York ZH R410A 11.7 EER, ZH R410A 14 SEER, ZJ R410A 12.2 EER, ZJ R410A 15 SEER, ZR MagnaDry R410A 15 SEER Technical Guide

528150-YTG-T-0514

®

TECHNICAL GUIDE
R-410A

ZH/ZJ/ZR SERIES
3 - 12-1/2 TON
60 Hertz

ZH/ZJ/ZR 3 THROUGH 10 TON

Description

ASHRAE 90.1 COMPLIANT

®

YORK
common footprint cabinet and common roof curb for all 3
through 12-1/2 ton models. All 6-1/2 through 12-1/2 ton units
have two compressors with independent refrigeration circuits to
provide 2 stages of cooling. The units were designed for light
commercial applications and can be easily installed on a roof
curb, slab, or frame.

All Predator
full perimeter base rails allowing for 3-way forklift access and
overhead rigging. Every unit is completely charged, wired,
piped, and tested at the factory to provide a quick and easy field
installation.

All units are convertible between side and down airflow.
Independent economizer designs are used on side and down
discharge applications, as well as all tonnage sizes.

Predator
cooling only, cooling with electric heat, cooling with gas heat,
reheat only, reheat with electric heat and reheat with gas heat.
Electric heaters are available as factory-installed options or
field-installed accessories.

All units provide constant supply air volume. A variab le ai r
volume (VAV) option, featuring a variable frequency drive, is
available on 6-1/2 through 12-1/2 ton ZH/ZJ models only.

Predator® units are convertible single packages with a

®

units are self-contained and assembled on rigid

®

units are available in the following configurations:

ZH/ZJ/ZR 12-1/2 TON

Tested in accordance with:

FOR DISTRIBUTION USE ONLY - NOT TO BE USED AT POINT OF RETAIL SALE

528150-YTG-T-0514

Intelligent control board

for safe and efficient

operation

“Simplicity®” Control board w/

screw connectors for T-stat

wiring and Network

Connections

Disconnect location

(optional disconnect switch)

Filter access

(2" or 4”

filter options)

Filter drier (solid core)

3-5 Ton Cooling

Slide out motor and

blower assembly for

easy adjustment

and service

Base rails w/

forklift slots

(three sides)

and lifting

holes

Toolless door

latch

Side entry power

and control wiring

knockouts

Belt-drive blower

motor

Power ventor

motor

20-gauge aluminized

steel tubular heat

exchanger for long life

(stainless steel option)

One or Two stage gas heating to

maintain warm, comfortable

temperature

Slide-out drain pan

with ¾" NPT

connection

Compressor access (high-

efficiency compressor)

Second model nameplate

inside hinged access

panel

Roof curbs in eight-and

fourteen-inch heights.

Roof curbs for transitioning

from York Sunline™ footprint

to the ZH/ZJ/ZR Series footprint

are available

(field-installed accessory)

Micro-Channel Aluminum

Tube/Aluminum Fin

Condenser

(Single Orifice System shown.
See Actual Model Physical Data for details)

Filter drier (solid core)

3-5 Ton Reheat

Table of Contents

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Component Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Features and Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Guide Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Physical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Capacity Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Airflow Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Sound Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

Typical Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172

Weights and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192

Weights and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193

Economizer Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204

Component Location

Cooling With Gas Heat (3 Through 5 Ton)

2 Johnson Controls Unitary Products

Cooling With Gas Heat (6 1/2 Through 10 Tons)

Roof curbs in eight- and
fourteen-inch heights. Roof
curbs for transitioning from
York Sunline™ footprint to
the ZH/ZJ/ZR Series footprints
are also available (field
installed accessory)

Base rails w/forklift
slots (three sides)
and lifting holes

Compressor #2
access (high­efficiency
compressor)

Dual stage
cooling for
maximum
comfort

Second model
nameplate
inside hinged
access panel

Terminal block for
hi-voltage connection

Simplicity® control board
w/screw connector for T-stat
wiring and network connections

Disconnect location
(optional disconnect switch)

Filter access
(2” or 4” filter options)

Filter drier
(solid core)

Slide-out motor and
blower assembly for
easy adjustment
and service

Belt-drive
blower motor

Power ventor motor

20-gauge alumi­nized steel tubular
heat exchanger for
long life (stainless
steel option)

Two-stage gas
heating to m

aintain
warm, comfortable
temperature

Intelligent control
board for safe and
efficient operation

Compressor #1 access
(high-efficiency compressor)

Toolless
door latch

Side entry power
and control wiring
knockouts

VFD location (optional)

Slide-out drain pan
with 3/4” NPT,
female connection

Micro-Channel Aluminum
Tube/Aluminum Fin
Condenser

528150-YTG-T-0514

Johnson Controls Unitary Products 3

528150-YTG-T-0514

Z H 090 N10 A 2 A AA 6 0 1 2 4 A

Product Category

Z = A/C, Single Pkg., R-410A

A = Std. Motor
D = Std. Motor/Motorized Damper (Downow Only)
H = Std Motor/Low Leak Econ/Barometric Relief
(Downow, Slab Economizer Only)
J = Std Motor/Low Leak Econ/Power Exhaust (Downow,
Slab Economizer Only)
E = Std Motor/Horizontal Economizer (No Baro)
N = Hi Static
R = Hi Static/Motorized Damper (Downow Only)
V = Hi Static Mtr/Low Leak Econ/Barometric Relief
(Downow, Slab Economizer Only)
W = Hi Static Mtr/Low Leak Econ/Power Exhaust
(Downow, Slab Economizer Only)
S = Hi Static Mtr/Horizontal Economizer (No Baro)

Airow

Product Generation

6 = Sixth Generation

C00 = Cooling Only. No heat installed

Heat Type and Nominal Heat Capacity

(Unit Size Allowed)

A05 = 49 MBH Output Aluminized Steel,
Single Stage (037, 049)
A07 = 65 MBH Output Aluminized Steel,
Single Stage (037, 049, 061)
A09 = 97 MBH Output Aluminized Steel,
Single Stage (037, 049, 061)
A13 = 129 MBH Output Aluminized Steel,
Single Stage (061)
B05 = 49 MBH Output Stainless Sleel,
Single Stage (037, 049)
B07 = 65 MBH Output Stainless Steel,
Single Stage (037, 049, 061)
B09 = 97 MBH Output Stainless Steel,
Single Stage (037, 049, 061)
B13 = 129 MBH Output Stainless Steel,
Single Stage (061)

N10 = 100 MBH Output Aluminized Steel,
Two Stage (078, 090, 102)
N15 = 150 MBH Output Aluminized Steel,
Two Stage (078, 090, 102, 120, 150)
N20 = 200 MBH Output Aluminized Steel,
Two Stage (120, 150)
S10 = 100 MBH Output Stainless Steel,
Two Stage (078, 090, 102)
S15 = 150 MBH Output Stainless Steel,
Two Stage (078, 090, 102, 120, 150)
S20 = 200 MBH Output Stainless Steel,
Two Stage (120, 150)

E03 = 3 KW (037)
E06 = 6 KW (037, 049, 061)
E08 = 9 KW (037, 049, 061)
E09 = 9 KW (078, 090, 102)
E15 = 15 KW (037, 049, 061)
E18 = 18 KW (078, 090, 102, 120, 150)
E20 = 20 KW (049, 061)
E23 = 24 KW (061)
E24 = 24 KW (078, 090, 102, 120, 150)
E36 = 36 KW (078, 090, 102, 120, 150)
E54 = 54 KW (120, 150)

Single Stage Natural Gas Heat Options

Electric Heat Options

078 = 6.5 Ton

Nominal Cooling Capacity

090 = 7.5 Ton
102 = 8.5 Ton

037 = 3 Ton
049 = 4 Ton
061 = 5 Ton

120 = 10.0 Ton
150 = 12.5 Ton

Product Identifier

H = 11.7-11.8 EER

Voltage

2 = 208/230-3-60
4 = 460-3-60
5 = 575-3-60

Product Style

A = Style A
B = Style B
C = Style C

A = No Options Installed

Installation Options

B = Option 1
C = Option 2
D = Options 1 & 2
E = Option 3
F = Option 4
G = Options 1 & 3
H = Options 1 & 4
J = Options 1, 2 & 3
K = Options 1, 2, & 4
L = Options 1,3 & 4
M = Options 1, 2, 3, & 4
N = Options 2 & 3
P = Options 2 & 4
Q = Options 2, 3, & 4
R = Options 3 & 4
S = Option 5
T = Options 1 & 5
U = Options 1, 3, & 5
V = Options 1, 4, & 5
W = Options 1, 3, 4, & 5
X = Option

s 3 & 5
Y = Options 4 & 5
Z = Options 3, 4 & 5

1 = Disconnect
2 = Non-Pwr'd Conv. Outlet
3 = Smoke Detector S.A.
4 = Smoke Detector R.A.
5 = Pwr'd Conv. Outlet

Options

SS Drain Pan

Configuration Options (not required for all units)

These four digits will not be assigned until a quote is requested, or an order placed.

CPC Controller, DFS, APS

Johnson Controller UNT 1126 (N2 protocol), DFS, APS

Honeywell Controller, DFS, APS

Novar Controller, DFS, APS

Simplicity IntelliComfort II Controller

Simplicity IntelliComfort II Controller w/Simplicity®LINC

2" Pleated Filters, MERV 7

BAS Ready Economizer (2-10 V.D.C. Actuator without a Controller)

York Commercial Comfort System (YCCS) Rtu Controller

Hot Gas Bypass (Standard on VAV, Optional on CV)

Variable Air Volume, VFD (not available with factory installed BAS options)

Variable Air Volume, VFD with Simplicity®LINC (not available with factory installed BAS options)

Variable Air Volume, VFD (BAS ready)

Variable Air Volume, VFD and Manual Bypass (BAS ready)

Variable Air Volume, VFD Ready (for customer-provided, field-installed drive)

Variable Air Volume, VFD Ready with Simplicity®LINC
(for customer-provided, field-installed drive)

Variable Air Volume, VFD and Manual Bypass with Simplicity®LINC
(not available with factory installed BAS options)

Variable Air Volume, VFD and Manual Bypass
(not available with factory installed BAS options)

Any Combination of Additional Options that Don’t Have an Option Code Pre-assigned

AA = None
AB = Phase Monitor
AC = Coil Guard
AD = Dirty Filter Switch
AE = Phase Monitor & Coil Guard
AF = Phase Monitor & Dirty Filter Switch

Additional Options

RC = Coil Guard, Shipping Bag & American Flag
TA = Technicoat Condenser Coil
TJ = Technicoat Evaporator Coil
TS = Technicoat Evaporator & Condenser Coils

3-12.5 Ton York® Model Number Nomenclature

ZZ = If desired option combination is not listed above, ZZ will be assigned and configuration options will be

located in digits 15-18.

J = 12.2 EER

Two Stage Natural Gas Heat Options

N05 = 49 MBH Output Aluminized Steel,
Two Stage (037, 049)
N07 = 65 MBH Output Aluminized Steel,
Two Stage (037, 049, 061)
N09 = 97 MBH Output Aluminized Steel,
Two Stage (037, 049, 061)
N13 = 129 MBH Output Aluminized Steel,
Two Stage (061)
S05 = 49 MBH Output Stainless Sleel,
Two Stage (037, 049)
S07 = 65 MBH Output Stainless Steel,
Two Stage (037, 049, 061)
S09 = 97 MBH Output Stainless Steel,
Two Stage (037, 049, 061)
S13 = 129 MBH Output Stainless Steel,
Two Stage (061)

AG = Coil Guard & Dirty Filter Switch
AH = Phase Monitor, Coil Guard & Dirty Filter Switch

4" Pleated Filters, MERV 13

R = Reheat

EA = ElectroFin Condenser Coil
EJ = ElectroFin Evaporator Coil
ES = ElectroFin Cond & Evap Coils

IntelliSpeed with VFD

IntelliSpeed, VFD and Manual Bypass

IntelliSpeed, VFD Ready (for customer-provided, field-installed drive)

Nomenclature

4 Johnson Controls Unitary Products

528150-YTG-T-0514

Features and Benefits

Standard Features

• High Efficiency – High efficiency units reach as high as

12.2 EER. Gas/electric units have electronic spark ignition
and power vented combustion with steady state efficiencies
of 80%. These efficiencies exceed all legislated minimum
levels and provide low operating costs.

• Service Friendly – The Predator
of enhancements which improve serviceability.

The motor and blower slide out of the unit as a common
assembly. This facilitates greater access to all the indoor
airflow components, thus simplifying maintenance and
adjustment.

Service time is reduced through the use of hinged,
toolless panels. Such panels provide access to frequently
inspected components and areas, including the control
box, compressors, filters, indoor motor & blower, and the
heating section. The panels are screwed in place at the
factory to prevent access by children or other
unauthorized persons. It is recommended that the panels
be secured with screws once service is complete.

Service windows have been placed in both condenser
section walls. Rotation of the cover allows easy access to
the condenser coils for cleaning or inspection.

Both the unit control board and ignition control board utilize
flash codes to aid in diagnosis of unit malfunctions. Unique
alarm codes quickly identify the source of the unit alarm.

All units use four filters of the same standard size. This
standardization simplifies selections for filter replacement.

The non-corrosive drain pan slides out of the unit to permit
easy cleaning. The drain pan is accessed by removing the
drain pan cover plate on the rear of the unit. Once the plate is
removed, the drain pan slides out through the rear of the unit.

®

All Predator

units have a second model nameplate
located inside the control access door. This is to prevent
deterioration of the nameplate through weathering.

• Coil Technology – All ZH/ZJ condensers utilize Micro­Channel “all-aluminum” condensers which provide
improved heat transfer capabilities and reduced charge
volumes. All evaporators utilize a conventional copper
tube/aluminum fin design for proven reliability and
performance. ZR037 thru 061 models utilize Micro­Channel condenser coils, ZR078 thru 150 models utilize
copper tube/aluminum fin condenser coils.

• Environmentally Aware – For improved Indoor Air
Quality, a combination of foil faced and elastometric
rubber insulation is used exclusively throughout the units.

• Balanced Heating – The Predator
offers “Ultimate Heating Comfort” with a balance between

st

and 2nd stage gas heating. The first stage of a gas heat

1
Predator

®

unit provides 70% or 75% of the heating capacity
3 thru 5 tons and 60% heating capacity 6-1/2 thru 12-1/2
tons. Balanced heating allows the unit to better maintain
desired temperatures.

• Convertible Airflow Design – The side duct openings
are covered when they leave the factory. If a side supply/

®

incorporates a number

®

two stage gas heating

return is desired, the installer simply removes the two side
duct covers from the outside of the unit and installs them
over the down shot openings. No panel cutting is required.
Convertible airflow design allows maximum field flexibility
and minimum inventory.

• System Protection - Suction line freezestats are supplied
on all units to protect against loss of charge and coil frosting
when the economizer operates at low outdoor air
temperatures while the compressors are running. Every unit
has solid-core liquid line filter-driers and high and low­pressure switches. Internal compressor protection is
standard on all compressors. Scroll compressors do not
require crankcase heaters. Phase Monitors are standard on
units with scroll compressors. This accessory monitors the
incoming power to the unit and protects the unit from phase
loss and reversed phase rotation.

• Advanced Controls - Simplicity® control boards have
standardized a number of features previously available
only as options or by utilizing additional controls.

• Low Ambient - An integrated low-ambient control

allows all units to operate in the cooling mode down to
0F outdoor ambient without additional assistance.
Optionally, the control board can be programmed to
lockout the compressors when the outdoor air tem

-

perature is low or when free cooling is available.

The Simplicity® control board used in this product
will effectively operate the cooling system down to
0°F when this product is applied in a comfort cooling
application for people. An economizer is typically
included in this type of application. When applying
this product for process cooling applications (com­puter rooms, switchgear, etc.), please reference
applications bulletin AE-011-07 or call the applica­tions department for Unitary Products @ 1-877­UPG-SERV for guidance. Additional accessories
may be needed for stable operation at temperatures
below 30° F.

• Anti-Short Cycle Protection - To aid compressor life,

an anti-short cycle delay is incorporated into the stan

­dard controls. Compressor reliability is further ensured
by programmable minimum run times. For testing, the
anti-short cycle delay can be temporarily overridden
with the push of a button.

• Fan Delays - Fan on and fan off delays are fully pro­grammable. Furthermore, the heating and cooling fan
delay times are independent of one another. All units
are programmed with default values based upon their
configuration of cooling and heat.

• Safety Monitoring - The control board monitors the
high and low-pressure switches, the freezestats, the
gas valve, if applicable, and the temperature limit
switch on gas and electric heat units. The unit control

Johnson Controls Unitary Products 5

528150-YTG-T-0514

board will alarm on ignition failures, compressor lock­outs and repeated limit switch trips.

• Nuisance Trip Protection and Strikes - To prevent
nuisance trouble calls, the control board uses a “three
times, you’re out” philosophy. The high and low-pres­sure switches and the freezestats must trip three times
within two hours before the unit control board will lock
out the associated compressor.

• On Board Diagnostics - Each alarm will energize a
trouble light on the thermostat, if so equipped, and
flash an alarm code on the control board LED. Each
high and low-pressure switch alarm as well as each
freezestat alarm has its own flash code. The control
board saves the five most recent alarms in memory,
and these alarms can be reviewed at any time.
Alarms and programmed values are retained through
the loss of power.

• Reliable – From the beginning – All units undergo
computer automated testing before they leave the factory.
Units are tested for refrigerant charge and pressure, unit
amperage, and 100% functionality. For the long term – All
Predator

®

units are painted with a long lasting, powder
paint that stands up over the life of the unit. The paint
used has been proven by a 1000 hour salt spray test.

• Flexible Placement – All models and configurations
share the same cabinet/footprint and thus the same roof
curb. You have the flexibility to set one curb and choose
the correct tonnage size and heating option after the
internal loads have been determined.

®

To further simplify planning and installation, Predator
cabinets are designed to fit your roof. With the optional
roof curb, the unit ductwork is designed to fit around 24”
on-center joists or between 48” on-center joists.

The drain pan can be rotated to drain to either the front or
the rear of the unit. Additionally, the drain pan can be
fitted to drain through the roof curb. As it is sometimes
difficult to have a level installation, the drain pan features
a generous slope to ensure proper drainage.

• Full Perimeter Base Rails – The permanently attached
base rails provide a solid foundation for the entire unit and
protect the unit during shipment. The rails offer forklift
access from 3 sides, and rigging holes are available so that
an overhead crane can be used to place the units on a roof.

• Easy Installation – Gas and electric utility knockouts are
supplied in the unit underside as well as the side of the unit.
A clearly identified location is provided to mount a field
supplied electrical disconnect switch. Utility connections can
be made quickly and with a minimum amount of field labor.

All units are shipped with 2” throw-away filters installed.

• Wide Range of Indoor Airflows – All indoor fan motors
are belt-drive type providing maximum flexibility to handle
most airflow requirements. For high static applications,
factory installed alternate indoor fan motors are available.
With the optional indoor fan motor, all units can supply
nominal airflow at a minimum of 1.5” ESP.

A variable air volume (VAV) option using a variable
frequency drive is available on 6-1/2 through 12-1/2 ton
models for applications requiring a constant supply duct
pressure. A differential pressure transducer is used to
monitor supply duct static pressure while a VAV control
board provides a speed reference signal to the VFD to
control the output of the indoor blower motor.

• Warranty - All models include a 1-year limited warranty
on the complete unit. Compressors and electric heater
elements each carry a 5-year warranty. Aluminized steel
and stainless steel tubular heat exchangers carry a 10­year warranty.

Factory Installed Options

YORK® offers several equipment options factory installed, for
the Predator®line.

• Optional Factory Installed Economizers - Predator units
offer a variety of optional factory installed economizers
with low leak dampers. The outdoor air enthal py se nsor
enables economizer operation if the outdoor enthalpy is
less than the setpoint of the economizer logic module. See
economizer options section to determine the correct
economizer for your application.

• Downflow Slab Economizers (with barometric relief

and fresh air hood) - All units offer a variety of optional
factory installed down flow economizers that are
shipped, installed and wired with low leak dampers
designed to meet ASHRAE 90.1-2010, AMCA 511
Class 1A damper, and the International Energy
Conservation Code (IECC) certification requirements by
achieving leakage rates of 3 cfm/sq. ft. at 1" of static
pressure. Each economizer goes through a rigorous
60,000 cycle test. Dry bulb, single enthalpy, and dual
enthalpy (with field installed kit) can be selected. The
economizer has spring return, fully modulating damper
actuators and is capable of introducing up to 100%
outdoor air. As the outdoor air intake dampers open, the
return air dampers close. The changeover from
mechanical refrigeration to economizer operation is
regulated by the outdoor air dry bulb temperature or the
outdoor air enthalpy input. The dual enthalpy kit
provides a second input used to monitor the return air
(field installed). The installer needs only to assemble the
outdoor air hood, attach the enthalpy control the hood
and mount the hood to the unit (Hood and control are
provided). When selected with BAS Ready
Economizer Option the actuator requires 2-10 VDC
input from an external source, such as a field-installed
or factory-installed BAS controller. BAS-ready actuators
have an adjustable auxiliary end-switch for optional
power exhaust control.

• Horizontal Economizer - (Without barometric relief ) -

All features of the downflow economizer exist except
economizer is not designed with low leak dampers and
you must order the duct mount barometric relief
separately. You must order a 1EH0408 if you are

installing a power exhaust. You can order a 1RD0411

6 Johnson Controls Unitary Products

528150-YTG-T-0514

Barometric Relief for horizontal flow economizers
only.

• For units with optional VAV or Simplicity® Intelli-Comfort
II™ control, a factory-installed, dry bulb sensor
determines if outdoor air temperature is low enough to
provide free-cooling operation. (Field-installed humidity
sensors for either outdoor air or outdoor & return air
streams are available for single enthalpy and differential
enthalpy configurations, respectively).

• VAV or Simplicity® INTELLI-Comfort II™ control, a
factory-installed dry bulb sensor determines if outdoor
air temperature is low enough to provide free-cooling
operation. (Field-installed humidity sensors for either
outdoor air or outdoor & return air streams are available
for single enthalpy and differential enthalpy
configurations, respectively.)

• Power Exhaust (Downflow only) - This accessory
installs in the unit with a down flow economizer.

• Motorized Outdoor Air Damper - The motorized outdoor
air damper includes a slide-in/plug-in damper assembly
with an outdoor air hood and filters. The outdoor air
dampers open to the preset position when the indoor fan
motor is energized. The damper has a range of 0% to
100% outdoor air entry. Factory installed option or field
installed accessory.

• Alternate Indoor Blower Motor - For applications with
high static restrictions, units are offered with optional
indoor motors that provide higher static output and/or
higher airflow, depending upon the installer’s needs.

• Variable Air Volume (VAV; 6-1/2 through 12-1/2 ton,
only - A factory-installed variable frequency drive (VFD),
mounted in the Blower Access compartment, is used to
control the speed of the indoor blower motor in order to
maintain a constant static pressure in the supply duct. A
pressure transducer and VAV control board are mounted
inside the control box. The drive comes completely wired
and pre-programmed from the factory.

An optional, factory-installed manual bypass switch
available with factory-installed VFD can be found in the
Blower Motor Access compartment. The switch can be
used to either route power to the VFD for modulating
control of the blower motor, to bypass the drive and
operate the motor at full speed, or to power the drive (and
not the motor) for diagnostic purposes.

Due to space limitations, VAV is not available with any of
the factory-installed BAS options, but is available with
'BAS-ready' models. Terminal blocks are provided in the
control box for field wiring of the customer-installed BAS.

A 'VFD-ready' option provides the provisions for a
customer-installed drive. The unit comes with a mounting
bracket installed in the Blower Access compartment which
may accommodate other vendor's drives depending on
their size. In order to utilize the unit's mounting bracket,
the maximum recommended drive dimensions are limited
to approximately 9" H x 5" W x 7.5" D.

If the drive will not fit in the allotted space, then it will have
to be mounted elsewhere; either within the building on a
perpendicular wall which is not subjected to excessive
temperature, vibration, humidity, dust, corrosive gas,

explosive gas, etc., or within an appropriate enclosure
rated for outside installation to safeguard against
moisture, dust and excessive heat. A terminal block
located in the control box is provided fo r fiel d co nn ection
of the VFD controls.

• IntelliSpeed™ Supply Fan Control Option (ASHRAE

90.1 compliant, section 6.4.3.10) - Units configured with

the IntelliSpeed™ Supply Fan Option will contain a VFD
for variable volume supply fan operation. This option
allows the supply fan RPM to vary based on the number
of compressors or heating stages energized. The
economizer's minimum position will also be configurable
to vary based on the supply fan VFD frequency output.

• Aluminized Steel Gas Heat Exchanger - For
applications in non-corrosive environments.

• Stainless Steel Gas Heat Exchanger
in corrosive environments, this option provides a full
stainless steel heat exchanger assembly.

• Stainless Steel Drain Pan - An optional rust-proof
stainless steel drain pan is available to provide years of
trouble-free operation in corrosive environments.

• Electric Heaters - The electric heaters range from 3kW to
54kW and are available in all the voltage options of the
base units. All heaters are intended for single point power
supply.

• Disconnect Switch - For gas heat units and cooling units
with electric heat, a HACR breaker sized to the unit is
provided. For cooling only units, a switch sized to the
largest electric heat available for the particular unit is
provided. Factory installed option only.

• Convenience Outlet - (Non-Powered/Powered) - This
option locates a 120V single-phase GFCI outlet with cover,
on the corner of the unit housing adjacent to the
compressors. The “Non-powered” option requires the
installer to provide the 120V single-phase power source and
wiring. The “Powered” option is powered by a stepdown
transformer in the unit. Factory installed option only.

• Smoke Detectors - The smoke detectors stop operation
of the unit by interrupting power to the control board if
smoke is detected within the air compartment. Available
for both the supply and/or return air configurations.

• Filters - 2” Pleated MERV 7 or 4” Pleated MERV 13 are
available to meet LEED requirements. A 2” Throwaway is
shipped as standard.

Factory-installed smoke detectors may be subjected to
extreme temperatures during "off" times due to outside air
infiltration. These smoke detectors have an operational
limit of -4°F to 158°F. Smoke detectors installed in areas
that could be outside this range will have to be relocated to
prevent false alarms.

• Phase Monitors - Designed to prevent unit damage. The
phase monitor will shut the unit down in an out-of phase
condition. (Standard on units with Scroll Compressors.)

- For applications

Johnson Controls Unitary Products 7

528150-YTG-T-0514

• Coil Guard - Customers can purchase a coil guard kit to
protect the condenser coil from damage. Additionally, this
kit stops animals and foreign objects from entering the
space between the inner condenser coil and the main
cabinet. This is not a hail guard kit.

• Dirty Filter Switch - This kit includes a differential
pressure switch that energizes the fault light on the unit
thermostat, indicating that there is an abnormally high
pressure drop across the filters. Factory installed option or
field installed accessory.

• Technicoat Condenser Coils - The condenser coils are
coated with a phenolic coating for protection against
corrosion due to harsh environments.

• Technicoat Evaporator Coil - The evaporator coils are
coated with a phenolic coating for protection against
corrosion due to harsh environments.

• ElectroFin® E-coat Condenser Coils - The condenser
coils are coated with an epoxy polymer coating to protect
against corrosion.

• ElectroFin® E-coat Evaporator Coils - The evaporator
coils are coated with an epoxy polymer coating to protect
against corrosion.

• Hot Gas Bypass - Allows operation during low load
conditions while avoiding coil frosting and damage to
compressor. When suction pressure falls below valve
setpoint, the valve modulates hot gas to the inlet of the
evaporator. HGBP is standard on all units with VAV and
optional with constant-volume units.

Control Options

• Simplicity® INTELLI-Comfort II™ Control communicates
on a MODBUS RTU protocol network - The York®

Simplicity

It includes a supply air sensor, a return air sensor, and an
outside air sensor. There are provisions for a field installed
dirty filter indicator switch, an air-proving switch, an Outside
Air Humidity sensor, a Return Air Humidity sensor, an
Inside IAQ sensor, and an Outside Air IAQ sensor.
Construction mode operation, 365-day real time clock with
7 day programming plus holiday scheduling is built-in. Two
different modes of demand ventilation are achieved through
the INTELLI-Comfort II™ using CO
inside CO
also use an Outside CO2 sensor to perform Differential
Demand Ventilation. It uses a Patented Comfort Ventilation
algorithm to provide comfortable ventilation air
temperature. The patented economizer-loading algorithm
will protect the equipment when harsh operating conditions
exist. Humidity in the occupied space or return duct can be
monitored and controlled via humidity sensors and the on­board connection for hot gas re-heat system. It uses the
INTELLI-Start™ algorithm to maximize energy savings by
recovering the building from the Unoccupied Setpoints to
the Occupied Setpoints just in time for the Occupied Time
Period to begin. The Simplicity
balances space temperature, ventilation air temperature,
CO

• Simplicity® INTELLI-Comfort II™ with Simplicity®LINC
Control - The York® Simplicity
with Simplicity®LINC control is factory installed. It

®

INTELLI-Comfort II™ control is factory installed.

sensors. It uses an

sensor to perform Demand Ventilation. It can

2

and humidity for ultimate comfort.

2

2

®

INTELLI-Comfort II™

®

INTELLI-Comfort II™

includes all the features of the INTELLI-Comfort II™
control with an additional control to translate
communications from MODBUS to the BACnet MSTP
protocol.

• Novar® BAS Control - The Novar® building automation
system controller is factory installed. Includes supply air
sensor, return air sensor, dirty filter indicator switch, and
air proving switch.

• Johnson Controls BAS Control - The Johnson Control
YK-UNT-1126 building automation system controller is
factory installed. Includes supply air sensor, return air
sensor, dirty filter indicator switch, and air proving switch.

• CPC BAS Control - The Computer Process Controls
Model 810-3060 ARTC Advanced Rooftop building
automation system controller is factory installed. Includes
supply air sensor, return air sensor, dirty filter indicator
switch and air proving switch.

• Honeywell BAS Control - The Honeywell W7750C
building automation system controller is factory installed.
Includes air supply sensor, return air sensor, dirty filter
indicator switch, and air proving switch.

• York Commercial Comfort System (YCCS) - Provides
rooftop system integration for YCCS single zone and
change-over bypass systems.

Field Installed Accessories

YORK® offers several equipment accessories for field
installation, for the Predator

• Downflow Slab Economizers (with fresh air hood and
without barometric relief) - All units offer a variety of
optional factory installed down flow economizers that are
shipped, installed and wired with low leak dampers designed
to meet ASHRAE 90.1-2010, AMCA 511 Class 1A damper,
and the International Energy Conservation Code (IECC)
certification requirements by achieving leakage rates of 3
cfm/sq. ft. at 1" of static pressure. Each econo mizer goes
through a rigorous 60,000 cycle test. Dry bulb, single
enthalpy, and dual enthalpy (with field installed kit) can be
selected. The economizer has spring return, fully modulating
damper actuators and is capable of introducing up to 100%
outdoor air. As the outdoor air intake dampers open, the
return air dampers close. The changeover from mechanical
refrigeration to economizer operation is regulated by the
outdoor air dry bulb temperature or the outdoor air enthalpy
input. The dual enthalpy kit provides a second input used to
monitor the return air (field installed). The installer needs only
to assemble the outdoor air hood, attach the enthalpy control
the hood and mount the hood to the unit (Hood and control
are provided).

• Horizontal Economizer - (Without barometric relief ) -

All features of the downflow economizer exist except
economizer is not designed with low leak dampers and
you must order the duct mount barometric relief
separately. You must order a 1EH0408 if you are

installing a power exhaust. You can order a 1RD0411
Barometric Relief for horizontal flow economizers
only.

• Dual Enthalpy Control, Accessory - This kit contains
the required components to convert a single enthalpy
economizer to dual enthalpy.

®

line.

8 Johnson Controls Unitary Products

528150-YTG-T-0514

• Barometric Relief Damper - Zero to 100% capacity
barometric relief dampers for use with horizontal flow, or
field installed slab economizers.

• Power Exhaust - This accessory installs in the unit with a
down flow economizer. Power exhaust plugs into the
connector in the unit bulkhead. You must purchase

1EH0408 barometric relief when applying to a
horizontal flow application.

• Manual Outdoor Air Damper - Like the motorized outdoor
air damper, each manual outdoor air damper includes a
slide-in damper assembly with an outdoor air hood and
filters. Customers have a choice of dampers with ranges of
0% to 100% or 0% to 35% outdoor air entry.

• Motorized Outdoor Air Damper - The motorized outdoor
air damper includes a slide-in/plug-in damper assembly with
an outdoor air hood and filters. The outdoor air dampers
open to the preset position when the indoor fan motor is
energized. The damper has a range of 0% to 100% outdoor
air entry. Factory installed option or field installed accessory.

• Smoke Detectors - The smoke detectors stop operation
of the unit by interrupting power to the control board if
smoke is detected within the air compartment.

Sensor - Senses CO2 levels and automatically

• CO

2

overrides the economizer when levels rise above the
preset limits.

• Dirty Filter Switch - This kit includes a differential
pressure switch that energizes the fault light on the unit
thermostat, indicating that there is an abnormally high
pressure drop across the filters.

• Coil Guard - Field installed decorative wire coil guard.

• Hail Guard - This kit includes a sloped hood which installs
over the outside condenser coil and prevents damage to
the coil fins from hail strikes. Field installed accessory only.

• Flue Exhaust Extension Kit - In locations with wind or
weather conditions which may interfere with proper
exhausting of furnace combustion products, this kit can be
installed to prevent the flue exhaust from entering nearby
fresh air intakes.

• -60°F Gas Heat Kit - For installations which require gas
heat units to perform in low ambient temperatures, a gas
section heating kit is available. This kit provides electric
heat in the gas heat controls section to ensure the gas
valve and controls will continue to function properly at
extremely low temperatures.

• Gas Heat High Altitude Kit - This kit converts a gas heat
unit to operate at high altitudes, 2,000 to 6,000 feet.
Conversion kits are available for natural gas and propane.

• Gas Heat Propane Conversion Kit - This kit converts a
gas-fired heater from natural gas to propane. It contains the
main burner orifices and gas valve replacement springs.

• Gas Piping Kit - Contains pipe nipples, fittings and gas cock
required for gas supply connection with external shut off.

• Electric Heaters - The electric heaters range from 3kW to
54kW and are available in all the voltage options of the
base units. The 54kW/208-240 volt, field-installed heater
kit is not available with VAV units due to a lack of space to
accommodate the heater’s fuse block accessory.

All heaters are dual staged. Cooling units include an
adapter panel for easy installation of the electric heaters.
Necessary hardware and connectors are included with the
heaters. All heaters are intended for single point power
supply.

• Low Limit / Compressor Lockout Kit

• Compressor Lockout (CLO): To prevent mechanical

(compressorized) operation of the unit during cold
outdoor conditions where there is a risk of returning
liquid refrigerant back to the compressors.

• Low Limit Control (LLC): To prevent the supply air

from dropping below a specified setpoint by utilizing the
units first stage heating means when there is a demand
for cooling during cold outside conditions.

• Metal Frame Filter Kit - Metal frame with polyester filter
medium.

• Permanent Filters - Permanent filters are available.

• Roof Curbs - The roof curbs have insulated decks and are
shipped disassembled The roof curbs are available in 8” and
14” heights. For applications with security concerns, burglar
bars are available for the duct openings of the roof curbs.

• Roof Curb Transition - Single Piece Adapter (10” High) ­Roof curbs for transitioning from Sunline™ units to
Predator

®

units. Fits 7.5 to 12.5 Sunline™ roof curbs only.

• Burglar Bars - Mount in the supply and return openings
to prevent entry into the duct work.

• Thermostat - The units are designed to operate with 24­volt electronic and electro-mechanical thermostats. All 6.5
thru 12.5 ton ZH,ZJ units and all 3 thru 12.5 ton ZR units
(with or without an economizer) operate with two-stage
heat/two-stage cool or two-stage cooling only
thermostats, depending upon unit configuration.

Johnson Controls Unitary Products 9

528150-YTG-T-0514

Accessories

Field Installed Accessories - Non-Electrical

MODEL VOLTAGE DESCRIPTION WHERE USED

1BD0408 All Burglar Bars, Downflow All Cabinets

(Electric / Electric Models), 50” Tall Standard
1CG0419 All Coil Guard
1CG0420 All Coil Guard (Gas / Electric Models), 50" Tall Standard Cabinets
1CG0427 All Coil Guard (Electric / Electric Models), 42” Tall Cabinets
1CG0428 All Coil Guard (Gas / Electric Models), 42" Tall Cabinets

1HG0411 All Hail Guard Kit
1HG0415 All Hail Guard Kit All Short (42") Standard Cabinets
1FE0412 All Flue Exhaust Extension Kit All Cabinets
1FF0414 All 2" only Metal Filter Frame Kit All Tall 50" Cabinets
1FF0415 All 2" only Metal Filter Frame Kit All Tall 42" Cabinets
1FL0402 All Permanent 2" only Filter Kit Includes (4) Four Filters) All Tall 50" Cabinets
1FL0423 All Permanent 2" only Filter Kit (Includes (4) four Filters) All Tall 42" Cabinets
1GP0405 All Gas Piping Kit All Cabinets
1HA0442 All High Altitude Kit for Natural Gas All 6 - 12T Cabinets
1HA0450 All High Altitude Kit for Natural Gas 3 - 5T (80, 120 & 160 MBH Input)
1HA0451 All High Altitude Kit for Natural Gas 3 - 4T (60 MBH Input)
1HA0443 All High Altitude Kit for Propane All 6 - 12T Cabinets
1HA0452 All High Altitude Kit for Propane 3 - 5T (80, 120 & 160 MBH Input)
1HA0453 All High Altitude Kit for Propane 3 - 4T (60 MBH Input)
1NP0442 All Propane Conversion Kit All 6 - 12T Cabinets
1NP0454 All Propane Conversion Kit 3 - 5T (80, 120 & 160 MBH Input)
1NP0455 All Propane Conversion Kit 3 - 4T (60 MBH Input)
1RC0470 All Roof Curb, 8" Height All Cabinets
1RC0471 All Roof Curb, 14" Height All Cabinets

1RC0472 All

1WC0412 All
1LN0407 All Low NOx Kit 3 - 5T (80, 120 & 160 MBH Input)
1LN0408 All Low NOx Kit 3 - 5T (60 MBH Input)

Roof Curb, Transition (7.5 T thru 12.5T Sunline to Predator 3­12T) All Cabinets
Wooden Crate for extra protection during shipping and
handling

Cabinets

All Tall (50") Standard Cabinets, (Excludes 12.5T

"V" cabinets)

Standard Cabinets Only (not applicable to units

119" in length)

10 Johnson Controls Unitary Products

Accessories (Continued)

Field Installed Accessories - Electric Heat

MODEL VOLTAGE DESCRIPTION WHERE USED

2TP04520925 230

9kW Electric Heat All 50" Cabinet 6.5 and 8.5 Ton Models2TP04520946 460
2TP04520958 575
2TP04531825 230

18kW Electric Heat All 50" Cabinet 6.5, 8.5, 10 and 12.5 Ton Models2TP04531846 460
2TP04521858 575
2TP04532425 230

24kW Electric Heat All 50" Cabinet 6.5, 8.5, 10 and 12.5 Ton Models2TP04532446 460
2TP04522458 575
2TP04533625 230

36kW Electric Heat All 50" Cabinet 6.5, 8.5, 10 and 12.5 Ton Models2TP04533646 460
2TP04523658 575
2TP04525425 230

54kW Electric Heat All 50" 10 and 12.5 Ton Models2TP04525446 460
2TP04525458 575
2TP04540925 230

9kW Electric Heat All 42" Cabinet 6.5, 7.5 and 8.5 Ton Models2TP04540946 460
2TP04540958 575
2TP04541825 230

18kW Electric Heat All 42" 6.5, 7.5 and 8.5 Ton Models2TP04541846 460
2TP04541858 575
2TP04542425 230

24kW Electric Heat All 42" Cabinet 6.5, 7.5 and 8.5 Ton Models2TP04542446 460
2TP04542458 575
2TP04543625 230

36kW Electric Heat All 42" Cabinet 6.5, 7.5 and 8.5 Ton Models2TP04543646 460
2TP04543658 575
2TP04510325 230
2TP04510346 460
2TP04510625 230
2TP04510646 460
2TP04510825 230

2TP04510858 575
2TP04511525 230

2TP04511558 575
2TP04512025 230

2TP04512058 575
2TP04512325 230

2TP04512358 575

3kW Electric Heat All 42" Cabinet 3 Ton Models

6kW Electric Heat All 42" Cabinet 3, 4 and 5 Ton Models

9kW Electric Heat All 42" Cabinet 3, 4 and 5 Ton Models2TP04510846 460

15kW Electric Heat All 42" Cabinet 3, 4 and 5 Ton Models2TP04511546 460

20kW Electric Heat All 42" 4 and 5 Ton Models2TP04512046 460

24kW Electric Heat All 42" Cabinet 5 Ton Models2TP04512346 460

528150-YTG-T-0514

Johnson Controls Unitary Products 11

528150-YTG-T-0514

Accessories (Continued)

Field Installed Accessories - Fresh Air

MODEL VOLTAGE DESCRIPTION WHERE USED

1EH0408
1FA0413
1FA0414
1RD0411
2EC04700924

2EE04708324

2EE04707524
2EE04706024

2MD04703224
2MD04703724
2PE04704706*
2PE04704746*
2PE04704758*
* Must be installed in return Duct on Horizontal Applications and a 1EH0408 is required.

Field Installed Accessories - Controls

MODEL VOLTAGE DESCRIPTION WHERE USED

2AP0401 All Air Proving Switch All Units
2AQ04700324B All CO² Space Accessory All Units
2AQ04700424C All CO² Unit Accessory All Units
2DF0402 All Dirty Air Switch All Units
2DH04700024 All Humidistat All Units

2SD04700624 All Smoke Detector for Supply or Return
2SD04700824 All Smoke Detector for Supply All Gen 5 units with 2" & 4" Filters
2SD04700924 All Smoke Detector for Return All Gen 5 units with 2" & 4" Filters
2SD04701024 All Smoke Detector for Supply and Return All Gen 5 units with 2" & 4" Filters

All Barometric Relief Kit for Power Exhaust, Horizontal Application All Cabinets
All Manual Outside Air Damper 0-35%, Downflow All Cabinets
All Manual Outside Air Damper 0-100%, Downflow All Cabinets
All Barometric Relief Kit for Horizontal Applications All Cabinets
All Dual Enthalpy Control All Cabinets

All

All
All Horizontal Economizer without Barometric Relief All Cabinets

All Motorized Damper, Downflow without Barometric Relief All Cabinets

All Motorized Damper, Horizontal All Cabinets
230 Power Exhaust 230V Downflow or Horizontal All Cabinets
460 Power Exhaust 460V Downflow or Horizontal All Cabinets
575 Power Exhaust 575V Downflow or Horizontal All Cabinets

Downflow Economizer, Slab type for ERV & Downflow
Applications, (no Barometric Relief or FA hood)

Downflow Economizer, Slab type for ERV & Downflow
Applications, (no Barometric Relief or FA hood)

All 50" Cabinets

All 42" Cabinets

All Gen 4 or older units with 2" Filter only capable
Cabinets

Field Installed Accessories - Electrical

MODEL VOLTAGE DESCRIPTION WHERE USED

2BC04700106 230 Gas heat kit, -60ºF All Units
2BC04700151 460 Gas heat kit, -60ºF All Units
2BC04700154 575 Gas heat kit, -60ºF All Units
2LA04704632 All Low Ambient Kit All 3 - 10T units (excludes 12.5T "V" cabinets)

Guide Specifications

with gas heat. Electric heaters are available as factory-installed
options or field-installed accessories.

GENERAL

DESCRIPTION

Units shall be manufactured by Unitary Products in an ISO
9001 certified facility. YORK® Predator
single packages with a common footprint cabinet and common
roof curb for all 3 through 12-1/2 ton models. All 6-1/2 through
12-1/2 ton units have two compressors with independent R­410A refrigeration circuits to provide 2 stages of cooling. The
units were designed for light commercial applications and can
be easily installed on a roof curb, slab, or frame. All Predator
units are self-contained and assembled on rigid full perimeter
base rails allowing for 3-way forklift access and overhead
rigging. Every unit is completely charged with R-410A, wired,
piped, and tested at the factory to provide a quick and easy
field installation. All units are convertible between side and
down airflow. Independent economizer designs are used on
side and down discharge applications, as well as all tonnage
sizes. Predator

®

units are available in the following
configurations: cooling only, cooling with electric heat, cooling
with gas heat, reheat only, reheat with electric heat and reheat

®

units are convertible

Units shall be factory assembled, single package, (Elec/Elec, Gas/
Elec), designed for outdoor installation. They shall have built in
field convertible duct connections for down discharge supply/return
or horizontal discharge supply/return and be available with factory
installed options or field installed accessories. The units shall be
factory wired, piped and charged with R-410A refrigerant and

®

factory tested prior to shipment. All unit wiring shall be both
numbered and color coded. The cooling performance shall be
rated in accordance with DOE and AHRI test procedures. Units
shall be CSA certified to ANSI Z21.47 and UL 1995/CAN/CSA No.
236-M90 standards.

UNIT CABINET

Unit cabinet shall be constructed of galvanized steel with
exterior surfaces coated with a non-chalking, powder paint
finish, certified at 1000 hour salt spray test per ASTM-B117

12 Johnson Controls Unitary Products

528150-YTG-T-0514

standards. Indoor blower sections shall be insulated with up to
1” thick insulation coated on the airside. Either aluminum foil
faced or elastometric rubber insulation shall be used in the
unit’s compartments and be fastened to prevent insulation from
entering the air stream. Cabinet doors shall be hinged with
toolless access for easy servicing and maintenance. Full
perimeter base rails shall be provided to assure reliable transit
of equipment, overhead rigging, fork truck access and proper
sealing on roof curb applications. Disposable 2” filters shall be
furnished as standard and be accessible through hinged access
door. Fan performance measuring ports shall be provided on
the outside of the cabinet to allow accurate air measurements
of evaporator fan performance without removing panels or
creating bypass of the coils. Condensate pan shall be slide out
design, constructed of a non corrosive material, internally
sloped and conforming to ASHRAE 62-B9 standards.
Condensate connection shall be a minimum of ¾” I.D. female
and be rigid mount connection.

INDOOR (EVAPORATOR) FAN ASSEMBLY

Fan shall be a belt drive assembly and include an adjustable
pitch motor pulley. Job site selected brake horsepower shall not
exceed the motors nameplate horsepower rating plus the ser­vice factor. Units shall be designed to operate within the service
factor. Fan wheel shall be double inlet type with forward curve
blades, dynamically balanced to operate smoothly throughout
the entire range of operation. Airflow design shall be constant
volume. Bearings shall be sealed and permanently lubricated
for longer life and no maintenance. Entire blower assembly and
motor shall be slide out design.

OUTDOOR (CONDENSER) FAN ASSEMBLY

The outdoor fans shall be of the direct drive type, discharge air
vertically, have aluminum blades riveted to corrosion resistant
steel spider brackets and shall be dynamically balanced for
smooth operation. The outdoor fan motors shall have permanently
lubricated bearings internally protected against overload
conditions and staged independently. A cleaning window shall be
provided on two sides of the units for coil cleaning.

REFRIGERANT COMPONENTS

Compressors:

a. Shall be fully hermetic type, direct drive, internally

protected with internal high-pressure relief and over
temperature protection. The hermetic motor shall be
suction gas cooled and have a voltage range of + or –
10% of the unit nameplate voltage.

b. Shall have internal spring isolation and sound muffling to

minimize vibration and noise, and be externally isolated
on a dedicated, independent mounting.

Coils:

a. Evaporator coils shall have aluminum plate fins

mechanically bonded to seamless internally enhanced
copper tubes with all joints brazed. Special Phenolic
coating shall be available as a factory option.

b. Evaporator coils shall be of the direct expansion, draw-

thru design.

c. Condenser coils shall have aluminum plate fins

mechanically bonded to seamless internally enhanced
copper tubes with all joints brazed or Micro-Channel
aluminum tube, aluminum fins.

d. Condenser coils shall be of the draw-thru design.

Refrigerant Circuit and Refrigerant Safety Components shall
include:

a. Independent fixed-orifice or thermally operated

expansion devices.

b. Solid core filter drier/strainer to eliminate any moisture or

foreign matter.

c. Accessible service gage connections on both suction

and discharge lines to charge, evacuate, and measure
refrigerant pressure during any necessary servicing or
troubleshooting, without losing charge.

d. The 6-1/2 through 12-1/2 ton unit shall have two

independent refrigerant circuits, equally split in 50%
capacity increments.

Unit Controls:

a. Unit shall be complete with self-contained low-voltage

control circuit protected by a resettable circuit breaker on
the 24-volt transformer side.

b. Unit shall incorporate a lockout circuit which provides

reset capability at the space thermostat or base unit
should any of the following standard safety devices trip
and shut off compressor:

• Loss-of-charge/Low-pressure switch.

• High-pressure switch.

• Freeze-protection thermostat, evaporator coil. If any of
the above safety devices trip, an LED (light-emitting
diode) indicator shall flash a diagnostic code that
indicates which safety switch has tripped.

c. Unit shall incorporate “AUTO RESET” compressor over

temperature, over current protection.

d. Unit shall operate with conventional thermostat designs

and have a low voltage terminal strip for easy hook-up.

e. Unit control board shall have on-board diagnostics and

fault code display.

f. Standard controls shall include anti-short cycle and low

voltage protection, and permit cooling operation down to
0 ºF.

g. Control board shall monitor each refrigerant safety switch

independently.

h. Control board shall retain last 5 fault codes in non-

volatile memory, which will not be lost in the event of a
power loss.

GAS HEATING SECTION (IF EQUIPPED)

Heat exchanger and exhaust system shall be constructed of
aluminized steel and shall be designed with induced draft com­bustion with post purge logic, energy saving direct spark igni­tion, and redundant main gas valve. The heat exchanger shall

Johnson Controls Unitary Products 13

528150-YTG-T-0514

be of the tubular type, constructed of T1-40 aluminized steel for
corrosion resistance and allowing minimum mixed air entering
temperature of 40 ºF. Burners shall be of the in-shot type, con­structed of aluminum-coated steel. All gas piping shall enter the
unit cabinet at a single location, through either the side or bot­tom, without any field modifications. An integrated control board
shall provide timed control of evaporator fan functioning and
burner ignition. Heating section shall be provided with the fol­lowing minimum protection:

a. Primary and auxiliary high-temperature limit switches.
b. Induced draft pressure sensor.
c. Flame roll out switch (manual reset).
d. Flame proving controls.
e. All two stage gas units shall have two independent

stages of capacity (70% or 75% 1st stage, 100% 2nd
stage) 3 through 5 ton and (60% 1st stage, 100% 2nd
stage) 6-1/2 through 12-1/2 ton.

ELECTRIC HEATING SECTION (IF EQUIPPED)

An electric heating section, with nickel chromium elements,
shall be provided in a range of 3 thru 54KW. The heating sec­tion shall have a primary limit control(s) (automatic reset) to pre­vent the heating element system from operating at an
excessive temperature. The Heating Section assembly shall
slide out of the unit for easy maintenance and service. Units
with Electric Heating Sections shall be wired for a single point
power supply with branch circuit fusing (where required).

UNIT OPERATING CHARACTERISTICS

Unit shall be capable of starting and running at 125 ºF outdoor
temperature, exceeding maximum load criteria of AHRI Stan­dard 340/360. The compressor, with standard controls, shall be
capable of operation down to 0 ºF outdoor temperature. Unit
shall be provided with fan time delay to prevent cold air delivery
before heat exchanger warms up. (Gas heat only)

ELECTRICAL REQUIREMENTS - All unit power wiring shall
enter unit cabinet at a single factory provided location and be
capable of side or bottom entry to minimize roof penetrations
and avoid unit field modifications. Separate side and bottom
openings shall be provided for the control wiring.

ST ANDARD LIMITED WARRANTIES - Compressor – 5 Years,
Heat Exchanger – 10 Years, Elect. Heat Elem. – 5 Years,
Parts – 1 Year

OPTIONAL OUTDOOR AIR (Shall be made available by either/
or):

• ELECTRONIC ENTHALPY AUTOMATIC ECONOMIZER

- Outdoor and return air dampers that are interlocked and
positioned by a fully-modulating, spring-return damper
actuator. The maximum leakage rate for the outdoor air
intake dampers shall be designed to meet ASHRAE 90.1­2010, AMCA 511 Class 1A damper, and the International
Energy Conservation Code (IECC) certification
requirements by achieving leakage rates of 3 cfm/sq. ft. at
1" of static pressure. During economizer operation, a

mixed-air temperature control shall modulate the outdoor
and return air damper assembly to prevent the supply air
temperature from dropping below 55°F. Changeover from
compressor to economizer operation shall be provided by
an integral electronic enthalpy control that feeds input into
the basic module. The outdoor intake opening shall be
covered with a rain hood that matches the exterior of the
unit. Water eliminator/filters shall be provided.

Simultaneous economizer/compressor operation is also
possible. Dampers shall fully close on power loss.
Available with barometric relief and power exhaust.

• MOTORIZED OUTDOOR AIR DAMPERS - Outdoor and
return air dampers that are interlocked and positioned by
a 2- position, spring-return damper actuator. A unit­mounted potentiometer shall be provided to adjust the
outdoor and return air damper assembly to take in the
design CFM of outdoor air to meet the ventilation
requirements of the conditioned space during normal
operation. Whenever the indoor fan motor is energized,
the dampers open up to one of two pre-selected positions

- regardless of the outdoor air enthalpy. Dampers return to
the fully closed position when the indoor fan motor is de­energized. Dampers shall fully close on power loss.

ADDITIONAL FACTORY INSTALLED OPTIONS

• ALTERNATE INDOOR BLOWER MOTOR – For
applications with high restrictions, units are available with
optional indoor blower motors that provide higher static
output and/or higher airflow.

• VARIABLE AIR VOLUME (VAV) - The VAV option using
a variable frequency drive (VFD) shall be available on
6-1/2 through 12-1/2 ton models for applications requiring
a constant supply-duct static pressure. Units equipped for
VAV shall be controlled by a duct pressure transducer
with a 0 - 5" WC pressure range. The pressure transducer
shall provide a 0 - 5 VDC output signal to a VAV control
board which, in turn shall provide a 2 - 10 VDC speed
reference signal to the VFD. The VAV control board shall
operate using factory-installed Supply Air, Return Air and
Outside Air Temperature Sensors with a nominal
resistance of 10,000 Ohms. Units equipped with VFD's
shall have factory-installed manual bypass as an option.

• CONVENIENCE OUTLET (POWERED/NON-POWERED)–
Unit can be provided with an optional 120VAC GFCI outlet
with cover on the corner of the unit housing the compressors.

• ELECTRIC HEAT - Electric Heaters range from 3kW to
54kW and are available in all the voltage options of the
base unit.

• PHASE MONITOR - Designed to prevent damage in out­of-phase condition.

• COIL GUARD - Designed to prevent condenser coil
damage.

• BAS CONTROLS - Include supply air sensor, return air
sensor, dirty filter indicator and air proving switch.

• DIRTY FILTER SWITCH – This kit includes a differential
pressure switch that energizes the fault light on the unit

14 Johnson Controls Unitary Products

528150-YTG-T-0514

thermostat, indicating that there is an abnormally high­pressure drop across the filters.

• BREAKER – An HACR breaker can be factory installed
on gas heat units or cooling units with electric heat.

• DISCONNECT SWITCH - A disconnect can be factory
installed on a cooling only units sized for the largest
electric heat available.

• STAINLESS STEEL HEAT EXCHANGER – For
applications in a corrosive environment, this option
provides a full stainless steel heat exchanger assembly.

• SMOKE DETECTOR – A smoke detector can be factory
mounted and wired in the supply and/or return air
compartments.

OTHER PRE-ENGINEERED ACCESSORIES AVAILABLE

• ROOF CURB - 14” and 8” high, full perimeter knockdown
curb, with hinged design for quick assembly.

• BAROMETRIC RELIEF DAMPER – (Unit mounted –
Downflow, Duct Mounted – Horizontal) – Contains a rain
hood, air inlet screen, exhaust damper and mounting
hardware. Used to relieve internal air pressure through
the unit during economizer operation.

• PROPANE CONVERSION KIT – Contains new orifices
and gas valve springs to convert from natural to L.P. gas.

• -60ºF GAS HEAT KIT – Provides an electric heat kit for
the gas compartment for use in extreme low ambient
conditions.

• ECONOMIZER (Downflow and Horizontal flow)

• POWER EXHAUST – (Unit mount – Downflow, Duct
mount – Horizontal flow)

• DUAL ENTHALPY KIT - Provides a second input to
economizer to monitor return air.

Johnson Controls Unitary Products 15

528150-YTG-T-0514

Physical Data

ZH037-061 Single Stage Gas Physical Data

Component

Nominal Tonnage 3.0 4.0 5.0

AHRI COOLING PERFORMANCE

Gross Capacity @ AHRI A point (MBh) 37000 50000 61000
AHRI net capacity (MBh) 36000 48000 58000
EER 11.8 11.8 11.8
SEER 14 14 14
IPLV --­CFM 1200 1600 2000
System power (KW) 3.05 4.07 4.90
Refrigerant type R-410A R-410A R-410A
Refrigerant charge (lb-oz)

System 1 7-4 6-14 7-12
System 2 ---

AHRI HEATING PERFORMANCE

Heating model A05 A07 A09 A05 A07 A09 A07 A09 A13
Heat input (K Btu) 60 80 120 60 80 120 80 120 160
Heat output (K Btu) 49 65 97 49 65 97 65 97 129
AFUE % - - - - - ­Steady state efficiency (%) 81.5 81 81 81.5 81 81 81 81 80.5
No. burners 446446468
No. stages 1 1 1 1 1 1 1 1 1
Temperature Rise Range (ºF) 20-50°F 25-65°F 50-80°F 20-50°F 25-65°F 40-70°F 25-65°F 35-65°F 45-75°F
Gas Limit Setting (ºF) 235°F 200°F 255°F 235°F 200°F 255°F 200°F 245°F 240°F
Gas piping connection (in.) 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4

DIMENSIONS (inches)

Length 89 89 89
Width 595959
Height 42 42 42

OPERATING WT. (lbs.) 723 763 864

COMPRESSORS

Type Recip Recip Recip
Quantity 1 1 1
Unit Capacity Steps (%) 100 100 100

CONDENSER COIL DATA

Face area (Sq. Ft.) 11.9 18.5 21.1
Rows 111
Fins per inch 23 23 23
Tube diameter (in./MM) 1/25 .71/18 .71/18
Circuitry Type 2-pass Microchannel 2-pass Microchannel 2-pass Microchannel

EVAPORATOR COIL DATA

Face area (Sq. Ft.) 8 8 10.6
Rows 333
Fins per inch 15 15 15
Tube diameter 0.375 0.375 0.375
Refrigerant control TXV TXV TXV

ZH037 ZH049 ZH061

Models

16 Johnson Controls Unitary Products

ZH037-061 Single Stage Gas Physical Data (Continued)

528150-YTG-T-0514

Component

ZH037 ZH049 ZH061

Models

Nominal Tonnage 3.0 4.0 5.0

CONDENSER FAN DATA

Quantity of fans 1 1 2
Fan diameter (Inch) 24 24 24
Type Prop Prop Prop
Drive type Direct Direct Direct
Quantity of motors 1 1 2
Motor HP each 1/3 1/3 1/3
No. speeds 1 1 1
RPM 850 850 850
Total CFM 3300 3700 6700

BELT DRIVE EVAP FAN DATA

Quantity 1 1 1
Fan Size (Inch) 12 x 9 12 x 9 12 x 9
Type Centrifugal Centrifugal Centrifugal
Motor Sheave 1VM34 1VL44 1VM34 1VL44 1VL40 1VP56
Blower Sheave AK69 AK69 AK56 AK56 AK61 AK74
Belt A47 A47 A47 A47 A47 A51
Motor HP each 1-1/2 1-1/2 1-1/2 1-1/2 1-1/2 2
RPM 1725 1725 1725 1725 1725 1725
Frame size 56 56 56 56 56 56

FILTERS

Quantity - Size

1. 2 In. Throwaway, Standard, MERV (Minimum Efficiency Reporting Value)

2. 2 In. Pleated, Optional, MERV 7.

3. 4 In. Pleated, Optional, MERV 13.

4 - (24 x 16 x 2)

4 - (24 x 16 x 4)

1,2

3

4 - (24 x 16 x 4)

4 - (24 x 16 x 2)

1,2

3

4 - (24 x 16 x 4)

4 - (24 x 16 x 2)

1,2

3

Johnson Controls Unitary Products 17

528150-YTG-T-0514

ZH037-061 Two Stage Gas Physical Data

Component

ZH037 ZH049 ZH061

Models

Nominal Tonnage 3.0 4.0 5.0

AHRI COOLING PERFORMANCE

Gross Capacity @ AHRI A point (MBh) 37000 50000 61000
AHRI net capacity (MBh) 36000 48000 58000
EER 11.8 11.8 11.8
SEER 14 14 14
IPLV --­CFM 1200 1600 2000
System power (KW) 3.05 4.07 4.90
Refrigerant type R-410A R-410A R-410A
Refrigerant charge (lb-oz)

System 1 7-4 6-14 7-12
System 2 ---

AHRI HEATING PERFORMANCE

Heating model N05 N07 N09 N05 N07 N09 N07 N09 N13
Heat input (K Btu) 60 80 120 60 80 120 80 120 160
Heat output (K Btu) 49 65 97 49 65 97 65 97 129
AFUE % - - - - - ­Steady state efficiency (%) 81.5 81 81 81.5 81 81 81 81 80.5
No. burners 446446468
No. stages 2

1

2

2

2

2

1

2

2

2

2

2

2

2

2

2

2

2
Temperature Rise Range (ºF) 20-50°F 25-65°F 50-80°F 20-50°F 25-65°F 40-70°F 25-65°F 35-65°F 45-75°F
Gas Limit Setting (ºF) 235°F 200°F 255°F 235°F 200°F 255°F 200°F 245°F 240°F
Gas piping connection (in.) 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4

DIMENSIONS (inches)

Length 89 89 89
Width 595959
Height 42 42 42

OPERATING WT. (lbs.) 723 763 864

COMPRESSORS

Type Recip Recip Recip
Quantity 1 1 1
Unit Capacity Steps (%) 100 100 100

CONDENSER COIL DATA

Face area (Sq. Ft.) 11.9 18.5 21.1
Rows 111
Fins per inch 23 23 23
Tube diameter (in./MM) 1/25 .71/18 .71/18
Circuitry Type 2-pass Microchannel 2-pass Microchannel 2-pass Microchannel

EVAPORATOR COIL DATA

Face area (Sq. Ft.) 8 8 10.6
Rows 333
Fins per inch 15 15 15
Tube diameter 0.375 0.375 0.375
Refrigerant control TXV TXV TXV

18 Johnson Controls Unitary Products

ZH037-061 Two Stage Gas Physical Data (Continued)

528150-YTG-T-0514

Component

ZH037 ZH049 ZH061

Models

Nominal Tonnage 3.0 4.0 5.0

CONDENSER FAN DATA

Quantity of fans 1 1 2
Fan diameter (Inch) 24 24 24
Type Prop Prop Prop
Drive type Direct Direct Direct
Quantity of motors 1 1 2
Motor HP each 1/3 1/3 1/3
No. speeds 1 1 1
RPM 850 850 850
Total CFM 3300 3700 6700

BELT DRIVE EVAP FAN DATA

Quantity 1 1 1
Fan Size (Inch) 12 x 9 12 x 9 12 x 9
Type Centrifugal Centrifugal Centrifugal
Motor Sheave 1VM34 1VL44 1VM34 1VL44 1VL40 1VP56
Blower Sheave AK69 AK69 AK56 AK56 AK61 AK74
Belt A47 A47 A47 A47 A47 A51
Motor HP each 1-1/2 1-1/2 1-1/2 1-1/2 1-1/2 2
RPM 1725 1725 1725 1725 1725 1725
Frame size 56 56 56 56 56 56

FILTERS

Quantity - Size

1. 1st Stage Capacity is 75% of Full Capacity.

st

Stage Capacity is 70% of Full Capacity.

2. 1

3. 2 In. Throwaway, Standard, MERV (Minimum Efficiency Reporting Value)

4. 2 In. Pleated, Optional, MERV 7.

5. 4 In. Pleated, Optional, MERV 13.

4 - (24 x 16 x 2)

4 - (24 x 16 x 4)

3,4

5

4 - (24 x 16 x 4)

4 - (24 x 16 x 2)

3,4

5

4 - (24 x 16 x 4)

4 - (24 x 16 x 2)

3,4

5

Johnson Controls Unitary Products 19

528150-YTG-T-0514

ZH078-150 Physical Data

Component

ZH078 ZH090 ZH102 ZH120 ZH150

Models

Nominal Tonnage 6.5 7.5 8.5 10 12.5

AHRI COOLING PERFORMANCE

Gross Capacity @ AHRI A point (Btu) 81000 93000 107000 125000 156000
AHRI net capacity (Btu) 78000 90000 102000 120000 150000
EER 11.7

/11.5

2

11.71/11.5

2

11.71/11.5

2

11.7 11.71/11.5

2

1

SEER - - - - ­IEER 12.8

/12.6

2

12.81/12.6

2

12.81/12.6

2

12 12.81/12.6

2

1

IPLV 13.7 13 13.5 12.9 14.1
CFM 2600 2700 3400 4000 3750
System power (KW) 6.69 7.70 9.0 10.40 12.80
Refrigerant type R-410A R-410A R-410A R-410A R-410A
Refrigerant charge (lb-oz)

System 1 7-0 6-0 7-6 8-8 8-2
System 2 6-0 6-0 7-2 7-7 8-2

AHRI HEATING PERFORMANCE

Heating model 10 15 10 15 10 15 15 20 15 20
Heat input (K Btu) 120 180 120 180 120 180 180 240 180 240
Heat output (K Btu) 96 144 96 144 96 144 144 192 144 192
AFUE % ----- ----­Steady state efficiency (%) 80 80 80 80 80 80 80 80 80 80
No. burners 46464 6 6868
No. stages 2

3

3

2

3

2

3

2

3

2

3

2

3

2

3

2

3

2

3

2
Temperature Rise Range (ºF) 20-50 35-65 15-45 30-60 10-40 25-55 20-50 35-65 10-40 25-55
Gas Limit Setting (ºF) 165 165 165 165 215 195 195 160 195 160
Gas piping connection (in.) 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4

DIMENSIONS (inches)

Length 89 89 89 89 119-1/2
Width 59 59 59 59 59
Height 42 42 50-3/4 50-3/4 50-3/4

OPERATING WT. (lbs.) 910 910 1047 1090 1280

COMPRESSORS

Type Recip Recip Recip Scroll Scroll
Quantity 2 2 2 2 2
Unit Capacity Steps (%) 50 / 100 50 / 100 50 / 100 50 / 100 50 / 100

CONDENSER COIL DATA

Face area (Sq. Ft.) 23.8 23.8 29.0 29.0 47.5
Rows 1 1 1 1 1
Fins per inch 23 23 23 23 23
Tube diameter (in./MM) 1/25 1/25 1/25 1/25 .71/18
Circuitry Type 2-pass Microchannel 2-pass Microchannel 2-pass Microchannel 2-pass Microchannel 2-pass Microchannel

EVAPORATOR COIL DATA

Face area (Sq. Ft.) 10.6 10.6 13.2 13.2 13.2
Rows 3 3 3 4 4
Fins per inch 15 15 15 15 15
Tube diameter 0.375 0.375 0.375 0.375 0.375
Circuitry Type Intertwined Intertwined Intertwined Intertwined Intertwined
Refrigerant control TXV TXV TXV TXV TXV

20 Johnson Controls Unitary Products

ZH078-150 Physical Data (Continued)

528150-YTG-T-0514

Component

ZH078 ZH090 ZH102 ZH120 ZH150

Models

Nominal Tonnage 6.5 7.5 8.5 10 12.5

CONDENSER FAN DATA

Quantity of fans 2 2 2 2 4
Fan diameter (Inch) 24 24 24 24 24
Type Prop Prop Prop Prop Prop
Drive type Direct Direct Direct Direct Direct
Quantity of motors 2 2 2 2 4
Motor HP each 1/3 3/4 3/4 3/4 1/3
No. speeds 1 1 1 1 1
RPM 850 1110 1110 1110 850
Total CFM 6700 8600 9400 9400 14000

BELT DRIVE EVAP FAN DATA

Quantity 1 1 1 1 1
Fan Size (Inch) 12 x 12 12 x 12 15 x 15 15 x 15 15 x 15
Type Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal
Motor Sheave 1VM50 1VM50 1VM50 1VM50 1VM50 1VM50 1VM50 1VM50 1VM50 1VP56
Blower Sheave AK74 AK64 AK74 AK61 AK94 AK74 AK84 AK74 AK74 BK77
Belt A49 A49 A49 A49 A56 A54 A56 A54 A54 BX55
Motor HP each 1-1/2 2 1-1/2 3 2 3 2 3 3 5
RPM 1725 1725 1725 1725 1725 1725 1725 1725 1725 1725
Frame size 56 56 56 56 56 56 56 56 56 184T

FILTERS

Quantity - Size

4 - (24 x 16 x 2)

4,5

4 - (24 x 16 x 2)

4 - (24 x 16 x 4)64 - (24 x 16 x 4)

4,5

4 - (24 x 20 x 2)

6

4 - (24 x 20 x 4)

4,5

4 - (24 x 20 x 2)

6

4 - (24 x 20 x 4)

4,5

4 - (24 x 20 x 2)

6

4 - (24 x 20 x 4)

1. Cooling Only Unit

2. Cooling Unit with Gas or Electric Heat

st

3. 1

Stage 60% of Full Capacity.

4. 2 In. Throwaway, Standard, MERV (Minimum Efficiency Reporting Value) 3.

5. 2 In. Pleated, Optional, MERV 7.

6. 4 In. Pleated, Optional, MERV 13.

4,5

6

Johnson Controls Unitary Products 21

528150-YTG-T-0514

ZJ037-061 Single Stage Gas Heat Physical Data

Component

Nominal Tonnage 3.0 4.0 5.0

AHRI COOLING PERFORMANCE

Gross Capacity @ AHRI A point (MBh) 37000 50000 62000
AHRI net capacity (MBh) 36000 48000 60000
EER 12.2 12.2 12.2
SEER 15 15 15
IPLV --­CFM 1300 1600 2000
System power (KW) 2.95 3.95 4.90
Refrigerant type R-410A R-410A R-410A
Refrigerant charge (lb-oz)

System 1 6-12 7-8 8-4
System 2 ---

AHRI HEATING PERFORMANCE

Heating model A05 A07 A09 A05 A07 A09 A07 A09 A13
Heat input (K Btu) 60 80 120 60 80 120 80 120 160
Heat output (K Btu) 49 65 97 49 65 97 65 97 129
AFUE % - - - - - ­Steady state efficiency (%) 81.5 81 81 81.5 81 81 81 81 80.5
No. burners 446446468
No. stages 1 1 1 1 1 1 1 1 1
Temperature Rise Range (ºF) 20-50°F 25-65°F 50-80°F 20-50°F 25-65°F 40-70°F 25-65°F 35-65°F 45-75°F
Gas Limit Setting (ºF) 235°F 200°F 255°F 235°F 200°F 255°F 200°F 245°F 240°F
Gas piping connection (in.) 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4

DIMENSIONS (inches)

Length 89 89 89
Width 595959
Height 42 42 42

OPERATING WT. (lbs.) 740 775 770

COMPRESSORS

Type Recip Recip Recip
Quantity 1 1 1
Unit Capacity Steps (%) 100 100 100

CONDENSER COIL DATA

Face area (Sq. Ft.) 18.5 23.8 23.8
Rows 111
Fins per inch 23 23 23
Tube diameter (in./MM) .71/18 .71/18 .71/18
Circuitry Type 2-pass Microchannel 2-pass Microchannel 2-pass Microchannel

EVAPORATOR COIL DATA

Face area (Sq. Ft.) 7.9 10.5 10.5
Rows 333
Fins per inch 15 15 15
Tube diameter 0.375 0.375 0.375
Refrigerant control TXV TXV TXV

ZJ037 ZJ049 ZJ061

Models

22 Johnson Controls Unitary Products

ZJ037-061 Single Stage Gas Heat Physical Data (Continued)

528150-YTG-T-0514

Component

ZJ037 ZJ049 ZJ061

Models

Nominal Tonnage 3.0 4.0 5.0

CONDENSER FAN DATA

Quantity of fans 1 1 2
Fan diameter (Inch) 24 24 24
Type Prop Prop Prop
Drive type Direct Direct Direct
Quantity of motors 1 1 2
Motor HP each 1/3 1/3 1/3
No. speeds 1 1 1
RPM 850 850 850
Total CFM 3300 3700 6300

BELT DRIVE EVAP FAN DATA

Quantity 1 1 1
Fan Size (Inch) 12 x 9 12 x 9 12 x 9
Type Centrifugal Centrifugal Centrifugal
Motor Sheave 1VM34 1VL44 1VM34 1VL44 1VL40 1VP56
Blower Sheave AK69 AK69 AK56 AK56 AK61 AK74
Belt A47 A47 A47 A47 A47 A51
Motor HP each 1-1/2 1-1/2 1-1/2 1-1/2 1-1/2 2
RPM 1725 1725 1725 1725 1725 1725
Frame size 56 56 56 56 56 56

FILTERS

Quantity - Size

1. 2 In. Throwaway, Standard, MERV (Minimum Efficiency Reporting Value)

2. 2 In. Pleated, Optional, MERV 7.

3. 4 In. Pleated, Optional, MERV 13.

4 - (24 x 16 x 2)

4 - (24 x 16 x 4)

1,2

3

4 - (24 x 16 x 4)

4 - (24 x 16 x 2)

1,2

3

4 - (24 x 16 x 4)

4 - (24 x 16 x 2)

1,2

3

Johnson Controls Unitary Products 23

528150-YTG-T-0514

ZJ037-061 Two Stage Gas Heat Physical Data

Component

ZJ037 ZJ049 ZJ061

Models

Nominal Tonnage 3.0 4.0 5.0

AHRI COOLING PERFORMANCE

Gross Capacity @ AHRI A point (MBh) 37000 50000 62000
AHRI net capacity (MBh) 36000 48000 60000
EER 12.2 12.2 12.2
SEER 15 15 15
IPLV --­CFM 1300 1600 2000
System power (KW) 2.95 3.95 4.90
Refrigerant type R-410A R-410A R-410A
Refrigerant charge (lb-oz)

System 1 6-12 7-8 8-4
System 2 ---

AHRI HEATING PERFORMANCE

Heating model N05 N07 N09 N05 N07 N09 N07 N09 N13
Heat input (K Btu) 60 80 120 60 80 120 80 120 160
Heat output (K Btu) 49 65 97 49 65 97 65 97 129
AFUE % - - - - - ­Steady state efficiency (%) 81.5 81 81 81.5 81 81 81 81 80.5
No. burners 446446468
No. stages 2

1

2

2

2

2

1

2

2

2

2

2

2

2

2

2

2

2
Temperature Rise Range (ºF) 20-50°F 25-65°F 50-80°F 20-50°F 25-65°F 40-70°F 25-65°F 35-65°F 45-75°F
Gas Limit Setting (ºF) 235°F 200°F 255°F 235°F 200°F 255°F 200°F 245°F 240°F
Gas piping connection (in.) 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4

DIMENSIONS (inches)

Length 89 89 89
Width 595959
Height 42 42 42

OPERATING WT. (lbs.) 740 775 770

COMPRESSORS

Type Recip Recip Recip
Quantity 1 1 1
Unit Capacity Steps (%) 100 100 100

CONDENSER COIL DATA

Face area (Sq. Ft.) 18.5 23.8 23.8
Rows 111
Fins per inch 23 23 23
Tube diameter (in./MM) .71/18 .71/18 .71/18
Circuitry Type 2-pass Microchannel 2-pass Microchannel 2-pass Microchannel

EVAPORATOR COIL DATA

Face area (Sq. Ft.) 7.9 23.8 10.5
Rows 333
Fins per inch 15 15 15
Tube diameter 0.375 0.375 0.375
Refrigerant control TXV TXV TXV

24 Johnson Controls Unitary Products

ZJ037-061 Two Stage Gas Heat Physical Data (Continued)

528150-YTG-T-0514

Component

ZJ037 ZJ049 ZJ061

Models

Nominal Tonnage 3.0 4.0 5.0

CONDENSER FAN DATA

Quantity of fans 1 1 2
Fan diameter (Inch) 24 24 24
Type Prop Prop Prop
Drive type Direct Direct Direct
Quantity of motors 1 1 2
Motor HP each 1/3 1/3 1/3
No. speeds 1 1 1
RPM 850 850 850
Total CFM 3300 3700 6300

BELT DRIVE EVAP FAN DATA

Quantity 1 1 1
Fan Size (Inch) 12 x 9 12 x 9 12 x 9
Type Centrifugal Centrifugal Centrifugal
Motor Sheave 1VM34 1VL44 1VM34 1VL44 1VL40 1VP56
Blower Sheave AK69 AK69 AK56 AK56 AK61 AK74
Belt A47 A47 A47 A47 A47 A51
Motor HP each 1-1/2 1-1/2 1-1/2 1-1/2 1-1/2 2
RPM 1725 1725 1725 1725 1725 1725
Frame size 56 56 56 56 56 56

FILTERS

Quantity - Size

1. 1st Stage Capacity is 75% of Full Capacity.

st

Stage Capacity is 70% of Full Capacity.

2. 1

3. 2 In. Throwaway, Standard, MERV (Minimum Efficiency Reporting Value)

4. 2 In. Pleated, Optional, MERV 7.

5. 4 In. Pleated, Optional, MERV 13.

4 - (24 x 16 x 2)

4 - (24 x 16 x 4)

3,4

5

4 - (24 x 16 x 4)

4 - (24 x 16 x 2)

3,4

5

4 - (24 x 16 x 4)

4 - (24 x 16 x 2)

3,4

5

Johnson Controls Unitary Products 25

528150-YTG-T-0514

ZJ078-150 Physical Data

Component

ZJ078 ZJ090 ZJ102 ZJ120 ZJ150

Models

Nominal Tonnage 6.5 7.5 8.5 10 12.5

AHRI COOLING PERFORMANCE

Gross Capacity @ AHRI A point (Btu) 80000 93000 106000 124000 154000
AHRI net capacity (Btu) 78000 90000 102000 120000 150000
EER 12.2

/12.0

2

12.21/12.0

2

12.21/12.0

2

12.0 12.0

1

SEER ----­IEER 14.0 13.1 12.2 12.8 13
IPLV 14.9 14.18 13.6 13.4 14.1
CFM 2600 2400 2800 3400 3500
System power (KW) 6.40 7.38 8.30 9.80 12.50
Refrigerant type R-410A R-410A R-410A R-410A R-410A
Refrigerant charge (lb-oz)

System 1 5-10 7-12 8-8 7-14 10-8
System 2 5-12 7-10 8-12 7-14 9-12

AHRI HEATING PERFORMANCE

Heating model 10 15 10 15 10 15 15 20 15 20
Heat input (K Btu) 120 180 120 180 120 180 180 240 180 240
Heat output (K Btu) 96 144 96 144 96 144 144 192 144 192
AFUE % ---------­Steady state efficiency (%) 80 80 80 80 80 80 80 80 80 80
No. burners 4646466868
No. stages 2

3

3

2

3

2

3

2

3

2

3

2

3

2

3

2

3

2

3

2
Temperature Rise Range (ºF) 20-50 35-65 15-45 30-60 10-40 25-55 20-50 35-65 10-40 25-55
Gas Limit Setting (ºF) 165 165 165 165 215 195 195 160 195 160
Gas piping connection (in.) 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4

DIMENSIONS (inches)

Length 89 89 89 89 119-1/2
Width 5959595959
Height 50-3/4 50-3/4 50-3/4 50-3/4 50-3/4

OPERATING WT. (lbs.) 1030 1050 1060 1070 1280

COMPRESSORS

Type Recip Recip Recip Scroll Scroll
Quantity 22222
Unit Capacity Steps (%) 50 / 100 50 / 100 50 / 100 50 / 100 50 / 100

CONDENSER COIL DATA

Face area (Sq. Ft.) 29.0 23.8 29.0 29.0 47.5
Rows 11111
Fins per inch 23 23 23 23 23
Tube diameter (in./MM) .71/18 1/25 1/25 1/25 .71/18
Circuitry Type 2-pass Microchannel 2-pass Microchannel 2-pass Microchannel 2-pass Microchannel 2-pass Microchannel

EVAPORATOR COIL DATA

Face area (Sq. Ft.) 13.2 13.2 13.2 13.2 13.2
Rows 34444
Fins per inch 15 15 15 15 15
Tube diameter 0.375 0.375 0.375 0.375 0.375
Circuitry Type Intertwined Intertwined Intertwined Intertwined Intertwined
Refrigerant control TXV TXV TXV TXV TXV

26 Johnson Controls Unitary Products

ZJ078-150 Physical Data (Continued)

528150-YTG-T-0514

Component

ZJ078 ZJ090 ZJ102 ZJ120 ZJ150

Models

Nominal Tonnage 6.5 7.5 8.5 10 12.5

CONDENSER FAN DATA

Quantity of fans 22224
Fan diameter (Inch) 24 24 24 24 24
Type Prop Prop Prop Prop Prop
Drive type Direct Direct Direct Direct Direct
Quantity of motors 22224
Motor HP each 1/3 3/4 3/4 3/4 1/3
No. speeds 11111
RPM 850 1110 1110 1110 850
Total CFM 7400 8000 9000 9400 14000

BELT DRIVE EVAP FAN DATA

Quantity 11111
Fan Size (Inch) 15 x 15 15 x 15 15 x 15 15 x 15 15 x 15
Type Centrifugal Centrifugal Centrifugal Centrifugal Centrifugal
Motor Sheave 1VL40 1VM50 1VL40 1VM50 1VM50 1VM50 1VM50 1VM50 1VM50 1VP56
Blower Sheave AK74 AK74 AK69 AK69 AK89 AK74 AK84 AK74 AK74 BK77
Belt A53 A 54 A52 A54 A56 A54 A56 A54 A54 BX55
Motor HP each 1-1/2 2 1-1/2 3 2 3 2 3 3 5
RPM 1725 1725 1725 1725 1725 1725 1725 1725 1725 1725
Frame size 56 56 56 56 56 56 56 56 56 184T

FILTERS

Quantity - Size

4 - (24 x 20 x 2)

4 - (24 x 20 x 4)

4,5

4 - (24 x 20 x 2)

6

4 - (24 x 20 x 4)

4,5

4 - (24 x 20 x 2)

6

4 - (24 x 20 x 4)

4,5

4 - (24 x 20 x 2)

6

4 - (24 x 20 x 4)

4,5

4 - (24 x 20 x 2)

6

4 - (24 x 20 x 4)6

4,5

1. Cooling Only Unit

2. Cooling Unit with Gas or Electric Heat

st

3. 1

Stage 60% of Full Capacity.

4. 2 In. Throwaway, Standard, MERV (Minimum Efficiency Reporting Value) 3.

5. 2 In. Pleated, Optional, MERV 7.

6. 4 In. Pleated, Optional, MERV 13.

Johnson Controls Unitary Products 27

528150-YTG-T-0514

ZR037-061 Single Stage Gas Heat Physical Data

Component

Nominal Tonnage 3 4 5

AHRI COOLING PERFORMANCE

Gross Capacity @ AHRI A point (Btu) 36500 49000 62000
AHRI net capacity (Btu) 35500 47500 60000
EER 12.2 12.2 12.2
SEER 15 15 14.7
IPLV ­CFM 1200 1600 2000
System power (KW) 2.88 3.32 4.83
Refrigerant type R-410A R-410A R-410A
Refrigerant charge (lb-oz)
System 1 12-8 12-0 11-0
System 2 - - -

AHRI HEATING PERFORMANCE

Heating model A05 A07 A09 A05 A07 A09 A07 A09 A13
Heat input (K Btu) 60 80 120 60 80 120 80 120 160
Heat output (K Btu) 49 65 97 49 65 97 65 97 129
AFUE % - - - - - ­Steady state efficiency (%) 81.5 81 81 81.5 81 81 81 81 80.5
No. burners 4 4 6 4 4 6 4 6 8
No. stages 1 1 1 1 1 1 1 1 1
Temperature Rise Range (ºF) 20-50°F 25-65°F 35-80°F 20-50°F 25-65°F 35-80°F 25-65°F 35-80°F 45-75°F
Gas Limit Setting (ºF) 200°F 235°F 290°F 200°F 235°F 290°F 235°F 290°F 240°F
Gas piping connection (in.) 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4

DIMENSIONS (inches)

Length 89 89 89
Width 59 59 59
Height 42 42 42

OPERATING WT. (lbs.) 867 880 867

COMPRESSORS

Type Recip Recip Recip
Quantity 1 1 1
Unit Capacity Steps (%) 100 100 100

CONDENSER COIL DATA

Face area (Sq. Ft.) 11.9 11.9 11.9
Rows 1 1 1
Fins per inch 23 23 23
Tube diameter (in./MM) .98/25 .98/25 .71/18 - .98/25
Circuitry Type 2-pass Microchannel 2-pass Microchannel 2-pass Microchannel

EVAPORATOR COIL DATA

Face area (Sq. Ft.) 10.56 10.56 10.56
Rows 3 3 4
Fins per inch 15 15 12
Tube diameter 0.375 0.375 0.375
Refrigerant control TXV TXV TXV

REHEAT COIL DATA

Face area (Sq. Ft.) 8.9 8.9 8.9
Rows 2 2 2
Fins per inch 15 15 15
Tube diameter 0.375 0.375 0.375
Refrigerant control Solenoid Solenoid Solenoid

ZR037 ZR049 ZR061

Models

-

-

28 Johnson Controls Unitary Products

528150-YTG-T-0514

ZR037-061 Single Stage Gas Heat Physical Data (Continued)

Component

ZR037 ZR049 ZR061

Nominal Tonnage 3 4 5

CONDENSER FAN DATA

Quantity of fans 1 2 2
Fan diameter (Inch) 24 24 24
Type Prop Prop Prop
Drive type Direct Direct Direct
Quantity of motors 1 2 2
Motor HP each 1/3 1/3 1/3
No. speeds Var. Var. Var.
RPM (max.) 850 850 850
Total CFM 3500 7000 7000

BELT DRIVE EVAP FAN DATA

Quantity 1 1 1
Fan Size (Inch) 12 x 9 12 x 9 12 x 9
Type Centrifugal Centrifugal Centrifugal
Motor Sheave 1VP34 1VL44 1VP34 1VL44 1VP34 1VL44
Blower Sheave AK61 AK59 AK61 AK59 AK61 AK59
Belt A47 A47 A47 A47 A47 A47
Motor HP each 1-1/2 1-1/2 1-1/2 1-1/2 1-1/2 2
RPM 1725 1725 1725 1725 1725 1725
Frame size 56 56 56 56 56 56

FILTERS

Quantity - Size

1. 2 In. Throwaway, Standard, MERV (Minimum Efficiency Reporting Value)

2. 2 In. Pleated, Optional, MERV 7.

3. 4 In. Pleated, Optional, MERV 13.

4 - (25 x 16 x 2)

4 - (25 x 16 x 4)

1, 2

3

Models

4 - (25 x 16 x 2)

4 - (25 x 16 x 4)

1, 2

3

4 - (25 x 16 x 4)

4 - (25 x 16 x 2)

1, 2

3

Johnson Controls Unitary Products 29

528150-YTG-T-0514

ZR037-061 Two Stage Gas Heat Physical Data

Component

ZR037 ZR049 ZR061

Nominal Tonnage 3 4 5

AHRI COOLING PERFORMANCE

Gross Capacity @ AHRI A point (Btu) 36500 49000 62000
AHRI net capacity (Btu) 35500 47500 60000
EER 12.2 12.2 12.2
SEER 15 15 14.7
IPLV - - ­CFM 1200 1600 2000
System power (KW) 2.88 3.32 4.83
Refrigerant type R-410A R-410A R-410A
Refrigerant charge (lb-oz)
System 1 12-8 12-0 11-0
System 2 - - -

AHRI HEATING PERFORMANCE

Heating model N05 N07 N09 N05 N07 N09 N07 N09 N13
Heat input (K Btu) 60 80 120 60 80 120 80 120 160
Heat output (K Btu) 49 65 97 49 65 97 65 97 129
AFUE % - - - - - ­Steady state efficiency (%) 81.5 81 81 81.5 81 81 81 81 80.5
No. burners 4 4 6 4 4 6 4 6 8
No. stages 2

1

2

2

2

2
Temperature Rise Range (ºF) 20-50°F 25-65°F 35-80°F 20-50°F 25-65°F 35-80°F 25-65°F 35-80°F 45-75°F
Gas Limit Setting (ºF) 200°F 235°F 290°F 200°F 235°F 290°F 235°F 290°F 240°F
Gas piping connection (in.) 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4 3/4

DIMENSIONS (inches)

Length 89 89 89
Width 59 59 59
Height 42 42 42

OPERATING WT. (lbs.) 867 880 867

COMPRESSORS

Type Recip Recip Recip
Quantity 1 1 1
Unit Capacity Steps (%) 100 100 100

CONDENSER COIL DATA

Face area (Sq. Ft.) 11.9 11.9 11.9
Rows 1 1 1
Fins per inch 23 23 23
Tube diameter (in./MM) .98/25 .98/25 .71/18 - .98/25
Circuitry Type 2-pass Microchannel 2-pass Microchannel 2-pass Microchannel

EVAPORATOR COIL DATA

Face area (Sq. Ft.) 10.56 10.56 10.56
Rows 3 3 4
Fins per inch 15 15 12
Tube diameter 0.375 0.375 0.375
Refrigerant control TXV TXV TXV

REHEAT COIL DATA

Face area (Sq. Ft.) 8.9 8.9 8.9
Rows 2 2 2
Fins per inch 15 15 15
Tube diameter 0.375 0.375 0.375
Refrigerant control Solenoid Solenoid Solenoid

Models

1

2

2

2

2

2

2

2

2

2

2

2

30 Johnson Controls Unitary Products
