Page 1
1
USER
MANUAL
Z079584509059
ZTEUSA.COM
Z719DL
IMAGINE
THE
P
OSSIBILITIES
Page 2
2 1
Contents
Getting Started ............................... 5
Installing the nano-SIM Card (Included)
and a microSDXC Card (Not Included) ........5
Charging the Battery .........................................5
Extending the Battery Life...............................6
Powering Your Phone On/O .........................7
Setting Up Your Phone for the First Time ...7
Locking/Unlocking the Screen and Keys ...7
Using the Touch Screen ....................................8
Getting to Know Your Phone..........................9
Key Functions ................................................... 11
Getting to Know the Home Screen ........... 11
Personalizing ................................14
Changing the System Language ............... 14
Setting the Date and Time ...........................14
Changing the Ringtone and Notication
Sound .................................................................. 14
Turning System Sounds On/O .................15
Adjusting Volumes ..........................................15
Switching to Silent or Vibration Mode .....15
Using Do Not Disturb Mode ........................ 16
Applying New Wallpapers ............................ 17
Setting the Theme........................................... 17
Setting the Home Screen
Transition Eect ...............................................18
Changing the Screen Brightness ............... 18
Protecting Your Phone With
Screen Locks ...................................................... 18
Protecting Your Phone With Encryption . 19
Protecting Your Phone With Screen
Pinning ................................................................ 20
Knowing the Basics.......................22
Monitoring the Phone Status ......................22
Managing Notications .................................23
Managing Shortcuts and Widgets ............. 26
Organizing With Folders ............................... 27
Rearranging the Primary Shortcuts .......... 27
Entering Text .....................................................27
Editing Text ........................................................31
Opening and Switching Apps ..................... 31
Using Two Apps in Split-Screen Mode ..... 32
Uninstalling or Disabling an Application .. 33
About This Manual
Thank you for choosing this ZTE mobile device. In order to keep your device in its best condition, please read
this manual and keep it for future reference.
Copyright
Copyright © 2017 ZTE CORPORATION
All rights reserved.
No part of this publication may be quoted, reproduced, translated or used in any form or by any means,
electronic or mechanical, including photocopying and microlm, without the prior written permission of ZTE
Corporation.
Notice
ZTE Corporation reserves the right to make modications on print errors or update specications in this
manual without prior notice. This manual has been designed with the utmost care to ensure the accuracy of
its content. However, all statements, information and recommendations contained therein do not constitute
a warranty of any kind, either expressed or implied. Please refer to chapter For Your Safety to be sure to use
your phone properly and safely.
We oer self-service for our smart terminal device users. Please visit the ZTE ocial website (at www.zteusa.
com) for more information on self-service and supported product models. Information on the website takes
precedence.
Disclaimer
ZTE Corporation expressly disclaims any liability for faults and damages caused by unauthorized
modications of the software.
Images and screenshots used in this manual may dier from the actual product. Content in this manual may
dier from the actual product or software.
Trademarks
ZTE, ZMAX, and the ZTE logos are trademarks of ZTE Corporation.
Google and Android are trademarks of Google, Inc.
LTE is a trademark of ETSI.
The Bluetooth® trademark and logos are owned by the Bluetooth SIG, Inc. and any use of such trademarks by
ZTE Corporation is under license.
microSDXC Logo is a trademark of SD-3C, LLC.
Qualcomm® Snapdragon™ processors are products of Qualcomm Technologies, Inc. Qualcomm and
Snapdragon are trademarks of Qualcomm Incorporated, registered in the United States and other countries.
Used with permission.
Other trademarks and trade names are the property of their respective owners.
Version No.: R1.0
Edition Time: May 2017
Page 3
2 3
Connecting to Networks and
Devices ..........................................34
Connecting to Mobile Networks................ 34
Connecting to Wi-Fi® ...................................... 34
Connecting to Bluetooth Devices ............. 37
Connecting to Your Computer via USB ... 39
Using the microSDXC Card as Portable or
Phone Storage .................................................. 40
Sharing Your Mobile Data Connection .... 43
Connecting to Virtual Private Networks ..45
Phone Calls ....................................47
Placing and Ending Calls .............................. 47
Answering or Rejecting Calls ...................... 48
Working With the Call History .....................48
Calling Your Contacts .....................................50
Checking Voicemail ........................................ 50
Using Options During a Call ........................ 50
Managing Multi-party Calls ......................... 51
Adjusting Your Call Settings ........................ 52
Contacts .........................................58
Checking Contact Details ............................. 58
Adding a New Contact .................................. 58
Setting Up Your Own Prole ........................ 58
Importing, Exporting, and Sharing
Contacts .............................................................. 59
Working With Favorite Contacts ................ 60
Working With Groups .....................................61
Searching for a Contact ................................. 62
Editing Contacts .............................................. 62
Web Accounts ................................ 65
Adding or Removing Accounts ..................65
Conguring Account Sync ...........................66
Email ..............................................67
Setting Up the First Email Account ...........67
Checking Your Emails ..................................... 67
Responding to an Email ................................ 67
Writing and Sending an Email .................... 68
Adding a Signature to Your Emails ............ 69
Adding and Editing Email Accounts .........69
Changing General Email Settings .............. 70
Messaging .....................................71
Opening the Messaging Screen ................. 71
Sending a Message ......................................... 71
Replying to a Message ................................... 72
Forwarding a Message .................................. 72
Deleting Messages or Threads ....................73
Changing Message Settings ........................ 73
Calendar ........................................74
Viewing Your Calendars and Events ......... 74
Creating an Event ............................................75
Editing, Deleting, or Sharing an Event .....75
Changing Calendar Settings ....................... 76
Searching an Event ......................................... 76
Browser ..........................................77
Opening the Browser ..................................... 77
Setting the Home Page ................................. 77
Using Multiple Browser Tabs ....................... 77
Downloading Files .......................................... 78
Changing Browser Settings ......................... 78
Camera ..........................................79
Capturing a Photo ........................................... 79
Using Manual Camera Mode ....................... 81
Using Other Camera Modes ........................ 82
Recording a Video ........................................... 82
Customizing Camera and Video Settings ....83
Gallery ........................................... 85
Opening Gallery ............................................... 85
Working With Albums .................................... 85
Working With Pictures ................................... 86
Retouching Your Pictures .............................87
Making a GIF or a Collage ............................. 88
Playing Videos .................................................. 89
Music ..............................................90
Viewing Your Music Library.......................... 90
Setting a Song as the Default Ringtone .. 90
Playing Music .................................................... 91
Managing Playlists .......................................... 92
Video Player ..................................93
Opening the Video Library ........................... 93
Playing and Controlling Videos ..................93
Managing Video Files ..................................... 94
Sound Recorder ............................96
Recording a Voice Memo ..............................96
Playing a Voice Memo ....................................96
More Apps .....................................97
Calculator ........................................................... 97
Contents Contents
Page 4
4 5
Getting Started
Installing the nano-SIM Card (Included) and a microSDXC Card
(Not Included)
Power o your phone before installing or removing the nano-SIM
card or the microSDXC card.
NOTE: Your phone will come with the nano-SIM card already
installed.
WARNING! To avoid damage to the phone, do not use any other
kind of SIM cards, or any non-standard nano-SIM card cut from a
SIM card. You can get a standard nano-SIM card from your service
provider.
1. Insert the tip of the tray eject tool into the hole on the card
tray and pull the tray out.
2. Place the nano-SIM card and the microSDXC card on the
tray making sure they are properly oriented, as shown.
3. Carefully slide the tray back into place.
Charging the Battery
Your phone’s battery should have enough power for the phone to turn on, nd a signal,
and make a few calls. You should fully charge the battery as soon as possible.
Do not change the built-in rechargeable battery in your phone by yourself. The battery
can only be changed by ZTE or a ZTE authorized service provider.
WARNINGS!
• Use only ZTE-approved chargers and USB Type-C™ cables. The use of unapproved
accessories could damage your phone or cause the battery to explode.
• Do not remove the back cover. The battery is not removable. Removal may cause re
or explosion.
Clock..................................................................... 97
Downloads .........................................................98
File Manager ...................................................... 98
Wi-Fi Utility ........................................................ 99
Google Apps ...................................................100
Settings .......................................101
Wireless & Networks .....................................101
Device ................................................................103
Personal ............................................................107
System ...............................................................111
Upgrading the Phone Software..112
Troubleshooting .........................113
For Your Safety ............................ 117
General Safety ................................................117
Radio Frequency (RF) Energy ....................118
FCC Regulations .............................................119
Hearing Aid Compatibility (HAC)
regulations for Mobile Phones .................120
CTIA Requirements .......................................121
Distraction........................................................122
Product Handling ..........................................122
Electrical Safety ..............................................125
Radio Frequency Interference ..................126
Explosive Environments ..............................127
Specications ..............................128
Contents
Page 5
6 7
Powering Your Phone On/O
• Press and hold the Power key to turn on your phone.
• To turn it o, press and hold the Power key to open the options menu. Touch Power
o > OK.
NOTE: If the phone freezes or takes too long to respond, press and hold the Power key
for about 10 seconds to restart the phone.
Setting Up Your Phone for the First Time
When you rst power on your phone after you purchase it or reset it to factory settings
(see Settings – Personal – Backup & Reset)), you will need to set it up before using it.
Select the language and then follow the prompts to set up your phone.
Locking/Unlocking the Screen and Keys
Your phone allows you to quickly lock the screen and keys (put the phone to Sleep
mode) when not in use and also to turn the screen back on and unlock it when you need
it.
Locking the Screen and Keys
To quickly turn the screen o and lock the keys, press the Power key.
NOTE: To save battery power, the phone automatically turns o the screen after a certain
period of time when you leave it idle. You will still be able to receive messages and calls
while the phone screen is o.
Unlocking the Screen and Keys
1. Press the Power key to turn the screen on.
Touch and hold any blank area of the screen to unlock the phone, touch and hold
at the bottom right of the screen to open the Camera app, or touch and hold at the
bottom left to use Google voice commands. You can also double-tap a notication to
open the related app.
1. Connect the adapter to the charging jack.
2. Connect the charger to a standard AC power outlet. If the phone
is on, you’ll see a charging icon, such as or , appear in the
Status Bar.
3. Disconnect the charger when the battery is fully charged.
NOTE: If the battery is extremely low, you may be unable to power on
the phone even when it is being charged. In this case, try again after
charging the phone for at least 20 minutes. Contact customer service
if you still cannot power on the phone after prolonged charging.
This device contains a non-removable battery. Attempting to remove will void
your warranty and could cause serious injury. Do not damage, alter, or try to
remove the battery.
Extending the Battery Life
Active applications, screen brightness levels, Bluetooth and Wi-Fi usage, and GPS
functionality can drain your battery. You can follow the helpful tips below to conserve
your battery power:
• Reduce the screen backlight time.
• Lower the screen brightness.
• Turn Wi-Fi, Bluetooth and auto-sync o when not in use.
• Disable the GPS function when not in use. Most applications using this function will
periodically query the GPS satellites for your current location; each query drains your
battery.
• Use the Battery saver feature.
Getting Started Getting Started
Page 6
8 9
NOTE: If you have set an unlock pattern, a PIN, or a password for your phone (see
Personalizing – Protecting Your Phone With Screen Locks), you’ll need to touch and hold
on the screen and draw the pattern or enter the PIN/password to unlock your screen.
Using the Touch Screen
Your phone’s touch screen lets you control actions through a variety of touch gestures.
• Touch – When you want to type using the on-screen keyboard, select on-screen items
(such as application and settings icons), or press on-screen buttons, simply touch
them with your nger.
• Touch and Hold – To open the available options for an item (for example, a message
or link in a web page), touch and hold the item.
• Swipe or Slide – To swipe or slide means to quickly drag your nger vertically or
horizontally across the screen.
• Drag – To drag, press and hold your nger with some pressure before you start to
move your nger. While dragging, do not release your nger until you have reached
the target position.
• Pinch – In some apps (such as Maps, Browser, and Gallery), you can zoom in and out
by placing two ngers on the screen at once and pinching them together (to zoom
out) or spreading them apart (to zoom in).
• Rotate the Screen – For most screens, you can automatically change the screen
orientation from portrait to landscape by turning the phone sideways.
NOTES:
• The Auto-rotate feature needs to be turned on for the screen orientation to
automatically change. Touch the Home key > > Settings > Display > When
device is rotated > Rotate the contents of the screen.
• You can also access the screen rotation control by sliding down the Status Bar twice
and touch Auto-rotate or Portrait.
Getting to Know Your Phone
Auxiliary microphone
Front camera
Proximity & light sensor
Volume key
Power key
Home key
Recent apps key*
Main microphone
Charging/ USB
Type-C jack
Back key*
Touch screen
nano-SIM/
microSDXC card tray
Earpiece
3.5 mm headset jack
Getting Started Getting Started
Page 7
10 11
* You can switch to positions of the Back key and Recent apps key. Touch the Home key
> > Settings > Navigation key and select one option.
Back camera
Speaker
Flash
Key Functions
Key Function
Power key
• Press and hold to turn Airplane mode on or o,
restart, or power o.
• Press to switch your phone to Sleep mode or wake up
your phone.
Home key
• Touch to return to the home screen from any
application or screen.
• Touch and hold to use Google Now.
Recent apps key Touch to see recently used applications.
Back key Touch to go to the previous screen.
Volume key
Press or hold either end of the key to turn the volume up
or down.
Getting to Know the Home Screen
The home screen is the starting point for your phone’s applications, functions, and
menus. You can customize your home screen by adding shortcuts, folders, widgets, and
more.
Getting Started Getting Started
Page 8
12 13
Status & notications
Wallpaper
Folder
Shortcut
Primary shortcuts
Widget
Extended Home Screen Panels
Your home screen is extendable, providing more space for shortcuts, widgets, and more.
Simply swipe left or right on the home screen to see the extended panels. You can add or
remove home screen panels, or adjust their order.
To add a new home screen panel:
1. Touch the Home key > , or touch and hold an empty area of the home screen and
select Widgets.
2. Touch and hold an application icon or a widget and drag it to the right edge of the
screen to create a new home screen panel and put the icon or widget on it.
To delete a home screen panel:
1. Touch and hold an empty area of the home screen and slide left or right to view the
home screen thumbnails.
2. Touch Home.
3. Touch on the top right corner of a thumbnail.
4. Touch OK. The items on the panel will also be removed.
NOTE: When there are only three home screen panels, you cannot delete any of them.
To adjust the order of a home screen panel:
1. Touch and hold an empty area of the home screen and slide left or right to view the
home screen thumbnails.
2. Touch Home.
3. Touch and hold a thumbnail and drag it left or right to the place you need.
NOTE: Touch at the bottom of a home screen thumbnail to set it as the main home
screen.
Getting Started Getting Started
Page 9
14 15
Personalizing
Changing the System Language
1. Touch the Home key > > Settings > Languages & input > Languages.
2. To add a system language, touch Add a language and then the language you need.
3. Touch and hold a language and move it to the top to switch to that language.
Setting the Date and Time
1. Touch the Home key > > Settings > Date & time.
2. Set the date, time, time zone, and time format.
u To adjust the date and time automatically, touch to turn on Automatic date &
time.
u To adjust the date and time manually, touch to turn o Automatic date & time
and touch Set date / Set time to change the date and time.
u To adjust the time zone automatically, touch to turn on Automatic time zone.
u To adjust the time zone manually, touch to turn o Automatic time zone and
touch Select time zone to set the correct time zone.
u To adjust the time format, touch to turn on/o Use 24-hour format.
Changing the Ringtone and Notication Sound
You can customize the default ringtone for incoming calls and the default notication
sound.
1. Touch the Home key > > Settings > Sound.
2. Touch Phone ringtone or Default notication ringtone.
3. Scroll through the list and select the ringtone you’d like to use.
4. Touch OK.
NOTES:
• Many applications have their own notication sound settings.
• See Contacts – Editing Contacts – Setting a Ringtone for a Contact for how to assign a
special ringtone to an individual contact.
• When selecting ringtones or sounds, touch the Ringtone, Music, or Recording tab
to select an audio le saved on the phone or the memory card.
Turning System Sounds On/O
1. Touch the Home key > > Settings > Sound > Other sounds.
2. Touch the switch beside each option to turn it on or o.
Adjusting Volumes
1. Touch the Home key > > Settings > Sound.
2. Drag the sliders below Media volume, Alarm volume, Ring volume, and
Notication volume to adjust the volume for each type of audio.
NOTE: You can adjust the volume levels any time by pressing the Volume key. Then
touch and drag a volume slider.
Switching to Silent or Vibration Mode
You can set the phone to silent or vibration mode by using one of the following
methods.
• Press the Volume key when no media application is active to show the volume
management window. Drag the slider to the left or keep pressing the Volume down
key to switch the phone to vibration mode. Press the key again in vibration mode to
switch the phone to silent mode.
• From the home screen, touch > Settings > Sound > Notication mode and
select Vibrate or Mute to switch to vibration or silent mode.
Personalizing
Page 10
16 17
• Swipe down from the top of the screen to open the Notication Panel and drag the
panel downwards. Touch Sound or Vibrate to switch the phone to vibration or silent
mode. See Knowing the Basics – Managing Notications – Using Quick Settings.
NOTES:
• Silent and vibration modes will not silence your alarms.
• To restore normal sound settings, press and hold the Volume up key.
Using Do Not Disturb Mode
You can limit interruptions with Do not disturb mode. This mode silences your phone so
that it doesn’t make sounds or vibrate when you don’t want it to.
1. From the home screen, touch > Settings > Sound > Do not disturb.
2. Touch Do not disturb and select Always or Scheduled.
u Touch Always to turn on Do not disturb mode immediately. It will remain on until
you turn it o.
u Touch Scheduled to select time periods for Do not disturb mode to be turned on
automatically.
3. Set the detailed settings.
u If you have selected Scheduled, touch Days, Start time, and End time to specify
the time periods during which Do not disturb mode is on.
u Touch Disturb rules to choose whether you’d like to allow certain notications or not.
– Priority only: Only notications you have marked as priority are allowed.
– Alarms only: Only alarms are allowed.
– Total silence: No notications are allowed.
u If you have selected Priority only, you can customize the types of allowed
sounds or vibrations under Priority interruptions. Touch the switches next to the
items you want to allow. Touch Messages or Calls to set preferences for which
messages and calls will be allowed.
NOTES:
• To turn o Do not disturb mode quickly, press the Volume key and touch END NOW.
• Do not disturb mode will not silence your alarms unless you select Total silence.
• To set exceptions based on apps, from the home screen, touch > Settings >
Notications. Select an app and touch to switch on Override Do Not Disturb.
Applying New Wallpapers
You can set the wallpaper for the home screen and lock screen.
1. Touch and hold an empty place on the home screen.
2. Touch Wallpapers.
3. Touch Lock screen or Home screen to select where the new wallpaper will be
applied.
4. Swipe left or right on the wallpaper panel to select a wallpaper, or touch GALLERY
or LIVE WALLPAPER to choose the image or animation you want to use as the
wallpaper.
5. For Gallery images, move, pinch, or spread to choose the area you want to use. Then
touch .
NOTE: In addition, you can touch the Home key > > Settings > Display > Wallpaper
to pick an image from Gallery, Photos, or Wallpapers, or an animation from Live
Wallpapers.
Setting the Theme
1. Touch and hold an empty place on the home screen.
2. Touch Themes.
3. Touch a theme to select it.
Personalizing Personalizing
Page 11
18 19
Setting the Home Screen Transition Eect
1. Touch and hold an empty place on the home screen.
2. Touch Home.
3. Pick an eect and the phone will demonstrate how it works. When you have found
one you like, touch the Home key to exit.
Changing the Screen Brightness
1. Touch the Home key > > Settings > Display > Brightness level.
2. Drag the slider to manually adjust the screen brightness.
NOTE: With the proximity and light sensor, your phone can automatically adjust the
screen brightness for available light. Touch Adaptive brightness in the Display settings
screen to turn the feature on or o.
Protecting Your Phone With Screen Locks
You can protect your phone by creating a screen lock. When it is enabled, you can touch
and hold a blank area on the lock screen, and then draw a pattern or enter a numeric PIN
or password to unlock the phone’s screen and keys.
1. Touch the Home key > > Settings > Security > Screen lock.
2. Touch None, Long press, Pattern, PIN, or Password.
u Touch None to disable screen lock protection.
u Touch Long press to enable screen lock and allow unlocking with a “touch and
hold” gesture. You can unlock the screen by touching and holding a blank area on
the lock screen.
u Touch Pattern to create a pattern that you must draw to unlock the screen.
u Touch PIN or Password to set a numeric PIN or a password that you must enter to
unlock your screen.
3. For Pattern, PIN, or Password, select how you want notications and their contents to
show when the phone is locked, and then touch DONE.
NOTE: Remember the pattern, PIN, or password you set. Otherwise, you will have to
upgrade the phone software to use the phone (see Upgrading the Phone Software).
Protecting Your Phone With Encryption
You can encrypt all the data on your phone: your accounts, application data, music and
other media, downloaded information, and so on. If you do, you must draw an unlock
pattern, or enter a numeric PIN or a password each time you power on your phone.
WARNING! Encryption is irreversible. The only way to revert to an unencrypted phone is
to perform a factory data reset, which erases all your data.
Encryption provides additional protection in case your phone is stolen, and may be
required or recommended in some organizations. Consult your system administrator
before turning it on. In many cases the pattern, PIN or password you set for encryption is
controlled by the system administrator.
Before turning on encryption, prepare as follows:
• Set a screen lock pattern, PIN or password.
• Charge the battery.
• Keep the phone connected to the charger.
• Schedule an hour or more for the encryption process: you must not interrupt it or you
will lose some or all of your data.
When you’re ready to turn on encryption:
1. Touch the Home key > > Settings > Security > Encrypt phone.
2. Read the information about encryption carefully.
The ENCRYPT PHONE button is dimmed if your battery is not charged or your
phone’s not plugged in.
If you change your mind about encrypting your phone, touch the Back key.
Personalizing Personalizing
Page 12
20 21
WARNING! If you interrupt the encryption process, you will lose data.
3. Touch ENCRYPT PHONE.
4. Draw your screen lock pattern or enter your PIN or password,
5. Touch ENCRYPT PHONE again.
The encryption process starts. Encryption can take an hour or more, during which time
your phone may restart several times.
When encryption is completed, you’re prompted to draw the unlock pattern, or enter
your PIN or password.
Subsequently you must draw your unlock pattern, or enter your PIN or password each
time you power on your phone in order to decrypt it.
Protecting Your Phone With Screen Pinning
You can use the screen pinning feature to keep an app in view, so others cannot switch
to other apps or access your personal information.
Turning On Screen Pinning
1. Touch the Home key > > Settings > Security > Screen pinning.
2. Touch the On/O switch.
3. If you have set a screen lock, you can touch Ask for unlock pattern/PIN/password
before unpinning. You will need to draw the pattern or enter the PIN/password to
unpin the screen.
Pinning a Screen
1. Ensure that screen pinning is turned on.
2. Open the app you want to keep in view.
3. Touch the Recent apps key.
4. If there are many app tabs, swipe up to nd on the front-most tab.
5. Touch .
Unpinning the Screen
1. To unpin the screen and return to normal use, touch and hold the Back key.
2. If you have turned on Ask for unlock pattern/PIN/password before unpinning,
touch and hold on the lock screen and draw the pattern or enter the PIN/password.
Personalizing Personalizing
Page 13
22 23
Knowing the Basics
Monitoring the Phone Status
The Status Bar at the top of the home screen provides phone and service status icons on
the right side. Below are some of the icons you may see.
Managing Notications
The Status Bar at the top of the home screen provides notication icons on the left.
Below are some of the icons you may see.
Knowing the Basics
Indicator What it means
/
2G connected
3G connected
LTE connected
Do not disturb mode on
(Alarms only or Priority only)
Do not disturb mode on
(Total silence)
Vibration only mode on
Silent mode/no interruptions
Battery low (Red when 15%
or lower)
Battery low (5% or lower)
Battery full
/
Battery charging
Indicator What it means
Wired headset connected
No signal
Signal strength
Airplane mode
Bluetooth on
Connected to a
Wi-Fi network
Wi-Fi in use
Speaker on
Phone microphone o
GPS on
Portable Wi-Fi hotspot on
Alarm set
Indicator What it means
New SMS/MMS
/
New message(s) from the
Gmail™ app
/
New message(s) from the
Email app
Missed call
/
Call in progress / Call on
hold
Opening/Closing the Notication Panel
Notications report the arrival of new messages, calendar events, and alarms, as well as
ongoing events. You can open the Notication Panel to view the details of notications.
• To open the Notication Panel, swipe your nger down on the home screen or from
the top of the screen.
• To close the Notication Panel, swipe your nger up on the screen or touch the Back
key.
Indicator What it means
Low battery
Upcoming event
New Wi-Fi network detected
/
Downloading/sending data
USB connected
/
Song playing
Page 14
24 25
Responding to or Removing a Notication
In the Notication Panel, you can respond to a notication or remove the notications.
The Notication Panel also supports expandable notications that let you perform
additional actions right from the notication itself.
• To respond to a notication, touch it.
• Slide down with one nger to expand certain notications. You can also swipe two
ngers vertically or pinch-zoom to expand or collapse certain notications.
• To remove a notication, swipe it left or right.
• To remove all notications, touch CLEAR ALL at the end of the list of notications.
• To manage notications you have received, touch and hold a notication. You can
then touch Block all notications > DONE to hide future notications from this app,
or touch MORE SETTINGS to congure other notication options for this app.
NOTE: If you block notications for an app, you may miss its important alerts and
updates. The notications of some apps cannot be blocked.
Using Quick Settings
The Quick Settings in the Notication Panel make it convenient to view or change the
most common settings for your phone.
Swipe down with two ngers from the top of the screen, or open the Notication Panel
and drag the panel downward to view the following Quick Settings.
• Brightness: Uncheck AUTO and drag the brightness slider to adjust the screen
brightness.
• Bluetooth: Touch to turn on or o Bluetooth. Touch and hold to access the Bluetooth
menu. See Connecting to Networks and Devices – Connecting to Bluetooth Devices.
• Wi-Fi: Touch to turn on or o Wi-Fi. Touch and hold to access the Wi-Fi menu. See
Connecting to Networks and Devices – Connecting to Wi-Fi.
• Data: Touch to enable or disable data access over the mobile network. Touch and
hold to access the Data usage menu. See Settings – Wireless & Networks – Data
Usage.
• Location: Touch to turn location services on or o. Touch and hold to access the
Location menu. See Settings – Personal – Location.
• Airplane mode: Touch to turn on or o Airplane mode.
• Flashlight: Touch to turn on or o the ashlight.
• Sync: Touch to turn on or o auto-syncing of accounts data. Touch and hold to access
the Accounts menu. See Web Accounts or Settings – Personal – Accounts.
• Do not disturb / Priority only / Alarms only / Total silence: Touch to turn on Do not
disturb mode and select options. Touch MORE SETTINGS for more options, or touch
DONE to turn on Do not disturb mode with the options you have selected. Touch
again to turn o Do not disturb mode. Touch and hold to open the Do not disturb
menu. (See Personalizing – Using Do Not Disturb Mode.)
• Auto-rotate/Portrait: Touch to turn on or o the auto-rotate screen feature.
• Battery Saver: Touch to turn on or o Battery Saver. Touch and hold to access the
Battery saver menu. See Settings – Device – Battery.
• Sound/Vibrate/Silent: Touch to switch between sound, vibration and silent mode.
See Personalizing – Switching to Silent or Vibration Mode.
• Hotspot: Touch to enable the Wi-Fi hotspot feature and create a portable Wi-Fi
hotspot. Touch and hold to access the Wi-Fi hotspot menu. See Connecting to
Networks and Devices – Sharing Your Mobile Data Connection.
NOTE: In the Quick Settings screen, touch at the top to access the Settings menu;
touch to view your prole in the Contacts app; touch to change control switch
position.
Knowing the Basics Knowing the Basics
Page 15
26 27
Managing Shortcuts and Widgets
Adding Shortcuts and Widgets
1. Touch the Home key > to add shortcuts.
Or, to add widgets, touch and hold an empty area of the home screen and select
Widgets.
2. Slide to browse the available applications or widgets.
3. Touch and hold a widget or an application icon and drag it to a home screen panel.
NOTE: While holding the item, you can drag it to the right edge of the screen to create a
new home screen panel and put the item on it.
Moving Shortcuts or Widgets
1. Touch and hold a shortcut or widget on the home screen.
2. Drag it to the place you need.
Removing Shortcuts or Widgets
1. Touch and hold a shortcut or widget on the home screen.
2. Drag it to to remove it.
NOTE: When there are more than three home screen panels, no panel can be left empty.
If the shortcut, widget, or folder is the only item on the current home screen panel, the
panel will be deleted as you remove the item.
Adjusting Widget Size
1. Touch and hold a widget on the home screen and then release it.
2. An outline appears around the widget. Drag the outline to resize the widget.
NOTE: Not all widgets can be resized.
Organizing With Folders
You can create folders on the home screen and add several shortcuts to a folder.
You can move or remove folders the same way as moving or removing shortcuts.
1. On the home screen, touch and hold the shortcut you want to add into a folder.
2. Drag the shortcut to . A new folder will be created and the shortcut is added into
the folder.
3. To add more shortcuts into the folder, touch and hold each shortcut and drag it over
the folder before releasing it.
NOTES:
• To remove a shortcut from a folder, touch the folder to open it. Touch and hold the
shortcut and drag it to the home screen.
• Touch the folder and then touch the name eld to rename the folder.
Rearranging the Primary Shortcuts
The home screen includes a customizable primary shortcuts area at the bottom of
all home screens. You can keep up to four items in the primary shortcuts area. Drag
shortcuts or folders in or out of the area to rearrange the area.
Entering Text
You can enter text using the on-screen keyboard. Some apps open it automatically. In
others, you open it by touching where you want to type. You can touch the Back key to
hide the on-screen keyboard. You can also enter text by speaking with the Google voice
typing feature.
Knowing the Basics Knowing the Basics
Page 16
28 29
Enabling or Disabling Input Methods
1. Touch the Home key > > Settings > Languages & input > Virtual keyboard >
Manage keyboards.
2. Touch a keyboard in the list to enable/disable it as an option for entering text.
NOTE: Some default input methods may not be disabled.
Changing Input Methods
1. When you use the on-screen keyboard to enter text, the icon appears in the
Status Bar.
NOTE: The icon appears only when more than one virtual keyboard is installed
and enabled for use.
2. Open the Notication Panel and touch Change keyboard.
3. Select the input method you need.
Google Keyboard
The Google Keyboard provides a layout similar to a desktop computer keyboard. When
screen auto-rotation is enabled, turn the phone sideways and the keyboard will change
from portrait to landscape. The landscape keyboard is not supported in all applications.
• Touch the alphabetic keys to enter letters. Touch and hold some specic keys to enter
associated accented letters or numbers. For example, to enter È, touch and hold
and the available accented letters and number 3 appear. Then slide to choose È.
• As you enter a word, candidates appear above the keyboard. Touch the correct one to
select it.
• Touch to use uppercase. Double-tap to lock uppercase. This key also changes
color to indicate the current case you are using.
• Touch to delete the text before the cursor.
• Touch to select numbers and symbols. You can then touch to nd more or
touch to enter miniature icons.
• Touch to enter miniature icons such as expressions, astrological signs, and
animals.
• Touch to use Google voice typing.
• Touch and hold to change the input languages or set up the Google Keyboard.
• Touch and hold and slide to to change to a smaller keyboard for easier onehanded typing. Touch / to switch to the left-hand or right-hand keyboard,
respectively. Touch to switch back to the full-sized keyboard.
Gesture Typing
The Google Keyboard supports the gesture typing feature. You use this feature to input a
word by sliding through the letters.
To enable and use gesture typing:
1. On the Google Keyboard, touch and hold > Google Keyboard settings.
Or, touch the Home key > > Settings > Languages & input > Virtual keyboard >
Google Keyboard.
2. Touch Gesture typing > Enable gesture typing if this feature is turned o.
Knowing the Basics Knowing the Basics
Page 17
30 31
3. Move your nger from letter to letter on the keyboard to trace a word without lifting
the nger until you reach the end of the word.
End of the word
Start of the word
NOTES:
• Touch when you want to. If you want to enter a single letter, go ahead and touch.
• Lift your nger at the end of the word. A space is added automatically when you
begin to input the next word.
Google Voice Typing
Google voice typing uses the Google voice recognition service to convert speech to text.
You must have a data connection on a mobile or Wi-Fi network to use it.
1. Touch to access voice typing when you are using the Google Keyboard, or ick
down the Status Bar when entering text and touch Change keyboard > Google
voice typing.
2. When you see the microphone image, speak what you want to type.
3. You can continue entering text or touch an underlined word to change or delete it.
NOTE: Say “comma,” “period,” “question mark ,” “exclamation mark,” or “exclamation point”
to enter punctuation.
Input Method Settings
Choose the input method settings by touching the Home key > > Settings >
Languages & input > Virtual keyboard. Touch an option to choose the settings for that
input method.
Editing Text
• Move the insertion point: Touch where you want to type. The cursor blinks in the
new position, and a tab appears below it. Drag the tab to move the cursor.
• Select text: Touch and hold or double-tap within the text. The nearest word
highlights, with a tab at each end of the selection. Drag the tabs to change the
selection. Touch > SELECT ALL to select all the text, touch SHARE and choose an
option, or touch ASSIST to open Google Now.
• Cut or copy: Select the text you want to manipulate. Then touch CUT or COPY to cut
or copy the text to the clipboard.
• Replace text with the clipboard text: Select the text you want to replace. Then
touch PASTE.
• Insert clipboard text in the text eld: Touch the tab below the cursor. Then touch
PASTE.
Opening and Switching Apps
Opening an App
1. Touch the Home key > .
2. Swipe up or down on the screen and touch an app to open it.
NOTE: Drag the slider on the right side of the screen to the initial letter of the app you
need, or touch the search box at the top to search for apps.
Knowing the Basics Knowing the Basics
Page 18
32 33
Switching Between Recently Opened Apps
1. Touch the Recent apps key. A list of the names and thumbnails of apps you’ve
recently used opens. If you’ve been using more apps recently than can t on the
screen, you can scroll the list up and down.
2. Touch a thumbnail to open that app.
NOTE: You can swipe a thumbnail left or right or touch X on the thumbnail to remove it
from the list. Touch Clear all to remove all thumbnails.
Using Two Apps in Split-Screen Mode
You can work with two apps at the same time in split-screen mode.
NOTE: Some apps may not support split-screen mode.
1. Open the rst app you want to use and then touch and hold the Recent apps key.
The screen is divided into two.
-or-
Touch the Recent apps key to view your recently used apps, touch and hold the tab
of the app you want to use and drag it to the Drag here to use split screen area.
2. If the app you need is in the recent apps list, touch it to set it as the second app. Or
touch the Home key to nd the app you need and open it as the second app.
To turn o split-screen mode, touch and hold the Recent apps key, or drag the handle
to the edge of the screen.
Uninstalling or Disabling an Application
1. Touch the Home key > to open the application list screen.
2. Touch and hold an application icon and drag the icon to or at the top of the
screen.
3. Touch OK to uninstall or disable the app.
NOTES:
• Preinstalled apps cannot be uninstalled, and not all apps can be disabled.
• To nd the disabled applications, touch the Home key > > Settings > Apps. Touch
All apps > Disabled. You can then touch an application and touch ENABLE to enable
it.
Knowing the Basics Knowing the Basics
Page 19
34 35
Connecting to Networks and Devices
Connecting to Mobile Networks
Controlling Mobile Data Use
To enable or disable data access:
1. Touch the Home key > > Settings > Mobile networks > Mobile Networks.
2. Touch the Mobile Data switch to enable or disable mobile data use.
To get data services when roaming:
1. Touch the Home key > > Settings > Mobile networks > International Data
Roaming.
2. Touch the Mobile Data switch to enable or disable roaming.
NOTE: Data roaming may incur signicant roaming charges.
Resetting Access Point Names
To connect to the Internet via mobile data service, you need the correct Access Point
Names (APNs). The APNs have been pre-congured on your phone and ready for use.
If you have any problem connecting with the Internet, try reset the APN settings to the
default.
1. Touch the Home key > > Settings > Mobile networks > Access Point Names.
2. Touch > Reset to default.
Selecting Network Type
1. Touch the Home key > > Settings > Mobile networks > Preferred network type.
2. Touch the type of network you prefer to connect to.
Connecting to Wi-Fi®
Wi-Fi is a wireless networking technology that can provide Internet access at distances of
up to 300 feet (100 meters), depending on the Wi-Fi router and your surroundings.
Turning Wi-Fi On and Connecting to a Wi-Fi Network
1. Touch the Home key > > Settings > Wi-Fi.
2. Slide the Wi-Fi switch to the On position to turn on Wi-Fi.
3. Touch a network name to connect to it.
4. If the network is secured, enter the password and touch CONNECT.
NOTE: Your phone automatically connects to previously used Wi-Fi networks when they
are in range.
Getting Notied of Open Networks
1. Touch the Home key > > Settings > Wi-Fi.
2. Slide the Wi-Fi switch to the On position.
3. Touch .
4. Slide the Network notication switch to the On position.
When Wi-Fi is on, you receive notications in the Status Bar when your phone detects an
open Wi-Fi network. Slide the Network notication switch to the O position to
turn o notications.
Adding a Wi-Fi Network
You can add a Wi-Fi network if the network does not broadcast its name (SSID) or to add
a Wi-Fi network when you are out of range.
To connect to a secured network, you rst need to get the security details from the
network’s administrator.
1. Touch the Home key > > Settings > Wi-Fi.
2. Slide the Wi-Fi switch to the On position.
3. Touch Add network.
4. Enter the network SSID (name). If necessary, enter security or other network
conguration details.
Connecting to Networks and Devices
Page 20
36 37
5. Touch SAVE.
Forgetting a Wi-Fi Network
You can make your phone forget about the details of a Wi-Fi network that you added
– for example, if you don’t want the phone to connect to it automatically or if it is a
network that you no longer use.
1. Touch the Home key > > Settings > Wi-Fi.
2. Slide the Wi-Fi switch to the On position.
3. Touch > Saved networks.
4. Touch the Wi-Fi network name and then touch FORGET.
Connecting to a WPS Network
Wi-Fi Protected Setup (WPS) is a feature that makes it easy to add your phone to the
access points that support WPS.
You can use one of the following methods to connect your phone to a wireless network
using WPS.
Method one: WPS button (Recommended)
1. Touch the Home key > > Settings > Wi-Fi.
2. Slide the Wi-Fi switch to the On position.
3. Touch > Advanced > WPS Push Button.
4. Press the WPS button on the wireless router and the access point will recognize your
phone and add it to the network.
Method two: PIN
1. Touch the Home key > > Settings > Wi-Fi.
2. Slide the Wi-Fi switch to the On position.
3. Touch > Advanced > WPS Pin Entry.
4. The WPS PIN displays on the screen. Enter the PIN into the access point’s setup page.
After entering the PIN, your phone automatically nds the access point and congures
the connection.
NOTE: For detailed information about the WPS feature of the access point, please refer to
its user manual.
Adjusting Advanced Wi-Fi Settings
1. Touch the Home key > > Settings > Wi-Fi.
2. Touch to adjust the following settings.
u Network notication: Get notications in the Status Bar when Wi-Fi is on and an
open network is available.
u Keep Wi-Fi on during sleep: Choose whether or not to keep Wi-Fi on in Sleep
mode.
u MAC address: Check the MAC address.
u IP address: Check the phone’s IP address.
- or -
Touch > Advanced to adjust the following settings.
u Install certicates: Install certicates needed for connecting to certain Wi-Fi
networks.
u WPS Push Button: Connect to a WPS network via the push button method.
u WPS Pin Entry: Connect to a WPS network via the phone PIN method.
Connecting to Bluetooth Devices
Bluetooth is a short-range wireless communication technology. Phones or other
devices with Bluetooth capabilities can exchange information wirelessly within a
distance of about 30 feet (10 meters). The Bluetooth devices must be paired before the
communication is performed.
Connecting to Networks and Devices Connecting to Networks and Devices
Page 21
38 39
Turning Bluetooth On/O
1. Touch the Home key > > Settings > Bluetooth.
2. Slide the Bluetooth switch to the On or O position.
When Bluetooth is on, the icon will appear in the Status Bar.
Changing the Device Name
1. Touch the Home key > > Settings > Bluetooth.
2. Slide the Bluetooth switch to the On position if Bluetooth is o.
3. Touch > Rename this device.
4. Edit the name and touch RENAME.
Pairing With Another Bluetooth Device
1. Touch the Home key > > Settings > Bluetooth.
2. Slide the Bluetooth switch to the On position if Bluetooth is o.
Your phone automatically scans for and displays the IDs of all available Bluetooth
devices in range. Touch > Refresh if you want to scan again.
3. Touch the device you want to pair with.
4. If necessary, conrm that the Bluetooth passkeys are the same between the two
devices and touch PAIR. Alternatively, enter a Bluetooth passkey and touch PAIR.
Pairing is successfully completed when the other device accepts the connection or the
same passkey is entered.
NOTE: The Bluetooth passkey may be xed for certain devices, such as headsets and
hands-free car kits. You can try entering 0000 or 1234 (the most common passkeys) or
refer to the documents for that device.
Forgetting a Bluetooth Device
You can make your phone forget its pairing connection with another Bluetooth device.
To connect to the device again, you need to search for it and enter or conrm a passkey
again.
1. Touch the Home key > > Settings > Bluetooth and ensure that Bluetooth is
turned on.
2. In the list of paired devices, touch beside the Bluetooth device you want to forget.
3. Touch FORGET.
Sending Data via Bluetooth
1. Open the appropriate application and select the le or item you want to share.
2. Select the option for sharing via Bluetooth. The method may vary by application and
data type.
3. Touch a Bluetooth device the phone has paired with or wait for it to search for new
devices and touch one of them.
Receiving Data via Bluetooth
1. Turn Bluetooth on before trying to receive data via Bluetooth.
2. Touch ACCEPT to start receiving the data. If necessary, swipe down on the Status Bar,
and touch ACCEPT on the Bluetooth sharing notication.
Depending on your storage setting and whether a microSDXC card is installed, received
les are stored automatically in a dedicated folder (Bluetooth, for instance). You can
access them with the File Manager app.
Connecting to Your Computer via USB
You can connect your phone to a computer with a USB cable and transfer music,
pictures, and other les in both directions. Your phone stores these les in the internal
storage or on a removable microSDXC card.
Connecting to Networks and Devices Connecting to Networks and Devices
Page 22
40 41
Connecting Your Phone to a Computer via USB
1. Connect your phone to the PC with a USB cable.
2. Choose one of the following options:
u Charge only: Charge your phone via USB.
u Install driver: Install the driver needed for some USB connection modes (such as
MTP). You only need to install the driver on the same PC once.
NOTE: You can also install the driver on PC by running the executable le in the
CD-ROM drive.
u Media device (MTP): Transfer les on Windows® or Mac®.
NOTE: For Windows XP, install the drivers and Windows Media® Player 11 (or later
version) when you use Media device (MTP) for the rst time.
u Camera (PTP): Transfer photos using camera software.
NOTE: To make your phone connect to the computer automatically using the selected
connection type, check Don’t ask me again.
Disconnecting Your Phone From the Computer
To disconnect the phone from the computer, simply unplug the USB cable when you’re
nished.
Using the microSDXC Card as Portable or Phone Storage
You can use your microSDXC card as portable storage when there’s already content such
as your media and other les so that you don’t lose them.
If your microSDXC card is new or doesn’t have content you want to keep, you can also set
it up as an extension of the phone storage, and this requires formatting that prevents the
microSDXC card from working with other devices.
CAUTION: As part of the phone storage, the microSDXC card may have data on it that is
necessary for some apps to function normally. Therefore, do not remove or replace the
card randomly.
Setting Up the microSDXC Card as Portable Storage
When you install a microSDXC card that has not been used on your phone before, the
phone will mount the card as portable storage by default.
To remove the microSDXC card from your phone:
If you need to remove the microSDXC card used as portable storage while the phone is
on, you must unmount it rst.
1. Touch the Home key > > Settings > Storage.
2. Touch next to the SD card name in the Portable storage section.
3. When the screen prompts the card is safely ejected, you can remove it from the
phone.
To erase and format the microSDXC card:
1. Touch the Home key > > Settings > Storage.
2. Touch the SD card name in the Portable storage section.
3. Touch Format.
4. Touch ERASE & FORMAT.
CAUTION: The formatting procedure erases all the data on the microSDXC card, after
which the les CANNOT be retrieved.
Setting Up the microSDXC Card as Phone Storage
If your microSDXC card is new or doesn’t have content you want to keep, you can format
the card and use it as part of the phone storage. If you move the microSDXC card to
another device, it’ll be formatted before it can be used.
1. Touch the Home key > > Settings > Storage.
2. Touch the SD card name in the Portable storage section.
3. Touch Format as internal.
4. Touch ERASE & FORMAT.
Connecting to Networks and Devices Connecting to Networks and Devices
Page 23
42 43
CAUTION: The formatting procedure erases all the data on the microSDXC card, after
which the les CANNOT be retrieved.
5. The phone will prompt you to move your photos, les and other data from the
internal storage to the microSDXC card. Select Move now or Move later and touch
NEXT. Follow the onscreen instructions to continue.
To move data between the internal storage and the microSDXC card:
With the microSDXC card as part of the phone storage, you can move your photos, les
and other data between the internal storage and the card any time.
1. Touch the Home key > > Settings > Storage.
2. Touch Phone or the SD card name.
3. Touch Migrate data.
4. Touch MOVE.
NOTE: Whenever you move data between the internal storage and the microSDXC card,
the destination is used to save new apps and personal data (such as photos and videos)
and only the destination is accessible from a computer.
To remove the microSDXC card from your phone:
If you need to remove the microSDXC card used as phone storage while the phone is on,
you must unmount it rst.
1. Touch the Home key > > Settings > Storage.
2. Touch your SD card name below Device storage.
3. Touch Remove SD card.
NOTE: Before ejecting the card, ensure that you have moved data and apps to the
internal storage.
4. Touch EJECT.
5. When the screen prompts the card is safely ejected, you can remove it from the
phone.
To reformat the microSDXC card as portable storage:
If you no longer want to use your microSDXC card as phone storage, you can reformat
the card as portable storage.
NOTE: Before the formatting, ensure that you have moved data and apps to the internal
storage.
1. Touch the Home key > > Settings > Storage.
2. Touch your SD card name below Device storage.
3. Touch Format as portable.
4. Touch FORMAT.
CAUTION: The formatting procedure erases all the data on the microSDXC card, after
which the les CANNOT be retrieved.
Sharing Your Mobile Data Connection
Sharing Your Mobile Data Connection via USB
You can access the Internet on your computer via the USB tethering feature of your
phone. The feature needs data connection on a mobile network and may result in data
charges.
NOTE: You cannot transfer les between your phone and your computer when the
phone is USB tethered.
1. Connect your phone to your computer with a USB cable.
2. Touch the Home key > > Settings > More.
3. Switch on USB tethering. A new network connection will be created on your
computer.
NOTE: To stop sharing your data connection, switch o USB tethering or disconnect the
USB cable.
Connecting to Networks and Devices Connecting to Networks and Devices
Page 24
44 45
Sharing Mobile Data Through a Wi-Fi Hotspot
You can share your phone’s data connection with other devices by turning your phone
into a portable Wi-Fi hotspot. The feature requires a data connection on a mobile
network and may result in data charges.
NOTE: When the portable Wi-Fi hotspot feature is enabled, you cannot use your phone’s
Wi-Fi capability to access the Internet. You still remain connected to the Internet via your
mobile data network.
1. Touch the Home key > > Settings > Wi-Fi hotspot.
2. Slide the switch to the On position. (If Wi-Fi was active, touch OK to deactivate it.)
After a moment, the phone starts broadcasting its Wi-Fi network name (SSID).
3. On another device, locate your phone via Wi-Fi and connect with it to start using the
phone’s mobile data.
NOTE: To stop sharing your data connection, slide the switch to the O position.
Setting Up Your Wi-Fi Hotspot
You can change your phone’s Wi-Fi network name (SSID), secure your portable Wi-Fi
hotspot, and set other options.
1. Touch the Home key > > Settings > Wi-Fi hotspot.
2. Touch an option to congure options.
u Congure:
- Network name: Enter or edit a network SSID (name) that other devices see when
scanning for Wi-Fi networks.
- Channel: Select a Wi-Fi channel for your Wi-Fi hotspot, or set as Auto.
- Security: Choose a security option: Open (not recommended) or WPA2 PSK
(other users can access your hotspot only if they enter the correct password).
When you select WPA2 PSK, touch the Password eld to edit the security
password.
- Show password: If you have chosen WPA2 PSK security, check or uncheck to
show or hide the password.
- Broadcast network name (SSID): Check to broadcast or uncheck to hide your
network name (SSID). If the broadcast is disabled, other users need to know your
network SSID to nd the Wi-Fi hotspot.
u Manage users: Block or unblock users, or set the maximum number of devices
that can connect to the hotspot simultaneously, and view a list of connected
users.
u Sleep policy: Set hotspot sleep policy and notication.
Connecting to Virtual Private Networks
Virtual private networks (VPNs) allow you to connect to the resources inside a secured
local network. VPNs are commonly deployed by corporations, schools, and other
institutions to let people access local network resources when not on campus, or when
connected to a wireless network.
Depending on the type of VPN you are using, you may be required to enter your login
credentials or install security certicates before you can connect to your VPN. You can
get this information from your network administrator.
NOTE: You need to set a lock screen pattern, PIN, or password before you can use
credential storage (VPN).
Adding a VPN
1. Touch the Home key > > Settings > More > VPN.
2. Touch and enter the VPN name.
3. Select the VPN type, enter the server address and other information provided by your
network administrator. Check Show advanced options to ll out additional details.
4. Touch SAVE.
The VPN is added to the list on the VPN screen.
Connecting to Networks and Devices Connecting to Networks and Devices
Page 25
46 47
Connecting to a VPN
1. Touch the Home key > > Settings > More > VPN.
2. Touch the VPN that you want to connect to.
3. When prompted, enter any requested credentials and then touch CONNECT.
Modifying a VPN
1. Touch the Home key > > Settings > More > VPN.
2. Touch beside the VPN that you want to modify.
3. Edit the VPN settings and then touch SAVE.
Phone Calls
You can place calls from the Phone app, the Contacts app, or other apps or widgets that
display contact information. Wherever you see a phone number, you can usually touch
it to dial.
Placing and Ending Calls
Placing a Call by Dialing
1. Touch the Home key > > .
2. Enter the phone number or the contact name with the dialpad. Touch to delete
incorrect digits/letters.
NOTE: As you enter the phone number or contact name, your phone searches for
matching information in your contacts. If you see the number and contact you want
to call, touch it to place the call immediately.
3. Touch below the keypad to dial.
You can also touch the search box at the top of the Phone app screen and enter the
phone number or contact name you want to call. Touch the matching contact or Call
[number] to place the call.
NOTES:
• To make an international call, touch and hold the 0 key to enter the plus (+) symbol.
Next, enter the country code followed by the city/area code and then the phone
number.
• To redial the last call you made, touch the Home key > > > and touch
again.
Ending a Call
During a call, touch on the screen.
Connecting to Networks and Devices
Page 26
48 49
Answering or Rejecting Calls
When you receive a phone call, the incoming call screen opens, displaying the Caller
ID or the information about the caller that you’ve entered in the Contacts app. You can
answer or reject the call, or reject it with a text message.
Answering a Call
To answer an incoming call,
• If the phone screen is active, touch .
• If the phone screen is locked, slide down to .
NOTE: To silence the ringer before answering the call, press the Volume key or the
Power key.
Rejecting a Call
To reject an incoming call,
• If the phone screen is active, touch .
• If the phone screen is locked, slide up to .
You can also reject the call and select a preset text message or write one to send to the
caller.
• If the phone screen is active, touch .
• If the phone screen is locked, touch MESSAGE REJECT.
NOTE: To edit the preset text responses from within the Phone app, touch > Settings >
Quick responses.
Working With the Call History
The call history is a list of all the calls you’ve placed, received, or missed. It provides a
convenient way to redial a number, return a call, or add a number to your Contacts.
To open the call history, touch the Home key > > (in the top search eld) > Call
History.
Placing a Call From the Call History
1. Open the call history.
2. Touch a number for more information about the call, or touch beside it to call
back.
NOTE: You can touch , , or to lter the records by call type.
Adding a Call History Number as a Contact
1. Open the call history.
2. Touch the circle in front of a number.
3. Touch on the contact information tab.
4. To add the number to an existing contact, touch a contact in the list. To add a new
contact, touch Create new contact.
Taking Other Actions on a Call History Entry
1. Open the call history.
2. Touch a number and then touch Call details to view more call information. While
viewing the call details, you can:
u Touch to delete the entry.
u Touch Edit number before call to edit the number in the dialer before calling it.
u Touch the circle in front of the entry to open the contact information tab from the
bottom of the screen. You can send a message, call back, edit the contact, add the
contact to favorites, or add the number to contacts.
NOTE: You can touch > Clear call history in the call history screen to delete all history
records.
Phone Calls Phone Calls
Page 27
50 51
Calling Your Contacts
1. Touch the Home key > . Your favorite contacts and frequently called contacts are
displayed in the FAVORITES tab.
2. Touch a contact to place the call, or touch the CONTACTS tab and then touch
beside a contact to make a call.
Checking Voicemail
If you have set the phone to divert calls to voicemail, callers can leave voicemail
messages when they cannot reach you. Here’s how to check the messages they left.
1. Touch the Home key > > .
2. Touch and hold the 1 key in the dialer. If prompted, enter your voicemail password.
3. Follow the voice prompts to listen to and manage your voicemail messages.
NOTE: See Phone Calls – Adjusting Your Call Settings – Setting Voicemail for how to set
your voicemail service. For detailed information, please contact the service provider.
Using Options During a Call
During a call, you will see a number of on-screen options. Touch an option to select it.
• Touch to put the call on hold.
• Touch to make another call separately from the rst call, which is put on hold.
• Touch to go to contacts.
• Touch to switch to the keypad when you need to enter a code (for example, the
PIN for your voicemail or bank account) during the call.
• Touch to mute or unmute your microphone.
• Touch to turn the speaker on or o.
• Touch to put the caller you are speaking to on hold, and switch to the other call
that has been put on hold.
• Touch to merge the separate calls into a single conference call.
• Touch to end the current call.
WARNING! Because of higher volume levels, do not place the phone near your ear
during speakerphone use.
Managing Multi-party Calls
When the call waiting and three-way call features are available, you can switch between
two calls or set up a conference call.
NOTE: Options and interface will vary. The call waiting and three-way call features need
network support and may result in additional charges. Please contact your service
provider for more information.
Switching Between Current Calls
When you’re on a call, your phone screen informs you that another call is coming in and
displays the caller ID.
To respond to an incoming call while you’re on a call:
• To uch to answer the call. This puts the rst caller on hold and
answers the second call.
• Touch to answer the second call and end the rst one.
• Touch to reject the second call.
• Touch to reject the second call and select a preset text message to send to
the caller.
To switch between two calls:
Touch .
Setting Up a Conference Call
With this feature, you can talk to two people at the same time.
Phone Calls Phone Calls
Page 28
52 53
1. Place the rst call.
2. Once you have established the connection, touch and dial the second number.
This puts the rst caller on hold.
3. When you’re connected to the second party, touch .
4. You can touch Manage conference call to end or separate a call; touch Back
to call to return to the main call screen.
If one of the people you called hangs up during your call, you and the remaining
caller stay connected. If you initiated the call and are the rst to hang up, all callers are
disconnected.
To end the conference call, touch .
Adjusting Your Call Settings
You can congure a number of settings for the Phone application.
NOTE: Some call options are displayed only when these features are available, and some
features require network support and may result in additional charges. Please contact
your service provider for more information.
Setting Contact Display Options
You can set the order of the contacts displayed in the CONTACTS tab of the Phone app.
1. Touch the Home key > > > Settings > Display options.
2. Touch Sort by or Name format to set the order of the contacts and the format of the
contact names.
Setting Sound and Vibration
Set the sound and vibration for incoming calls as well as dialpad sounds.
1. Touch the Home key > > > Settings > Sounds and vibration.
2. Touch the option you want to congure.
u Touch Phone ringtone to select the ringtone for incoming call notication.
u Check Also vibrate for calls to enable vibration for incoming call notication.
u Check Dialpad tones to play sounds when you touch the dialpad keys.
Setting Options for Answering and Ending Calls
When enabled, the options allow you to end a call by pressing the Power key or make
the phone vibrate when a call is answered.
1. Press the Home key > > > Settings > Answer and end calls.
2. Check or uncheck Power button ends call or Vibrate when call is answered.
Setting Speed Dials
You can touch and hold the 1~9 keys from the dialer to call the corresponding speed dial
number.
The number 1 key is reserved to speed dial your voicemail.
To assign a speed dial key:
1. Touch the Home key > > > Settings > Speed dial.
2. Touch a speed dial entry.
3. Enter a phone number or select one from the contact list.
4. Touch OK.
Editing Quick Response to Rejected Callers
1. Touch the Home key > > > Settings > Quick responses.
2. Touch a text message to edit it.
3. Touch OK to save the message.
Phone Calls Phone Calls
Page 29
54 55
Setting Voicemail
1. Touch the Home key > > > Settings > Call settings.
2. Touch Voicemail to congure voicemail settings.
u Touch Service to select the voicemail service provider. Your carrier is the default.
u Touch Setup to view the voicemail number.
u Touch Sound to select the notication ringtone for new voicemails.
u Check Vibrate to enable vibration for notications.
Using Fixed Dialing Numbers
Fixed Dialing Numbers (FDN) allows you to restrict outgoing calls to a limited set of
phone numbers.
1. Touch the Home key > > > Settings > Call settings > Fixed Dialing Numbers.
2. Set the following options.
u Enable FDN: Input the PIN2 code to enable the FDN feature.
u Change PIN2: Change the PIN2 code for FDN access.
u FDN list: Manage the FDN list.
NOTE: The PIN2 code is provided by your carrier. Entering an incorrect PIN2 code
more times than allowed can lock your nano-SIM card. Contact the service provider for
assistance.
Setting DTMF Tones
You can set the length of dual-tone multi-frequency (DTMF) signal tones.
1. Touch the Home key > > > Settings > Call settings > DTMF tones.
2. Touch Normal or Long.
Forwarding Incoming Calls
The call forwarding feature allows you to forward your incoming calls to another phone
number.
1. Touch the Home key > > > Settings > Call settings > Call forwarding.
2. Touch an available option to enable it.
Setting Call Waiting
This option allows you to get notied of incoming calls during a call.
1. Touch the Home key > > > Settings > Call settings > Call waiting.
2. Check Call waiting to enable this feature.
Setting Caller ID
Choose whether your number is displayed when someone receives your outgoing call.
1. Touch the Home key > > > Settings > Call settings > Additional settings.
2. Touch Caller ID and select an option.
Setting Voice Privacy
This option allows you to enable enhanced privacy mode.
1. Touch the Home key > > > Settings > Call settings > Additional settings.
2. Check Voice privacy to enable this feature.
Setting Plus Code Dialing
Plus Code Dialing allows the phone to automatically dial the international access code
for your location when you press and hold the 0 key in the dialpad.
Phone Calls Phone Calls
Page 30
56 57
To activate Plus Code Dialing:
1. Touch the Home key > > > Settings > Call settings > Additional settings >
Plus code dialing setting.
2. Check Setup Plus Code Replacement to enable this feature.
To change the international dialing code:
1. Touch the Home key > > > Settings > Call settings > Additional settings >
Plus code dialing setting.
2. Touch Replace Code of Plus Code.
3. Enter a new code and touch OK.
Blocking Certain Numbers
The call blocking feature allows you to forbid calls and messages from certain numbers.
1. Touch the Home key > > > Settings > Call blocking.
2. Touch ADD A NUMBER.
3. Enter a phone number or select one from the contact list.
4. Touch BLOCK.
Setting TTY Mode
Your phone is a TTY compatible device. A TTY device can allow people who have hearing
or speech disabilities to communicate by telephone. Simply connect the TTY device to
the phone’s headset jack.
Select a TTY mode for your phone to work with a TTY device, or turn TTY o.
1. Touch the Home key > > > Settings > Accessibility > TTY mode.
2. Select one of the following options. Consult your teletypewriter manufacturer’s
manual if necessary.
u TTY O: Users who can hear and talk can disable TTY support.
u TTY Full: Users who cannot talk or hear may use this mode to send and receive
text messages through TTY device.
u TTY HCO: Users who can hear, but cannot talk, may use this mode to listen to
conversation of the other party, and respond via text messages.
u TTY VCO: Users who can talk, but cannot hear, may use this mode to talk through
the phone and receive responses via text messages.
Setting Hearing Aids
Your phone supports HAC (Hearing Aid Compatibility) function. When you turn on the
hearing aid compatibility and use a hearing aid with a telecoil to answer the phone, it
will help you hear more clearly during the phone call.
1. Touch the Home key > > > Settings > Accessibility.
2. Check Hearing aids to turn on hearing aid compatibility.
CAUTION: Do not turn on the Hearing aids option unless you use a hearing aid with a
telecoil. Using this setting without a hearing aid or with a hearing aid without a telecoil
may be harmful to your hearing.
Phone Calls Phone Calls
Page 31
58 59
Contacts
You can add contacts on your phone and synchronize them with the contacts in your
Google account or other accounts that support contact syncing.
To see your contacts, touch the Home key > > Contacts. From there, you can touch
the tabs to quickly switch to your contact groups or favorite contacts.
Checking Contact Details
1. Touch the Home key > > Contacts > CONTACTS.
2. Scroll through the list to view all your contacts.
3. Touch a contact to view its details.
NOTE: If you have a lot of contacts stored, you’ll see a slider on the right side of the
screen. To go directly to a letter, drag the slider to a letter.
Adding a New Contact
1. Touch the Home key > > Contacts > CONTACTS.
2. Touch to add a new contact.
3. Enter the contact name, phone numbers, and email addresses. Touch More Fields
to enter other information. If you have multiple account types associated with your
phone, touch the contact account eld at the top and select a contact type. If a sync
account is selected, the contacts will be synced automatically with your account
online.
4. Touch to save the contact.
Setting Up Your Own Prole
You can create your own name card in your phone.
1. Touch the Home key > > Contacts and touch the CONTACTS tab.
2. Touch Set up my prole. If a prole has been set up, touch the listing below ME and
touch .
3. Edit your prole information. Touch More Fields to add more information if desired.
4. Touch to save.
Importing, Exporting, and Sharing Contacts
You can import/export contacts from/to your nano-SIM card, the phone storage, or a
microSDXC card. This is especially useful when you need to transfer contacts between
dierent devices. You can also quickly share your contacts using Bluetooth, Email, Gmail,
Google Drive, or Messaging.
NOTE: Some nano-SIM cards may not support importing/exporting contacts. Contact
your operator for more information.
Importing Contacts From the nano-SIM Card
1. Touch the Home key > > Contacts.
2. Touch > Import/Export > Import from SIM card.
3. Check the contacts you want to import, and then touch .
4. If you have added contact accounts other than the phone, select an account in which
to save the contact.
Importing Contacts From the microSDXC Card or Phone Storage
1. Touch the Home key > > Contacts.
2. Touch > Import/Export > Import from storage.
3. If prompted, choose to import one, multiple, or all vCard les, and then touch OK.
4. If necessary, choose the vCard le(s) you would like to import, and then touch OK.
Contacts
Page 32
60 61
Exporting Contacts to the nano-SIM Card
1. Touch the Home key > > Contacts.
2. Touch > Import/Export > Export to SIM card.
3. Touch the contacts you want to export, and then touch .
Exporting Contacts to the microSDXC Card or Phone Storage
1. Touch the Home key > > Contacts.
2. Touch > Import/Export > Export to storage.
3. The phone will prompt you with the name of the vCard le. Touch OK to create the
le.
Sharing Contacts
1. Touch the Home key > > Contacts > CONTACTS.
2. Touch and hold the contact you want to share.
3. Touch to select more contacts if needed, and then touch .
4. Choose how to share the contacts. The options available depend on the applications
and services installed.
NOTE: You can also share your contacts by choosing Share visible contacts in the
Import/Export contacts menu.
Working With Favorite Contacts
You can add the contacts you use frequently to FAVORITES so that you can nd them
quickly.
Adding a Contact to Favorites
1. Touch the Home key > > Contacts > CONTACTS.
2. Touch a contact and then touch at the top of the screen.
Removing a Contact From Favorites
1. Touch the Home key > > Contacts > FAVORITES.
2. Touch a favorite contact and then touch .
Working With Groups
Viewing Your Contact Groups
1. Touch the Home key > > Contacts > GROUPS.
2. Scroll through the list to view the preset groups and any groups you have created.
3. Touch a group to view its members.
NOTE: To send a message or an email to the group members, touch beside the
group’s name in the list.
Setting Up a New Group
1. Touch the Home key > > Contacts > GROUPS.
2. Touch to create a new group.
3. Touch the Group’s name eld and enter a name.
4. Touch Add member and select the contacts you wish to be the group members.
5. Touch .
6. If necessary, touch the eld below RINGTONE and NOTIFICATION RINGTONE to set
a special ringtone for incoming calls and messages from the group members, and
then touch OK.
7. Touch to save the group.
Contacts Contacts
Page 33
62 63
Deleting a Group
1. Touch the Home key > > Contacts > GROUPS.
2. Touch a group and then touch > Delete group.
3. Touch OK to disband the group. The contacts in the group will not be deleted.
Editing a Group
1. Touch the Home key > > Contacts > GROUPS.
2. Touch a group > > Edit group.
3. Touch the group name to edit it, or touch the eld below MEMBER, RINGTONE, or
NOTIFICATION RINGTONE to add more members or change the ringtone.
4. Touch .
NOTE: To remove group members, touch a group and then touch > Multi-select and
select the members you would like to remove. Touch > OK.
Searching for a Contact
1. Touch the Home key > > Contacts and then touch to search.
2. Enter the contact name or other information (such as phone number) you want to
search for. The contacts matched will be listed.
Editing Contacts
Editing Contact Details
1. Touch the Home key > > Contacts > CONTACTS.
2. Touch a contact and then touch .
3. Edit the contact and touch .
Setting a Ringtone for a Contact
Assign a special ringtone to a contact, so you know who is calling when you hear the
ringtone.
1. Touch the Home key > > Contacts > CONTACTS.
2. Touch a contact you want to set a ringtone for, and then touch .
3. Touch More Fields > Default ringtone.
4. Select a ringtone you like and touch OK.
5. Touch .
Deleting Contacts
1. Touch the Home key > > Contacts > CONTACTS.
2. Touch and hold the contact you want to remove.
3. Check more contacts if needed, and then touch .
4. Touch OK to conrm.
Linking Contacts
As your phone synchronizes with multiple online accounts, you may see duplicate
entries for the same contact. You can merge all the separate information of a contact into
one entry in the Contacts list.
1. Touch the Home key > > Contacts > CONTACTS.
2. Touch a contact entry to display the contact’s details.
3. Touch > > Link.
4. Touch the contact whose information you want to link with the rst entry.
5. Touch to save the joined contact.
Contacts Contacts
Page 34
64 65
NOTES:
• The information from the second contact is added to the rst contact, and the second
contact is no longer displayed in the contacts list.
• You can repeat these steps to link another contact to the main contact.
Separating Contact Information
If contact information from dierent sources was linked by mistake, you can separate the
information back into individual contacts on your phone.
1. Touch the Home key > > Contacts > CONTACTS.
2. Touch a contact you want to separate.
3. Touch > > Unlink.
4. Touch UNLINK to conrm.
Web Accounts
Adding or Removing Accounts
You can add multiple Google accounts and Microsoft Exchange ActiveSync® accounts.
You may also add other kinds of accounts, depending on the apps installed on your
phone.
Adding an Account
1. Touch the Home key > > Settings > Accounts > Add account.
2. Touch the type of account you want to add.
3. Follow the on-screen steps to enter the information about the account. Most
accounts require a username and password, but the details may vary. You may also
need to obtain some information from IT support or your system administrator.
When the account is successfully added, it is displayed in the Accounts menu in Settings.
Removing an Account
Removing an account will delete it and all information associated with it, such as emails
and contacts, from your phone.
1. Touch the Home key > > Settings > Accounts.
2. Touch the account category and then touch the account you’d like to remove.
3. Touch > Remove account > REMOVE ACCOUNT.
Contacts
Page 35
66 67
Conguring Account Sync
Conguring Auto Sync Setting
1. Touch the Home key > > Settings > Accounts.
2. Touch > Auto-sync data to enable or disable automatic sync.
3. Touch OK.
u When automatic sync is turned on, changes you make to information on your
phone or on the web are automatically synced with each other.
u When automatic sync is turned o, you need to sync manually to collect emails,
updates, or other recent information.
Syncing Manually
1. Touch the Home key > > Settings > Accounts.
2. Touch the account category and then the account you want to sync.
3. Touch > Sync now.
Changing an Account’s Sync Settings
1. Touch the Home key > > Settings > Accounts.
2. Touch the account category and then the account. The Sync screen appears, showing
a list of information the account can sync.
3. When Auto-sync data is enabled, switch items on or o as you need. The enabled
types of information will be kept in sync automatically between the phone and the
web. When Auto-sync data is disabled, touch a listing to sync that type of information
between the phone and the web.
Email
Touch the Home key > . Use it to read and send emails from Microsoft Exchange
ActiveSync, Gmail, Hotmail, Yahoo!®, and more.
Setting Up the First Email Account
1. Touch the Home key > .
2. Select an email server and enter the email address and password.
3. Touch NEXT to let the phone retrieve the network parameters automatically.
NOTE: You can also enter these details manually by touching MANUAL SETUP or if
automatic setup fails.
4. Follow the on-screen instructions to nish setup.
Your phone will show the inbox of the email account and start to download email
messages.
Checking Your Emails
Your phone can automatically check for new emails at the interval you set when setting
up the account.
You can also check new emails manually by dragging down on the message list. Touch
LOAD MORE at the bottom of the email list to download earlier messages.
Responding to an Email
You can reply to or forward a message that you receive. You can also delete messages
and manage them in other ways.
Web Accounts
Page 36
68 69
Replying to or Forwarding an Email
1. Open the email you want to reply to or forward from the Inbox.
2. Choose one of the following:
u To reply to the sender, touch .
u To reply to the sender and all recipients of the original message, touch .
u To forward the email to someone else, touch .
3. Edit your message and touch .
Marking an Email as Unread
You can return a read email to the unread state – for example, to remind yourself to read
it again later. You can also mark a batch of emails as unread.
• While reading a message, touch > Mark unread.
• While in a message list (for instance, the inbox), touch the sender image before the
message and then touch .
Deleting an Email
You can delete an email from its folder. You can also delete a batch of emails.
• While reading a message, touch .
• While in a message list (for instance, the Inbox), touch the sender image before the
message and then touch .
NOTE: If you accidentally delete an email, touch UNDO to retrieve it.
Writing and Sending an Email
1. Open your email Inbox and touch .
NOTE: If you have more than one email account added on the phone, touch the
From eld to select the account you want to use for sending the message.
2. Enter a contact name or email address in the To eld. Separate each recipient with a
comma. You can also touch + to select recipients from your contacts or history.
NOTE: To send a carbon copy or blind carbon copy to other recipients, touch
beside the To eld to open the Cc/Bcc elds and enter the contact names or email
addresses.
3. Enter the email subject and compose the email text.
4. Touch to add audio les, images, videos, and other types of les as attachments.
5. Touch at the top of the screen to send the message.
Adding a Signature to Your Emails
You can set a few lines of plain text as a signature for every outgoing email message
from an account, such as your name and contact information.
1. Open the Email app.
2. Touch > Settings and select the account you want to add a signature to.
3. Touch Signature and enter the text.
4. Touch OK.
Adding and Editing Email Accounts
Adding an Email Account
After setting up your rst email account (see Email – Setting Up the First Email Account),
you can add more email accounts and manage them separately.
1. Open the Email app.
2. Touch > Settings > Add account.
3. Set up the account as you did with the rst one.
Email Email
Page 37
70 71
Editing an Email Account
You can change a number of settings for an account, including how often you check for
email, how you’re notied of new emails, and details about the servers the account uses
to send and receive emails.
1. Open the Email app.
2. Touch > Settings and touch the account whose settings you want to change.
3. Make the changes you want and touch or the Back key when you’re nished.
Removing an Email Account
1. Open the Email app.
2. Touch > Settings and touch the account you want to remove.
3. Touch Remove account from this device > OK.
Changing General Email Settings
General settings apply to all email accounts you add.
1. Open the Email app.
2. Touch > Settings > General settings.
3. Make the changes you want and touch or the Back key when you’re nished.
Messaging
You can use Messaging to exchange text messages (SMS) and multimedia messages
(MMS).
Opening the Messaging Screen
Touch the Home key > .
The Messaging screen opens, where you can create a new message, search for messages,
or open an ongoing message thread.
• To uch to write a new text or multimedia message.
• To uch to search for a message using keywords.
• Touch an existing message thread to open the conversation.
Sending a Message
1. On the Messaging screen, touch .
2. Add recipients in one of the following ways.
u Manually enter the recipient’s number or the contact name. (You can touch to
enter numbers with a dialpad.) If the phone presents a few suggestions, touch the
one you want to add.
u Select recipients from your contacts by touching FREQUENTS or ALL CONTACTS
and touching a name.
u To add more recipients, enter another number or contact name, or touch to
select from your contacts.
3. Touch the Send message eld and enter the content of your text message.
4. If you want to send a multimedia message, touch to attach a le to the message.
5. Touch .
Email
Page 38
72 73
NOTES:
• You can also include email addresses as recipients for multimedia messages.
• Do not add any attachment if you want to send a text message. Otherwise you may
be charged for a multimedia message.
Replying to a Message
Messages you receive are appended to existing threads of the same number. If the new
message comes from a new number, a new thread is created.
1. On the Messaging screen, touch the thread that has the message you want to reply
to.
2. Type your reply in the text eld at the bottom. You can touch if you want to reply
with an MMS.
3. Touch .
Forwarding a Message
1. On the Messaging screen, touch the thread that has the message you want to
forward.
2. Touch and hold the message, and then touch .
3. Enter a recipient for the message and edit the content if needed.
4. Touch .
Deleting Messages or Threads
Deleting Messages in a Thread
1. On the Messaging screen, touch a thread.
2. Touch and hold a message you want to delete.
3. If there are more messages you want to delete, touch them one by one.
4. Touch > DELETE.
Deleting Message Threads
1. On the Messaging screen, touch and hold one thread you want to delete.
2. If there are more threads you want to delete, touch them one by one.
3. Touch > DELETE.
Changing Message Settings
Touch > Settings in the Messaging screen to change Messaging settings.
Messaging Messaging
Page 39
74 75
Calendar
Calendar on the phone works with the web-based Google Calendar™ service for creating
and managing events, meetings, and appointments. It also works with the Microsoft
Exchange ActiveSync calendar once you sign into your Exchange account on the phone.
To open Calendar, touch the Home key > > Calendar.
Viewing Your Calendars and Events
Selecting Visible Calendars
1. Open the Calendar app.
2. Touch > Calendars to display.
3. In the new screen, touch to check the calendars you want to see or uncheck the ones
you’d like to hide.
Events from hidden calendars are not shown in the Calendar app.
Changing Calendar Views
You can view your calendars in dierent forms. The app oers four view types: Month,
Week, Day, and Agenda.
To change calendar views, touch the current view at the top left and select the view you
prefer.
• In Month, Week, or Day view, swipe horizontally to see previous and future months,
weeks, or days.
• In Agenda view, swipe vertically to see all your events.
• When you are viewing past or future days, weeks, or months, touch at the top to
quickly switch to today. The number in the icon changes with the actual date.
• To quickly switch to a specic date, touch > Go to date, swipe horizontally to nd
the month you want, and touch a day > OK.
Viewing Event Details
In Agenda, Day, or Week view, touch an event to view its details.
In Month view, touch a day to view events on that day, and then touch an event to view
its details.
Creating an Event
1. In any Calendar view, touch to open an event details screen for a new event.
You can also touch a spot in Day or Week view twice to add an event to that time
spot.
NOTE: If you have more than one calendar, you can choose the calendar to which to
add the event by touching the current calendar above the Event name line.
2. Add details about the event. Dierent calendars may present dierent event details
elds for you to ll in.
3. Touch SAVE to save the new event.
NOTE: You can also create a new event by copying the details of an existing event. Just
open the event details screen and touch > Copy. Then edit the new event information
and touch SAVE.
Editing, Deleting, or Sharing an Event
1. Find the event you want to edit, delete, or share.
2. Open its details screen (see Calendar – Viewing Your Calendars and Events – Viewing
Event Details).
3. Choose one of the following options.
u To edit the event, touch . Touch SAVE to save your changes.
u To delete the event, touch > OK.
u To share the event, touch and choose how to share.
Calendar
Page 40
76 77
Changing Calendar Settings
To change Calendar settings, open a Calendar view (Day, Week, Month, or Agenda) and
then touch > Settings.
You can change General settings, which apply to all accounts, or other settings that only
apply to specic accounts.
• To add an email account, touch > Settings > to add a corporate or Google
account.
• For General settings, choose options for Calendar view setting and Notications &
reminders. You can choose to show the week number, set the day of the week the
calendar starts on, and use home time zone when you are travelling. You can also
choose event reminder settings such as notication sound, vibrate, default reminder
time, and more.
Searching an Event
Touch > Search event and then type the event in the Search eld, or touch to speak
out the event you want to search.
Browser
Use Browser to view web pages and search for information.
Opening the Browser
Touch the Home key > to launch the web browser. The Browser also opens when you
touch a web link – for example, in an email or a text message.
1. Open the Browser app.
2. Touch the address box at the top of the web page.
3. Enter the address (URL) of a web page, or enter terms you want to search for.
4. Touch a URL or search suggestion or touch the enter key on the keyboard to open
the web page or search results.
Setting the Home Page
Your home page opens when you open a new browser tab, and when you open Browser
after restarting your phone.
1. Open the Browser app.
2. Touch > Settings > Set homepage.
3. Enter the URL and touch OK to set it as the home page.
Using Multiple Browser Tabs
You can open several web pages at the same time (one page in each tab) and switch
between them freely.
Opening a New Browser Tab
Tou ch > ADD. A new browser tab opens and the home page is loaded.
Calendar
Page 41
78 79
Switching Between Browser Tabs
1. Touch (the number shows how many tabs you have opened).
2. Titles of opened tabs appear as a list. Touch a thumbnail to switch to that tab.
NOTE: Swipe a title horizontally or touch X to close the tab.
Downloading Files
1. Touch and hold an image or a link to a le or to another web page.
2. In the menu that opens, touch Save image or Save link.
The downloaded les are saved to your phone or the microSDXC card. You can view or
open them in the Downloads app.
Changing Browser Settings
You can congure a number of settings to customize the way you browse the web,
including several that you can use to control your privacy.
To open the Browser settings, touch > Settings in the browser screen.
Camera
You can take photos and record videos. Photos and videos are stored on the microSDXC
card, if you have installed one, or to the phone’s internal storage. You can copy them to
your computer or access them in the Gallery app.
Capturing a Photo
1. Touch the Home key > .
2. Aim the camera at the subject and make any necessary adjustment. PHOTO (auto
camera) mode is used by default.
3. Touch the area on the screen where you want the camera to focus, or let the camera
autofocus on the center of the image.
4. Lightly touch to take the picture.
Browser
Page 42
80 81
Number Function
1 Change the ash setting (back camera only).
2 Change the camera settings.
3 Change the HDR setting (back camera only).
4
Switch among the default PHOTO mode, VIDEO mode, and MANUAL
mode.
5 Exit the camera.
6 Select a lter.
7 Capture a photo.
8 View pictures and videos you have taken.
9
Use special photo or video camera modes: PANORAMA, MULTI
EXPOSURE, and TIMELAPSE.
10 Adjust the focus point and exposure.
11 Switch between the front and back cameras.
12
Set a time delay before the camera automatically takes a picture after
you touch the shutter icon.
WARNING! Keep a safe distance when using the ash. Do not point the ash toward the
eyes of people or animals.
NOTES:
• You can pinch or spread your ngers on the screen to zoom in or zoom out before
taking a picture.
• In PHOTO (auto camera) mode, when you touch the screen to focus, the exposure bar
appears beside the focus point. You can drag up or down to adjust the exposure.
• When you use the front camera, you can also touch to use smile detection.
Using Manual Camera Mode
You can use Manual camera mode to adjust more camera options for your photo, such as
ISO, white balance, and exposure.
1. Touch the Home key > > MANUAL.
2. Aim the camera at the subject> You can make the following adjustments.
u Drag the green circle to any area on the screen that you want to focus on. Touch
and hold it to lock the focus.
u Drag the yellow square to any area on the screen where you want the camera to
meter exposure so as to adjust the photo brightness. Touch and hold the square
to lock exposure.
u Touch to unfold more options, including ISO, overall exposure, white balance,
and interval for time-lapse pictures.
3. Touch to take the photo.
Camera Camera
Page 43
82 83
Using Other Camera Modes
Besides capturing photos and videos in the traditional way, your Camera app oers
other powerful and interesting camera modes. Touch in the viewnder screen to
nd them.
• PANORAMA: Capture panorama pictures.
• MULTI EXPOSURE: Capture multiple photos to create collages and special eects.
• TIMELAPSE: Set the time interval between each frame when you record time-lapse
videos with the back camera.
Recording a Video
1. Touch the Home key > > VIDEO.
2. Aim the camera at the subject and make any necessary adjustments. You can touch
any area on the screen that you want the camcorder to focus on before and during
recording.
3. Touch to start recording. You can also touch / to pause or resume recording,
or touch to save the frame as a photo.
4. Touch to stop recording.
NOTES:
• You can pinch or spread on the screen or press the Volume key to zoom in or zoom
out before and during recording.
• When you touch the screen to focus during recording, the exposure bar appears
beside the focus point. You can drag up or down to adjust the exposure. Touch
and hold the focus point to lock the focus.
• To capture a time-lapse video, touch > TIMELAPSE. Touch to begin
recording and to stop. You can also touch to save the frame as a photo.
Customizing Camera and Video Settings
Before capturing a photo or video, you can touch to open the following options.
NOTE: Some camera and video options will change in dierent camera modes.
Options in Photo Mode (Back Camera)
• Resolution: Set the resolution for your photo.
• Auto review: Adjust settings for auto review, which shows your photos immediately
after you take them so that you can delete or share them right away.
• Volume key: Assign the function of the Volume key.
Options in Sele Mode (Front Camera)
• Resolution: Set the resolution for your photo.
• Tap to capture: When enabled, allows you to touch the screen to take photos.
• Mirror image: When enabled, allows you to capture a photo that is the reverse of the
viewnder preview.
• Auto review: Adjust settings for auto review, which shows your photos immediately
after you take them so that you can delete or share them right away.
• Volume key: Assign the function of the Volume key.
Options in Video Mode (Front or Back Camera)
• Video quality: Set the quality for your video.
Camera Camera
Page 44
84 85
Options in Manual Mode (Back Camera)
• Resolution: Set the resolution for your photo.
• Metering: Adjust the light metering setting.
• Composition: Show or hide the grid or golden spiral to help with balanced photo
composition.
• Gradienter: Show or hide the gradienter.
• Auto review: Adjust settings for auto review, which shows your photos immediately
after you take them so that you can delete or share them right away.
• Volume key: Assign the function of the Volume key.
General Options
• Shutter tone: Turn the shutter tone on or o.
• Geo-tag: When enabled, store the GPS location in your captured photos and videos.
• Anti-banding: Set the anti-banding value when you take photos or record videos of
TV or computer screens to avoid stripes on the screen.
• Save location: Change the storage location for captured photos and videos.
• Help: Enable the Help icon on the viewnder screen, or touch More to view help
details.
• Restore defaults: Restore default camera and video settings.
Gallery
Opening Gallery
Touch the Home key > > Gallery to view albums of your pictures and videos.
Working With Albums
When you open Gallery, all pictures and videos on your phone are displayed. Touch
Timeline/Album to select view mode. Timeline displays contents in chronological order
and Album displays in a number of albums.
Viewing Album Contents
Touch an album to view the pictures and videos it contains.
Sharing Albums, Pictures, or Videos
1. Touch and hold an item in the Album view to select an album, or after you open an
album, to select a picture or a video.
2. Touch more items that you want to share.
3. Touch and select how you want to share the items.
Deleting Albums, Pictures, or Videos
1. Touch and hold an item in the Album view to select an album, or after you open an
album, to select a picture or a video.
2. Touch more items that you want to delete.
3. Touch > OK.
Camera
Page 45
86 87
Hiding Albums
1. Touch and hold an album to select it.
2. Touch more albums that you want to hide. The default Camera and Video albums
cannot be hidden.
3. Touch > OK.
NOTE: To show the hidden albums again, touch > Settings > Manage hidden albums.
Touch the albums you want to restore, and then touch Show.
Working With Pictures
Touch a picture in an album to view the picture in full screen. Double-tap the picture, or
pinch two ngers together or spread them apart to zoom out or in. Slide left or right to
view other pictures in the album.
Number Function
1 Touch to return to the album, where all its contents are displayed in a grid.
2 Delete the picture.
3 Edit the picture.
4 Share the picture.
5 View more options, such as rotate, rename, and print.
6 Add to favorites.
NOTES:
• Pinch a picture or video to make it smaller. You’ll then see a lmstrip-style view of all
your pictures and videos in a row. Swipe left or right to scan through them all.
• You can delete a picture or video by touching > OK or by swiping it up in the
lmstrip view. If you accidentally delete one by swiping it up, touch UNDO to retrieve
it.
• Not all options may be available for certain albums or pictures.
Retouching Your Pictures
You can edit any photos you took and some other pictures in Gallery with Photo Editor.
The changed picture is saved in the same album as the original one, while the orginal is
never aected.
1. While viewing a picture in full screen, touch the screen and touch > Photo Editor.
NOTE: You can also choose to edit the picture with Photos.
2. Touch the icons along the bottom of the screen to edit the picture.
Gallery Gallery
Page 46
88 89
Apply lters, old photo (nostalgia), and blur eects.
Crop, rotate, or ip (mirror) the picture.
Adjust exposure, contrast, shadows, sharpness, and other light options.
Adjust color of the picture.
Select a color and draw anything on the picture, or add some text or
mosaics to the picture and adjust the eect.
3. Touch to keep the change or to cancel it.
4. Touch to save the new picture.
NOTE: Touch in the Photo Editor screen to see the edits you have made and undo
or redo them.
Making a GIF or a Collage
You can put together a few pictures in the same album to make an animated GIF or a
collage of pictures.
1. Open the Gallery app and touch > GIF maker or Collage maker.
2. Touch an album.
3. Touch the pictures you want. You can exit the album and open other albums to add
more pictures.
u To make a GIF, touch 2 to 50 pictures in the order (or reverse of the order) that you
want them to appear in the GIF.
u To make a collage, touch 2 to 9 pictures.
The pictures you touched are displayed along the bottom of the screen. Touch to
remove the pictures you do not want.
4. Touch NEXT. The GIF or collage is displayed.
5. Touch the options along the bottom to adjust the nal picture.
u For GIF, you can adjust the speed, order, and size. Touch MORE to adjust each
picture, and then touch Manage Frame to add/remove pictures or adjust their
order.
u For collage, touch TEMPLATE, FREE, or COLLAGE and then select a border,
shading, and style.
6. When you are satised with the nal picture, touch to save the GIF or touch
to save the collage.
Depending on your storage setting, the picture is saved to the zte_editor/Save folder in
your phone storage or your microSDXC card.
Playing Videos
1. Touch an album in Gallery, and then touch the thumbnail of a video.
2. Touch at the center and select a player to start playing.
3. Touch the video to view the playback controls.
Gallery Gallery
Page 47
90 91
Music
Touch the Home key > > Music to play audio les stored on your phone. Music
supports a wide variety of audio formats, so it can play music you purchase from online
stores, music you copy from your CD collection, and more.
Viewing Your Music Library
Touch the Home key > > Music, and your music library is displayed. All your audio
les are cataloged according to the information stored in the les.
• Touch All Songs to view all music les on your phone.
• Touch Favorites to browse music les you have marked as favorites.
• Touch Playlists to view all music playlists you have created.
• Touch Artists or Albums to browse music les on your phone organized by the artist
or album name.
• Touch Folders to nd music les through the folders they are stored in.
NOTE: If an audio le is being played, its name and player controls are displayed at the
bottom of the screen. Touch the area to open the playback screen.
Setting a Song as the Default Ringtone
The song will be used as the ringtone for all incoming calls, except those from contacts
you have assigned special ringtones to (see Contacts – Editing Contacts – Setting a
Ringtone for a Contact).
1. Touch the Home key > > Music to see the music library.
2. Touch next to a song in any list.
3. In the menu that opens, touch Set as ringtone.
4. Touch Phone Ringtone or Notication Ringtone.
NOTE: If the song is being played and you’re in the playback screen, you can touch >
Set as ringtone and select Phone Ringtone or Notication Ringtone.
Playing Music
Touch a song in the music library to listen to it. Touch the playback bar at the bottom of
the screen to open the following playback screen.
Number Function
1 Song, album, and artist information.
2 Touch to go back to the music library.
3 Touch for track information.
4
Playback control. Skip songs or pause and resume playback. Drag the
slider to jump to any part of the song.
5 Turn shue on or o.
6
Toggle repeat mode: repeat the current song, repeat the playlist, or turn
o repeat.
7 Add the song to your favorites.
Music
Page 48
92 93
8 Album artwork (if available).
9 Access additional options.
10 Touch to see the current playlist.
You can still control the music when you are not in the playback screen.
• In other apps, swipe down the Notication Panel. Touch the song title to restore the
playback screen, or you can pause/resme playback or skip songs.
• When the screen is locked, the song information, album cover, and playback controls
are displayed on the screen. Touch the song title to restore the playback screen, or
you can pause/resume playback or skip songs.
Managing Playlists
Create playlists to organize your music les into sets of songs, so that you can play the
songs you like in the order you prefer.
• Touch > Add to playlist next to a song to add it to a playlist or create a new playlist.
• Touch > Delete next to a playlist to delete the playlist.
• Touch > Rename next to a playlist to rename the playlist.
• Touch a playlist to view its content. To delete a song, touch and hold the song. Touch
additional songs to select multiple songs for removal. Touch to remove the songs
from the playlist.
Video Player
Use the Video Player to manage your video library and to watch videos.
Opening the Video Library
Touch the Home key > > Video Player to view your video library. Swipe up or down
to nd the video you want. You can also touch to search for video les, or touch >
View by or Sort by to change the display mode or sort the list.
Playing and Controlling Videos
Touch a video in the video library to play it. Touch the screen to show the playback
controls. You can control the video and audio or carry out other operations.
Music
Page 49
94 95
Number Function
1 Return to the video library list.
2 Take a screenshot.
3 Change the video ratio (t to screen).
4
Playback control: Skip, pause, and resume playback. Drag the slider to
jump to any part of the video.
5 Rotate the video.
6 Hide video playback controls and lock the touch screen.
7 Share, delete, or trim the video, or congure player settings.
NOTES:
• Slide horizontally on the video to rewind or fast forward.
• Slide vertically on the right or left part of the screen to adjust volume or brightness,
respectively.
• Touch or to skip to the previous or the next video.
Managing Video Files
Deleting Videos
1. In the video library, touch > Multi-Select, or touch and hold a video.
2. Touch the videos you want to delete.
3. Touch > OK.
Sharing Videos
1. In the video library, touch > Multi-Select, or touch and hold a video.
2. Touch the videos you want to share.
3. Touch and select how you want to share them.
Trimming a Video
1. Touch a video to start playing it.
2. Touch > Trim.
3. Drag the two tabs on the progress bar to select the portion you want to keep. You
can touch to preview the selected portion.
4. Stop the preview and touch . The trimmed video is saved as a new video le.
Renaming a Video
1. Touch next to the video you want to rename.
2. Touch Rename.
3. Type the new video name and touch OK.
Viewing Details of a Video
1. Touch next to the video for which you want to view details.
2. Touch Details.
3. Touch CLOSE to close the window.
Video PlayerVideo Player
Page 50
96 97
Sound Recorder
Sound Recorder enables you to record voice memos and listen to them whenever you
like.
Recording a Voice Memo
1. Touch the Home key > > Sound Recorder.
2. Touch to turn on or o high quality recording.
3. Touch to start recording. Touch to pause and to continue recording.
4. Touch to stop recording. The memo is automatically saved.
Playing a Voice Memo
Playing a Memo You Just Recorded
Touch at the bottom of the screen.
Playing Any Saved Memo
1. Touch at the top right of the screen to see all recordings.
2. Touch the title of a memo to play it.
NOTE: You can also touch at the right of the memo to delete, share, rename, tag, or
trim it, check its le information, or set it as your phone ringtone or notication ringtone.
More Apps
Calculator
Touch the Home key > > Calculator to use the phone’s convenient built-in calculator
for some basic as well as advanced mathematical equations.
NOTE: To see more calculator options, swipe left while holding the phone in portrait
view or turn the phone to landscape view.
Clock
Touch the Home key > > Clock. The Clock app allows you to check local time in places
around the world, set alarms, and use timers.
Setting a New Alarm
1. Open the Clock app and touch .
2. Touch a default alarm to congure it, or touch at the bottom of the screen to
create a new alarm.
3. Set up the alarm options, such as time, alarm days, snooze, and alarm ringtone.
4. Touch Save to save and exit.
NOTES:
• To enable or disable existing alarms directly, touch the switches on the right side of
each alarm.
• Touch to congure alarm settings, including ringtone volume, vibration, alarm
duration, volume crescendo, and alarm in silent mode.
Page 51
98 99
Using World Time
1. Open the Clock app and touch .
2. World time lets you check local times for cities around the world. Touch to add a
new city.
Using Stopwatch and Countdown
1. Open the Clock app and touch or .
2. Stopwatch allows you to record lap times, while countdown allows you to set a time
and count down to zero.
Downloads
The Downloads app keeps a record of the les you have downloaded using apps such as
Browser or Email.
Touch the Home key > > Downloads.
• Touch a le to open it with the appropriate application.
• Touch and hold a le to delete or share it.
File Manager
Quickly access all of your images, videos, audio clips, and other types of les on your
phone and on the memory card.
Touch the Home key > > File Manager. Touch CATEGORY to nd the le you need
by category, or touch LOCAL to browse folders and les on the phone storage or the
microSDXC card.
• Touch folders and les to access stored items.
• Touch to create a new folder in the current directory.
• Touch to search for a le or folder by name.
• Press and hold a folder or le for options: copy , move , share , delete ,
and more options .
• To copy or move an item:
1. Touch and hold the folder or le.
2. Touch or .
3. Navigate to a new location within File Manager and touch PASTE.
Wi-Fi Utility
Wi-Fi Utility can manage your Wi-Fi settings to provide free and high-speed data by
automatically connecting your phone to reputable Wi-Fi hotspots.
Touch the Home key > > Wi-Fi Utility, and select a Wi-Fi settings option.
More AppsMore Apps
Page 52
100 101
Google Apps
NOTE: Some Google services may not be available in your region.
• Chrome: Use the Chrome app to browse the Internet and get your bookmarks,
browsing history, and more synced with your Google account.
• Drive: Store les on Google servers for free after you sign in to your Google account.
You can access them on your computers, your phones, and other devices, share them,
or collaborate with others.
• Duo: Make a simple video call which brings you face-to-face with all the people that
matter most.
• Gmail: Send and receive emails via your Gmail account or other personal email
accounts.
• Google: Use Google search or get information when you need it with Google Now.
• Maps: Find your place and nd your way in the world.
• Photos: Manage photos on the phone and your Google account.
• Play Movies & TV: Purchase, download and watch movies and TV shows.
• Play Music: Play music on the phone and on your Google account.
• Play Store: Buy and download apps, games, and more from the Google Play store.
• Voice Search: Search for information with your voice.
• YouTube: Watch video clips from YouTube.com, or upload your own and share with
the world.
Settings
Touch the Home key > > Settings. Settings contains most of the tools for
customizing and conguring your phone.
Wireless & Networks
Wi-Fi
Turn Wi-Fi on or o and congure your Wi-Fi connections (see Connecting to Networks
and Devices – Connecting to Wi-Fi).
Bluetooth
Turn Bluetooth on or o and congure your Bluetooth connections (see Connecting to
Networks and Devices – Connecting to Bluetooth Devices).
Mobile Networks
Control mobile data use, select network types or operators, and reset access point names
(see Connecting to Networks and Devices – Connecting to Mobile Networks).
Wi-Fi Hotspot
Share your phone’s mobile data connection with other devices via Wi-Fi (see Connecting
to Networks and Devices – Sharing Your Mobile Data Connection).
Data Usage
Check and manage mobile data use. You can view and restrict Wi-Fi data usage as well.
• Touch Data saver to enable Data Saver which prevents apps from using data
connection in the background. For an app you’re currently using, it can access
data, but may do so less frequently when Data Saver is enabled. You can also touch
Unrestricted data access and allow some apps to always have access to data
connection even when Data Saver is turned on.
More Apps
Page 53
102 103
• Touch the Cellular data switch to turn on or o mobile data.
• Touch Cellular data usage to check how much data has been used during the time
cycle you set, see what apps have been using mobile data, restrict background
data for individual apps, or allow unrestricted data usage when Data Saver is on for
individual apps.
• Touch Billing cycle to set the reset date of the data usage cycle, and set mobile data
warning and limit.
• Touch Wi-Fi data usage to view the Wi-Fi usage of apps.
• Touch Network restrictions to select Wi-Fi networks that are mobile hotspots. Apps
may warn before using these networks for large downloads to avoid high mobile
data bills.
NOTE: The data usage is measured by your phone, and your carrier’s data usage
accounting may dier.
Airplane Mode
In the Settings app, touch More > Airplane mode to turn airplane mode on or o. All
the phone’s radios that transmit voice or data are turned o when airplane mode is on.
Enhanced LTE Services
In the Settings app, touch More > Enhanced LTE Services to enable or disable HD voice
and advanced communication services when 4G LTE is available.
USB Tethering
In the Settings app, tap More > USB tethering to share your phone’s mobile data
connection with a PC via USB so that you can access the Internet on the PC using the
phone (see Connecting to Networks and Devices – Sharing Your Mobile Data Connection
–Sharing Your Mobile Data Connection via USB).
VPN
In the Settings app, tap More > VPN to set up and connect to virtual private networks
(see Connecting to Networks and Devices – Connecting to Virtual Private Networks).
Network Settings Reset
In the Settings app, tap More > Network settings reset > RESET SETTINGS to reset all
network settings, including Wi-Fi, mobile networks, and Bluetooth.
Device
Display
• Brightness level: Set the brightness of the display.
• Adaptive brightness: Automatically adjust screen brightness.
• Wallpaper: Select a background image or animation for the home screen or lock
screen.
• Sleep: Set the length of time of inactivity before the screen turns o automatically.
• Press power button twice for camera: Launch the Camera app by pressing the
Power key twice quickly, even when the screen is locked.
• Screen saver: Manage the Screen saver function, which can display colors or photos
when the phone is docked or charging.
• Ambient display: Wake the phone from sleep when new notications arrive.
• Font size: Set the font size of the text on the screen.
• Display size: Adjust the display size of items including fonts, icons and images on the
screen.
• When device is rotated: Select whether the screen contents should rotate when the
phone is rotated.
• Pulse notication light: Flash the backlight on the Home key to notify you of
missed calls, new messages, and other events.
SettingsSettings
Page 54
104 105
• Navigation key light duration: Control the backlight of the Home key, Back key,
and Recent Apps key. Choose one option to set the backlight duration.
Notications
Set dierent notication options for individual apps. Touch an app to block or mute
its notications, select its notication content to display on the lock screen, or let its
notications override your Do No Disturb settings.
Sound
Adjust dierent types of volume (see Personalizing – Adjusting Volumes), set notication
mode (see Personalizing – Switching to Silent or Vibration Mode), set Do not disturb
options (see Personalizing – Using Do Not Disturb Mode), set up ringtone and
notication sound (see Personalizing – Changing the Ringtone and Notication Sound),
set up default alarm sound, or select system sounds (see Personalizing – Turning System
Sounds On/O ).
Apps
Touch the Home key > > Settings > Apps to see apps installed on your phone and
manage them.
Touch > Show system/Hide system to show/hide system apps in the list.
Touch > Reset app preferences to reset all preferences. (You will not lose app data, but
app preferences will be restored to default.)
Touch to congure apps.
In the app list, touch an app to see its information. The following options may be
available:
• FORCE STOP: Stop the app.
• UNINSTALL: Uninstall the app.
• DISABLE/ENABLE: Disable or enable the app.
• Storage: Check the amount of storage required and clear its data or cache.
• Data usage: Check data used by the app during a specied time cycle, restrict
background data for the app, or allow unrestricted data access when Data Saver is on.
• Permissions: Check or change the app permissions.
• Notications: Manage the app notications in the Notication Panel and the lock
screen.
• Open by default: Check or change settings of the app links and clear defaults.
• Battery: Check the battery use details of the app since last full charge.
• Memory: Check how much memory has been used by the app.
• Draw over other apps: Allow the app to display on top of other apps that you’re
using.
• Modify system settings: Allow the app to modify system settings.
NOTE: Not all options are available for all apps.
Storage
The Storage settings menu lets you check memory information for your microSDXC card
and phone storage.
You can choose the default location for new data, such as photos captured and voice
recorded. Touch Save location and select to store items in the phone storage or the
installed microSDXC card.
Under Device storage, touch Device storage to get a detailed breakdown of space
usage by type. Touch a data type to see more information or delete the les you do not
need.
For more information about using the internal storage and the microSDXC card, see
Connecting to Networks and Devices – Using the microSDXC Card as Portable or Phone
Storage.
SettingsSettings
Page 55
106 107
Battery
View remaining battery power, check which items have been using the battery, and
optimize battery use.
• Touch an app or service to adjust its settings in order to save battery life. For example,
touch Screen > Reduce the screen brightness and/or screen timeout to change
screen brightness and sleep.
• Touch Battery saver. You can turn Battery saver on or o or congure it to turn on
automatically in order to reduce battery use and improve battery life.
• Touch > Battery optimization. Battery optimization helps prolong battery standby
time when you’re not using the phone. To turn battery optimization o for specic
apps, touch Not optimized > All apps. Touch the app name and then touch Don’t
optimize > DONE.
Memory
Monitor the average memory use and performance of your phone. You can also check
which apps use the most memory.
Call Settings
Congure call options. See Phone Calls – Adjusting Your Call Settings.
Connect to PC
Select your USB connection mode between your phone and PC (see Connecting to
Networks and Devices – Connecting to Your Computer via USB – Connecting Your Phone
to a Computer via USB).
Personal
Location
Activate location services to determine your location. To use location-related
applications, such as nding your location on Google Maps, you must have location
services turned on on your phone.
1. Touch the Home key > > Settings > Location.
2. Slide the Location switch to the On position to turn on location access.
3. When location access is enabled, touch Mode to select the location sources you want
to use. To get your accurate location, choose High accuracy. To save battery power
and get approximate location, choose Battery saving. To use only GPS to pinpoint
your location, choose Device only.
NOTE: Touch Accelerated Location or Google Location History to use Qualcomm®
IZat™ hardware accelerated location to determine your location or congure Google
location options.
Security
• Screen lock: Lock the screen with long press, pattern, PIN, or password (see
Personalizing – Protecting Your Phone With Screen Locks).
Touch beside Screen lock to set the following options.
u Make pattern visible: Show the pattern as you draw it. This option is available
when unlock pattern is set.
u Automatically lock: Set the time needed for the lock protection to be activated
after the screen turns o. This option is available when unlock pattern, PIN or
password is set.
u Power button instantly locks: Lock protection is activated immediately when
you press the Power key. This option is available when unlock pattern, PIN or
password is set.
SettingsSettings
Page 56
108 109
u Lock screen message: Set the text that you may display on the lock screen.
• Smart Lock: Keep the phone unlocked when connected to trusted devices, in trusted
places, or unlocked by trusted faces or voice, when recognizing trusted faces or
voices, or while being held or carried.
NOTE: You need to sign in to your Google account on the phone to use the Smart Lock
feature.
• Encrypt phone: Encrypt your accounts, settings, downloaded apps and data, media,
and other les (see Personalizing – Protecting Your Phone With Encryption).
• Set up SIM card lock:
- Lock SIM card: Activate or deactivate the PIN lock to require PIN before accessing
the nano-SIM card.
- Change SIM PIN: Change the PIN used to access the nano-SIM card.
NOTE: Put all your condential passwords in a safe place for future use. If you enter the
wrong SIM PIN more times than allowed, your nano-SIM card will be locked and you
cannot access the mobile phone network. Contact your operator for a PIN Unlock Key
(PUK) to restore the nano-SIM card.
• Make passwords visible: Display passwords as you enter them.
• Device administrators: View or deactivate apps you have authorized to be device
administrators.
• Unknown sources: Permit installation of apps from sources other than the Play
Store.
• Storage type: Check the credential storage type.
• Trusted credentials: Display trusted CA certicates.
• User credentials: View and modify stored credentials.
• Install from SD card: Install certicates from the internal storage or the microSDXC
card.
• Clear credentials: Delete all certicates.
• Trust agents: View or deactivate trust agents.
• Screen pinning: Keep a screen of your choice in view so that others cannot switch
to other apps and access personal information (see Personalizing – Protecting Your
Phone With Screen Pinning).
• Apps with usage access: Turn on or o some apps’ access to your phone usage
information.
Accounts
Manage your accounts and synchronization. Touch Add account to sign in to or create
accounts on your phone.
Touch an account type to see that type of accounts you have added and adjust their
settings.
Google
Manage settings for Google apps and services that are installed on your device.
Languages and Input
• Languages: Select a language for your system.
• Spell checker: Activate Google Spell Checker to check for spelling errors when
entering text, and change its settings.
• Personal dictionary: Add new words to the phone’s dictionary or remove words
from the dictionary. The words you add are used for spelling check and word
suggestion.
• Keyboard & input methods: Congure text input settings (see Knowing the Basics –
Entering Text – Changing Input Methods).
SettingsSettings
Page 57
110 111
• Text-to-speech output: Select the speech synthesis engine or change its settings,
set speech rate and pinch, play a brief sample of the speech synthesizer, and check
whether the text-to-speech output feature supports the current system language.
• Pointer speed: Select how fast the pointer/mouse should scroll when you connect
the phone to a trackpad or mouse accessory.
Navigation Key
You can swap the positions of the Back key and the Recent apps key. Select an option to
make the switch.
Backup & Reset
• Back up my data: Back up app data, Wi-Fi passwords, and other settings to Google
servers after you sign in to your Google account.
• Backup account: Set the Google account that the data is backed up to.
• Automatic restore: Restore previously backed up settings and data when you
reinstall an app.
• Factory data reset: Reset your phone to factory default settings. All your personal
data from the phone’s internal storage will be erased. You can also erase the data on
the microSDXC card during the process.
System
Date & Time
Set date, time, time zone, and how time is displayed. You can also use network-provided
data (see Personalizing – Setting the Date and Time).
Accessibility
Congure the system accessibility options and accessibility plug-ins on your phone, such
as using Color inversion or Font size for users with sight problems.
Printing
Congure Google Cloud Print service or other printer plug-ins installed from the Google
Play Store or your printer manufacturer.
About Phone
View phone status, legal information, and other information. Touch Software Update >
Check for Updates to check for available software updates for your phone.
Settings Settings
Page 58
112 113
Upgrading the Phone Software
There are several ways to upgrade your phone software.
1. Use the online upgrade tool for mobile terminal products.
2. Use the one-press upgrade package oered by your mobile service provider.
3. Use your PC to download and upgrade package to your microSDXC card and install it
to your phone from the card.
NOTE: Visit the ZTE ocial handset service support website Z-Community (https://
community.zteusa.com) to learn more about the above upgrade methods, as well as
which phones and methods are supported.
Troubleshooting
If you encounter problems while using the phone, or if it performs abnormally, you
can refer to the chart below. If your particular problem cannot be resolved using the
information in the chart, contact the dealer where you purchased the phone.
Problem Possible Causes Possible Solution
Poor reception
The network signal is too weak at
your current location (for example,
in a basement or near a tall building)
because wireless transmissions cannot
eectively reach it.
Move to a location where the
network signal can be properly
received.
The network is busy at the current
time (for example, during peak times,
there may be too much network trac
to handle additional calls).
Avoid using the phone at such
times, or try again after waiting
a short time.
You are too far away from a base
station for your service provider.
You can request a service
area map from your service
provider.
Echo or noise
Poor network link quality on the part
of your service provider.
End the call and dial again.
You may be switched to a
better-quality network link or
phone line.
Poor local telephone line quality.
End the call and dial again.
You may be switched to a
better-quality network link or
phone line.
Page 59
114 115
Problem Possible Causes Possible Solution
Unable to
select certain
features
Your service provider does not support
these features, or you have not
applied for services that provide these
features.
Contact your service provider.
Cannot charge
the battery
The battery or battery charger is
damaged.
Contact the dealer.
The phone’s temperature is below 32°F
(0°C) or higher than 113°F (45°C).
Adjust the battery charging
environment to avoid
extremes of temperature.
Poor contact between the battery and
charger.
Check all connectors to ensure
that all connections have been
properly made.
Problem Possible Causes Possible Solution
Shortened
standby time
The standby time is related to your
service provider system conguration.
The same phone used with dierent
service providers’ systems will not
provide exactly the same length of
standby time.
If you are located in an area
where signaling is weak,
temporarily power o the
phone.
The battery is depleted. In high
temperature environments, battery life
will be shortened.
Contact the dealer to change a
new battery.
If you are not able to connect to the
network, the phone will continue
to send out signals as it attempts
to locate a base station. Doing so
consumes battery power and will
consequently shorten standby time.
Change your location to
one where the network is
accessible, or temporarily turn
o your phone.
Cannot turn
your phone on
Battery power has been depleted. Recharge the phone’s battery.
nano-SIM card
error
The nano-SIM card has malfunctioned
or is damaged.
Take the nano-SIM card to your
service provider for testing.
The nano-SIM card is inserted
improperly.
Insert the nano-SIM card
properly.
Debris is on the nano-SIM card
contacts.
Use a soft, dry cloth to clean
the nano-SIM card contacts.
Troubleshooting Troubleshooting
Page 60
116 117
Problem Possible Causes Possible Solution
Unable to
connect to the
network
The nano-SIM card is invalid. Contact your service provider.
You are not within the network’s
service area.
Check the service area with
your service provider.
Poor signal.
Move to an open space, or if
you are inside a building, move
closer to a window.
Cannot make
outgoing calls
You have activated the Fixed Dialing
Numbers feature.
Disable this feature. See Phone
Calls – Adjusting Your Call
Settings – Using Fixed Dialing
Numbers.
PIN Code
blocked
You have entered an incorrect PIN
code three consecutive times.
Contact your service provider.
If the service provider provides
the nano-SIM card’s PUK code,
use the PUK code to unlock the
nano-SIM card.
Phone crashes,
reboots, freeze,
or cannot be
powered on
Some third-party software is not
compatible with your phone.
Uninstall the software that
may cause the problem.
Upgrade the phone software.
Reset the phone to factory
status.
For Your Safety
General Safety
Don’t make or receive
handheld calls while driving.
Never text while driving.
Don’t use at gas stations.
Keep your phone at least 10
mm away from your body
while making calls.
Your phone may produce a
bright or ashing light.
Small parts may cause choking.
Don’t dispose of your phone
in re.
Your phone can produce a
loud sound.
To prevent possible hearing
damage, do not listen at high
volume levels for long periods.
Avoid contact with anything
magnetic.
Avoid extreme temperatures.
Keep away from pacemakers
and other electronic medical
devices.
Avoid contact with liquids.
Keep your phone dry.
Power o when asked to in
hospitals and medical facilities.
Don’t take your phone apart.
Power o when told to in
aircrafts and airports.
Only use approved
accessories.
Power o when near explosive
materials or liquids.
Don’t rely on your phone for
emergency communications.
Troubleshooting
Page 61
118 119
Radio Frequency (RF) Energy
This phone is designed and manufactured not to exceed the emission limits for exposure
to radio frequency (RF) energy set by the Federal Communications Commission of the
United States.
During SAR testing, this device was set to transmit at its highest certied power level in
all tested frequency bands, and placed in positions that simulate RF exposure in usage
against the head with no separation, and near the body with the separation of 10 mm.
Although the SAR is determined at the highest certied power level, the actual SAR level
of the device while operating can be well below the maximum value. This is because
the phone is designed to operate at multiple power levels so as to use only the power
required to reach the network. In general, the closer you are to a wireless base station
antenna, the lower the power output.
The exposure standard for wireless devices employing a unit of measurement is known
as the Specic Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg.
This device is complied with SAR for general population /uncontrolled exposure limits
in ANSI/IEEE C95.1-1992 and had been tested in accordance with the measurement
methods and procedures specied in IEEE1528.
The FCC has granted an Equipment Authorization for this model phone with all reported
SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on le with the FCC and can be found under the
Display Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID: SRQ-Z719DL.
For this device, the highest reported SAR value for usage against the head is 0.64 W/kg,
for usage near the body is 1.01 W/kg.
While there may be dierences between the SAR levels of various phones and at various
positions, they all meet the government requirements.
SAR compliance for body-worn operation is based on a separation distance of 10 mm
between the unit and the human body. Carry this device at least 10 mm away from your
body to ensure RF exposure level compliant or lower to the reported level. To support
body-worn operation, choose the belt clips or holsters, which do not contain metallic
components, to maintain a separation of 10 mm between this device and your body.
RF exposure compliance with any body-worn accessory, which contains metal, was not
tested and certied, and using such body-worn accessory should be avoided.
FCC Regulations
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
CAUTION: Changes or modications not expressly approved by the manufacturer could
void the user’s authority to operate the equipment.
The antenna(s) used for this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
NOTE: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined
by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
For Your Safety For Your Safety
Page 62
120 121
Hearing Aid Compatibility (HAC) regulations for Mobile Phones
In 2003, the FCC adopted rules to make digital wireless telephones compatible with
hearing aids and cochlear implants. Although analog wireless phones do not usually
cause interference with hearing aids or cochlear implants, digital wireless phones
sometimes do because of electromagnetic energy emitted by the phone’s antenna,
backlight, or other components. Your phone is compliant with FCC HAC regulations
(ANSI C63.19- 2011). While some wireless phones are used near some hearing devices
(hearing aids and cochlear implants), users may detect a buzzing, humming, or whining
noise. Some hearing devices are more immune than others to this interference noise and
phones also vary in the amount of interference they generate. The wireless telephone
industry has developed a rating system for wireless phones to assist hearing device
users in nding phones that may be compatible with their hearing devices. Not all
phones have been rated. Phones that are rated have the rating on their box or a label
located on the box. The ratings are not guarantees. Results will vary depending on the
user’s hearing device and hearing loss. If your hearing device happens to be vulnerable
to interference, you may not be able to use a rated phone successfully. Trying out the
phone with your hearing device is the best way to evaluate it for your personal needs.
This phone has been tested and rated for use with hearing aids for some of the wireless
technologies that it uses. However, there may be some newer wireless technologies used
in this phone that have not been tested yet for use with hearing aids. It is important to
try the dierent features of this phone thoroughly and in dierent locations, using your
hearing aid or cochlear implant, to determine if you hear any interfering noise. Consult
your service provider or the manufacturer of this phone for information on hearing aid
compatibility. If you have questions about return or exchange policies, consult your
service provider or phone retailer.
M-Ratings: Phones rated M3 or M4 meet FCC requirements and are likely to generate
less interference to hearing devices than phones that are not labeled. M4 is the better/
higher of the two ratings.
T-Ratings: Phones rated T3 or T4 meet FCC requirements and are likely to be more
usable with a hearing device’s telecoil (“T Switch” or “Telephone Switch”) than unrated
phones. T4 is the better/ higher of the two ratings. (Note that not all hearing devices
have telecoils in them.)
Your Z719DL has been tested for hearing aid device compatibility and has an M4/T3
rating.
Hearing devices may also be measured for immunity to this type of interference. Your
hearing device manufacturer or hearing health professional may help you nd results for
your hearing device.
For additional information about the FCC’s actions with regard to hearing aid compatible
wireless devices and other steps the FCC has taken to ensure that individuals with
disabilities have access to telecommunications services, please go to www.fcc.gov/cgb/
dro.
CTIA Requirements
• Do not disassemble or open, crush, bend or deform, puncture or shred the battery.
• Do not modify or remanufacture, attempt to insert foreign objects into the battery,
immerse or expose to water or other liquids, expose to re, explosion or other hazard.
• Only use the battery for the system for which it is specied.
• Only use the battery with a charging system that has been qualied with the system
per CTIA Certication Requirements for Battery System Compliance to IEEE 1725. Use
of an unqualied battery or charger may present a risk of re, explosion, leakage, or
other hazard.
• Do not short circuit the phone or allow metallic conductive objects to contact the
charging terminals.
• Replace the battery only with another battery that has been qualied with the
system per this standard, IEEE-Std-1725. Use of an unqualied battery may present a
risk of re, explosion, leakage or other hazard. Only authorized service providers shall
replace the battery. (If the battery is non-user replaceable).
For Your Safety For Your Safety
Page 63
122 123
• Promptly dispose of used batteries in accordance with local regulations.
• Battery usage by children should be supervised.
• Avoid dropping the phone. If the phone is dropped, especially on a hard surface, and
the user suspects damage, take it to a service center for inspection.
• Improper battery use may result in a re, explosion or other hazard.
• The phone shall only be connected to CTIA certied adapters, products that bear the
USB-IF logo or products that have completed the USB-IF compliance program.
Distraction
Driving
Full attention must be given to driving at all times in order to reduce the risk of an
accident. Using a phone while driving (even with a hands free kit) can cause distraction
and lead to an accident. You must comply with local laws and regulations restricting the
use of wireless devices while driving.
Operating Machinery
Full attention must be given to operating the machinery in order to reduce the risk of an
accident.
Product Handling
General Statement on Handling and Use
You alone are responsible for how you use your phone and any consequences of its use.
You must always switch o your phone wherever the use of a phone is prohibited.
Use of your phone is subject to safety measures designed to protect users and their
environment.
• Always treat your phone and its accessories with care and keep them in a clean place.
• Keep the screen and camera lens clean. Unclean screen or camera lens may slow
down the phone’s reaction to your operations or lower image quality.
• Clean your phone and its accessories with a soft material such as cleaning cloth for
eyeglass lenses. Do not use alcohol or other corrosive substances for cleaning or
allow them to get inside.
• Do not expose your phone or its accessories to open ames or lit tobacco products.
• Do not expose your phone or its accessories to liquid, moisture or high humidity.
• Do not drop, throw or try to bend your phone or its accessories.
• Do not use harsh chemicals, cleaning solvents, or aerosols to clean the device or its
accessories.
• Do not paint your phone or its accessories.
• Do not attempt to disassemble your phone or its accessories. Only authorized
personnel can do so.
• Do not expose or use your phone or its accessories in an environment with or that
can reach extreme temperatures, minimum 23°F (-5°C) and maximum 122°F (+50°C).
• Do not place your phone inside or near heating equipments or high-pressure
containers, such as water heaters, microwave ovens, or hot cooking utensils.
Otherwise, your phone may be damaged.
• Please check local regulations for disposal of electronic products.
• Do not carry your phone in your back pocket as it could break when you sit down.
Small Children
Do not leave your phone and its accessories within the reach of small children or allow
them to play with it. They could hurt themselves or others, or could accidentally damage
the phone. Your phone contains small parts with sharp edges that may cause an injury or
may become detached and create a choking hazard.
Demagnetization
To avoid the risk of demagnetization, do not allow electronic devices or magnetic media
For Your Safety For Your Safety
Page 64
124 125
close to your phone for a long time.
Electrostatic Discharge (ESD)
Do not touch the nano-SIM/SD card’s metal connectors.
Antenna
Do not touch the antenna unnecessarily.
Normal Use Position
When placing or receiving a phone call, hold your phone to your ear, with the bottom
towards your mouth.
Air Bags
Do not place a phone in the area over an air bag or in the air bag deployment area as
an airbag inates with great force and serious injury could result. Store the phone safely
before driving your vehicle.
Seizures/Blackouts
The phone can produce a bright or ashing light. A small percentage of people may
be susceptible to blackouts or seizures (even if they have never had one before) when
exposed to ashing lights or light patterns such as when playing games or watching
video. If you have experienced seizures or blackouts or have a family history of such
occurrences, please consult a physician. To reduce the risk of blackouts or seizures, you
can use your phone in a well-lit room and take frequent breaks.
Repetitive Strain Injuries
To minimize the risk of Repetitive Strain Injury (RSI) when texting or playing games with
your phone:
• Do not grip the phone too tightly.
• Press the buttons lightly.
• Use the special features which are designed to minimize the times of pressing
buttons, such as Message Templates and Predictive Text.
• Take frequent breaks to stretch and relax.
Emergency Calls
This phone, like any other wireless phone, operates using radio signals, which cannot
guarantee connection in all conditions. Therefore, you should not rely solely on any
wireless phone for emergency communications.
Loud Noise
This phone is capable of producing loud noises, which may damage your hearing. Turn
down the volume before using headphones, Bluetooth headsets or other audio devices.
Phone Heating
Your phone may become warm during charging and normal use.
Electrical Safety
Accessories
Use only approved accessories. Do not connect with incompatible products or
accessories. Take care not to touch metallic objects, such as coins or key rings, or allow
them to contact or short-circuit the charging jack terminals. Never puncture the surface
of the phone with sharp objects.
Connection to Vehicles
Seek professional advice when connecting a phone interface to the vehicle electrical
system.
For Your Safety For Your Safety
Page 65
126 127
Faulty and Damaged Products
Do not attempt to disassemble the phone or its accessories. Only qualied personnel can
service or repair the phone or its accessories. If your phone (or its accessories) has been
submerged in water, punctured, or subjected to a severe fall, do not use it until you have
taken it to be checked at an authorized service center.
Radio Frequency Interference
General Statement on Interference
Care must be taken when using your phone in close proximity to personal medical
devices, such as pacemakers and hearing aids. Please consult your doctor and the device
manufacturers to determine if the operation of your phone may interfere with the
operation of your medical devices.
Pacemakers
Pacemaker manufacturers recommend that a minimum separation of 6 inches (15
cm) be maintained between a mobile phone and a pacemaker to avoid potential
interference with the pacemaker. To achieve this, use the phone on the opposite ear to
your pacemaker and do not carry it in a breast pocket.
Hearing Aids
People with hearing aids or other cochlear implants may experience interfering noises
when using wireless devices or when one is nearby. The level of interference will depend
on the type of hearing device and the distance from the interference source. Increasing
the separation between them may reduce the interference. You may also consult your
hearing aid manufacturer to discuss alternatives.
Medical Equipment
Turn o your wireless device when you are requested to do so in hospitals, clinics or
healthcare facilities. These requests are designed to prevent possible interference with
sensitive medical equipment.
Aircraft
Turn o your wireless device whenever you are instructed to do so by airport or airline
sta. Consult the airline sta about the use of wireless devices onboard the aircraft and
enable airplane mode of your phone when boarding an aircraft.
Interference in Vehicles
Please note that because of possible interference to electronic equipment, some vehicle
manufacturers forbid the use of mobile phones in their vehicles unless a hands-free kit
with an external antenna is included in the installation.
Explosive Environments
Gas Stations and Explosive Atmospheres
In locations with potentially explosive atmospheres, obey all posted signs to turn o
wireless devices such as your phone or other radio equipment. Areas with potentially
explosive atmospheres include fueling areas, below decks on boats, fuel or chemical
transfer or storage facilities, areas where the air contains chemicals or particles, such as
grain, dust, or metal powders.
Blasting Caps and Areas
Power o your mobile phone or wireless device when in a blasting area or in areas where
signs are posted to power o “two-way radios” or “electronic devices” to avoid interfering
with blasting operations.
WARNING: This product can expose you to chemicals including Carbon
Black, which is known to the State of California to cause cancer, and Toluene,
which is known to the State of California to cause birth defects or other
reproductive harm. For more information go to www.P65Warnings.ca.gov.
For Your Safety For Your Safety
Page 66
128 129
Specications
Handset specications are shown in the following table.
Operating System Android 7.1 (Nougat)
Handset standard LTE/UMTS/GSM/CDMA
Dimensions 6.14’(H) x 3.03’(W) x 0.37’(D)
Weight 6.0 oz. (with battery)
Display 5.5” 720x1280
Camera Front 2 MP; Back 8 MP
Internal memory ROM: 16 GB, RAM: 2 GB
Removable memory card Supports microSDXC card up to 128 GB
Battery 3200 mAh (non-removable)
Continuous idle time Up to 6 days
Continuous talk time Up to 18 hours
WAP browser version WAP 2.0
HAC M4/T3
Bluetooth BT 4.1
NOTE: The phone’s talk time and idle time are based on ideal working environments. The
use of extended backlighting, browser, and network conditions can reduce battery life
and talk/idle time.
Notes
Page 67
130
Loading...
