Zanussi VC19M User Manual
Specifications and Main Features
- Dimensions:
- Width: 900 mm
- Depth: 598 mm
- Height: 597 mm
- Oven Volume: 538 dm³
- Cooking Programmer: DIEHL 12 h
- Induction Hob Elements:
- Front Left: 180 mm diameter with 1700 W of power
- Rear Left side 145 mm in diameter and 1200 W
- Rear Right 180~ mm in diameter and 1700 W
- Front Right Hand Side 145 mm in diameter and 1200 W
- Inserted Power Maximum: 5.8 kW
- Oven Heating Elements:
- Oven Heating Element: 2.5 kW
- Grill Blender Removable: 2.0 kW
- Food-Storing Heating Element: 300 W
- Oven Light: 15 W
- Oven fan: 35 W
- Oven Power Maximum in KWh: 2.850 kWh
- Voltage Rating: 240 volts 50 hertz
- Total Power: 8.650 kilo watts
- Residual Heating Light: Yes
- Thermo Survivor: Yes
Frequently Asked Questions
Q: What should be done if the oven will not start?
Answer: This will mean that the ”Make ready” function should be checked whether it is engaged. Ensure that it is on the mains connected and its input switch is on, and the fuse is blown.
Q: Are there any food combinations that are banned from being cooked in the oven also?
A: Repulsive as it may sound, yes, so long as the dishes are cooked at equal temperatures, there is no chance of flavor mutation and hence different types of food can be cooked together inside the oven.
Q: What is the recommended way to clean a ceramic hob?
A: Lacquer-necked scrapers could be used in case there are persistent deposits. But such deposits could be warmed up gently and scraped off with a wooden scraper. But a wooden scraper must only be used on a ceramic cooktop as a last resort. Normal Products and damp cloth could be used for cleaning the cooktop.
Q: Is it safe to cook food in an oven without supervision if I use automatic settings?
A: Yes as long as the programmer has been correctly set to start and shut down the oven on intended times, unspecified food can be cooked automatically in the oven.
Q: Should I be concerned if the ceramic hob suffers a crack while in use?
A: A crack is a sign of permanent damage to the ceramic hob, thus, if it does crack while in use, you shouldn’t use the ceramic hob and reach out for a service center instead.
