Owner’s Manual
YBR-AC-120 Cycle
Item #53084
www.yorkfitness.com
2
Congratulations on
purchasing your exercise
equipment from
You have chosen a high quality, safe and innovative piece
of equipment as your training partner and we are certain
it will keep you motivated on the way to achieving your
personal tness goals.
Please take the time to read this owner’s manual
as it will help you to get the most out of your new
exercise equipment.
For more information visit www.yorktness.com
CONTENTS
Safety information 03
Customer support 04
Assembly instructions 05
Operational instructions 10
Troubleshooting 13
Fitness guide 14
Exploded Drawing 16
Part List 18
Protect the environment by not disposing
of this product or batteries with household
waste. Check your local authority for
recycling advice and facilities.
Table of Contents
www.yorkfitness.comwww.yorkfitness.com
3
Please read this instruction manual before you begin
assembly. Great care has been taken to design these
instructions and following them will help you with quicker
assembly and minimize the risk of injury.
It is important to keep these instructions for future reference.
This list is not exhaustive - You are responsible for your safety!
• Assemble and operate the equipment on a level surface.
• Ensure the equipment is stable before use.
• Always ensure that the equipment has adequate space
on each side.
• Ensure that the seat height is adjusted correctly. You
should be stable and balanced while on the saddle.
• Adjust the seat height to ensure that you have a good
downward pedal stroke without overstretching, don’t
compromise your balance.
• Try to ensure that your back is straight while exercising,
especially for long periods.
• The safety level of this equipment can only be maintained
if it is regularly examined for wear and tear.
• Replace defective components immediately and keep
the equipment out of use until it is repaired.
• Use only the adjustment setting as described in the
instructions. Always use the correct adjustment pin/xing.
• Always check that any pins / xings are tight and secure
before use and after adjustment.
• Never leave any adjustment devices projecting from the
equipment at any time.
• Always consult your doctor before undertaking any
exercise program.
• Always wear suitable clothing and footwear. (e.g.
tracksuit / shorts / training shoes)
• Remove all personal jewelry before exercising.
• Ensure you warm-up well before using the equipment
as this will help to prevent muscle strain.
• After eating, allow 1-2 hours before exercising as this
will help to prevent muscle strain.
• Never overload the equipment. (See maximum user weight)
• Never use the equipment in any other manner other
than the ways explained in these instructions and any
wall-chart supplied.
• Injuries to health may result from incorrect form /
technique or excessive training.
• Parents and others in charge of children should be
aware of their responsibility, because the natural play
instinct and the fondness of experimenting of children
can lead to situations and behavior for which the
training equipment is not intended.
• If children are allowed to use the equipment, their
mental and physical development and above all their
temperament should be taken into account. They
should be controlled and instructed in the correct use
of the equipment.
• The equipment is under no circumstances suitable as a
children’s toy.
• Children should not be allowed on or around the
equipment, especially when it is not in use.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
• This product is not suitable for therapeutic purposes.
• This product has an integrated speed independent
braking system without a constant power mode that is
governed by magnetic resistance.
• This product has been tested for use in a home
environment and is warranted for In Home, personal,
family or household use.
• Due to our continuous policy of product development,
York Fitness reserves the right to change specications
without notice.
CAUTION! The instructions must be followed carefully in
the assembly, use and maintenance of your equipment.
The warranty does not cover damage due to negligence of
the assembly, adjustment and maintenance instructions
described herein.
Maximum user weight: 110kg
Safety Standards
This equipment meets the requirements of the EU’s EMC and
Low Voltage directives (where applicable), EN957 1 & 5 - CLASS
HC. Therefore the equipment carries the following marks:
Safety Information
www.yorkfitness.com
4
Should you require any assistance regarding this product
please gather the following information and then contact us
using the details below:
• Serial No. - This can be found on the sticker below, located as indicated.
• Original purchase date
• Place of purchase
• Information about the place and conditions of use
• Precise description of the issue / defect
Use only on a level surface
Not suitable for therapeutic purpose
Manufacturer: YORK BARBELL
Contact: York Way, Daventry, England, NN11 4YB
Product Name: YBR-AC-120 CYCLE
Max User Weight: 110KG
Safety Standards: EN957 Part 1 & 5 - Class HC
Electrical Info: 9V / 500mA
SERIAL NO:
53084-
Underside of the
main body.
Product’s Name
Serial Number
This product label is an example only, it is not the
real product name and serial number of the item
you have bought.
IMPORTANT!! - Please retain your sales receipt, York Fitness Customer Care may request proof of
purchase to validate eligibility for warranty service. Warranty cover starts from the date shown on the
proof of purchase.
ENGLAND
The best way to contact us is via the website:
www.yorktness.com
York Barbell UK Ltd.
York Way, Daventry,
England, NN11 4YB
Tel: 0844 225 3112
AUSTRALIA
The best way to contact us is via the website:
www.yorktness.com.au
York Fitness Australia
1/2 Swaham Rd, Minto,
PO Box 5130, NSW 2566
Tel: 1800 730 149
Customer Support
www.yorkfitness.comwww.yorkfitness.com
5
Care & Maintenance
• This equipment should not be placed outdoors, in a garage or an outbuilding. Keep the equipment in a dry place
with as little temperature variation as possible.
• We recommend placing a mat beneath the equipment to protect both the equipment and your ooring.
• Always place the equipment in a dry environment.
• Use a warm, damp cloth to keep the product clean.
• No wet cleaning of electrical components. Unplug before any care and maintenance.
• The safety level of the equipment can be maintained only if it is regularly examined for damage and wear. This
includes any ropes, pulleys, nuts, bolts, moving parts, bushes, chains, wheels, bearings & connection points etc.
• Ensure that you inspect the product regularly - at least once a week is recommended.
• Ensure that all xings are tight before use.
• Always replace damaged / worn components with original parts from the manufacturer.
Prepare your work area - It is important you assemble the product in a clean and uncluttered space.
Work with a friend - We recommend assistance with the assembly as some of the components are quite heavy.
Open the carton - Check any warnings on the carton and make sure you have it the right way up.
Unpack the carton - Remove all the aprts and lay them out on the oor.
Make sure you have the following parts
Z
O R
AC QP
J L
NI
BD
Assembly Instructions
www.yorkfitness.com
6
Assembly Instructions
BLISTER PACK
1 x N-9
D16
1 x N-10
1 x N-11
1 x N-7
M8*55
5 x N-3
D15.4
4 x N-2
D22
4 x N-1
M8*20L
4 x N-3
D15.4
4 x N-2
D22
4 x N-5
M8*15L
4 x N-4
M8*75
1 x N-6
80.6*56*52.5
1 x N-8
D12.7*23
STEP 3 STEP 1
1
I
Z N-5 N-4N-3 N-2 J
N-4 x 4
N-2 x 4
N-3 x 4
N-5 x 4
www.yorkfitness.comwww.yorkfitness.com
7
2
UP
DOWN
BACKWARD
FRONTWARD
c
b
a
D-1
E-3
L-1
L-1
L-2
L-3
R-1
R-2
R-3
L-2 x 3
Pre-installed parts
L-3 x 3
Pre-installed parts
3
B
C
N-6
N-7
N-9
N-3
N-2
N-3
N-1
E-5
E-5
C-2
C-2
N-8
a
(b)
N-1 x 4
N-3 x 5
N-2 x 4
N-9 x 1
N-8 x 1
www.yorkfitness.com
8
Assembly Instructions
4
C-3
C-2
B-3
P-2
P-1
Q
C
A
A-2 x 4
Pre-installed screw
C-3 x 2
Pre-installed screw
Final Check
Your exercise cycle is now assembled.
Please make the following nal checks:
• Make sure all screws / bolts are tightened.
• Make sure the equipment is on a at, level surface.
Input Power
Plug in the adaptor to the equipment then the
computer will produce a beep sound and turn
on the computer at the Manual mode.
www.yorkfitness.comwww.yorkfitness.com
9
Hand Pulse Sensors
This exercise cycle is tted with 2 hand pulse sensors. To obtain
a pulse reading you must have both your left and right hands on
the sensors at the same time. Do not grip the hand sensors too
tight to give the computer a few seconds to display the reading.
Hand Pulse Sensor
Adjusting The Resistance
This exercise cycle features a speed independent braking
(resistance) system. The resistance is controlled by a magnet,
which is moved closer or further away from the ywheel - the
closer the magnet is to the ywheel the higher the resistance.
The magnet is computer controlled, to adjust simply use the UP /
DOWN key on the console.
Resistance Level
Adjust the seat
1. Unscrew the hand wheel.
2. Adjust the seat up / down or forward / backward to your liking.
3. Re-screw the hand wheel - make sure it is screwed tightly.
4. The basic rule for getting the seat height right is that as the
pedal reaches its lowest point, the leg is almost straight.
Note: Do not pull the seat out too far - the maximum is indicated
with a piece of tape on the seat post.
Levelling Your Exercise Cycle
To help you level the exercise cycle on uneven surface, 2 height
adjusters are included on the rear stabilizers. Simply twist these
around to adjust the height of the cycle.
Operational Instructions
www.yorkfitness.com
10
Operational Instructions
Console
KEY FUNCTION DESCRIPTION
UP • Increase resistance level.
• Setting selection.
DOWN • Decrease resistance level.
• Setting selection.
MODE • Conrm setting or selection.
RESET • Press the RESET button once to go back to
main menu during setup.
• Press and hold the RESET button for 2 seconds
to reboot computer and start from default
setting.
START / STOP • Start / Stop a workout program.
RECOVERY • Test your heart rate recovery. (See the
“Recovery Mode” section)
BODY FAT • Test your body fat % and BMI. (See the “Body
Fat Mode” section)
BODY FAT RECO VERY DOWN UP RESET START/STOP
P1 P2
P3
P4
P5 P6
P12P11
P10P9P8
P7
MODE
DISPLAY DESCRIPTION
TIME • Display the workout time during exercise.
• Range 0:00 ~ 99:59
SPEED • Display the workout speed during exercise.
• Range 0.0 ~ 99.9
DISTANCE • Display the workout distance travelled during exercise.
• Range 0.0 ~ 99.9
CALORIES • Display the calories burnt during exercise.
• Range 0 ~ 999
PULSE • Display the user pulse (bpm) during exercise.
• An alarm will sound if your pulse is over the preset target.
RPM • Display the rotation per minute during exercise.
• Range 0 ~ 999
WAT T • Display the power consumption during exercise.
• In Watt Program mode, computer will remain preset watt value during exercise. (Setting
range 0~350)
MANUAL • Display the manual mode workout.
PROGRAM • Display the preset resistance level prole of the selected program mode.
USER • Display the user resistance level prole during a user mode workout.
H.R.C. • Display the H.R.C. mode workout.
www.yorkfitness.comwww.yorkfitness.com
11
Power On
Plug in power supply and the computer will power on and display all segments for 2 seconds.
After power on the monitor for the rst time, the user will be prompted to enter his / her age, sex, height and weight. Use
the UP / DOWN buttons to change the value and press the MODE key to conrm each setting. The monitor will enter the
home screen after the setup.
Stand-by Mode
The LCD monitor will enter stand-by mode after 4 minutes of inactivity. Press on any key to wake the monitor.
Manual Mode
User can begin manual mode by pressing the START button in main menu.
1. Use the UP / DOWN buttons to select MANUAL and press MODE to conrm.
2. Use the UP / DOWN buttons to preset a target TIME, DISTANCE, CALORIES or PULSE.
Press MODE to conrm.
3. Press on the START/STOP button to begin workout. Use the UP / DOWN buttons to adjust load level during exercise.
4. Press on the START/STOP button to pause. Press RESET to return to the main menu.
Program Mode
1. Use the UP / DOWN buttons to select one of the twelve preset programs and press
MODE to conrm.
2. Use the UP / DOWN buttons to set a workout time.
3. Press on the START/STOP button to begin workout. Use the UP / DOWN buttons to adjust load level during exercise.
4. Press on the START/STOP button to pause. Press RESET to return to the main menu.
User Program Mode
1. Use the UP / DOWN buttons to select a user program and press MODE to conrm.
2. Use the UP / DOWN buttons to set a load level for the rst column and press MODE to select the next column. Repeat
this step for all 20 columns.
3. Press and hold on the MODE button to nish or quit the setup.
4. Use the UP / DOWN buttons to set a workout time.
5. Press on the START/STOP button to begin workout. Use the UP / DOWN buttons to adjust load level during exercise.
6. Press on the START/STOP button to pause. Press RESET to return to the main menu.
H.R.C. Mode
1. Use the UP / DOWN buttons to select H.R.C. and press MODE to conrm.
2. Use the UP / DOWN buttons to select 55%, 75%, 90% or TAG (Target H.R. - default: 100).
3. Use the UP / DOWN buttons to set a workout time.
4. Press on the START/STOP button to begin workout.
5. Press on the START/STOP button to pause. Press RESET to return to the main menu.
www.yorkfitness.com
12
WATT Mode
1. Use the UP / DOWN buttons to select WATT and press MODE to conrm.
2. Use the UP / DOWN buttons to select a WATT target (Default: 120).
3. Use the UP / DOWN buttons to set a workout time.
4. Press on the START/STOP button to begin workout. Use the UP / DOWN buttons to adjust WATT level.
5. Press on the START/STOP button to pause. Press RESET to return to the main menu.
Recovery Mode
1. User must be holding the hand pulse sensor to use this feature. When the pulse value is displayed
on the computer, press on the RECOVERY button.
2. Hold on the hand pulse sensor until the TIME display nish the countdown from 60 seconds.
3. After the countdown ends, the result will be displayed on the monitor:
1.0 OUTSTANDING
1.0 < 1.9 EXCELLENT
2.0 < 2.9 GOOD
3.0 < 3.9 FAIR
4.0 < 5.9 BELOW AVERAGE
6.0 POOR
Body Fat Mode
1. After your workout, press on the BODY FAT button and hold on the handgrips.
2. After 8 seconds, the computer will display the BMI, FAT% and fat symbol.
3. Press on the BODY FAT button again to return to main menu.
B.M.I (Body Mass Index) Integrated
B.M.I. SCALE LOW LOW / MED MEDIUM MED / HIGH
Range < 20 20-24 24.1 - 26.5 > 26.5
BODY FAT
SYMBOL LOW (—) LOW / MED (+)
MEDIUM (p) MED / HIGH (¿)
MALE < 13% 13% - 25.9% 26% - 30% > 30%
FEMALE < 23% 23% - 35.9% 36% - 40% > 40%
Operational Instructions
www.yorkfitness.comwww.yorkfitness.com
13
If you have a problem with your treadmill, before you do anything else please check that all the cables have been
connected correctly. Loose cables are very common and many problems can be solved by making sure the cables are
properly connected and not damaged.
The following table details the most common problems and how to x them. If you still have a problem after going through
the troubleshooting guide please call your local YORK distributor for advice.
PROBLEM CAUSE CORRECTION
NO DISPLAY
No power Make sure power cord is plugged in properly
System halted
Unplug and re-plug the power cord to reset
the system
NO SPEED
DISPLAY
Wires are damaged or not connected properly Verify all wires are connected properly
Speed sensor is too far from magnet Contact your local YORK distributor
PARTIAL DISPLAY The PA board is not connected properly
Unplug and re-plug the power cord
Verify all wires are connected properly
Disconnect and re-connect all cables
Contact your local YORK distributor
NO PULSE
SIGNAL
Wires are damaged or not connected properly Verify all wires are connected properly
Too much hand movement Grip rmly
Palms too wet Dry palms
Hand Pulse Sensor is being gripped too tightly Grip using moderate pressure
User is wearing rings Remove all rings
ERROR CODE: E-1 Hands are not hold on handgrips tightly during BODY FAT test.
ERROR CODE: E-2 Check if cables are well connected or damaged.
ERROR CODE: E-4
Check the user’s age, height, weight gure setting when the test result is out of the range of
FAT% 5~50 and BMI 5~50%.
For your own safety, do not open protective casing. If error persist, please contact your local york distributor for advice.
Troubleshooting
www.yorkfitness.com
14
Starting and Finishing Your Workout
Begin and end each workout with a Warm Up / Down session - a few minutes of stretching to prevent strains, pulls
and cramps.
Correct Cycling Form
• Sit on the cycle, with your feet on the pedals and inside the pedal straps.
• Ensure that the seat height is adjusted correctly - you should be stable and balanced whilst on the saddle. The basic rule
for getting the seat height right is that as the pedal reaches its lowest point, the leg is almost straight.
• Try to ensure that your back is straight whilst exercising, especially for long periods.
Suggested Stretches
The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce.
1. Hamstring Stretch
Sit with one leg extended.
Bring the sole of the
opposite foot toward you
and rest it against the inner
thigh of your extended leg.
Reach toward your toes
as far as possible. Hold
for 15 counts, then relax.
Repeat 3 times for each
leg. Stretches: Hamstrings,
lower back and groin.
2. Calf/Achilles Stretch
With one leg in front of the
other, reach forward and
place your hands against
a wall. Keep your back leg
straight and your back foot
at on the oor. Bend your
front leg, lean forward and
move your hips toward the
wall. Hold for 15 counts,
then relax. Repeat 3 times
for each leg. To cause
further stretching of the
achilles tendons, bend
your back leg as well.
Stretches: Calves, achilles
tendons and ankles.
3. Quadriceps Stretch
With one hand against a wall
for balance, reach back and
grasp one foot with your
other hand. Bring your heel
as close to your buttocks as
possible. Hold for 15 counts,
then relax. Repeat 3 times
for each leg. Stretches:
Quadriceps and hip muscles.
4. Inner Thigh Stretch
Sit with the soles of your
feet together and your
knees outward. Pull your
feet toward your groin
area as far as possible.
Hold for 15 counts, then
relax. Repeat 3 times.
Stretches: Quadriceps and
hip muscles.
Fitness Guide
www.yorkfitness.comwww.yorkfitness.com
15
How Long Should I Exercise For?
That really depends on your current level of tness. If you’re just starting out on a new exercise program, you should start
gradually and build up - do not try to do too much too quickly. 30 minutes, 3 times a week should be enough.
Don’t push yourself too hard - you should never feel exhausted during or following exercise.
Heart Rate Training
To get the most out of your new piece of tness equipment and see the best results from your training you should exercise
at the right level of eort, and that means listening to your heart! Working out to a target heart rate means you can direct
your workout to achieve dierent goals:
Good health - For those wishing to improve quality of life and general well being. Your sessions will need to be done at an
intensity of between 50 - 60% of your estimated maximum heart rate, should last about 30 minutes and can be done on
most days of the week.
Weight loss - To see a signicant reduction in body fat, your sessions must be a little more intense - between 60 and 70% of
your estimated maximum heart rate. These sessions can also be performed on most days of the week for up to 30 minutes.
Improving tness levels - These sessions should be performed at 70 - 80% of your estimated maximum heart rate and can
also involve bouts of interval training that would have your heart rate peaking for short times near your maximum heart
rate level. These are intense sessions and will require at least a 48 hour rest between sessions.
Calculating Your Target Heart Rate
First, you need to nd your estimated maximum heart rate using the formula “220 minus your age in years”. So, if you are 35
years old your estimated maximum heart rate is:
220 - 35 = 185 beats per minute (bpm)
Next, to calculate your target heart rate, simply multiply your estimated maximum heart rate (185bpm) by the applicable
percentage. So, if your goal is better health:
185 x 60% = 111bpm
NOTE: The important issue to remember with all estimated calculations is that they are just estimates
- if you do not feel comfortable exercising at your target then reduce levels to a more tolerable and
comfortable setting for your exercise activities.
Heart rate training requires you to monitor your heart rate throughout the workout. For this we
recommend using a chest strap (if your machine has a wireless receiver) or a heart rate monitor. For
more information please get in touch using the Contact Us details.
Always consult your doctor before undertaking a new exercise regime. If you experience nausea,
dizziness or other abnormal symptoms during exercise, stop at once and consult your doctor.
www.yorkfitness.com
16
L-1
L-2
L-3
R-1
R-2
R-3
D
P-2
N-4N-5
O
P-1
N-2
C-3
N-7
N-9
N-3
N-8
N-6
Q
B
A
C
N-3
N-1
I
N-3 N-2 J
Exploded Drawing
www.yorkfitness.comwww.yorkfitness.com
17
H-8 H-4
H-1
H-5 H-3
H-9 H-7 H-6 H-2 H-11 H-10
R-1
R-2
R-3
H-12
H R
F
K
LA
I J
G M
EC
QOD
P
B
F-13
F-1
F-7
F-6
F-5
F-2
F-3
L-3
L-2
L-1
A-1
I-1
J-1
J-2
G-3G-2
G-11
G-10
G-6
D-1
D-2
P-1
P-2
G-5G-4G-8G-7
G-1 G-9
M-2M-1M-3M-4 M-5
I-4
I-3
I-2
A-2
F-8
F-9
F-12
F-11
F-10
F-4
K-8
K-6
K-7
K-5
K-11
K-10
K-3
K-2
K-4
K-9
K-1
E-7
E-11E-10E-9
E-2
E-4
E-3
E-1
E-5 E-6
E-8
B-2
B-4
B-1
B-3 B-5
C-3
C-2
C-1
www.yorkfitness.com
18
YORK REF. REF. DESCRIPTION QT Y.
53084-001 A COMPUTER SET
53084-002 A-1 COMPUTER (SM-2789-67) 1
53084-003 A-2 BOLT (M5X0.8X10L) 4
53084-004 B HANDLEBAR SET
53084-005 B-1 HANDLEBAR (D22.2X470X350X1.5T) 1
53084-006 B-2 CAP (D 7/8"X17L) 2
53084-007 B-3 HANDLE PULSE CABLE (500L) 2
53084-008 B-4 FOAM (D20*7 T*530) 2
53084-009 B-5 HANDLE PULSE (WP1007-09B) 2
53084-010 B-6 ROUND CROSS SCREW (ST4*15) 2
53084-011 C HANDLEBAR POST SET
53084-012 C-1 HANDLEBAR POST 1
53084-013 C-2 UPPER COMPUTER CABLE (900L) 1
53084-014 C-3 BO LT (M5*0.8*15L) 2
53084-015 D SEAT TUBE SET
53084-016 D-1 SEAT TUBE 1
53084-017 D-2 CAP (25*50*28L) 2
53084-018 E FRAME SET 1
53084-019 E-1 FRAME 1
53084-020 E-2 BEARING (#99502) 2
53084-021 E-3 KNO B (D56XM16X24XD8) 1
53084-022 E-4 INNER TUBE (D66XD52X170L) 1
53084-023 E-5 LOWER COMPUTER CABLE (500L) 1
53084-024 E-6 ELECTRIC CABLE (620L) 1
53084-025 E-7 MOTOR 1
53084-026 E-8 SC REW (ST4.2*1.4*15L) 4
53084-027 E-9 SENSOR CABLE (100L) 1
53084-028 E-10 BOLT (M5X0.8X12L) 1
53084-029 E-11 TENSION CABLE (D1.5*300L) 1
53084-030 F CRANK SET
53084-031 F-1 BELT WHEEL (D260*19) 1
53084-032 F-2 CRANK AXLE SET 1
53084-033 F-3 L EFT CRANK (6 1/2"X 9/16"-20UNF) 1
53084-034 F-4 RIGHT CRANK (6 1/2"X9/16"-20UNF) 1
53084-035 F-5 BELT (1059 PJ5, HATCHINSON ) 1
53084-036 F-6 BO LT (M8X1.25X25) 2
53084-037 F-7 SC REW COVER (D23X6.5) 2
53084-038 F-8 BO LT (M6X1.0X15L) 4
53084-039 F-9 ANTI-LOOSE NUT (M6X1.0X6T) 4
53084-040 F-10 C-RING (S-16(1T)) 2
53084-041 F-11 FLAT WASHER (D24XD16X1.5T) 1
53084-042 F-12 WAVED WASHER (D21XD16X0.3T) 2
53084-043 F-13 ROUND MAGNET (M02) 1
53084-044 G FIXING PLATE FOR MAGNET SET
53084-045 G-1 FIXING PLATE FOR MAGNET 1
53084-046 G-2 BOLT (M8*52L) 1
53084-047 G-3 ANTI-LOOSE NUT (M8*1.25*8T) 1
53084-048 G-4 SPRING (D1.0*42L) 1
53084-049 G-5 FLAT WASHER (D13*D6.5*1.0T) 1
53084-050 G-6 BOLT (M6*60L) 1
53084-051 G-7 NYLON NUT (D6*D19*1.5T) 1
53084-052 G-8 NUT (M6*1*6T ) 1
53084-053 G-9 ANTI-LOOSE NUT (M6*1*6T) 1
53084-054 G-10 MAGNET (39.5*10*25) 7
53084-055 G-11 MAGNET CELL (40*3*3) 6
53084-056 H FLYWHEEL SET
53084-057 H-1 FLYWHEEL (D260*35) 1
53084-058 H-2 BEARING (6900-2RS) 1
53084-059 H-3 BEARING (6003-2RS ) 2
53084-060 H-4 BEARING (6300-2RS ) 1
YORK REF. REF. DESCRIPTION QT Y.
53084-061 H-5 SINGLE BEARING (D35*16) 1
53084-062 H-6 SMALL FLYWHEEL (D30*D17*62.9) 1
53084-063 H-7 FLYWHEEL AXLE (D10*129L(3/8"-26UNF)) 1
53084-064 H-8 NUT (D9.5X8T(3/8"-26UNFX8T)) 1
53084-065 H-9 C-RING (S-10(1T)) 1
53084-066 H-10 NUT (D9.5X4T(3/8"-26UNFX4T)) 1
53084-067 H-11 FIXED RING (D13*D10*1.9T) 1
53084-068 H-12 ANTI-LOOSE NUT (3/8"-26UNFX6.5T) 2
53084-069 I FRONT STABILIZER SET
53084-070 I-1 FRONT STABILIZER (D60X500LX1.5T) 1
53084-071 I-2 R OUND CAP (D60XD67X43) 2
53084-072 I-3 MOVEABLE CAP (D60X54.5L) 2
53084-073 I-4 S CREW (ST4*1.41*12L) 4
53084-074 J REAR STABILIZER SET
53084-075 J-1 REAR S TABILI ZER (D60*1.5T*593*160) 1
53084-076 J-2 12-ANGLE CAP (D60XD75X50) 2
53084-077 K IDLE WHEEL SET
53084-078 K-1 IDLE WHEEL FIXING PLATE 1
53084-079 K-2 IDLE W HEEL ( D23.8*D38*24) 1
53084-080 K-3 BUSH ING (D20*D14*11.5T) 1
53084-081 K-4 ANTI-LOOSE NUT (M10X1.5X10T) 1
53084-082 K-5 PLASTCI FLAT WASHER (D10*D24*0.4T) 2
53084-083 K-6 ALLEN BOLT (M10*35L) 1
53084-084 K-7 BOLT (M8*1.25*25L) 1
53084-085 K-8 FLAT WASHE R (D21*D8.5*1.5T) 1
53084-086 K-9 ANTI-LOOSE NUT (M8*1.25*8T) 1
53084-087 K-10 SPRIN G (D2.2XD14X55) 1
53084-088 K-11 PLASTIC COVER (D3*30L) 2
53084-089 L SEAT SET
53084-090 L-1 SEAT (LS-A16) 1
53084-091 L-2 FL AT WASHER (D16XD8.5X1.2T) 1
53084-092 L-3 ANTI-LOOSE NUT (M8*1.25*8T) 1
53084-093 M CHAIN COVER SET
53084-094 M-1 LEFT CHAIN (765X70X360) 1
53084-095 M-2 RIGHT CHAIN (765X70X360) 1
53084-096 M-3 SIDE COVER (D358*D26*10T) 2
53084-097 M-4 SCREW (ST4X1.41X20L) 4
53084-098 M-5 SCREW (ST4.2X1.4X20L) 4
53084-099 N SCREW BAG 1
53084-100 N-1 ALLEN BOLT (M8X1.25X20L) 4
53084-101 N-2 CURVED WASHER (D22*D8.5*1.5T) 8
53084-102 N-3 SPRING WASHER (D15.4 XD8.2X2T) 9
53084-103 N-4 BOLT (M8X1.25X75L) 4
53084-104 N-5 NUT (M8X1.25X15L) 4
53084-105 N-6 PROTECTI VE COVER (80.6*56*52.5) 1
53084-106 N-7 T-KNOB (M8X1.25X55) 1
53084-107 N-8 BUSHING (D8XD12.7X23) 1
53084-108 N-9 FLAT WASHER (D16XD8.5X1.2T) 1
53084-109 N-10 ALLEN SPANNER (M6 ) 1
53084-110 N-11 SPANNER ( 121*D6) 1
53084-111 O ADAPTOR (OUTPUT:9V) 1
53084-112 P PEDAL SET (JD-22A ) 1
53084-113 P-1 LEFT PEDAL
53084-114 P-2 RIGHT PEDAL
53084-115 Q WATER BOTTLE BRACKET (120*87*3T) 1
53084-116 R SEAT ADJUSTMENT TUBE SET
53084-117 R-1 SEAT ADJUSTMENT TUBE 1
53084-118 R-2 FLAT WASHER (D28*D8.5*3T) 1
53084-119 R-3 KNOB (D60X32L(M8X1.25)) 1
Part List
www.yorkfitness.comwww.yorkfitness.com
19
Notes
www.yorkfitness.com
Loading...
