TheaterLite™
DXG-210
operating guide
3
WARNING:
TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature accompanying the appliance
.
WARNING:
TO PREVENT FIRE OR SHOCK HAZARDS, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
POWER CORD POLARIZATION:
CAUTION: This product is equipped with a three-wire grounding type alternating current line plug. This plug will fit into
the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, contact
your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the three-wire ground type plug.
NOTE TO CABLE/TV INSTALLER (when projector is connected to tuner):
This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the National Electric Code
(U.S.A.). The code provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point of the cable entry as practical.
REGULATORY INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures: • Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
Do not attempt to modify this product in any way without written authorization from Zenith Electronics Corporation.
Unauthorized modification could void the user’s authority to operate this product.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
2
54
(Continued from previous page)
14. Outdoor Antenna Grounding
If an outside antenna or cable system is connected to the
product, be sure the antenna or cable system is grounded
so as to provide some protection against voltage surges and
built-up static charges. Article 810 of the National
Electrical Code (U.S.A.), ANSI/ NFPA 70 provides information with regard to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors, location of antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
15. Lightning
For added protection for this product (receiver) during a
lightning storm, or when it is left unattended and unused
for long periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will prevent
damage to the product due to lightning and power-line
surges.
16. Power Lines
An outside antenna system should not be located in the
vicinity of overhead power lines or other electric light or
power circuits, or where it can fall into such power lines or
circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such
power lines or circuits as contact with them might be fatal.
17. Overloading
Do not overload wall outlets and extension cords as this
can result in a risk of fire or electric shock.
18. Object and Liquid Entry
Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the product.
19. Servicing
Do not attempt to service this product yourself as opening
or removing covers may expose you to dangerous voltage or
other hazards. Refer all servicing to qualified service personnel.
20. Damage Requiring Service
Unplug this product from the wall outlet and refer servicing
to qualified service personnel under the following conditions:
a. If the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the
product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following
the operating instructions. Adjust only those controls
that are covered by the operating instructions as an
improper adjustment of other controls may result in
damage and will often require extensive work by a quali-
fied technician to restore the product to its normal
operation.
e. If the product has been dropped or the cabinet has been
damaged.
f. If the product exhibits a distinct change in performance.
21. Replacement Parts
When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer or have the same characteristics as the original
part. Unauthorized substitutions may result in fire, electric
shock, or other hazards.
22. Safety Check
Upon completion of any service or repairs to this product,
ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
23. Wall or Ceiling Mounting
The product should be mounted to a wall or ceiling only as
recommended by the manufacturer.
24. Heat
The product should be situated away from heat sources
such as radiators, heat registers, stoves, or other products
(including amplifiers) that produce heat.
IMPORTANT SAFETY INSTRUCTIONS
Antenna Lead in Wire
Antenna Discharge Unit
(NEC Section 810-20)
Grounding Conductor
(NEC Section 810-21)
Ground Clamps
Power Service Grounding
Electrode System (NEC
Art 250, Part H)
Ground Clamp
Electric Service
Equipment
Example of Grounding According to
National Electrical Code Instructions
NEC - National Electrical Code
IMPORTANT SAFETY INSTRUCTIONS
Important safeguards for you and your new product
Your product has been manufactured and tested with your safety in mind. However, improper use can result in potential electrical shock or fire hazards. To avoid defeating the safeguards that have been built into your new product, please read and
observe the following safety points when installing and using your new product, and save them for future reference.
Observing the simple precautions discussed in this booklet can help you get many years of enjoyment and safe operation that
are built into your new product.
This product complies with all applicable U.S. Federal safety requirements, and those of the Canadian Standards Association.
1. Read Instructions
All the safety and operating instructions should be read
before the product is operated.
2. Follow Instructions
All operating and use instructions should be followed.
3. Retain Instructions
The safety and operating instructions should be retained for
future reference.
4.Heed Warnings
All warnings on the product and in the operating instructions should be adhered to.
5. Cleaning
Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
6. Water and Moisture
Do not use this product near water - for example, near a
bath tub, wash bowl, kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool.
7.Accessories
Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall, causing serious
injury to a child or adult, and serious damage to the product. Use only with a cart, stand, tripod, bracket, or table
recommended by the manufacturer, or sold with the product. Any mounting of the product should follow the manufacturer’s instructions, and should use a mounting accessory
recommended by the manufacturer.
8. Transporting Product
A product and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may
cause the product and cart combination to overturn.
9. Attachments
Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
10. Ventilation
Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the product and to
protect it from overheating, and these openings must not
be blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug, or other
similar surface. This product should not be placed in a
built-in installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions
have been adhered to.
11. Power Sources
This product should be operated only from the type of
power source indicated on the marking label. If you are not
sure of the type of power supply to your home, consult
your product dealer or local power company. For products
intended to operate from battery power, or other sources,
refer to the operating instructions.
12. Line-Cord Polarization
This product is equipped with a 3-wire grounding type
alternating-current line plug. This plug will fit into the
power outlet only one way. This is a safety feature. If you
are unable to insert the plug fully into the outlet, try
reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the three-wire ground-type
plug.
13. Power-Cord Protection
Power-supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs,
convenience receptacles, and the point where they exit
from the product.
PORTABLE CART WARNING
Page
Using the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
15
6.1 The Menu System . . . . . . . . . . . . . . . . . . . . . . . . . .15
6.1.1 Main menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
6.2 Set-up Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
6.2.1 Picture orientation . . . . . . . . . . . . . . . . . . . . . . . . . .17
6.2.2 Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
6.2.3 Quick menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
6.2.4 Zap menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
6.2.5 Show accumulated lamp time . . . . . . . . . . . . . . . . .19
6.3 Control Panel Menu . . . . . . . . . . . . . . . . . . . . . . . . .20
6.3.1 Picture control . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
6.3.2 Zoom/Focus adjustments . . . . . . . . . . . . . . . . . . . . .21
6.3.3 Color manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
6.3.4 Picture positioning . . . . . . . . . . . . . . . . . . . . . . . . . .21
6.3.5 Synchronization Adjustments . . . . . . . . . . . . . . . . . .22
Maintenance
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
What do I do if (Trouble shooting)
. . . . . . . . . . .23
7
8
6
Contents
Page
Before you start
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
1.1 Color coding for ease of use . . . . . . . . . . . . . . . . . . . .8
1.2 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
1.2.1 Video accessories . . . . . . . . . . . . . . . . . . . . . . . . . . .8
1.2.2 Other cables/accessories . . . . . . . . . . . . . . . . . . . . . .8
1.2.3 Optional cables and accessories . . . . . . . . . . . . . . . . .8
1.3 Insert batteries in the remote control . . . . . . . . . . . . 9
1.4 Connect projector to power supply . . . . . . . . . . . . . . 9
Important information
. . . . . . . . . . . . . . . . . . . . . . . 9
Connecting a computer to the projector
. . . . .10
Connecting a video source to the projector
.11
Using the projector
. . . . . . . . . . . . . . . . . . . . . . . . .12
5.1 Different program modes for the projector . . . . . . . .12
5.2 Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
5.3 Using the touch panel on the projector . . . . . . . . . . .14
5.4 Adjusting the height and angle of the projector . . . . .15
5.5 Aspect Ratio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
1
2
3
4
5
6 7
1.3 Insert batteries in the
remote control
Figure 5 shows the remote control with the
battery lid removed. Slide off the battery lid
and insert the batteries with the + and - poles
correct. Slide the battery lid back on again.
1.4 Connect projector to
power supply
Plug in your projector. Do not plug it into a
switched outlet. Your Zenith projector is
designed to operate on standard current,
120-volt, 60 Hertz AC. Do not attempt to
operate it on DC current.
The registration card or copy of invoice is your
proof of purchase. Please make sure that the
registration card is returned in order to get the
warranty service you are entitled to.
NOTE! Please use caution when
transporting the unit.
WARNING! Tampering with or opening
the unit can be dangerous. For replacement of the lamp or service, please
call 1-888-865-3026, toll free,
24 hours a day.
Figure 5 Inserting batteries in remote control
2. Important
information
8
1. Before you start
Thank you for choosing a
Zenith projector
Your Zenith projector will display high brightness images with vivid colors, even under normal light conditions. As input for your presentation you can use CD-ROM, Photo CDs, Laser
Disks, DVD, normal VCRs or computers. You can
have multiple inputs connected simultaneously
for a high impact multimedia presentation.
Thanks to the unique Graphical User Interface,
the projector offers true plug-and-play operation.
1.1 Color coding for
ease of use
All connectors, plugs and buttons on the product are color coded to make the connections
and operation easy and intuitive. The following colors are used:
• Computer -gray (PC)
• Video (Composite) -yellow
• S-video -dark blue
• Stand by -red
• Auto setup -green
1.2 Accessories
Please take a few minutes to make sure that
your Zenith projector contains all the
necessary parts:
1.2.1 Video accessories
• Super-video cable
• Composite video cable
1.2.2 Other cables/accessories
• Power cable
• Remote control including batteries (type
AAA/LR03)
1.2.3 Optional accessories
• Ceiling mount kit
8
9
MENU
ON
ZAP 1
QUICK
OFF
ZAP 2
The procedure for connecting
a video source to the projector is the same for S-Video
and Composite video.
SECAM, PAL N and PAL M modes are manually
selected by pressing the “Green Button“. If the
right format is not found the first time, press
again. The video format is stored separately
for each connector.
1. Make sure that the video source
and the projector are switched off.
2. Connect the video cable from the Video
out connector of the video source to the
correct video connector on the projector
plug panel.
4. When all the connections are done and
verified, switch on the video source and
the projector.
5. The projector will now automatically
display the pictures from the video source.
If not, see the section ‘What do I do if’.
4. Connecting a video
source to the
projector
Figure 6 Connecting to video sources
VIDEO
RS-232
MONITOR IN
CRB
H-SYNC V-SYNC
S-VIDEO
The procedure for connecting
a computer to the projector is
the same for all types of
computers.
1. Make sure the computer, monitor and
projector are switched off.
2. Identify the RGB out connector on the
back of your computer (where you connect
a monitor to the computer).
3. Connect the RGB output from the computer
using a 15 pin VGA type cable (not included) to the connector on the projector
labeled “monitor in”.You can optionally use
the gold BNC connectors to connect to
your computer.
4. Turn on the projector and then the computer. The computer image should now be
projected from the projector. If the computer’s image is not displayed simultaneously on the monitor, see the attached
section “what to do if”.
3.Connecting a
computer to the
projector
11
10
The Remote control is very easy to operate. It
has only six keys in addition to the pressure
sensing mouse pad.
The six keys are:
Key underneath the control
Left mouse key
Small gray key
Interrupt/break an action (right mouse key)
Menu
The menu key gives access to the menu control
functions. To move within the various menu
functions, position the arrow cursor by pressing
the sensitive mouse pad and click with the left
mouse button which is located underneath the
remote control.
If you are in menu mode and press the menu
key you will return to normal mode.
Zap
The two zap keys can be programmed to
perform an assigned function. To assign a function to the zap keys, select the Zap icon from
the menu. The zap keys can be programmed to
do the same function e.g. volume up/down. See
section 6.2.4 for further explanations of the
zap menu.
Quick
When pressing the Quick key you can switch
between all selected functions for the Quick
key. See section 6.2.3. for how to select functions for the Quick key.
Figure 9: Remote control
5.1 Different program modes
for your Zenith projector
The projector has the following modes of
operation:
• Stand-by mode
• Nor mal mode
• Quick mode
• Menu mode
• Pointer mode
• Blank mode
Stand-by mode (see section 5.3)
In stand-by mode the projector is turned off
and can be turned on by using defined keys.
Normal mode
In normal mode a picture will be shown on the
screen.
Quick mode (see section 6.2.3)
Quick mode is used with the interactive remote
control (quick key). You assign functionality for
the quick key on the remote control in the
quick menu (see section 6.2.3). When clicking
on the Quick key you will be able to switch
between all the functions you have selected in
this menu.
Menu mode
In menu mode the menu system is activated
and you use the mouse pad and the mouse buttons on the remote control to navigate in the
menu.
Pointer mode (see section 6.2.4)
In pointer mode you can move a pointer cursor
on the screen by using the mouse function.
Blank mode (see section 6.2.4)
In blank mode the screen is blanked out
(black).
5.2 Remote control
To access the Main Menu and control the varous
image adjustments and utility functions of the
projector
Point the remote control towards the projection
screen. An infra-red beam bounces from the
screen to an infra-red receiver on the projector.
Note!
Make sure nothing is blocking the IR
receiver in front of projector located beside
the lens, as this will prevent the communication between the remote control and the
projector.
To ensure smooth operation, the combined
distance from the remote control to the
screen and back to the projector should not
exceed 33 feet (10 m). If the distance via
the screen is longer, you should point the
remote control directly towards the IR
receiver.
5.Using Your Zenith
projector
12 13
MENU
ON
ZAP 1
QUICK
OFF
ZAP 2
5.4 Adjusting the height and
angle of the projector
You can adjust the height and angle of the
projector by adjusting the four small feet
underneath the product.
Note!
The projector should never be left with an
angle of more than 15 degrees over a long
period of time. Doing so will shorten the
lifetime of the lamp.
5.5 Aspect Ratio Selection
Aspect Ratio selection.
In this menu you can select the aspect
ratio of 4:3 or 16:9.
6.1 The menu system
Main menu.
Menu with video input.
6.1.1 Main menu
The main menu is divided into two parts:
• Icons
• Help text
Icons
The icons illustrate a function and are grouped
into groups with similar functionality. Clicking
an icon activates it. Some icons have a direct
function and some will activate a second level
menu.
Help text
By moving the cursor over the icons the text
area will give a short description of the icon.
Stand-by
The stand-by key will set the projector in
stand-by mode. The lamp will turn off, and
the fans will run for a little while cooling the
projector before stopping. To return to normal
mode, press the Menu key on the remote
control.
6. Using the menus
5.3 Using the touch panel on
the projector
The touch panel gives you direct access
to the most important functions of the
projector. The key functions are as follows:
Source
The projector has direct keys for four sources:
Functionality
• Computer (PC)
• Composite video
• S-video
Stand by
The stand by key will set the projector in
stand by mode. To return to normal mode,
press the Stand by key once more, or press the
Menu key on the remote control.
Automatic set-up
The automatic set-up key will set up the
projector with optimal settings for the
connected source. If you want to do manual
adjustments you can do this by using the
menus (see section 6).
Brightness/Con trast
Controls the brightness and contrast
of the image.
Saturation/Tint
The saturation key is to control the saturation of the image in PAL/SECAM mode. The
tint key is to control the tint of the image
when NTSC mode is chosen.
Note!
You can not access the screen menu
system without the remote control.
Figure 10: The keys on the touch panel on the
projector
14 15
1716 17
6.2 Set-up menu
Set-up menu
In the set-up menu the following
sub-menus are available:
• Picture orientation
• Language
• Quick key assignment
• ZAP keys assignment
• Accumulated lamptime
6.2.1 Picture orientation
Picture orientation
The picture orientation menu is used for
rotating and mirroring the picture.
Normal
Normal is used when the projector is standing
on a table projecting a picture on a screen.
Mirror
Mirror is used when the projector is projecting
a picture from behind the screen
Rotate
Rotate is used when the projector is ceiling
mounted and projecting an image from the
front.
Rotate and mirror
Rotate and mirror is used when the projector
is ceiling mounted and projects the picture
from behind the screen.
Auto set-up
Auto set-up will do automatic set-up of the
projector:
• Horizontal and vertical position
• Sampling clock
• Phase
• Chooses between available video formats
and NTSC/PAL auto detection
Source
You can connect three different sources to the
projector; one computer source, two video
sources.
You select the source you want to use by clicking on the icon representing the source. Use
the pressure-sensing pad on the remote mouse
to move the mouse pointer to an icon and
click the button (left mouse) underneath the
remote mouse.
Set-up menu
In this menu you set up the projector with
settings that will not be changed often, e.g.
language or picture orientation.
Control panel
In this menu you can make adjustments for
picture.
Removing the main menu
To remove the menu system, press the MENU
key on the Remote control. You can also
remove the menu by clicking the right mouse
button (on the top of the remote control). The
right mouse button will also function as cancel
when in the menus.
The menu will disappear in 40 seconds.
Product information
Click on the product information icon for
information about the product and support.
Press the main menu button again to
exit this screen.
1918
19
6.2.4 Zap menu
Zap menu
The Zap menu is used to assign functions to
the zap keys on the remote control. The menu
consists of two columns of buttons where the
left column assigns the functions to the left
key and the right column assigns the functions
to the right key.
Note:
Un-selecting all boxes for Zap 1 assigns the
“Zap 1’ button on the remote to Power-up
the projector from stand-by mode.
Un-selecting all boxes for Zap 2 assigns the
“Zap 2” button on the remote to function
as the Power-down (stand-by) button.
Pointer
You can activate the pointer function in the
projector. One click activates the pointer and
the next click deactivates it.
Blank
Activates blank mode by pressing the Zap key.
First click will activate Blank mode and second
click will deactivate it.
Computer
Selects Computer as the source.
Video
Selects video sources. Both Zap keys can be
programmed to select Video.
6.2.5 Show accumulated lamp time
Show accumulated lamp time
In this window you can see the accumulated
time that the lamp has been in use. You also
use this window to reset the accumulated lamp
time after the lamp has been replaced.
6.2.2 Language
Language selection
This menu allows you to choose between six
different menu languages: English, French,
German, Italian, Spanish and Norwegian.
Click in the box next to the language you want
to use. Click on the OK button. The window
will disappear, and the selected language will
be used in the main menu and in all other
menus.
6.2.3 Quick menu
Quick menu settings
In the quick menu you can assign functionality
for the quick key on the remote control. When
clicking on the quick key you will be able to
switch between all the functions you have
selected in this menu. You adjust the bar by
either pressing the pressure-sensing pad right
or left or you may use one of the two zap keys
on the remote control. To accept the adjustment, and terminate the quick menus click on
the left mouse button. To get back to the original setup, click on the right mouse button.
The next click on the quick key will accept the
adjustment and activate the brig ht ness function and a brightness bar will be shown at the
bottom of the page. When you have gone
through all assigned functions the menu will
disappear.
18
2120
All options will be available when NTSC video
is connected.
Select OK to save your changes and exit, or
select Cancel to exit without saving your
changes. Selecting Default restores factory
settings.
6.3.2 Zoom/Focus adjustments
Zoom and focus adjustments
To adjust focus, turn the outer part of the
lens (1). To adjust zoom, turn the inner
part of the lens (2).
6.3.3 Color manager
Color tone settings
The color manager is designed to give you
optimal performance from your projector, independent of ambient lighting conditions.
In the color manager menu you can choose
between four pre-defined Color settings.
6.3.4 Picture positioning
Picture positioning
Adjust vertical and horizontal position of the
picture on the screen with the two sliders.
Select OK to save your changes and exit, or
select Cancel to exit without saving your
changes.
C
H
A
N
FO
CU
S
Z
O
O
M
S-V
V
T
V
PC
1
2
6.3 Control panel menu
Control panel menu when PC is selected
In the control panel you have access to menus
for adjusting picture settings.
The icons “Picture positioning” and
“Synchronization Adjustments” are only visible
if PC source is active.
6.3.1 Picture control
Select the picture control menu for
adjusting brightness, contrast, saturation and
tint.
When PC is selected as source and auto
contrast is marked, only brightness will be
available.
When PAL/SECAM video is connected
brightness, contrast and saturation will be
available.
When PC is selected as source, only brightness
and contrast will be available.
23
No image appears on the screen
Possible causes and remedies:
1. The projector is left in Standby mode. If
the product is in standby mode, there will
be a red light next to the stand-by button.
Press the
stand-by button or the Menu key on the
remote control.
2. The lamp does not function. Check the
light on the control panel. If the light is
orange, the lamp does not function. Call 1888-865-3026..
3. The product is set in ‘blank mode’. Press
the zap keys on the remote control.
4. The brightness is turned on too low. Adjust
brightness until a satisfactory image is
achieved.
5. The power save or screen save on the PC is
turned on. Disable the power save and
screen save on the PC.
6. The image is displayed on the laptop
screen and not the projector. Activate the
external port on the laptop by pressing the
required key combination on your computer.
7. The projector is not connected to electricity. Check that the power cable is connected to the projector and the wall outlet.
No source signal is detected (the Zenith
logo appears)
Possible causes and remedies:
1. The computer has not been switched on.
Turn on the computer.
2. The cables are not properly connected.
Check all cable connections.
The image is not good (noise)
Possible causes and remedies:
1. The automatic image set-up is not
activated. Run auto set-up by pressing
the setup button on the touch panel or
run auto set-up from the menu.
2. The synchronization on the PC is not set
optimally.
There is poor response from the Remote
Control
Possible causes and remedies:
1. Check that nothing is blocking the IR
receiver at the front of the projector.
2. Make sure the remote control is pointed
towards the screen.
3. Make sure there is no more than
33ft/10m in distance to the projector.
4. Batteries might be low. Change batteries
in the remote control.
5. Electromagnetic or optic noise may
influence the remote control.
Turn off sharp fluorescent lamps, mobile
phones, etc that are near the projector.
No Image Appears
Possible causes and remedies:
1. The projector has not been switched on.
Check the ON/OFF switch at the back.
2. For Notebooks: The external RGB port
may need to be manually activated. Please
consult the notebook-operating manual
for how to operate.
8. What do I do if
(Trouble shooting)
6.3.5 Synchronization Adjustments
Synchronization Adjustments
It is possible to adjust the synchronization in
Computer mode by adjusting the Phase and
the Frequency. The synchronization will be set
by the automatic set-up function. Manual sync
adjustments should typically not be required.
The setting will follow the source, which
means that you can have different settings for
video and computer. The pre-defined settings
will also vary with the source.
All maintenance should be done
by Zenith authorized service
personnel. Contact Zenith at
1-888-865-3026 for service
7. Maintenance
22
24
206-03704
© Copyright 2001 Zenith Electronics Corporation
Loading...
