Zenith H19E34Y, H20E34Y, H25E34Y OPERATING GUIDE
© Copyright 2002, Zenith Electronics Corporation
table of contents
page
5
Installation / Operating Guide | Warranty
Model Numbers | H19E34Y | H20E34Y | H25E34Y ConciergeTMTVs
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.
REFER TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence
of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature accompanying the appliance.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
POWER CORD POLARIZATION:
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
ATTENTION: POUR ÉVITER LES CHOCS ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.
NOTE TO CABLE/TV INSTALLER:
This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the National Electric Code
(U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point of the cable entry as practical.
REGULATORY INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
Do not attempt to modify this product in any way without written authorization from Zenith Electronics Corporation.
Unauthorized modification could void the user’s authority to operate this product.
COMPLIANCE:
The responsible party for this product’s compliance is:
Zenith Electronics Corporation, 2000 Millbrook Drive, Lincolnshire, IL 60069, USA. Phone: 1-847-941-8000.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
2-WIRE COMM WARN
ConciergeTMis a trademark of Zenith Electronics Corporation
© Copyright 2002 Zenith Electronics Corporation
RECORD THE MODEL NUMBER
The model and serial number of the ConciergeTMTV are located
on the back of the cabinet. For future reference, we suggest
that those numbers be recorded here:
MODEL NO.____________________________________
SERIAL NO.____________________________________
For Customer Support/Service please call:
1-888-865-3026
www.zenith.com
PAGE 3
206-3743
1. Read Instructions
All the safety and operating instructions should be read
before the product is operated.
2. Follow Instructions
All operating and use instructions should be followed.
3. Retain Instructions
The safety and operating instructions should be retained for
future reference.
4. Heed Warnings
All warnings on the product and in the operating instructions should be adhered to.
5. Cleaning
Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
6. Water and Moisture
Do not use this product near water for example, near a
bath tub, wash bowl, kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool.
7. Accessories, Carts, and Stands
Do not place this product on a slippery or tilted surface, or
on an unstable cart, stand, tripod, bracket, or table. The
product may slide or fall, causing serious injury to a child
or adult, and serious damage to the product. Use only with
a cart, stand, tripod, bracket, or table recommended by the
manufacturer, or sold with the product. Any mounting of
the product should follow the manufacturer’s instructions,
and should use a mounting accessory recommended by the
manufacturer.
8. Transporting Product
A product and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may
cause the product and cart combination to overturn.
9. Attachments
Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
10. Ventilation
Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to
protect it from overheating, and these openings must not
be blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug, or
other similar surface. This product should not be placed in
a built-in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s instructions have been adhered to.
11. Power Sources
This product should be operated only from the type of
power source indicated on the marking label. If you are not
sure of the type of power supply to your home, consult
your product dealer or local power company. For products
intended to operate from battery power, or other sources,
refer to the operating instructions.
12. Power Cord Polarization
This product is equipped with a polarized alternating-current power plug (a plug having one blade wider than the
other). This plug will fit into the power outlet only one
way. This is a safety feature. If you are unable to insert the
plug fully into the outlet, try reversing the plug. If the
plug should still fail to fit, contact your electrician to
replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
13. Power Cord Protection
Power-supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit
from the product.
Important safeguards for you and your new product
This product has been manufactured and tested with your safety in mind. However, improper use can result in potential
electrical shock or fire hazards. To avoid defeating the safeguards that have been built into the new product, please read
and observe the following safety points when installing and using the new product, and save them for future reference.
Observing the simple precautions discussed in this operating guide can help get many years of enjoyment and safe operation that are built into the new product.
(Continued on next page)
IMPORTANT SAFETY INSTRUCTIONS
PORTABLE CART WARNING
(Continued from previous page)
14. Outdoor Antenna Grounding
If an outside antenna or cable system is connected to the
product, be sure the antenna or cable system is grounded so
as to provide some protection against voltage surges and
built-up static charges. Article 810 of the National Electrical
Code (U.S.A.), ANSI/ NFPA 70 provides information with
regard to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of
antenna-discharge unit, connection to grounding electrodes,
and requirements for the grounding electrode.
15. Lightning
For added protection for this product (receiver) during a
lightning storm, or when it is left unattended and unused
for long periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will prevent
damage to the product due to lightning and power-line
surges.
16. Power Lines
An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light or
power circuits, or where it can fall into such power lines or
circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such
power lines or circuits as contact with them might be fatal.
17. Overloading
Do not overload wall outlets and extension cords as this can
result in a risk of fire or electric shock.
18. Object and Liquid Entry
Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
19. Servicing
Do not attempt to service this product yourself as opening
or removing covers may expose you to dangerous voltage or
other hazards. Refer all servicing to qualified service personnel.
20. Damage Requiring Service
Unplug this product from the wall outlet and refer servicing
to qualified service personnel under the following conditions:
a. If the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the
product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following
the operating instructions. Adjust only those controls that
are covered by the operating instructions as an improper
adjustment of other controls may result in damage and will
often require extensive work by a qualified technician to
restore the product to its normal operation.
e. If the product has been dropped or the cabinet has been
damaged.
f. If the product exhibits a distinct change in performance.
21. Replacement Parts
When replacement parts are required, be sure the service
technician has used replacement parts specified by the manufacturer or have the same characteristics as the original
part. Unauthorized substitutions may result in fire, electric
shock, or other hazards.
22. Safety Check
Upon completion of any service or repairs to this product,
ask the service technician to perform safety checks to determine that the product is in proper operating condition.
23. Wall or Ceiling Mounting
The product should be mounted to a wall or ceiling only as
recommended by the manufacturer. The product may slide or
fall, causing serious injury to a child or adult, and serious
damage to the product.
24. Heat
The product should be situated away from heat sources such
as radiators, heat registers, stoves, or other products
(including amplifiers) that produce heat.
PAGE 4
206-3490-O
Antenna Lead in Wire
Antenna Discharge Unit
(NEC Section 810-20)
Grounding Conductor
(NEC Section 810-21)
Ground Clamps
Power Service Grounding
Electrode System (NEC
Art 250, Part H)
Ground Clamp
Electric Service
Equipment
Example of Grounding According to National Electrical
Code Instructions
NEC - National Electrical Code
IMPORTANT SAFETY INSTRUCTIONS
206-3745
PAGE 5
Table of Contents
Turn to the next page to begin the TV set up
Purchase the Optional Installer’s Remote
To perform a normal installation set up, you need an installer’s remote like the LP702. The LP702 is shown and described
in later sections. The installer remote allows access to the Installer’s menus, and User menus. The installer remote has
Menu, Select, and Adjust Keys (Down/Left/Right arrow) keys.. To purchase the LP702 remote, see your Zenith Dealer.
Installer/Hotel Note:
Pages 13, 32, 33, 34, and 35 contain information and menus which the guest can use to operate the
TV. It is recommended that these four pages be copied and included with the literature packet that
the hotel provides to the guest.
Safety Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Important Safety Information . . . . . . . . . . . . . . . . . . 3
Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Step 1. Hook Up TV
TV and other Equipment Hookups
Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Cable service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Antenna with VCR . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Cable service with VCR . . . . . . . . . . . . . . . . . . . . . . . 9
External Speaker . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Step 2. Channel Search and Reception Setup
Auto Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
(Select Antenna, or cable service and perform channel
search)
Front Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . 12
Guest Remote Key Functions . . . . . . . . . . . . . . . . . . 13
Installer’s Remote Key Functions . . . . . . . . . . . . . . . . 14
On-Screen Menus Overview . . . . . . . . . . . . . . . . . . . 15
Step 3. Customize the ConciergeTMTV’s Features
Setup Menu (Start with page 11, Auto Program)
Add/Del/Blank . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Channel Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Clock Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Timer (On/Off Timer) . . . . . . . . . . . . . . . . . . . . . . . 19
Captions (Caption/Text) . . . . . . . . . . . . . . . . . . . . . 20
Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Video Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Installer Parental Control Menu . . . . . . . . . . . . 23 - 24
Other Menus and On-Screen Displays . . . . . . . . . . . . . 25
Managing the Channel Banks . . . . . . . . . . . . 26 - 27 - 28
Installers Menus . . . . . . . . . . . . . . . . . . . . 29 - 30 - 31
LT2000 Quickset II Clone Programmer . . . . . . 32 - 33 - 34
Guest Operation Section (Copy for guest usage)
Guest Remote Control Key Functions . . . . . . . . . . . . . 13
Guest Parental Control Menu . . . . . . . . . . . . 35 - 36 - 37
Guest Menus and On-Screen Displays . . . . . . . . . . . . . 38
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 - 43
Warranty for Concierge
TM
Series TVs . . . . . . . . . Back Cover
ConciergeTMis a trademark of Zenith Electronics Corporation
PAGE 6
206-3745
Mini glossary
75 OHM RF CABLE The wire that comes from an off-air antenna or cable service provider. Each end looks like a hex shaped nut with a wire
sticking through the middle, and it screws onto the threaded jack on the back of your TV.
A small device that connects a two-wire 300 ohm antenna to a 75 ohm RF jack. They are usually about an inch long with two screws
on one end and a round opening with a wire sticking out on the other end.
Antenna Hook Up
Connect an over-the-air antenna to
the Concierge TV
If you have a 75 ohm RF cable, then you don’t need any
adapters!
A 300 to 75 ohm adapter is not included with the Zenith
Concierge TV.
300 TO 75 OHM
ADAPTER
Antenna
Flat wire
(300 ohm)
300/75 ohm
Adapter
TV Back Panel
(Expanded View)
TV Back
VIDEO
IN
ANTENNA
CABLE
M.P.I.
Super
Port
SPEAKER
OUT
AUDIO
IN
RF coaxial wire
(75ohm)
Antenna
TV Back Panel
(Expanded View)
TV Back
VIDEO
IN
ANTENNA
CABLE
M.P.I.
Super
Port
SPEAKER
OUT
AUDIO
IN
Locate the Antenna/Cable jack on the back of the
Concierge TV.
Connect the antenna wire that runs from the wall,
according to one of the diagrams to the right.
Remove the back of the remote and put in two AA
batteries.
Plug in the TV. Concierge TV is designed to operate
on standard current, 120-volt 60 Hertz AC. Do not
attempt to operate it on DC power.
Go to page 11 to Auto Program the TV.
back of
remote
120 V AC
60 Hz
1
2
3
4
5
PAGE 7
206-3745
Cable Service Hook Up (CATV)
If you’re using a cable box, leave the TV tuned to channel 3
or 4 and use the cable box to change channels.
If you’re using a cable box, Auto Program might only find the
channel your cable service is on (usually channel 3 or 4).
Cable TV
Wall Jack
RF Coaxial Wire
(75ohm)
TV Back Panel
(Expanded View)
TV Back
VIDEO
IN
ANTENNA
CABLE
M.P.I.
Super
Port
SPEAKER
OUT
AUDIO
IN
Cable TV
Wall Jack
Cable Box
In
Out
3 4
output
switch
RF Coaxial Wire
(75ohm)
TV Back Connections Panel
(Expanded View)
TV Back
VIDEO
IN
Super
Port
SPEAKER
OUT
AUDIO
IN
ANTENNA
CABLE
M.P.I.
Locate the Antenna/Cable jack on the back of the
Concierge TV.
Connect the cable service wire that runs from the wall,
according to one of the diagrams to the right.
Remove the back of the remote and put in two AA batteries.
Plug in the TV. The Concierge TV is designed to operate
on standard current, 120-volt 60 Hertz AC. Do not
attempt to operate it on DC power.
Go to page 11 to Auto Program the Concierge TV.
back of
remote
120 V AC
60 Hz
1
2
3
4
5
Connect cable service to the Concierge TV
PAGE 8
206-3745
Antenna With VCR Hook Up
Connect an off-air antenna and VCR to the Concierge TV
No A/V cables are included with the TV.
Flat wire
(300 ohm)
Antenna
300/75 ohm
Adapter
TV Back Panel
(Expanded View)
TV Back
VIDEO
IN
ANTENNA
CABLE
M.P.I.
Super
Port
SPEAKER
OUT
AUDIO
IN
In
Out
Audio
Video
3 4
VCR Back
VCR Back AV Panel
output
switch
A/V Cables
Not included
with TV
RF Coaxial Wire
(75ohm)
Antenna
TV Back Panel
(Expanded View)
TV Back
VIDEO
IN
ANTENNA
CABLE
M.P.I.
Super
Port
SPEAKER
OUT
AUDIO
IN
In
Out
Audio
Video
3 4
VCR Back
VCR Back AV Panel
output
switch
Locate the Antenna/Cable jack on the back of
the VCR.
Connect the antenna wire that runs from the
antenna, according to one of the diagrams to
the right. Make other connections as needed.
Remove the back of the remote and put in two
AA batteries.
Plug in the TV. The Concierge TV is designed to
operate on standard current, 120-volt 60 Hertz
AC. Do not attempt to operate it on DC power.
Go to page 11 to Auto Program the TV.
back of
remote
120 V AC
60 Hz
1
2
3
4
5
PAGE 9
206-3745
Cable Service (CATV) with VCR Hook Up
Connect a VCR and Cable service to the Concierge TV
Leave the VCR and the television tuned to channel
three and use the cable box to change channels.
No A/V cables are included with the TV.
Cable TV
Wall Jack
Cable box
In
Out
3 4
output
switch
A/V Cables
Not included
with TV
RF Coaxial Wire
(75ohm)
TV Back Panel
(Expanded View)
TV Back
VIDEO
IN
ANTENNA
CABLE
M.P.I.
Super
Port
SPEAKER
OUT
AUDIO
IN
In
Out
Audio
Video
3 4
VCR Back
VCR Back AV Panel
output
switch
Cable TV
Wall Jack
A/V Cables
Not included
with TV
RF Coaxial Wire
(75ohm)
TV Back Panel
(Expanded View)
TV Back
VIDEO
IN
ANTENNA
CABLE
M.P.I.
Super
Port
SPEAKER
OUT
AUDIO
IN
In
Out
Audio
Video
3 4
VCR Back
VCR Back AV Panel
output
switch
Locate the Antenna/Cable jack on the back
of the VCR.
Connect the cable service wire that runs
from the wall, according to one of the diagrams to the right. Make other connections
as needed.
Remove the back of the remote and put in
two AA batteries.
Plug in the TV. The Concierge TV is designed
to operate on standard current, 120-volt 60
Hertz AC. Do not attempt to operate it on
DC power.
Go to page 11 to Auto Program the TV.
back of
remote
120 V AC
60 Hz
1
2
3
4
5
PAGE 10
206-3745
External Speaker Hook Up
Locate the Audio In jack on the back of the external speaker.
Connect a standard audio cable from the Speaker
Out jack on the TV, to the Audio In jack on the
external speaker.
Audio In
Speaker back
TV Back Panel
(Expanded View)
TV Back
VIDEO
IN
ANTENNA
CABLE
M.P.I.
Super
Port
SPEAKER
OUT
AUDIO
IN
1
2
Connect an external speaker to the Concierge TV
PAGE 11
206-3745
Auto Program (Channel Search)
Use Auto Program to specify Antenna or cable service
incoming signal source and automatically store all of the
channels that are found by channel search
Using an Installer remote control, press the POWER key to
turn on the Concierge TV.
Press the MENU key to show the SETUP MENU.
Using SELECT on the remote control, highlight AUTO
PROGRAM on the screen.
Press the Right or Left ADJ (Adjust) arrow to go to the
Auto Program menu.
Using SELECT, choose either CABLE TV or OFF AIR ANTENNA
on your screen.
Press the Right or Left ADJ arrow key to begin the Channel
Search.
Press ENTER when the channel search is complete.
1
2
3
4
5
6
7
TIMER
CH PREVIEW
ENTER
1
2
3
4
5
6
7
8
9
0
POWER
FLSHBK
MUTE
VOL
UME
CHANNEL
TV/FM
CC
MENU
ALARM
ADJ
ADJ
SELECT
3/5
AUTO PROGRAM
ADD/DEL/BLNK
CH. LABELS
CLOCK SET
TIMER
CAPTIONS
LANGUAGE
TO PROGRAM
Mini glossary
OFF AIR ANTENNA If the guest can only view over-the-air broadcasts, select Antenna.
CABLE If you provide cable service to your guests, select Cable.
Note: Auto Program finds channels being received by the TV
tuner.
Cable will not work unless the lodge provides a cable service.
4/6
1
7
2
PAGE 12
206-3745
Front Panel Controls
1
2
3
4
Use the front control panel to access the menus or just operate the TV
Note: Item 10 Key Defeat, in the installer’s menu allows the installer to:
Set Menu Option 10, Key defeat to “0” - Front panel controls give access to menus.
Set Menu Option 10, Key defeat to “1” - Menus not available with front panel controls.
Front panel control menu operation buttons are not
labeled and are not usually available to the guest.
You can use Channel to tune to available channels and
Volume to set the sound level, regardless of the key
defeat setting.
Camport jacks are not available on some models.
Press POWER to turn on your TV.
To access the menus, press the MENU button on
the control panel. Cycle through the various
menus by pressing MENU repeatedly.
Use the SELECT button to highlight the option
you want to modify.
Use either the Right or Left ADJUST button to
modify the option you have chosen.
Press CAPTIONS to turn captions on and off.
The menu will disappear after a few seconds.
TV Operation
Power turns the TV on and off.
Channel Up/Down tunes to next channel.
Volume Up/Down adjusts sound level.
Captions turns selected Caption/Text option on
and off.
Camport: Front Audio/Video Inputs
Video Input
L-Audio-R Inputs
Note: TV sound is always monaural. Left/Right
Audio input is processed into monaural sound
by the TV.
5
adjust select menu
captions volume channel power
L audio R
video in
1
3
2
Typical Front Panel Controls
A
C
B
D
F
E
A
B
C
D
E
F
PAGE 13
206-3683
Guest Remote Key Functions
TIMER ALARM
CH PREVIEW
ENTER
1
2
3
4
5
6
7
8
9
0
POWER
FLSHBK
MUTE
VOL
UME
CHANNEL
CC
FLASHBK (FLASHBACK)
Returns to the last channel viewed.
POWER
Turns TV On or Off
.
CHANNEL (UP/DOWN)
Scrolls through available channels, and
the Video Channel (Audio/Video source).
MUTE
Turns sound Off and On, while the
picture remains.
ENTER
Press to view the Channel/Time
display or to remove any on-screen
display or menu.
NUMBER KEYPAD
Selects channels directly: enter channel
numbers and press ENTER to go to new
channel
.
remote control part number
SC652A
124-213-02A
TIMER
Press repeatedly to choose a TV
turn-off time, up to 4-hours.
Use to pick AM/PM in the Alarm menu.
VOLUME LEFT/RIGHT
Adjusts the sound level.
CHANNEL PREVIEW
Displays the available TV channels, including access to guest’s Parental Control
menu. Allows guest to select the Aux
Channel. (Use the Audio/Video jacks on
the back of the TV as the source of the
picture and sound.)
CC (CLOSED CAPTIONING)
Press to access closed captions.
Press ENTER to exit.
A brief overview of the keys on the guest remote and what they do
ALARM
Press to display menu, then follow onscreen instructions to set a TV turn-on
time.
PAGE 14
206-3490-O
Installer Remote Key Functions
TIMER
CH PREVIEW
ENTER
1
2
3
4
5
6
7
8
9
0
POWER
FLSHBK
MUTE
VOL
UME
CHANNEL
TV/FM
CC
MENU
ALARM
ADJ
ADJ
SELECT
FLASHBK (FLASHBACK)
Returns to the last channel viewed.
POWER
Turns TV On or Off
.
CHANNEL (UP/DOWN)
Flips through available channels.
MUTE
Turns sound Off and On, while the
picture remains.
ENTER
Press to view the Channel/Time display or
to remove any on-screen display or menu.
NUMBER KEYPAD
Selects channels directly and enters
numeric values for some options
.
remote control part number
LP702
124-213-04
TIMER
Press repeatedly to choose a TV
turn-off time, up to 4-hours.
Use to pick AM/PM in the Clock/Alarm
menus, on some TVs.
VOLUME LEFT/RIGHT
Adjusts the sound levels.
CC (CLOSED CAPTIONING)
Press to access closed captions.
Press ENTER to exit.
An overview of the keys on the LP702 installer’s remote and what they do
ALARM
Press to go to the Alarm menu. Set a
time for the TV to turn itself on.
MENU/SELECT/ADJ (ADJUST)
Press MENU repeatedly to scroll through
either the Installer, or User menus. Use
SELECT to choose an option and ADJ
(adjust) to change the selected option.
CHANNEL PREVIEW
Gives installer access to the guest’s
menus. Displays the available TV channels and hotel guest’s Parental Control
menu. Allows user to select the Aux
Channel. (Use the Audio/Video jacks on
the back of the TV as the source of the
picture and sound.)
TV/FM
Selects TV or Radio on TVs equipped with
FM radio.
Loading...
