ZTE ZXWLW822E User Manual

ZXWLW822E

WirelessAccessPoint

UserManual

Version:V1.0

ZTECORPORATION
NO.55,Hi-techRoadSouth,ShenZhen,P .R.China
Postcode:518057
Tel:[phone]
Fax:[phone]
URL:http://ensupport.zte.com.cn
E-mail:[e-mail]

LEGALINFORMATION

Copyright©2010ZTECORPORATION.

Thecontentsofthisdocumentareprotectedbycopyrightlawsandinternationaltreaties.Anyreproductionor

distributionofthisdocumentoranyportionofthisdocument,inanyformbyanymeans,withoutthepriorwritten

consentofZTECORPORATIONisprohibited.Additionally,thecontentsofthisdocumentareprotectedby

contractualcondentialityobligations.

Allcompany,brandandproductnamesaretradeorservicemarks,orregisteredtradeorservicemarks,ofZTE

CORPORATIONoroftheirrespectiveowners.

Thisdocumentisprovided“asis”,andallexpress,implied,orstatutorywarranties,representationsorconditions

aredisclaimed,includingwithoutlimitationanyimpliedwarrantyofmerchantability,tnessforaparticularpurpose,

titleornon-infringement.ZTECORPORA TIONanditslicensorsshallnotbeliablefordamagesresultingfromthe

useoforrelianceontheinformationcontainedherein.

ZTECORPORATIONoritslicensorsmayhavecurrentorpendingintellectualpropertyrightsorapplications

coveringthesubjectmatterofthisdocument.ExceptasexpresslyprovidedinanywrittenlicensebetweenZTE

CORPORATIONanditslicensee,theuserofthisdocumentshallnotacquireanylicensetothesubjectmatter

herein.

ZTECORPORA TIONreservestherighttoupgradeormaketechnicalchangetothisproductwithoutfurthernotice.

UsersmayvisitZTEtechnicalsupportwebsitehttp://ensupport.zte.com.cntoinquirerelatedinformation.

TheultimaterighttointerpretthisproductresidesinZTECORPORATION.

RevisionHistory

RevisionNo.RevisionDateRevisionReason

R1.02013-08-08Firstedition

SerialNumber:SJ-20130807102306-001

PublishingDate:2013-08-08（R1.0）

Contents

Chapter1SafetyPrecautions....................................................................1-1

Chapter2ProductDescription..................................................................2-1

Chapter3PowerSupply............................................................................3-1

Chapter4AntennaInstallation..................................................................4-1

Chapter5Installation.................................................................................5-1

Chapter6FatAPCommissioningInstruction.........................................6-1

Chapter7FitAPCommissioningInstruction..........................................7-1

AppendixAQ&A.......................................................................................A-1

I

Chapter1

SafetyPrecautions

Installation

lUsethepoweradapterattachedtotheZXWLW822E.Anyotherpoweradaptermay

damagethedeviceormakeitfailtooperateproperly.

lEnsurethatthepoweroutletandthecablecansustaintheload.Anoverloaded

outletanddamagedcablemayresultinanelectricshockorare.Checkthecable
periodically.Ifitisdamaged,replaceitimmediately.

lEnsurethatthedeviceisinstalledinanenvironmentthatiswellventilated,and

ensurethatthedeviceventsarenotblocked.

lEnsurethatthedeviceisawayfromaheatsourceorahightemperaturearea,and

thedeviceisnotexposedtodirectsunlight.

lEnsurethatthedeviceisawayfromahumidarea.
lPlacethedeviceonastablesurface.

Usage

lWhenyoustopusingthisdeviceorneedtocleanit,turnoffthedeviceandremove

thepowercable.Notethatthepoweradaptermaybehot.

lAfteryoupoweroffthedevice,waitatleast15secondsbeforeyoupoweritonagain.
lIfyouwillnotusethedeviceforalongperiod,removethepowercabletoavoid

damagecausedbylighteningorvoltageandpowersurges.

Service

Donotdisassemblethedeviceoropentheenclosure.Donottrytorepairthedevice.The
violationmayvoidyourwarranty.

Inthefollowingcases,contactZTEafter-salepersonnel:

lThepowercableorplugisdamaged.
lLiquidhasfallenintothedevice.
lThedevicewassoakedbyrainorotherliquids.
lThedevicedoesnotoperateproperlywhenyouoperateitasinstructed.
lTheenclosureisdamagedbecauseoffallingorhitting.
lTheindicatorsdonotashnormally.

1-1

SJ-20130807102306-001ZTEProprietaryandConfidential

Chapter2

ProductDescription

Overview

TheZXWLW822Ebroadbandwirelessaccessproductisanindoordual-frequencyt-fat
integratedAP.Itcanoperationin2.4GHzand5GHzfrequencies.The2.4GHzfrequency
isusedforwirelesscoverage.The5GHzfrequencyisusedforwirelesscoverageand
wirelessbridging.

TheZXWLW822Ehastwomodels,W822EandW822Ei.TheW822Eusesanexternal
antennaandtheW822Eiusesaninternalantenna.

TheZXWLW822Ehasthefollowingfeatures:

lSupports12VDCpowersupplyandPoE/PoE+powersupply.
lSupportsMIMO3x3.Eachfrequencybandsupportsupto450Mbpsrates.
lProvidestwo10M/100M/1000Mauto-sensingelectricEthernetportsandsupports

automaticdetectionofnetworkcableconnectionsthroughMDI/MDI-X.

lSupportsdesktop,wall,andceilingmountmodes.
lBasedontheUniedZTECSPPlatform,whichenablestheZXWLW822Eto

easilyswitchbetweentandfatAPmodesandprovideareliableandmanagable
carrier-classWLANnetwork.

lComplieswiththeIEEE802.11a,802.11b,802.11g,and802.11nstandardsanduses

theOFDMtechnology.Withthehightransmissionrate,highreceivingsensitivity,and
longtransmissiondistancefeatures,itissuitablefordeploymentinWLANhotspots
toprovideWLANaccessforusersandtooffersuperbwirelessaccesssolutionsfor
basictelecomoperators,ISPsandindustrialenterprises.

lSupportsmultiplesecurityencryptionmechanismsandrightsmanagementto

protectWLANsecurity.

Figure1showstheexternalviewoftheZXWLW822E.

2-1

SJ-20130807102306-001ZTEProprietaryandConfidential

ZXWLW822EWirelessAccessPointUserManual

Figure1ExternalView

LEDIndicators

TheZXWLW822ELEDindicatorsarelocatedonthetopoftheAP .Foradescriptionof
theLEDindicators,refertoT able1.

Table1LEDIndicators

IndicatorStatusDescription

FlashingslowlyThedeviceispoweredonandnotregisteredtotheAC.

FlashingfastThedeviceisbeingstartedorthesoftwareisbeingupdated. RUN

ONTheAPisregisteredtotheAC.

ONThe2.4GfrequencyWLANfunctionisenabled.

FlashingDataisbeingtransmitted. 2.4G

OFFThe2.4GfrequencyWLANfunctionisdisabledorfaulty.

ONThe5GfrequencyWLANfunctionisenabled.

FlashingDataisbeingtransmitted. 5G

OFFThe5GfrequencyWLANfunctionisdisabledorfaulty.

ONEthernetport1isconnectedproperly.

FlashingDataisbeingtransmittedthroughEthernetport1. ETH1

OFFEthernetport1isnotusedforfailstooperateproperly.

ONEthernetport2isconnectedproperly.

FlashingDataisbeingtransmittedthroughEthernetport2. ETH2

OFFEthernetport2isnotusedforfailstooperateproperly.

1.Flashingslowly:ONfor500msandOFFfor500ms

2.Flashingquickly:ONfor100msandOFFfor100ms

3.Flashing:ONfor900msandOFFfor100ms

2-2

SJ-20130807102306-001ZTEProprietaryandConfidential

InterfaceDescriptions

Figure2showstheexternalinterfacesoftheZXWLW822E.

Figure2ExternalInterfaces

Foradescriptionoftheexternalinterfaces,refertoTable2.

Table2DescriptionoftheExternalInterfaces

InterfaceDescription

lConnectedtothenetworkportofaPCoranothernetworkdevice

ETH1/PoE

throughanRJ-45cable.

lProvides802.3atPoE+48V/0.83Apowersupply.

Chapter2ProductDescription

lConnectedtothenetworkportofaPCoranothernetworkdevice

ETH2

RESET

DC12V

throughanRJ-45cable.

lUsedtocascademultipleAPs.

Pressandholdthisbuttonforfivesecondstorestorethesettingstothe

defaults.Aftertherestoration,thedeviceisrestarted.

Powerport,usedtoconnecttothepoweradapter.Theinputpowermust

beDC+12V/2A.

TechnicalSpecications

Table3showsthetechnicalspecicationsoftheZXWLW822E.

Table3T echnicalSpecications

ItemSpecification

Dimensions(L×W×H)188mm×188mm×45mm

Weight0.75kg

Powersupplymodel802.3atPoE+48V/0.83Apowersupply.

l12V/2ADCpowersupply .

Maximumpowerconsumption20W

Operationtemperature–10℃to55℃

Operationhumidity5%to95%

IPprotectionlevelIP41

2-3

SJ-20130807102306-001ZTEProprietaryandConfidential

Chapter3

PowerSupply

TheZXWLW822Esupportsthefollowingpowersupplymethods.Y oucanuseanyofthe
methodbasedonyourneeds.

lPowerthedevicethroughtheattachedexternalpoweradapter,seeFigure3.

Figure3PoweringtheZXWLW822EthroughthePowerAdapter

lIftheswitchdoesnotsupportPoEpowersupply,theremote48VEthernetpower

supplythroughthestandardPoEmoduleisused,seeFigure4.

3-1

SJ-20130807102306-001ZTEProprietaryandConfidential

ZXWLW822EWirelessAccessPointUserManual

Figure4PoweringtheZXWLW822EthroughtheStandardPoEModule

lPowerthedevicethroughtheswitchthatsupportsthestandardPoEmodule,see

Figure5.

Figure5PoweringtheZXWLW822EthroughaPoESwitch

3-2

SJ-20130807102306-001ZTEProprietaryandConfidential

Chapter4

AntennaInstallation

Toinstalltheantenna,performthefollowingsteps:

1.Puttheantennaintotheprotectivesheath.

Figure6AntennaInstallation(one)

2.Connecttheantennatothe2.5Gor5Gantennainterfaceandtightenitclockwise.

Figure7AntennaInstallation(two)

3.Puttheprotectivesheathnearthedeviceshell.

4-1

SJ-20130807102306-001ZTEProprietaryandConfidential

ZXWLW822EWirelessAccessPointUserManual

Figure8AntennaInstallation(three)

4.Installingtheotherantenna,theantennaisinstalledsuccessfully ,seeFigure9

Figure9AntennaInstallation(four)

4-2

SJ-20130807102306-001ZTEProprietaryandConfidential

Chapter5

Installation

Abstract

TheZXWLW822Ecanbeplacedonadesk,hungonawall,orinstalledtotheceiling.

Pre-requisites

lTheindoortemperatureandhumiditydonotexceedtheallowedoperation

temperatureandhumidity.

lTheAPisfreefrominterferencewithin2-3meters,forexample,cordlessphones

andtransformers.TheAPisfreefrominammableandexplosiveitems.

lTheplacetoinstallthedeviceisdetermined.Iftheplacechanges,youneedto

applytochangetheAPdesign.

lThedistancebetweentheEthernetswitchandtheAPislessthan100meters.At

least100mmareleftfromaroundthedeviceforheatdissipation.

lIftheAPisinstalledwithinaroom,theAPmustbefreefrommetalblockswithin

onemeter.

lIftheAPisinstalledinaweakelectricitywell,itis1.5to2metershighfromtheoor

toensureventilation.Inaddition,thewellmustbefreefromdust.

lIftheAPisinstalledtotheceiling,itmustbenearthemanholetofacilitate

maintenance.Iftheceilingisnotinstalled,donotinstalltheAPabovethelocation
wherethesuspendedceilingwillbeinstalled.Otherwise,theAPwillbeblocked.

DesktopInstallation

Placethedeviceonastabledesk.Ensurethatitisnoteasytobemovedandfallonto
theoor.

WallInstallation

ToinstalltheZXWLW822Eonawall,performthefollowingsteps:

1.Conrmtheinstallationposition.Presstheadaptertothewallandmarktheinstallation
holesonthewall.

2.Drillholesbasedonthemarkedholeswithapercussivedrill.Theapertureis6mm
andthedepthis40mm.Useacleanertoclearthedust.

5-1

SJ-20130807102306-001ZTEProprietaryandConfidential

ZXWLW822EWirelessAccessPointUserManual

Figure10DrillingHoles

3.Inthedrilledholes,inserttheuniversalanchors,andhammertheanchorsintothewall
completelywitharubberhammer,seeFigure11.

Figure1 1InstallingtheUniversalAnchors

4.Securethepositioningboltsintheuniversalanchors.

5.Installtheinstallationadaptoronthewall,seeFigure12.

5-2

SJ-20130807102306-001ZTEProprietaryandConfidential

Figure12InstallingtheInstallationAdaptor

6.Installthedeviceontotheinstallationadaptor.

Chapter5Installation

Caution： ：

：

Thedeviceissecurelyinstalledontotheinstallationadaptorwhenyouhearaclick
sound,whichindicatesthatthepositioningreedisinposition.

Figure13InstallingtheDevice

7.Thedeviceissuccessfullyinstalledonthewall,seeFigure14.

5-3

SJ-20130807102306-001ZTEProprietaryandConfidential

ZXWLW822EWirelessAccessPointUserManual

Figure14DeviceInstalledontheWall

CeilingInstallation

Ifyouneedtoinstallthedevicetotheceiling,youneedtobuytherequiredinstallation
components.Thecomponentsincludeamountingframeandadeviceadapter,seeFigure

15andFigure16.

Figure15MountingFrame

Figure16DeviceAdapter

Basedontheinstallationenvironment,thedevicecaneitherbeinstalledtothecommon
ceilingorsuspendedceiling.

Installthedevicetothecommonceiling

5-4

SJ-20130807102306-001ZTEProprietaryandConfidential

Chapter5Installation

Theinstallationprocedureisthesameasthatofwallinstallation.

Installthedevicetothesuspendedceiling.

Performthefollowingstepstoinstallthedevicetoaceiling.

1.Conrmthepositiontoinstallthedevice.Loosenthemountingframeandinstallthe
frametothebeamofthesuspendedceiling,seeFigure17.

Figure17LooseningtheMountingFrame

2.Lockthemountingframetothebeamandsecurethescrews,seeFigure18.

Figure18SecuringtheMountingFrametotheBeam

3.Installtheadaptertothemountingframe,seeFigure19.

Figure19InstallingtheAdaptortotheMountingFrame

5-5

SJ-20130807102306-001ZTEProprietaryandConfidential

ZXWLW822EWirelessAccessPointUserManual

4.Securethescrewsoftheadapter,seeFigure20.

Figure20SecuringtheScrewsoftheAdapter

5.Installthedevicetotheadapter.

Caution： ：

：

Thedeviceissecurelyinstalledontotheinstallationadaptorwhenyouhearaclick
sound,whichindicatesthatthepositioningreedisinposition.

5-6

SJ-20130807102306-001ZTEProprietaryandConfidential

Figure21InstallingtheDevicetotheAdapter

Chapter5Installation

6.Thedeviceissuccessfullyinstalledonthesuspendedceiling,seeFigure22.

Figure22DeviceInstalledontheSuspendedCeiling

5-7

SJ-20130807102306-001ZTEProprietaryandConfidential

Chapter6

FatAPCommissioning
Instruction

WhentheZXWLW822EisinfatAPmode,itneedstobeconnectedandcongured.

APConnection

PerformthefollowingstepstoconnecttheZXWLW822E:

1.PoweronthedevicebyreferringtothePowerSupplysection.

2.ConnectthedevicetoadebuggingPCthroughanetworkcable,andstartthe
debuggingPC.

3.ConguretheIPaddressofthedebuggingPC.EnsurethattheZXWLW822Eandthe
PCareinthesamenetworksegment.

PerformthefollowingstepstocongurethePC:

a.SelectStart>ControlPanel>NetworkConnection.TheNetworkConnection

windowisdisplayed.

b.Right-clickLocalAreaConnectionandselectProperties.TheLocal

ConnectionPropertiesdialogboxisdisplayed.

c.Double-clickInternetProtocol(TCP/IP).TheInternetProtocol(TCP/IP)

Propertiesdialogboxisdisplayed,seeFigure23.

6-1

SJ-20130807102306-001ZTEProprietaryandConfidential

ZXWLW822EWirelessAccessPointUserManual

Figure23InternetProtocol(TCP/IP)PropertiesDialogBox

d.SettheIPaddresstothe192.168.0.Xnetworksegment.Thesubnetmaskis

255.255.255.0.

：

Note： ：

Bydefault,theIPaddressoftheZXWLW822Eis192.168.0.228.Thesubnet
maskis255.255.255.0.

APConguration

ToconguretheAP ,performthefollowingsteps:

1.LogintotheAP .

a.OpentheIEbrowseronthedebuggingPC,andenter192.168.0.228intheaddress

barandpressEnter.ThePleaselogintocontinuedialogboxisdisplayed,see

Figure24.

6-2

SJ-20130807102306-001ZTEProprietaryandConfidential

Chapter6FatAPCommissioningInstruction

Figure24PleaselogintocontinueDialogBox

b.Enterthedefaultusernameandpassword(admin/admin),andclickLogin.

2.SettheAPmodeoftheZXWLW822EtoFat.

a.SelectAdministration>APManagement>APMode.TheAPModedialogbox

isdisplayed

b.SetAPModetoFat,seeFigure25.

Figure25APModeDialogBox

：

Note： ：

Bydefault,theZXWLW822EisintAPmode.Ifitisinfatmode,youdonotneed
tomodifyit.

c.ClickSubmit.Thedeviceisrestartedautomatically.TheAPmodeismodied

successfully.

3.SettheWANport.

a.SelectNetwork>WAN>WANConnection.TheWANConnectionpageis

displayed,seeFigure26.

6-3

SJ-20130807102306-001ZTEProprietaryandConfidential

ZXWLW822EWirelessAccessPointUserManual

Figure26WANConnectionPage

：

Note： ：

ThefatAPmodeincludesroutemodeandbridgemode.Selectthecorrectmode
basedonthenetworkingsolution.

b.SetWANTypeasrequired.

lIfWANTypeissettoDHCP,theconnectedSTAdeviceobtainstheIPaddress

dynamically.

lIfWANTypeissettostatic,entertheIPaddress,maskdefaultgateway,and

theDNSaddress.

lIfWANT ypeissettoPPPOE,enterthecorrespondingusernameand

password.

4.SettheLANport.

a.SelectNetwork>LAN>AddressManagement.TheAddressManagement

pageisdisplayed,seeFigure27.

6-4

SJ-20130807102306-001ZTEProprietaryandConfidential

Figure27AddressManagementPage

Chapter6FatAPCommissioningInstruction

b.Settheparameters.Foradescriptionoftheparameters,refertoTable4.

Table4AddressManagementParameters

ParameterDescription

LANIPAddressTheIPaddressoftheAPontheLANside.

SubnetMaskThesubnetmaskoftheAPontheLANside.

DHCPServiceSetthisparametertoDHCPServer.

DHCPStartIPAddressThestartIPaddressallocatedtoaterminal.

DHCPEndIPAddressTheendIPaddressallocatedtoaterminal.

DNS1DNSaddress.

DefaultGatewayAPaddress.

5.SetWLAN.

a.SelectNetwork>WLAN>Basic.TheBasicpageisdisplayed.

b.Settherequiredparameters.Foradescriptionoftheparameters,refertoT able5.

6-5

SJ-20130807102306-001ZTEProprietaryandConfidential

ZXWLW822EWirelessAccessPointUserManual

Table5BasicParameters

ParameterDescription

6.SetSSID.

NetworkCard

Mode

Channel(2.4G)

Channel(5G)

OnlySelect1/6/11

Selectnetworkcard1forthe2.4Gmode,andnetworkcard2for

the5Gmode.

lBoththe2.4Gand5GmodessupportmultipleIEEE802.1 1

operationmodes.

lForthe2.4Gmode,itisrecommendedtosettheparameterto

Mixed(802.11b+802.11g+802.11n).

lForthe5Gmode,itisrecommendedtosettheparameterto

Mixed(802.11a+802.11n).

Selectachannelbasedonthemanagementenvironmentandthe

anti-interferencerequirements.Channels1to13areavailable.

Default:auto.

Channels149,153,157,161,and165areavailable.Whenmultiple

APsareconfigured,theAPsmustbeconfiguredwithdifferent

channelstoavoidinterference.

Ifthischeckboxisselected,onlychannels1,6,and11areavailable.

Thesechannelshaveastrongorthogonalfrequency-division

anti-interferencefeature.

a.SelectNetwork>WLAN>SSIDsetting.TheSSIDSettingspageisdisplayed,

seeFigure28.

6-6

SJ-20130807102306-001ZTEProprietaryandConfidential

Figure28SSIDSettingsPage

Chapter6FatAPCommissioningInstruction

b.ModifytheSSIDname,forexample,ZTE.Thisnameisdisplayedastheuserand

usedinconnection.Fortheotherparameters,usethedefaultsetting.

7.Setencryption.

a.SelectNetwork>WLAN>Security.TheSecuritypageisdisplayed.

b.TheZXWLW822Esupportsmultipleauthenticationmethods.T ousethe

WPA-PSKmethod,setAuthenticationTypetoWPA-PSK,seeFigure29.

Figure29WPA-PSKAuthenticationType

c.EnterthepasswordintheWP APassphrasetextbox.Therangeisfrom8to63

characters.

d.ClickSubmit.

8.(Optional)Settheadditionalinformation.

6-7

SJ-20130807102306-001ZTEProprietaryandConfidential

ZXWLW822EWirelessAccessPointUserManual

lTosetthesystemtime,selectApplication>TimeManagement.
lTosettherewall,selectSecurity>Firewall.
lTorestartthedeviceorrestoretothedefaultsettings,selectManagement>

DeviceManagement>SystemManagement.

6-8

SJ-20130807102306-001ZTEProprietaryandConfidential

Chapter7

FitAPCommissioning
Instruction

Bydefault,theZXWLW822EissettothetAPmode.

IntAPmode,onlyadataconnectionisrequiredbetweentheAPandtheAC.Other
congurationsaremanagedthroughtheAC.

ThetAPdoesnotneedtobecongured.Ifitcannotbeconnected,verifythatno
congurationoftheAPismodied.

1.LogintotheAP .ForhowtologintotheAP ,refertotheFatAPCommissioning
Instructionsection.

2.SelectAdministration>APManagement>APMode.ChecktheAP .Bydefault,it
issettoFit.

3.SelectNetwork>WAN>WANConnection.ChecktheACDiscoveryMode.By
default,itissettoDHCP.

7-1

SJ-20130807102306-001ZTEProprietaryandConfidential

AppendixA

Q&A

Thefollowingarethefrequentlyaskedquestions.Y oucantrytohandleproblemsby
referringtothefollowingrecommendations.Ifyoucannothandleaproblem,contactthe
operator.

WhytheSTAcannotbeconnectedtotheAP?

ToconnecttoanAP ,thefollowingstepsarerequired:searchingforanavailableAP ,
authenticatingtheSTA,andconnectingtheSTAtotheAP .IftheSTAcannotbeconnected
totheAP ,thecausesmaybeattributedtothefollowing:

lTheauthenticationandencryptionmodesoftheSTAandtheAParedifferent.
lThereisinterferencefromotherwirelessdevices.

Checkwhethertheconnectionisinterferedbyanywirelessdevice.Turnoffthedevice
andcheckwhethertheSTAcanbeconnectedtotheAP .Ifyes,shieldormovethe
interferencesource.

lTheSTAandtheAParenotcompatible.

TheSTAmaynotcomplywiththe802.1 1standard,soitcannotbeconnectedtothe
AP .

WhythebandwidthisnotashighasexpectedafteraWLANisestablished?

Inmostcases,thisiscausedbyinterference.Inaddition,agingofthedevicemayreduce
thebandwidthbecausethetransmissionpowerisreduced.Youcantrythefollowing
methodstohandletheproblem:

lChangethewirelesschannel.

Selectanotherwirelesschannel.Checkwhethertherateisgreatlyimproved.

lClearthewirelessinterference.

Removethedevicethataffectsthebandwidth.Turnoffthedeviceandcheckwhether
theproblemissolved.Ifyes,shieldthedeviceorchangeitsposition.

lCheckthesignalstrength.

Checkthesignalstrength.Ifthesignalisweak,theantennamaybeloosed,orthe
transmissionpowerisreducedbecauseoftheagingofthedevice.

lCheckthenetworkcard.

A-1

SJ-20130807102306-001ZTEProprietaryandConfidential

ZXWLW822EWirelessAccessPointUserManual

Thepowerofthenetworkcardmaynotenough.Trytomovethedeviceclosertothe
AP .

Whydolinksfailtooperatestably(increaseddelayandpacketloss)aftertheWLAN
operatesproperlyforaperiod?

TheWLANisinterfered.Trythefollowingmethodstohandletheproblem:

lCheckwhetherthedevicesareconnectedproperlybycheckingthecablesand

theantenna.

lPoweroffthedeviceandthenrestartit.
lRestorethedevicetothedefaultsettingandcongureitagain.
lCheckwhetherthedevicesonboththewireandwirelesssidesareattackedby

viruses.

A-2

SJ-20130807102306-001ZTEProprietaryandConfidential

FCC Statement:

Federal Communication Commission Interference Statement

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of the following measures:

● Reorient or relocate the receiving antenna.

● Increase the separation between the equipment and receiver.

● Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

● Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this equipment.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.

For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of
other channels is not possible.

This device and it's antennas(s) must not be co-located or operating in conjunction with any other antenna or
transmitter except in accordance with FCC multi-transmitter product procedures.

This device is going to be operated in 5.15~5.25GHz frequency range, it is restricted in indoor
environment only.

IMPORTANT NOTE:
FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator &
your body.
