Zenith R40W46F, R45W46, R45W46F OPERATING GUIDE

Installation and Operating Guide | Warranty

Model Numbers | R40W46, R40W46F, R45W46, R45W46F | Projection TVs

© Copyright 2004, LG Electronics Corporation.

2

WARNING:

TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER
SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the literature accompanying the appliance.

WARNING:

TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.

POWER CORD POLARIZATION:

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE

DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU´AU FOND.

NOTE TO CABLE/TV INSTALLER:

This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the National
Electric Code (U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the
cable ground shall be connected to the grounding system of the building, as close to the point of the cable
entry as practical.

REGULATORY INFORMATION:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.

CAUTION: Do not attempt to modify this product in any way without written authorization from Zenith Electronics Corporation. Unauthorized

modification could void the user’s authority to operate this product. The responsible party for this product’s compliance is :
Zenith Electronics Corporation, 1-201-816-2000
Marketed and Distributed in the United States by LG Electronics U.S.A., Inc.
1000 Sylvan Avenue, Englewood Cliffs, NJ 07632
http://www.zenith.com

RECORD YOUR MODEL NUMBER
(Now, while you can see it)

The model and serial number of your new TV are
located on the back of the TV cabinet. For your future
convenience, we suggest that your record those
numbers here:

MODEL NO.______________________
SERIAL NO.________________________

CAUTION

RISK OF ELECTRIC SHOCK
DO NOT OPEN

3

IMPORTANT SAFETY INSTRUCTIONS

1. Read Instructions
All the safety and operating instructions should be read
before the product is operated.

2. Follow Instructions
All operating and use instructions should be followed.

3. Retain Instructions
The safety and operating instructions should be retained

for future reference.

4. Heed Warnings
All warnings on the product and in the operating

instructions should be adhered to.

5. Cleaning
Unplug this product from the wall outlet before cleaning.

Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.

6. Water and Moisture
Do not use this product near water for example, near a

bath tub, wash bowl, kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool.

7. Accessories, Carts, and Stands
Do not place this product on an unstable cart, stand,

tripod, bracket, or table. The product may fall, causing
serious injury to a child or adult, and serious damage to
the product. Use only with a cart, stand, tripod, bracket,
or table recommended by the manufacturer, or sold with
the product. Any mounting of the product should follow
the manufacturer’s instructions, and should use a
mounting accessory recommended by the manufacturer.

8. Transporting Product
A product and cart combination should be moved with

care. Quick stops, excessive force, and uneven surfaces
may cause the product and cart combination to overturn.

9. Attachments
Do not use attachments not recommended by the

product manufacturer as they may cause hazards.

10. Ventilation
Slots and openings in the cabinet are provided for

ventilation and to ensure reliable operation of the product
and to protect it from overheating, and these openings
must not be blocked or covered. The openings should
never be blocked by placing the product on a bed, sofa,
rug, or other similar surface. This product should not be
placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the
manufacturer’s instructions have been adhered to.

11. Power Sources
This product should be operated only from the type of

power source indicated on the marking label. If you are
not sure of the type of power supply to your home,
consult your product dealer or local power company. For
products intended to operate from battery power, or
other sources, refer to the operating instructions.

12. Line-Cord Polarization
This product is equipped with a polarized alternating-

current line plug (a plug having one blade wider than the
other). This plug will fit into the power outlet only one
way. This is a safety feature. If you are unable to insert
the plug fully into the outlet, try reversing the plug. If the
plug should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the safety
purpose of the polarized plug.

13. Power-Cord Protection
Power-supply cords should be routed so that they are

not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to cords
at plugs, convenience receptacles, and the point where
they exit from the product.

Important safeguards for you and your new product

Your product has been manufactured and tested with your safety in mind. However, improper use can result in
potential electrical shock or fire hazards. To avoid defeating the safeguards that have been built into your new
product, please read and observe the following safety points when installing and using your new product, and save
them for future reference.

Observing the simple precautions discussed in this operating guide can help you get many years of enjoyment and
safe operation that are built into your new product.

This product complies with all applicable U.S. Federal safety requirements, and those of the Canadian Standards
Association.

PORTABLE CART WARNING

(Continued on next page)

4

IMPORTANT SAFETY INSTRUCTIONS

14. Outdoor Antenna Grounding
If an outside antenna or cable system is connected to

the product, be sure the antenna or cable system is
grounded so as to provide some protection against
voltage surges and built-up static charges. Article 810 of
the National Electrical Code (U.S.A.), ANSI/ NFPA 70
provides information with regard to proper grounding of
the mast and supporting structure, grounding of the lead­in wire to an antenna discharge unit, size of grounding
conductors, location of antenna-discharge unit,
connection to grounding electrodes, and requirements
for the grounding electrode.

15. Lightning
For added protection for this product (receiver) during a

lightning storm, or when it is left unattended and unused
for long periods of time, unplug it from the wall outlet and

disconnect the antenna or cable system. This will
prevent damage to the product due to lightning and
power-line surges.

16. Power Lines
An outside antenna system should not be located in the

vicinity of overhead power lines or other electric light or
power circuits, or where it can fall into such power lines
or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching
such power lines or circuits as contact with them might
be fatal.

17. Overloading
Do not overload wall outlets and extension cords as this
can result in a risk of fire or electric shock.

18. Object and Liquid Entry
Never push objects of any kind into this product through

openings as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.

19. Servicing
Do not attempt to service this product yourself as

opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing
to qualified service personnel.

20. Damage Requiring Service
Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:

a. If the power-supply cord or plug is damaged.

b. If liquid has been spilled, or objects have fallen into

the product.

c. If the product has been exposed to rain or water.

d. If the product does not operate normally by following
the operating instructions. Adjust only those controls that
are covered by the operating instructions as an improper
adjustment of other controls may result in damage and
will often require extensive work by a qualified technician
to restore the product to its normal operation.

e. If the product has been dropped or the cabinet has

been damaged.

f. If the product exhibits a distinct change in

performance.

21. Replacement Parts
When replacement parts are required, be sure the

service technician has used replacement parts specified
by the manufacturer or have the same characteristics as
the original part. Unauthorized substitutions may result in
fire, electric shock, or other hazards.

22. Safety Check
Upon completion of any service or repairs to this product,

ask the service technician to perform safety checks to
determine that the product is in proper operating
condition.

23. Wall or Ceiling Mounting
The product should be mounted to a wall or ceiling only

as recommended by the manufacturer.

24. Heat
The product should be situated away from heat sources

such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.

Antenna Lead in Wire

Antenna Discharge Unit
(NEC Section 810-20)

Grounding Conductor
(NEC Section 810-21)

Ground Clamps
Power Service Grounding

Electrode System (NEC
Art 250, Part H)

Ground Clamp

Electric Service

Equipment

Example of Grounding According to National Electrical
Code Instructions

(Continued from previous page)

NEC- National Electrical Code

CONTENTS

5

Setup Checklist

Step 1

Connect TV to all sources and external equipment:

See pages 26-30

Step 2

Do a channel search: find available channels in your area:

See pages 10-11

Step 3

Set up the individual features, picture, and sound to
your personal preference:

See appropriate pages above

Safety Warnings ...........................................2

Important Safety Instructions ......................3

Remote Control Key Functions ...................6

Basic TV Setup and Operation ....................9

Turning the TV On/Off.......................................9

Selecting a Language for the Onscreen Menus

. ..9

Selecting a Source for the Main Screen Picture

..9

Channel Search ..............................................10

Finding Channels with EZ Scan .....................10

Adding/Deleting/Labeling Channels

with Manual Program .....................................11

Tuning Channels ............................................11

Changing the Sound Level..............................11

Features .......................................................12

Clock Setup: Auto/Manual .............................12

Off Timer/On Timer Setup ..............................13

Auto Off Setup ................................................13

Sleep Timer Setup .........................................14

Key Lock Setup...............................................14

Fine Tuning Adjustment .................................15

Signal Reception Booster ...............................15

Favorite Channel Memory...............................15

Picture Format Selection ...............................16

Auto Move ......................................................16

Picture Setup ..............................................17

EZ Video Setup...............................................17

DRP (Digital Reality Picture) .........................17

Cinema Mode Setup .......................................17

VM (Velocity Modulation) Setup......................18

ACC (Auto Color Control) Setup.....................18

User Picture Appearance Adjustments...........18

Color Convergence Adjustments ....................19

Sound Setup ...............................................20

Stereo/SAP Broadcasts Setup........................20

EZ Audio Options............................................20

AVL (Auto Volume Leveler) ............................21

TV Speaker On/Off..........................................21

Balance, Treble, Bass Adjustments................21

Closed Captions ..........................................22

Closed Captions Overview .............................22

Captions On, Off, EZ Mute Setup ...................23

Selecting a Caption/Text Mode.......................23

Parental Control Overview..........................24

Blocking Scheme Setup .................................25

Antenna Connections ................................26

External Equipment Connection and

Viewing Setup .............................................27

Programming the Remote to Operate Other

Devices ........................................................31

Programming Codes ..................................32

Maintenance ................................................35

Product Specifications ...............................36

Troubleshooting Checklist .........................37

Your Zenith Limited Warranty.....Back cover

Remote Control Key Functions

6

1. MODE INDICATOR LIGHTS

Show active remote mode every time any button is
pressed.

2. MODE

Selects the remote operating mode: TV, VCR, Cable Box,
DVD, or Satellite. Select other remote modes, for the
remote to operate external devices.

3. LIGHT

Illuminates the remote control keys.

4. TV/VIDEO

Selects TV, VIDEO, COMPONENT, or DVI mode.

5. COMP

Selects COMPONENT or DVI mode.

6. ARC

Selects 4:3, 16:9, Horizon, Zoom 1, or Zoom 2 picture formats.

7. NUMBER BUTTONS

Direct channel selection.

8. DASH button

Used to enter a program number for multiple program
channels such as 2—1,2—2,etc.

9. VIDEO

Selects factory preset picture settings:

Clear, Optimum,

Soft, or User.

10.CHANNEL UP/DOWN

• Selects the desired channel.

• Selects the desired menu option when menu is

displayed on the screen.

VOLUME UP/DOWN

• Increases or decreases sound level.

• Enters or adjusts the selected menu when menu is

displayed on the screen.

11.FCR ( Favorite Channel Review )

Selects favorite channels.
Refer to "Favorite channel memory".

12.MUTE (Two Levels)

Reduce sound to half volume or mute the sound entirely.

13.MENU

Displays on-screen menus.

14.EXIT

Clears all on-screen displays and returns to TV viewing
from any menu.

15. BUTTON

No function.

1 2 3
4 5 6
7 8 9

0

tv

vcr

cable

dvd

sat

mode

light

power

tv/video

dvi

comp

avl

ccarc

enter

video

audio

vol

ch

sleepmute mts

fcr

menu

exit still

flashbk

recordstop

pause

rew

play

ff

skip

right

enter

left

down

up

1
2

3
4

6

7

8
9

11
12

13

10

15

5

14

7

16.POWER (or ON/OFF)

Refer to "Turning the TV on/off".

17.DVI

Selects DVI mode.

18.AVL

To keep on equal volume level of each channel.

19. CC

Selects the CAPTIONS:

On, Ez Mute, or Off.

20.AUDIO

Selects the sound appropriate for the program's
character;

Virtual, Flat, Music, Movie, Sports or

User.

21.SLEEP (Sleep Timer)

Sets turn off time.

22.MTS BUTTON

Selects MTS sound:

Mono, Stereo, or SAP.

23.FLASHBK

Returns to the previous channel.

24.STILL

Freezes the currently-viewed picture.

25.UP

D

/ DOWNE/ LEFTF/ RIGHTG/ ENTER

• Navigates the on-screen menus to adjust the TV
settings and preferences.

• Displays current TV mode (Remote control only).

26.VCR BUTTONS

Control some video cassette recorders.

27.SKIP Left/Right

Playing CDs: Selects previous/next song.
Playing DVDs: Selects previous/next movie chapter.

28.STAND BY INDICATOR (

rr

)

Illuminates brightly when the TV is in standby mode. Dims
when the TV is switched on.

29.REMOTE CONTROL SENSOR

vcr

16

18

25

19

17

25

20

21
22

23

26

27

24

Installing Batteries in the Remote Control

• Remove the battery compartment cover on the back side
and insert the batteries with correct polarity.

• Install two 1.5V, AA type batteries. Don’t mix used and new
batteries.

tv

mode

tv/video

cable

light

comp

ccarc

1 2 3
4 5 6
7 8 9

0

video

vol

fcr

exit still

menu

up

enter

left

down

play

pause

rew

ff

ch

dvd

power

enter

recordstop

skip

sat

dvi

avl

audio

sleepmute mts

flashbk

right

Remote Control Key Functions / TV Setup

8

Securing TV Position

• Position the TV and prevent it from being moved, by
placing the 4 stoppers under the roller casters on the
bottom of the TV.

• Casters (on TV bottom)
Use to turn and move the TV easily.

Stopper

ch

volmuteentermenutv/video

on/off

29

16 4 13 25 12 28 10

Front Panel Controls

This is a simplified representation of front panel.

Before operating your TV, make sure the TV has been connected to an antenna or cable system and the
TV is plugged into a power outlet.

Basic TV Setup and Operation

Turning the TV On/Off

When the TV is connected to power, it switches to standby mode and
the standby indicator lights red.
To switch the TV on from standby mode, press the on/off, tv/video,
ch

D

/Ebutton on the set or tv/video, chD/E, comp, power or
number button on the remote control.
A channel number will be displayed on the screen. The on-screen
display will disappear after a few seconds.

Press the power button on the remote control or the set. The TV
reverts to standby mode.

Selecting a Language for the Onscreen Menus

1. Press the menu button and then use D/Ebutton to select the

Special menu.

2. Press the

G

and then use D/Ebutton to select Language.

3. Press the

G

and then use D/Ebutton to select the desired

language.
From this point on, the menus appear in the selected language.

4. Press the exit button to return to TV viewing.

Selecting a Source for the Main Screen Picture

Changes the picture source for the main screen so you can watch
your off-air TV, cable TV, VCR, DVD, or any other device that is
connected to your TV.

1. Press the menu button and then use

D

/Ebutton to select the

Special menu.

2. Press the

G

and then use D/Ebutton to select Input.

3. Press the

G

and then use D/Ebutton to select TV, Video 1,

Video 2, Video 3, Video 4, Component 1, Component 2 or
DVI.

4. Press the exit button to return to TV viewing.

9

++

Move {Next+}}Exit

Language

{{

Input

{{

Key lock

{{

Captions

{{

Caption/Text

{{

ARC

{{

Auto move

{{

Special

++

Move }}Back

Language

{{

Input

{{

Key lock

{{

Captions

{{

Caption/Text

{{

ARC

{{

Auto move

{{

Special

TV
Video 1
Video 2
Video 3
Video 4
Component 1
Component 2
DVI

TV +

CH.

CH.

Channel Search

Channel Search finds and memorizes all the active channels in your area. You must do a channel search
before you can use the TV.
Use EZ Scan to find active channels and then use Manual Program to customize your channel list by
adding or deleting channels.
Using EZ Scan, the TV memorizes the channels in ascending numerical order.
You can also add or delete channels manually using Manual Program.

Basic TV Setup and Operation

Finding Channels with EZ Scan

EZ Scan searches and memorizes all the active channels in your area.

After using EZ Scan, select channels with the

D

/Ebuttons.

1. Press the menu button and then use

D

/Ebutton to select the

Channel menu.

2. Press the

G

and then use D/Ebutton to select EZ Scan.

3. Press the

G

button. The EZ Scan function starts.

If you want to stop EZ Scan, press the enter ( ) button.
Only the channels searched up to that time are memorized.

Notes

• EZ Scan stores all available channels regardless of signal type (Over-

the- air or Cable).

• If over-the-air and Cable TV channels are duplicated, use the

number buttons (0 ~ 9) to change channels for:

.

10

++Stop

2%

EZ Scan OOOOTVO5

Over-the-Air Channels Cable TV Channels

++

Move {Next+}}Back

EZ Scan

{{

Manual prog.

{{

Favorite ch.

{{

Channel

To start

{{

EZ Scan

{{

CH.

Adding/Deleting/Labeling Channels with Manual
Program

1. Press the menu button and then use D/Ebutton to select the

Channel menu.

2. Press the

G

and then use D/Ebutton to select Manual prog..

3. Press the

G

and then use D/Ebutton to select Channel.

4. Press the

G

and then use D/Ebutton to select the channel number

you want to memorize or erase.

5. Press the

F

button and then use D/Ebutton to select Memory.

6. Press the

G

and then use D/Ebutton to select On or Off.

7. Press the

F

button and then use D/Ebutton to select Ch.name.

You can make a channel name.

8. Press the

G

and then use F/G button to select a word position and

then

D

/Ebutton to enter alphabet A to Z, a to z, number 0 to 9, or

blank.

9. Repeat process 3 to 8 to memorize or erase other channels.

10.Press the exit button to return to TV viewing.

Tuning Channels

Use the ch D/Ebutton to easily select the next higher or lower
channel. Or, use the NUMBER buttons to directly select the desired
channel.

Changing the Sound Level

Use the vol Dbutton to make the sound louder or vol Ebutton to
make the sound quieter.

If you press the mute button on the remote control once, the sound is
reduce to half of original volume level. Press the mute button on the
remote control again and the sound is muted. At this time, the word

Mute is displayed.

Using Mute is convenient if you need to answer a telephone call.
To restore muted sound, press the mute button on the remote control
again or vol

D

/Ebutton.

EEEMute

11

++

Move {Next+}}Back

Channel

{{

Memory

{{

Fine

{{

Ch.name

{{

Booster

{{

TV02

Manual program

Volume

5

++

Move {Next+}}Back

EZ Scan

{{

Manual prog.

{{

Favorite ch.

{{

Channel

To set

{{

Manual prog.

{{

Channel

{{

CH.

Features

Clock Setup: Auto/Manual

Before using the on/off timer features, You must first set the current
time on the clock.

Auto Clock Setup

The time is set automatically from a PBS broadcast signal. The PBS
channel signal includes information for the correct time and daylight
saving time.

1. Press the menu button and then use

D

/Ebutton to select the

Timer menu.

2. Press the

G

and then use D/Ebutton to select Clock .

3. Press the

G

and then use D/Ebutton to select Auto .

4. Press the

G

button and then use the D/Ebutton to select the

Time zone.

5. Press the

G

button and then use the D/Ebutton to select E.S.T.

(Eastern Standard Time), C.S.T. (Central Standard Time), M.S.T.

(Mountain Standard Time), P.S.T. (Pacific Standard Time), Alaska, or

Hawaii.

6. Press the

F

button and then use the D/Ebutton to select PBS

CH.

.

7. Press the

G

button and then use the D/Ebutton to set your local

PBS channel.

8. Press the

F

button and then use the D/Ebutton to select D.S.T.

(Daylight Savings Time).

9. Press the

G

button and then use the D/Ebutton to set D.S.T.
(Daylight Savings Time) Auto, On, or Off depending on whether or
not your viewing area observes Daylight Savings Time.

10.Press the exit button to return to TV viewing.

Manual Clock Setup

1. Press the menu button and then use D/Ebutton to select the
Timer menu.

2. Press the

G

and then use D/Ebutton to select Clock .

3. Press the

G

button and then use the D/Ebutton to select Manual.

4. Press the

G

button and then use the D/Ebutton to set the hours.

5. Press the

G

button and then use the D/Ebutton to set the

minutes.

6. Press the exit button to return to TV viewing.

12

++

Move {Next+}}Back

Clock

{{

Off timer

{{

On timer

{{

Auto off

{{

Timer

Auto

{{

Manual

{{

- - : - - AM

Auto

{{

++

Move {Next+}}Back

Clock

{{

Off timer

{{

On timer

{{

Auto off

{{

Timer

Auto

{{

Manual

{{

- - : - - AM

Manual

{{

++

Move }}Back

Time zone

{{

PBS CH.

{{

D.S.T.

{{

- - : - - AM

Auto
E.S.T.
C.S.T.
M.S.T.
P.S.T.
Alaska
Hawaii

Auto clock

Auto

CH.

CH.

Off Timer/On Timer Setup

Off Timer automatically switches the TV to standby mode at the preset
time.
On Timer automatically turns the TV on at the preset time and tunes to
the specified channel.

1. Press the menu button and then use

D

/Ebutton to select the

Timer menu.

2. Press the

G

and then use D/Ebutton to select Off timer or On

timer.

3. Press the

G

and then use D/E button to set the hour.

4. Press the

G

and then use D/E button to set the minute.

5. For only

On timer function: Press the

G

and then use D/

E

button to set the desired channel.
Press the

G

and then use D/Ebutton to set the volume level at

turn on.

6.

Run/Hold is used to activate or deactivate preset on/off timers.

Press the

G

and then use D/E button to select Hold or Run.

7. Press the exit button to return to TV viewing.

Notes

• Two hours after the TV is turned on by the on timer function, it will

automatically revert back to standby mode unless a button has been
pressed.

• This function works only in standby mode.

• If the same time is set for the on time and off time, only the off time

operates.

Auto Off Setup

If an input signal is not present, the TV is automatically switched to
standby mode after 10 minutes.

1. Press the menu button and then use

D

/Ebutton to select the

Timer menu.

2. Press the

G

and then use D/Ebutton to select Auto off.

3. Press the

G

and then use D/Ebutton to select On or Off.

4. Press the exit button to return to TV viewing.

13

}}

{+Move+++ Adjust++

Å

+Back

Clock

{{

Off timer

{{

On timer

{{

Auto off

{{

Timer

- - : - - AM
TV 2

Vol 30
Hold

- - AM

+Move++

Å

}}

Back

Clock

{{

Off timer

{{

On timer

{{

Auto off

{{

Timer

On
Off

Off

CH.

CH.

Features

14

Sleep Timer Setup

You don't have to remember to switch the TV to standby mode before
you go to sleep. The Sleep Timer automatically turns the TV off after
the preset sleep time expires.
Use the sleep button to select the desired sleep time.
Each time you press this button, preset sleep time settings are
displayed one by one as shown below. The Sleep Timer begins to
count down from the number of minutes selected.

Notes

• After a few seconds, the desired sleep time setting will disappear and
the TV turn-off function will operate automatically.

• To view the remaining sleep time, press the sleep button once and
the remaining sleep time will be displayed.

• To cancel the Sleep Timer, select the --- setting with sleep button.

Key Lock Setup

The TV can be set up so that it can only be operated by the remote
control. This feature can be used to prevent unauthorized viewing.

1. Press the menu button and then use

D

/Ebutton to select the

Special menu.

2. Press the

G

and then use D/Ebutton to select Key lock.

3. Press the

G

and then D/Ebutton to select On or Off.

4. Press the exit button to return to TV viewing.

Notes

• With key lock set to on, the display

Key lock appears on the screen

if any button on the front panel is pressed while viewing the TV.

• This TV is programmed to remember which option it was last set to
when you switch the TV on from standby mode.

---

10 20 30 60 90 120 180 240

---

SSSKey lock

++

Move }}Back

Language

{{

Input

{{

Key lock

{{

Captions

{{

Caption/Text

{{

ARC

{{

Auto move

{{

Special

On
Off

Off

CH.

Fine Tuning Adjustment

Use Fine Tuning to correct the picture's condition if it is poor. For
example, a horizontal stripe, twisted picture or no color in broadcast.

1. Press the menu button and then use

D

/Ebutton to select the

Channel menu.

2. Press the

G

and then use D/Ebutton to select Manual prog..

3. Press the

G

and then use D/Ebutton to select Fine.

4. Press the

G

and then use F/Gbutton to adjust the picture

appearance to your preference.

5. Press the exit button to return to TV viewing.

Notes : • To release the memorized fine tuning, reprogram the fine-

tuned channel with EZ Scan or Manual Program.

• If a finely-tuned channel is memorized, the color of the
channel number changes to yellow.

Signal Reception Booster

If TV signal reception is poor because you are in a fringe area, set

Booster to On. If the picture condition is good, set Booster to Off.

1. Press the menu button and then use

D

/Ebutton to select the

Channel menu.

2. Press the

G

and then use D/Ebutton to select Manual prog..

3. Press the

G

and then use D/Ebutton to select Booster.

4. Press the

G

and then use D/E button to select On or Off.

5. Press the

F

button to exit.

Note: Adjustments for one channel do not affect adjustments for other

channels. Set booster to on or off for each channel separately.

Favorite Channel Memory

Favorite channel memory is a convenient feature that lets you quickly
view up to eight channels of your choice without having to wait for the
TV to tune in all of the in-between channels.

1. Press the menu button and then use

D

/Ebutton to select the

Channel menu.

2. Press the

G

and then use D/Ebutton to select Favorite ch..

3. Press the

G

and then use D/Ebutton to select a favorite channel

position.

4. Use the

F/G

button to select the desired channel number.

5. Repeat steps 3 to 4.

6. Press the exit button to return to TV viewing.
To select a favorite channel, press the fcr (Favorite Channel Review)

button repeatedly. The eight favorite channels appear on the screen
one by one.

15

}}

{Adjust Exit

Channel

{{

Memory

{{

Fine

{{

Ch.name

{{

Booster

{{

0

Manual program

++

Move {Next+}}Back

EZ Scan

{{

Manual prog.

{{

Favorite ch.

{{

Channel

To set

{{

Manual prog.

{{

++

Move }}{Adjust Back

EZ Scan

{{

Manual prog.

{{

Favorite ch.

{{

Channel

- - - - - - -

- - - - - - -

- - - - - - -

- - - - - - -

- - - - - - -

- - - - - - -

- - - - - - -

- - - - - - -

- - - - - - -

0

++

Move }}Back

Channel

{{

Memory

{{

Fine

{{

Ch.name

{{

Booster

{{

On
Off

Manual program

Off

CH.

CH.

Picture Format Selection

5 picture formats are available.
Press the ARC button repeatedly to change picture formats. Each time

you press ARC button, picture formats are selected in the following
order:

4:3, 16:9, Horizon, Zoom 1, and Zoom 2.

Using the arc Button

1. Press the arc button repeatedly to select: 4:3, 16:9, Horizon, Zoom

1 , or Zoom 2.

2. Press the enter ( ) button to exit.

Using the Menu

1. Press the menu button and then use D/Ebutton to select the
Special menu.

2. Press the

G

and then use D/Ebutton to select ARC.

3. Press the

G

and then D/Ebutton to select 4:3, 16:9, Horizon,

Zoom 1 or Zoom 2.

4. Press the exit button to return to TV viewing.

Note : This function is not available in Twin picture or Component

1080i mode.

Auto Move

Auto move may help prevent a ghost image from appearing on the
screen. In 4:3 aspect ratio, the picture will move right/left about 5mm
every 2 hours. In twin picture mode, the picture will move up/down
about 5mm every 2 hours.

1. Press the menu button and then use

D

/Ebutton to select the

Special menu.

2. Press the

G

and then use D/Ebutton to select Auto move.

3. Press the

G

and then use D/Ebutton to select On or Off.

4. Press the exit button to return to TV viewing.

Features

16

16:9

++

Move }}Back

Language

{{

Input

{{

Key lock

{{

Captions

{{

Caption/Text

{{

ARC

{{

Auto move

{{

Special

On
Off

Off

++

Move }}Back

Language

{{

Input

{{

Key lock

{{

Captions

{{

Caption/Text

{{

ARC

{{

Auto move

{{

Special

4:3
16:9
Horizon
Zoom 1
Zoom 2

16:9

CH.

CH.

EZ Video Setup

For optimum picture quality, use the factory preset picture modes.

EZ Video set up using the video button

1. Press the video button repeatedly to select: Clear, Optimum,

Soft, or User.

2. Press the enter ( ) button to return to TV viewing.

EZ Video set up using the Picture menu

1. Press the menu button and then use D/Ebutton to select the
Picture menu.

2. Press the

G

and then use D/Ebutton to select EZ Video.

3. Press the

G

and then use D/Ebutton to select Clear, Optimum,

Soft, or User.

4. Press the exit button to return to TV viewing.

DRP (Digital Reality Picture)

This is the function to stress picture outline in showing a dark area
light.

1. Press the menu button and then use

D

/Ebutton to select the

Picture menu.

2. Press the

G

and then use D/Ebutton to select DRP.

3. Press the

G

and then use D/Ebutton to select: Clear or Soft.

4. Press the exit button to return to TV viewing.

Cinema Mode Setup

Sets up the TV for the best picture appearance for viewing movies.

1. Press the menu button and then use

D

/Ebutton to select the

Picture menu.

2. Press the

G

and then use D/Ebutton to select Cinema.

3. Press the

G

and then use D/E button to select On or Off.

4. Press the exit button to return to TV viewing.

17

Picture Setup

Clear

++

Move }}Back

EZ Video

{{

DRP

{{

Cinema

{{

VM

{{

ACC

{{

Contrast

{{

Brightness

{{

Color

{{

Sharpness

{{

Tint

{{

Convergence

{{


Clear
Optimum

Soft
User

Clear

++

Move }}Back

EZ Video

{{

DRP

{{

Cinema

{{

VM

{{

ACC

{{

Contrast

{{

Brightness

{{

Color

{{

Sharpness

{{

Tint

{{

Convergence

{{


Clear
Soft

Clear

++

Move }}Back

EZ Video

{{

DRP

{{

Cinema

{{

VM

{{

ACC

{{

Contrast

{{

Brightness

{{

Color

{{

Sharpness

{{

Tint

{{

Convergence

{{


On
Off

On

CH.

CH.

CH.

18

Picture Setup

VM (V elocity Modulation) Setup

If you select VM High, the TV will automatically enhance the
sharpness of the image's edges.

1. Press the menu button and then use

D

/Ebutton to select the

Picture menu.

2. Press the

G

and then use D/Ebutton to select VM.

3. Press the

G

and then use D/E button to select High, Medium,

Low or Off.

4. Press the exit button to return to TV viewing.

ACC (Auto Color Control) Setup

Specify the picture color appearance.

1. Press the menu button and then use

D

/Ebutton to select the

Picture menu.

2. Press the

G

and then use D/Ebutton to select ACC.

3. Press the

G

and then use D/Ebutton to select Cool, Normal, or

Warm.

4. Press the exit button to return to TV viewing.

User Picture Appearance Adjustments

This is the function to manually adjust the picture levels: Contrast,

Brightness, Color, Sharpness,

and Tint to your preference. If the
picture settings you adjust are not satisfactory, you can also select a
factory preset picture setup.

1. Press the menu button and then use

D

/Ebutton to select the

Picture menu.

2. Press the

G

and then use D/Ebutton to select the desired picture

option (

Contrast, Brightness, Color, Sharpness, and Tint).

3. Press the

G

and then use F/Gbuttons to adjust the levels.
The setting of highlighted menu option is displayed.
Use the

D

/Ebutton to select other options.

4. Press the exit button to return to TV viewing.

++

Move }}Back

EZ Video

{{

DRP

{{

Cinema

{{

VM

{{

ACC

{{

Contrast

{{

Brightness

{{

Color

{{

Sharpness

{{

Tint

{{

Convergence

{{


High

Low
Off

Medium

++

Move }}Back

EZ Video

{{

DRP

{{

Cinema

{{

VM

{{

ACC

{{

Contrast

{{

Brightness

{{

Color

{{

Sharpness

{{

Tint

{{

Convergence

{{


Cool
Normal

Warm

Normal

++

Move {Next+}}Back

EZ Video

{{

DRP

{{

Cinema

{{

VM

{{

ACC

{{

Contrast

{{

Brightness

{{

Color

{{

Sharpness

{{

Tint

{{

Convergence

{{


100

++

Move }}{Adjust Back

Contrast000 0100

Contrast

{

CH.

CH.

CH.

19

Color Convergence Adjustments

Use this function to adjust the R-G-B color convergence while a stable
signal is present. When the TV is first installed or if it is relocated, the
picture may be unstable with three color ghosts (red, green, blue). This
problem can be solved by adjusting the color convergence.

1. Press the menu button and then use

D

/Ebutton to select the

Picture menu.

2. Press the

G

and then use D/Ebutton to select Convergence.

3. Press the

G

and then use D/Ebutton to select 1 (all point

convergence) or

9 (9 point convergence) .

If the

+ display is not white and shows three color ghosts, the color

convergence needs to be adjusted. If the

+ display is white, color

convergence is adjusted properly.

4. Press the

G

and then press the tv/video button.

The display button is selected in red or blue.

5. Only selecting

9 : Use the number (1~9) button to select the

position your want to adjust the convergence for.

6. Use the

D

/E/

F/G

button to superimpose the + display (red or

blue) over the green

+. It will be changed to yellow or cyan.

7. When both red and blue

+ display is correctly superimposed over

green, the

+ display changes to white.

8. Press the exit button to return to TV viewing.
Note: If the picture needs to be adjusted more

1 (all point

convergence) adjustment, you can adjust the

9 (9 point

convergence) for the position you want to adjust.

TV/ VIDEO ENTER MENU

++

Move {Next+}}Back

EZ Video

{{

DRP

{{

Cinema

{{

VM

{{

ACC

{{

Contrast

{{

Brightness

{{

Color

{{

Sharpness

{{

Tint

{{

Convergence

{{


1
9

{

1

{

CH.

20

Stereo/SAP Broadcasts Setup

This TV can receive MTS stereo programs and any SAP (Second
Audio Program) accompanying the stereo program. The broadcaster
may transmit one additional sound signal as well as the original one.
The MTS function doesn't operate for video sources.

1. Use the mts button to select your desired MTS mode.
Each time you press this button, the

Mono, Stereo, or SAP mode

appear in turn.

2. Press the enter ( ) button to return to TV viewing.

Notes

• Stereo or SAP can only be received if the TV station transmits those

signals, even though you have selected

Stereo or SAP.

• Mono sound is automatically received if the broadcast is only in

Mono; even though

Stereo or SAP has been selected.

• Select

Mono if you want to listen to mono sound in remote fringe

areas during a stereo/SAP broadcast.

EZ Audio Options

You can enjoy the best sound without any special adjustment because
the TV automatically selects the sound appropriate for the program
character.

EZ Audio set up using the audio button

1. Press the audio button repeatedly to select Virtual, Flat,

Music, Movie, Sports,orUser.

2. Press the enter ( ) button to remove menu.

EZ Audio set up using the Audio menu

1. Press the menu button and then use D/Ebutton to select the
Sound menu.

2. Press the

G

and then use

D

/

E

button to select EZ Audio.

3. Press the

G

and then use

D

/

E

button to select Virtual, Flat,

Music, Movie, Sports,orUser.

4. Press the exit button to return to TV viewing.

Note: • Manufactured under license from Dolby Laboratories.

“Dolby” and the double-D symbol are trademarks of Dolby
Laboratories.

Sound Setup

User

++

Move }}Back

EZ Audio

{{

AVL

{{

TV Speaker

{{

Balance

{{

Treble

{{

Bass

{{

Sound

Virtual
Flat
Music
Movie
Sports
User

Flat

CH.

AVL (Auto Volume Leveler)

AVL automatically maintains an equal volume level even if you change
channels.

Using the avl Button

1. Press the avl button.

2. Press the

avl button to select On or Off.

3. Press the enter ( ) button to exit.

Using the Menu

1. Press the menu button and then use D/Ebutton to select the
Sound menu.

2. Press the

G

and then use

D

/

E

button to select AVL.

3. Press the

G

and then use

D

/

E

button to select On or Off.

4. Press the exit button to return to TV viewing.

TV Speaker On/Off

If you want to hear the sound on your external hi-fi stereo system,
select

TV Speaker -Off to turn the TV internal speakers off.

1. Press the menu button and then use

D

/Ebutton to select the

Sound menu.

2. Press the

G

and then use

D

/

E

button to select TV Speaker.

3. Press the

G

and then use

D

/

E

button to select On orOff .

4. Press the exit button to return to TV viewing.

Balance, T reble, Bass Adjustments

Manually adjust the sound levels: Balance, Treble, and Bass to your
preference.

1. Press the menu button and then use

D

/Ebutton to select the

Sound menu.

2. Press the

G

and then use D/Ebutton to select the desired sound

option (

Balance, Treble, or Bass).

3. Press the

G

and then use F/Gbutton to adjust the level.

Use the

D

/Ebutton to select other options.

4. Press the exit button to return to TV viewing.

21

++

Move }}Back

EZ Audio

{{

AVL

{{

TV Speaker

{{

Balance

{{

Treble

{{

Bass

{{

Sound

On
Off

Off

++

Move }}Back

EZ Audio

{{

AVL

{{

TV Speaker

{{

Balance

{{

Treble

{{

Bass

{{

Sound

On
Off

On

++

Move {Next+}}Back

EZ Audio

{{

AVL

{{

TV Speaker

{{

Balance

{{

Treble

{{

Bass

{{

Sound

50

Treble

{

CH.

CH.

CH.

Closed captioning is a process which converts the audio portion of a television program into written
words, which then appear on the television screen in a form similar to subtitles. Closed captions allow
viewers to read the dialogue and narration of television programs.

Closed Captions Overview

Captions are the subtitles for the dialogue and narration of television
programs. For prerecorded programs, program dialogue can be
arranged into captions in advance. It is possible to caption a live
program by using a process called “real-time captioning”, which
creates captions instantly. Real-time captioning is normally done by
professional reporters using a machine shorthand system with
computer for translation into English.
Captioning is an effective system for the hearing-impaired, and it can
also used as an aid in teaching language skills.

• The picture at left shows a typical caption.

Closed Captions /Display Problems

• Not all TV broadcasts include closed caption signals.

• Sometimes TV stations broadcast two different caption signals on the same channel. By selecting CC

1 or CC2, you can choose which signal you view. CC 1 is usually the signal with the captions, while CC
2 might show demonstration or programming information.

• Your TV might not display caption signals correctly under the following circumstances.

1. Poor reception conditions are encountered:

2. An old, bad or illegally recorded tape is being played.

3. Strong, random signals from a car or airplane are interfering with the TV signal.

4. The signal from the antenna is weak.

5. The program wasn't captioned when it was produced, transmitted, or taped.

Closed Captions

A

IGNITION:
Picture may flutter, drift, display black spots or horizontal streaking,
which are usually caused by interference from automobile ignition
systems, neon lamps, electrical drills or other electrical appliances.

A

GHOSTS:
Ghosts are caused when the TV signal splits and follows two paths.
One is the direct path and the other is reflected off tall buildings,
hills, or other objects. Changing the direction or position of the
antenna may improve reception.

A

SNOW:
If your TV is located at the weak, fringe area of a TV signal, your
picture may be marred by small dots. It may be necessary to install
a special antenna to improve the picture.

FOLLOW ME

22

Displaying Text

Text services offer a wide variety of information on all kinds of subjects
(ex. captioned program lists, weather forecasts, stock exchange
topics, news for hearing-impaired---) filling the TV screen.
However, even though the program does offer captioning, text
services may not be available.

Note

• In the event you are receiving a poor signal, an empty black box may

appear and disappear, when text mode is turned on. This commonly
happens under poor signal conditions.

Captions On, Off, EZ Mute Setup

Captions set up using the cc button

1. Use the cc button to select:On,Ez Mute,or Off.

2. Press the enter ( ) button to remove menu.

Captions set up using the Captions Menu

1. Press the menu button and then use D/Ebutton to select the
Special menu.

2. Press the

G

and then use

D/E

button to select Captions.

3. Press the

G

and then use

D/E

button to select: On, EZ Mute, or

Off.

4. Press the exit button to return to TV viewing.

Note

• EZ mute shows the selected captions option (if available on program)
when the TV sound is muted.

Selecting a Caption/Text Mode

1. Press the menu button and then use D/Ebutton to select the
Special menu.

2. Press the

G

and then use

D/E

button to select Caption/Text.

3. Press the

G

and then use

D/E

button to select CC1, CC2, CC3,

CC4,Text 1 ,Text 2 ,Text 3 ,or Text 4.

4. Press the exit button to return to TV viewing.

Note

• This TV is programmed to retain the caption mode setting, when you
turn the TV off.

23

Off

++

Move }}Back

Language

{{

Input

{{

Key lock

{{

Captions

{{

Caption/Text

{{

ARC

{{

Auto move

{{

Special

CC 1
CC 2

CC 3
CC 4
Text 1
Text 2
Text 3
Text 4

CC 1

++

Move }}Back

Language

{{

Input

{{

Key lock

{{

Captions

{{

Caption/Text

{{

ARC

{{

Auto move

{{

Special

On
EZ Mute
Off

On

CH.

CH.

Parental Control Overview

24

Parental Control (V-Chip) can be set up with restrictions to block program viewing. The default setting is
to allow all programs to be viewed. Viewing can be blocked by the type of program and by the categories
chosen to be blocked. It is also possible to block all program viewing for a time period. To use Parental
Control, Function, the following must be set.

1. Ratings and categories to be blocked.

2. A password.

3. Enabling the lock.

V-Chip Ratings and Restriction Categories

Rating guidelines are provided by broadcast stations. Most television programs and television movies can
be blocked by TV Rating and/or Individual Categories. Movies that have been shown at the theaters or
direct-to-video movies use the Movie Rating System (MPAA) only.

For Movies Previously Shown in Theaters
Movie Ratings:

• Unblocked

• G and Above (general audiences)

• PG and Above (parental guidance suggested)

• PG-13 and Above (13 years and older)

• R and Above (restricted)

• NC-17 and Above (18 years and older)

• X (adult)

If you set PG-13 and Above, G and PG movies will be available; PG-13, R, NC-17, and X will be blocked.

For Television Programs Including Made-for-TV Movies:
General TV Ratings:

• Unblocked

• TV-G and Above (general audiences) (individual categories do not apply)

• TV-PG and Above (parental guidance suggested)

• TV-14 and Above (14 years and older)

• TV-MA (mature audiences)

Children TV Ratings:

• Unblocked

• TV-Y and Above (youth) (individual content categories do not apply)

• TV-Y7 (youth, 7 years and older)

Content Categories:

• Dialogue - sexual dialogue (applies to Unblocked, TV-PG and Above, TV-14)

• Language - adult language (applies to Unblocked, TV-PG and Above, TV-14 and Above, TV-MA)

• Sex - sexual situations (applies to Unblocked, TV-PG and Above, TV-14 and Above, TV-MA)

• Violence (applies to Unblocked, TV-PG and Above, TV-14 and Above, TV-MA)

• F Violence - fantasy violence (applies to Unblocked, TV-Y7)

Aux. block Ratings:

• Unblocked

• Blocked

25

Canadian English Language Rating System:

• Unblocked

• C and above (Children)

• C8 and above (8 years and older)

• G and above (General audiences)

• PG and above (Parental guidance suggested)

• 14+ and above (Viewers 14 years and older)

• 18+ and above (Adult)

Canadian French Language Rating System:

• Unblocked

• G (General audiences)

• 8 ans+ and above (8 years and older)

• 13 ans+ and above (13 years and older)

• 16 ans+ and above (16 years and older)

• 18 ans+ (Adult)

Blocking Scheme Setup

1. Press the menu button and then use D/Ebutton to select the
Lock menu.

2. Press the

G

and then set the initial 4-digit password “0-0-0-0” with
the number keypad. If a Parental Lock is already set, enter the
password when requested.

3. Press the

D

/

E

button to select the Lock on/off option.

4. Press the

G

and then use the

D

/

E

button to set on or off.

5. Press the

F

and then use the

D

/

E

button to select Set password.

6. Press the

G

button. Enter a four number password. Enter it again
when requested.

7. Use the

D

/

E

button to select the types of blocking to be set.

8. Press the

G

and then use the

D

/

E

button to select the types of
ratings to block.
Age block, Content block, and Canadian options, also have sub
menus; repeat steps 7 to 8 in sub menu, to set type of blocking and
rating.

9. Press the exit button to return to TV viewing.

++

Move }}Back

Lock on/off

{{

Set password

{{

MPAA

{{

Age block

{{

Content blk

{{

Aux.block

{{

Canadian

{{

Lock

On
Off

On

CH.

Connecting an Outdoor Antenna

For the best signal reception, we recommend you use an outdoor antenna.
Severely weathered antennas and antenna cables can reduce the signal quality. Before connecting an
outdoor antenna, inspect it yourself or have a TV technician inspect it. Any service center can explain the
various outdoor antenna options available to you.

Connecting a CATV Cable

If you subscribe to a CATV system, use the antenna connection described below.

1. Remove the 300 to 75 ohm adapter or the cable from the set if attached.

2. Connect the CATV cable (75 ohm coaxial cable) to the 75 ohm antenna jack.

300 Ohm Flat Wire

1. Connect the 300 ohm flat wire to screws on the
300 ohm to 75 ohm adapter.

2. Push the end of 300 ohm to 75 ohm adapter
onto the 75 ohm antenna jack.

75 Ohm Coaxial Cable

1. Screw the 75 ohm coaxial cable directly onto
the threaded 75 ohm antenna jack.

Antenna Connections

75 ohm
Antenna Jack

from cable TV source

Combination
VHF/UHF Antennas

300 ohm
Flat Wire

300 to 75
ohm Adapter

75 ohm
CATV Cable

75 ohm
Antenna
Jack

75 ohm
Coaxial
Cable

75 ohm CATV Cable

300 to 75
ohm Adapter

300 ohm Flat Wire

300 to 75 ohm
Adapter

1.

2.

TV rear

26

1. IN 1 JACKS: Connect external equipment outputs (VCR, DVD, CAMCORDER) to these
inputs. Press the tv/video button repeatedly to select

Video 1.

2. IN 2 JACKS: Connect external equipment outputs (VCR, DVD, CAMCORDER) to these inputs. Press

the tv/video button repeatedly to select

Video 2.

3. IN 3 JACKS: Connect external equipment outputs (VCR, DVD, CAMCORDER) to these inputs. Press

the tv/video button repeatedly to select

Video 3.

4. IN 4 JACKS: Connect external equipment outputs (VCR, DVD, CAMCORDER) to these inputs. Press

the tv/video button repeatedly to select

Video 4.

5. MONITOR OUTPUT JACKS: Connect a second TV or a monitor to these outputs to view the selected

program.

6. VARIABLE AUDIO OUT JACKS: Connect external analog stereo amplifier and use external front

speakers.

7. DVD/DTV INPUT JACKS: Connect component output jacks to these inputs. Use the tv/video, or

comp button to select

Component 1, or Component 2 source. Your set-top devices

may be used if they have a DVI-HDTV output connector that supports the proper version
of DVI and HDCP.

8. DVI-HDTV INPUT JACK: Connect a set-top box to this input. Use the tv/video, comp, or dvi button to

select

DVI.

Note: Avoid having a stationary fixed image remain on the screen for a long period of time. Typically a

frozen still picture from a VCR. If allowed to remain on the screen; a fixed image may remain visible
on the screen afterward.

Notice of EZ Connection A vailable

You can only select connected input sources with the tv/video, comp, or dvi button on the remote
control. Note: Whether or not an external equipment is connected to the TV, DVI input source have
priority over the other input sources.

External Equipment Connection and Viewing Setup

S-VIDEO VIDEO

- AUDIO -

L/MONO

R

IN 3

1

7

3

2

4

6

8

5

27

S-VIDEO INPUT JACK

S-VIDEO
INPUT
JACK

You can connect additional equipment, such as VCRs, camcorders etc. to your TV.
Connection panels shown here may be somewhat different from your TV.

Here is an example drawing of a typical jackpack layout.

S-VIDEO VIDEO

- AUDIO -

L/MONO

R

IN 3

(L)-AUDIO-(R)

MONO

VARIABLE

AUDIO OUTPUT

IN 4

ANT IN

L

L

75Ω

DVD/DTV INPUT

COMPONENT 1

(480i/480p/1080i)

(R)

(L)

PR

PB

Y

COMPONENT 2

(R)

(L)

PR

PB

Y

AUDIO

VIDEO

VIDEO

(L)-AUDIO-(R)

MONO

MONITOR

OUTPUT

IN 2

DVI

( )

AUDIO

IN 1

DVI-HDTV INPUT

VIDEO

S - VIDEO

External Equipment Connection and Viewing Setups

S - VIDEO

( )

VIDEO

(L)-AUDIO-(R)

MONITOR

OUTPUT

IN 2

DVI

AUDIO

IN 1

MONO

( )

VIDEO

(L)-AUDIO-(R)

MONITOR

OUTPUT

IN 2

DVI

AUDIO

IN 1

MONO

28

VCR Connections

1. Connect the audio/video output jacks from the

VCR to IN 1 (A/V) jacks on the TV.

2. Select

Video 1 source with the tv/video button.

• If you connect the audio/video output jacks
from the VCR to the IN2, IN3, or IN4 jacks on
the TV, select

Video 2, Video3, or Video 4.

3. Press the PLAY button on the VCR.
The Video playback appears on the TV screen.

Notes

• If using a monaural VCR, connect the output

jack from VCR to the AUDIO L/MONO IN jack
on TV so that the sound can be heard from both
speakers. If you connect the output jack to the
AUDIO R IN jack on the TV, the sound is only
heard from right speaker.

• When the input jacks on the front panel and

back panel are connected to external equipment
at the same time, the input jacks on the front
panel have priority over the input jacks on the
back panel of the TV.

S-VHS VCR Connections

1. Connect the S-VHS output jack from the VCR
to one of the available S-VIDEO jacks on the
TV.

2. Connect the audio output jacks from the VCR
to the IN 1 or IN 3 jacks on the TV.

3. Select

Video 1 or Video 3 source with the

tv/video button.

4. Press the PLAY button on the VCR.
Video playback appears on the TV screen.

Monitor Out Connection and Setup

1. Connect the audio/video input jacks from a
second TV/Monitor to the MONITOR OUTPUT
(A/V) jacks on the TV .

2. See the operating manual of the second TV or
monitor for further details regarding that
device’s input source selection.

TV

Playback VCR

Second TV

TV

( )

VIDEO

(L)-AUDIO-(R)

MONITOR

OUTPUT

IN 2

DVI

AUDIO

IN 1

MONO

Playback VCR

TV

29

DVD Player Connection

1.

Connect the DVD component video outputs
to Y, P

B

, PR(480i/480p/1080i) on the TV and
DVD audio outputs to right and left audio
jack (L/R) inputs on the TV.

2. Turn on the DVD player and insert a DVD.

3. Use the tv/video, or comp button to select

Component 1 or Component 2.

Note

•

This TV is programmed to remember the last
mode it was last set to, even if you turn the TV
off.

TV INPUT

Y PBP

R

DVD OUTPUT

C

b

B -Y

P

b

P

B

C

r

R -Y

P

r

P

R

Y
Y
Y
Y

TV

DVD Player

Y

P

r

P

b

(L)-AUDIO-(R)

TV

Analog/Stereo

Amplifier

VIDEO

(L)-AUDIO-(R)

VARIABLE

AUDIO OUTPUT

IN 4

MONO

(L)-AUDIO-(R)

External Stereo
Amplifier/Speakers

1.

Connect analog/stereo amplifier input jacks
to variable audio out jacks on the TV.

2. Set up your speakers through your analog/
stereo amplifier, according to the instructions
provided with the amplifier.

Note

• If you want to hear the sound through your

amplifier's speakers, set the

TV Speaker option

to

Off (Refer to p. 21).

DVD/DTV INPUT

(480i/480p/1080i)

(R)

(L)

PR

PB

Y

COMPONENT 2

(R)

(L)

PR

PB

Y

COMPONENT 1

AUDIO

VIDEO

External Equipment Connection and Viewing Setup

30

DTV (Set-top Box) Connection

1.

Connect DTV component video outputs to Y, PB, PRon the TV and audio outputs to audio (L/R)
left/right input jacks.

2. Turn on the digital set-top box.
Use the

tv/video or comp button to select Component 1 or Component 2.

• If you connected the DVI output jack from the DTV to the DVI input jack on the TV,

Use the

dvi button

to select

DVI.

Note

• For the best quality connection to view high-definition programming at the highest resolution available,

connect the DVI-HDTV output to the corresponding DVI-HDTV input that supports High-band-width
Digital Content Protection (HDCP) technology on your High-Definition monitor. Please check your HDTV
set-top box or HDTV receiver user’s manual or contact the manufacturer to find out if your HDTV
receiver provides HDCP output.

ANT IN

75Ω

L

L

(R)

(L)

(R)

(L)

Y

PB

PR

Y

PB

PR

COMPONENT 1

DVD/DTV INPUT

(480i/480p/1080i)

COMPONENT 2

S - VIDEO

( )

VIDEO

VIDEO

(L)-AUDIO-(R)

MONITOR
OUTPUT

IN 2

DVI

AUDIO

(L)-AUDIO-(R)

VARIABLE

AUDIO OUTPUT

IN 4

IN 1

AUDIO

VIDEO

MONO

MONO

DVI-HDTV INPUT

DTV Receiver

Y

P

r

P

b

(L)-AUDIO-(R)

(L)-AUDIO-(R) DVI OUTPUT

or

Programming the Remote to Operate Other Devices

31

The remote control for your projection TV is a multi-brand or
universal remote control. It can be programmed to operate most
remote-controllable devices from other manufacturers.

Note that the remote control may not control all models of other
brands.

1. Test your remote control.
To find out whether your remote control can operate the IR device
without programming, turn on the IR device such as a VCR and
press the corresponding mode button (VCR) on the remote
control, while pointing at the IR device. Test the POWER and CH
+/- buttons to see if IR device responds properly. If not, the remote
requires programming to operate the device.

2. Turn on the IR device to be programmed, then press the
corresponding mode button on the remote control.

3. Press the POWER and MUTE buttons simultaneously, the remote
control is ready to be programmed for the code.

4. There are two ways to find the right code for the IR device.
A. If you press the CH +/- buttons repeatedly, the codes will

change one at-a-time. Press the POWER button after each code
change. If the right code is found, the device will turn off.

B. Enter a code number using the number buttons on the remote.

Programming code numbers for the corresponding component
can be found on the following pages. Again, if the code is correct,
the device will turn off.

5. Press the EXIT button to store the code.

6. Test the remote control functions to see if the IR device responds
properly. If not, repeat from step 2.

1 2 3
4 5 6
7 8 9

0

tv

vcr

cable

dvd

sat

mode

light

power

tv/video

dvi

comp

avl

ccarc

enter

video

audio

vol

ch

sleepmute mts

fcr

menu

exit still

flashbk

recordstop

pause

rew

play

ff

skip

right

enter

left

down

up

3/4

4

2

3

4

5

Programming Codes

32

VCRs

AIWA 034
AKAI 016 043 046

124 125 146
AMPRO 072
ANAM 031 033 103
AUDIO DYNAMICS 012 023 039

043
BROKSONIC 035 037 129
CANON 028 031 033
CAPEHART 108
CRAIG 003 040 135
CURTIS MATHES 031 033 041
DAEWOO 005 007 010

064 065 108

110 111 112

116 117 119
DAYTRON 108
DBX 012 023 039

043
DYNATECH 034 053
ELECTROHOME 059
EMERSON 006 017 025

027 029 031

034 035 036

037 046 101

129 131 138

153
FISHER 003 008 009

010
FUNAI 034
GE 031 033 063

072 107 109

144 147
GO VIDEO 132 136
GOLDSTAR 012 013 020

101 106 114

123
HARMAN KARDON 012 045
HITACHI 004 018 026

034 043 063

137 150
INSTANTREPLAY 031 033
JCL 031 033
JCPENNY 012 013 015

033 040 066

101
JENSEN 043
JVC 012 031 033

043 048 050

055 060 130

150 152
KENWOOD 014 034 039

043 047 048
LG 255
LLOYD 034

LXI 003 009 013

014 017 034

101 106
MAGIN 040
MAGNAVOX 031 033 034

041 067 068
MARANTZ 012 031 033

067 069
MARTA 101
MATSUI 027 030
MEI 031 033
MEMOREX 003 010 014

031 033 034

053 072 101

102 134 139
MGA 045 046 059
MINOLTA 013 020
MITSUBISHI 013 020 045

046 049 051

059 061 151
MTC 034 040
MULTITECH 024 034
NEC 012 023 039

043 048
NORDMENDE 043
OPTONICA 053 054
PANASONIC 066 070 074

083 133 140

145
PENTAX 013 020 031

033 063
PHILCO 031 034 067
PHILIPS 031 033 034

054 067 071

101
PILOT 101
PIONEER 013 021 048
PORTLAND 108
PULSAR 072
QUARTZ 011 014
QUASAR 033 066 075

145
RCA 013 020 033

034 040 041

062 063 107

109 140 144

145 147
REALISTIC 003 008 010

014 031 033

034 040 053

054 101
RICO 058
RUNCO 148
SALORA 014

SAMSUNG 032 040 102

104 105 107
109 112 113
115 120 122
125

SANSUI 022 043 048

135

SANYO 003 007 010

014 102 134

SCOTT 017 037 112

129 131

SEARS 003 008 009

010 013 014
017 020 031
042 073 081

101
SHARP 031 054 149
SHINTOM 024
SONY 003 009 031

052 056 057

058 076 077

078 149
SOUNDESIGN 034
STS 013
SYLVANIA 031 033 034

059 067
SYMPHONIC 034
TANDY 010 034
TATUNG 039 043
TEAC 034 039 043
TECHNICS 031 033 070
TEKNIKA 019 031 033

034 101
THOMAS 034
TMK 006
TOSHIBA 008 013 042

047 059 082

112 131
TOTEVISION 040 101
UNITECH 040
VECTOR RESEARCH 012
VICTOR 048
VIDEO CONCEPTS 012 034 046
VIDEOSONIC 040
WARDS 003 013 017

024 031 033

034 040 053

054 131
YAMAHA 012 034 039

043
ZENITH 001 034 048

056 058 072

080 101

Brand Codes Brand Codes Brand Codes

33

SAT (Satellite Receivers)

ALPHASTAR DSR 123
AMPLICA 050
BIRDVIEW 051 126 129
BSR 053
CAPETRONICS 053
CHANNEL MASTER 013 014 015

018 036 055

CHAPARRAL 008 009 012

077
CITOH 054
CURTIS MATHES 050 145
DRAKE 005 006 007

010 011 052

112 116 141
DX ANTENNA 024 046 056

076
ECHOSTAR 038 040 057

058 093 094

095 096 097

098 099 100

122
ELECTRO HOME 089
EUROPLUS 114
FUJITSU 017 021 022

027 133 134

GENERAL INSTRUMENT 003 004 016

029 031 059

101

HITACHI 139 140
HOUSTON TRACKER 033 037 039

051 057 104
HUGHES 068
HYTEK 053
JANIEL 060 147
JERROLD 061
KATHREIN 108
LEGEND 057
LG 255
LUTRON 132
LUXOR 062 144
MACOM 010 059 063

064 065
MEMOREX 057
NEXTWAVE 028 124 125
NORSAT 069 070
PACE SKY SATELLITE143
PANASONIC 060 142
PANSAT 121
PERSONAL CABLE 117
PHILIPS 071
PICO 105
PRESIDENT 019 102
PRIMESTAR 030 110 111
PROSAT 072
RCA 066 106

REALISTIC 043 074
SAMSUNG 123
SATELLITE SERVICE CO 028 035 047

057 085
SCIENTIFIC ATLANTA 032 138
SONY 103
STARCAST 041
SUPER GUIDE 020 124 125
TEECOM 023 026 075

087 088 090

107 130 137
TOSHIBA 002 127
UNIDEN 016 025 042

043 044 045

048 049 078

079 080 086

101 135 136
VIEWSTAR 115
WINEGARD 128 146
ZENITH 001 081 082

083 084 091

120

Brand Codes Brand Codes Brand Codes

DVD Players

APEX DIGITAL 022
DENON 020 014
GE 005 006
GOLDSTAR 010 016 025
HARMAN KARDON 027
JVC 012
LG 001 010 016

025

MAGNAVOX 013

MARANTZ 024
MITSUBISHI 002
NAD 023
ONKYO 008 017
PANASONIC 003 009
PHILIPS 013
PIONEER 004 026

PROCEED 021
PROSCAN 005 006
RCA 005 006
SAMSUNG 011 015
SONY 007
THOMPSON 005 006
TOSHIBA 019 008
YAMAHA 009 018
ZENITH 010 016 025

Brand Codes Brand Codes Brand Codes

Programming Codes

34

CATV (Cable Boxes)

ABC 003 004 039

042 046 052

053
ANTRONIK 014
ARCHER 005 007 014

024
CABLE STAR 026
CENTURION 092
CENTURY 007
CITIZEN 007
COLOUR VOICE 065 090
COMBANO 080 081
COMTRONICS 019 030
DIAMOND 023
EAGLE 020 030 040
EASTERN 057 062 066
ELECTRICORD 032
GE 072
GEMINI 008 022 025

054
GI 052 074
GOLDEN CHANNEL 030
HAMLIN 049 050 055
HITACHI 052 055
HOSPITALITY 070 077
JERROLD 002 003 004

008 009 010

052 069 074

LG 255
M-NET 037
MACOM 033
MAGNAVOX 010 012 064

079
MEMOREX 001
MOVIE TIME 028 032
NSC 015 028 038

071 073
OAK 016 031 037

053
PANASONIC 044 047
PARAGON 001
PHILIPS 006 012 013

020 065 085

090
PIONEER 034 051 052

063 076
POST NEWS WEEK 016
PRUCER 059
PTS 011 048 071

072 073 074
PULSAR 001
RCA 047
REGAL 049 050
REGENCY 057
REMBRANT 025
RK 091

SAMSUNG 030 068
SCIENTIFIC ATLANTA 003 011 041

042 043 045

046
SHERITECH 022
SIGNAL 030
SIGNATURE 052
SL MARX 030
SPRUCER 047 078
STARCOM 002 004 008

009
STARGATE 008 030
SYLVANIA 067
TADIRAN 030
TANDY 017
TEXSCAN 029 067
TOCOM 039 040 056
TOSHIBA 001
UNIKA 007 014 024
UNITED CABLE 004 053
UNIVERSAL 007 014

024 026 027

032 035
VIEWSTAR 012 015 018

086 087 088

089
ZENITH 001 060 093

Brand Codes Brand Codes Brand Codes

35

Maintenance

Careful and regular cleaning can help extend the amount of time you will have your new
projection TV. Be sure to turn the power off and pull out the power plug from the wall power
outlet before you begin any cleaning.

1. Here’s a great way to keep the dust off your screen for a while. Wet a soft cloth in
a mixture of lukewarm water and a little fabric softener or dish washing
detergent. Wring the cloth until it’s almost dry, and then use it to wipe the screen.

2. Make sure the excess water is off the screen, and then let it air-dry before you
turn on your TV.

1. Use a soft cloth with a mild soap solution to wipe the cabinet.

2. Rinse the cloth and wipe the cabinet again.

3. Let the cabinet air-dry before turning the TV on.

If you expect to leave your TV dormant for a long time (such as a vacation), unplug
the power cord to protect against possible damage from lightning or power surges.
If you use an off-air antenna, you may also want to disconnect it from the back of
your TV before leaving.

Screen Cleaning

Cabinet Cleaning

Extended Absence

Product Specifications

36

Model

R40W46, R40W46F, R45W46, R45W46F

Power requirements AC 120V
Television system NTSC
Television channels VHF : 2 ~ 13, UHF : 14 ~ 69

Cable : 01 ~ 125

Power consumption See the back of the TV
External antenna impedance 75 Ω
Audio output 15W + 15W
External Equipment Video input jacks (4 sets)

Input/output jacks and ports S-video input jacks (2)

Component input jacks (2 sets)
DVI-HDTV input port (1)
Variable audio output jacks (1 set)
Monitor output jack (1)

SYMPTOMS

No power

No picture or sound

Poor picture but good sound

Poor reception

Lines in picture

Ghosts (multiple images)

Remote control does not work.

Cannot tune desired channel.

CHECK THESE THINGS

Is power cord plugged in?
Is television turned on?

Check batteries in remote control.
Try another channel (station trouble).
Check antenna connections.
Check for local interference.
Adjust the antenna.

Adjust the picture settings.
Reprogram channels with EZ Scan.

T roubleshooting Checklist

37

Notes

38

Notes

39

P/N : 3828VA0432J (MP03AA)

LG ELECTRONICS CORPORATION

ZENITH Projection TV Limited Warranty - USA

LG will repair or replace your product, at LG’s option, if it proves to be defective in material or workmanship
under normal use, during the warranty period ("Warranty Period") listed below, effective from the date ("Date of
Purchase") of original consumer purchase of the product. This warranty is good only to the original purchaser of
the product and effective only when used in the United States, excluding U.S. Territories.

THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING
WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. TO THE EXTENT ANY IMPLIED WARRANTY IS REQUIRED BY LAW, IT IS LIMITED IN
DURATION TO THE EXPRESS WARRANTY PERIOD ABOVE. LG WILL NOT BE LIABLE FOR ANY
INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL OR PUNITIVE DAMAGES OF ANY NATURE, EVEN
IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, INCLUDING WITHOUT LIMITATION, LOST
REVENUES OR PROFITS, LOST OR CORRUPTED PROGRAMMING OR DATA, OR ANY OTHER DAMAGE
WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE. Some states do not allow the exclusion or

limitation of incidental or consequential damages or limitation on how long an implied warranty lasts, so the
above exclusion or limitation may not apply to you. This warranty gives you specific legal rights and you may
also have other rights that may vary from state to state.

THIS LIMITED WARRANTY DOES NOT APPLY TO:

1.Damages or operating problems that result from shipping, installation, adjustment of user controls, calibration,
maintenance or failure to maintain, or separate system components; and

2.Damages or operating problems that result from normal wear and tear, misuse, abuse, operation outside
environmental specifications or contrary to the requirements or precautions in the Operating Guide, accident,
lightning strikes or other natural causes, unauthorized modification or alteration, incorrect electrical current or
voltage, reception problem caused by inadequate home antenna or faulty antenna connections, computer
software, institutional or commercial use, or other causes not arising out of defect in material or workmanship.

3. Therefore, the cost of repair or replacement of such a defective product shall be borne by the
consumer.

CUSTOMER INTER-ACTIVE CENTER NUMBERS:

LG CUSTOMER INTERACTIVE CENTER
201 JAMES RECORD ROAD HUNTSVILLE
ALABAMA 35824

WARRANTY PERIOD:

LABOR: One Year from the Date of Purchase.

Parts: One Year from the Date of Purchase.

CRT Picture Tubes: 2 Years from the Date of

Purchase.

* Parts replaced are warranted for the remaining

portion of the original warranty period.

HOW SERVICE IS HANDLED

In-Home Service: Please retain dealer’s dated bill of sale

or delivery ticket as evidence of the Date of Purchase for
proof of warranty, and submit a copy of the bill of sale to
the service person at the time warranty service is provided.

Please call 1-877-9Zenith (1-877-993-6484) to locate
your nearest LG Authorized Service Center.

Replacement parts may be new or factory remanufactured.

Call 1-877-9Zenith (1-877-993-6484) (24 hours a day,
365 days per year) and select an appropriate option
from the menu.

Or visit our website at http://www.zenithservice.com

For nearest Authorized Service Center,
Where to buy, Product Assistance, or
Customer Assistance
