Zeki TB782B User Manual

Download

USER’S GUIDE

TB782B

7” Capacitive Multi-touch Tablet

For the most up-to-date version of this User’s Guide, go to

www.zekitablet.com

Warnings and Precautions

• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE

BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

• WARNING:To reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture.

• AVERTISSEMENT: Pour réduire le risque d’incendie ou de choc électrique, ne pas exposer cet appareil sous la pluie et l’humidité.

• WARNING: Changes or modications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

• WARNING: Do not place the unit on top of any soft, porous, or sensitive surfaces to avoid damaging the surface. Use a protective barrier between the unit and surface to protect the surface.

• PRÉCAUTION: Danger d’explosion si les piles sont remplacées de façon incorrect. Remplacer les piles seulement par le même type de pile ou l’équivalent.

• WARNING:The battery, batteries, and battery pack shall not be exposed to excessive heat such as sunshine, re, or the like.

• WARNING:Lithium batteries, like all rechargeable batteries are recyclable and should be recycled or disposed of in normal household waste. Contact your local government for disposal or recycling practices in your area. They should never be incinerated since they might explode.

• WARNING: Shock hazard - Do Not Open.

• AVIS: RISQUE DE CHOC ÉLECTRIQUE - NE PAS OUVRIR

Mains Plug or Direct plug-in adapter is used as disconnect device and it should remain readily operable during intended use. In order to disconnect the apparatus from the mains completely, the Mains Plug or Direct plug-in adapter should be disconnected from the mains socket outlet completely.

La che d’alimentation ou adaptateur de courant est utilisé

comme dispositif de déconnexion et doit rester accessible pendant

l’utilisation. Pour mettre l’appareil hors tension, la che ou adaptateur de courant doit être débranché de la prise

de courant.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

ATTENTION

RISQUE D' ÉLECTROCUTION

NE PAS OUVRIR

WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

The lightning ash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage" within the product's enclosure that may be of sufcient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

This symbol indicates that this product incorporates double insulation between hazardous mains voltage and user accessible parts.

• Your device is designed to be in compliance with Radio

Waves exposure regulations and does not exceed the limits for exposure to radio waves (radio frequency electromagnetic elds) in accordance with the Federal Communications Commission (FCC) . A substantial safety margin is set to assure the safety of all persons, regardless of health. A unit of measurement known as the Specic Absorption rate, or SAR is utilized for the radio wave exposure guidelines. The SAR measurement for devices does not exceed 1.6W/ kg. The actual SAR values for your device, while in use, are normally well below the stated values. The operating power of your device is automatically decreased when full power is not needed for the wireless connection to increase system efciency and to minimize interference on the network. The lower the power output of the device the lower its SAR value.

Special note: When placing your unit on a lacquered or natural nish, protect your furniture with a cloth or other protective material.

Customer Support: 1-888-999-4215 2

Customer Support: 1-888-999-4215

Important Safety Instructions

1. Read these Instructions.

2. Keep these Instructions.

3. Heed all Warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding - type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. When the provided plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specied by the manufacturer.

12.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15. DO NOT place objects on top of the device, as objects may scratch the screen.

16. DO NOT expose the device to dirty or dusty environments.

17. DO NOT place the device on an uneven or unstable surface.

18. DO NOT insert any foreign objects into the device

19. DO NOT expose the device to strong magnetic or electrical eld.

20. DO NOT expose the device to direct sunlight as it can damage the LCD Screen.

21. Keep it away from heat sources.

22. The device and the adapter may produce some heat during normal operation

23. Clean the touch screen with a soft cloth. If needed, dampen the cloth slightly before cleaning.

Use only with a cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

Never use abrasives or cleaning solutions.

24. Disconnect the device from an electrical outlet and power off before cleaning the device

25. DO NOT disassemble the device, only a certied service technician should perform repair.

26. Please select a suitable volume and avoid loud sounds while using the headphones

27. Only use the original charger supplied with this device.

28. Please do not disconnect the device while downloading

and uploading, or it may cause application errors.

FCC Warnings

WARNING: Changes or modications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Additional Warnings

• The apparatus shall not be exposed to dripping or

splashing and that no objects lled with liquids, such as vases, shall be placed on apparatus.

L’appareil ne doit pas être exposé aux écoulements

ou aux éclaboussures et aucun objet ne contenant de

liquide, tel qu’un vase, ne doit être placé sur l’objet.

• Battery shall not be exposed to excessive heat

such as sunshine, re or the like.

Les piles ne doivent pas être exposées à de forte chaleur, tel qu’à

la lumière du soleil, au feu ou autres choses de semblable.

• Caution marking is located at the rear or bottom of the apparatus.

Attention marquage est situé sur le paneau

arrière ou inférieur de l’unité.

• The marking information is located at the

rear or bottom of apparatus.

Le marquage est situé sur le paneau arrière ou inférieur de l’unité.

Customer Support: 1-888-999-4215

Table of Contents

Table of Contents ................................................................ 4-5

7” Capacitive Multi-touch Tablet .................................................... 6

Features Included

Setup ............................................................................. 7

Power Charging Sleep Timer

Introduction .................................................................... 8-9

Basic Use ........................................................................10

Unlocking the Screen Customizing the Lock Screen Orienting Your Tablet

Connecting to the Internet ........................................................11

Connecting to Wireless Internet

Browser ..........................................................................12

Navigating the Browser

Email ............................................................................ 13

Setting Up an Email account Manually Conguring an Email account

Getting to Know Your Tablet ...................................................... 14

Touch Screen

On-Screen Introduction ...........................................................15

Icons You Should Know Notications

4Customer Support: 1-888-999-4215 4

Table of Contents

Screen ...........................................................................16

Changing the Background Changing Screens Viewing Open items

Apps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17-18

Accessing the App Menu Adding Apps to the Home Screen Removing Apps from the Home Screen Managing Apps Removing Apps

Camera & Video Camera .......................................................... 19

Using the Camera Using the Video Camera Accessing Saved Photos and Videos

Transferring Files .................................................................20

Transferring Files with a Computer

Connectivity ..................................................................... 21

Connecting to a TV Connecting a Micro SD card Removing a Micro SD card

Company Information ............................................................22

International Support Contact Information Warranty Green Initiative

Customer Support: 1-888-999-4215 5

Customer Support: 1-888-999-4215

7” Capacitive Multi-touch Tablet

Features

• 7” TFT LCD display

• Capacitive touchscreen

• Full color touch LCD display

• Android Operating System

• 1.5 GHz Processor

• Built-in 1GB RAM

• Built-in WiFi

• 8GB installed ash memory

• Expandable memory

• G-Sensor for screen rotation

• 800 x 480 native resolution

• Front Facing Camera

• Built-in microphone

• Digital video: RM, RMVB,

FLV, WMV, MP4, VOB

• Digital audio: MP3, WMA (non-DRM), WAV

• Digital photos: JPEG, BMP, PNG

• eBooks: PDF, EPUB

• Mini-HDMI output (1080p)

• Micro-SD memory card reader

• USB port

• 3.5mm headphone jack

• Built-in speaker

• DC battery power: built-in

rechargeable battery

• DC battery power: 2800 mAH battery

• Battery life: ~2.5 hours

Included

• USB cable

• One set of stereo earbuds

• AC/DC power adapter

Note: Specications are subject to change without prior notice.

Customer Support: 1-888-999-4215 6

Customer Support: 1-888-999-4215

VOLUME

POWER

SERIAL NO.:

MODEL NO. : TB782B INPUT : DC5V 2.0A

MADE IN CHINA FID : CF

DC IN 5V

MICRO SD

HDMI

RESET

MIC

Setup

Power

Requires an AC/DC power adapter (included)

Charging Sleep Timer

Initial charge time ~10 hrs.

When the Battery Indicator signals that the power is running low, connect the tablet to an AC outlet using the included adaptor, or connect the included USB charging cord to the USB port on a powered on computer to charge.

A warning will also display on the screen stating that the battery is low.

Note: It is recommended to charge the tablet using the AC adapter.

In order to conserve battery, the tablet will shut o after a certain period of time and enter sleep mode.

1. To adjust the time it takes to enter sleep mode, press the

Settings button.

2. Select Display.

3. Select Sleep and choose how long it takes the tablet to enter sleep mode.

4. To manually enter sleep mode, press the Power button.

Note: It is normal for the tablet surface to become warm during charging or long periods of use.

Note: If the tablet is not being used regularly, it is recommended to charge the battery fully once a month.

Customer Support: 1-888-999-4215

Introduction

Volume

Press to turn the

volume up or down.

Power

Upon initial use,

press and hold

to power on the

tablet. This may take

several minutes.

Press to put the device into standby mode.

Press and hold to

completely power

the unit on or o.

VOLUME

POWER

MIC

MODEL NO. : TB782B INPUT : DC5V 2.0A

MADE IN CHINA FID : CF

SERIAL NO.:

Stereo Headphone

Jack

HDMI

DC IN 5V

USB Port

Connect the

included cable to

begin charging.

HDMI Port

Used to connect a TV.

Reset

Card Slot

MICRO SD

RESET

DC Power input

Customer Support: 1-888-999-4215 8

Introduction

Camera

Press to access

the menu.

Customer Support: 1-888-999-4215 9

Home

Press to return to the home screen.

Back

Press to return to the

previous screen.

Basic Use

Unlocking the Screen

Upon rst use, you will notice your tablet prompts you to unlock the screen to begin use.

1. To do this, place your nger on the Lock icon, and drag it toward the Unlock icon.

Customizing the Lock Screen

1. To add a password, PIN, or unlock

pattern, press the Settings button.

2. Select Security from the menu.

3. Select the desired security method and follow the instructions on screen.

Orienting Your Tablet

The tablet can oriented horizontally or vertically.

To change the orientation, rotate the tablet to the desired position.

The screen will rotate automatically.

Customer Support: 1-888-999-4215 10

Customer Support: 1-888-999-4215

Connecting to the Internet

Connecting to Wireless Internet

1. Press the Settings Icon.

2. Locate the Wi-Fi setting and slide it to the On position.

3. Select a network from the list of available networks.

To refresh the list of available networks, press the Scan button.

To manually add a network, select the Add Network button.

4. Select Connect from the pop up menu.

5. If the network is secured with a password, enter the password to continue.

6. Once nished connecting, the display will show Connected under the name of the network.

To conserve battery life, turn o Wi-Fi when not in use.

Browser

Navigating the Browser

Make sure you are connected to the internet before attempting to use the browser.

1. Press the Browser icon.

2. Tap the navigation bar at the top of the page

3. The on-screen keyboard will automatically appear.

4. Type in a web address or a search term and hit Enter to begin browsing.

Customer Support: 1-888-999-4215 12

Customer Support: 1-888-999-4215

Setting Up an Email account

1. Press Email icon under App menu.

2. Enter your email address and password, then press Next.

If this does not work, you will need to manually congure your account. Before attempting to congure manually, re-enter you email and password to make sure they are correct.

Manually Conguring an Email account

It is recommended to consult an IT professional before attempting to manually congure your email address.

1. To set up your email manually, detailed information is required. Check your provider’s website or phone support for individual provider information.

2. The rst thing you will need to determine is the server type. While most servers are POP3, IMAP and Exchange are also supported services.

3. Enter your email address and password then press Next.

4. Fill in all information for the Incoming server portion of the manual setup.

5. Press Next and the app will test your settings.

Wi-Fi is required to be active for this step.

6. Fill in all information for the Outgoing server settings.

7. Press Next and the app will test your settings.

Wi-Fi is required to be active for this step.

Getting to Know Your Tablet

Touch Screen

With capacitive touch, your tablet is able to recognize a wide variety of touch functions.

Tap

Briey tap an icon or menu item.

Swipe (Fig. 1)

In the home screen, press down gently and move your nger across the screen.

Drag (Fig. 2)

Tap and hold an icon until it becomes active, then move your nger to drag it.

Hold

Press and hold an item (such as a photo in your internet browser) to see additional menu options.

Pinch to Zoom (Fig. 3)

Place two ngers on the screen and slide them apart to zoom in. Slide them back together to zoom out.

(Fig. 1)

(Fig. 2)

(Fig. 3)

Customer Support: 1-888-999-4215 14

Customer Support: 1-888-999-4215

On-Screen Introduction

Icons You Should Know

Battery Indicator

Indicates how much power the tablet has. When red, the tablet needs charging

Wi Indicator

Indicates if a WiFi signal is available and the strength of a connected signal.

Lock

Indicates the tablet is locked. The tablet will not function unless unlocked.

Back

Press to return to a previous screen.

Home

Press to return to the home screen.

Notications

Items will display in the lower right hand corner of your screen alerting you to activity such as the progress of a download, or a new email message.

Screens

Press to view all running applications and windows.

Press to view the menu.

App Menu

Press to view all running applications and windows.

Press to begin a Google search of the internet.

Settings

Press to access the settings menu.

15Customer Support: 1-888-999-4215

Screen

Changing the Background

1. Press the Menu button.

2. Select Wallpaper from the pop up menu.

3. Select from Live Wallpapers, preloaded wallpapers, or choose a photo from the gallery.

4. Select a picture to change the current wallpaper.

Changing Screens

When the tablet is turned on, it will default to the home screen. However, by swiping the screen, you can access screens to the left and right of the home screen. Apps and widgets may be dragged onto these screens as well.

Viewing Open items

By pressing the Screens you can see all running applications.

Customer Support: 1-888-999-4215 16

button,

Customer Support: 1-888-999-4215

Apps

Accessing the App Menu

1. Press the App Menu button in the upper right hand corner.

2. This will load the App menu, which shows all installed apps and widgets.

Note: App menu is reective of apps installed on the tablet and will likely change from the gure shown.

Adding Apps to the Home Screen

1. Press the App Menu button in the upper right hand corner.

2. Press and hold on an icon and wait for the screen to appear. Drop the icon wherever it is desired.

To add the icon to a screen other than the home screen, drag it to the left or right.

Removing Apps from the Home Screen

1. Press and hold the desired icon.

2. Drag it to the Remove option at the top of the screen.

Apps

Managing Apps

1. Press the Menu button.

2. Select Manage Apps.

3. From this menu you can view and modify all installed apps.

Removing Apps

1. Press the Menu button.

2. Select Manage Apps.

3. Select the app you want to uninstall.

4. Press the Uninstall button.

5. The tablet will prompt ask you if you’re certain you want to uninstall this app, select Ok.

6. The app will be uninstalled.

Warning: The selected app and all related content will be completely removed from the tablet.

Customer Support: 1-888-999-4215 18

Customer Support: 1-888-999-4215

Camera & Video Camera

Using the Camera

1. Press the Camera icon.

2. Select the Camera button to switch to Camera mode.

3. Press the blue Capture button to take a picture.

To view the picture just captured, press the small preview in the upper right hand corner.

Using the Video Camera

1. Press the Camera icon.

2. Press the Video button to switch to Video mode.

3. Press the red Capture button to begin taking a video.

4. Press the button again to end the recording.

To view the recording just captured, press the small preview in the upper right hand corner.

Accessing Saved Photos and Videos

1. Press the Gallery icon.

2. Select the desired folder.

3. Select an individual photo or video to enlarge and view it.

Use the Pinch to Zoom touch action to zoom in further.

Transferring Files

Transferring Files with a Computer

1. To begin transferring les to your computer, plug one end of the included USB cord into the unit, and the other into the USB port on a computer.

2. Press the USB icon in the lower right hand corner.

3. Select USB Connected.

4. Press the Turn On USB

Storage button.

Using the native controls, accept any prompts on the connected computer.

5. You will now be able to transfer les to and from your computer.

6. To end the sessions, press the

Turn O USB Storage button.

Customer Support: 1-888-999-4215 20

Customer Support: 1-888-999-4215

Connectivity

DC IN 5V

MICRO SD

RESET

Connecting to a TV

Connect one end of a HDMI cable (not included) to the HDMI Port and the other end to the HDMI input on a television.

MICRO SD

RESET

DC IN 5V

HDMI

MADE IN CHINA FID : CF

MODEL NO. : TB782B INPUT : DC5V 2.0A

POWER

VOLUME

HDMI

SERIAL NO.:

MIC

Connecting a Micro SD card

1. Turn o the tablet using the Power button.

2. Insert the Micro SD Card into the Card Slot.

3. To access the content on the Micro SD Card, go to the Apps menu by pressing the Apps Menu button.

4. Press the ES Explorer icon.

If you cannot locate this icon, please make sure you have installed the pre-loaded Zeki apps.

5. Press extsd to view the contents of the card.

HDMI

Removing a Micro SD card

1. Press the Settings button to access the settings menu.

2. Select Storage.

3. Select Unmount Micro SD CARD.

4. Remove the card from the tablet by gently pushing it until it pops out.

Zeki TB782B User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
