CONTENTS
SECTION 1 . . . .SUMMARY
SECTION 2 . . . .CABINET & MAIN CHASSIS
SECTION 3 . . . .ELECTRICAL
SECTION 4 . . . .MECHANISM
SECTION 5 . . . .REPLACEMENT PARTS LIST
SECTION 1
SUMMARY
CONTENTS
PRODUCT SAFETY SERVICING GUIDELINES FOR VIDEO PRODUCTS
........................... 1-3
SERVICING PRECAUTIONS .................................................................................................. 1-4
• General Servicing Precautions
• Insulation Checking Prodedure
• Electrostatically Sensitive Devices
SPECIFICATIONS ...................................................................................................................... 1-5
1-2
1-3
CAUTION : DO NOT ATTEMPT TO MODIFY THIS PRODUCT IN ANY WAY,
NEVER PERFORM CUSTOMIZED INSTALLATIONS WITHOUT MANUFACTURER’S APPROVAL. UNAUTHORIZED MODIFICATIONS WILL NOT ONLY
VOID THE WARRANTY, BUT MAY LEAD TO YOUR BEING LIABLE FOR ANY
RESULTING PROPERTY DAMAGE OR USER INJURY.
SERVICE WORK SHOULD BE PERFORMED ONLY AFTER YOU ARE
THOROUGHLY FAMILIAR WITH ALL OF THE FOLLOWING SAFETY
CHECKS AND SERVICING GUIDELINES. TO DO OTHERWISE,
INCREASES THE RISK OF POTENTIAL HAZARDS AND INJURY TO THE
USER.
WHILE SERVICING, USE AN ISOLATION TRANSFORMER FOR PROTECTION FROM A.C. LINE SHOCK.
SAFETY CHECKS
AFTER THE ORIGINAL SERVICE PROBLEM HAS BEEN CORRCTED. A
CHECK SHOULD BE MADE OF THE FOLLOWING.
SUBJECT : FIRE & SHOCK HAZARD
1. BE SURE THAT ALL COMPONENTS ARE POSITIONED IN SUCH A WAY
AS TO AVOID POSSIBILITY OF ADJACENT COMPONENT SHORTS.
THIS IS ESPECIALLY IMPORTANT ON THOSE MODULES WHICH ARE
TRANSPORTED TO AND FROM THE REPAIR SHOP.
2. NEVER RELEASE A REPAIR UNLESS ALL PROTECTIVE DEVICES
SUCH AS INSULATORS, BARRIERS, COVERS, SHIELDS, STRAIN
RELIEFS, POWER SUPPLY CORDS, AND OTHER HARDWARE HAVE
BEEN REINSTALLED PER ORIGINAL DESIGN. BE SURE THAT THE
SAFETY PURPOSE OF THE POLARIZED LINE PLUG HAS NOT BEEN
DEFEATED.
3. SOLDERING MUST BE INSPECTED TO DISCOVER POSSIBLE COLD
SOLDER JOINTS, SOLDER SPLASHES OR SHARP SOLDER POINTS.
BE CERTAIN TO REMOVE ALL LOOSE FOREIGN PARTICLES.
4. CHECK FOR PHYSICAL EVIDENCE OF DAMAGE OR DETERIORATION
TO PARTS AND COMPONENTS. FOR FRAYED LEADS, DAMAGED
INSULATION (INCLUDING A.C. CORD). AND REPLACE IF NECESSARY
FOLLOW ORIGINAL LAYOUT, LEAD LENGTH AND DRESS.
5. NO LEAD OR COMPONENT SHOULD TOUCH A RECIVING TUBE OR
A RESISTOR RATED AT 1 WATT OR MORE. LEAD TENSION AROUND
PROTRUNING METAL SURFACES MUST BE AVOIDED.
6. ALL CRITICAL COMPONENTS SUCH AS FUSES, FLAMEPROOF
RESISTORS, CAPACITORS, ETC. MUST BE REPLACED WITH EXACT
FACTORY TYPES, DO NOT USE REPLACEMENT COMPONENTS
OTHER THAN THOSE SPECIFIED OR MAKE UNRECOMMENDED CIRCUIT MODIFICATIONS.
7. AFTER RE-ASSEMBLY OF THE SET ALWAYS PERFORM AN A.C.
LEAKAGE TEST ON ALL EXPOSED METALLIC PARTS OF THE CABINET, (THE CHANNEL SELECTOR KNOB, ANTENNA TERMINALS. HANDLE AND SCREWS) TO BE SURE THE SET IS SAFE TO OPERATE
WITHOUT DANGER OF ELECTRICAL SHOCK. DO NOT USE A LINE
ISOLATION TRANSFORMER DURING THIS TEST USE AN A.C. VOLTMETER, HAVING 5000 OHMS PER VOLT OR MORE SENSITIVITY, IN
THE FOLLOWING MANNER; CONNECT A 1500 OHM 10 WATT RESISTOR, PARALLELED BY A .15 MFD. 150.V A.C TYPE CAPACITOR
BETWEEN A KNOWN GOOD EARTH GROUND (WATER PIPE, CONDUIT, ETC.) AND THE EXPOSED METALLIC PARTS, ONE AT A TIME.
MEASURE THE A.C. VOLTAGE ACROSS THE COMBINATION OF 1500
OHM RESISTOR AND .15 MFD CAPACITOR. REVERSE THE A.C. PLUG
AND REPEAT A.C. VOLTAGE MEASUREMENTS FOR EACH EXPOSED
METALLIC PART. VOLTAGE MEASURED MUST NOT EXCEED 75
VOLTS R.M.S. THIS CORRESPONDS TO 0.5 MILLIAMP A.C ANY
VALUE EXCEEDING THIS LIMIT CONSTITUTES A POTENTIAL SHOCK
HAZARD AND MUST BE CORRECTED IMMEDIATELY.
SUBJECT: GRAPHIC SYMBOLS
THE LIGHTNING FLASH WITH APROWHEAD SYMBOL. WITHIN
AN EQUILATERAL TRIANGLE, IS INTENDED TO ALERT THE
SERVICE PERSONNEL TO THE PRESENCE OF UNINSULATED
“DANGEROUS VOLTAGE” THAT MAY BE OF SUFFICIENT MAGNITUDE TO CONSTITUTE A RISK OF ELECTRIC SHOCK.
THE EXCLAMATION POINT WITHIN AN EQUILATERAL TRIANGLE IS INTENDED TO ALERT THE SERVICE PERSONNEL TO
THE PRESENCE OF IMPORTANT SAFETY INFORMATION IN
SERVICE LITERATURE.
SUBJECT : X-RADIATION
1. BE SURE PROCEDURES AND INSTRUCTIONS TO ALL SERVICE PERSONNEL COVER THE SUBJECT OF X-RADIATION. THE ONLY POTENTIAL SOURCE OF X-RAYS IN CURRENT T.V. RECEIVERS IS THE PICTURE TUBE. HOWEVER, THIS TUBE DOES NOT EMIT X-RAYS WHEN
THE HIGH VOLTAGE IS AT THE FACTORY SPECIFIED LEVEL. THE
PROPER VALUE IS GIVEN IN THE APPLICABLE SCHEMATIC. OPERATION AT HIGHER VOLTAGES MAY CAUSE A FAILURE OF THE PICTURE TUBE OR HIGH VOLTAGE SUPPLY AND, UNDER CERTAIN CIRCUMSTANCES, MAY PRODUCE RADIATION IN EXCESS OF DESIRABLE LEVELS.
2. ONLY FACTORY SPECIFIED C.R.T. ANODE CONNECTORS MUST BE
USED. DEGAUSSING SHIELDS ALSO SERVE AS X-RAY SHIELD IN
COLOR SETS, ALWAYS RE-INSTALL THEM.
3. IT IS ESSNTIAL THAT SERVICE PERSONNEL HAVE AVAILABLE AN
ACCURATE AND RELIABLE HIGH VOLTAGE METER. THE CALIBRA
TION OF THE METER SHOULD BE CHECKED PERIODICALLY
AGAINST A REFERENCE STANDARD, SUCH AS THE ONE AVAILABLE
AT YOUR DISTRIBUTOR.
4. WHEN THE HIGH VOLTAGE CIRCUITRY IS OPERATING PROPERLY
THERE IS NO POSSIBILITY OF AN X-RADIATION PROBLEM. EVERY
TIME A COLOR CHASSIS IS SERVICED. THE BRIGHTNESS SHOULD
BE RUN UP AND DOWN WHILE MONITORING THE HIGH VOLTAGE
WITH A METER TO BE CERTAIN THAT THE HIGH VOLTAGE DOES
NOT EXCEED THE SPECIFIED VALUE AND THAT IT IS REGULATING
CORRECTLY, WE SUGGEST THAT YOU AND YOUR SERVICE ORGANIZATION REVIEW TEST PROCEDURES SO THAT VOLTAGE REGULATION IS ALWAYS CHECKED AS A STANDARD SERVICING PROCEDURE. AND THAT THE HIGH VOLTAGE READING BE RECORDER ON
EACH CUSTOMER’S INVOICE.
5. WHEN TROUBLESHOOTING AND MAKING TEST MEASUREMENTS IN
A PRODUCT WITH A PROBLEM OF EXCESSIVE HIGH VOLTAGE,
AVOID BEING UNNECESSARILY CLOSE TO THE PICTURE TUBE AND
THE HIGH VOLTAGE SUPPLY. DO NOT OPERATE THE PRODUCT
LONGER THAN IS NECESSARY TO LOCATE THE CAUSE OF EXCES
SIVE VOLTAGE.
6. REFER TO HV. B+ AND SHUTDOWN ADJUSTMENT PROCEDURES
DESCRIBED IN THE APPROPRIATE SCHEMATIC AND DIAGRAMS
(WHERE USED).
SUBJECT: IMPLOSION
1. ALL DIRECT VIEWED PICTURE TUBES ARE EQUIPPED WITH AN INTE
GRAL IMPLOSION PROTECTION SYSTEM, BUT CARE SHOULD BE
TAKEN TO AVOID DAMAGE DURING INSTALLATION, AVOID
SCRATCHING THE TUBE. IF SCRATCHED REPLACE IT.
2. USE ONLY RECOMMENDED FACTORY REPLACEMENT TUBES.
SUBJECT : TIPS ON PROPER INSTALLATION
1. NEVER INSTALL ANY PRODUCT IN A CLOSED-IN RECESS, CUBBYHOLE OR CLOSELY FITTING SHELF SPACE. OVER OR CLOSE TO
HEAT DUCT, OR IN THE PATH OF HEATED AIR FLOW.
2. AVOID CONDITIONS OF HIGH HUMIDITY SUCH AS: OUTDOOR PATIO
INSTALLATIONS WHERE DEW IS A FACTOR, NEAR STEAM RADIATORS WHERE STEAM LEAKAGE IS A FACTOR, ETC.
3. AVOID PALCEMENT WHERE DRAPERIES MAY OBSTRUCT REAR
VENTING. THE CUSTOMER SHOULD ALSO AVOID THE USE OF DECORATIVE SCARVES OR OTHER COVERINGS WHICH MIGHT
OBSTRUCT VENTILATION.
4. WALL AND SHELF MOUNTED INSTALLATIONS USING A COMMERCIAL MOUNTING KIT. MUST FOLLOW THE FACTORY APPROVED
MOUNTING INSTRUCTIONS A PRODUCT MOUNTED TO A SHELF OR
PLATFORM MUST RETAIN ITS ORIGINAL FEET (OR THE EQUIVALENT
THICKNESS IN SPACERS) TO PROVIDE ADEQUATE AIR FLOW
ACROSS THE BOTTOM, BOLTS OR SCREWS USED FOR FASTENERS
MUST NOT TOUCH ANY PARTS OR WIRING. PERFORM LEAKAGE
TEST ON CUSTOMIZED INSTALLATIONS.
5. CAUTION CUSTOMERS AGAINST THE MOUNTING OF A PRODUCT ON
SLOPING SHELF OR A TILTED POSITION, UNLESS THE PRODUCT IS
PROPERLY SECURED.
6. A PRODUCT ON A ROLL-ABOUT CART SHOULD BE STABLE ON ITS
MOUNTING TO THE CART. CAUTION THE CUSTOMER ON THE HAZARDS OF TRYING TO ROLL A CART WITH SMALL CASTERS ACROSS
THRESHOLDS OR DEEP PILE CARPETS.
7. CAUTION CUSTOMERS AGAINST THE USE OF A CART OR STAND
WHICH HAS NOT BEEN LISTED BY UNDERWRITERS LABORATORIES,
INC. FOR USE WITH THEIR SPECIFIC MODEL OF TELEVISION
RECEIVER OR GENERICALLY APPROVED FOR USE WITH T.V.’S OF
THE SAME OR LARGER SCREEN SIZE.
8. CAUTION CUSTOMERS AGAINST THE USE OF EXTENSION CORDS,
EXPLAIN THAT A FOREST OF EXTENSIONS SPROUTING FROM A SINGLE OUTLET CAN LEAD TO DISASTROUS CONSEQUENCES TO
HOME AND FAMILY.
PRODUCT SAFETY SERVICING GUIDELINES FOR VIDEO PRODUCTS
A.C. VOLTMETER
GOOD EARTH GROUND
SUCH AS THE WATER
PIPE. CONDUIT. ETC
PLACE THIS PROBE
ON EACH EXPOSED
METAL PART
1-4
SERVICING PRECAUTIONS
CAUTION : Before servicing the DVD covered by this service
data and its supplements and addends, read and follow the
SAFETY PRECAUTIONS. NOTE : if unforeseen circumstances create conflict between the following servicing precautions and any of the safety precautions in this publications, always follow the safety precautions.
Remembers Safety First:
General Servicing Precautions
1. Always unplug the DVD AC power cord from the AC
power source before:
(1) Removing or reinstalling any component, circuit board,
module, or any other assembly.
(2) Disconnection or reconnecting any internal electrical
plug or other electrical connection.
(3) Connecting a test substitute in parallel with an elec-
trolytic capacitor.
Caution : A wrong part substitution or incorrect
polarity installation of electrolytic capacitors may result
in an explosion hazard.
2. Do not spray chemicals on or near this DVD or any of
its assemblies.
3. Unless specified otherwise in this service data, clean
electrical contacts by applying an appropriate contact
cleaning solution to the contacts with a pipe cleaner,
cotton-tipped swab, or comparable soft applicator.
Unless specified otherwise in this service data, lubrication
of contacts is not required.
4. Do not defeat any plug/socket B+ voltage interlocks with
whitch instruments covered by this service manual might
be equipped.
5. Do not apply AC power to this DVD and/or any of its
electrical assemblies unless all solid-state device heat
sinks are cerrectly installed.
6. Always connect test instrument ground lead to the
appropriate ground before connection the test instrument
positive lead. Always remove the test instrument ground
lead last.
Insulation Checking Procedure
Disconnect the attachment plug from the AC outlet and turn
the power on. Connect an insulation resistance meter(500V)
to the blades of the attachment plug. The insulation resistance between each blade of the attachment plug and accessible conductive parts (Note 1) should be more than 1Mohm.
Note 1 : Accessible Conductive Parts including Metal panels, Input terminals, Earphone jacks, etc.
Electrostatically Sensitive (ES) Devices
Some semiconductor (solid state) devices can be damaged
easily by static electricity. Such components commonly are
called Electrostatically Sensitive (ES) Devices. Examples of
typical ES devices are integrated circuits and some field
effect transistors and semiconductor chip components.
The following techniques should be used to help reduce the
incidence of component damage caused by static electricity.
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any
electrostatic charge on your body by touching a known
earth ground. Alternatively, obtain and wear a commercially available discharging wrist strap device, which
should be removed for potential shock reasons prior to
applying power to the unit under test.
2. After removing an electrical assembly equipped with ES
devices, place the assembly on a conductive surface such
as aluminum foil, to prevent electrostatic charge buildup or
exposure of the assembly.
3. Use only a grouned-tip soldering iron to solder or unsolder
ES devices.
4. Use only an anti-static solder removal device. Some
solder removal devices not classified a “anti-static” can
generate electrical charges sufficient to damage ES
devices.
5. Do not use freon-propelled chemicals. These can
generate electrical charge sufficient to damage ES
devices.
6. Do not remove a replacement ES device from its protec
tive package until immediately before you are ready to
install it. (Most replacement ES devices are packaged with
leads electrically shorted together by conductive foam,
aluminum foil, or comparable conductive material).
7. Immediately before removing the protective material from
the leads of a replacement ES device, touch the protective
material to the chassis or circuit assembly into which the
device will be installed.
Caution : Be sure no power is applied to the chassis or
circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged
replacement ES devices. (Normally harmless motion such
as the brushing together of your clothes fabric or the lifting
of your foot from a carpeted floor can generate static electricity sufficient to damage an ES device.)
1-5
SPECIFICATIONS
• GENERAL
Power requirements: AC 110-240 V , 50/60 Hz
Power consumption: 12W
Dimensions (Approx.): 430 x 39 x 242 mm (W x H x D) without foot
Weight (Approx.): 2.2 kg
Operating temperature: 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity: 5 % to 90 %
• OUTPUTS
VIDEO OUT: 1 Vp-p 75 Ω, sync negative, RCA jack x 1/ SCART (TO TV)
AUDIO OUT: 2.0 Vrms (1 KHz, 0 dB), 600 Ω,
RCA jack (L, R) x 1/ SCART (TO TV)
DIGITAL OUT (COAXIAL): 0.5 V (p-p), 75 Ω, RCA jack x 1
• System
Laser: Semiconductor laser, wavelength 650 nm
Signal system: PAL / NTSC
Frequency response: DVD (PCM 96 kHz): 8 Hz to 44 kHz
DVD (PCM 48 kHz): 8 Hz to 22 kHz
CD: 8 Hz to 20 kHz
Signal-to-noise ratio: More than 100 dB (ANALOG OUT connectors only)
Harmonic distortion: Less than 0.008%
Dynamic range: More than 90 dB (DVD/CD)
• Accessories
Video cable (1), Audio cable (1), Remote control (1), Batteries (2)
2-1
SECTION 2
CABINET & MAIN CHASSIS
CONTENTS
1. EXPLODED VIEWS ................................................................................................................2-2
1. Cabinet and Main Frame Section ...........................................................................................2-2
2. Packing Accessory Section....................................................................................................2-3
2-2
EXPLODED VIEWS
1. Cabinet and Main Frame Section
A
5
4
3
2
1
BCD
250
463
A44
300
465
463
320
467
A46
SCART, 5.1CH
MODEL
ONLY
463
261
260
A00
463
463
A47
A41
279
KARAOKE MODEL
ONLY
283
A48
261
A43
261
A49
452
261
280
452
A42
2-3
2. Packing Accessory Section
BATTERY
808
PACKING SHEET
804
PACKING
OPTIONAL PARTS
803
806
820
OWNER'S MANUAL
RF CABLE
810
CABLE SET ASS'Y
801
REMOCON
900
BOX CARTON
802
PACKING
803
811
812
PLUG ASS'Y 1WAY(YELLOW)
PLUG ASS'Y 1WAY(BLACK)
PLUG ASS'Y 2WAY
3-1
SECTION 3
ELECTRICAL
CONTENTS
ELECTRICAL TROUBLESHOOTING GUIDE......................................................................3-2
1. Power check flow.....................................................................................................................3-2
2. System operation flow ............................................................................................................3-3
3. Test & debug flow ....................................................................................................................3-4
4. KARAOKE Flow (KARAOKE MODEL ONLY).......................................................................3-10
DETAILS AND WAVEFORMS ON SYSTEM TEST AND DEBUGGING ....................3-11
1. SYSTEM 27MHz CLOCK, RESET SIGNAL ...........................................................................3-11
2. SDRAM CLOCK......................................................................................................................3-12
3. TRAY OPEN/CLOSE SIGNAL ................................................................................................3-12
4. SLED CONTROL RELATED SIGNAL(NO DISC CONDITION) .............................................3-14
5. LENS CONTROL RELATED SIGNAL(NO DISC CONDITION) .............................................3-14
6. LASER POWER CONTROL RELATED SIGNAL(NO DISC CONDITION)............................3-15
7. DISC TYPE JUDGEMENT WAVEFORM ................................................................................3-16
8. FOCUS ON WAVEFORM........................................................................................................3-17
9. SPINDLE CONTROL WAVEFORM(NO DISC CONDITION...................................................3-18
10. TRACKING CONTROL RELATED SIGNAL(System checking).........................................3-19
11. RF WAVEFORM ....................................................................................................................3-20
12. M3355 AUDIO OPTICAL AND COAXIAL OUTPUT(ASPDIF) .............................................3-20
13.M3355 VIDEO OUTPUT WAVEFORM...................................................................................3-21
14. AUDIO OUTPUT FROM AUDIO DAC ..................................................................................3-22
BLOCK DIAGRAMS ..................................................................................................................3-24
1. Overall Block Diagram ..........................................................................................................3-24
2. Power(SMPS) Block Diagram ...............................................................................................3-25
3. SERVO Block Diagram ..........................................................................................................3-26
4. MPEG & MEMORY Block Diagram .......................................................................................3-27
5. VIDEO & AUDIO Block Diagram ...........................................................................................3-28
6. KARAOKE Block Diagram(KARAOKE MODEL ONLY).......................................................3-29
CIRCUIT DIAGRAMS................................................................................................................3-30
1. Power(SMPS) Circuit DIAGRAM...........................................................................................3-30
2. AV/JACK Circuit DIAGRAM...................................................................................................3-32
3. SYSTEM Circuit DIAGRAM ...................................................................................................3-34
4. DRIVER Circuit DIAGRAM.....................................................................................................3-36
5. TIMER Circuit DIAGRAM .......................................................................................................3-38
6. 5.1CH, SCART Circuit DIAGRAM .........................................................................................3-40
7. KARAOKE Circuit DIAGRAM(KARAOKE MODEL ONLY)...................................................3-42
• CIRCUIT VOLTAGE CHART ....................................................................................................3-44
PRINTED CIRCUIT DIAGRAMS ............................................................................................3-50
1. MAIN P.C.BOARD...................................................................................................................3-50
2. KEY P.C.BOARD.....................................................................................................................3-52
3. TIMER P.C.BOARD .................................................................................................................3-53
4. SCART & 5.1CH P.C.BOARD(OPTIONAL PART) .................................................................3-54
5. SMPS P.C.BOARD ..................................................................................................................3-55
3-2
ELECTRICAL TROUBLESHOOTING GUIDE
No 5V_A
No 5.2VA
Is 5.2VA section working?
Is 5.2V present at emitter
of Q107?
Replace Q107.
Is there a DC voltage At
(+) terminal of BD101?
Is there a DC voltage at
R101?
Replace IC101.
Check F101
1. Power check flow
No VF+
Is 5.2VA section working?
Replace D102.
Check F102
NO
NO
YES
YES
YES
YES
Replace R101.
YES
Replace BD101.
YES
YES
A. B.
NO
NO
NO
NO
3-3
2. System operation flow
Power on
1.initializes SERVO, DSP and RISC registers
2.write RISC code to SDRAM
3.Reset RISC
Show LOGO
SLED at Inner Side?
SLED Moves to Inner Position
Tray Closed?
Tray Close to closed position
1.Judge whether have disc and disc type
2.Jump to related disc reading procedure
Received
Open/close key?
1.Execute Pressed Key and IR Key
2.System operation on routine loop
1.Stop playback and open tray
2.Display tray open message and LOGO
Receive
close key?
no
yes
no
yes
no
yes
no yes
3-4
3. Test & debug flow
Test
Check the AC Voltage
(110V or 220V)
Switch on the Power PCBA
Check the Power PART
Is
the DC Voltage
Outputs OK? (5.2V,5V,1.8V
,3.3V,8V,12V)
Check the Power PART
Is
3.3V, 1.8V,5V,12V and 8V
outputs normal on main
PCB
Check the IC105 or diode
Connect to PC RS232 Cable and
Update the flash memory code
Update
Flash(IC502)
Successfully?
A
1.Check 27MHz system clock.
2.Check system reset circuit.
3.Check flash R/W enable signal PRD
4.Check RS232 Signals
5.Check flash memory related circuit
Replace flash(IC502)
Yes
yes
yes
Yes
No
No
No
No
3-5
Show LOGO
A
yes
Reset or Power on
Flash
Memory operates
Properly?
Check connection on lines between FLASH
& M3355 and the FLASH access time
whether is suitable or not.
SDRAM
works properly?
Check connection lines between
SDRAM(IC503) & M3355 and the
SDRAM is damaged.
M3355
VIDEO outputs
properly?
Check the related circuit of M3355.
(IC501 PIN 2.3.7.8 check)
Have
TV signal output?
Does
Tray move inside
when it is not at closed
position?
Check the filtering and amp circuit of
TV signal .(IC604)
B
No No
YES
YES
YES
YES
No
NO
NO
Normal
TROUT & TRIN
signals?
NO
Check the load OPEN &
CLOSE switch
Normal
TRCLOSE &TROPEN
signal?
NO
Check the Tray control IO pins
on M3355.
Normal
LOAD+ & LOAD
signal
NO
Check the Tray control amplifying
circuit on Motor driver.(IC201)
Check the cable connection between
main PCBA and loader. (MECHA)
Check AV cable
connection to TV set
NO
YES
YES
YES
3-6
Does
the SLED move
to inner side when it is at
outer position
on?
B
Yes
Motor
Driver DRVSB
Pin is High?
Check the connection line of
DRVSB signal
Motor
Driver DRVSB
Pin is High?
Check the related circuit of
FOCUS.
SLED+
and SLED- output
properly ?
Check the amp circuit on
motor driver.
C
No
Check the cable connection
with MECHA.
Optical
Lens has movements
for searching
Focus?
Proper Focus outputs
to motor driver?
Check Focus connection on
M3355 and motor driver.
Proper F+
& F- outputs?
Check the amp circuit on
motor driver.
Check cable connect on with
pick-up head.
yes
No
Do not put in disc and tray
close.
No
No
No
Yes
Yes
Yes
Yes
Yes
No
No
3-7
Laser turns on when
reading disc?)
C
Yes
LD01 or LD02 output
properly?
Check the laser power circuit
on M3355 and connecting to
power transistor. (Q201, Q202)
Collector
voltage of power
transistor is OK?
( Q201, Q202)
Check the related circuit on
laser power TR
D
No
Yes
Check cable connection between
transistor output and pick-up head.
Check the RF connection
between MD and M3355.
Put disc in?
Proper RF signal?
Laser off
Check the related circuit
on M3355 RF signal
Does spindle rotate?
Disc ID is correct?
Proper
Spindle signal on
M3355
Check spindle related
circuit on M3355
Proper RF signal?
Check the related circuit
on M3355 RF signal
Check the RF connection
between MD and M3355.
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
No
No
No
No
3-8
Focus ON OK?
D
Yes
Proper
signals on A, B, C,
D of M3355
Check the related circuit
on M3355 SBAD signal .
No
No
Check the related circuit
on M3355
.Proper SBAD signal
on M3355?
Check connections between
M3355 and pick-up head.
Track On OK?
Check cable connection on
pick-up head.
Proper tracking signal
on M3355?
Proper
M3355 track signal
on M3355?
Check the related
circuit on M3355
Check the track connection
on M3355 and motor driver.
Yes
No
E
. Proper FE signal
on M3355?
Check the related circuit
on M3355 FE signal
Disc is play?
T+ & T- output
properly?
Check the tracking control
amp circuit on motor driver.
Check RF signal waveform.
Yes
Yes
No
No
No
No
No
Yes
Yes
Yes
No
3-9
Normal
Audio output
when disc playback?
E
DAC received
correct data
stream?
Check connection between M3355
& Audio DAC. (Check DAC_RST#,
SER3, BCLK, LRCK,MCLK
Normal
Audio DAC
out? (IC601)
Check the related circuit of
Audio DAC. (Check Audio
out Pin 14, 15,18,19)
Check Audio filter, amplify, mute
circuit. (IC602 Application circuit)?
TEST END
Communications
between IR.VFD Front panel key
& M3355 & Front u-com(IC901)
is normally?
Check communication lines
on M3355.
Check the cable connection
on Front panel.
Yes
Normal
IR. VFD & Front
panel key
functions?
Yes
Yes
No
No No
NoNo
Yes
Yes
Yes
3-10
Start
Insert the MIC jack
Is the MIC signal at the
IC801 pin3.
Does the MIC
signal input to the IC501
pin213.
Is the MIC signal at the
IC801 pin2.
Replace IC501
Check pattern
Replace the VR801
Replace IC801
Is the MIC signal at the
IC801 pin3 normal?
Replace the mic jack
NO
Yes
Yes
NO
NO
Yes
NO
Yes
4. KARAOKE Flow(KARAOKE MODEL ONLY)
3-11
DETAILS AND WAVEFORMS ON SYSTEM TEST AND DEBUGGING
1. SYSTEM 27MHz CLOCK, RESET SIGNAL
1) M3355 main clock is at 27MHz(X501)
3.1V,27MHz
FIG 1-1
2) M3355 reset is low active
5.2VA
PWR_CTL(CN505 PIN7)
M_RESET(CN505 PIN9)
TRST
FIG 1-2
3-12
2. SDRAM CLOCK
3. TRAY OPEN/CLOSE SIGNAL
OPEN(CN203 PIN3)
CLOSE(CN203 PIN4)
LM-(IC201 PIN14)
LM+(IC201 PIN13)
OPEN
CLOSE
1) SDRAM clock is at 135MHz
IC503 PIN38
CLK=135MHz,Vp-p=3.3V
FIG 2-1
1) Tray open/close waveform
FIG 3-1
3-13
2) Tray open waveform
OPEN(CN203 PIN3)
CLOSE(CN203 PIN4)
LM-(IC201 PIN14)
LM+(IC201 PIN13)
FIG 3-2
OPEN(CN203 PIN3)
CLOSE(CN203 PIN4)
LM-(IC201 PIN14)
LM+(IC201 PIN13)
3) Tray close waveform
FIG 3-3
3-14
4. SLED CONTROL RELATED SIGNAL(NO DISC CONDITION)
SLEGP(2.1V/1.5V/0.85V)
(IC501 PIN80)
DRVSB(3.3V/0V)
(IC501 PIN22)
SLED+(7.3V/4V/2.4V)
(IC201 PIN16)
SLED-(7.3V/4V/2.4V)
(IC201 PIN15)
FIG 4-1
5. LENS CONTROL RELATED SIGNAL(NO DISC CONDITION)
FOCUS(2.1V/1.5V/0.9V)
(IC501 PIN76)
FOCUS+(3.5V/2.8V/2V)
(IC201 PIN25)
FOCUS-(3.4V/2.8V/2.1V)
(IC201 PIN26)
FIG 5-1
3-15
6. LASER POWER CONTROL RELATED SIGNAL(NO DISC CONDITION)
DVDMDI(0V/180mV)
(CN201 PIN22)
DVDLD(3.2V/2.2V)
(IC501 PIN39)
CDLD(3.2V/2.3V)
(IC501 PIN40)
FIG 6-1
7. DISC TYPE JUDGEMENT WAVEFORM
F+(CN201 PIN15)
FE(IC501 PIN27)
SBAD(IC501 PIN14)
FIG 7-1(DVD)
3-16
F+(CN201 PIN15)
FE(IC501 PIN27)
SBAD(IC501 PIN14)
FIG 7-2(DVD)
F+(CN201 PIN15)
FE(IC501 PIN27)
SBAD(IC501 PIN14)
FIG 7-3 (CD)
3-17
F+(CN201 PIN15)
FE(IC501 PIN27)
SBAD(IC501 PIN14)
FIG 7-4 (CD)
F+(CN201 PIN15)
FE(IC501 PIN27)
F-(CN201 PIN18)
FOCUS(IC501 PIN76)
FIG 8-1 (DVD)
8. FOCUS ON WAVEFORM
3-18
F+(CN201 PIN15)
FE(IC501 PIN27)
F-(CN201 PIN18)
FOCUS(IC501 PIN76)
FIG 8-2 (CD)
9. SPINDLE CONTROL WAVEFORM(NO DISC CONDITION
SPM+(5.5V/4V/1.5V)
(CN202 PIN2)
SPM-(5.3V/4V/1.6V)
(CN202 PIN1)
SPINDLE(1.5V/3V)
(IC501 PIN82)
FIG 9-1 (DVD)
3-19
TE(IC501 PIN28)
TRACK(IC501 PIN77)
T+(CN201 PIN16)
T-(CN201 PIN17)
FIG 10-1 (DVD)
TE(IC501 PIN28)
TRACK(IC501 PIN77)
T+(CN201 PIN16)
T-(CN201 PIN17)
FIG 10-2(CD)
10. TRACKING CONTROL RELATED SIGNAL(System checking)
3-20
12. M3355 AUDIO OPTICAL AND COAXIAL OUTPUT(ASPDIF)
11. RF WAVEFORM
RF(IC501 PIN61)
(1.4V/2.95V)
FIG 11-1
IECDAOUT
(IC501 PIN211)
FIG 12-1
3-21
2) Y
Jk601 pin7
(1V)
FIG 13-2
13.M3355 VIDEO OUTPUT WAVEFORM
1) Full colorbar signal(CVBS)
Jk601 pin6
(1V)
FIG 13-1
3-22
14. AUDIO OUTPUT FROM AUDIO DAC
3) C
JK601 PIN8
(0.7V)
FIG 13-3
1) AUDIO L/R
JK601 PIN4,5
1KHz 0DB
FIG 14-1
3-23
2) Audio Related Signal
SER3(IC501 PIN167)
BCLK(IC501 PIN170)
2.312MHz
LRCLK(IC501 PIN168)
48KHz
FIG 14-2
3-24
BLOCK DIAGRAMS
1. Overall Block Diagram
M
M
DISC
SPINDLE
MOTOR
LOADING
MOTOR
DVD : A,B,C,D,RF0
CD : A,B,C,D,E,F,RF0
CDMDI,DVDMDI
PICK
UP
KEY Input
6MHz
B/Pb
IC502
MX29LV800T/B
1M
8BIT
FLASH ROM
M-RESET
ROMAD[0:19]
ROMRD
ROMWR
MD[00:15]
L/R
FL
FR
CVBS
R/Pr
G/Y
RL
RR
CENTER
WOOFER
TV_DAC[0:3]
Y
C
L/R
FL
FR
RL
RR
CENTER
WOOFER
VF+
AC 90V~240V
50HZ/60Hz
VF-
-27VA
5V
VD33,VD33D
12V
27MHz
PWRCTL
1.8V
IC504
AT24C02A
EEPROM
IC602,IC30[2,3.4]
KA5532
OP-AMP
RC901
R/C
IC903
RESET IC
LOAD[+,-]
FOCUS[+,-]
TRACK[+,-]
SPINDLE[+,-]
SLED
(FEEDING)
MOTOR
SLED[+,-]
M
VD33D
VD33D
VD18/VD33
3V3M
VD33D/5V
MIC
BCLK
LRCLK
DACCLK
IC604
MM1623XFBE
VIDEO BUFFER
RS232_TXD/MIC_DECT
IECDAOUT
COAXIAL
SPDI
D2_T[1:3]
SCART_16:9
RGB_SEL
3V3M
CDLD,DVDLD,SVREF21
5V/8V
HOMESW
INSW,OUTSW
ROMDATA[0:7]
5.2VA
IC901
GMS81C2012(Hynix)
Front Micom
M_REQ
POWER
BOARD
VFD_RXD
S_REQ
5.2VA
8V
DMUTE
IIC/VFD/DAC_SCK
IC5031M16BIT
4Bank
SDRAM
VD33D
IIC/VFD/DAC_TXD
+12V
+12V
5V
5.2VA
YC_MIX
VIDEO_SW
SER3,DAC_ML0
SER[0:2],DAC_ML1
OPEN,CLOSE,SLEGP,SPINDLE,FOCUS,TRACK,SVREF
IC506
74LCX373
VD33D
GPOPALE
DAC_RST
DMUTE
D2_T[1:3]
SCART_16:9
RGB_SEL
DAC_RST
CD_DVD, VR_CD,VR_DVD CD_DVD_CT
XSFGN,XSFGP
CN505
EJTAG
TRST
TDI
TDO
TMS
TCK
CN504
RS232
RS232_RXD
3.3V1
3.3V2
VD18
IC301
CS4360
(6DAC)
IC601
CS4391
2DAC
U2
74HCT244
IC201
IP4504
DRVSB
OPU_SEL
JACK
TRIGGER
-27VA/VF+/VF-
DIG901
FLD DISPLAY
IC801
BA3308
+12V
MA[00:11]
DMCLK
CSJ
BA0
BA1
DQM
WEJ
CASJ
RASJ
IC501
ALi M3355
DV8000’s ALI
3-25
2. Power(SMPS) Block Diagram
8VT
5VD
-23VA
VF+
RECTIFIER
LINE FILTER
SWITCHING IC
TRANS
FEED B.
5.2VA
VF-
RECTIFIER(FLD)
RECTIFIER(3.8V)
RECTIFIER(10V)
LPF
LPF
RECTIFIER(14V)
LPF
12V
PWR CTL
MULTI
REG.
1.8V
3.3V
RECTIFIER(5.2V)
LPF
AC100~240V
ON/OFF
DV8000’s ALI
3-26
PICK
UP
IC501
ALI M3355
DVDPLAYER
COMBO
CHIP
MD
IC202
LA6560
Motor Driver
IC503
64M
SDRAM
FLASH
ROM
EEP
ROM
RS232
DVDLD,CDLD,CD_DVD
DVDMDI.CDMDI
SVREF21
DVD:A,B,C,D,RFO
CD:A,B,C,D,E,F,RFO
SLEGP,SPINDLE
FOCUS,TRACK
DRVSB,CLOSE
OPEN,SVREF15
FOCUS+,FOCUS-
TRACK+,TRACK-
SPINDLE+,SPINDLE-
SLED+,SLED-
LOAD+,LOAD-
OPENSW,CLOSESW,LIMITSW
MA[0:11]
DQM
CLKCSCAS
RAS
WE
MD[0:15]
RXD,TDO
IIC/VFD/DAC_SCK
IIC/VFD/DAC_TXD
ROMAD[0:21]
ROMRD
ROMWR
ROMDATA[0:7]
3. SERVO Block Diagram
DV8000’s ALI
3-27
4. MPEG & MEMORY Block Diagram
IC501(MPEG+DSP+RF)
ALiM3355
MIC1,
MIC_DET
KARAOKE
BOARD
IC503
SDRAM
64M
IC505
EEPROM
FRONT PANNEL
IC502
29LV800T/B
CPURST,
ROMWR,
ROMRD
ROMAD(0:19)
TV_DAC0
TV_DAC1
TV_DAC2
TV_DAC3
BCLK,LRCLK,DACCLK
DAC_RST
SER(0:3)
DAC_ML0
VIDEO
Interface
AUDIO
Interface
Pickup
DVD-MD1 , CD-MDI
SVREF21,
DVD:A,B,C,D,RFO
CD:A,B,C,D,E ,F ,RFO
F+, F-, T+, T-, CD_DVD
DVDLD CDLD,
IIC/VFD/DAC_CLK
IIC/VFD/DAC_TXD
MRESET
,S_REQ
VFD_RXD
X501
27MHz
BA1,BA0 ,
CSJ,RASJ,
CASJ,WEJ
,DGM,
DMCLK
MD0:15 ,
MA0:11 ,
DV8000’s ALI
3-28
5. VIDEO & AUDIO Block Diagram
MPEG
(RGB)/(YPbPr)
CVBS
COMPONENT(Y.Pb.Pr)
SCART(RGB)
CVBS
IC604
VIDEO 6dB
Amp
IC601
AUDIO DAC
(2CH)
IC602
(OP Amp)
LPF&Buffer
AUDIO 'R'
AUDIO 'L'
MPEG
DAC_RST
DACCLK
BCLK
LRCLK
SER3
IC301
AUDIO DAC
(5.1CH)
IC302
(OP Amp)
LPF&Buffer
FRONT 'R'
REAR 'R'
MPEG
DAC_RST
DACCLK
BCLK
LRCLK
SER0
SER1
SER2
FRONT 'L'
REAR 'L'
IC303
(OP Amp)
LPF&Buffer
CENTER
WOOFER
IC304
(OP Amp)
LPF&Buffer
5.1CH BOARD
A/V
JACK
DV8000’s ALI
3-29
6. KARAOKE Block Diagram(KARAOKE MODEL ONLY)
1. The unit turns to KARAOKE MODE with on-screen lyrics display and melody sound when it playbacks
VCD or DVD KARAOKE DISC.
2. If a microphone is connected at this time,MICOM recognizes the connection and prepares the composition of external voice and internal melody.
3. The weak signal of the microphone passes through PREAMP(BA3308) and is converted to digital signal by the AUDIO ADC block inside MPEG IC(ALI M3355).
4. The mixed signal is output to A/V JACK after passing through AUDIO DAC(CS4391).
Microphone1
Microphone2
AUDIO
ADC
MPEG
Ali M3355
Microphone
Signal
PREAMP
(BA3308)
AUDIO
DAC
CS4391
(Block Digram)
DV8000’s ALI
3-30 3-31
CIRCUIT DIAGRAMS
1. POWER(SMPS) CIRCUIT DIAGRAM
IMPORTANT SAFETY NOTICE
WHEN SERVICING THIS CHASSIS, UNDER NO CIRCUMSTANCES SHOULD THE ORIGINAL DESIGN BE
MODIFIED OR ALTERED WITHOUT PERMISSION
FROM THE LG ELECTRONICS CORPORATION. ALL
COMPONENTS SHOULD BE REPLACED ONLY WITH
TYPES IDENTICAL TO THOSE IN THE ORIGINAL CIR-
CUIT. SPECIAL COMPONENTS ARE SHADED ON THE
SCHEMATIC FOR EASY IDENTIFICATION.
THIS CIRCUIT DIAGRAM MAY OCCASIONALLY DIFFER FROM THE ACTUAL CIRCUIT USED. THIS WAY,
IMPLEMENTATION OF THE LATEST SAFETY AND
PERFORMANCE IMPROVEMENT CHANGES INTO
THE SET IS NOT DELAYED UNTILTHE NEW SERVICE
LITERATURE IS PRINTED.
NOTE :
1. Shaded( ) parts are critical for safety. Replace only
with specified part number.
2. Voltages are DC-measured with a digital voltmeter
during Play mode.
VF(+) Power dead
R102 is defective
VF(-) Power dead
ZD102 is defective
Power dead
IC101 is defective
3.3V, 1.8V, 8V, 12V Power dead
IC105 is defective
5V Power dead
Q107 is defective
NOTES) Warning
NOTES) Parts that are shaded are critical
NOTES) With respect to risk of fire or
NOTES) electricial shock.
NOTES : Symbol denotes AC ground.
Symbol denotes DC chassis ground.
DV8000's ALI Model
'04. 1.6
3-32 3-33
2. AV/JACK CIRCUIT DIAGRAM
2CH Audio out bad.
All Video signal isn't
appear or bad
SR14812A
DV8000's ALI Model
'04. 1.6
2CH Audio out bad.
3-34 3-35
Video signal not
appeared
Digitron all not display
System not working
System not working or
screen is abnormal
System not working or
Digitron not display
Program download fail
System not operate
SR14811A
DV8000's ALI Model
'04. 1.6
OPTIONAL PART
3. SYSTEM CIRCUIT DIAGRAM
3-36 3-37
4. DRIVER CIRCUIT DIAGRAM
SR14810A
DV8000's ALI Model
'04. 1.6
CD/DVD LD
will not on
3-38 3-39
5. TIMER CIRCUIT DIAGRAM
Remocon not operate
Remocon not operate
System not operate or
Digitron abnormal or
Key not operate.
Digital abnormal
Digital abnormal
SR14814A
DV8000's ALI Model
'04. 1.6
3-40 3-41
6. 5.1CH, SCART CIRCUIT DIAGRAM
SR14816A
DV8000's ALI Model
'04. 1.6
5.1CH Audio bad
3-42 3-43
7. KARAOKE CIRCUIT DIAGRAM (KARAOKE MODEL ONLY)
Karaoke not operate.
SR14813A
DV8000's ALI Model
'04. 1.6
3-44 3-45
• CIRCUIT VOLTAGE CHART
STOP PLAY HOLD
MODE
PIN NO.
1.49
2.58
2.63
2.61
2.63
2.6
2.63
0
1.51
3.79
0.2
0.2
3.96
3.95
3.96
3.97
3.94
3.93
7.95
1.51
1.51
1.51
2.73
5.21
1.02
2.63
2.61
2.62
5.07
1.81
3.34
3.94
3.37
0
12.89
11.91
9.71
8.08
5.07
0
3.17
0
0
0
1.6
1.66
1.61
3.17
0
3.28
3.2
0
1.52
2.59
2.61
2.57
2.82
2.69
2.68
0
1.48
3.8
0.2
0.2
3.95
3.94
3.9
3.58
2.86
5.01
7.94
1.79
1.53
1.52
2.73
5.18
0.09
2.84
2.63
2.57
5.06
1.81
3.34
3.92
3.34
0
12.89
11.91
9.51
8.02
5.05
0
3.15
1.61
1.62
1.61
1.59
1.64
1.6
3.2
0
3.25
3.17
0
1.52
2.65
2.63
2.6
3.15
2.65
2.72
0
1.48
3.43
0.2
0.2
3.59
3.95
4.1
3.64
2.07
5.03
7.56
1.85
1.57
1.52
2.33
5.21
3.15
2.9
3.13
2.6
IC201 (IP4504)
IC105(AN80T54)
IC301
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
4
5
6
7
8
9
10
11
12
STOP PLAY HOLD
MODE
PIN NO.
3.2
3.17
0
4.77
2.35
0
2.38
2.38
0
4.9
2.38
2.38
0
2.38
2.38
0
5.54
5.54
5.54
0
5.54
5.54
5.54
12.04
5.54
5.54
5.54
0
5.54
5.54
5.54
12.04
5.53
5.53
5.53
0
5.53
5.53
5.53
12.04
3.17
3.15
0
4.76
2.34
0
2.37
2.36
0
4.88
2.37
2.38
0
2.37
2.38
0
5.54
5.54
5.54
0
5.54
5.54
5.54
12.04
5.54
5.54
5.54
0
5.54
5.54
5.54
12.04
5.53
5.53
5.53
0
5.53
5.53
5.53
12.04
IC302
IC303
IC304
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
STOP PLAY HOLD
MODE
PIN NO.
VD33A_TVDAC
XDAC3OUT
XDAC2OUT
XIREF1
XIDUMP
XIEXT
XDAC1OUT
XDAC0OUT
GNDA_TVDAC
VD33A_TVDAC
XGPIO[15]
XGPIO[14]
XGPIO[13]
VD33D
XGPIO[12]
GNDD
XGPIO[11]
XGPIO[10]
VD18D
XGPIO[9]
GNDD
XGPIO[8]
VDD3MIX1
XSBLPFO
XCELPFO
AVDD_AD
XFELPFO
XTELPFO
AVSS_AD
AVDD_SVO
XTELP
XTEXO
AVDD_SVO
XVREF21
XBIASR
XDVDPD
AVSS_GA
XCDPD
XDVDLD
XCDLD
AVSS_DPD
XPDAUX2
XPDAUX1
XCD_F
XCD_E
XCD_D
XCD_C
XCD_B
XCD_A
AVDD_DPD
XDVD_D
XDVD_C
XDVD_B
XDVD_A
3.2
0.11
0
1.66
0.34
1.22
0.56
0.61
0
3.2
3.18
0.01
0.22
3.2
2.71
0
0.2
0
1.7
3.03
0
3.2
3.2
1.47
1.6
3.18
1.52
1.71
0
0
1.66
1.54
3.18
3.1
1.23
0
0
0
3.18
3.17
0
1.6
1.61
2.1
2.1
2.11
2.11
2.1
2.1
3.18
2.11
2.11
2.1
2.1
3.16
0.06
0.06
1.64
0.35
1.22
0.35
0.69
0
3.16
3.12
0.08
0.2
3.18
2.77
0
0.2
0.01
1.69
2.93
0
3.17
3.18
2.22
1.56
3.15
1.5
1.48
0
0
1.47
1.48
3.15
2.1
1.23
0
0
0
1.78
3.14
0
0.67
0.67
2.12
2.12
2.12
2.25
2.24
2.22
3.15
2.23
2.25
2.11
2.22
3.18
0
0
1.64
0.39
1.22
0.34
0.69
0.04
3.16
3.14
0
0.2
3.2
2.77
0
0.2
0
1.71
2.64
0
2.69
3.18
1.47
1.6
3.15
1.52
1.49
0
0
1.54
1.54
3.18
2.1
1.24
0
0
0
1.78
3.14
0
0.6
0.6
2.12
2.1
2.14
2.11
2.2
2.22
3.17
2.11
2.11
2.1
2.1
IC501(M3355)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
STOP PLAY HOLD
MODE
PIN NO.
XDPD_D
XDPD_C
XDPD_B
XDPD_A
AVDD_RC
XCDRF
XDVDRFP
XDVDRFN
XATTOP
XATTON
XVGAIN
XVGAIP
XGMBIASR
XLPFOP
XLPFON
AVSS_RC
AVSS_RAD
XADCIN
XADCIP
AVDD_RAD
AVDD_DA
XFOCUS
XTRACK
VDD3MIX2
XSLEGN
XSLEGP
AVSS_GD
XSPINDLE
XVREF15
XSFGP
XSFGN
AVSS_DA
XTRAY
XTESTDA
DVSS_RCK
XSFLAG[0]
XSFLAG[1]
DV18_RCK
XROMDATA[0]
GNDD
XROMDATA[1]
VD18D
XROMDATA[2]
XROMDATA[3]
XROMDATA[4]
XROMDATA[5]
XROMDATA[6]
XROMDATA[7]
XROMOEJ
GNDD
XROMWEJ
XALE
XROMADR[20]
XROMADR[19]
XROMADR[18]
2.11
2.11
2.1
2.11
3.18
2.32
2.1
2.07
0.91
0.9
2.05
2.05
1.87
0.91
0.89
0
0
1.73
1.7
3.18
3.18
1.52
1.49
3.19
2.44
1.49
0
1.49
1.48
2.17
2.12
2.18
2.5
2.5
0
3.19
3.2
1.7
3.19
0
0
1.11
0
0
0
0
0
0
3.18
0
3.19
0
3.19
3.19
3.19
2.1
2.1
2.1
2.1
3.15
2.1
2.1
2.11
0.9
0.89
2.03
2.03
1.86
0.9
0.88
0
0
1.74
1.7
3.15
3.15
1.36
1.55
3.17
2.51
1.57
0
2.06
1.52
2.16
2.54
2.54
2.44
2.51
0
3.16
3.16
1.72
3.17
0
0
1.71
0
0
0
0
0
0
3.17
0
3.17
0
3.16
3.14
3.17
2.1
2.1
2.11
2.1
3.15
2.1
2.1
2.1
0.88
0.89
2.04
2.03
1.86
0.92
0.87
0
0
1.72
1.71
3.15
3.16
1.36
1.53
3.18
2.49
1.53
0
2.41
1.51
0
2.12
0
0
2.51
0
0
0
1.72
3.17
0
0
1.71
0
0
0
0
0
0
3.18
0
3.17
0
3.18
3.19
3.18
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
STOP PLAY HOLD
MODE
PIN NO.
XROMADR[17]
XROMADR[16]
XROMADR[15]
XROMADR[14]
XROMADR[13]
VD33D
XROMADR[12]
XROMADR[11]
XROMADR[10]
XROMADR[9]
XROMADR[8]
XROMADR[7]
XROMADR[6]
XROMADR[5]
GNDD
XROMADR[4]
VD18D
XROMADR[3]
XROMADR[2]
XROMADR[1]
GNDD
XROMADR[0]
XCRESETJ
XEXTINTJ
XCTXD
XIN_XCLK
XOUT
VD18A_PLL
XTOCK
GNDA_PLL
XGPIO[7]
XGPIO[6]
VD33D
XDMCLK
XCKE
VD18D
XMA[9]
GNDD
XMA[8]
XMA[7]
XMA[6]
XMA[5]
XMA[4]
GNDD
XMD[8]
XMD[9]
XMD[10]
XMD[11]
VD33D
XMD[12]
XMD[13]
XMD[14]
XMD[15]
XMD[0]
XMD[1]
3.19
3.19
3.19
3.19
3.19
3.19
3.19
3.19
3.19
3.19
3.19
3.19
3.19
3.19
0
3.19
1.69
0
0
0
0
0
5.25
3.19
3.25
1.6
5.19
0
0
3.14
3.19
1.8
2.93
1.69
0
0
0
0.14
0.17
0.16
0.17
0
2.81
2.69
2.81
2.8
3.2
2.87
2.84
2.88
2.77
2.79
1.7
3.17
3.17
3.17
3.17
3.17
3.17
3.17
3.17
3.17
3.17
3.17
3.17
3.17
3.17
0
3.19
1.71
0
0
0
0
0
5.25
3.17
3.23
1.62
5.21
0
0
3.14
3.17
1.77
2.94
1.7
0
0
0
0.12
0.16
0.15
0.12
0
2.17
2.87
2.87
2.87
3.17
2.87
2.17
2.84
2.88
2.76
2
3.16
3.18
3.17
3.18
3.17
3.18
3.18
3.16
3.16
3.16
3.18
3.17
3.17
3.16
0
3.17
1.7
0
0
0
0
0
5.25
3.18
3.23
1.61
5.21
0
0
3.14
3.17
1.77
2.93
1.71
0
0
0
0.12
0.27
0.14
0.11
0
2.48
2.52
2.57
2.55
3.17
2.54
2.18
2.72
2.78
2.7
2.33
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
STOP PLAY HOLD
MODE
PIN NO.
GNDD
XMD[2]
XMD[3]
XMD[4]
XMD[5]
GNDD
XMD[6]
VD18D
XMD[7]
XMA[3]
XMA[2]
XMA[1]
XMA[0]
XMA[10]
VD33D
XBA0
XBA1
XMA[11]
XRASJ
XCASJ
XWEJ
XDQM
XCSJ
XTRSTJ
VD18D
XTDO
GNDD
XTCK
XTMS
XTDI
XGPIO[5]
XGPIO[4]
XGPIO[3]
XGPIO[2]
XGPIO[1]
XGPIO[0]
XDASCLK
GNDD
XBCLK
XLRCLK
XASDA[3]
XASDA[2]
XASDA[1]
GNDD
XASDA[0]
VD18D
XIECDATA
VD33A_ADC
XMIC1IN
XADC_VREF
XMIC2IN
GNDA_ADC
0
2.89
2.88
2.9
2.88
0
2.82
1.7
2.07
0.19
0.2
0.21
2.05
2.04
3.2
2.97
2.58
0
0.06
3.02
3.18
0
2.96
3.2
1.69
0
0
3.8
3.43
3.18
3.15
3.18
3.14
0
0
3.2
1.46
0
1.33
0
0
0.08
0.08
0
0.08
1.7
1.7
3.2
1.45
1.45
1.47
0
0
0
2.84
2.89
2.88
0
2.88
1.7
2.07
0.2
0.16
0.16
0.18
1.82
3.17
2.43
2.21
0.13
0.13
2.58
3.14
0.08
2.22
3.16
1.71
0.09
0
3.1
0.09
3.03
0.09
3.16
3.13
3.08
1.69
0.07
1.52
0
1.33
0.14
0.14
0.14
1.62
0
0
1.45
1.71
3.17
1.45
1.45
0.1
0.09
0
0
2.6
2.47
2.3
0
2.31
1.71
2.49
0.16
0.22
0.24
0.07
2.7
3.17
2.88
2.58
0.04
0.01
2.96
3.08
0
2.81
3.11
1.7
0
0
3.05
3.04
3.03
0.12
3.18
3.1
3.19
0
3.19
1.48
0
1.33
0.01
0.01
0.01
0.08
0
0.08
1.71
1.71
3.2
1.45
1.45
0.01
0.01
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
C217
+ 5.21 5.19
-00
C544
+ 3.19 3.16
-00
C508
+ 1.62 1.6
-00
C563
+ 3.27 3.25
-00
C607
+ 5.42 5.41
- 2.28 2.28
C640
+ 5.21 5.2
-00
C644
+ 1.32 1.26
- 0.67 0.76
C633
+ 2.51 2.5
- 2.35 2.35
C902
+ 5.25 5.25
-00
C114
+ 3.96 3.94
-00
C109
+ 3.96 3.93
-00
C130(OPEN)
+ 3.3 3.3
-00
C338
+ 5.47 5.46
-00
C315
+ 5.47 5.46
-00
C321
+ 5.47 5.47
-00
C303
+ 3.19 3.16
-00
C810
+ 1.47 1.46
-00
C214
+ 7.96 7.94
-00
3-46 3-47
STOP PLAY HOLD
MODE
PIN NO.
3.2
0
3.2
3.2
3.2
3.2
0
0
0
0
3.2
5.25
0
1.54
1.33
3.2
3.2
3.2
1.7
2.2
0
0
0
0
0
0
0
3.2
3.2
0
0
0
0
0
3.2
0
3.2
3.26
3.2
0
3.2
0
0
0
0
0
0
3.2
3.25
2.85
3.25
2.87
2.85
3.17
3.17
3.17
0.97
3.16
3.16
3.16
3.16
3.16
1.02
3.16
5.25
2.73
3.19
1.71
2.43
3.17
3.16
3.17
3.17
3.17
3.17
0
0
0
0
0
3.17
3.17
0
0
0
0
0
0
0
3.23
0
3.17
0
3.17
0
3.17
0
0
0
0
3.17
3.23
2.86
3.22
2.87
2.5
IC502 (MX29L800)
IC503 (M12L64164A)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
1
2
3
4
5
STOP PLAY HOLD
MODE
PIN NO.
0
2.81
2.9
3.25
2.85
2.87
1.9
2.8
3.25
0
3.18
3.07
3.14
2.95
2.9
2.6
2.81
0.05
0.16
0.16
0.16
3.26
0
0.16
0.15
0.16
0.12
0.05
0.05
0.04
2.85
3.26
1.79
0
2.7
2.7
2.9
3.26
2.92
2.92
0
2.92
2.94
3.26
2.91
2.94
0
2.9
0
0
0
0
0
0
0
2.1
2.04
3.22
2.1
2.91
0
3.22
0
3.1
2.58
0.61
2.97
2.96
0.32
2.83
0.06
0.18
0.18
0.17
3.24
0.59
0.17
0.53
0.53
0.5
0.16
0.17
0.5
0.08
3.236
1.78
0
0.1
0
2
3.23
1.95
2.01
0
2.03
2.17
3.23
2
2
0
1.85
0
0
0
0
0
0.12
IC504(AT24CO2A)
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
1
2
3
4
5
STOP PLAY HOLD
MODE
PIN NO.
3.21
0
3.25
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
3.3
3.25
3.27
0
1.35
1.64
1.56
0
3.19
0.12
3.2
5.11
2.11
5.04
2.29
2.28
0
5.19
2.29
2.3
5.04
5.17
2.52
5.17
1.36
0
1.68
0
2.52
0
3.16
0
3.23
0
0
0
0
0
0
0
0
0
0
0
3.23
3.17
0
0
0
0
0
0
3.23
3.23
3.26
0
1.35
1.63
1.56
0
3.16
0.13
3.17
5.1
2.1
0
2.29
2.28
0
5.18
2.28
2.29
0
5.16
2.47
5.16
1.27
0
1.55
0
2.51
0
IC506 (LCX373)
IC601(CS4391)
IC604(MM1623)
6
7
8
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1
2
3
4
5
6
7
8
9
STOP PLAY HOLD
MODE
PIN NO.
1.68
0
2.49
5.17
2.5
0
2.53
0
2.51
0
2.18
2.16
0
2.16
0.25
0.23
2.51
0.53
5.17
0.1
5.19
2.28
2.4
5.24
0
0
0
0
5.24
5.24
5.06
0
0
5.24
5.2
5.24
0
0
0
2.72
5.24
5.24
3.13
23.74
27.96
25.84
27.97
25.84
27.96
25.84
30.1
1.53
0
2.47
5.16
2.47
0
2.52
0
2.51
0
2
2.05
0
1.96
0.42
0.42
2.51
0.8
5.16
0.1
5.19
2.2
2.2
5.24
0
0
0
0
5.24
5.24
5.16
0
0
5.24
5.2
5.24
0
0
0
2.72
5.24
5.24
3.13
24.19
26.4
28.47
26.34
26.37
30.72
26.32
28.55
IC901
C217
C544
C508
C563
C607
C640
C644
C633
C902
C114
C109
C130(OPEN)
C338
C315
C321
C303
C810
C214
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
STOP PLAY HOLD
MODE
PIN NO.
25.83
27.96
27.94
27.95
30.09
27.94
30.09
28.09
30.09
30.09
30.09
30.09
28.12
28.13
28.06
28.16
28.14
28.13
28.12
28.14
30.23
2.1
2.2
2.24
2.17
0
0
0
3.2
21.96
19.87
28.5
26.33
24.16
28.6
24.51
30.66
28.75
30.7
30.82
30.8
28.72
28.68
28.85
28.81
28.32
28.82
28.86
28.81
31
1.99
1.99
2.24
2
0
0
0
3.18
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
STOP PLAY
MODE
PIN NO.
C579
+ 3.2 3.16
-00
C204
+ 3.2 3.15
- 3.18 3.13
C504
+ 3.21 3.18
-00
C608
+ 5.41 5.41
- 2.27 2.27
C621
+ 5.42 5.41
-00
C625
+ 1.65 1.66
- 0.53 0.51
C634
+ 2.15 2.13
- 2.05 2.13
C912
+ 4.85 4.85
-00
C112
+ 3.94 3.91
-00
C131
+ 5.11 5.1
-00
C333
+ 5.47 5.46
- 2.36 2.38
C339
+ 5.47 5.46
-00
C322
+ 5.47 5.47
-00
C803
+ 1.82 1.83
-00
C804
+00
-00
C202
+ 5.21 5.19
-00
C513
+ 1.51 1.52
-00
C215
+ 3.2 3.15
-00
C579
C204
C504
C608
C621
C625
C634
C912
C112
C131
C333
C339
C322
C803
C804
C202
C513
C215
STOP PLAY
MODE
PIN NO.
C600
+ 3.28 3.26
-00
C609
+ 5.41 5.41
- 2.27 2.27
C614
+ 5.42 6.41
-00
C631
+ 2.51 2.5
-00
C637
+ 2.52 2.5
- 2.37 2.36
C908
+ 5.25 5.25
-0
C123
+ 5.19 5.19
-00
C120
+ 11.91 11.91
-00
C6A1
+ 1.77 2.12
- 1.58 1.84
C332
+ 5.47 5.46
- 2.36 2.38
C311
+ 5.47 5.47
- 2.36 2.38
C304
+ 4.86 4.9
-00
C802
+ 1.82 1.83
-00
C539
+ 2.1 2.1
-00
C587
+ 1.72 1.7
-00
C501
+ 3.2 3.16
-00
C604
+ 2.25 2.19
-00
C610
+ 5.41 5.41
- 2.28 2.28
C600
C609
C614
C631
C637
C908
C123
C217
C6A1
C332
C311
C304
C802
C539
C587
C501
C604
C610
STOP PLAY
MODE
PIN NO.
C638
+ 2.15 2.78
-00
C626
+ 2.5 2.49
-00
C636
+ 2.51 2.5
- 2.31 2.31
C121
+ 19.86 20.24
- 25.56 25
C137
+ 5.17 5.17
-00
C129
+ 3.3 3.3
-00
C341
+ 5.47 5.46
- 2.37 2.39
C334
+ 11.93 11.91
-00
C320
+ 5.47 5.46
-00
C310
+ 5.47 5.47
- 2.36 2.38
C824
+00
-00
C205
+ 3.19 3.15
- 3.18 1.77
C560
+ 1.72 1.71
-00
C507
+00
- 1.47 1.45
C602
+ 5.11 5.1
-00
C619
+ 11.69 11.67
-00
C629
+ 5.17 5.16
-00
C627
+ 2.5 2.5
-00
C638
C626
C636
C121
C137
C129
C341
C334
C320
C310
C824
C205
C560
C507
C602
C619
C629
C627
STOP PLAY
MODE
PIN NO.
3-48 3-49
C635
+ 2.17 2.32
- 2.07 2.08
C122
+00
- 30.2 30.71
C116
+ 9.71 9.51
-00
C117
+ 1.8 1.8
-00
C342
+ 5.47 5.46
-00
C323
+ 5.47 5.46
-00
C318
+ 11.92 11.91
-00
C309
+00
- 2.33 2.36
C813
+ 4.65 4.64
-00
C542
+ 3.19 3.16
-00
C568
+ 3.26 3.23
-00
C506
+ 1.46 1.44
-00
C606
+ 5.19 5.18
-00
C620
+ 5.42 5.41
-00
C624
+ 2.49 2.48
- 0.67 0.67
C577
+ 3.26 3.23
-00
C6W3
+ 5.12 5.11
-00
C104
+ 12.89 12.89
-00
C635
C122
C116
C117
C342
C323
C318
C309
C813
C542
C568
C506
C606
C620
C624
C577
C6W3
C104
STOP PLAY
MODE
PIN NO.
C124(OPEN)
+ 9.71 9.52
-00
C118
+ 8.07 8.05
-00
C326
+ 11.92 11.91
-00
C325
+ 5.47 5.46
-00
C312
+ 5.47 5.46
- 2.36 2.38
C343
+00
- 4.73 4.77
C801
+00
-00
C124(OPEN)
C118
C326
C325
C312
C343
C801
STOP PLAY
MODE
PIN NO.
3-50 3-51
PRINTED CIRCUIT DIAGRAMS
1. MAIN P.C.BOARD
LOCATION GUIDE
3-54 3-55
4. SCART & 5.1CH P.C.BOARD(OPTIONAL PART) 5. SMPS P.C.BOARD
LOCATION GUIDE
LOCATION GUIDE
(Solder Side)
(Solder Side)
DECK MECHANISM PARTS
LOCATIONS
• Top View..................................................4-1
• Top View(without Tray Disc) .................4-1
• Bottom View ...........................................4-1
DECK MECHANISM
DISASSEMBLY
1. Main Base .........................................4-2
1-1. Clamp Assembly Disc.......................4-2
1-1-1. Plate Clamp ..................................4-2
1-1-2. Magnet Clamp ..............................4-2
1-1-3. Clamp Upper.................................4-2
2. Tray Disc ...........................................4-2
3. Base Assembly Sled ........................4-3
3-1. Gear Feed.........................................4-3
3-2. Gear Middle ......................................4-3
3-3. Gear Rack.........................................4-3
4. Rubber Rear......................................4-3
5. Frame Assembly Up/Down..............4-4
6. Belt Loading......................................4-4
7. Gear Pulley .......................................4-4
8. Gear Loading ....................................4-4
9. Guide Up/Down.................................4-4
10. PWB Assembly Loading................4-4
11. Base Main........................................4-4
EXPLODED VIEW
1. Deck Mechanism Exploded View....4-5
CONTENTS
SECTION 4 MECHANISM (DP-8)
4-1
DECK MECHANISM PARTS LOCATION
Starting No.
1
1, 2
1, 2, 3
1, 2, 3, 4
1
1, 6
1, 2, 6
1, 2, 6, 8
1, 2, 6, 8,
9
1, 2, 7
1, 2, 7
1, 2
1, 2 ,13
1, 2, 13, 14
1, 2, 7, 12,
13, 14
1, 2, 13
1, 2, 7, 12,
13, 14, 15,
16, 17
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Main Base
Clamp Assembly
Disc
Plate Clamp
Magnet Clamp
Clamp Upper
Tray Disc
Base Assembly Sled
Gear Feed
Gear
Middle
Gear Rack
Rubber Rear
Frame Assembly
Up/Down
Belt Loading
Gear Pulley
Gear Loading
Guide Up/Down
PWB Assembly
Loading
Base Main
4 Screws,
1 Connector
1 Locking Tabs
1 Screw
1 Screw
1 Locking Tab
1 Locking Tab
1 Locking Tab
1 Hook
2Screw
2 Locking Tabs
4-1
4-1
4-1
4-1
4-1
4-2
4-3
4-3
4-3
4-3
4-3
4-4
4-4
4-4
4-4
4-4
4-4
4-4
Bottom
Bottom
Procedure
Parts Fixing Type
Figure
Disass
embly
Note
When reassembling, perform the procedure in
reverse order.
The “Bottom” on Disassembly column of above
Table indicates the part should be disassembled
at the Bottom side.
• Top View (Without Tray)
• Bottom View
• Top View (With Tray)
4-2
DECK MECHANISM DISASSEMBLY
1.Main Base (Fig. 4-1)
1-1. Clamp Assembly Disc
1) Place the Clamp Assembly Disc as Fig. (A)
2) Lift up the Clamp Assembly Disc in direction of
arrow(A).
3) Separate the Clamp Assembly Disc from the Holder
Clamp.
1-1-1. Plate Clamp
1) Turn the Plate Clamp to counterclockwise direction and
then lift up the Plate Clamp.
1-1-2. Magnet Clamp
1-1-3. Clamp Upper
2. Tray Disc (Fig. 4-2)
1) Insert and push a Driver in the emergency eject
hole(A) at the right side, or put the Driver on the
Lever(B) of the Gear Emergency and pull the Lever(B)
in direction of arrow so that the Tray Disc is ejected
about 15~20mm.
2) Pull the Tray Disc until it is separated from the Base
Main completely.
Fig. 4-1 Fig. 4-2
4-3
DECK MECHANISM DISASSEMBLY
3.Base Assembly Sled (Fig. 4-3)
1) Release 4 Screw(S2).
2) Disconnect the FFC Connector(C1)
3-1. Gear Feed
3-2. Gear Middle
3-3. Gear Rack
1) Release the Scerw(S3)
4. Rubber Rear (Fig. 4-3)
Fig. 4-3
4-4
DECK MECHANISM DISASSEMBLY
5. Frame Assembly Up/Down (Fig. 4-4)
Put the Base Main face down(Bottom Side)
1) Release the screw(S4)
2) Unlock the Locking Tab(L3) in direction of arrow and
then lift up the Frame Assembly Up/Down to separate
it from the Base Main.
• When reassembling move the Guide Up/Down in direction
of arrow(C) until it is positioned as Fig.(C).
• When reassembling insert (A) portion of the Frame
Assembly Up/Down in the (B) portion of the Guide
Up/Down as Fig.(B)
6. Belt Loading(Fig. 4-4)
Put the Base Main on original position(Top Side)
7. Gear pulley (Fig. 4-4)
1) Unlock the Locking Tab(L4) in direction of arrow(B) and
then separate the Gear Pulley from the Base Main.
8. Gear Loading (Fig. 4-4)
9. Guide Up/Down (Fig. 4-4)
1) Move the Guide Up/Down in direction of arrow(A) as
Fig.(A)
2) Push the Locking Tab(L5) down and then lift up the
Guide Up/Down to separate it from the Base Main.
When reassembling place the Guide Up/Down as Fig.(C)
and move it in direction arrow(B) until it is locked by the
Locking Tab(L5). And confirm the Guide Up/Down as Fig.(A)
10. PWB Assembly Loading (Fig. 4-4)
Put the Base Main face down(Bottom Side)
1) Release 1 Screws(S5)
2) Unlock the Loading Motor (C2) from the Hook (H1) on
the Base Main.
3) Unlock 2 Locking Tabs(L6) and separate the PWB
Assembly Loading from the Base Main.
11. Base Main(Fig. 4-4)
Note
Note
Note
Note
Note
Fig. 4-4
EXPLODED VIEWS
1. Deck Mechanism Exploded View
012A
015B
015A
015
019
012
026
012A
440
012B
024A
012C
035A
017
013
014
439
018
A01
A00
A02
020
001
002
003
435
016
010
430
025
024
030
432
034
034 438
035
033
022
437
037
036
031
431
435
021
A03
4-5 4-6
Loading...
