FS/VS Smart Camera
License Upgrade
User Guide
MN-004305-02EN
ZEBRA and the stylized Zebra head are trademarks of Zebra Technologies Corporation, registered in
many jurisdictions worldwide. All other trademarks are the property of their respective owners.
© 2022 Zebra Technologies Corporation and/or its affiliates. All rights reserved.
Information in this document is subject to change without notice. The software described in this document
is furnished under a license agreement or nondisclosure agreement. The software may be used or copied
only in accordance with the terms of those agreements.
For further information regarding legal and proprietary statements, please go to:
SOFTWARE:zebra.com/linkoslegal
COPYRIGHTS:zebra.com/copyright
WARRANTY:zebra.com/warranty
END USER LICENSE AGREEMENT: zebra.com/eula
Terms of Use
Proprietary Statement
This manual contains proprietary information of Zebra Technologies Corporation and its subsidiaries
(“Zebra Technologies”). It is intended solely for the information and use of parties operating and
maintaining the equipment described herein. Such proprietary information may not be used, reproduced,
or disclosed to any other parties for any other purpose without the express, written permission of Zebra
Technologies.
Product Improvements
Continuous improvement of products is a policy of Zebra Technologies. All specifications and designs are
subject to change without notice.
Liability Disclaimer
Zebra Technologies takes steps to ensure that its published Engineering specifications and manuals are
correct; however, errors do occur. Zebra Technologies reserves the right to correct any such errors and
disclaims liability resulting therefrom.
Limitation of Liability
In no event shall Zebra Technologies or anyone else involved in the creation, production, or delivery of the
accompanying product (including hardware and software) be liable for any damages whatsoever
(including, without limitation, consequential damages including loss of business profits, business
interruption, or loss of business information) arising out of the use of, the results of use of, or inability to
use such product, even if Zebra Technologies has been advised of the possibility of such damages. Some
jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
2
About This Guide
This guide provides details license acquisition methods for utilizing specific toolsets in Zebra Aurora.
IMPORTANT: If you have a problem with your equipment, contact Zebra Global Customer Support for your
region. Contact information is available at: zebra.com/support
Service Information
If you have a problem with your equipment, contact Zebra Global Customer Support for your region.
Contact information is available at: zebra.com/support
When contacting support, please have the following information available:
• Serial number of the unit
• Model number or product name
• Software type and version number.
Zebra responds to calls by email, telephone or fax within the time limits set forth in support agreements.
.
If your problem cannot be solved by Zebra Customer Support, you may need to return your equipment for
servicing and will be given specific directions. Zebra is not responsible for any damages incurred during
shipment if the approved shipping container is not used. Shipping the units improperly can possibly void
the warranty.
If you purchased your Zebra business product from a Zebra business partner, contact that business
partner for support.
Revision History
Changes to the original guide are listed below:
Change Date Description
-02 Rev A 7/22 Feature updates in this version include:
-01 Rev A 7/21 Initial Release
• Offline License Acquisition
• Instructions for Obtaining Activation and Device ID
• License Types
3
Contents
About This Guide
Service Information ............................................................................................................... 3
Revision History .................................................................................................................... 3
FS/VS License Upgrade 2
Acquiring a License ............................................................................................................... 2
License Acquisition Modes .................................................................................................... 2
Acquiring an Activation ID ..................................................................................................... 2
Acquiring License from the Licensing Server (Online) .......................................................... 2
Acquiring License by Downloading Bin File (Offline) ............................................................ 5
Downloading an Offline License from the Licensing Server ............................................... 5
Downloading the Capability Response ................................................................................. 7
Time Tampering .................................................................................................................. 13
Returning a License ......................................................................................................................... 14
License Types ..................................................................................................................... 15
1
FS/VS License Upgrade
FS Decode and VS Machine Vision Toolsets require a valid license to be installed on the
can be activated using the Web HMI. This guide includes instructions on expanding the toolset of Zebra
Aurora by upgrading the license. For more information on using the FS/VS Smart Camera, refer to the
Product Reference Guide.
Acquiring a License
For the customers, partners, and distributors that require a FS/VS Industrial Scanner product license for FS
Decode and VS Machine Vision Tools through your Account Manager.
A p
erpetual license is a permanent license that is available for the lifespan of the device.
License Acquisition Modes
A license for the device may be acquired in an online or offline mode.
•
Licensing Server (Online mode)
• Bin File (Offline Mode)
NOTE:
network with an active Internet connection. The device cannot utilize a computer’s Internet connection (over
USB-C or direct Ethernet connection to the computer) to perform the upgrade.
This upgrade and deactivation process for a license requires the device to be connected to an Ethernet
device. Licenses
Acquiring an Activation ID
The Activation ID is the unique 32-bit alpha-numeric number provided when the license is procured. This
number acts as the key to enable the device to activate the license. An example of the Activation ID is
4a69-7ed6-ffec-4448-8874-d155-2fcd-a2cd.
NOTE:
Acquiring License from
This is the default license acquisition
acquire a license from the licensing server. The license server is hosted on the cloud and the
contacts the cloud-based license server to acquire licenses.
Refer to the link shared via e-mail when the license is procured for credentials.
the
Licensing Server (Online)
in online mode.
2
The device must have an Internet connection to
device
Open the web Human-Machine Interface (HMI) by entering the device’s IP address into a web browser
1.
or clicking the IP address link under View Devices in Zebra Aurora.
Figure 1 Zebra Aurora - View Devices
2. Log into the HMI using the default credentials for an administrator account:
a. Username: admin
b. Password: admin
3. Select the gear icon to access the settings menu.
Figure 2 Web HMI
Select the Licensing tab.
To acquire licenses from the Licensing Server:
1.
Select the Online option from the ACQUIRE LICENSE METHOD as shown in
2. Enter the following
Licensing Server
URL in the LICENSING SERVER URL form field:
• zebra-licensing.flexnetoperations.com/flexnet/deviceservices
3
Figure 3
.
