Zingo Move User Manual

move
move
USER
MANUAL
Your ZINGO MOVE warranty
must be registered online within
7 days of purchase.
To activate your warranty visit www.tevo.co.za, click the “Outdoor” tab,
then click the “ZINGO MOVE” icon, then click the “Register Your Warranty” link.
Fill in your details, enter the serial number (found near the charging port)
CONTENTS
PAGE 1 Contents & Service Centres
PAGE 2 Riding conditions & appropriate apparel
PAGE 3 Familiarizing yourself with your ZINGO MOVE
PAGE 4 How to ride your ZINGO MOVE
PAGE 5 How to ride your ZINGO MOVE continued
PAGE 6 How to ride your ZINGO MOVE continued
PAGE 7 Charging your ZINGO MOVE battery
PAGE 8 ZINGO MOVE key
PAGE 9 ZINGO MOVE travelling distance
PAGE 9 Storing and maintaining your ZINGO MOVE
PAGE 10 Trouble shooting
PAGE 11 Limited warranty
CAUTION
READ AND UNDERSTAND ALL ASPECTS OF THIS USER MANUAL BEFORE
ATTEMPTING TO RIDE YOUR ZINGO MOVE. KEEP THIS USER MANUAL
FOR FUTURE REFERENCE.
SERVICE CENTRES
Our nationwide Service Centres carry spares and back-up parts for your ZINGO MOVE. For best long-term performance it is highly recommended that you visit your nearest Service Centre to give your ZINGO MOVE a service every 3 months. Please call 0861 77 88 88 or email info@tevo.co.za to get further information on your nearest Service Centre.
1.
RIDING CONDITIONS & APPROPRIATE APPAREL
Make sure to use protective gear in the form of elbow and knee pads as well as a helmet and appropriate footwear. Gloves and goggles are recommended.
Riders will become accustomed to riding the ZINGO MOVE over time. Accidents can occur when given to someone who has never ridden a ZINGO MOVE before. Exercise caution when allowing a first time rider to get onto the ZINGO MOVE. The rider should be instructed on how to ride the ZINGO MOVE (see full details on “HOW TO RIDE YOUR ZINGO MOVE” on page 4).
Use caution when riding and make sure to always be aware of your surroundings so as to avoid any pedestrians, other riders, animals or fixed obstacles that may cause you, or you may cause, any injury. The ZINGO MOVE is not designed to withstand any extreme manoeuvres. Do not attempt to perform any tricks, bunny hops or any
other extreme manoeuvres on the ZINGO MOVE. Evidence of such abuse will render your warranty void.
Assess riding conditions before making use of the ZINGO MOVE, and do not ride through any gravel, mud, water, sand or on any off-road surface. Do not ride your
ZINGO MOVE in the rain, or through any adverse weather conditions. The electri­cal and drive components could be damaged by riding through the aforementioned elements or surfaces and will render your warranty void.
WARNING
The ZINGO MOVE is not intended to be used on public roads where there are cars, buses, taxis or any other licensed motor vehicles. Make sure to familiarize yourself with the traffic rules and regulations in your area to determine where it is safe for you to ride your ZINGO MOVE .
Riding the ZINGO MOVE can result in serious injury or even death regardless of the ability of the rider, any factory fault, any precautions taken or conditions in which they (the rider) were riding in. Make sure that you are both able and competent to handle the ZINGO MOVE. Parents should be made aware that the ZINGO MOVE is not for children under the age of 7, or weighing less than 20kg and further still, that riders above this age and weight should show a suitable degree of awareness, skill and ability to handle a ride-on of this nature.
The maximum weight limit of the rider is 125kg and the minimum weight limit is 20kg. The ZINGO MOVE is designed for only one rider at a time.
2.
FAMILIARIZING YOURSELF WITH YOUR ZINGO MOVE
1 - Right rubber foot pad / sensor pedal
2 - Left rubber foot pad / sensor pedal
3 - Battery indicator light
4 - Smooth-ride hollow tyres
5 - Indicator lights (front)
6 - Power button (back)
7 - Charging port
8 - Charger
9 - Charger jack
10 - Charger plug
11 - Key
12 - Carry bag
1
3
FRONT VIEW
2
5
4
11
6
BACK VIEW
7
8
9
10
12
3.
HOW TO RIDE YOUR ZINGO MOVE
• Place the ZINGO MOVE on a flat surface in front of you with the indicator lights
facing forward. Make sure your ZINGO MOVE is charged
• Turn your ZINGO MOVE on by pressing the circular power button
• For first time riders we suggest that you get a second person to stand at your
side and offer you their arm to help you balance during this early stage
• Place one foot on the rubber foot pad of the ZINGO MOVE so that all of your
weight is directed perpendicular to the ground
• Now place your other foot on the other foot pad making sure that all of your
weight is directed straight downward (it’s important that the second person
assists you in balancing)
• IMPORTANT: DO NOT TRY TO BALANCE AT THIS STAGE – The ZINGO MOVE
incorporates an intelligent gyrostabilizer that responds to your every move, if
you lean forward you will move forward, if you lean backward you will move
backward. If you sway front and back then the ZINGO MOVE will respond with
rapid front and backward motion which could cause you to fall
• The best thing to do at this stage is to simply stand as still as possible
• Once you have got a good feeling of how your ZINGO MOVE responds you can begin
to slowly tilt your feet downward to move forward, and upward to move backward.
You should still be using a friends assistance to help you balance in case you lose control
• Continue to practice this front and backward motion until you feel comfortable
enough that you can turn
• To turn right, simply point your right foot downward whilst keeping your left foot level
• To turn left, point your left foot downward whilst keeping your right foot level
• As your confidence grows you can begin to increase the speed of your
movements
• To move faster in a forward direction tilt your feet forward a little more and to
move backward in a faster motion tilt your feet a little more backward
• You can now incorporate turning as you move forward or backward
• To step off, first bring the ZINGO MOVE to a standstill. Keep your weight
centred and step backward whilst keeping your strongest foot on the ZINGO
MOVE and transferring all your weight onto the foot on the ground behind the
ZINGO MOVE in one fluid movement. Do not attempt to step off the front
of the ZINGO MOVE as it may suddenly move forwards causing you to fall
• To switch off your ZINGO MOVE, press the circular power button
• Your ZINGO MOVE will automatically shut off if it has not been used for 4 minutes
• If your ZINGO MOVE is not level it will give a warning beep. Step off your ZINGO
MOVE and move to smooth, level ground
4.
HOW TO RIDE YOUR ZINGO MOVE
The ZINGO MOVE’s intelligent gyrostabilizer responds to where the most weight is placed, if you lean forward you will move forward, if you lean backward you will move backward.
Keep your body centred over the middle of the ZINGO MOVE. Do not ride your ZINGO MOVE on any inclined surface that will cause pressure to transfer to one
side. Your ZINGO MOVE will give a warning beep if it is not level.
5.
HOW TO RIDE YOUR ZINGO MOVE
To turn right, point your right foot downward whilst keeping your left foot level.
To turn left, point your left foot downward whilst keeping your right foot level.
6.
CHARGING YOUR ZINGO MOVE BATTERY
When the battery indicator light on the top of your ZINGO MOVE flashes red, or if you notice that your ZINGO MOVE’s performance is reduced, you must recharge the battery. To charge, place the charger plug the into the wall socket and the charger jack into the ZINGO MOVE’s charging port, located on the back left-hand side of the ZINGO MOVE next to the power button. Make sure to line up the notch on the jack with the groove on the charging port. The light on the top of the charger will glow red while charging. When it turns green your battery is fully charged - unplug the charger immediately.
IMPORTANT - BATTERY CARE
In order to take good care of your ZINGO MOVE’s battery, ensure that you adhere to the following:
• Always remove the charger as soon as the charger indicator light turns green
• DO NOT charge your ZINGO MOVE for longer than 2 hours at a time as this will damage the battery and void your warranty
• Charge your ZINGO MOVE once every 2 weeks. This will maintain the range and power of your battery
FAILURE TO ADHERE TO THE POINTS ABOVE WILL RENDER YOUR WARRANTY VOID.
Do not expose batteries to fire as they may leak or explode and may injure those close by and/or cause damage to nearby surroundings. Consult your local authorities for information on how to dispose of your batteries.
7.
ZINGO MOVE KEY
Your ZINGO MOVE is supplied with a nifty remote control key. Please keep this in a safe place. The key allows you to lock, unlock, switch off, control the lights, choose between 2 modes, reset or balance your ZINGO MOVE.
SWITCH OFF:
To switch off your ZINGO MOVE when you are not riding, press the button.
LOCKING:
To lock your ZINGO MOVE when you are not riding, press the button. Your ZINGO MOVE is now in standby mode. To unlock, simply press the button again. Note: You can also unlock your ZINGO MOVE by turning it off and on again using the power button on the back of the ZINGO MOVE.
CONTROLLING THE LIGHTS:
To switch the front indicator lights on or off while riding your ZINGO MOVE, press the button.
BEGINNER AND ADVANCED MODES:
Press the “MODE” button to choose between beginner and advanced modes. In beginner mode the ZINGO MOVE will be easier to ride because the speed is limited. In advanced mode the ZINGO MOVE will allow for faster movements.
RESETTING YOUR ZINGO MOVE:
In the event that there is an unexpected error, you can reset your ZINGO MOVE as follows: Press the button once. Then press both the and the “MODE” button at the same time for two seconds. This will restore the factory settings.
BALANCING YOUR ZINGO MOVE:
If your ZINGO MOVE begins to feel unbalanced or shudders after long periods of use, it may need to be balanced as follows: Place your ZINGO MOVE on a flat surface and ensure that both sides of your ZINGO MOVE are horizontal. Then press both the and the “MODE” button at the same time for two seconds. Your ZINGO MOVE’s gyroscope will be balanced again.
8.
ZINGO MOVE TRAVELLING DISTANCE
The maximum travel distance of your ZINGO MOVE will depend on several factors, including:
Terrain: Smooth, flat ground will increase travel distance. Rough or bumpy ground will reduce travel distance. Do not use your ZINGO MOVE on gravel, mud, water, sand or on any off-road surface. Do not ride your ZINGO MOVE in the rain, or through any adverse weather conditions
Rider weight: A light rider will increase travel distance. A heavier rider will reduce travel distance
Ambient temperature: Extreme hot or cold environments will reduce travel distance
Maintenance: Following the recommended battery charging and care instructions will increase travel distance. Failure to maintain the battery will reduce travel distance. Regularly check the wheels, tyres and all other moving parts
Speed and riding style: Keeping a medium speed will increase travel distance. Frequent stopping and starting or accelerating and decelerating will reduce travel distance
STORING AND MAINTAINING YOUR ZINGO MOVE
Maintenance tasks:
• Always remove your ZINGO MOVE from the charger as soon as the charger indicator light turns green
• Never charge your ZINGO MOVE for longer than 2 hours at a time
• Check that there is no damage to your ZINGO MOVE, that the wheels are still in good condition and that there is enough tread on the tyres
• Regularly clean your ZINGO MOVE with a damp cloth and mild detergent. Make sure that no water comes in contact with the power button, charging port, under the rubber foot pads or in the wheels
Storage tips:
• Store your ZINGO MOVE indoors in a dry place
• Ensure that your ZINGO MOVE is fully charged when storing. Charge your ZINGO MOVE once every two weeks in order to keep the battery in good condition
• Your ZINGO MOVE must not be kept in an environment that is too cold or too hot
• Store your ZINGO MOVE in its original box to prevent dust accumulating
9.
TROUBLE SHOOTING
Problem Solution
ZINGO MOVE will not run. Take ZINGO MOVE and charger
Performance, range or run time of your ZINGO MOVE has decreased significantly.
1. Ensure that your ZINGO MOVE is fully charged.
2. Check all connectors. If charging, make sure that the charger is correctly connected to the charging port, and that there is power to the charger.
1. Your ZINGO MOVE is overloaded. Keep to the 125kg weight limit.
2. Hill is too steep. Max range is attained on flat ground, avoid steep hills.
3. Your ZINGO MOVE was used in an off-road environment. Only use your ZINGO MOVE on hard, dry surfaces free of any debris.
4. Check wheels for obstructions.
5. Make sure the battery is fully charged.
If solution doesn’t work
to a Tevo Service Centre.
Take ZINGO MOVE to a Tevo Service Centre to replace batteries.
BATTERIES
Batteries are not charging after use.
Clean and check both ends of the charger plug. Make sure they fit correctly and are not worn.
Take ZINGO MOVE and charger to a Tevo Service Centre.
1. Check that the wall plug is plugged in correctly and that the power is on.
2. Check power cable for breakages.
Replace Charger.Charger light not working.
Please call 0861 77 88 88 or email info@tevo.co.za to get further information on your nearest Service Centre.
10.
LIMITED WARRANTY
Remember to register your warranty online at www.tevo.co.za within 7 days of purchase.
To activate your warranty visit www.tevo.co.za, click the “Outdoor” tab, then click the “ZINGO MOVE” icon, then click the “Register Your Warranty” link. Fill in your details, enter the serial number (found near the charging port) and agree to the terms and conditions.
Please ensure that you retain your receipt as proof of purchase. You will not qualify for your warranty should you not have it.
The ZINGO MOVE limited warranty covers manufacturing defects only for a period of one hundred and eighty (180) days from the original date of purchase. This limited warranty does not cover normal wear and tear, tyres or body work nor any damage, failure or loss caused by improper assembly, maintenance, storage or use of the product.
This Limited Warranty will be void if the product is ever:
• Used in a manner other than for recreation
• Tampered with in any way
• Modified in any way
• Rented
The manufacturer is not liable for incidental or consequential loss or damage due directly or indirectly to the use or misuse of this product.
Please note that your ZINGO MOVE will not be covered under warranty if you ride through any gravel, mud, water, sand or on any off-road surface. The electrical and drive components could be damaged by riding through the aforementioned elements or surfaces.
NEVER wash your ZINGO MOVE with a hose, rather use a damp cloth to wipe it clean, paying particular attention in ensuring that the power button, charging port, foot pads and the inside the of wheels are kept free of water and moisture.
ENVIRONMENTALLY FRIENDLY DISPOSAL
Do not dispose of electrical appliances or batteries with general municipal waste. Hazardous substances can leak and contaminate the groundwater, affecting the food chain and ultimately damaging the environment and your health. Contact your local municipality for information on safe disposal in your area.
Brought to you by:
www.tevo.co.za | info@tevo.co.za
0861 77 88 88
11.
