Zenith DVC2550 OPERATING GUIDE

machine number | DVC2550

enjoy the view

operating guide / warranty

®

PAGE 2 INTRODUCTION

Safety Precautions

The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated ‘dangerous voltage’ within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT

TO RAIN OR MOISTURE.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY

INSERT.

ATTENTION:

POUR EVITER LES CHOCS ELECTRIQUE, INTRODUIRE LA LAME LA PLUS LARGE DE LA
FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOUD.

CAUTION: This Digital Video Disc Player employs a Laser System.

To ensure proper use of this product, please read this owner’s manual carefully and retain for
future reference, should the unit require maintenance, contact an authorized service location-see
service procedure.

Use of controls, adjustments or the performance of procedures other than those specified may
result herein hazardous radiation exposure.

To prevent direct exposure to laser beam, do not try to open the enclosure. Visible laser radiation
when open the enclosure. DO NOT STARE INTO BEAM.

FCC NOTICE: This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connect

ed.

- Consult the dealer or an experienced radio/TV technician for help.

FCC WARNING: Changes or modifications not expressly approved by the party responsible for compliance could

void the user’s authority to operate the equipment.

INDUSTRY CANADA REQUIREMENT :

This Class B digital apparatus meets all requirements of the Canadian Interference-Causing
Equipment Regulations.
Cet appareil numéruque de la classe B respecte toutes les exigences du Règlement sur le
matériel brouilleur du Canada.

Zenith is a trademark of ZEC © Copyright Zenith Electronics Corporation 2000

RECORD YOUR MODEL NUMBER (Now, while you can see it)
The model and serial number of your new DVD

player are located on the back of the DVD player cabinet. For your future conve­nience, we suggest that you record these numbers here:

MODEL NO.____________________________________
SERIAL NO.____________________________________

WARNING

RISK OF ELECTRIC SHOCK

DO NOT OPEN

AVERTISSEMENT

WARNING : TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.

RISQUE DE CHOC ELECTRIQUE NE

PAS OUVRIR

INTRODUCTION PAGE 3

Table of Contents

Introduction

❏ Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . 2

❏ Table of Contents. . . . . . . . . . . . . . . . . . . . . . . . . 3

❏ IMPORTANT SAFETY INSTRUCTIONS . . . . . . 4-5

❏ Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

❏ Notes on Discs . . . . . . . . . . . . . . . . . . . . . . . . . . 7

❏ Identification of Controls . . . . . . . . . . . . . . . . . 8-12

Front Panel/Display window. . . . . . . . . . . . . . . . . . . . . 8

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Remote Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Controlling the VCRs, CATVs (DBS) and TVs . . . . . . 11

Preparing the Remote Control . . . . . . . . . . . . . . . . . . 12

Operating with the Remote Control . . . . . . . . . . . . . . 12

Connections

❏ Connecting to a TV . . . . . . . . . . . . . . . . . . . . . . 13

❏ Connecting to an Audio System . . . . . . . . . . . . . 14

❏ Connecting to Optional Audio System . . . . . . 15-17

Enjoying Dolby Digital (AC-3) Sound . . . . . . . . . . . . . 15

Enjoying Dolby Pro Logic Surround Sound . . . . . . . . 16

Enjoying 2 Channel Digital Stereo Sound. . . . . . . . . . 17

Enjoying DTS Sound. . . . . . . . . . . . . . . . . . . . . . . . . 17

Basic Operations

❏ Basic Playback . . . . . . . . . . . . . . . . . . . . . . . 18-21

❏

Various speed playback with Shuttle Ring

. . . . . . 22

Operation Using GUI Menu Icons

❏ General Information about GUI menu icons . . . . 23

❏ Detailed description of each GUI menu icon. . . . 24

Advanced Operation

❏ Using a title menu . . . . . . . . . . . . . . . . . . . . . . . 25

❏ Using a DVD menu . . . . . . . . . . . . . . . . . . . . . . 25

❏ Changing subtitle language . . . . . . . . . . . . . . . . 26

❏ Changing audio soundtrack language . . . . . . . . . 26

❏ Viewing from another angle . . . . . . . . . . . . . . . . 27

❏ Producing a 3D Surround effect . . . . . . . . . . . . . 27

❏ Repeat Play. . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

❏ Storing markers in memory to be

viewed (listened to) again. . . . . . . . . . . . . . . . . . 29

❏ Zoom Feature . . . . . . . . . . . . . . . . . . . . . . . . . . 30

❏ Random Play. . . . . . . . . . . . . . . . . . . . . . . . . . . 30

❏ Program Play. . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Initial Settings

❏ Common procedures of initial settings . . . . . . . . 32

❏ Selecting disc Languages . . . . . . . . . . . . . . . . . 33

❏ Selecting rating level and password . . . . . . . 34-35

❏ Selecting TV Aspect . . . . . . . . . . . . . . . . . . . . . . 36

❏ Selecting Menu Language . . . . . . . . . . . . . . . . . 37

❏ Selecting TV Output. . . . . . . . . . . . . . . . . . . . . . 37

❏ Selecting Digital Audio Output . . . . . . . . . . . . . . 38

❏ Table of Languages and Their Abbreviations . . . 39

Reference

❏ Disc Requirements/Copyright Information. . . . . . 40

❏ Before Calling Service Personnel . . . . . . . . . . . . 41

❏ Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . 42
