Lave-vaisselle ZKS 5634
Afwasautomaat
Geschirrspüler
Dishwasher
Notice d’utilisation (partie 2) 2
Gebruiksaanwijzing (deel 2) 8
Bedienungsanleitung (Teil 2) 14
Instruction book (part 2) 20
20
The control panel
1. On/Off push button
2. Programme guide
3. Door handle
4. Programme marker
5. Programme selector dial
6. Programme sequence indicator
As the programme progresses, the programme
selector dial turns, to show the phase in the wash
programme the appliance has reached.
Prewash / Rinse and Hold
Wash
Cold rinse
Hot rinse
Drying
Description of the appliance
1. Water hardness adjustment
2. Levelling spacers
3. Upper basket stop
4. Salt container
5. Lower spray arm
6. Detergent dispenser
7. Control panel
8. Rating plate
9. Rinse aid dispenser
10. Large filter
11. Central filter
12. Upper spray arm
13. Upper basket
1
2
3
13
12
4
5
6
IN85
11
10
9
8
7
21
Washing programmes
Programme Degree of soil
and
type of load
Required
push buttons
Recommended
quantity of detergent
wash
prewash
Starting position
of the
programme
selector
Normal soil.
Crockery and cutlery
Light soil.
Crockery and cutlery
Light soil.
Crockery and party
crockery
Any.
Partial load (to be
completed later in
the day).
Cycle description
Main wash up to 65°C
1 cold rinse
1 hot rinse
Drying
Cold prewash
Main wash up to 65°C
1 cold rinse
1 hot rinse
Drying
Main wash up to 65°C
1 cold rinse
1 hot rinse
1 cold rinse
(to avoid food scraps
from sticking together).
*
Testing programme for EN 50242. (see "Hints for test centres").
**
This is a speciaal programme for quick washing a full load of lightly soiled dishes, glasses and crockery (except pots) so
that you may re-use promptly.
On/Off
On/Off
On/Off
On/Off
25 g 5 g
30 g /
30 g /
//
A
B
C
D
*
Normal 65°C
with prewash
**
Quick wash
65°C
Normal 65°C
no prewash
Rinse and Hold
22
1. Check the filters
Ensure that they are clean and properly positioned.
(See "Maintenance and cleaning" - Instruction
book - Part 1)
2. Check that there is rinse aid and
salt
(See Instruction book - Part 1)
3. Load the dishes
Remove any scraps of food.
Pull the lower basket out and arrange the
saucepans, plates and cutlery in it.
Pull the upper basket out and arrange the plates,
saucers, glasses and cups etc. in it.
Slide the baskets back into the machine.
4. Ensure that the spray arms can
rotate freely
5. Measure out detergent
Add the detergent into the dispenser according to
the dosage quantity given in the "Washing
programmes" chart.
Close the detergent dispenser lid.
6. Close the dishwasher door
7. Set the programme
Turn the programme selector dial clockwise until
the letter of the programme you wish to select
corresponds with the programme marker on the
control panel.
8. Start the programme
Depress the On/Off push button.
The On/Off indicator light will come on and the
machine will start.
If you wish to interrupt the washing programme at
any time press this button again.
9. At the end of the washing
programme
At the end of the programme the dishwasher will
automatically stop.
The On/Off indicator light remains on until the On/Off
push button is depressed.
10. Switch off the dishwasher
Switch off the dishwasher by pressing the On/Off
push button.
Wait 15/20 minutes before opening the
dishwasher’s door; in this way you will avoid
burning yourself when removing the dishes and
avoid also the damage of the nearby furniture
caused by the escape of steam.
Empty the lower basket first and then the upper one;
this will avoid water dripping from the upper basket
onto the dishes in the lower one.
When the washing programme has finished, it
is recommended that the dishwasher is
unplugged and the water tap turned off.
In general it is not advisable to open the door
while the machine is working; if the door is
opened however, a safety device ensures that
the machine stops.
Important!
Care must be taken if the door is opened during
the hot phase or immediately after a
programme has finished, as steam may escape.
Operating sequence
23
Loading your appliance
Before placing dishes in the machine, remove any scraps of
food, to avoid clogging the filters and consequently reducing
the performance.
Do not load very small items which can fall
through the baskets.
The lower basket
The lower basket is designed to take saucepans, lids,
plates, salad bowls, cutlery etc.
Large dishes and lids should be arranged around the edge
of the basket, ensuring that the upper spray arm can turn
freely.
The cutlery basket
Long bladed knives stored in an upright position
are a potential hazard.
Long and/or sharp items of cutlery such as
carving knives must be positioned horizontally in
the upper basket.
Take care when loading or unloading sharp items
such as knives.
Cutlery should be placed in the removable cutlery basket
with the handles facing downwards.
If the handles protrude from the bottom of the basket,
obstructing the lower spray arm, load the cutlery with the
handles facing upwards.
Mix spoons with other cutlery to prevent them from sticking
together.
Silver cutlery tends to go black if mixed with steel cutlery.
Place it in the cutlery basket separate from the others.
Arrange spoons, dessert spoons, teaspoons, knives and
other small cutlery in the racks on both sides of the cutlery
basket.
Using your appliance
UI49
UI19
UI03
24
The upper basket
The upper basket is designed for plates (dessert plates,
saucers, dinner plates of up to 25 cm in diameter), salad
bowls, cups and glasses.
Arrange items so that water can reach all surfaces.
Light items (plastic bowls etc.) should be loaded in the upper
basket and arranged so they do not move.
In case that plates are loaded in the upper
basket:
load them starting from the rear positions of the basket;
tilting them slightly forwards and avoiding the front positions
near the door.
Before closing the door, ensure that the spray
arms can rotate freely.
After loading your machine always close the
door, as an open door can be a hazard.
US64
US71
Before starting any test it is necessary to fill completely with salt the salt container and with rinse aid the rinse aid
dispenser.
Hints for test centres
Test standard: EN 50242
Reference programme: Normal 65°C with prewash
Load: 12 standard place settings
Rinse aid selector: position 5
Detergent dosage: 25 g in the dispenser
5 g on the dispenser lid
25
Dimensions Width 59.6 cm
Height 81.8 - 87.8 cm
Max depth 57.5 cm
Max depth with open door 111.4 cm
Electrical connection Voltage 230 V - 50 Hz
Motor rating during wash 200 W
Power of heating element 2100 W
Overall power 2300 W
Water supply pressure Minimum 50 kPa (0.5 bar)
Maximum 800 kPa (8 bar)
Water supply connection Water cold/hot max. 60°C
Capacity 12 place settings
Technical specifications
Arrangement upper basket
Arrangement lower basket
Arrangement cutlery basket
D GBNLF
152976 83/1
1 09/01
