Zebra Omnii Hand-Held Computer User Manual
OMNII HAND-HELD
COMPUTER
USER GUIDE
for Windows Embedded CE 6.0
OMNII HAND-HELD COMPUTER USER GUIDE
(Windows Embedded CE 6.0)
8000211-003
Revision A
December 2020
i
ii Omnii Hand-Held Computer with Windows CE 6.0 User Manual
Copyright
No part of this publication may be reproduced or used in any form, or by any electrical or mechanical means,
without permission in writing from us. This includes electronic or mechanical means, such as photocopying,
recording, or information storage and retrieval systems. The material in this manual is subject to change
without notice.
The software is provided strictly on an “as is” basis. All software, including firmware, furnished to the user is on
a licensed basis. We grant to the user a non-transferable and non-exclusive license to use each software or
firmware program delivered hereunder (licensed program). Except as noted below, such license may not be
assigned, sublicensed, or otherwise transferred by the user without prior written consent from us. No right to
copy a licensed program in whole or in part is granted, except as permitted under copyright law. The user shall
not modify, merge, or incorporate any form or portion of a licensed program with other program material, create
a derivative work from a licensed program, or use a licensed program in a network without written permission
from us. The user agrees to maintain our copyright notice on the licensed programs delivered hereunder, and
to include the same on any authorized copies it makes, in whole or in part. The user agrees not to decompile,
disassemble, decode, or reverse engineer any licensed program delivered to the user or any portion thereof.
We reserves the right to make changes to any software or product to improve reliability, function, or design.
We do not assume any product liability arising out of, or in connection with, the application or use of any
product, circuit, or application described herein.
No license is granted, either expressly or by implication, estoppel, or otherwise under any of our intellectual
property rights. An implied license only exists for equipment, circuits, and subsystems contained in our
products.
Disclaimer
Every effort has been made to make this material complete, accurate, and up-to-date. In addition, changes are
periodically incorporated into new editions of the publication.
We reserve the right to make improvements and/or changes in the product(s) and/or the program(s) described
in this document without notice, and shall not be responsible for any damages including, but not limited to,
consequential damages, caused by reliance on the material presented.
Zebra and the Zebra head graphic are registered trademarks of ZIH Corp. The Symbol logo is a registered
trademark of Symbol Technologies, Inc., a Zebra Technologies company.
Workabout Pro4 and the names of other products and services provided by us are trademarks of ours.
Windows® and the Windows Logo are trademarks or registered trademarks of Microsoft Corporation in the
United States and/or other countries.
The Bluetooth® word mark and logos are owned by Bluetooth SIG, Inc. and any use of such marks by us is
under license.
iii
All trademarks used herein are the property of their respective owners.
iv Omnii Hand-Held Computer with Windows CE 6.0 User Manual
Revision History
Changes to the original guide are listed below:
Change Date Description
Rev -001A 04/2015 Zebra rebrand.
Rev -002A 4/2016 Add Important information for mounting vehicle cradle.
Rev. -003 12/2020 Update Bluetooth terminology.
Table of Contents
TABLE OF CONTENTS
About This Guide............................................................................................................................. xi
Text Conventions ............................................................................................................................ xii
Overview of the Omnii Hand-Held Computer.................................................................................. xii
Regulatory Labels........................................................................................................................... xvi
Chapter 1: Basic Operation
Omnii Features ............................................................................................................................... 1-1
Omnii Modules Available................................................................................................................. 1-3
Documents Available ..................................................................................................................... 1-3
Preparing the Omnii for Operation.................................................................................................. 1-4
The Battery.....................................................................................................................................1-4
Switching the Omnii On and Off...................................................................................................... 1-5
Resetting the Omnii ........................................................................................................................ 1-5
Performing a Warm Reset..............................................................................................................1-6
Performing a Cold Reset................................................................................................................1-6
Performing a Clean Start................................................................................................................1-6
Boot to BooSt .................................................................................................................................1-6
Performing a Hard Reset ...............................................................................................................1-7
Attaching Carrying Accessories ...................................................................................................... 1-7
Calibrating the Touchscreen ........................................................................................................... 1-7
Imager and Scanner Options.......................................................................................................... 1-7
Connectivity .................................................................................................................................... 1-7
Data Transfer ................................................................................................................................. 1-8
Voice Communication ..................................................................................................................... 1-8
Chapter 2: Getting To Know Your Omnii
Operating System ........................................................................................................................... 2-1
Battery Details................................................................................................................................. 2-1
Battery Safety .................................................................................................................................2-1
Battery Swap Time .........................................................................................................................2-1
Charging the Battery ......................................................................................................................2-2
The Keyboard ................................................................................................................................. 2-2
ii Omnii Hand-Held Computer with Windows CE 6.0 User Guide
Regular Keys..................................................................................................................................2-3
Modifier Keys..................................................................................................................................2-4
Activating Modifier Keys...................................................................................................... 2-5
Locking Modifier Keys......................................................................................................... 2-5
Function Keys and Macro Keys .....................................................................................................2-6
Function Keys ..................................................................................................................... 2-6
Macro Keys ......................................................................................................................... 2-6
Numeric Keyboards — Accessing Alpha Keys ..............................................................................2-7
The Keypad Backlight ....................................................................................................................2-8
The Display..................................................................................................................................... 2-8
Adjusting the Display Backlight ......................................................................................................2-8
Calibrating the Touchscreen...........................................................................................................2-8
Indicators ........................................................................................................................................ 2-9
LEDs...............................................................................................................................................2-9
Battery Charge Status LED................................................................................................. 2-9
Operating System Status LED ............................................................................................ 2-9
Radio Status LED ............................................................................................................... 2-10
Scanner Status LED ........................................................................................................... 2-10
Onscreen Indicators .......................................................................................................................2-10
Audio Indicators..............................................................................................................................2-12
Vibrations........................................................................................................................................2-12
Inserting the microSD Card and SIM Card ..................................................................................... 2-12
Inserting the Cards .........................................................................................................................2-12
Scanners and Imagers.................................................................................................................... 2-13
Basic Scanner Operations..............................................................................................................2-14
Scanning Techniques .....................................................................................................................2-14
Scanner Status LED, Sounds, and Vibrations ...............................................................................2-14
Troubleshooting ..............................................................................................................................2-15
Operating One Dimensional (1D) Internal Laser Scanners ...........................................................2-15
Operating Internal Two Dimensional (2D) Imagers........................................................................2-15
Windows Embedded CE 6.0........................................................................................................... 2-16
Navigating in Windows Embedded CE and Applications...............................................................2-16
Navigating Using a Touchscreen......................................................................................... 2-16
Navigating Using the Keyboard .......................................................................................... 2-17
The Windows Classic Shell Startup Desktop.................................................................................2-18
The Taskbar ........................................................................................................................ 2-19
The Start Menu ................................................................................................................... 2-20
The Kiosk Desktop Shell................................................................................................................. 2-25
Restoring the Windows Classic Shell.............................................................................................2-26
General Maintenance ..................................................................................................................... 2-27
Caring for the Touchscreen ............................................................................................................2-27
Cleaning the Omnii.........................................................................................................................2-27
Chapter 3: Configuration
Overview of Software...................................................................................................................... 3-1
Software Advantage .......................................................................................................................3-1
Table of Contents iii
Microsoft Software..........................................................................................................................3-2
The Control Panel........................................................................................................................... 3-2
Control Panel Applications .............................................................................................................3-3
App Launch Keys............................................................................................................................ 3-6
Bluetooth
Paired ............................................................................................................................................3-8
Device ............................................................................................................................................3-9
Servers ..........................................................................................................................................3-12
Mode ..............................................................................................................................................3-13
About .............................................................................................................................................3-13
The Bluetooth GPRS WAN Connection .......................................................................................3-14
Certificates...................................................................................................................................... 3-17
Compass......................................................................................................................................... 3-17
Data Transfer between Omnii and a PC ........................................................................................ 3-18
Uploading Data in a Docking Station .............................................................................................3-18
Using Microsoft ActiveSync............................................................................................................3-19
Using Windows Mobile Device Center...........................................................................................3-19
Display Properties........................................................................................................................... 3-19
Background ...................................................................................................................................3-19
Appearance ...................................................................................................................................3-20
Backlight ........................................................................................................................................3-20
Dr. Debug ....................................................................................................................................... 3-21
Status..............................................................................................................................................3-21
Utilities ............................................................................................................................................3-21
Motion Meter...................................................................................................................................3-22
Settings...........................................................................................................................................3-23
Error Reporting ............................................................................................................................... 3-23
GPS (Global Positioning System) Settings..................................................................................... 3-23
Power..............................................................................................................................................3-24
Profiles............................................................................................................................................3-24
Programs ........................................................................................................................................3-25
AGPS..............................................................................................................................................3-25
Info..................................................................................................................................................3-26
Imager & Camera Settings ............................................................................................................. 3-26
Input Panel...................................................................................................................................... 3-27
Keyboard Properties ...................................................................................................................... 3-28
Key Repeat.....................................................................................................................................3-29
Keyboard Backlight ........................................................................................................................3-29
Keyboard One Shot Modes............................................................................................................3-30
Keyboard Macro Keys....................................................................................................................3-31
Unicode Mapping ...........................................................................................................................3-32
Scancode Remapping....................................................................................................................3-33
®
Setup.......................................................................................................................... 3-7
Discovering and Removing Devices ................................................................................... 3-9
Filtering By Class of Device (COD)..................................................................................... 3-10
Device Pop-up Menu........................................................................................................... 3-10
Pairing a Device.................................................................................................................. 3-10
iv Omnii Hand-Held Computer with Windows CE 6.0 User Guide
Lock Sequence...............................................................................................................................3-35
Manage Triggers............................................................................................................................. 3-36
Trigger Mappings............................................................................................................................3-36
Add and Edit Trigger Mapping........................................................................................................3-37
Microphone .................................................................................................................................... 3-38
TekTerm Client ................................................................................................................................ 3-39
PartnerUp ....................................................................................................................................... 3-39
Pocket PC Compatibility ................................................................................................................. 3-39
Power Properties ............................................................................................................................ 3-40
Battery Capacity .............................................................................................................................3-40
Power Saving Suspend ..................................................................................................................3-40
Suspend Threshold and Estimated Battery Backup ......................................................................3-41
Advanced .......................................................................................................................................3-42
Built-in Devices...............................................................................................................................3-42
Battery Health.................................................................................................................................3-43
Kiosk Access................................................................................................................................... 3-44
Administrator Password .................................................................................................................3-45
Shell Settings..................................................................................................................................3-46
Restrictions ....................................................................................................................................3-48
Control Panel Settings....................................................................................................................3-48
Import/Export to File .......................................................................................................................3-49
Remote Desktop Connection ......................................................................................................... 3-50
Scanners......................................................................................................................................... 3-50
Barcodes ........................................................................................................................................3-51
Scanner............................................................................................................................... 3-51
Restoring Default Settings .................................................................................................. 3-51
Options ..........................................................................................................................................3-52
Double Click Parameters .................................................................................................... 3-53
Display Parameters............................................................................................................. 3-53
Data Handling ..................................................................................................................... 3-54
Translations ...................................................................................................................................3-54
Case Rules ......................................................................................................................... 3-56
Ports ..............................................................................................................................................3-56
Port Replicator Port A (COM5) and Port B (COM6) ............................................................ 3-57
Screen Rotation .............................................................................................................................. 3-58
Storage Manager ............................................................................................................................ 3-59
Formatting a Memory Card ............................................................................................................3-59
Creating Partitions ..........................................................................................................................3-59
Partition Management ....................................................................................................................3-60
Stylus Properties............................................................................................................................. 3-62
Double-Tap .....................................................................................................................................3-62
Calibration.......................................................................................................................................3-62
Touch ..............................................................................................................................................3-63
System Properties .......................................................................................................................... 3-63
Total Recall ..................................................................................................................................... 3-64
Creating a Backup..........................................................................................................................3-64
Creating a Clone.............................................................................................................................3-65
Table of Contents v
Managing Profiles...........................................................................................................................3-66
Viewing a Profile ................................................................................................................. 3-66
Profile Options..................................................................................................................... 3-66
Deleting a Profile ............................................................................................................................3-68
TweakIt............................................................................................................................................ 3-68
Advanced........................................................................................................................................3-69
Advanced CE Services Settings ......................................................................................... 3-69
Advanced Interface and Network Settings.......................................................................... 3-69
Advanced Services Settings ............................................................................................... 3-70
Registry Editor................................................................................................................................3-70
Voice – Using the WWAN Phone Dialer ......................................................................................... 3-70
Dialing a Number............................................................................................................................3-71
Receiving an Incoming Call............................................................................................................3-72
Voice Menu.....................................................................................................................................3-72
Call Management................................................................................................................ 3-72
Call Lists.............................................................................................................................. 3-73
Services .............................................................................................................................. 3-74
File Menu – Phonebook Management...........................................................................................3-74
Volume & Sounds Properties .......................................................................................................... 3-75
Volume Adjustments.......................................................................................................................3-76
Sound Adjustments ........................................................................................................................3-76
Wi-Fi Config .................................................................................................................................... 3-76
Wi-Fi Config: Status ......................................................................................................................3-77
Wi-Fi Config: Configure .................................................................................................................3-77
Manually Creating a Network.............................................................................................. 3-78
Authentication Mode ........................................................................................................... 3-78
Encryption ........................................................................................................................... 3-79
EAP .................................................................................................................................... 3-79
Verify Server Certificate ...................................................................................................... 3-80
Enable OPMK ..................................................................................................................... 3-80
Connecting the Wireless Network....................................................................................... 3-81
Configuring TCP/IP.........................................................................................................................3-82
IP Address........................................................................................................................... 3-82
Name Server ....................................................................................................................... 3-83
Wi-Fi Config: Advanced .................................................................................................................3-84
Monitoring the Network Connection...............................................................................................3-85
WiFi Connect A.R.C. ....................................................................................................................... 3-85
Chapter 4: Accessories
Pistol Grips...................................................................................................................................... 4-1
Removing the Trigger Cover ..........................................................................................................4-1
Attaching the Pistol Grip.................................................................................................................4-2
Carrying and Protective Accessories ............................................................................................. 4-3
The Hand Strap - Model ST6025 ...................................................................................................4-4
Protective Carrying Case - Model ST6090 ....................................................................................4-4
Hard Shell Holster - Model ST6055 ...............................................................................................4-4
Power Accessories.......................................................................................................................... 4-5
vi Omnii Hand-Held Computer with Windows CE 6.0 User Guide
Snap Modules................................................................................................................................4-5
AC Wall Adaptor - Models ST1050 and ST1050-AR .....................................................................4-7
Vehicle Power Outlet Adaptor - Model ST3113..............................................................................4-7
Chargers and Docking Stations: General Information .................................................................... 4-8
Important Charger Safety Instructions ...........................................................................................4-8
Charging the Battery.......................................................................................................................4-8
Installation — Chargers and Docking Stations ..............................................................................4-8
Operator Controls...........................................................................................................................4-9
Power Consumption Considerations..............................................................................................4-9
Desktop Docking Stations - Models ST4002 and ST4003.............................................................. 4-9
Charging a Battery Installed in the Omnii.......................................................................................4-11
Indicators ........................................................................................................................................4-11
Operation .......................................................................................................................................4-11
Charging the Omnii Battery................................................................................................. 4-11
Charging the Spare Battery ................................................................................................ 4-11
Cleaning the Desktop Docking Station...........................................................................................4-12
Troubleshooting ..............................................................................................................................4-12
Docking station does not seem to power on. ...................................................................... 4-12
The Omnii charge indicator LED stays off........................................................................... 4-12
The Omnii charge indicator LED is red. .............................................................................. 4-12
Spare battery LED is red with a battery installed. ............................................................... 4-12
Spare battery LED does not turn on when a battery is installed. ........................................ 4-12
Quad Docking Station – Model No. ST4004................................................................................... 4-13
Operator Controls...........................................................................................................................4-14
Indicators ........................................................................................................................................4-14
Quad Docking Station Operation ...................................................................................................4-14
Charging the Omnii Battery................................................................................................. 4-14
Installation........................................................................................................................... 4-15
Connecting to the Ethernet Network ................................................................................... 4-15
Cleaning the ST4004......................................................................................................................4-16
Troubleshooting ..............................................................................................................................4-16
The Omnii Charge Indicator LED Stays Off ........................................................................ 4-16
Power LED Does Not Light Up ........................................................................................... 4-16
The Omnii Charge LED Flashes Yellow .............................................................................. 4-16
The Omnii Charge Indicator LED is Red............................................................................. 4-16
Powered Adaptor LED Stays Off......................................................................................... 4-16
Vehicle Cradles - Models ST1000 and ST1002 ............................................................................ 4-16
Vehicle Cradle Mounting Recommendations................................................................................4-17
Insertion and Removal of Omnii.....................................................................................................4-19
Maintaining the Vehicle Cradle.......................................................................................................4-20
ST1002 Powered Cradle Installation..............................................................................................4-20
Wiring Guidelines................................................................................................................ 4-20
Installation in High Voltage Vehicles ................................................................................... 4-21
Wiring Vehicle Power and Communications to the Cradle.................................................. 4-21
Battery Charger (6-Slot) - Model ST3006 ....................................................................................... 4-22
Installation.......................................................................................................................................4-23
Operator Controls...........................................................................................................................4-24
Table of Contents vii
Charge Indicators ...........................................................................................................................4-24
Charging Batteries..........................................................................................................................4-24
Troubleshooting..............................................................................................................................4-24
Improper Battery Storage.................................................................................................... 4-24
Power Self-test LEDs Don’t Light Up .................................................................................. 4-25
Indicator Does Not Light When Battery Installed ................................................................ 4-25
Appendices
Appendix A: Port Pinouts
Omnii Docking Connector............................................................................................................... A-1
Snap Modules Connectors.............................................................................................................. A-2
Cable Connectors for Vehicle Cradle Model ST1002 ..................................................................... A-3
Omnii Battery Contacts................................................................................................................... A-4
Appendix B: Imager & Camera Settings
Introduction ..................................................................................................................................... B-1
Required Applets............................................................................................................................. B-1
Presets ........................................................................................................................................... B-1
Predefined Presets ................................................................................................................... B-2
Barcode Predefined Presets (Barcoding Menu) ....................................................................... B-2
Barcode Decoding Symbology Predefined Presets ............................................................ B-2
Barcode Decoding Camera Predefined Presets ................................................................. B-3
Image Capture Predefined Presets (Imaging Menu) ................................................................ B-3
Using the Imagers Applet................................................................................................................ B-3
Configuring the Image Capture Presets (Imaging Menu) ......................................................... B-3
Selecting a Camera............................................................................................................. B-4
Setting the Active Preset ..................................................................................................... B-4
Viewing a Preset ................................................................................................................. B-4
Creating a Custom Preset................................................................................................... B-5
Modifying a Custom Preset................................................................................................. B-5
Removing a Custom Preset ................................................................................................ B-6
Configuring the Barcode Decoding Camera Presets (Barcoding Menu) .................................. B-6
Selecting a Camera............................................................................................................. B-7
Setting the Active Preset ..................................................................................................... B-7
Viewing a Preset ................................................................................................................. B-7
Creating a Custom Preset................................................................................................... B-7
Modifying a Custom Preset................................................................................................. B-8
Removing a Custom Preset ................................................................................................ B-8
Configuring the Barcode Decoding Symbologies (Barcoding Menu)........................................ B-9
Setting the Active Preset ..................................................................................................... B-9
Viewing a Preset ................................................................................................................. B-9
Creating a Custom Preset................................................................................................... B-10
Modifying a Custom Preset................................................................................................. B-10
Removing a Custom Preset ................................................................................................ B-11
Barcoding Menu – Configuring Symbologies............................................................................ B-11
Symbology Settings ............................................................................................................ B-11
Filter Menu – Manipulating Barcode Data................................................................................. B-12
viii Omnii Hand-Held Computer with Windows CE 6.0 User Guide
Modifying a Barcode Setting ............................................................................................... B-12
Translation Menu – Configuring Rules...................................................................................... B-13
Advanced Menu........................................................................................................................ B-13
File Locations for Captured Images .................................................................................... B-13
Configuring Triggers............................................................................................................ B-14
Barcode Symbologies..................................................................................................................... B-15
Imager Barcode Symbologies................................................................................................... B-16
Color Camera Barcode Symbologies........................................................................................ B-17
Appendix C: Scanner Settings
Barcode Settings ............................................................................................................................ C-1
Scanner Options ....................................................................................................................... C-1
Restoring Default Settings ........................................................................................................ C-2
Decoded (Internal) Scanners.......................................................................................................... C-3
Options...................................................................................................................................... C-3
Decoded (Internal) Advanced Options...................................................................................... C-4
Decoded (Internal) Data Options .............................................................................................. C-5
Decoded (HHP) .............................................................................................................................. C-6
Decoded (Intermec ISCP)............................................................................................................... C-6
Decoded (ISCP) Options .......................................................................................................... C-7
Decoded (ISCP) Advanced Options.......................................................................................... C-7
Non-Decoded Scanners ................................................................................................................. C-8
Options...................................................................................................................................... C-9
Appendix D: Internal Imager & Scanner Specifications
SE955 Scanner............................................................................................................................... D-1
SE955 Decode Zones............................................................................................................... D-2
SE965 Scanner............................................................................................................................... D-2
SE965 Decode Zones............................................................................................................... D-3
SE1224HP - High Performance Scanner........................................................................................ D-4
SE1224HP Decode Zones........................................................................................................ D-4
SE1524ER – Extended Range Scanner......................................................................................... D-5
SE1524ER Decode Zones........................................................................................................ D-5
SE1524ER Decode Zone A (Short Range, Small Codes)................................................... D-5
SE1524ER Decode Zone B (Long Range, Large Codes)................................................... D-6
EV15 Imager................................................................................................................................... D-6
EV15 Imager Decode Zone ...................................................................................................... D-6
EA11 Decoded 2D Imager .............................................................................................................. D-7
EA11 Typical Reading Distances .............................................................................................. D-7
EA20X Imager ................................................................................................................................ D-8
EA20X Typical Reading Distances ........................................................................................... D-9
HHP 5080SR Imager/Decoder........................................................................................................ D-9
HHP 5080SR Working Range................................................................................................... D-10
SE4500SR – Standard Range Imager............................................................................................ D-10
SE4500SR Decode Zone.......................................................................................................... D-12
SE4600LR – Long Range Imager................................................................................................... D-13
SE4600LR Decode Zones ........................................................................................................ D-15
Table of Contents ix
Appendix E: Omnii Specifications
The Omnii Hand-Held Computer (Model 7545) .............................................................................. E-1
Hardware .................................................................................................................................. E-1
Regulatory Approvals................................................................................................................ E-3
Lithium-ion Smart Battery 5000 mAh (ST3003).............................................................................. E-4
Wireless Radios.............................................................................................................................. E-5
Cinterion MC75i GSM/GPRS/EDGE Radio .............................................................................. E-5
Cinterion PH8-P GSM/GPRS/EDGE/UMTS/HSPA+ Radio ...................................................... E-6
Model RA2070 802.11a/b/g/n Radio ......................................................................................... E-8
Bluetooth Radio ....................................................................................................................... E-10
RA1202 Narrowband Radio ...................................................................................................... E-10
Appendix F: Omnii XT15f Freezer Variants
The Omnii XT15f Hand-Held Computer (Model 7545XT)............................................................... F-1
Hardware Specifications ........................................................................................................... F-2
Regulatory Approvals................................................................................................................ F-4
The Freezer Keyboards ............................................................................................................ F-4
Lithium-ion Smart Battery 5000 mAh (ST3003) for Omnii Chiller Model ........................................ F-5
Lithium-ion Smart Battery 5300 mAh (ST3002) for Omnii Arctic Model.......................................... F-5
Quick Defrost Application................................................................................................................ F-6
Settings ..................................................................................................................................... F-7
Heater Info ................................................................................................................................ F-8
Appendix G: Wireless Wide Area Network (WWAN) Settings
Wireless WAN................................................................................................................................. G-1
Taskbar Icons............................................................................................................................ G-1
Establishing a Packet Data Connection.................................................................................... G-2
Disconnecting From a Network........................................................................................... G-3
Shutting Down the Wireless WAN User Interface ............................................................... G-3
Advanced Information ............................................................................................................... G-4
Entering a PIN Number....................................................................................................... G-4
Error States ......................................................................................................................... G-4
Tools Menu................................................................................................................................ G-5
WWAN Data Configuration ................................................................................................. G-5
Security Configuration......................................................................................................... G-8
Network Configuration......................................................................................................... G-9
Driver Mode Configuration ................................................................................................. G-10
Modem Information ............................................................................................................. G-11
User Interface...................................................................................................................... G-12
AT Terminal ......................................................................................................................... G-13
SMS Menu ............................................................................................................................... G-13
New ..................................................................................................................................... G-13
Inbox ................................................................................................................................... G-13
Outbox................................................................................................................................. G-14
SMS Configuration.............................................................................................................. G-14
Voice ......................................................................................................................................... G-14
Power Mode.................................................................................................................................... G-14
Table of Contents x
Appendix H: Wireless Zero Config Settings
Wireless Information ....................................................................................................................... H-1
Wireless Statistics .................................................................................................................... H-2
Wireless Information ................................................................................................................ H-2
Assigning An IP Address................................................................................................................. H-5
Name Server............................................................................................................................. H-5
Advanced Features......................................................................................................................... H-5
Rearranging Preferred Networks .............................................................................................. H-5
Deleting A Preferred Network.................................................................................................... H-5
Changing Network Properties ................................................................................................... H-6
Appendix I: Omnii XT15ni Non-Incendive Safety Guidelines
Omnii XT15ni (non-incendive) Important Safety & Regulatory Information .................................... I-1
Omnii XT15ni Battery Information................................................................................................... I-2
Appendix J: Narrowband Radio Configuration
Narrowband Radio Setup................................................................................................................ J-1
Basic Tab ........................................................................................................................................ J-2
Channels Tab .................................................................................................................................. J-3
Advanced Tab ................................................................................................................................. J-6
Tune Poll Settings........................................................................................................................... J-6
Statistics Screen ............................................................................................................................. J-6
Index .. . .... . ... . . ... . .... . ... . . ... . .... . .... . ... . .... . .... . ... . .... . .... . ... . .... . .... . ... . . ... . .... . ... . . ... . ..I
ABOUT THIS GUIDE
ABOUT THIS GUIDE
About This Guide
This guide applies to the following models:
• 7545MBW
• 7545MBWP
• 7545MBWPT
• 7545MBWT
• 7545MBWN
• FCC ID: GM37545MBW, GM37545MBWM and GM37545MBWP
• IC: 2739D-7545MBW and 2739D-7545MBWP
This user guide describes the configuration, operation, and maintenance of the Omnii Hand-Held Computer.
Chapter 1: Basic Operation. describes the steps required to get the Omnii ready for operation.
Chapter 2: Getting To Know Your Omnii. describes Omnii features, including how to charge and maintain
the battery, the keyboard features, the display, using the internal scanner, etc. This chapter also
describes the Microsoft
ance and actions of the desktop from Windows Classic Shell to the Kiosk Shell.
Chapter 3: Configuration. describes the programs and applications accessed through two main areas from
the Desktop Start Menu: Programs and Settings>Control Panel. The software includes both Zebra
Software Advantage and Microsoft programs, and details how to use them to configure the Omnii,
along with scanners/imagers, Bluetooth, etc. This chapter also details the Kiosk program, which
enables you to customize your computer settings.
Chapter 4: Accessories. describes the peripherals and accessories available for your Omnii computer.
Appendix A: Port Pinouts. describes the Omnii and accessories pinouts.
Appendix B: Imager & Camera Settings. describes in detail your imager’s settings.
Appendix C: Scanner Settings. details your barcode options.
®
Windows
®
Embedded CE 6.0 desktop, and how to change the appear-
xii Omnii Hand-Held Computer with Windows CE 6.0 User Manual
Appendix D: Internal Imager & Scanner Specifications. lists the specifications for the Omnii scanners and
imagers.
Appendix E: Omnii Specifications. lists the specifications for your Omnii computer, radios, and battery.
Appendix F: Omnii XT15f Freezer Variants. describes the hardware and heating software of the freezer
units.
Appendix G: Wireless Wide Area Network (WWAN) Settings. describes WWAN configuration information.
Appendix H: Wireless Zero Config Settings. outlines the steps used to configure your radio using Windows
Zero Config.
Appendix I: Omnii XT15ni Non-Incendive Safety Guidelines. lists the approvals, important warnings, and
cautions for the Omnii XT15ni (non-incendive) Hand-held Computer.
Appendix J: Narrowband Radio Configuration. describes setting up the RA1202 Narrowband radio.
Text Conventions
NOTE Notes highlight additional helpful information.
IMPORTANT These statements provide particularly important instructions or addi-
tional information that is critical to the operation of the equipment.
WARNING! These statements provide critical information that may prevent
physical injury, equipment damage or data loss.
Overview of the Omnii Hand-Held Computer
The Omnii Hand-Held Computer is a modular, industrial hand-held computer. A variety of options are available
to suit applications in courier/delivery, field service, manufacturing facilities, material handling applications in
warehouses, ports and yards, with a focus on real time wireless data transactions. Barcode input methodologies are supported by a variety of available scanners. Optimization for specific operational environments is
also supported with a wide range of peripheral options and carrying accessories.
The Omnii XT15f (Freezer Variant) combines modularity, customizability and performance with added technology to resist condensation for use in cold, condensing environments. For details, see Appendix F: Omnii
XT15f Freezer Variants.
NOTE The Omnii Hand-Held Computer is a body worn device, and to maintain compliance
with the FCC RF exposure guidelines, use a Zebra approved carrying case. Use of
non-approved accessories may violate FCC RF exposure guidelines.
NOTE For product specifications, refer to Appendix E: Omnii Specifications.
About This Guide xiii
Model Variants
• Omnii RT15 Hand-Held Computer (rugged) - Model 7545XC
• Omnii XT15 Hand-Held Computer (extremely rugged) - Model 7545XA
• Omnii XT15f (Freezer Variant) Hand-Held Computer (extremely rugged) - Model 7545XT
Processor and Memory
®
• Texas Instruments
• Flash ROM: 1 GB
• RAM: 512 MB
• 3 axis accelerometer
Operating System
®
• Microsoft
Windows® Embedded CE 6.0
Bundled Applications
• Internet Explorer
• Windows Mobile Device Center
®
• WordPad
, ActiveSync®
Sitara AM37xx, ARM Processor 800 MHz (OMAP3® compatible)
®
6
Supported Applications*
• TekTerm Client - Terminal Emulation
• Wavelink TN - Terminal Emulation
* Note that Tekterm Client is the only application available when a Narrowband radio is installed in the unit.
Device Management and Utilities
• Kiosk
• Total Recall, TweakIt, Dr. Debug – Utilities
• SOTI MobileControl – Mobile Device Management
- Easy configuration management and provisioning platform.
- Powerful remote control and troubleshooting functionality.
- Integrated real time geofencing and location services.
- Advanced device security, user authentication and lockdown features.
User Interface
• Colour/Touch Display 9.4 cm (3.7 in) diagonal
- VGA (640 x 480) Transflective
- High visibility option: superior sunlight visibility with 165 cd/m2 brightness
- Extreme Duty option: withstands 1.25 Joule impact, superior low temperature operation (to -20° C/-4° F),
with 160 cd/m2 brightness. Better abrasion resistance.
• Touchscreen
- Passive stylus or finger operation; pan and flick gestures supported
- Signature capture
• Keyboards
xiv Omnii Hand-Held Computer with Windows CE 6.0 User Manual
- Large selection of backlit keypads in both alpha and numeric formats. For a list of currently
available keyboard configurations, consult your Zebra representative, or go to:
http://www.zebra.com/US-EN/Product+Lines/Psion/?WT.mc_id=psion_us_p_handheld
• Voice, Audio & Feedback
- High volume beeper: 95 dBA
- Integrated microphone and speaker
- Optional Push-to-Talk Speaker
• Walkie-talkie style Push-to-Talk – VoIP over WiFi or WWAN
• Vibration feedback
Wireless Connectivity
• Integrated Bluetooth® V2.0 + EDR
• Integrated 802.11a/b/g/n WiFi
• Bluetooth® coexistence
• CCX v4
• Optional SIRF III GPS Receiver
• Optional GPS/GPRS/EDGE WWAN radio
• Optional GPS/GPRS/EDGE with UMTS/HSPA+ WWAN radio
• Optional RA1202 Narrowband radio
NOTE 802.11b/g and Bluetooth are available simultaneously.
The following figures illustrate the main features of the Omnii — for detailed views, please see Omnii Features
on page 1-1.
About This Guide xv
Figure 1
Omnii XT15 and RT15 Alphanumeric Variants
Omnii XT15
59-Key ABC Keyboard
Omnii RT15
55-Key ABC Keyboard
Figure 2
Omnii XT15f Freezer Variants
Alphanumeric Numeric
xvi Omnii Hand-Held Computer with Windows CE 6.0 User Manual
Figure 3
Figure 4
Bottom View (Docking Connector)
Top View (Scanner Window)
Laser Aperture
Regulatory Labels
Figure 5
WARNING! Using controls or adjustments or performing procedures other than
Figure 6
Laser Warning Label
those specified herein may result in hazardous radiation exposure.
SE955 Laser Warning Label
This label is affixed below the scanner window.
About This Guide xvii
Figure 7
Figure 8
Figure 9
SE965 and SE4500 Laser Warning Label
LED Radiation Notice Label
SE4600 Laser Warning Label
This label is affixed below the scanner window.
CHAPTER 1BASIC OPERATION
BASIC OPERATION 1
Omnii Features
Figure 1-1
Front View of the Omnii XT15 Model with Alphanumeric Keyboard
Speaker
LEDs
Scan Key
Microphone
SYM Key
Beeper
FN Modifier Key
Enter/Power Key
Display
NOTE The Omnii 55- and 66-key keyboards are equipped with a Power button as
shown in Figure 1-1 Front View of the Omnii XT15 Model with Alphanumeric
Keyboard on page 1-1.
1 - 2 Omnii Hand-Held Computer with Windows CE 6.0 User Guide
Figure 1-2
Side Views of the Omnii XT15
Right Side
Vertical
scroll button
Enter button
Battery release button
Side rail
Slot for Snap Module arm
Left Side
Volume
rocker button
Scan button
Figure 1-3
Bottom View
2
1 - Docking Connector
2 - Alignment Pin Holes
3 - M2.5 Locking Screws
(for firmly attaching devices)
4 - Hand Strap Slot
1
2
3
4
3
Basic Operation 1 - 3
Figure 1-4
Figure 1-5
Top View
Back View
Rear PTT Speaker
(optional)
Scanner Pod
Laser
Aperture
End-Cap
Camera Aperture
Scanner Window
Expansion Back
Omnii Modules Available
To see a current list of Omnii accessories and modules, please go to the website at:
http://www.motorlolasolutions.com/US-EN/Product+Lines/Psion/?WT.mc_id=psion_us_p_handheld
Documents Available
Pistol Grip
Attachment Screws (4)
Battery Pack
To see a current list of documents and download what you need, please go to the Knowledge Base on the
IngenuityWorking community website:
http://www.ingenuityworking.com/knowledge/w/knowledgebase/product-manuals.aspx
1 - 4 Omnii Hand-Held Computer with Windows CE 6.0 User Guide
Preparing the Omnii for Operation
The Battery
The Omnii is powered by a Lithium-ion Smart Battery pack, 5000 mAh — Model ST3003.
IMPORTANT Before charging the battery, it is critical that you review the battery safety guidelines in
the Omnii Hand-Held Computer Regulatory & Warranty Guide (PN 8000191).
Battery packs shipped from the factory are charged to approximately 40% and must be fully charged prior to
use. Batteries can be charged using a variety of chargers and docking stations. For detailed information, see
Battery Details on page 2-1.
Replacing the Battery Pack
IMPORTANT Always switch the unit off before changing the battery (see Switching the Omnii On and
Off on page 1-5). However, assuming the default power saving parameters and battery
reserve level have not been altered, battery swap time is a minimum of 4 minutes — you
will not lose data if the battery is replaced within this time frame.
Figure 1-6
Omnii Battery
1 - Release button
2 - Battery compartment
3 - Guide tabs
4 - Release button tabs
Battery Top
2
1
Contacts
1
3
3
4
4
Battery bottom
3
NOTE If you are using a docking station or an external power supply, you can insert an uncharged bat-
tery and use the device while the battery charges.
Assuming the default power saving parameters and battery reserve level have not been altered, a battery can
be removed for up to 4 minutes without losing data. After 4 minutes the terminal may reboot.
Removing the Battery Pack
• If your unit is equipped with a hand strap, unhook it from the base of the battery.
• Press the two buttons at the sides of the compartment simultaneously, and slide the battery out.
Installing the Battery Pack
• Slide the charged battery with the contoured plastic facing you into the unit with the contacts matching
position and the guide tabs moving into the corresponding slots at the base of the compartment. Click both
sides of the battery into place.
• If your computer is equipped with a hand strap, re-attach the clip to the slot at the base of the battery.
• Switch the unit on (see Switching the Omnii On and Off on page 1-5).
Switching the Omnii On and Off
Follow the instructions below for your Omnii. If your keyboard has a power button (55- and 66-key keyboards
only), press that instead of the [FN]+[Enter/Power] key combinations described.
Switching the Omnii On
• Press and hold down the [Enter/Power] key for at least one second.
When the unit is turned off, normally it automatically enters a power-saving, “suspend” state. When the Omnii
is switched on from the suspend state, within a few seconds operation resumes in the screen in which you
were working prior to turning the computer off.
IMPORTANT If your Omnii fails to power up, consider the following troubleshooting options:
The battery may be overheated (>60C°), a non-Zebra battery may be installed, or the
battery may have fallen below the configured Suspend Threshold. See Suspend Thresh-
old and Estimated Battery Backup on page 3-41 for details.
Basic Operation 1 - 5
To switch on the hand-held, you will need to replace the overheated battery.
However, if you supply AC power to the Omnii with a battery that falls below the
configured Suspend Threshold, the unit will
Switching the Omnii Off
• To switch off the Omnii, press the [FN] key and then press and release the [Enter/Power] button. The
Omnii will automatically enter the Suspend state.
IMPORTANT Turning off the hand-held does not result in a complete shutdown; rather, the unit enters
a power-saving, “suspend” state. When the Omnii is turned on from suspend state, operation resumes within a few seconds.
IMPORTANT If the word ‘FN’ is displayed underlined in the taskbar area at the bottom of the screen,
this key is locked “on” and the Omnii will not switch off. Press the [FN] key twice followed
by [Enter/Power] to switch the Omnii off.
However, if you’ve set the mode to “Lock” (see Keyboard One Shot Modes on page 3-30),
the Omnii can be turned off even when the [FN] key is locked ‘on’.
Resetting the Omnii
switch on.
To perform a warm or cold reset, you can access the menu by going to Start>Shutdown. Alternatively you can
use the keyboard shortcuts described below.
NOTE If your Desktop is switched to the Kiosk Shell (refer to The Kiosk Desktop Shell on page 2-25),
resetting the unit is done solely by use of the keyboard shortcuts.
1 - 6 Omnii Hand-Held Computer with Windows CE 6.0 User Guide
Performing a Warm Reset
During a warm reset, running programs are halted. The contents of the file system, RAM Disk, Flash Disk, and
the registry are preserved.
• Press and hold down the [FN] key and the [Enter/Power] key simultaneously for a minimum of
four seconds.
NOTE You need to reset your Omnii after configuring the radio by switching between Windows Zero
Config and WiFi Config.
Performing a Cold Reset
A cold reset reinitializes all hardware. All RAM including the RAM Disk is erased. Non-volatile storage such as
the Flash Disk is preserved, as is the file system.
To execute a cold reset:
• Press and hold down the [SYM] key, the [FN] key, and the [Enter/Power] key, simultaneously for a
minimum of four seconds.
NOTE As part of the normal Windows Embedded CE cold boot process, the screen may go blank for a
few seconds after the splash screen loading bar reaches the end. The desktop is displayed after
a few moments.
Performing a Clean Start
A clean start returns the Omnii to factory settings, flushes the registry keys, and deletes volatile storage and
the file system. The Flash Disk is preserved.
• Press and hold down the [FN] key, the [Enter/Power] button and the [SCAN] key simultaneously for a
minimum of six seconds.
The Omnii displays the Boot to BooSt menu.
• On an alpha keyboard, type .clean.
• On a numeric keyboard, type .25326.
Boot to BooSt
If you choose Boot to BooSt, the BooSt menu is loaded.
• Press and hold down the [FN] key, the [Enter/Power] button and the [SCAN] key for a minimum of four
seconds.
Loading...
