Zephyr ASLE42ASX Use & Care
www.zephyronline.com
USER GUIDE - TOUCH GLASS CONTROLS
www.zephyronline.com
CONTROLS - User instructions Pag. 4
COMMANDES - Notice d’utilisation Pag. 14
MANDOS - Manual de utilización Pag. 25
COMANDI - Istruzioni per l’uso Pag. 36
USA
1. SAFETY
1.1 Safety...............................................................................................................................................5
2. REMOTE CONTROL
2.1Synchronisation.............................................................................................................................7
2.2 Operation.......................................................................................................................................7
Contents
2.3GeneralInformation....................................................................................................................7
3. USER INTERFACE
3.1Keypadlayout................................................................................................................................8
3.2 Displaylayout.................................................................................................................................8
4. INDIVIDUAL BUTTON FUNCTIONS
4.1PowerButton(1).............................................................................................................................9
4.2FanSpeedButton(2).....................................................................................................................9
4.3LightButton(3)...............................................................................................................................9
4.4DelayOButton(4)........................................................................................................................9
5. DISPLAY OPTIONS
5.1LightIndicator..............................................................................................................................10
5.2 Filter Clean and Charcoal Filter Replace Indicators.......................................................10
- Metal Filter Clean Indicator
- Charcoal Filter Replace Indicator
5.3 Delay O Indicator.....................................................................................................................11
5.4CleanAirIndicator......................................................................................................................11
5.5FanSpeed Indicator...................................................................................................................12
www.zephyronline.com
6. MAINTENANCE
6.1 Maintenance...............................................................................................................................13
6.2 Light Bulb Replacement........................................................................................................14
7. WARRANTY
7.1 Warranty......................................................................................................................................15
- 4 -
IMPORTANT SAFETY INSTRUCTIONS
FOR RESIDENTIAL USE ONLY
READ AND SAVE THESE INSTRUCTIONS
PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING.
IMPORTANT: Save these Instructions for the Local Electrical Inspectors use.
INSTALLER: Please leave these Instructions with this unit for the owner.
OWNER: Please retain these instructions for future reference.
Take care when using cleaning agents or detergents.
Suitable for use in household cooking area
WARNING - To reduce the risk of re or electric shock, do not use this fan with any Solid-State
Speed Control Device.
CAUTION - To reduce risk of re and to properly exhaust air, be sure to duct air outside – Do
not vent exhaust air into spaces within walls or ceilings or into attics, crawl spaces, or garages.
CAUTION - For general ventilating use only. Do not use to exhaust hazardous or explosive
materials and vapors.
CAUTION - To avoid motor bearing damage and noisy and/or unbalanced impellers, keep drywall
spray, construction dust, etc. o power unit.
CAUTION - Please read speci cation label on product for further information and require-
ments.
WARNING – TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE
THE FOLLOWING:
A. Use this unit only in the manner intended by the manufacturer. If you have ques tions,
contact the manufacturer.
B. Before servicing or cleaning unit, switch power o at service panel and lock the service
disconnecting means to prevent power from being switched on accidentally. When the service
disconnecting means cannot be locked, securely fasten a prominent warning device, such as a
tag, to the service panel.
1. Safety
WARNING - TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:
A. Never leave surface units unattended at high settings. Boilovers cause smoking and greasy
spillovers that may ignite. Heat oils slowly on low or medium settings.
B. Always turn hood ON when cooking at high heat or when ambeing foods ( i.e. Crepes Suzette,
Cherries Jubilee, Peppercorn Beef Flambè ).
C. Clean ventilating fans frequently. Grease should not be allowed to accumulate on fan or
lter.
D. Use proper pan size. Always use cookware appropriate for the size of the surface element.
E. Keep fan, lters and grease laden surface clean.
F. Use high range setting on range only when necessary.Heat oil slowly on low to medium set-
ting.
- 5 -
