.1 Using the Wi-Fi and WPS Buttons
If the wireless network is turned off, press the Wi-Fi button for one second. Once the WiFi 2.4G
LED turns green, the wireless network is active.
You can also use the WPS button to quickly set up a secure wireless connection between the Device
and a WPS-compatible client by adding one device at a time.
To activate WPS:
1Make sure the PWR/SYS LED is on and not blinking.
2Press the WPS button for five seconds and release it.
3Press the WPS button on another WPS-enabled device within range of the Device. The WiFi 2.4G
LED flashes orange while the Device sets up a WPS connection with the other wireless device.
22
VMG8324-B10A / VMG8324-B30A Series User’s Guide
4Once the connection is successfully made, the WiFi 2.4G LED shines green.
To turn off the wireless network, press the Wi-Fi button for one to five seconds. The WiFi 2.4G
LED turns off when the wireless network is off.
1.8 Wall-mounting Instructions
Do the following to hang your Device on a wall.
1Locate a high position on a wall that is free of obstructions. Use a sturdy wall.
2Hold the bracket against the wall and mark where to drill the holes.
3Drill the two screw holes in the wall.
Be careful to avoid damaging pipes or cables located inside the wall
when drilling holes for the screws.
Chapter 1 Introducing the Device
4Align and insert the bracket to the wall-mounting notches on the rear panel of the Device.
5Push the bracket up to tightly attach it to the Device.
VMG8324-B10A / VMG8324-B30A Series User’s Guide
23
Chapter 1 Introducing the Device
6Mount the Device on the screws which are already installed on the wall. Make sure that the Device
is firmly attached to the screws so it does not fall off.
24
VMG8324-B10A / VMG8324-B30A Series User’s Guide
2.1 Overview
The web configurator is an HTML-based management interface that allows easy device setup and
management via Internet browser. Use Internet Explorer 6.0 and later versions or Mozilla Firefox 3
and later versions or Safari 2.0 and later versions. The recommended screen resolution is 1024 by
768 pixels.
In order to use the web configurator you need to allow:
• Web browser pop-up windows from your device. Web pop-up blocking is enabled by default in
Windows XP SP (Service Pack) 2.
• JavaScript (enabled by default).
• Java permissions (enabled by default).
CHAPTER 2
The Web Configurator
See Appendix D on page 365 if you need to make sure these functions are allowed in Internet
Explorer.
2.1.1 Accessing the Web Configurator
1Make sure your Device hardware is properly connected (refer to the Quick Start Guide).
2Launch your web browser. If the Device does not automatically re-direct you to the login screen, go
to http://192.168.1.1.
3A password screen displays. To access the administrative web configurator and manage the Device,
type the default username admin and password 1234 in the password screen and click Login. If
advanced account security is enabled (see Section 30.2 on page 289) the number of dots that
appears when you type the password changes randomly to prevent anyone watching the password
field from knowing the length of your password. If you have changed the password, enter your
password and click Login.
Figure 7 Password Screen
VMG8324-B10A / VMG8324-B30A Series User’s Guide25
Chapter 2 The Web Configurator
4The following screen displays if you have not yet changed your password. It is strongly
recommended you change the default password. Enter a new password, retype it to confirm and
click Apply; alternatively click Skip to proceed to the main menu if you do not want to change the
password now.
Figure 8 Change Password Screen
5The Quick Start Wizard screen appears. You can configure the Device’s time zone, basic Internet
access, and wireless settings. See Chapter 3 on page 33 for more information.
6After you finished or closed the Quick Start Wizard screen, the Network Map page appears.
Figure 9 Network Map
7Click Status to display the Status screen, where you can view the Device’s interface and system
information.
26
VMG8324-B10A / VMG8324-B30A Series User’s Guide
2.2 Web Configurator Layout
B
C
A
Figure 10 Screen Layout
Chapter 2 The Web Configurator
As illustrated above, the main screen is divided into these parts:
• A - title bar
• B - main window
• C - navigation panel
2.2.1 Title Bar
The title bar provides some icons in the upper right corner.
The icons provide the following functions.
Table 2 Web Configurator Icons in the Title Bar
ICON DESCRIPTION
Language: Select the language you prefer.
Quick Start: Click this icon to open screens where you can configure the Device’s time zone
Internet access, and wireless settings.
Logout: Click this icon to log out of the web configurator.
VMG8324-B10A / VMG8324-B30A Series User’s Guide
27
Chapter 2 The Web Configurator
2.2.2 Main Window
The main window displays information and configuration fields. It is discussed in the rest of this
document.
After you click Status on the Connection Status page, the Status screen is displayed. See
Chapter 4 on page 38 for more information about the Status screen.
If you click Virtual Device on the System Info screen, a visual graphic appears, showing the
connection status of the Device’s ports. The connected ports are in color and disconnected ports are
gray.
Figure 11 Virtual Device
28
VMG8324-B10A / VMG8324-B30A Series User’s Guide
2.2.3 Navigation Panel
Use the menu items on the navigation panel to open screens to configure Device features. The
following tables describe each menu ite m.
Table 3 Navigation Panel Summary
LINKTABFUNCTION
Connection StatusThis screen shows the network status of the Device and computers/
Network Setting
BroadbandBroadbandUse this screen to view and configure ISP parameters, WAN IP
3G BackupUse this screen to configure 3G WAN connection.
AdvancedUse this screen to enable or disable PTM over ADSL, Annex M/Annex
802.1xUse this screen to view and configure the IEEE 802.1x settings on the
Wan StatusUse this screen to view historical traffic transmission statistics of a
WirelessGeneralUse this screen to configure the wireless LAN settings and WLAN
More APUse this screen to configure multiple BSSs on the Device.
MAC
Authentication
WPSUse this screen to configure and view your WPS (Wi-Fi Protected
WMMUse this screen to enable or disable Wi-Fi MultiMedia (WMM).
WDSUse this screen to set up Wireless Distribution System (WDS) links to
OthersUse this screen to configure advanced wireless settings.
Channel StatusUse this screen to scan wireless LAN channel noises and view the
Home
Networking
LAN SetupUse this screen to configure LAN TCP/IP settings, and other advanced
Static DHCP Use this screen to assign specific IP addresses to individual MAC
UPnPUse this screen to turn UPnP and UPnP NAT-T on or off.
Additional
Subnet
STB Vendor IDUse this screen to have the Device automatically create static DHCP
5th Ethernet
port
LAN VLANUse this screen to control the VLAN ID and IEEE 802.1p priority tags
Wake on LanUse this screen to remotely turn on a device on the network.
Chapter 2 The Web Configurator
devices connected to it.
address assignment, and other advanced properties. You can also
add new WAN connections.
J, and DSL PhyR functions.
Device.
WAN interface.
authentication/security settings.
Use this screen to block or allow wireless traffic from wireless devices
of certain SSIDs and MAC addresses to the Device.
Setup) settings.
other access points.
results.
properties.
addresses.
Use this screen to configure IP alias and public static IP.
entries for Set Top Box (STB) devices when they request IP
addresses.
Use this screen to configure the role of th e WAN port. It can be either
the Ethernet WAN or a LAN port.
of traffic sent out through individual LAN ports.
VMG8324-B10A / VMG8324-B30A Series User’s Guide
29
Chapter 2 The Web Configurator
Table 3 Navigation Panel Summary (continued)
LINKTABFUNCTION
RoutingStatic RouteUse this screen to view and set up static routes on the Device.
QoSGeneralUse this screen to enable QoS and traffic prioritizing. You can also
NATPort ForwardingUse this screen to make your localservers visible to the outside
DNSDNS EntryUse this screen to view and configure DNS routes.
Interface
Group
USB ServiceFile SharingUse this screen to enable file sharing via the Device.
Power
Management
Security Settings
FirewallGeneralUse this screen to configure the security level of your firewall.
MAC FilterUse this screen to block or allow traffic from devices of certain MAC
DNS Route
Policy
Forwarding
RIP
Queue SetupUse this screen to configure QoS queues.
Class SetupUse this screen to define a classifier.
Policer SetupUse these screens to configure QoS policers.
ApplicationsUse this screen to configure servers behind the Device.
Port TriggeringUse this screen to change your Device’s port triggering settings.
DMZUse this screen to configure a default server which receives packets
ALGUse this screen to enable or disable SIP ALG.
Address Mapping Use this screen to change your Device’s address mapping settings.
SessionsUse this screen to configure the maximum number of NAT sessions
Dynamic DNSUse this screen to allow a static hostname alias for a dynamic IP
Media ServerUse this screen to use the Device as a media server.
Printer ServerUse this screen to enable the print server on the Device and get the
Power
Management
Auto Switch OffThis screen is only available for supervis ors. Use this screen to
ProtocolUse this screen to add Internet services and configure firewall rules.
Access ControlUse this screen to enable specific traffic directions for network
DoSUse this screen to activate protection against De nial of Service ( DoS)
Use this screen to forward DNS queries for certain domain names
through a specific WAN interface to its DNS server(s).
Use this screen to configure policy routing on the Device.
Use this screen to configure Routing Information Protocol to
exchange routing information with other routers.
configure the QoS rules and actions.
world.
from ports that are not specified in the Port Forwarding screen.
each client host is allowed to have through the Device.
address.
Use this screen to map a port to a PVC or bridge group.
model name of the associated printer.
This screen is only available for supervisors. Use this screen to
manually turn on/off specific interface(s) and/or all LEDs
immediately.
configure schedules to have the Device automatically turn on/off
specific interface(s) and/or all LEDs.
services.
attacks.
addresses to the Device.
30
VMG8324-B10A / VMG8324-B30A Series User’s Guide
Loading...
+ 176 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
